MEAN WELL SPB09 Series: DC-DC Regulated Converter - SPB09C-15

Description

Series: Single group output Rated power: 9W Input voltage (range):48V(36~75V) Input current no-load: 5mA, full load: 213mA Output voltage: 15V Output current: 0 ~ 600mA Efficiency (TYP.):88% Capacitive load (maximum):100μF Size (mm):24X9.6X11.2

Click to download Airtac product catalog

Product Features

1. SIP8 package has industry standard pins, 2:1 ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load.

2. Efficiency up to 89%, protection: short circuit (continuous)/overload/low voltage input, 1.5KVDC input/output isolation, remote on/off, 9V model available (optional),3 years warranty.

MEAN WELL SPB09 Series: DC-DC Regulated Converter - SPB09C-15

Product form

Series: Single group output Rated power: 9W Input voltage (range):48V(36~75V) Input current no-load: 5mA, full load: 213mA Output voltage: 15V... Read more

$40.16 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Single group output Rated power: 9W Input voltage (range):48V(36~75V) Input current no-load: 5mA, full load: 213mA Output voltage: 15V Output current: 0 ~ 600mA Efficiency (TYP.):88% Capacitive load (maximum):100μF Size (mm):24X9.6X11.2

    Click to download Airtac product catalog

    Product Features

    1. SIP8 package has industry standard pins, 2:1 ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load.

    2. Efficiency up to 89%, protection: short circuit (continuous)/overload/low voltage input, 1.5KVDC input/output isolation, remote on/off, 9V model available (optional),3 years warranty.
