HLG Series: Constant Current & Constant Voltage (C.C. + C.V.) LED Driver

Show previous products

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-42A

  HLG-600H-42A LED Driver HLG-600H-42A is a MEAN WELL HLG-600H metal-case, Class I LED driver with 42 V DC rated output, 14.3 A rated current and 600.6 W rated power. It provides constant-voltage and constant-current operation with a 21–42 V constant-current region. Internal potentiometer adjustment. IP65 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-42A; Internal potentiometer adjustment Rated output 42 V DC; 14.3 A; 600.6 W Constant-current region 21–42 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 250 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Current adjustment 7.1–14.3 A by the internal potentiometer; do not exceed the rated output envelope. Voltage adjustment 35.7–44.1 V by the internal potentiometer. Efficiency 96% typical at 230 VAC; 96% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 46–50 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. Type HL compliance of A/AB versions requires built-in installation consideration in the final equipment. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP65 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Weather protection This IP65 model must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-36A

  HLG-600H-36A LED Driver HLG-600H-36A is a MEAN WELL HLG-600H metal-case, Class I LED driver with 36 V DC rated output, 16.7 A rated current and 601.2 W rated power. It provides constant-voltage and constant-current operation with a 18–36 V constant-current region. Internal potentiometer adjustment. IP65 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-36A; Internal potentiometer adjustment Rated output 36 V DC; 16.7 A; 601.2 W Constant-current region 18–36 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 250 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Current adjustment 8.3–16.7 A by the internal potentiometer; do not exceed the rated output envelope. Voltage adjustment 30.6–37.8 V by the internal potentiometer. Efficiency 95.5% typical at 230 VAC; 95.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 39.5–43.5 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. Type HL compliance of A/AB versions requires built-in installation consideration in the final equipment. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP65 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Weather protection This IP65 model must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-30A

  HLG-600H-30A LED Driver HLG-600H-30A is a MEAN WELL HLG-600H metal-case, Class I LED driver with 30 V DC rated output, 20 A rated current and 600 W rated power. It provides constant-voltage and constant-current operation with a 15–30 V constant-current region. Internal potentiometer adjustment. IP65 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-30A; Internal potentiometer adjustment Rated output 30 V DC; 20 A; 600 W Constant-current region 15–30 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 200 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Current adjustment 10–20 A by the internal potentiometer; do not exceed the rated output envelope. Voltage adjustment 25.5–31.5 V by the internal potentiometer. Efficiency 95% typical at 230 VAC; 95% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 32.5–36.5 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. Type HL compliance of A/AB versions requires built-in installation consideration in the final equipment. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP65 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Weather protection This IP65 model must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-24A

  HLG-600H-24A LED Driver HLG-600H-24A is a MEAN WELL HLG-600H metal-case, Class I LED driver with 24 V DC rated output, 25 A rated current and 600 W rated power. It provides constant-voltage and constant-current operation with a 12–24 V constant-current region. Internal potentiometer adjustment. IP65 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-24A; Internal potentiometer adjustment Rated output 24 V DC; 25 A; 600 W Constant-current region 12–24 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 150 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Current adjustment 12.5–25 A by the internal potentiometer; do not exceed the rated output envelope. Voltage adjustment 20.4–25.2 V by the internal potentiometer. Efficiency 95% typical at 230 VAC; 95% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 26–30 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. Type HL compliance of A/AB versions requires built-in installation consideration in the final equipment. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP65 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Weather protection This IP65 model must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-20A

  HLG-600H-20A LED Driver HLG-600H-20A is a MEAN WELL HLG-600H metal-case, Class I LED driver with 20 V DC rated output, 28 A rated current and 560 W rated power. It provides constant-voltage and constant-current operation with a 10–20 V constant-current region. Internal potentiometer adjustment. IP65 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-20A; Internal potentiometer adjustment Rated output 20 V DC; 28 A; 560 W Constant-current region 10–20 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 150 mVp-p Voltage tolerance ±1.5%, including set-up, line and load regulation Line / load regulation ±0.5% / ±1% Current adjustment 14–28 A by the internal potentiometer; do not exceed the rated output envelope. Voltage adjustment 17–21 V by the internal potentiometer. Efficiency 94.5% typical at 230 VAC; 94.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 22–26 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. Type HL compliance of A/AB versions requires built-in installation consideration in the final equipment. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP65 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Weather protection This IP65 model must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-15A

  HLG-600H-15A LED Driver HLG-600H-15A is a MEAN WELL HLG-600H metal-case, Class I LED driver with 15 V DC rated output, 36 A rated current and 540 W rated power. It provides constant-voltage and constant-current operation with a 7.5–15 V constant-current region. Internal potentiometer adjustment. IP65 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-15A; Internal potentiometer adjustment Rated output 15 V DC; 36 A; 540 W Constant-current region 7.5–15 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 150 mVp-p Voltage tolerance ±2%, including set-up, line and load regulation Line / load regulation ±0.5% / ±1.5% Current adjustment 18–36 A by the internal potentiometer; do not exceed the rated output envelope. Voltage adjustment 12.7–15.8 V by the internal potentiometer. Efficiency 93.5% typical at 230 VAC; 93.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 16.5–20.5 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. Type HL compliance of A/AB versions requires built-in installation consideration in the final equipment. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP65 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Weather protection This IP65 model must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-12A

