  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-380WCAN

  MEAN WELL HEP-2300-380WCAN is a fanless industrial AC/DC power supply with a factory 380 V output and 6.05 A factory current and a 2300 W maximum-power limit. This wired version uses CANBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-380WCAN Series HEP-2300-HV Connection construction wired Operating configuration Power-supply mode Communication interface CANBus Catalogue configuration availability By request Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 380 V Factory default output current 6.05 A Maximum output current 6.9 A Maximum rated output power 2300 W Voltage range at maximum rated power 334–400 V Ripple and noise maximum 4000 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 260–400 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 420–480 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports CANBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length One SOOW 17 AWG × 2C cable; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; CANH / CANL / GND-AUX Use the colours and lead construction for this exact suffix. The function table lists remote ON/OFF, but this wiring drawing does not identify a dedicated remote lead. Confirm the supplied wiring if remote ON/OFF is required. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-230WCAN

  MEAN WELL HEP-2300-230WCAN is a fanless industrial AC/DC power supply with a factory 230 V output and 10 A factory current and a 2300 W maximum-power limit. This wired version uses CANBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-230WCAN Series HEP-2300-HV Connection construction wired Operating configuration Power-supply mode Communication interface CANBus Catalogue configuration availability By request Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 230 V Factory default output current 10 A Maximum output current 10.6 A Maximum rated output power 2300 W Voltage range at maximum rated power 216–260 V Ripple and noise maximum 2500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 170–260 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 273–312 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports CANBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length Two SJOW 17 AWG × 2C cables; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; CANH / CANL / GND-AUX Use the colours and lead construction for this exact suffix. The function table lists remote ON/OFF, but this wiring drawing does not identify a dedicated remote lead. Confirm the supplied wiring if remote ON/OFF is required. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-115WCAN

  MEAN WELL HEP-2300-115WCAN is a fanless industrial AC/DC power supply with a factory 115 V output and 20 A factory current and a 2300 W maximum-power limit. This wired version uses CANBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-115WCAN Series HEP-2300-HV Connection construction wired Operating configuration Power-supply mode Communication interface CANBus Catalogue configuration availability By request Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 115 V Factory default output current 20 A Maximum output current 20 A Maximum rated output power 2300 W Voltage range at maximum rated power 115–138 V Ripple and noise maximum 1500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 90–138 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 145–166 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports CANBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length Two SJOW 17 AWG × 2C cables; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; CANH / CANL / GND-AUX Use the colours and lead construction for this exact suffix. The function table lists remote ON/OFF, but this wiring drawing does not identify a dedicated remote lead. Confirm the supplied wiring if remote ON/OFF is required. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-380WPM

  MEAN WELL HEP-2300-380WPM is a fanless industrial AC/DC power supply with a factory 380 V output and 6.05 A factory current and a 2300 W maximum-power limit. This wired version uses PMBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-380WPM Series HEP-2300-HV Connection construction wired Operating configuration Power-supply mode Communication interface PMBus Catalogue configuration availability By request Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 380 V Factory default output current 6.05 A Maximum output current 6.9 A Maximum rated output power 2300 W Voltage range at maximum rated power 334–400 V Ripple and noise maximum 4000 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 260–400 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 420–480 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports PMBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length One SOOW 17 AWG × 2C cable; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; SDA / SCL / GND-AUX Use the colours and lead construction for this exact suffix. The function table lists remote ON/OFF, but this wiring drawing does not identify a dedicated remote lead. Confirm the supplied wiring if remote ON/OFF is required. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-230WPM

  MEAN WELL HEP-2300-230WPM is a fanless industrial AC/DC power supply with a factory 230 V output and 10 A factory current and a 2300 W maximum-power limit. This wired version uses PMBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-230WPM Series HEP-2300-HV Connection construction wired Operating configuration Power-supply mode Communication interface PMBus Catalogue configuration availability By request Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 230 V Factory default output current 10 A Maximum output current 10.6 A Maximum rated output power 2300 W Voltage range at maximum rated power 216–260 V Ripple and noise maximum 2500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 170–260 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 273–312 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports PMBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length Two SJOW 17 AWG × 2C cables; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; SDA / SCL / GND-AUX Use the colours and lead construction for this exact suffix. The function table lists remote ON/OFF, but this wiring drawing does not identify a dedicated remote lead. Confirm the supplied wiring if remote ON/OFF is required. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-115WPM

  MEAN WELL HEP-2300-115WPM is a fanless industrial AC/DC power supply with a factory 115 V output and 20 A factory current and a 2300 W maximum-power limit. This wired version uses PMBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-115WPM Series HEP-2300-HV Connection construction wired Operating configuration Power-supply mode Communication interface PMBus Catalogue configuration availability By request Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 115 V Factory default output current 20 A Maximum output current 20 A Maximum rated output power 2300 W Voltage range at maximum rated power 115–138 V Ripple and noise maximum 1500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 90–138 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 145–166 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports PMBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length Two SJOW 17 AWG × 2C cables; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; SDA / SCL / GND-AUX Use the colours and lead construction for this exact suffix. The function table lists remote ON/OFF, but this wiring drawing does not identify a dedicated remote lead. Confirm the supplied wiring if remote ON/OFF is required. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-380W

  MEAN WELL HEP-2300-380W is a fanless industrial AC/DC power supply with a factory 380 V output and 6.05 A factory current and a 2300 W maximum-power limit. This wired version uses external PV/PC control. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-380W Series HEP-2300-HV Connection construction wired Operating configuration Power-supply mode Communication interface No digital communication interface Catalogue configuration availability In Stock Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 380 V Factory default output current 6.05 A Maximum output current 6.9 A Maximum rated output power 2300 W Voltage range at maximum rated power 334–400 V Ripple and noise maximum 4000 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 260–400 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 420–480 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 334 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 167 V to 100% at 300.6 V, stays at 100% through 334 V, and falls to 83.3% at 400 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. The factory 380 V point is about 113.7% of the 334 V reference and is marked at 4.37 V external PV control. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length One SOOW 17 AWG × 2C cable; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; PV / PC / GND(signal) Use the colours and lead construction for this exact suffix. The function table lists remote ON/OFF, but this wiring drawing does not identify a dedicated remote lead. Confirm the supplied wiring if remote ON/OFF is required. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-230W

  MEAN WELL HEP-2300-230W is a fanless industrial AC/DC power supply with a factory 230 V output and 10 A factory current and a 2300 W maximum-power limit. This wired version uses external PV/PC control. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-230W Series HEP-2300-HV Connection construction wired Operating configuration Power-supply mode Communication interface No digital communication interface Catalogue configuration availability In Stock Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 230 V Factory default output current 10 A Maximum output current 10.6 A Maximum rated output power 2300 W Voltage range at maximum rated power 216–260 V Ripple and noise maximum 2500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 170–260 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 273–312 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 216 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 108 V to 100% at 194.4 V, stays at 100% through 216 V, and falls to 83.3% at 260 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. The factory 230 V point is about 106.5% of the 216 V reference and is marked at 4 V external PV control. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length Two SJOW 17 AWG × 2C cables; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; PV / PC / GND(signal) Use the colours and lead construction for this exact suffix. The function table lists remote ON/OFF, but this wiring drawing does not identify a dedicated remote lead. Confirm the supplied wiring if remote ON/OFF is required. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-115W

  MEAN WELL HEP-2300-115W is a fanless industrial AC/DC power supply with a factory 115 V output and 20 A factory current and a 2300 W maximum-power limit. This wired version uses external PV/PC control. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-115W Series HEP-2300-HV Connection construction wired Operating configuration Power-supply mode Communication interface No digital communication interface Catalogue configuration availability In Stock Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 115 V Factory default output current 20 A Maximum output current 20 A Maximum rated output power 2300 W Voltage range at maximum rated power 115–138 V Ripple and noise maximum 1500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 90–138 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 145–166 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 115 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 57.5 V to 100% at 103.5 V, stays at 100% through 115 V, and falls to 83.3% at 138 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length Two SJOW 17 AWG × 2C cables; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; PV / PC / GND(signal) Use the colours and lead construction for this exact suffix. The function table lists remote ON/OFF, but this wiring drawing does not identify a dedicated remote lead. Confirm the supplied wiring if remote ON/OFF is required. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-380PM

