SPBW06G-03 — Regulated SIP DC/DC converter

The MEAN WELL SPBW06G-03 is an isolated, regulated single-output SIP8 DC/DC converter in the 6 W SPBW06/DPBW06 family. It accepts 18–75 V DC (48 V nominal) and provides 3.3 V DC, with 0–1500 mA. The 3.3 V version is limited to 4.95 W by its 1500 mA current rating. Remote ON/OFF control is provided; observe the specified control method, external EMC components and temperature derating.

Download MEAN WELL SPBW06 Datasheet (PDF)
Download MEAN WELL EMI Testing Guidance (PDF)

SPBW06 electrical, environmental, mechanical and packing specifications: PDF pages 13–18.

Electrical specifications

Model and output configuration SPBW06G-03; isolated, regulated single-output DC/DC converter with industry-standard SIP8 pinout.
Output voltage 3.3 V DC.
Output current range 0–1500 mA. No minimum load is required.
Output power and current limit This is a 6 W series. The selected 3.3 V output is limited to 1500 mA, corresponding to 4.95 W calculated from voltage × current, before thermal derating.
Nominal input and operating range 48 V DC nominal; 18–75 V DC operating range, 4:1 range family.
Input current 3 mA at no load; 155 mA at full load under the general measurement conditions.
Typical efficiency 82% at nominal input and rated load under the general measurement conditions.
Series efficiency capability The SPBW06/DPBW06 family offers efficiency up to 89% across its models; use the selected model’s typical value above.
Maximum capacitive load 4700 µF.
Input surge limit 100 V DC for 100 ms maximum.
Input filter and recommended fuse Internal input capacitor; a 630 mA fast-acting input fuse is recommended.
Internal power dissipation 500 mW.
Output voltage accuracy ±1.5%.
Ripple and noise 100 mVp-p. Measured at 20 MHz using a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors.
Line regulation ±0.2%, measured from low line to high line at rated load.
Load regulation ±0.5%, measured from 0% to 100% rated load.
Switching frequency 580 kHz typical.
General measurement conditions Unless otherwise specified: nominal 48 V input, rated load, 25°C and 70% RH ambient.

Protection, control and thermal operation

Short-circuit protection Continuous short-circuit protection with automatic recovery.
Overload protection Automatic recovery after the fault is removed.
Remote control Power ON: leave R.C. open at high impedance. Power OFF: supply 2–4 mA to the R.C. pin, referenced to −Vin. The recommended circuit applies this current through a 1 kΩ series resistor. If remote control is unused, leave R.C. open.
Operating and case temperature −40 to +85°C ambient, subject to derating; case temperature +100°C maximum.
Cooling and load derating Free-air natural convection. For this 3.3 V DC model, the curve shows 100% load from −40 to +61°C and 50% at +85°C. Do not extend the specified operating range beyond +85°C.
Working humidity 20–90% RH, non-condensing.
Storage conditions −55 to +125°C; 10–95% RH, non-condensing.
Temperature coefficient 0.03%/°C over 0 to +65°C.
Soldering conditions At 1.5 mm from the case: 1–3 seconds at 260°C maximum.
Vibration 10–500 Hz, 2 G; 10 minutes per cycle, for 60 minutes along each of the X, Y and Z axes.

Isolation, EMC and reliability

Applicable safety approvals EAC TP TC 020/2011 approved. EAC TP TC 004 also applies to this 48 V input type.
Isolation withstand voltage Input to output: 1.5 kV DC.
Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH.
Typical isolation capacitance 50 pF.
EMC emission BS EN/EN 55032 (CISPR 32): radiated Class A/B with external components. The conducted-emission entry is N/A.
ESD immunity BS EN/EN 61000-4-2, Level 2: ±8 kV air and ±4 kV contact.
Radiated RF immunity BS EN/EN 61000-4-3, Level 2: 3 V/m.
EFT and surge immunity BS EN/EN 61000-4-4: Level 1, 0.5 kV; BS EN/EN 61000-4-5: Level 1, 0.5 kV line to line.
Conducted RF and magnetic-field immunity BS EN/EN 61000-4-6: Level 2, 3 V e.m.f.; BS EN/EN 61000-4-8: Level 2, 3 A/m.
MTBF 1,850 Khrs, MIL-HDBK-217F at 25°C.
Manufacturer warranty 3 years.
EMC suggestion circuit Use the catalog’s BS EN/EN 55032 external-component circuit. L1 is in the positive input lead. C1 is across the input before L1, and C2 is across the module input after L1. C4 links module-side +Vin to +Vout; C3 links −Vin to −Vout. All listed capacitors are ceramic.
Class A external components C1 = 1 µF / 100 V; C2 = N.C.; C3 = C4 = 150 pF / 2 kV; L1 = 10 µH.
Class B external components C1 = 2.2 µF / 100 V; C2 = 2.2 µF / 100 V; C3 = C4 = 1500 pF / 2 kV; L1 = 10 µH.

Mechanical details, installation and packing

Dimensions and material 21.8 × 9.2 × 11.1 mm (L × W × H); catalog reference 0.86 × 0.36 × 0.44 inch. Non-conductive black plastic case, UL 94 V-0 rated.
Pin assignment Pin 1: −Vin; pin 2: +Vin; pin 3: R.C.; pin 5: N.C.; pin 6: +Vout; pin 7: −Vout; pin 8: N.C. The bottom-view drawing identifies the pin numbers; pin position 4 is absent.
Lead and mounting geometry Body stand-off: 0.5 mm. Lead extension: 4.1 mm; lead cross-section references: 0.5 × 0.3 mm. Pin pitch: 2.54 mm; total pin span: 17.8 mm. Bottom-view position references are 2 mm and 3.5 mm.
Mechanical tolerances General dimensions x.x: ±0.5 mm; pin pitch: ±0.05 mm.
Typical applications Telecom and datacom systems, wireless networks, industrial control, instruments, analyzers, detectors, data switches and distributed power architectures.
Per-unit mass 4.5 g as the catalog packing reference per unit, not a measured net or shipping weight.
Packing quantities and gross masses 14 pieces per tube; tube gross weight 81.5 g. A carton contains 147 tubes / 2,058 pieces and has a gross weight of 13.98 kg.
Packaging dimensions Tube length: 330 mm; the tube-profile drawing marks 11.6, 10.4, 12.8 and 21 mm. Carton: 390.9 × 284.8 × 175.7 mm (L × W × H). These are packaging dimensions.

Installation and system verification

Complete-system EMC verification Verify EMC with the converter installed in the final equipment and connected to a representative load. Wiring, assembly and the application affect the result. Follow the model's specified EMC conditions and any required external components; the linked EMI testing guidance does not certify the finished equipment.
