Description
Series: Single group output Rated power: 3W Input voltage (range):5V(4.5~9V) Input current no-load: 15mA, full load: 779mA Output voltage: 5V Output current: 600mA Efficiency (TYP.):78% Capacitive load (maximum):2200 μF Size (mm):31.8X20.3X10.2
Click to download Airtac product catalog
Product Features
1. The DIP24 package has industry standard pins.
2, 2:1 wide input range, working temperature range -40~90 ℃, no minimum load.
3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 87%.
4. Protection: short circuit (continuous)/overload/input undervoltage, 3KVDC input/output isolation, 3 years warranty.