  MEAN WELL HEP-2300-380PM is a fanless industrial AC/DC power supply with a factory 380 V output and 6.05 A factory current and a 2300 W maximum-power limit. This terminal version uses PMBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-380PM Series HEP-2300-HV Connection construction terminal Operating configuration Power-supply mode Communication interface PMBus Catalogue configuration availability By request The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 380 V Factory default output current 6.05 A Maximum output current 6.9 A Maximum rated output power 2300 W Voltage range at maximum rated power 334–400 V Ripple and noise maximum 4000 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 260–400 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 420–480 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 334 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 167 V to 100% at 300.6 V, stays at 100% through 334 V, and falls to 83.3% at 400 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. The factory 380 V point is about 113.7% of the 334 V reference and is marked at 4.37 V external PV control. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports PMBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC terminals / DC terminals 1 = FG; 2 = AC/L; 3 = AC/N; 1, 2, 3 = +V; 4, 5, 6 = −V CN81 board connector / CN81 mating housing JST S8B-PHDKS-B; JST PHDR-8VS CN11 board connector / CN11 mating housing JST S14B-PHDKS-B; JST PHDR-14VS Crimp contact for both connectors / CN81 pin 1 / pin 2 JST SPHD-001T-P0.5; PV / PC CN81 pins 3 and 4 / CN81 pins 5 and 6 GND(signal), non-isolated; NC: do not connect CN81 pins 7 and 8 / CN11 pins 1 and 2 NC: do not connect; Remote ON/OFF CN11 pins 3, 4, 13 and 14 / CN11 pins 5 and 6 NC: do not connect; DC OK CN11 pins 7 and 8 / CN11 pins 9 and 10 +12 V AUX; GND-AUX CN11 pin 11 / CN11 pin 12 SDA; SCL Short the remote input to AUX for ON; open it for OFF. The detailed table gives 10.8–13.2 V ON, 0–0.5 V OFF and a maximum 13.2 V input. AUX remains available when the main output is remotely OFF. The detailed DC OK table specifies 4.4–5.5 V high, −0.5 to +0.5 V low and 10 mA maximum sourcing current. Power-supply low/high thresholds are ≤77% ±6% and ≥80% ±6% of nominal voltage. CN81 PV/PC use non-isolated GND(signal). CN11 controls use GND-AUX, isolated from the main output. Follow the actual orientation and leave NC contacts disconnected. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-230PM

  MEAN WELL HEP-2300-230PM is a fanless industrial AC/DC power supply with a factory 230 V output and 10 A factory current and a 2300 W maximum-power limit. This terminal version uses PMBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-230PM Series HEP-2300-HV Connection construction terminal Operating configuration Power-supply mode Communication interface PMBus Catalogue configuration availability By request The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 230 V Factory default output current 10 A Maximum output current 10.6 A Maximum rated output power 2300 W Voltage range at maximum rated power 216–260 V Ripple and noise maximum 2500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 170–260 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 273–312 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 216 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 108 V to 100% at 194.4 V, stays at 100% through 216 V, and falls to 83.3% at 260 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. The factory 230 V point is about 106.5% of the 216 V reference and is marked at 4 V external PV control. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports PMBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC terminals / DC terminals 1 = FG; 2 = AC/L; 3 = AC/N; 1, 2, 3 = +V; 4, 5, 6 = −V CN81 board connector / CN81 mating housing JST S8B-PHDKS-B; JST PHDR-8VS CN11 board connector / CN11 mating housing JST S14B-PHDKS-B; JST PHDR-14VS Crimp contact for both connectors / CN81 pin 1 / pin 2 JST SPHD-001T-P0.5; PV / PC CN81 pins 3 and 4 / CN81 pins 5 and 6 GND(signal), non-isolated; NC: do not connect CN81 pins 7 and 8 / CN11 pins 1 and 2 NC: do not connect; Remote ON/OFF CN11 pins 3, 4, 13 and 14 / CN11 pins 5 and 6 NC: do not connect; DC OK CN11 pins 7 and 8 / CN11 pins 9 and 10 +12 V AUX; GND-AUX CN11 pin 11 / CN11 pin 12 SDA; SCL Short the remote input to AUX for ON; open it for OFF. The detailed table gives 10.8–13.2 V ON, 0–0.5 V OFF and a maximum 13.2 V input. AUX remains available when the main output is remotely OFF. The detailed DC OK table specifies 4.4–5.5 V high, −0.5 to +0.5 V low and 10 mA maximum sourcing current. Power-supply low/high thresholds are ≤77% ±6% and ≥80% ±6% of nominal voltage. CN81 PV/PC use non-isolated GND(signal). CN11 controls use GND-AUX, isolated from the main output. Follow the actual orientation and leave NC contacts disconnected. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-115PM

  MEAN WELL HEP-2300-115PM is a fanless industrial AC/DC power supply with a factory 115 V output and 20 A factory current and a 2300 W maximum-power limit. This terminal version uses PMBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-115PM Series HEP-2300-HV Connection construction terminal Operating configuration Power-supply mode Communication interface PMBus Catalogue configuration availability By request The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 115 V Factory default output current 20 A Maximum output current 20 A Maximum rated output power 2300 W Voltage range at maximum rated power 115–138 V Ripple and noise maximum 1500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 90–138 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 145–166 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 115 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 57.5 V to 100% at 103.5 V, stays at 100% through 115 V, and falls to 83.3% at 138 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports PMBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC terminals / DC terminals 1 = FG; 2 = AC/L; 3 = AC/N; 1, 2, 3 = +V; 4, 5, 6 = −V CN81 board connector / CN81 mating housing JST S8B-PHDKS-B; JST PHDR-8VS CN11 board connector / CN11 mating housing JST S14B-PHDKS-B; JST PHDR-14VS Crimp contact for both connectors / CN81 pin 1 / pin 2 JST SPHD-001T-P0.5; PV / PC CN81 pins 3 and 4 / CN81 pins 5 and 6 GND(signal), non-isolated; NC: do not connect CN81 pins 7 and 8 / CN11 pins 1 and 2 NC: do not connect; Remote ON/OFF CN11 pins 3, 4, 13 and 14 / CN11 pins 5 and 6 NC: do not connect; DC OK CN11 pins 7 and 8 / CN11 pins 9 and 10 +12 V AUX; GND-AUX CN11 pin 11 / CN11 pin 12 SDA; SCL Short the remote input to AUX for ON; open it for OFF. The detailed table gives 10.8–13.2 V ON, 0–0.5 V OFF and a maximum 13.2 V input. AUX remains available when the main output is remotely OFF. The detailed DC OK table specifies 4.4–5.5 V high, −0.5 to +0.5 V low and 10 mA maximum sourcing current. Power-supply low/high thresholds are ≤77% ±6% and ≥80% ±6% of nominal voltage. CN81 PV/PC use non-isolated GND(signal). CN11 controls use GND-AUX, isolated from the main output. Follow the actual orientation and leave NC contacts disconnected. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-380