  HLG-600H-12A LED Driver HLG-600H-12A is a MEAN WELL HLG-600H metal-case, Class I LED driver with 12 V DC rated output, 40 A rated current and 480 W rated power. It provides constant-voltage and constant-current operation with a 6–12 V constant-current region. Internal potentiometer adjustment. IP65 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-12A; Internal potentiometer adjustment Rated output 12 V DC; 40 A; 480 W Constant-current region 6–12 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 150 mVp-p Voltage tolerance ±3%, including set-up, line and load regulation Line / load regulation ±0.5% / ±2% Current adjustment 20–40 A by the internal potentiometer; do not exceed the rated output envelope. Voltage adjustment 10.2–12.6 V by the internal potentiometer. Efficiency 92% typical at 230 VAC; 92.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 13–16 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. Type HL compliance of A/AB versions requires built-in installation consideration in the final equipment. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP65 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Weather protection This IP65 model must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-54

  HLG-600H-54 LED Driver HLG-600H-54 is a MEAN WELL HLG-600H metal-case, Class I LED driver with 54 V DC rated output, 11.2 A rated current and 604.8 W rated power. It provides constant-voltage and constant-current operation with a 27–54 V constant-current region. Fixed-output cable version. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-54; Fixed-output cable version Rated output 54 V DC; 11.2 A; 604.8 W Constant-current region 27–54 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 350 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 96% typical at 230 VAC; 96% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 59–63 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-48

  HLG-600H-48 LED Driver HLG-600H-48 is a MEAN WELL HLG-600H metal-case, Class I LED driver with 48 V DC rated output, 12.5 A rated current and 600 W rated power. It provides constant-voltage and constant-current operation with a 24–48 V constant-current region. Fixed-output cable version. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-48; Fixed-output cable version Rated output 48 V DC; 12.5 A; 600 W Constant-current region 24–48 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 250 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 96% typical at 230 VAC; 96% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 52.5–56.5 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-42

  HLG-600H-42 LED Driver HLG-600H-42 is a MEAN WELL HLG-600H metal-case, Class I LED driver with 42 V DC rated output, 14.3 A rated current and 600.6 W rated power. It provides constant-voltage and constant-current operation with a 21–42 V constant-current region. Fixed-output cable version. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-42; Fixed-output cable version Rated output 42 V DC; 14.3 A; 600.6 W Constant-current region 21–42 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 250 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 96% typical at 230 VAC; 96% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 46–50 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-36

  HLG-600H-36 LED Driver HLG-600H-36 is a MEAN WELL HLG-600H metal-case, Class I LED driver with 36 V DC rated output, 16.7 A rated current and 601.2 W rated power. It provides constant-voltage and constant-current operation with a 18–36 V constant-current region. Fixed-output cable version. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-36; Fixed-output cable version Rated output 36 V DC; 16.7 A; 601.2 W Constant-current region 18–36 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 250 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 95.5% typical at 230 VAC; 95.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 39.5–43.5 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-30

  HLG-600H-30 LED Driver HLG-600H-30 is a MEAN WELL HLG-600H metal-case, Class I LED driver with 30 V DC rated output, 20 A rated current and 600 W rated power. It provides constant-voltage and constant-current operation with a 15–30 V constant-current region. Fixed-output cable version. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-30; Fixed-output cable version Rated output 30 V DC; 20 A; 600 W Constant-current region 15–30 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 200 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 95% typical at 230 VAC; 95% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 32.5–36.5 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-24

  HLG-600H-24 LED Driver HLG-600H-24 is a MEAN WELL HLG-600H metal-case, Class I LED driver with 24 V DC rated output, 25 A rated current and 600 W rated power. It provides constant-voltage and constant-current operation with a 12–24 V constant-current region. Fixed-output cable version. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-24; Fixed-output cable version Rated output 24 V DC; 25 A; 600 W Constant-current region 12–24 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 150 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 95% typical at 230 VAC; 95% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 26–30 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-20

  HLG-600H-20 LED Driver HLG-600H-20 is a MEAN WELL HLG-600H metal-case, Class I LED driver with 20 V DC rated output, 28 A rated current and 560 W rated power. It provides constant-voltage and constant-current operation with a 10–20 V constant-current region. Fixed-output cable version. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-20; Fixed-output cable version Rated output 20 V DC; 28 A; 560 W Constant-current region 10–20 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 150 mVp-p Voltage tolerance ±1.5%, including set-up, line and load regulation Line / load regulation ±0.5% / ±1% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 94.5% typical at 230 VAC; 94.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 22–26 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-15

  HLG-600H-15 LED Driver HLG-600H-15 is a MEAN WELL HLG-600H metal-case, Class I LED driver with 15 V DC rated output, 36 A rated current and 540 W rated power. It provides constant-voltage and constant-current operation with a 7.5–15 V constant-current region. Fixed-output cable version. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-15; Fixed-output cable version Rated output 15 V DC; 36 A; 540 W Constant-current region 7.5–15 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 150 mVp-p Voltage tolerance ±2%, including set-up, line and load regulation Line / load regulation ±0.5% / ±1.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 93.5% typical at 230 VAC; 93.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 16.5–20.5 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-600H series: Constant Voltage + Constant Current LED Driver - HLG-600H-12

