MEAN WELL SFTN01 Series: DC-DC Unregulated Converter - SFTN01L-09SC

Description

Rated power: 1W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 30mA, full load: 260mA Output voltage: 9V Output current: 11.1 ~ 111mA Efficiency (TYP.):76% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.7X7.1

Click to download Airtac product catalog

Product Features

1. SMD package has industry standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 82%.

2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.

MEAN WELL SFTN01 Series: DC-DC Unregulated Converter - SFTN01L-09SC

Product form

Rated power: 1W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 30mA, full load: 260mA Output voltage: 9V Output current: 11.1... Read more

$13.29 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Rated power: 1W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 30mA, full load: 260mA Output voltage: 9V Output current: 11.1 ~ 111mA Efficiency (TYP.):76% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.7X7.1

    Click to download Airtac product catalog

    Product Features

    1. SMD package has industry standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 82%.

    2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