  MEAN WELL HEP-2300-380 is a fanless industrial AC/DC power supply with a factory 380 V output and 6.05 A factory current and a 2300 W maximum-power limit. This terminal version uses CANBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-380 Series HEP-2300-HV Connection construction terminal Operating configuration Power-supply mode Communication interface CANBus Catalogue configuration availability In Stock The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 380 V Factory default output current 6.05 A Maximum output current 6.9 A Maximum rated output power 2300 W Voltage range at maximum rated power 334–400 V Ripple and noise maximum 4000 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 260–400 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 420–480 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 334 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 167 V to 100% at 300.6 V, stays at 100% through 334 V, and falls to 83.3% at 400 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. The factory 380 V point is about 113.7% of the 334 V reference and is marked at 4.37 V external PV control. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports CANBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC terminals / DC terminals 1 = FG; 2 = AC/L; 3 = AC/N; 1, 2, 3 = +V; 4, 5, 6 = −V CN81 board connector / CN81 mating housing JST S8B-PHDKS-B; JST PHDR-8VS CN11 board connector / CN11 mating housing JST S14B-PHDKS-B; JST PHDR-14VS Crimp contact for both connectors / CN81 pin 1 / pin 2 JST SPHD-001T-P0.5; PV / PC CN81 pins 3 and 4 / CN81 pins 5 and 6 GND(signal), non-isolated; NC: do not connect CN81 pins 7 and 8 / CN11 pins 1 and 2 NC: do not connect; Remote ON/OFF CN11 pins 3, 4, 13 and 14 / CN11 pins 5 and 6 NC: do not connect; DC OK CN11 pins 7 and 8 / CN11 pins 9 and 10 +12 V AUX; GND-AUX CN11 pin 11 / CN11 pin 12 CANH; CANL Short the remote input to AUX for ON; open it for OFF. The detailed table gives 10.8–13.2 V ON, 0–0.5 V OFF and a maximum 13.2 V input. AUX remains available when the main output is remotely OFF. The detailed DC OK table specifies 4.4–5.5 V high, −0.5 to +0.5 V low and 10 mA maximum sourcing current. Power-supply low/high thresholds are ≤77% ±6% and ≥80% ±6% of nominal voltage. CN81 PV/PC use non-isolated GND(signal). CN11 controls use GND-AUX, isolated from the main output. Follow the actual orientation and leave NC contacts disconnected. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-230

  MEAN WELL HEP-2300-230 is a fanless industrial AC/DC power supply with a factory 230 V output and 10 A factory current and a 2300 W maximum-power limit. This terminal version uses CANBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-230 Series HEP-2300-HV Connection construction terminal Operating configuration Power-supply mode Communication interface CANBus Catalogue configuration availability In Stock The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 230 V Factory default output current 10 A Maximum output current 10.6 A Maximum rated output power 2300 W Voltage range at maximum rated power 216–260 V Ripple and noise maximum 2500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 170–260 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 273–312 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 216 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 108 V to 100% at 194.4 V, stays at 100% through 216 V, and falls to 83.3% at 260 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. The factory 230 V point is about 106.5% of the 216 V reference and is marked at 4 V external PV control. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports CANBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC terminals / DC terminals 1 = FG; 2 = AC/L; 3 = AC/N; 1, 2, 3 = +V; 4, 5, 6 = −V CN81 board connector / CN81 mating housing JST S8B-PHDKS-B; JST PHDR-8VS CN11 board connector / CN11 mating housing JST S14B-PHDKS-B; JST PHDR-14VS Crimp contact for both connectors / CN81 pin 1 / pin 2 JST SPHD-001T-P0.5; PV / PC CN81 pins 3 and 4 / CN81 pins 5 and 6 GND(signal), non-isolated; NC: do not connect CN81 pins 7 and 8 / CN11 pins 1 and 2 NC: do not connect; Remote ON/OFF CN11 pins 3, 4, 13 and 14 / CN11 pins 5 and 6 NC: do not connect; DC OK CN11 pins 7 and 8 / CN11 pins 9 and 10 +12 V AUX; GND-AUX CN11 pin 11 / CN11 pin 12 CANH; CANL Short the remote input to AUX for ON; open it for OFF. The detailed table gives 10.8–13.2 V ON, 0–0.5 V OFF and a maximum 13.2 V input. AUX remains available when the main output is remotely OFF. The detailed DC OK table specifies 4.4–5.5 V high, −0.5 to +0.5 V low and 10 mA maximum sourcing current. Power-supply low/high thresholds are ≤77% ±6% and ≥80% ±6% of nominal voltage. CN81 PV/PC use non-isolated GND(signal). CN11 controls use GND-AUX, isolated from the main output. Follow the actual orientation and leave NC contacts disconnected. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300-HV series: Industrial AC/DC Power Supply - HEP-2300-115

  MEAN WELL HEP-2300-115 is a fanless industrial AC/DC power supply with a factory 115 V output and 20 A factory current and a 2300 W maximum-power limit. This terminal version uses CANBus. Product Datasheet Download MEAN WELL HEP-2300-HV Datasheet (PDF) The HEP-2300-HV section is on PDF pages 55, 56, 57, 58, 59, 60, 61, 62, 63, 64, 65, 66, 67. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-115 Series HEP-2300-HV Connection construction terminal Operating configuration Power-supply mode Communication interface CANBus Catalogue configuration availability In Stock The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. This high-voltage model is a power supply. It does not inherit the 55 V version’s internal charging curves or battery NTC interface. Charging applications require a suitable external battery-management arrangement. Output Ratings and Adjustment Factory default output voltage 115 V Factory default output current 20 A Maximum output current 20 A Maximum rated output power 2300 W Voltage range at maximum rated power 115–138 V Ripple and noise maximum 1500 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 90–138 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 145–166 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 115 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 57.5 V to 100% at 103.5 V, stays at 100% through 115 V, and falls to 83.3% at 138 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports CANBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC terminals / DC terminals 1 = FG; 2 = AC/L; 3 = AC/N; 1, 2, 3 = +V; 4, 5, 6 = −V CN81 board connector / CN81 mating housing JST S8B-PHDKS-B; JST PHDR-8VS CN11 board connector / CN11 mating housing JST S14B-PHDKS-B; JST PHDR-14VS Crimp contact for both connectors / CN81 pin 1 / pin 2 JST SPHD-001T-P0.5; PV / PC CN81 pins 3 and 4 / CN81 pins 5 and 6 GND(signal), non-isolated; NC: do not connect CN81 pins 7 and 8 / CN11 pins 1 and 2 NC: do not connect; Remote ON/OFF CN11 pins 3, 4, 13 and 14 / CN11 pins 5 and 6 NC: do not connect; DC OK CN11 pins 7 and 8 / CN11 pins 9 and 10 +12 V AUX; GND-AUX CN11 pin 11 / CN11 pin 12 CANH; CANL Short the remote input to AUX for ON; open it for OFF. The detailed table gives 10.8–13.2 V ON, 0–0.5 V OFF and a maximum 13.2 V input. AUX remains available when the main output is remotely OFF. The detailed DC OK table specifies 4.4–5.5 V high, −0.5 to +0.5 V low and 10 mA maximum sourcing current. Power-supply low/high thresholds are ≤77% ±6% and ≥80% ±6% of nominal voltage. CN81 PV/PC use non-isolated GND(signal). CN11 controls use GND-AUX, isolated from the main output. Follow the actual orientation and leave NC contacts disconnected. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300 series: Industrial AC/DC Power Supply - HEP-2300-55HMOD

