Description
Rated power: 1W Input voltage (range):5V(4.5~5.5V) Input current no-load: 35mA, full load: 267mA Output voltage: 3.3V Output current: 30 ~ 300mA Efficiency (TYP.):75% Capacitive load (max):470μF Performance difference:-40 ~ +90 ℃ working temperature, longest one second short circuit protection, standard product Size (mm):12.9X10.9X7.1
Click to download Airtac product catalog
Product Features
1. SMD package has industry standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 84%.
2. Protection: short circuit, 1.5KVDC input/output isolation (3KVDC input/output isolation optional), low cost, 3 years warranty.
