Description
Output voltage: 48V Output current: 0 ~ 10A Output power rating: 480W economic type Output voltage adjustment range: 48~55V Input AC voltage range: 85 ~ 264VAC Input DC voltage range: 120 ~ 370VDC Size (mm):48X125.2X125
Click to download Airtac product catalog
Product Features
1.85 ~ 264Vac input, built-in PFC, multi-domain global certification (ITE 62368-1, industrial 61558-1/-2-61010),48mm ultra-thin width.
2. Efficiency up to 96%, no-load power consumption <1.2W, built-in constant current limiting circuit, up to 1920W(3 1) when used in parallel, protection: short circuit/overload/overvoltage/overtemperature, fanless design, natural air cooling.
3. Overvoltage category III (OVC III),-40 ~ +70 ℃ wide working temperature range (>+50 ℃ reduction), working height up to 5000 meters.
4. Built-in DC OK relay contact, can be installed on TS-35/7.5 or 15 DIN rail, 3 years warranty.