  MEAN WELL HEP-2300-55HMOD is a fanless industrial AC/DC power supply with a factory 55 V output and 41.8 A factory current and a 2304 W maximum-power limit. This waterproof-connector version uses Modbus RTU over RS-485 and supports a configurable charging profile. Product Datasheet Download MEAN WELL HEP-2300 Datasheet (PDF) The HEP-2300 section is on PDF pages 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-55HMOD Series HEP-2300 Connection construction waterproof-connector Operating configuration Power-supply mode by default; charging can be configured Communication interface Modbus RTU over RS-485 Catalogue configuration availability By request Ingress-protection construction IP66 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. Terminal blank selects CANBus, and PM selects PMBus. W is the wired PV/PC version; WPM/WCAN select wired protocols. H/HPM/HMOD use waterproof connectors with CANBus, PMBus or Modbus RTU respectively. Output Ratings and Adjustment Factory default output voltage 55 V Factory default output current 41.8 A Factory default output power 2300 W Maximum output current 48 A Maximum rated output power 2304 W Voltage range at maximum rated power 48–57.6 V Ripple and noise maximum 480 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 39–57.6 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Battery-Charging Configuration Default boost charge voltage 57.6 V Default float charge voltage 55.2 V Rated charging current 40 A Battery-capacity reference 120–400 Ah Factory charging profile Three stages Three-stage charging uses constant current, constant boost voltage and then float. The two-stage curve omits float. The illustrated completion/float transition is at 10% of charging current. The charging table lists open and sealed lead-acid batteries. The programmable description also covers lithium-ion types, including lithium iron phosphate and lithium manganese. Confirm all voltage, current, stage and timeout settings with the battery manufacturer; the suggested Ah range is not permission to exceed its charging-current limit. Use the fitted Modbus RTU interface to configure charging curves and timeout parameters according to the manufacturer’s protocol manual. Power-supply and charging currents are different mode ratings. Do not substitute one for the other or replace the printed power limit by multiplying rounded charging-table values. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 59–69.1 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK relay Closed when normal; open during alarm AC Fail relay Closed when AC input is normal; open during alarm Temperature Alarm relay Open when normal; closed during alarm Relay contact rating 30 V maximum, 1 A maximum resistive load AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports Modbus RTU over RS-485. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. In power-supply mode green indicates normal output and red indicates protection. During charging, orange indicates stages 1/2, green indicates float/stage 3, and red indicates protection or charging timeout. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC input connector / AC input mating connector ALTW CC-03PMMS-QC800P; ALTW CC-03BFFA-QL8APP AC contacts and current limit / DC output 1 and 2 connectors 1 = AC/L; 2 = FG; 3 = AC/N; 20 A maximum; ALTW CC-03PMFS-QC800P DC output 1 and 2 mating connectors / DC output 1 and 2 contacts and limits ALTW CC-03BFMA-QL8APP; 1, 3 = +V; 2 = −V; 20 A maximum per connector DC output 3 and battery connectors / DC output 3 and battery mating connectors ALTW PWM-02RMFS-TS7001; ALTW PWM-02BFMB-TL7001 DC output 3 / battery contacts and rating / Alarm/control connector 1 = +V; 2 = −V; 50 A maximum connector rating; ALTW CD-12PMMS-QC8001 Alarm/control mating connector / Control pins 1 and 3 ALTW CD-12BFFA-QL8AP0; DC OK relay reference and signal Control pin 2 / Control pin 4 Remote ON/OFF; +12 V AUX Control pins 5 and 7 / Control pins 6 and 8 GND-AUX; AC Fail relay reference and signal Control pins 9 and 11 / Control pin 10 Temperature Alarm relay reference and signal; RS-485 Data+ Control pin 12 RS-485 Data− Connector ampere limits do not add power capacity. Keep combined outputs within 2304 W and the selected voltage/current limits. Charging is limited to 40 A; a 50 A connector does not increase charging current. For remote ON/OFF, short pin 2 to AUX pin 4 for ON and leave it open for OFF. Relay references are separate from the AUX return. Use the listed ALTW assemblies or suitable equivalents, maintain polarity, and seal unused ports with the appropriate optional caps. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. The charging specification lists storage at −40 to +80°C; the power-supply specification lists −40 to +85°C. Use the applicable mode specification. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Cap for output 3 and battery-charger ports PFF1ZAHB-A0025(A) Cap for AC input, output 1/2 and alarm/control ports PFF1CAP-WACMQMA1(B) Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300 series: Industrial AC/DC Power Supply - HEP-2300-55HPM

  MEAN WELL HEP-2300-55HPM is a fanless industrial AC/DC power supply with a factory 55 V output and 41.8 A factory current and a 2304 W maximum-power limit. This waterproof-connector version uses PMBus and supports a configurable charging profile. Product Datasheet Download MEAN WELL HEP-2300 Datasheet (PDF) The HEP-2300 section is on PDF pages 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-55HPM Series HEP-2300 Connection construction waterproof-connector Operating configuration Power-supply mode by default; charging can be configured Communication interface PMBus Catalogue configuration availability By request Ingress-protection construction IP66 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. Terminal blank selects CANBus, and PM selects PMBus. W is the wired PV/PC version; WPM/WCAN select wired protocols. H/HPM/HMOD use waterproof connectors with CANBus, PMBus or Modbus RTU respectively. Output Ratings and Adjustment Factory default output voltage 55 V Factory default output current 41.8 A Factory default output power 2300 W Maximum output current 48 A Maximum rated output power 2304 W Voltage range at maximum rated power 48–57.6 V Ripple and noise maximum 480 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 39–57.6 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Battery-Charging Configuration Default boost charge voltage 57.6 V Default float charge voltage 55.2 V Rated charging current 40 A Battery-capacity reference 120–400 Ah Factory charging profile Three stages Three-stage charging uses constant current, constant boost voltage and then float. The two-stage curve omits float. The illustrated completion/float transition is at 10% of charging current. The charging table lists open and sealed lead-acid batteries. The programmable description also covers lithium-ion types, including lithium iron phosphate and lithium manganese. Confirm all voltage, current, stage and timeout settings with the battery manufacturer; the suggested Ah range is not permission to exceed its charging-current limit. Use the separately selected MEAN WELL SBP-001 smart battery-charging programmer with a PC, or the actual fitted communication protocol, to configure curves and timeout parameters. Power-supply and charging currents are different mode ratings. Do not substitute one for the other or replace the printed power limit by multiplying rounded charging-table values. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 59–69.1 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK relay Closed when normal; open during alarm AC Fail relay Closed when AC input is normal; open during alarm Temperature Alarm relay Open when normal; closed during alarm Relay contact rating 30 V maximum, 1 A maximum resistive load AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports PMBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. In power-supply mode green indicates normal output and red indicates protection. During charging, orange indicates stages 1/2, green indicates float/stage 3, and red indicates protection or charging timeout. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC input connector / AC input mating connector ALTW CC-03PMMS-QC800P; ALTW CC-03BFFA-QL8APP AC contacts and current limit / DC output 1 and 2 connectors 1 = AC/L; 2 = FG; 3 = AC/N; 20 A maximum; ALTW CC-03PMFS-QC800P DC output 1 and 2 mating connectors / DC output 1 and 2 contacts and limits ALTW CC-03BFMA-QL8APP; 1, 3 = +V; 2 = −V; 20 A maximum per connector DC output 3 and battery connectors / DC output 3 and battery mating connectors ALTW PWM-02RMFS-TS7001; ALTW PWM-02BFMB-TL7001 DC output 3 / battery contacts and rating / Alarm/control connector 1 = +V; 2 = −V; 50 A maximum connector rating; ALTW CD-12PMMS-QC8001 Alarm/control mating connector / Control pins 1 and 3 ALTW CD-12BFFA-QL8AP0; DC OK relay reference and signal Control pin 2 / Control pin 4 Remote ON/OFF; +12 V AUX Control pins 5 and 7 / Control pins 6 and 8 GND-AUX; AC Fail relay reference and signal Control pins 9 and 11 / Control pin 10 Temperature Alarm relay reference and signal; SDA Control pin 12 SCL Connector ampere limits do not add power capacity. Keep combined outputs within 2304 W and the selected voltage/current limits. Charging is limited to 40 A; a 50 A connector does not increase charging current. For remote ON/OFF, short pin 2 to AUX pin 4 for ON and leave it open for OFF. Relay references are separate from the AUX return. Use the listed ALTW assemblies or suitable equivalents, maintain polarity, and seal unused ports with the appropriate optional caps. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. The charging specification lists storage at −40 to +80°C; the power-supply specification lists −40 to +85°C. Use the applicable mode specification. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Charging-curve programming option SBP-001 for the fitted supported protocol Cap for output 3 and battery-charger ports PFF1ZAHB-A0025(A) Cap for AC input, output 1/2 and alarm/control ports PFF1CAP-WACMQMA1(B) Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300 series: Industrial AC/DC Power Supply - HEP-2300-55H

