Description
Output voltage: 48V Output current: 0 ~ 20A Output power rating: 960W economic type Output voltage adjustment range: 48~55V Input AC voltage range: 180 ~ 264VAC Input DC voltage range: 254.5 ~ 370VDC Size (mm):96X125.2X132
Click to download Airtac product catalog
Product Features
1.180 ~ 264Vac input, built-in PFC, multi-domain global certification (ITE 62368-1, industrial 61558-1/-2-61010),96mm ultra-thin width.
2. The efficiency is as high as 95.5, the no-load power consumption is 3.9W, the built-in constant current limiting circuit is as high as 3840W(3 1) when used in parallel, the protection: short circuit/overload/overvoltage/overtemperature, no fan design, natural air cooling.
3. Overvoltage category III (OVC III),-40 ~ +70 ℃ wide working temperature range (>+50 ℃ reduction), working height up to 5000 meters.
4. Built-in DC OK relay contact, can be installed on TS-35/7.5 or 15 DIN rail, 3 years warranty.
