Description
Series: Single group output Rated power: 6W Input voltage (range): standard voltage 48V(36~72V) Input current no-load: 3mA, full load: 126mA Output voltage: 5V Output current: 1000mA Efficiency (TYP.):83% Capacitive load (max):4700μF Size (mm):31.8X20.3X10.2
Click to download Airtac product catalog
Product Features
1. DIP24 package, industry standard pin.
2, 2:1 wide input range, working temperature range -40~90 ℃, no minimum load.
3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 87%.
4. Protection: short circuit (continuous)/overload/input undervoltage, 3KVDC input/output isolation, 3 years warranty.
