MEAN WELL SPAN02W8 series: DC-DC regulator converter - SPAN02W8-15

Description

Series: Single group output Rated power: 2W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 12mA, full load: 50mA Output voltage: 15V Output current: 0 ~ 134mA Efficiency (TYP.):83% Capacitive load (max):134μF Size (mm):21.8X9.2X11.1

Click to download Airtac product catalog

Product Features

1. SIP8 package has industry standard pins, 8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load.

2. Comply with BS EN/EN55032 Radiation Class A, no additional parts are required, and the efficiency is as high as 83%.

3. Protection: short circuit (continuous)/overload/undervoltage lockout, 3KVdc input/output isolation, remote on/off, 3-year warranty.

MEAN WELL SPAN02W8 series: DC-DC regulator converter - SPAN02W8-15

Product form

Series: Single group output Rated power: 2W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 12mA, full load: 50mA Output voltage:... Read more

$18.00 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Single group output Rated power: 2W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 12mA, full load: 50mA Output voltage: 15V Output current: 0 ~ 134mA Efficiency (TYP.):83% Capacitive load (max):134μF Size (mm):21.8X9.2X11.1

    Click to download Airtac product catalog

    Product Features

    1. SIP8 package has industry standard pins, 8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load.

    2. Comply with BS EN/EN55032 Radiation Class A, no additional parts are required, and the efficiency is as high as 83%.

    3. Protection: short circuit (continuous)/overload/undervoltage lockout, 3KVdc input/output isolation, remote on/off, 3-year warranty.