  HLG-600H-12 LED Driver HLG-600H-12 is a MEAN WELL HLG-600H metal-case, Class I LED driver with 12 V DC rated output, 40 A rated current and 480 W rated power. It provides constant-voltage and constant-current operation with a 6–12 V constant-current region. Fixed-output cable version. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-600H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 105–112. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-600H-12; Fixed-output cable version Rated output 12 V DC; 40 A; 480 W Constant-current region 6–12 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 150 mVp-p Voltage tolerance ±3%, including set-up, line and load regulation Line / load regulation ±0.5% / ±2% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 92% typical at 230 VAC; 92.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 15 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 7 / 3.3 / 2.9 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.95 / 0.93 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥50% load at 115/230 VAC and ≥75% load at 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 70 A; 1000 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 1 / 2 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 115–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 13–16 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Remote ON/OFF Available on all versions: ON with RC+ high (>2–5 V) or open; OFF with RC+ low (0–0.5 V) or shorted to RC−. Use the catalog circuit and signal reference. Auxiliary standby supply 5 V / 0.5 A; ±5% voltage tolerance; 100 mVp-p ripple maximum. Standby power consumption is <0.5 W at remote OFF. Remote / auxiliary leads RC+ brown; RC−/GND black; +5VSB yellow. UL2517 22 AWG × 3C; 300 ±20 mm. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: 100% load through +55°C, then derate to 60% at +70°C. The plotted ambient range starts at −40°C. The catalog gives a typical +55°C maximum ambient at rated constant current. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 126.6 mm from the drawing’s right-side inner reference and 47 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 85°C Temperature coefficient ±0.03%/°C (0–55°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 913.4 K hours, Telcordia SR-332 (Bellcore); 76.9 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 60950-1; UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; J61347-1 and J61347-2-13; EAC TP TC 004; AS/NZS 60950.1 by CB; KC 61347-1 and 61347-2-13; GB 19510.1 and GB 19510.213 apply to the optional CCC configuration; confirm the ordered approval configuration. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1 only for the optional CCC configuration; KS C 9815; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; BS EN/EN 55024; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. KS C 9815 and KS C 9547. EMC testing used a 360 × 360 × 1 mm metal plate. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. Mechanical details and connection Dimensions / case 280 × 144 × 48.5 mm (L × W × H); case 228. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 3.9 kg per unit; 4 units / 16.6 kg / 0.9 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJTW 14 AWG × 2C output cables; 300 ±20 mm. Vo+ red; Vo− black. The pairs share the driver’s total rated current and power; the rating is not per cable. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 80°C; the THD/efficiency plots are for the 48 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram.

  Read more less

  $451.46

  View options

•

  View options

  MEAN WELL HLG-480H series: Constant Voltage + Constant Current LED Driver - HLG-480H-54DX

  HLG-480H-54DX LED Driver HLG-480H-54DX is a MEAN WELL HLG-480H metal-case, Class I LED driver with 54 V DC rated output, 8.9 A rated current and 480.6 W rated power. It provides constant-voltage and constant-current operation with a 27–54 V constant-current region. Smart timer dimming by request. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-480H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 91–104. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-480H-54DX; Smart timer dimming by request Rated output 54 V DC; 8.9 A; 480.6 W Constant-current region 27–54 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 350 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 95% typical at 230 VAC; 95% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 16 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 5 / 2.45 / 2 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.97 / 0.95 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥40% load at 115, 230 and 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 35 A; 1800 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 2 / 3 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 110–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 60–70 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Smart timer By-request smart timer dimming. Adaptive proportional timing follows the supplied profile; arrange the customer schedule with MEAN WELL. The D01/D02/D03 plots are examples, not a promise that this DX order includes a particular preset. Catalog timer examples Elapsed hours from switch-on: D01 = 0–6 h 100%, 6–7 h 70%, 7–11 h 50%, 11–14 h 70%; D02 = 0–1 h 50%, 1–3 h 80%, 3–8 h 100%, 8–11 h 60%, 11–14 h 80%; D03 = 0–1.5 h 70%, 1.5–11 h 100%, 11–14 h 70%. Use the elapsed-time tables; the example clock labels contain inconsistencies. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: at 110 VAC, 100% load through +50°C; on the curve labeled above 230 VAC, 100% through +60°C. Both reach 60% at +65°C. The plotted ambient range starts at −40°C. The catalog gives a typical +60°C maximum ambient at rated constant current and 230 VAC. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 113.8 mm from the drawing’s right-side inner reference and 58 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 80°C Temperature coefficient ±0.02%/°C (0–60°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 1185.9 K hours, Telcordia SR-332 (Bellcore); 95.4 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; GB 19510.1 and GB 19510.213; EAC TP TC 004; AS/NZS IEC 61347.2.13:2013 and AS/NZS 61347.1:2016. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. ErP installation condition For the stated EU ErP compliance, install the LED power supply after a switch; do not leave it permanently connected to the mains supply. Mechanical details and connection Dimensions / case 262 × 125 × 43.8 mm (L × W × H); case 251. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 2.8 kg per unit; 4 units / 12.2 kg / 0.55 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables One SJOW 17 AWG × 2C / H05RN-F 2 × 1.0 mm² output cable in the mechanical drawings; 300 ±20 mm. Vo+ red; Vo− black. Multiple output pairs share the one driver’s total rated current and power. DX mechanical confirmation Confirm the supplied DX drawing and cable arrangement when ordering; the illustrated mechanical alternatives show the Blank/A/B/AB cable layouts. Optional accessories and ordering Optional junction box The catalog offers a junction-box option for all types, by request. Overall assembly 397.2 × 125 × 43.8 mm; the drawing shows 150 ±20 mm cables. Confirm the required option before ordering. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 75°C; the THD/efficiency plots are for the 42 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2.

