Description
Rated power: 201.6W Function: built-in DC OK effective signal and redundancy function, note: standard Input voltage: 90 ~ 264VAC,127 ~ 370VDC Output voltage: 24V Output current: 0 ~ 8.4A Size (mm):194X55X26
Product Features
1. International universal full range input: 90 ~ 264VAC, can withstand 300VAC surge input up to 5S.
2. Half glue filling, dustproof, anti-vibration (except UHP-2500), slender, low height.
3. Built-in active PFC function, 150% peak load capacity (100ms,UHP-200 ~ 500).
4. Fanless design, natural air cooling, adjustable output voltage and constant current value (1000W and above).
5. Protection type: short circuit/overload/overvoltage/overtemperature.
6. PMBus and CANBus communication protocols (UHP-1500/2500) can be selected.
7. Redundant function (UHP-R series)/remote control switch (1000W and above),DC OK/LED power indication.
8.3-year warranty (UHP-200 ~ 750) and 5-year warranty (UHP-1000/1500/2500).