  MEAN WELL HEP-2300-55H is a fanless industrial AC/DC power supply with a factory 55 V output and 41.8 A factory current and a 2304 W maximum-power limit. This waterproof-connector version uses CANBus and supports a configurable charging profile. Product Datasheet Download MEAN WELL HEP-2300 Datasheet (PDF) The HEP-2300 section is on PDF pages 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-55H Series HEP-2300 Connection construction waterproof-connector Operating configuration Power-supply mode by default; charging can be configured Communication interface CANBus Catalogue configuration availability In Stock Ingress-protection construction IP66 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. Terminal blank selects CANBus, and PM selects PMBus. W is the wired PV/PC version; WPM/WCAN select wired protocols. H/HPM/HMOD use waterproof connectors with CANBus, PMBus or Modbus RTU respectively. Output Ratings and Adjustment Factory default output voltage 55 V Factory default output current 41.8 A Factory default output power 2300 W Maximum output current 48 A Maximum rated output power 2304 W Voltage range at maximum rated power 48–57.6 V Ripple and noise maximum 480 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 39–57.6 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Battery-Charging Configuration Default boost charge voltage 57.6 V Default float charge voltage 55.2 V Rated charging current 40 A Battery-capacity reference 120–400 Ah Factory charging profile Three stages Three-stage charging uses constant current, constant boost voltage and then float. The two-stage curve omits float. The illustrated completion/float transition is at 10% of charging current. The charging table lists open and sealed lead-acid batteries. The programmable description also covers lithium-ion types, including lithium iron phosphate and lithium manganese. Confirm all voltage, current, stage and timeout settings with the battery manufacturer; the suggested Ah range is not permission to exceed its charging-current limit. Use the separately selected MEAN WELL SBP-001 smart battery-charging programmer with a PC, or the actual fitted communication protocol, to configure curves and timeout parameters. Power-supply and charging currents are different mode ratings. Do not substitute one for the other or replace the printed power limit by multiplying rounded charging-table values. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 59–69.1 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK relay Closed when normal; open during alarm AC Fail relay Closed when AC input is normal; open during alarm Temperature Alarm relay Open when normal; closed during alarm Relay contact rating 30 V maximum, 1 A maximum resistive load AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports CANBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. In power-supply mode green indicates normal output and red indicates protection. During charging, orange indicates stages 1/2, green indicates float/stage 3, and red indicates protection or charging timeout. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC input connector / AC input mating connector ALTW CC-03PMMS-QC800P; ALTW CC-03BFFA-QL8APP AC contacts and current limit / DC output 1 and 2 connectors 1 = AC/L; 2 = FG; 3 = AC/N; 20 A maximum; ALTW CC-03PMFS-QC800P DC output 1 and 2 mating connectors / DC output 1 and 2 contacts and limits ALTW CC-03BFMA-QL8APP; 1, 3 = +V; 2 = −V; 20 A maximum per connector DC output 3 and battery connectors / DC output 3 and battery mating connectors ALTW PWM-02RMFS-TS7001; ALTW PWM-02BFMB-TL7001 DC output 3 / battery contacts and rating / Alarm/control connector 1 = +V; 2 = −V; 50 A maximum connector rating; ALTW CD-12PMMS-QC8001 Alarm/control mating connector / Control pins 1 and 3 ALTW CD-12BFFA-QL8AP0; DC OK relay reference and signal Control pin 2 / Control pin 4 Remote ON/OFF; +12 V AUX Control pins 5 and 7 / Control pins 6 and 8 GND-AUX; AC Fail relay reference and signal Control pins 9 and 11 / Control pin 10 Temperature Alarm relay reference and signal; CANH Control pin 12 CANL Connector ampere limits do not add power capacity. Keep combined outputs within 2304 W and the selected voltage/current limits. Charging is limited to 40 A; a 50 A connector does not increase charging current. For remote ON/OFF, short pin 2 to AUX pin 4 for ON and leave it open for OFF. Relay references are separate from the AUX return. Use the listed ALTW assemblies or suitable equivalents, maintain polarity, and seal unused ports with the appropriate optional caps. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. The charging specification lists storage at −40 to +80°C; the power-supply specification lists −40 to +85°C. Use the applicable mode specification. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Charging-curve programming option SBP-001 for the fitted supported protocol Cap for output 3 and battery-charger ports PFF1ZAHB-A0025(A) Cap for AC input, output 1/2 and alarm/control ports PFF1CAP-WACMQMA1(B) Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300 series: Industrial AC/DC Power Supply - HEP-2300-55HMOD

  MEAN WELL HEP-2300-55HMOD is a fanless industrial AC/DC power supply with a factory 55 V output and 41.8 A factory current and a 2304 W maximum-power limit. This waterproof-connector version uses Modbus RTU over RS-485 and supports a configurable charging profile. Product Datasheet Download MEAN WELL HEP-2300 Datasheet (PDF) The HEP-2300 section is on PDF pages 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-55HMOD Series HEP-2300 Connection construction waterproof-connector Operating configuration Power-supply mode by default; charging can be configured Communication interface Modbus RTU over RS-485 Catalogue configuration availability By request Ingress-protection construction IP66 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. Terminal blank selects CANBus, and PM selects PMBus. W is the wired PV/PC version; WPM/WCAN select wired protocols. H/HPM/HMOD use waterproof connectors with CANBus, PMBus or Modbus RTU respectively. Output Ratings and Adjustment Factory default output voltage 55 V Factory default output current 41.8 A Factory default output power 2300 W Maximum output current 48 A Maximum rated output power 2304 W Voltage range at maximum rated power 48–57.6 V Ripple and noise maximum 480 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 39–57.6 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Battery-Charging Configuration Default boost charge voltage 57.6 V Default float charge voltage 55.2 V Rated charging current 40 A Battery-capacity reference 120–400 Ah Factory charging profile Three stages Three-stage charging uses constant current, constant boost voltage and then float. The two-stage curve omits float. The illustrated completion/float transition is at 10% of charging current. The charging table lists open and sealed lead-acid batteries. The programmable description also covers lithium-ion types, including lithium iron phosphate and lithium manganese. Confirm all voltage, current, stage and timeout settings with the battery manufacturer; the suggested Ah range is not permission to exceed its charging-current limit. Use the fitted Modbus RTU interface to configure charging curves and timeout parameters according to the manufacturer’s protocol manual. Power-supply and charging currents are different mode ratings. Do not substitute one for the other or replace the printed power limit by multiplying rounded charging-table values. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 59–69.1 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK relay Closed when normal; open during alarm AC Fail relay Closed when AC input is normal; open during alarm Temperature Alarm relay Open when normal; closed during alarm Relay contact rating 30 V maximum, 1 A maximum resistive load AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports Modbus RTU over RS-485. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. In power-supply mode green indicates normal output and red indicates protection. During charging, orange indicates stages 1/2, green indicates float/stage 3, and red indicates protection or charging timeout. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC input connector / AC input mating connector ALTW CC-03PMMS-QC800P; ALTW CC-03BFFA-QL8APP AC contacts and current limit / DC output 1 and 2 connectors 1 = AC/L; 2 = FG; 3 = AC/N; 20 A maximum; ALTW CC-03PMFS-QC800P DC output 1 and 2 mating connectors / DC output 1 and 2 contacts and limits ALTW CC-03BFMA-QL8APP; 1, 3 = +V; 2 = −V; 20 A maximum per connector DC output 3 and battery connectors / DC output 3 and battery mating connectors ALTW PWM-02RMFS-TS7001; ALTW PWM-02BFMB-TL7001 DC output 3 / battery contacts and rating / Alarm/control connector 1 = +V; 2 = −V; 50 A maximum connector rating; ALTW CD-12PMMS-QC8001 Alarm/control mating connector / Control pins 1 and 3 ALTW CD-12BFFA-QL8AP0; DC OK relay reference and signal Control pin 2 / Control pin 4 Remote ON/OFF; +12 V AUX Control pins 5 and 7 / Control pins 6 and 8 GND-AUX; AC Fail relay reference and signal Control pins 9 and 11 / Control pin 10 Temperature Alarm relay reference and signal; RS-485 Data+ Control pin 12 RS-485 Data− Connector ampere limits do not add power capacity. Keep combined outputs within 2304 W and the selected voltage/current limits. Charging is limited to 40 A; a 50 A connector does not increase charging current. For remote ON/OFF, short pin 2 to AUX pin 4 for ON and leave it open for OFF. Relay references are separate from the AUX return. Use the listed ALTW assemblies or suitable equivalents, maintain polarity, and seal unused ports with the appropriate optional caps. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. The charging specification lists storage at −40 to +80°C; the power-supply specification lists −40 to +85°C. Use the applicable mode specification. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Cap for output 3 and battery-charger ports PFF1ZAHB-A0025(A) Cap for AC input, output 1/2 and alarm/control ports PFF1CAP-WACMQMA1(B) Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300 series: Industrial AC/DC Power Supply - HEP-2300-55HPM

