Description
Series: Single group output Rated power: 8W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 392mA Output voltage: 9V Output current: 889mA Efficiency (TYP.):85% Capacitive load (maximum):680μF Size (mm):31.8X20.3X12.2
Click to download Airtac product catalog
Product Features
1. The DIP24 package has industry standard pins.
2.8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required.
3. Comply with BS EN/EN55032 radiation A level, no additional parts are required, and the efficiency is as high as 86%.
4. Protection function: short circuit (continuous)/overload/overvoltage/undervoltage lockout, remote on/off control (optional),3KVdc input/output isolation, 3 years warranty.
