MEAN WELL SPB09W8 series: DC-DC regulator converter - SPB09W8-15

Description

Series: Single group output Rated power: 9W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 431mA Output voltage: 15V Output current: 0 ~ 600mA Efficiency (TYP.):86% Capacitive load (maximum):220μF Size (mm):24X9.6X11.2

Click to download Airtac product catalog

Product Features

1. SIP8 package has industry standard pins, 8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +85 ℃, no minimum load.

2. Efficiency up to 87%, protection: short circuit (continuous)/overload/undervoltage lock, 1.5KVdc input/output isolation, remote on/off, 3 years warranty.

MEAN WELL SPB09W8 series: DC-DC regulator converter - SPB09W8-15

Product form

Series: Single group output Rated power: 9W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 431mA Output voltage:... Read more

$31.71 Incl. VAT

    • Guaranteed secure & safe checkout.

      shop pay

    Description

    Series: Single group output Rated power: 9W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 431mA Output voltage: 15V Output current: 0 ~ 600mA Efficiency (TYP.):86% Capacitive load (maximum):220μF Size (mm):24X9.6X11.2

    Click to download Airtac product catalog

    Product Features

    1. SIP8 package has industry standard pins, 8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +85 ℃, no minimum load.

    2. Efficiency up to 87%, protection: short circuit (continuous)/overload/undervoltage lock, 1.5KVdc input/output isolation, remote on/off, 3 years warranty.
