MEAN WELL SGA12E series: Slim Wall-Mounted AC/DC Power Adapter - SGA12E07-P1J

Description

MEAN WELL SGA12E07-P1J is an SGA12E single-output AC/DC adapter with a two-pin European mains plug and a center-positive P1J DC plug on a fixed cable. The catalogue specifies 7.5 VDC, 1.6 A and 12 W maximum rated output. Its fully enclosed Class II construction has no protective-earth pin. Apply the output-current, power and temperature limits together.

Product Datasheet

Download MEAN WELL SGA12E Datasheet (PDF)

The SGA12E section is on PDF pages 5, 6, 7. Refer to the complete mechanical drawings and notes when planning installation.

Model and Configuration

Complete order number SGA12E07-P1J.
Safety model identifier SGA12E07.
Product type Slim Wall-Mounted AC/DC Power Adapter.
Mains plug / electrical class Two-pin European plug; Class II, without protective earth.
No-load input power <0.075 W.
Energy-efficiency statement Energy efficiency Level VI; EU ErP and Code of Conduct Version 5, as stated in the 2015-12-17 catalogue.
Case Fully enclosed 94V-0 flame-retardant plastic case.
Limited power source LPS, as stated in the applicable catalogue.

The catalogue lists applications in consumer electronics, telecommunications, office facilities and industrial equipment.

The complete order number identifies the European input-plug version and the standard P1J output termination.

Model-Specific DC Output

Nominal output 7.5 VDC.
Rated output current 1.6 A.
Current range 0–1.6 A.
Catalogue-rated output power, maximum 12 W.
Ripple and noise, maximum 50 mVp-p.
Voltage tolerance ±5.0%.
Line regulation ±1.0%.
Load regulation ±5.0%.
Efficiency, typical 83%.

The current rating and maximum power rating are both limits; observe both when selecting the load. The DC voltage set point is measured at the plug terminals at 50% load.

Input and Timing

AC input range 90–264 VAC.
Input frequency 47–63 Hz.
AC input current 0.5 A at 115 VAC; 0.25 A at 230 VAC.
Inrush current, maximum 30 A at 115 VAC; 60 A at 230 VAC.
Leakage current, maximum 0.25 mA at 240 VAC.
Set-up / rise / hold-up 1300 / 50 / 12 ms at 230 VAC and at 115 VAC, full load.

Protection

Short circuit / overload 110–200% of rated output power; hiccup operation with automatic recovery after the fault condition is removed.
Overvoltage 110–140% of rated output voltage; clamping by a Zener diode, output short.

Cooling and Environmental Limits

Working ambient −20 to +60°C, subject to derating.
Temperature/load curve 100% load from −20°C to 40°C; decrease along the plotted line to 50% load at 60°C.
Input/load curve 100% load across 90–264 VAC in the static-characteristics graph; temperature limits still apply.
Working humidity 20–90% RH, non-condensing.
Storage temperature / humidity −20 to +85°C; 10–95% RH.
Temperature coefficient ±0.03%/°C over 0–40°C.
Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis.

The maximum operating temperature does not permit full output at every ambient temperature. Use the catalogue derating curves when planning the installation.

Safety, Isolation and EMC

Catalogue safety listing TUV EN60950-1 approval is listed in the 2015-12-17 specification table.
Input/output withstand 4242 VDC.
Insulation resistance Input/output: 100 MΩ at 500 VDC, 25°C and 70% RH.
EMC emission EN55022 Class B; EN61000-3-2 and -3-3, as listed in this catalogue.
EMC immunity EN61000-4-2, -4-3, -4-4, -4-5, -4-6, -4-8 and -4-11; light-industry level, criterion A, as listed in this catalogue.

These standards describe the cited catalogue revision. Confirm the applicable approvals and markings for the supplied unit and destination. The final equipment must be evaluated again for compliance with the applicable EMC directives in its intended configuration.

Dimensions and Output Connections

Dimensions in the specification table 62.2 × 27.4 × 39.5 mm, L × W × H.
Corresponding mechanical drawing Length 62.2 mm; width 27.4 mm; the P1J version has a marked height of 39.7 mm. AC pins project beyond the marked housing height; use the full drawing for installation clearance.
Output plug P1J, tuning-fork type; 2.1 mm inside diameter × 5.5 mm outside diameter × 11 ±0.5 mm insertion length.
Polarity C+: center/inside positive, outside negative.
Fixed output cable UL2468, 18 AWG; 1000 mm with +150/−0 mm length tolerance.

Match the equipment socket to the stated dimensions and center-positive polarity. The cable and P1J termination described here are the configuration of this order number.

Options and Installation

Alternative plugs and cables Other types are available by customer request, as stated in the catalogue.
Standard option scope P1J is the standard cable termination; USB Type A is a separate standard 5 V configuration.

Choose the specified output configuration when ordering. Alternative termination details require a defined order specification; they do not change the electrical output limits.

Follow the mechanical drawings and the manufacturer installation instructions for the supplied configuration.

Reliability and Packing

Catalogue life reference 3 years at 100% load, 40°C and 8 hours of operation per day.
Minimum MTBF 265 thousand hours, MIL-HDBK-217F at 25°C.
Manufacturer warranty 3 years, as stated in the applicable catalogue.
Catalogue single-unit weight 100 g; explicit per-unit packing reference, not a measured shipping-package weight.
Carton packing 90 pieces / 10 kg / carton.

Measurement Conditions and Datasheet

General measurement conditions Unless otherwise specified: 230 VAC input, rated load, 25°C and 70% RH.
DC voltage measurement At the plug terminals and 50% load.
Ripple/noise method 20 MHz bandwidth; a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors.
Voltage-tolerance scope Includes set-up tolerance, line regulation and load regulation.
Line regulation measurement From low input line to high input line at rated load.
Load regulation measurement From 10% to 100% rated load.
Applicable catalogue revision 2015-12-17; combined PDF pages 5, 6, 7.
