Description
Metal shell type Output voltage range (UVW):380V max, line-to-line 0~268V PWM adjustable, suitable for three-phase 200~240V motors Rated output current: 1.4A Peak Output Current: 2.8A for 5S Output power: 350W Input voltage: 90 ~ 264VAC Size (mm):146X62X31
Product Features
1.90 ~ 264VAC input and built-in PFC(VFD-200C/350C/750C/250P/350P/-230).
2.20 ~ 55VDC input (VFD-150P/250P/350P-48).
3. The drive efficiency is as high as 93%, and the whole series is designed without fan.
4, can provide instant 200, peak power up to 5 seconds.
5. With a variety of detection functions: current, DC voltage, temperature detection.
6. It is suitable for driving BLDC brushless motors, and can be used in HVAC systems, exhaust equipment, water pumps, air conditioners, medical care, power tools, AVG, tool machines, fitness equipment, home appliances, etc.
7, -30 ~ +70 ℃ wide working temperature, can choose another control card.
8, through EN61800-5/3 certification, 3 years warranty.
