Description
Output default current: 2100mA Output power rating: 100W Output constant current range: 27~56V Output full power current range: 1750 ~ 2780mA Output open circuit voltage (maximum):60V Output current adjustment range: 875 ~ 2780mA Input voltage: 90 ~ 305VAC,127 ~ 431VDC IP rating: IP67 Function: Constant power output value can be adjusted by internal potentiometer & three-in-one dimming function (0 ~ 10Vdc,10V PWM signal and resistance), standard product AC input line: AC input line with connector Size (mm):ø130X56
Click to download Airtac product catalog
Product Features
1. Constant power design.
2, in the current range of 70% ~ 100% can be full power output.
3. Wide input range: 100 ~ 305VAC.
4. Built-in active PFC function, metal shell design meets IP67.
5. Output dimming line isolation design, in line with the latest regulations.
6. AC input line version with connector, which can be installed flexibly.
7. Optional functions: output internal potentiometer adjustment, three-in-one dimming.
8. Protection type: short circuit/over current/over voltage/over temperature, 5 years warranty.
