Description
Output voltage rating (default):1400mA Output power rating: 239.4W Output constant current range: 90~171V Output full power current range: 1400 ~ 2100mA Output open circuit voltage (maximum):186V Input voltage: 100 ~ 305VAC,142 ~ 431VDC Indian version (input overvoltage protection on request) Function: The output current value can be adjusted by internal potentiometer & three-in-one dimming function (0 ~ 10Vdc,10V PWM signal and resistance), standard product Size (mm):219X63X35.5
Product Features
1. Constant current mode output (XLG-20).
2. Constant power mode output (XLG-25 ~ 320).
3. Full power output in 70% ~ 100% constant power mode.
4. Wide input range: 100 ~ 305VAC.
5. Metal shell, IP67 protection grade; Built-in active PFC,Class 2 power supply (<100W).
6. 6KV/4KV lightning protection (10KV/6KV optional).
7. The Indian version (EESL) has input overvoltage protection (IOVP).
8. Protection type: short circuit/over current/over voltage/over temperature; 5 years warranty.