  Read more less

  $350.42

  View options

•

  View options

  MEAN WELL HLG-480H series: Constant Voltage + Constant Current LED Driver - HLG-480H-48DX

  HLG-480H-48DX LED Driver HLG-480H-48DX is a MEAN WELL HLG-480H metal-case, Class I LED driver with 48 V DC rated output, 10 A rated current and 480 W rated power. It provides constant-voltage and constant-current operation with a 24–48 V constant-current region. Smart timer dimming by request. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-480H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 91–104. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-480H-48DX; Smart timer dimming by request Rated output 48 V DC; 10 A; 480 W Constant-current region 24–48 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 250 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 94.5% typical at 230 VAC; 95% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 16 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 5 / 2.45 / 2 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.97 / 0.95 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥40% load at 115, 230 and 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 35 A; 1800 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 2 / 3 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 110–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 53–63 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Smart timer By-request smart timer dimming. Adaptive proportional timing follows the supplied profile; arrange the customer schedule with MEAN WELL. The D01/D02/D03 plots are examples, not a promise that this DX order includes a particular preset. Catalog timer examples Elapsed hours from switch-on: D01 = 0–6 h 100%, 6–7 h 70%, 7–11 h 50%, 11–14 h 70%; D02 = 0–1 h 50%, 1–3 h 80%, 3–8 h 100%, 8–11 h 60%, 11–14 h 80%; D03 = 0–1.5 h 70%, 1.5–11 h 100%, 11–14 h 70%. Use the elapsed-time tables; the example clock labels contain inconsistencies. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: at 110 VAC, 100% load through +50°C; on the curve labeled above 230 VAC, 100% through +60°C. Both reach 60% at +65°C. The plotted ambient range starts at −40°C. The catalog gives a typical +60°C maximum ambient at rated constant current and 230 VAC. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 113.8 mm from the drawing’s right-side inner reference and 58 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 80°C Temperature coefficient ±0.02%/°C (0–60°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 1185.9 K hours, Telcordia SR-332 (Bellcore); 95.4 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; GB 19510.1 and GB 19510.213; EAC TP TC 004; AS/NZS IEC 61347.2.13:2013 and AS/NZS 61347.1:2016. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. ErP installation condition For the stated EU ErP compliance, install the LED power supply after a switch; do not leave it permanently connected to the mains supply. Mechanical details and connection Dimensions / case 262 × 125 × 43.8 mm (L × W × H); case 251. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 2.8 kg per unit; 4 units / 12.2 kg / 0.55 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables One SJOW 17 AWG × 2C / H05RN-F 2 × 1.0 mm² output cable in the mechanical drawings; 300 ±20 mm. Vo+ red; Vo− black. Multiple output pairs share the one driver’s total rated current and power. DX mechanical confirmation Confirm the supplied DX drawing and cable arrangement when ordering; the illustrated mechanical alternatives show the Blank/A/B/AB cable layouts. Optional accessories and ordering Optional junction box The catalog offers a junction-box option for all types, by request. Overall assembly 397.2 × 125 × 43.8 mm; the drawing shows 150 ±20 mm cables. Confirm the required option before ordering. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 75°C; the THD/efficiency plots are for the 42 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2.

  Read more less

  $350.42

  View options

•

  View options

  MEAN WELL HLG-480H series: Constant Voltage + Constant Current LED Driver - HLG-480H-42DX

  HLG-480H-42DX LED Driver HLG-480H-42DX is a MEAN WELL HLG-480H metal-case, Class I LED driver with 42 V DC rated output, 11.4 A rated current and 478.8 W rated power. It provides constant-voltage and constant-current operation with a 21–42 V constant-current region. Smart timer dimming by request. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-480H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 91–104. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-480H-42DX; Smart timer dimming by request Rated output 42 V DC; 11.4 A; 478.8 W Constant-current region 21–42 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 250 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 95% typical at 230 VAC; 95.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 16 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 5 / 2.45 / 2 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.97 / 0.95 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥40% load at 115, 230 and 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 35 A; 1800 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 2 / 3 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 110–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 46–55 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Smart timer By-request smart timer dimming. Adaptive proportional timing follows the supplied profile; arrange the customer schedule with MEAN WELL. The D01/D02/D03 plots are examples, not a promise that this DX order includes a particular preset. Catalog timer examples Elapsed hours from switch-on: D01 = 0–6 h 100%, 6–7 h 70%, 7–11 h 50%, 11–14 h 70%; D02 = 0–1 h 50%, 1–3 h 80%, 3–8 h 100%, 8–11 h 60%, 11–14 h 80%; D03 = 0–1.5 h 70%, 1.5–11 h 100%, 11–14 h 70%. Use the elapsed-time tables; the example clock labels contain inconsistencies. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: at 110 VAC, 100% load through +50°C; on the curve labeled above 230 VAC, 100% through +60°C. Both reach 60% at +65°C. The plotted ambient range starts at −40°C. The catalog gives a typical +60°C maximum ambient at rated constant current and 230 VAC. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 113.8 mm from the drawing’s right-side inner reference and 58 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 80°C Temperature coefficient ±0.02%/°C (0–60°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 1185.9 K hours, Telcordia SR-332 (Bellcore); 95.4 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; GB 19510.1 and GB 19510.213; EAC TP TC 004; AS/NZS IEC 61347.2.13:2013 and AS/NZS 61347.1:2016. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. ErP installation condition For the stated EU ErP compliance, install the LED power supply after a switch; do not leave it permanently connected to the mains supply. Mechanical details and connection Dimensions / case 262 × 125 × 43.8 mm (L × W × H); case 251. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 2.8 kg per unit; 4 units / 12.2 kg / 0.55 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJOW 17 AWG × 2C / H05RN-F 2 × 1.0 mm² output cables in the mechanical drawings; 300 ±20 mm. Vo+ red; Vo− black. Multiple output pairs share the one driver’s total rated current and power. DX mechanical confirmation Confirm the supplied DX drawing and cable arrangement when ordering; the illustrated mechanical alternatives show the Blank/A/B/AB cable layouts. Optional accessories and ordering Optional junction box The catalog offers a junction-box option for all types, by request. Overall assembly 397.2 × 125 × 43.8 mm; the drawing shows 150 ±20 mm cables. Confirm the required option before ordering. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 75°C; the THD/efficiency plots are for the 42 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2.

