Description
Rated power: 7515W Input voltage: 3ø3W/196 ~ 305VAC or 3ø4W/340 ~ 530VAC Output voltage: 380V forced air cooling Output current: 0 ~ 22.5A Size (mm):460X211X83.5
Product Features
1, can choose water cooling/forced air cooling (RST-7K5/SHP-10K), forced air cooling (RST-15K/SHP-30K).
2. Built-in CANBus/optional PMBus/MODBus-RTU/RS-485 communication protocol (SHP).
3. Wide voltage adjustment range 1~120%(RST).
4. RST has an output parallel function of 28.5KW, and SHP can have a maximum parallel function of 120KW.
5. Output voltage and constant current programmable, built-in ON-OFF control/alarm signal.
6. DC OK signal and 12V auxiliary power output (SHP-10K/30K).
7. Protection type: short circuit/overload/over voltage/over temperature.
8 and 5 years warranty.
