Description
Series: Single group output Rated power: 10W Input voltage (range):24V(18~36V) Input current no-load: 25mA, full load: 478mA Output voltage: 15V Output current: 666mA Efficiency (TYP.):88% Capacitive load (maximum):690μF Size (mm):25.4X25.4X10.2
Click to download Airtac product catalog
Product Features
1. The DIP 1 "X1" package has industry standard pins.
2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load.
3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%.
4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