  Read more less

  $350.42

  View options

•

  View options

  MEAN WELL HLG-480H series: Constant Voltage + Constant Current LED Driver - HLG-480H-36DX

  HLG-480H-36DX LED Driver HLG-480H-36DX is a MEAN WELL HLG-480H metal-case, Class I LED driver with 36 V DC rated output, 13.3 A rated current and 478.8 W rated power. It provides constant-voltage and constant-current operation with a 18–36 V constant-current region. Smart timer dimming by request. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-480H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 91–104. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-480H-36DX; Smart timer dimming by request Rated output 36 V DC; 13.3 A; 478.8 W Constant-current region 18–36 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 250 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 95% typical at 230 VAC; 95.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 16 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 5 / 2.45 / 2 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.97 / 0.95 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥40% load at 115, 230 and 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 35 A; 1800 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 2 / 3 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 110–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 40–50 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Smart timer By-request smart timer dimming. Adaptive proportional timing follows the supplied profile; arrange the customer schedule with MEAN WELL. The D01/D02/D03 plots are examples, not a promise that this DX order includes a particular preset. Catalog timer examples Elapsed hours from switch-on: D01 = 0–6 h 100%, 6–7 h 70%, 7–11 h 50%, 11–14 h 70%; D02 = 0–1 h 50%, 1–3 h 80%, 3–8 h 100%, 8–11 h 60%, 11–14 h 80%; D03 = 0–1.5 h 70%, 1.5–11 h 100%, 11–14 h 70%. Use the elapsed-time tables; the example clock labels contain inconsistencies. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: at 110 VAC, 100% load through +50°C; on the curve labeled above 230 VAC, 100% through +60°C. Both reach 60% at +65°C. The plotted ambient range starts at −40°C. The catalog gives a typical +60°C maximum ambient at rated constant current and 230 VAC. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 113.8 mm from the drawing’s right-side inner reference and 58 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 80°C Temperature coefficient ±0.02%/°C (0–60°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 1185.9 K hours, Telcordia SR-332 (Bellcore); 95.4 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; GB 19510.1 and GB 19510.213; EAC TP TC 004; AS/NZS IEC 61347.2.13:2013 and AS/NZS 61347.1:2016. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. ErP installation condition For the stated EU ErP compliance, install the LED power supply after a switch; do not leave it permanently connected to the mains supply. Mechanical details and connection Dimensions / case 262 × 125 × 43.8 mm (L × W × H); case 251. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 2.8 kg per unit; 4 units / 12.2 kg / 0.55 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJOW 17 AWG × 2C / H05RN-F 2 × 1.0 mm² output cables in the mechanical drawings; 300 ±20 mm. Vo+ red; Vo− black. Multiple output pairs share the one driver’s total rated current and power. DX mechanical confirmation Confirm the supplied DX drawing and cable arrangement when ordering; the illustrated mechanical alternatives show the Blank/A/B/AB cable layouts. Optional accessories and ordering Optional junction box The catalog offers a junction-box option for all types, by request. Overall assembly 397.2 × 125 × 43.8 mm; the drawing shows 150 ±20 mm cables. Confirm the required option before ordering. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 75°C; the THD/efficiency plots are for the 42 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2.

  Read more less

  $350.42

  View options

•

  View options

  MEAN WELL HLG-480H series: Constant Voltage + Constant Current LED Driver - HLG-480H-30DX

  HLG-480H-30DX LED Driver HLG-480H-30DX is a MEAN WELL HLG-480H metal-case, Class I LED driver with 30 V DC rated output, 16 A rated current and 480 W rated power. It provides constant-voltage and constant-current operation with a 15–30 V constant-current region. Smart timer dimming by request. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-480H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 91–104. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-480H-30DX; Smart timer dimming by request Rated output 30 V DC; 16 A; 480 W Constant-current region 15–30 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 200 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 94.5% typical at 230 VAC; 95% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 16 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 5 / 2.45 / 2 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.97 / 0.95 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥40% load at 115, 230 and 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 35 A; 1800 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 2 / 3 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 110–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 33–40 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Smart timer By-request smart timer dimming. Adaptive proportional timing follows the supplied profile; arrange the customer schedule with MEAN WELL. The D01/D02/D03 plots are examples, not a promise that this DX order includes a particular preset. Catalog timer examples Elapsed hours from switch-on: D01 = 0–6 h 100%, 6–7 h 70%, 7–11 h 50%, 11–14 h 70%; D02 = 0–1 h 50%, 1–3 h 80%, 3–8 h 100%, 8–11 h 60%, 11–14 h 80%; D03 = 0–1.5 h 70%, 1.5–11 h 100%, 11–14 h 70%. Use the elapsed-time tables; the example clock labels contain inconsistencies. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: at 110 VAC, 100% load through +50°C; on the curve labeled above 230 VAC, 100% through +60°C. Both reach 60% at +65°C. The plotted ambient range starts at −40°C. The catalog gives a typical +60°C maximum ambient at rated constant current and 230 VAC. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 113.8 mm from the drawing’s right-side inner reference and 58 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 80°C Temperature coefficient ±0.02%/°C (0–60°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 1185.9 K hours, Telcordia SR-332 (Bellcore); 95.4 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; GB 19510.1 and GB 19510.213; EAC TP TC 004; AS/NZS IEC 61347.2.13:2013 and AS/NZS 61347.1:2016. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. ErP installation condition For the stated EU ErP compliance, install the LED power supply after a switch; do not leave it permanently connected to the mains supply. Mechanical details and connection Dimensions / case 262 × 125 × 43.8 mm (L × W × H); case 251. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 2.8 kg per unit; 4 units / 12.2 kg / 0.55 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJOW 17 AWG × 2C / H05RN-F 2 × 1.0 mm² output cables in the mechanical drawings; 300 ±20 mm. Vo+ red; Vo− black. Multiple output pairs share the one driver’s total rated current and power. DX mechanical confirmation Confirm the supplied DX drawing and cable arrangement when ordering; the illustrated mechanical alternatives show the Blank/A/B/AB cable layouts. Optional accessories and ordering Optional junction box The catalog offers a junction-box option for all types, by request. Overall assembly 397.2 × 125 × 43.8 mm; the drawing shows 150 ±20 mm cables. Confirm the required option before ordering. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 75°C; the THD/efficiency plots are for the 42 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2.

