MEAN WELL SPA01W8 series: DC-DC regulator converter - SPA01W8-03

Description

Series: Single group output Rated power: 1W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 3mA, full load: 54mA Output voltage: 3.3V Output current: 0 ~ 300mA Efficiency (TYP.):77% Capacitive load (maximum):220μF Size (mm):17.4X7.75X11.1

Click to download Airtac product catalog

Product Features

1. SIP6 package has industry standard pins, 8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +95 ℃, no minimum load required.

2. Comply with BS EN/EN55032 radiation A level, no additional parts are required, and the efficiency is as high as 80%.

3. Protection: short circuit (continuous)/overload/undervoltage lockout, 1.5KVdc input/output isolation, 3 years warranty.

MEAN WELL SPA01W8 series: DC-DC regulator converter - SPA01W8-03

Product form

Series: Single group output Rated power: 1W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 3mA, full load: 54mA Output voltage:... Read more

$16.29 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Single group output Rated power: 1W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 3mA, full load: 54mA Output voltage: 3.3V Output current: 0 ~ 300mA Efficiency (TYP.):77% Capacitive load (maximum):220μF Size (mm):17.4X7.75X11.1

    Click to download Airtac product catalog

    Product Features

    1. SIP6 package has industry standard pins, 8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +95 ℃, no minimum load required.

    2. Comply with BS EN/EN55032 radiation A level, no additional parts are required, and the efficiency is as high as 80%.

    3. Protection: short circuit (continuous)/overload/undervoltage lockout, 1.5KVdc input/output isolation, 3 years warranty.