  MEAN WELL HEP-2300-55HPM is a fanless industrial AC/DC power supply with a factory 55 V output and 41.8 A factory current and a 2304 W maximum-power limit. This waterproof-connector version uses PMBus and supports a configurable charging profile. Product Datasheet Download MEAN WELL HEP-2300 Datasheet (PDF) The HEP-2300 section is on PDF pages 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-55HPM Series HEP-2300 Connection construction waterproof-connector Operating configuration Power-supply mode by default; charging can be configured Communication interface PMBus Catalogue configuration availability By request Ingress-protection construction IP66 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. Terminal blank selects CANBus, and PM selects PMBus. W is the wired PV/PC version; WPM/WCAN select wired protocols. H/HPM/HMOD use waterproof connectors with CANBus, PMBus or Modbus RTU respectively. Output Ratings and Adjustment Factory default output voltage 55 V Factory default output current 41.8 A Factory default output power 2300 W Maximum output current 48 A Maximum rated output power 2304 W Voltage range at maximum rated power 48–57.6 V Ripple and noise maximum 480 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 39–57.6 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Battery-Charging Configuration Default boost charge voltage 57.6 V Default float charge voltage 55.2 V Rated charging current 40 A Battery-capacity reference 120–400 Ah Factory charging profile Three stages Three-stage charging uses constant current, constant boost voltage and then float. The two-stage curve omits float. The illustrated completion/float transition is at 10% of charging current. The charging table lists open and sealed lead-acid batteries. The programmable description also covers lithium-ion types, including lithium iron phosphate and lithium manganese. Confirm all voltage, current, stage and timeout settings with the battery manufacturer; the suggested Ah range is not permission to exceed its charging-current limit. Use the separately selected MEAN WELL SBP-001 smart battery-charging programmer with a PC, or the actual fitted communication protocol, to configure curves and timeout parameters. Power-supply and charging currents are different mode ratings. Do not substitute one for the other or replace the printed power limit by multiplying rounded charging-table values. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 59–69.1 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK relay Closed when normal; open during alarm AC Fail relay Closed when AC input is normal; open during alarm Temperature Alarm relay Open when normal; closed during alarm Relay contact rating 30 V maximum, 1 A maximum resistive load AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports PMBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. In power-supply mode green indicates normal output and red indicates protection. During charging, orange indicates stages 1/2, green indicates float/stage 3, and red indicates protection or charging timeout. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC input connector / AC input mating connector ALTW CC-03PMMS-QC800P; ALTW CC-03BFFA-QL8APP AC contacts and current limit / DC output 1 and 2 connectors 1 = AC/L; 2 = FG; 3 = AC/N; 20 A maximum; ALTW CC-03PMFS-QC800P DC output 1 and 2 mating connectors / DC output 1 and 2 contacts and limits ALTW CC-03BFMA-QL8APP; 1, 3 = +V; 2 = −V; 20 A maximum per connector DC output 3 and battery connectors / DC output 3 and battery mating connectors ALTW PWM-02RMFS-TS7001; ALTW PWM-02BFMB-TL7001 DC output 3 / battery contacts and rating / Alarm/control connector 1 = +V; 2 = −V; 50 A maximum connector rating; ALTW CD-12PMMS-QC8001 Alarm/control mating connector / Control pins 1 and 3 ALTW CD-12BFFA-QL8AP0; DC OK relay reference and signal Control pin 2 / Control pin 4 Remote ON/OFF; +12 V AUX Control pins 5 and 7 / Control pins 6 and 8 GND-AUX; AC Fail relay reference and signal Control pins 9 and 11 / Control pin 10 Temperature Alarm relay reference and signal; SDA Control pin 12 SCL Connector ampere limits do not add power capacity. Keep combined outputs within 2304 W and the selected voltage/current limits. Charging is limited to 40 A; a 50 A connector does not increase charging current. For remote ON/OFF, short pin 2 to AUX pin 4 for ON and leave it open for OFF. Relay references are separate from the AUX return. Use the listed ALTW assemblies or suitable equivalents, maintain polarity, and seal unused ports with the appropriate optional caps. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. The charging specification lists storage at −40 to +80°C; the power-supply specification lists −40 to +85°C. Use the applicable mode specification. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Charging-curve programming option SBP-001 for the fitted supported protocol Cap for output 3 and battery-charger ports PFF1ZAHB-A0025(A) Cap for AC input, output 1/2 and alarm/control ports PFF1CAP-WACMQMA1(B) Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300 series: Industrial AC/DC Power Supply - HEP-2300-55H

  MEAN WELL HEP-2300-55H is a fanless industrial AC/DC power supply with a factory 55 V output and 41.8 A factory current and a 2304 W maximum-power limit. This waterproof-connector version uses CANBus and supports a configurable charging profile. Product Datasheet Download MEAN WELL HEP-2300 Datasheet (PDF) The HEP-2300 section is on PDF pages 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-55H Series HEP-2300 Connection construction waterproof-connector Operating configuration Power-supply mode by default; charging can be configured Communication interface CANBus Catalogue configuration availability In Stock Ingress-protection construction IP66 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. Terminal blank selects CANBus, and PM selects PMBus. W is the wired PV/PC version; WPM/WCAN select wired protocols. H/HPM/HMOD use waterproof connectors with CANBus, PMBus or Modbus RTU respectively. Output Ratings and Adjustment Factory default output voltage 55 V Factory default output current 41.8 A Factory default output power 2300 W Maximum output current 48 A Maximum rated output power 2304 W Voltage range at maximum rated power 48–57.6 V Ripple and noise maximum 480 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 39–57.6 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Battery-Charging Configuration Default boost charge voltage 57.6 V Default float charge voltage 55.2 V Rated charging current 40 A Battery-capacity reference 120–400 Ah Factory charging profile Three stages Three-stage charging uses constant current, constant boost voltage and then float. The two-stage curve omits float. The illustrated completion/float transition is at 10% of charging current. The charging table lists open and sealed lead-acid batteries. The programmable description also covers lithium-ion types, including lithium iron phosphate and lithium manganese. Confirm all voltage, current, stage and timeout settings with the battery manufacturer; the suggested Ah range is not permission to exceed its charging-current limit. Use the separately selected MEAN WELL SBP-001 smart battery-charging programmer with a PC, or the actual fitted communication protocol, to configure curves and timeout parameters. Power-supply and charging currents are different mode ratings. Do not substitute one for the other or replace the printed power limit by multiplying rounded charging-table values. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 59–69.1 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF Remote ON/OFF Short Remote ON/OFF to +12 V AUX for ON; open for OFF DC OK relay Closed when normal; open during alarm AC Fail relay Closed when AC input is normal; open during alarm Temperature Alarm relay Open when normal; closed during alarm Relay contact rating 30 V maximum, 1 A maximum resistive load AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports CANBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. In power-supply mode green indicates normal output and red indicates protection. During charging, orange indicates stages 1/2, green indicates float/stage 3, and red indicates protection or charging timeout. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC input connector / AC input mating connector ALTW CC-03PMMS-QC800P; ALTW CC-03BFFA-QL8APP AC contacts and current limit / DC output 1 and 2 connectors 1 = AC/L; 2 = FG; 3 = AC/N; 20 A maximum; ALTW CC-03PMFS-QC800P DC output 1 and 2 mating connectors / DC output 1 and 2 contacts and limits ALTW CC-03BFMA-QL8APP; 1, 3 = +V; 2 = −V; 20 A maximum per connector DC output 3 and battery connectors / DC output 3 and battery mating connectors ALTW PWM-02RMFS-TS7001; ALTW PWM-02BFMB-TL7001 DC output 3 / battery contacts and rating / Alarm/control connector 1 = +V; 2 = −V; 50 A maximum connector rating; ALTW CD-12PMMS-QC8001 Alarm/control mating connector / Control pins 1 and 3 ALTW CD-12BFFA-QL8AP0; DC OK relay reference and signal Control pin 2 / Control pin 4 Remote ON/OFF; +12 V AUX Control pins 5 and 7 / Control pins 6 and 8 GND-AUX; AC Fail relay reference and signal Control pins 9 and 11 / Control pin 10 Temperature Alarm relay reference and signal; CANH Control pin 12 CANL Connector ampere limits do not add power capacity. Keep combined outputs within 2304 W and the selected voltage/current limits. Charging is limited to 40 A; a 50 A connector does not increase charging current. For remote ON/OFF, short pin 2 to AUX pin 4 for ON and leave it open for OFF. Relay references are separate from the AUX return. Use the listed ALTW assemblies or suitable equivalents, maintain polarity, and seal unused ports with the appropriate optional caps. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. The charging specification lists storage at −40 to +80°C; the power-supply specification lists −40 to +85°C. Use the applicable mode specification. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Charging-curve programming option SBP-001 for the fitted supported protocol Cap for output 3 and battery-charger ports PFF1ZAHB-A0025(A) Cap for AC input, output 1/2 and alarm/control ports PFF1CAP-WACMQMA1(B) Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300 series: Industrial AC/DC Power Supply - HEP-2300-55WCAN