  Read more less

  $350.42

  View options

•

  View options

  MEAN WELL HLG-480H series: Constant Voltage + Constant Current LED Driver - HLG-480H-24DX

  HLG-480H-24DX LED Driver HLG-480H-24DX is a MEAN WELL HLG-480H metal-case, Class I LED driver with 24 V DC rated output, 20 A rated current and 480 W rated power. It provides constant-voltage and constant-current operation with a 12–24 V constant-current region. Smart timer dimming by request. IP67 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-480H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 91–104. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-480H-24DX; Smart timer dimming by request Rated output 24 V DC; 20 A; 480 W Constant-current region 12–24 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 200 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Internal adjustment No user-accessible internal voltage/current adjustment is specified for this option. Efficiency 94% typical at 230 VAC; 94.5% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 16 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 5 / 2.45 / 2 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.97 / 0.95 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥40% load at 115, 230 and 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 35 A; 1800 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 2 / 3 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 110–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 27–33 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Smart timer By-request smart timer dimming. Adaptive proportional timing follows the supplied profile; arrange the customer schedule with MEAN WELL. The D01/D02/D03 plots are examples, not a promise that this DX order includes a particular preset. Catalog timer examples Elapsed hours from switch-on: D01 = 0–6 h 100%, 6–7 h 70%, 7–11 h 50%, 11–14 h 70%; D02 = 0–1 h 50%, 1–3 h 80%, 3–8 h 100%, 8–11 h 60%, 11–14 h 80%; D03 = 0–1.5 h 70%, 1.5–11 h 100%, 11–14 h 70%. Use the elapsed-time tables; the example clock labels contain inconsistencies. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: at 110 VAC, 100% load through +50°C; on the curve labeled above 230 VAC, 100% through +60°C. Both reach 60% at +65°C. The plotted ambient range starts at −40°C. The catalog gives a typical +60°C maximum ambient at rated constant current and 230 VAC. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 113.8 mm from the drawing’s right-side inner reference and 58 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 80°C Temperature coefficient ±0.02%/°C (0–60°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 1185.9 K hours, Telcordia SR-332 (Bellcore); 95.4 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; GB 19510.1 and GB 19510.213; EAC TP TC 004; AS/NZS IEC 61347.2.13:2013 and AS/NZS 61347.1:2016. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. ErP installation condition For the stated EU ErP compliance, install the LED power supply after a switch; do not leave it permanently connected to the mains supply. Mechanical details and connection Dimensions / case 262 × 125 × 43.8 mm (L × W × H); case 251. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP67 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 2.8 kg per unit; 4 units / 12.2 kg / 0.55 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables Two SJOW 17 AWG × 2C / H05RN-F 2 × 1.0 mm² output cables in the mechanical drawings; 300 ±20 mm. Vo+ red; Vo− black. Multiple output pairs share the one driver’s total rated current and power. DX mechanical confirmation Confirm the supplied DX drawing and cable arrangement when ordering; the illustrated mechanical alternatives show the Blank/A/B/AB cable layouts. Optional accessories and ordering Optional junction box The catalog offers a junction-box option for all types, by request. Overall assembly 397.2 × 125 × 43.8 mm; the drawing shows 150 ±20 mm cables. Confirm the required option before ordering. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 75°C; the THD/efficiency plots are for the 42 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2.

  Read more less

  $350.42

  View options

•

  View options

  MEAN WELL HLG-480H series: Constant Voltage + Constant Current LED Driver - HLG-480H-54AB

