Description
Rated output voltage: L type Output current rating (default):350mA Output constant current range: 32.4~54V Output power rating: 18.9W Output open circuit voltage (maximum):60V Input voltage: 90 ~ 305VAC IP rating: IP67 Function: fixed output current, three-in-one dimming function (1 ~ 10Vdc,10V PWM signal and resistance), standard product Size (mm):95X63X30
Click to download Airtac product catalog
Product Features
1. Constant current mode output (XLG-20).
2. Constant power mode output (XLG-25 ~ 320).
3. Full power output in 70% ~ 100% constant power mode.
4. Wide input range: 100 ~ 305VAC.
5. Metal shell, IP67 protection grade; Built-in active PFC,Class 2 power supply (<100W).
6. 6KV/4KV lightning protection (10KV/6KV optional).
7. The Indian version (EESL) has input overvoltage protection (IOVP).
8. Protection type: short circuit/over current/over voltage/over temperature; 5 years warranty.
