MEAN WELL SMA01 Series: DC-DC Unregulated Converter - SMA01N-09

Description

DC output voltage: 9V Current output: 0 ~ 110mA Efficiency: 75% Rated power: 1W Input voltage: 21.6~26.4V Input normal voltage: 24V Input DC current full load: 57mA, no load: 11mA Size (mm):12.7X10.16X7.62

Click to download Airtac product catalog

Product Features

1. 1500VDC input/output isolation, 3000VDC input/output isolation (optional).

2. Operating temperature range -40 ~ +85 ℃, no derating, internal SMD technology, built-in EMI filter circuit, natural cooling.

3. Insulated plastic shell, double-row package, industry standard pin arrangement, 100% full load aging, low cost, high reliability, 2 years warranty.

MEAN WELL SMA01 Series: DC-DC Unregulated Converter - SMA01N-09

Product form

DC output voltage: 9V Current output: 0 ~ 110mA Efficiency: 75% Rated power: 1W Input voltage: 21.6~26.4V Input normal voltage:... Read more

$11.57 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    DC output voltage: 9V Current output: 0 ~ 110mA Efficiency: 75% Rated power: 1W Input voltage: 21.6~26.4V Input normal voltage: 24V Input DC current full load: 57mA, no load: 11mA Size (mm):12.7X10.16X7.62

    Click to download Airtac product catalog

    Product Features

    1. 1500VDC input/output isolation, 3000VDC input/output isolation (optional).

    2. Operating temperature range -40 ~ +85 ℃, no derating, internal SMD technology, built-in EMI filter circuit, natural cooling.

    3. Insulated plastic shell, double-row package, industry standard pin arrangement, 100% full load aging, low cost, high reliability, 2 years warranty.