  HLG-480H-54AB LED Driver HLG-480H-54AB is a MEAN WELL HLG-480H metal-case, Class I LED driver with 54 V DC rated output, 8.9 A rated current and 480.6 W rated power. It provides constant-voltage and constant-current operation with a 27–54 V constant-current region. Internal voltage/current adjustment and 3-in-1 external dimming. IP65 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-480H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 91–104. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-480H-54AB; Internal voltage/current adjustment and 3-in-1 external dimming Rated output 54 V DC; 8.9 A; 480.6 W Constant-current region 27–54 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 350 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Current adjustment 4.4–8.9 A by the internal potentiometer; do not exceed the rated output envelope. Voltage adjustment 45.9–56.7 V by the internal potentiometer. Efficiency 95% typical at 230 VAC; 95% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 16 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 5 / 2.45 / 2 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.97 / 0.95 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥40% load at 115, 230 and 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 35 A; 1800 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 2 / 3 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 110–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 60–70 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Dimming methods 0–10 V DC, 10 V PWM at 100 Hz–3 kHz, or an external resistance across DIM+ and DIM−. The control adjusts the constant-current level. Control source current 100 μA typical from the dimming interface. Resistance and parallel control 0 to 100 kΩ/N for N drivers in synchronized dimming; use the catalog connection diagram. Dimming range Approximately 6–100% current with dim-to-off. The range 0 < Iout < 6% is undefined. The catalog shows off at approximately 0 V, 0 Ω or 0% PWM duty; verify the controller and load together. Dimming wiring DIM+ = purple; DIM− = pink. Do not connect DIM− to either power-output conductor (Vo+ or Vo−); the catalog states both restrictions in different control diagrams. Dimming load connection Direct connection to LEDs is suggested; this dimming function is not suitable for an additional driver stage. Control isolation The catalog explicitly specifies an isolated 3-in-1 dimming interface. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: at 110 VAC, 100% load through +50°C; on the curve labeled above 230 VAC, 100% through +60°C. Both reach 60% at +65°C. The plotted ambient range starts at −40°C. The catalog gives a typical +60°C maximum ambient at rated constant current and 230 VAC. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 113.8 mm from the drawing’s right-side inner reference and 58 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 80°C Temperature coefficient ±0.02%/°C (0–60°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 1185.9 K hours, Telcordia SR-332 (Bellcore); 95.4 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; GB 19510.1 and GB 19510.213; EAC TP TC 004; AS/NZS IEC 61347.2.13:2013 and AS/NZS 61347.1:2016; J61347-1(H29) and J61347-2-13(H29). Type HL compliance of A/AB versions requires built-in installation consideration in the final equipment. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. ErP installation condition For the stated EU ErP compliance, install the LED power supply after a switch; do not leave it permanently connected to the mains supply. Mechanical details and connection Dimensions / case 262 × 125 × 43.8 mm (L × W × H); case 251. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP65 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 2.8 kg per unit; 4 units / 12.2 kg / 0.55 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables One SJOW 17 AWG × 2C / H05RN-F 2 × 1.0 mm² output cable in the mechanical drawings; 300 ±20 mm. Vo+ red; Vo− black. Multiple output pairs share the one driver’s total rated current and power. Dimming cable UL2517 20 AWG × 2C; 330 ±20 mm; DIM+ purple, DIM− pink. Optional accessories and ordering Optional junction box The catalog offers a junction-box option for all types, by request. Overall assembly 397.2 × 125 × 43.8 mm; the drawing shows 150 ±20 mm cables. Confirm the required option before ordering. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 75°C; the THD/efficiency plots are for the 42 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Weather protection This IP65 model must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Controller installation Verify the compatibility and capacity of the controller or network for this exact interface. For standalone use with dimming conductors smaller than 18 AWG (0.75 mm²), use SELV controllers/networks; contact MEAN WELL for guidance before using FELV control. Follow this model’s control wiring. Dimming isolation The current catalog identifies this 480H 3-in-1 dimming interface as isolated; follow its exact DIM wiring and controller requirements.

  Read more less

  $350.42

  View options

•

  View options

  MEAN WELL HLG-480H series: Constant Voltage + Constant Current LED Driver - HLG-480H-48AB