  MEAN WELL HEP-2300-55WCAN is a fanless industrial AC/DC power supply with a factory 55 V output and 41.8 A factory current and a 2304 W maximum-power limit. This wired version uses CANBus and supports a configurable charging profile. Product Datasheet Download MEAN WELL HEP-2300 Datasheet (PDF) The HEP-2300 section is on PDF pages 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-55WCAN Series HEP-2300 Connection construction wired Operating configuration Power-supply mode by default; charging can be configured Communication interface CANBus Catalogue configuration availability By request Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. Terminal blank selects CANBus, and PM selects PMBus. W is the wired PV/PC version; WPM/WCAN select wired protocols. H/HPM/HMOD use waterproof connectors with CANBus, PMBus or Modbus RTU respectively. Output Ratings and Adjustment Factory default output voltage 55 V Factory default output current 41.8 A Factory default output power 2300 W Maximum output current 48 A Maximum rated output power 2304 W Voltage range at maximum rated power 48–57.6 V Ripple and noise maximum 480 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 39–57.6 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Battery-Charging Configuration Default boost charge voltage 57.6 V Default float charge voltage 55.2 V Rated charging current 40 A Battery-capacity reference 120–400 Ah Factory charging profile Three stages Three-stage charging uses constant current, constant boost voltage and then float. The two-stage curve omits float. The illustrated completion/float transition is at 10% of charging current. The charging table lists open and sealed lead-acid batteries. The programmable description also covers lithium-ion types, including lithium iron phosphate and lithium manganese. Confirm all voltage, current, stage and timeout settings with the battery manufacturer; the suggested Ah range is not permission to exceed its charging-current limit. Use the separately selected MEAN WELL SBP-001 smart battery-charging programmer with a PC, or the actual fitted communication protocol, to configure curves and timeout parameters. Power-supply and charging currents are different mode ratings. Do not substitute one for the other or replace the printed power limit by multiplying rounded charging-table values. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 59–69.1 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports CANBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. During charging, orange indicates stages 1/2, green indicates float/stage 3, and red indicates protection or charging timeout. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length Three SJOW 14 AWG × 2C cables; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; CANH / CANL / GND-AUX Use the colours and lead construction for this exact suffix. These wired versions do not provide the terminal model’s remote ON/OFF input. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. The charging specification lists storage at −40 to +80°C; the power-supply specification lists −40 to +85°C. Use the applicable mode specification. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Charging-curve programming option SBP-001 for the fitted supported protocol Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300 series: Industrial AC/DC Power Supply - HEP-2300-55WPM

  MEAN WELL HEP-2300-55WPM is a fanless industrial AC/DC power supply with a factory 55 V output and 41.8 A factory current and a 2304 W maximum-power limit. This wired version uses PMBus and supports a configurable charging profile. Product Datasheet Download MEAN WELL HEP-2300 Datasheet (PDF) The HEP-2300 section is on PDF pages 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-55WPM Series HEP-2300 Connection construction wired Operating configuration Power-supply mode by default; charging can be configured Communication interface PMBus Catalogue configuration availability By request Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. Terminal blank selects CANBus, and PM selects PMBus. W is the wired PV/PC version; WPM/WCAN select wired protocols. H/HPM/HMOD use waterproof connectors with CANBus, PMBus or Modbus RTU respectively. Output Ratings and Adjustment Factory default output voltage 55 V Factory default output current 41.8 A Factory default output power 2300 W Maximum output current 48 A Maximum rated output power 2304 W Voltage range at maximum rated power 48–57.6 V Ripple and noise maximum 480 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 39–57.6 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Battery-Charging Configuration Default boost charge voltage 57.6 V Default float charge voltage 55.2 V Rated charging current 40 A Battery-capacity reference 120–400 Ah Factory charging profile Three stages Three-stage charging uses constant current, constant boost voltage and then float. The two-stage curve omits float. The illustrated completion/float transition is at 10% of charging current. The charging table lists open and sealed lead-acid batteries. The programmable description also covers lithium-ion types, including lithium iron phosphate and lithium manganese. Confirm all voltage, current, stage and timeout settings with the battery manufacturer; the suggested Ah range is not permission to exceed its charging-current limit. Use the separately selected MEAN WELL SBP-001 smart battery-charging programmer with a PC, or the actual fitted communication protocol, to configure curves and timeout parameters. Power-supply and charging currents are different mode ratings. Do not substitute one for the other or replace the printed power limit by multiplying rounded charging-table values. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 59–69.1 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. This order code supports PMBus. Use its manufacturer protocol manual for addresses, commands and bus parameters; PMBus, CANBus and RS-485 are not interchangeable interfaces. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. During charging, orange indicates stages 1/2, green indicates float/stage 3, and red indicates protection or charging timeout. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length Three SJOW 14 AWG × 2C cables; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; SDA / SCL / GND-AUX Use the colours and lead construction for this exact suffix. These wired versions do not provide the terminal model’s remote ON/OFF input. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. The charging specification lists storage at −40 to +80°C; the power-supply specification lists −40 to +85°C. Use the applicable mode specification. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Charging-curve programming option SBP-001 for the fitted supported protocol Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options

