Description
Output voltage: 12V Output load current range: 0 ~ 10A Rated power: 120W Peak current (5 seconds):20A Peak power (5 seconds):240W Voltage adjustment range: 12~15V Input AC voltage range: 85 ~ 305VAC Input DC voltage range: 80 ~ 431VDC (50% load reduction 80VDC) Output Terminal Type: Lever Actuated Size (mm):30X125.2X116
Click to download Airtac product catalog
Product Features
1.85 ~ 305Vac input (277Vac available), multi-domain global certification (ITE 62368-1, Industrial 61558-1/-2-16,61010) and Marine DNV,SEMI47,CID2 HazLoc certification.
2, 30mm ultra-thin width, efficiency as high as 94%,R.C no-load power consumption of 0.9W ~ 1W,200 peak power, 600 transient peak current, built-in constant current limiting circuit.
3. Protection: short circuit/overload/overvoltage/overtemperature, fanless design, natural air cooling, overvoltage category III (OVC III),-40 ~ +85 ℃ wide working temperature range (>+60 ℃ reduction).
4. The working height can reach 5000 meters, with built-in remote switch control and DC OK relay contacts, ultra-low surge current <6 ~ 15A, built-in ORing FET, and tool-free terminal blocks (LA type).
5. Protective coating, can be installed on TS-35/7.5 or 15 DIN rail, 5 years warranty.