  HLG-480H-48AB LED Driver HLG-480H-48AB is a MEAN WELL HLG-480H metal-case, Class I LED driver with 48 V DC rated output, 10 A rated current and 480 W rated power. It provides constant-voltage and constant-current operation with a 24–48 V constant-current region. Internal voltage/current adjustment and 3-in-1 external dimming. IP65 enclosure; observe the connection-sealing, installation and derating conditions below. Download MEAN WELL HLG-480H Datasheet (PDF)Download MEAN WELL LED Installation ManualCatalog reference: PDF pages 91–104. Select this exact model and option when checking drawings and operating curves. Output and operating performance Model and option HLG-480H-48AB; Internal voltage/current adjustment and 3-in-1 external dimming Rated output 48 V DC; 10 A; 480 W Constant-current region 24–48 V. Keep the LED operating voltage within this region for direct constant-current operation; stay within the rated and derated current/power envelope. Output mode Constant voltage + constant current. Actual CV/CC transition depends on the LED load. The operation diagram also illustrates CV supply of an external DC/DC stage; the dimming restrictions below apply to dimmable versions. Ripple and noise (max.) 250 mVp-p Voltage tolerance ±1%, including set-up, line and load regulation Line / load regulation ±0.5% / ±0.5% Current adjustment 5–10 A by the internal potentiometer; do not exceed the rated output envelope. Voltage adjustment 40.8–50.4 V by the internal potentiometer. Efficiency 94.5% typical at 230 VAC; 95% typical at 277 VAC Setup / rise time 500 ms / 80 ms at both 115 and 230 VAC. Catalog timing is measured at the first cold start; repeated ON/OFF operation may increase setup time. Hold-up time 16 ms at 115 and 230 VAC Input and protection Input voltage / frequency 90–305 VAC or 127–431 VDC; AC frequency 47–63 Hz. Apply the input/load and temperature derating curves together. AC input current (typ.) 5 / 2.45 / 2 A at 115 / 230 / 277 VAC Power factor (typ.) ≥0.98 / 0.97 / 0.95 at 115 / 230 / 277 VAC, full load Total harmonic distortion <20% at ≥40% load at 115, 230 and 277 VAC. Inrush current (typ.) Cold start at 230 VAC: 35 A; 1800 μs width at 50% of peak; measured per NEMA 410. Circuit-breaker loading Catalog reference: 2 / 3 units on B-type / C-type 16 A breakers at 230 VAC. Confirm breaker characteristics and the actual installation; these are configuration-dependent catalog values. Leakage current <0.75 mA at 277 VAC Input/load derating At 60 Hz: 90 VAC: 80% load; 110–305 VAC: 100% load. Between plotted endpoints, follow the catalog curve; this does not authorize overload. Over-current protection 95–108% of rated output; constant-current limiting, with automatic recovery after the fault is removed. Short-circuit protection Constant-current limiting; automatic recovery after the fault is removed. Over-voltage protection 53–63 V; Output shuts down; re-power to recover. Over-temperature protection Output shuts down; re-power to recover. Control and option-specific functions Dimming methods 0–10 V DC, 10 V PWM at 100 Hz–3 kHz, or an external resistance across DIM+ and DIM−. The control adjusts the constant-current level. Control source current 100 μA typical from the dimming interface. Resistance and parallel control 0 to 100 kΩ/N for N drivers in synchronized dimming; use the catalog connection diagram. Dimming range Approximately 6–100% current with dim-to-off. The range 0 < Iout < 6% is undefined. The catalog shows off at approximately 0 V, 0 Ω or 0% PWM duty; verify the controller and load together. Dimming wiring DIM+ = purple; DIM− = pink. Do not connect DIM− to either power-output conductor (Vo+ or Vo−); the catalog states both restrictions in different control diagrams. Dimming load connection Direct connection to LEDs is suggested; this dimming function is not suitable for an additional driver stage. Control isolation The catalog explicitly specifies an isolated 3-in-1 dimming interface. Thermal and environmental limits Cooling / ambient derating Fanless free-air convection. Horizontal mounting: at 110 VAC, 100% load through +50°C; on the curve labeled above 230 VAC, 100% through +60°C. Both reach 60% at +65°C. The plotted ambient range starts at −40°C. The catalog gives a typical +60°C maximum ambient at rated constant current and 230 VAC. Case temperature Working case temperature Tc = −40 to +90°C; +90°C maximum. Use the Tc point in the mechanical drawing. Ambient temperature and Tc are separate limits. Case-temperature measuring point 113.8 mm from the drawing’s right-side inner reference and 58 mm above the lower edge; verify the indicated Tc symbol and reference edges in the exact option drawing. Working / storage humidity Working: 20–95% RH, non-condensing; storage: 10–95% RH. Storage temperature −40 to 80°C Temperature coefficient ±0.02%/°C (0–60°C) Vibration 10–500 Hz, 5 G; 12-minute cycle; 72 minutes along each X, Y and Z axis. Altitude Above 2000 m, reduce permissible ambient temperature by 3.5°C per 1000 m for this fanless driver. Life and reliability Typical life expectancy >62,000 hours at Tc ≤75°C under the catalog conditions. MTBF: 1185.9 K hours, Telcordia SR-332 (Bellcore); 95.4 K hours, MIL-HDBK-217F at 25°C. Life and MTBF are different statistical/operating measures. Manufacturer warranty The catalog states a 7-year warranty; the manufacturer’s warranty statement and applicable operating conditions govern. Safety and compliance Construction Metal housing; Class I protective-earth connection; SELV output as described by the series catalog. Follow model-specific safety and installation qualifications. Safety standards and option limits Catalog safety approvals/references for this configuration: UL 8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC, BS EN/EN 61347-1 and 61347-2-13, independent type; BS EN/EN 62384; GB 19510.1 and GB 19510.213; EAC TP TC 004; AS/NZS IEC 61347.2.13:2013 and AS/NZS 61347.1:2016; J61347-1(H29) and J61347-2-13(H29). Type HL compliance of A/AB versions requires built-in installation consideration in the final equipment. EMC emissions BS EN/EN 55015; BS EN/EN 61000-3-2, Class C at ≥50% load; BS EN/EN 61000-3-3; GB 17743 and GB 17625.1; EAC TP TC 020. EMC immunity BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547; surge immunity 4 kV line-to-earth / 2 kV line-to-line; EAC TP TC 020. Withstand voltage Input–output: 3.75 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, between input–output, input–FG and output–FG. ErP installation condition For the stated EU ErP compliance, install the LED power supply after a switch; do not leave it permanently connected to the mains supply. Mechanical details and connection Dimensions / case 262 × 125 × 43.8 mm (L × W × H); case 251. Mounting Four mounting holes, Ø4.5 mm. Use the exact drawing for hole pitch, the Tc location and clearances; follow the horizontal-mounting thermal curves. Enclosure rating IP65 for the specified cable version; rating does not replace sealed field connections or installation requirements. Unit weight / packing 2.8 kg per unit; 4 units / 12.2 kg / 0.55 cu ft AC cable SJOW 17 AWG × 3C / H05RN-F 3 × 1.0 mm²; 300 ±20 mm. AC/L brown; AC/N blue; FG green/yellow. DC output cables One SJOW 17 AWG × 2C / H05RN-F 2 × 1.0 mm² output cable in the mechanical drawings; 300 ±20 mm. Vo+ red; Vo− black. Multiple output pairs share the one driver’s total rated current and power. Dimming cable UL2517 20 AWG × 2C; 330 ±20 mm; DIM+ purple, DIM− pink. Optional accessories and ordering Optional junction box The catalog offers a junction-box option for all types, by request. Overall assembly 397.2 × 125 × 43.8 mm; the drawing shows 150 ±20 mm cables. Confirm the required option before ordering. Measurement and installation conditions Electrical test conditions Unless otherwise stated: 230 VAC input, rated output current and 25°C ambient. Ripple/noise uses a 20 MHz bandwidth measurement with a 12-inch twisted pair terminated by 0.1 μF and 47 μF capacitors. Performance-curve conditions Power-factor, THD and efficiency plots use Tc = 75°C; the THD/efficiency plots are for the 42 V model. Example-model curves do not replace the efficiency and operating limits listed for this exact SKU. LED compatibility Select an LED load compatible with the voltage/current window, startup behavior, thermal limits and the selected control option. Consult the catalog and manufacturer for configurations outside the illustrated operating regions. Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor or protective-earth terminal to PE according to this Class I model’s wiring diagram. Weather protection This IP65 model must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Controller installation Verify the compatibility and capacity of the controller or network for this exact interface. For standalone use with dimming conductors smaller than 18 AWG (0.75 mm²), use SELV controllers/networks; contact MEAN WELL for guidance before using FELV control. Follow this model’s control wiring. Dimming isolation The current catalog identifies this 480H 3-in-1 dimming interface as isolated; follow its exact DIM wiring and controller requirements.

  Read more less

  $350.42

  View options

Show more products