•

  View options

  MEAN WELL HEP-2300 series: Industrial AC/DC Power Supply - HEP-2300-55W

  MEAN WELL HEP-2300-55W is a fanless industrial AC/DC power supply with a factory 55 V output and 41.8 A factory current and a 2304 W maximum-power limit. This wired version uses external PV/PC control. Product Datasheet Download MEAN WELL HEP-2300 Datasheet (PDF) The HEP-2300 section is on PDF pages 39, 40, 41, 42, 43, 44, 45, 46, 47, 48, 49, 50, 51, 52, 53, 54. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order code HEP-2300-55W Series HEP-2300 Connection construction wired Operating configuration Power-supply mode Communication interface No digital communication interface Catalogue configuration availability In Stock Ingress-protection construction IP67 The full suffix selects the interface and construction. Catalogue availability identifies the configuration, not current distributor stock. Terminal blank selects CANBus, and PM selects PMBus. W is the wired PV/PC version; WPM/WCAN select wired protocols. H/HPM/HMOD use waterproof connectors with CANBus, PMBus or Modbus RTU respectively. Output Ratings and Adjustment Factory default output voltage 55 V Factory default output current 41.8 A Factory default output power 2300 W Maximum output current 48 A Maximum rated output power 2304 W Voltage range at maximum rated power 48–57.6 V Ripple and noise maximum 480 mVp-p Voltage tolerance ±1% Line regulation ±0.5% Load regulation ±0.5% Output adjustment range 39–57.6 V Voltage tolerance includes initial setting, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth, a 12-inch twisted-pair lead, and 0.1 µF plus 47 µF capacitors in parallel at the output. Observe voltage, current, rated-power and derating limits together. Maximum voltage and maximum current are not unrestricted simultaneous operating points. Use only the local or external adjustment available on this construction. Factory voltage, current and printed power are separate catalogue entries; their rounded product does not replace the maximum-power limit. Input Supply and Timing AC input voltage range 90–305 VAC DC input voltage range 250–431 VDC AC frequency 47–63 Hz Typical power factor >0.99 at 115 VAC; >0.95 at 230 VAC; >0.93 at 277 VAC, full load Typical input current 13.3 A at 115 VAC; 11 A at 230 VAC; 9.3 A at 277 VAC Typical efficiency 95.5% Typical cold-start inrush current 60 A at 230 VAC Leakage current <1.8 mA peak at 240 VAC; <2 mA peak at 277 VAC Set-up / rise time 1800 / 100 ms at 230 VAC, full load Typical hold-up time 12 ms at 230 VAC, full load Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C ambient. Active PFC is built in. Apply the input-voltage derating curve; the input range does not guarantee full output at every voltage. Set-up and rise times refer to the first cold start. Rapid repeated switching can increase rise time. Protection and Recovery Overload threshold 105–115% of rated output power Overload recovery Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Short-circuit protection Constant-current limiting, then output shutdown after 5 seconds; reapply AC power Over-voltage protection 59–69.1 V; shutdown, reapply AC power Over-temperature protection Shutdown; automatic recovery after cooling External Voltage and Current Programming External PV input 0–5 VDC Output-voltage programming range 50–120% of the plotted voltage reference External PC input 0–5 VDC Current programming range 20–100% of rated current PV 100% voltage reference 48 V The voltage/current control relationships are non-linear. Use the catalogue curves rather than proportional interpolation. Below 0.4 V external control, the default setting applies. The minimum-control plateau is 50% voltage or 20% current. PV/PC use the non-isolated GND(signal) reference, not GND-AUX. Applying PV control disables the local SVR voltage adjustment; follow the connections for this exact construction. The voltage-dependent current envelope rises from 80% at 24 V to 100% at 43.2 V, stays at 100% through 48 V, and falls to 83.3% at 57.6 V. The factory voltage is a separate operating point; observe the maximum-power limit. PC reaches its plotted 100% current point at 4.7 V external control. The manufacturer recommends a programmed current below 100% of rated current. Auxiliary Output, Control and Status Auxiliary output 12 V, 0.5 A, ±10%; maximum ripple 150 mVp-p Auxiliary behaviour Available independently of remote main-output ON/OFF DC OK signal High for output ON; low for output OFF AUX is a separate control supply. Do not add its current to the main output rating. Its GND-AUX return is isolated from the main DC output. The main specification gives 4.5–5.5 V ON; the detailed interface table gives 4.4–5.5 V high. Both use −0.5 to +0.5 V low. Reference DC OK to GND-AUX; maximum sourcing current is 10 mA and maximum external voltage is 5.5 V. In power-supply mode green indicates normal output and red indicates protection. Flashing red is the approximately 95°C internal-temperature warning while output remains operating; it is not an ambient-temperature rating. Connections, Pin Assignments and Mating Parts AC cable / AC colours SJTW 14 AWG × 3C, 300 ±20 mm; Brown = AC/L; blue = AC/N; green/yellow = FG DC cable construction / DC cable length Three SJOW 14 AWG × 2C cables; 300 ±20 mm DC colours / Control cable Red = +V; black = −V; Two UL2517 22 AWG × 3C cables, 360 ±20 mm Control cable 1: brown / yellow / black / Control cable 2: green / blue / white DC OK / +12 V AUX / GND-AUX; PV / PC / GND(signal) Use the colours and lead construction for this exact suffix. These wired versions do not provide the terminal model’s remote ON/OFF input. Route and insulate leads to preserve the stated ingress protection. PV/PC use a non-isolated output reference. For communication versions, the wiring-page note references isolated GND-AUX; connect communication and auxiliary returns according to that diagram. Environment and Derating Working ambient temperature −40 to +70°C, subject to load and orientation Working humidity 20–95% RH, non-condensing Storage temperature −40 to +85°C Storage humidity 10–95% RH, non-condensing Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 20–500 Hz, 10G; 12 minutes/cycle, 72 minutes each along X, Y and Z Cooling and case Fanless conduction cooling; aluminium case filled with heat-conducting glue Catalogue warranty 6 years For operation above 2000 m, reduce the permitted ambient temperature by 3.5°C for each additional 1000 m for this fanless supply. Follow the stated orientation and mounting clearances. Horizontal mounting permits full load through +40°C and reduces to 60% at +60°C. Vertical mounting permits full load through +50°C and reduces to 60% at +70°C. Do not extend the horizontal curve beyond its plotted +60°C endpoint. The 60 Hz input curve shows 50% load at 90 VAC, 60% at 115 VAC and full load from 220 through 305 VAC. Apply input and temperature derating together. The catalogue life reference is at least 55,000 hours when the marked case temperature Tc is approximately 80°C or less. The temperature-dependent life plot is a design reference, not a warranty extension. Dimensions, Mounting and Weight Catalogue body dimensions 375 × 280 × 88 mm Catalogue packing reference per unit 12500 g Standard mounting-plate envelope references 447 mm length; 91 mm height Bottom mounting Four M6, L = 25 mm screws Side mounting Two M6, L = 15 mm screws This is the catalogue packing reference per unit, not a measured net or parcel mass. The table lists 12.5 kg per unit and one unit per 13.5 kg carton. Allow connection and cable clearance separately from body dimensions. Use the mounting drawing’s edge-reference coordinates for hole positions and apply the corresponding horizontal or vertical thermal curve. Rear pole mounting uses PGG2BKT-003 with PGG2BKT-004. Side pole mounting uses PGG2BKT-001, PGG2BKT-002 and PGG2BKT-004. The illustrated pole installation has the AC-input side downward. Compatible Optional Equipment Optional housing-side bracket PGG2BKT-001 Optional pole-side bracket PGG2BKT-002 Optional rear plate PGG2BKT-003 Optional pole-attachment kit PGG2BKT-004 Select only the items listed here for the stated construction and purpose. Optional items are selected separately according to the actual order; an installation illustration does not establish package contents. Safety, EMC and Reliability Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004 Input-to-output withstand 6 kVDC Input-to-FG withstand 4 kVDC Output-to-FG withstand 4 kVDC Insulation resistance 100 MΩ at 500 VDC, 25°C, 70% RH Minimum MTBF, Telcordia SR-332 478 k hours Minimum MTBF, MIL-HDBK-217F at 25°C 44.8 k hours Over-voltage category OVC III BS EN/EN61558-1 and BS EN/EN60335-1 are design references available by request; this does not constitute approval of the complete installation. Conducted emissions follow BS EN/EN55032 (CISPR32) Class B. Radiated emissions are Class A. Harmonic current follows BS EN/EN61000-3-2 Class A; flicker follows BS EN/EN61000-3-3. Immunity references are BS EN/EN55024 and BS EN/EN61000-6-2: ESD 8 kV air / 4 kV contact; radiated immunity and EFT level 3; surge 2 kV line-to-line / 4 kV line-to-earth; conducted immunity level 3; magnetic-field level 4. Dips include >95% for 0.5 period and 30% for 25 periods, with >95% interruption for 250 periods. This is a component for installation in finished equipment. Confirm EMC in the final system. The test setup uses a 1100 × 650 × 1 mm metal plate. For the specified isolation test, temporarily remove the identified Screw A and reinstall it afterward.

  Read more less

  $2,532.30

  View options
