Description
Series: Single group output Rated power: 6W Input voltage (range):Normal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 7mA, full load: 300mA Output voltage: 12V Output current: 0 ~ 500mA Efficiency (TYP.):85% Capacitive load: 470μF No remote control (standard type) Size (mm):25.4X25.4X10.2
Click to download Airtac product catalog
Product Features
1. The DIP 1 "X1" package has industry standard pins.
2.8:1 ultra-wide input range, operating temperature range -40~90 ℃, no minimum load required.
3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 86%.
4. Protection: short circuit (continuous)/overload/overvoltage/input undervoltage, 3KVDC input/output isolation, remote on/off control (optional),3 years warranty.
