Description
Series: Single group output Rated power: 20W Input voltage (range):48V(18~75V) Input current no-load: 8mA, full load: 468mA Output voltage: 15V Output current: 0 ~ 1330mA Efficiency (TYP.):88% Capacitive load (max):1300μF Size (mm):25.4X25.4X10.2
Click to download Airtac product catalog
Product Features
1. The DIP 1 "X1" package has industry standard pins.
2.4:1 ultra-wide input range, operating temperature range -40~85 ℃, no minimum load required.
3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 89%.
4. Protection: short circuit (continuous)/overload/overvoltage/input undervoltage, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
