Description
Output open circuit voltage: 60V Output default current: 900mA Output current adjustment range (via ETS software):0.9 ~ 1.7A Output constant current region: 9~54V Output power rating: 60W Input voltage: 100 ~ 305VAC,155 ~ 400VDC Function: Built-in KNX interface, with independent side cover (independent), standard Size (mm):176 X45X 32,136X45X32
Click to download Airtac product catalog
Product Features
1. Output current gear is set through ETS database.
2. No stroboscopic design, in line with CE ErP directive.
3. Built-in KNX interface, support KNX data encryption function.
4. Meet emergency lighting (EL) applications.
5. The minimum dimming level is 0.5%.
6. Built-in constant illumination output (CLO) function (ETS provides three preset L70/L80/L90 and custom).
7. Independent KNX push dimming interface is built in.
8 and 5 years warranty.
