Description
Rated power: 1608W Input voltage: 90 ~ 264VAC,250 ~ 370VDC Output voltage: 48V Communication protocol: PMBus protocol, optional Output current: 0 ~ 33.5A Size (mm):300X85X41
Click to download Airtac product catalog
Product Features
1. 1U low shell with a height of only 41mm(RSP-750/1000/1600/2000).
2. Built-in active PFC function, built-in DC fan forced cooling.
3. The high power density can reach 25w/in3(RSP-1600).
4. The output voltage is adjustable, the widest can reach 40~125%, and the output constant current value is adjustable (RSP-750/1600).
5. Current sharing function, parallel RSP-1000/1500/2000*4 sets, RSP-1600 * 6 sets and RSP-2400/3000*3 sets.
6. Built-in remote sensing and ON/OFF control. Built-in auxiliary output power, DC OK signal.
7. OTP alarm output signal (RSP-1600/2000).
8, optional spray moisture, protection type: short circuit/overload/overvoltage/over temperature, 5 years warranty.
