MEAN WELL HRPG-1000N3-48 is an enclosed AC/DC power supply rated at 1008 W, 48 V and 21 A. It combines active PFC, fan cooling, remote sensing and current sharing; high-peak operation is limited by the input/model curve, pulse duration, duty cycle and average power. Product Datasheet Download MEAN WELL HRPG-1000N3 Datasheet (PDF) The HRPG-1000N3 section is on PDF pages 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Configuration Complete model HRPG-1000N3-48 HRPG / 1000 / N3 HRPG identifies the series; 1000 is the nominal power class; N3 denotes the three-times-peak-power design. Use this model's 1008 W continuous rating and its specific peak/duty curve. Output-voltage code 48 denotes a nominal 48 V single output. Built-in functions Active PFC, fan cooling, remote sensing, remote ON/OFF, DC-OK, active current sharing and an independent 5 V standby output. Output Specifications Nominal voltage / rated current 48 V / 21 A Current range / rated output power 0 to 21 A / 1008 W Output adjustment 46 to 56 V Ripple and noise, maximum 250 mVp-p Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Efficiency, typical 94% Setup / rise time 1000 ms / 50 ms at 230 VAC; 2000 ms / 50 ms at 115 VAC, full load Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load Voltage tolerance includes setup, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth and a 12-inch twisted pair terminated by parallel 0.1 uF and 47 uF capacitors. Setup time is measured at first cold start; repeated input ON/OFF may increase it. Input and Power Conversion Input range / frequency 90 to 264 VAC or 127 to 370 VDC; 47 to 63 Hz for AC input Short-duration withstand 300 VAC for 5 seconds; this does not extend the continuous input range Power factor, typical >0.95 at 230 VAC; >0.99 at 115 VAC, full load AC input current, typical 8.5 A at 115 VAC; 5 A at 230 VAC Inrush current, typical 25 A at 115 VAC; 40 A at 230 VAC Leakage current <1.2 mA at 240 VAC Switching / input functions PFC 65 kHz; PWM 90 kHz; active inrush-current limiting. No-load power <0.85 W with CN100 pins 3 (RC+) and 4 (RC-) open, switching the main output OFF. Peak Power and Repetition Limits Average-power requirement Pav = [Ppk x t + Pnpk x (T - t)] / T <= Prated. This model's Prated is 1008 W. Pulse / duty limit Peak pulses must not exceed 5 seconds. Duty = t / T x 100% <= 35%, with a lower duty limit where required by the input/model curve. 100 VAC curve anchors 1300 W at 35% duty; 1600 W at 10%; 2000 W at 5%. These are upper curve points, not continuous output ratings. 200 VAC, 48 V curve 2200 W at 35% duty; 2500 W at 25%; 2800 W at 15%; 3200 W at 5%. Use the 24 V / 36 V / 48 V curve, not the lower 12 V branch. Ppk is peak power; Pnpk non-peak power; t peak duration; T repetition period; Pav average power. Apply the peak/duty curve, average-power limit, input-voltage and temperature derating together. A 35% global duty ceiling does not authorize maximum peak power at 35% duty. The datasheet advertises up to 320% peak capability for the series. This is a short-duration, input- and model-dependent feature, not an unconditional multiplier of every model's rated wattage. Use the complete plotted curves for intermediate points. The 2500 W / 25% duty / 20-second-period / 511 W non-peak worked example is explicitly for the 24 V model. Do not assign its non-peak limit to this 48 V model without applying the complete curve and average-power calculation. Protection and Restart Timed overload shutdown Output power >105% of rated for more than 5 seconds causes output shutdown; re-power to recover. Model-specific higher overload threshold For this 48 V model, output power >350% of rated causes shutdown; re-power to recover. This protection threshold is not an allowable peak rating. Over-voltage trip / recovery 58 to 65 V; output shuts down, re-power to recover. Over-temperature protection Output shuts down and recovers automatically after temperature falls. Restart after protection The catalog instructs restarting about 30 seconds after input power is disconnected. Short-circuit protection is listed. Do not treat overload shutdown as a documented continuous constant-current operating mode or automatic overload restart. Thermal, Input and Environmental Limits Cooling / fan control Built-in fan. The table specifies ON/OFF control by NTC (RT50) or 30% minimum load; no precise temperature setpoint is given. Operating temperature / humidity -40°C to +70°C is the series table range; apply this model's temperature curve. Working humidity: 20% to 90% RH, non-condensing. Model-specific thermal curve Horizontal mounting: 100% load through 60°C, then derate to 60% load at 70°C. Do not extend operation beyond this model's plotted endpoint. Low-input curve At 60 Hz: 80% load at 90 VAC, increasing to 100% at 200 VAC; 100% is plotted from 200 to 264 VAC. Combine with thermal and peak/duty limits. Storage / temperature coefficient -40°C to +85°C, 10% to 95% RH non-condensing; temperature coefficient ±0.03%/°C over 0°C to 50°C. Vibration 10 to 500 Hz, 5 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Altitude derating Above 2000 m, reduce allowed ambient temperature by 5°C per 1000 m for this fan-cooled model. These pages do not specify a maximum operating altitude. Follow the fan airflow direction and complete mechanical drawing. Do not apply fanless-model altitude derating or a 5000 m limit from another power class. Power Terminals and CN100 Signal Pins AC input terminals 1: AC/L; 2: AC/N; 3: FG / protective earth. DC output terminals 1 to 3: +V; 4 to 6: -V. CN100 pins 1 / 2 1: AUXG, auxiliary-output ground. 2: AUX, auxiliary output referenced to pin 1. CN100 pins 3 / 4 3: RC+, remote-control input. 4: RC-, remote-control ground. CN100 pins 5 / 6 / 8 5: CS, current-sharing signal. 6 and 8: GND, connected to main -V and used as DC-OK return. CN100 pins 7 / 9 / 10 7: DC-OK. 9: +S, positive remote sense. 10: -S, negative remote sense. CN100 connector / housing HRS DF11-10DP-2DS / HRS DF11-10DS, or equivalents. Mating contact family, as printed HRS DF11-**SC, or equivalent. DF11-**SC contains a wildcard; it is not a complete purchasable terminal variant. Select the exact contact for the wire and housing. The reviewed pages do not state an included harness, jumper, connector quantity or separate mounting kit. Remote Sense, Control, Standby and DC-OK Remote sensing Connect +S (pin 9) to load positive and -S (pin 10) to load negative. Twist the sense pair; maximum line-drop compensation is 0.5 V. Remote ON/OFF logic Short pins 3 and 4 for main output ON; open them for OFF. A required closed contact is not evidence that a jumper is included. 5 V standby output 5 V at up to 0.3 A; tolerance ±5%; ripple 50 mVp-p maximum; range 4.75 to 5.25 V, referenced to AUXG (pin 1). The output is not controlled by remote ON/OFF. DC-OK signal TTL signal on pin 7: 3.3 to 5.6 V when ON; 0 to 1 V when OFF. Referenced to GND pin 8; the function table also identifies pin 6 as GND. Active Current Sharing Parallel configuration Up to four units. The series feature list describes up to 4000 W / (3+1), but the usable continuous output must satisfy the rated-current equation and all derating. Maximum parallel output current Rated current per unit x number of units x 0.9. For this model, use 21 A as the rated current per unit. Voltage matching / minimum-load boundary Output-voltage difference between units must be <0.2 V. Below 5% of the combined rated current, sharing may not be fully balanced. Interconnections Use short, large-diameter power wiring to the common load. Join CS pin 5 and GND as shown in the parallel diagram. Keep remote-control and sense connections consistent with that diagram. The documented parallel-current formula is not permission to multiply an individual peak-power curve by the unit count. Verify the complete load, thermal and wiring requirements of the planned parallel system. Dimensions and Installation Body dimensions / case 218 x 105 x 61.5 mm (L x W x H), case 977H; mechanical drawing tolerance ±1 mm. Threaded mounting holes Base: 4-M4, L=6. Sides: 8-M4, L=4, both sides as printed. These annotations are not included screw quantities. Mounting references Base fixing spans 152.4 x 63.5 mm; side fixing spans 152.4 x 38.3 mm. Use the complete drawing for offsets and individual locations. Terminal projections Input side 12 mm maximum; output side 18 mm maximum. Terminal drawing dimensions Input labels 10 mm and 8.2 mm; output labels 11 mm and 9.2 mm. These are drawing labels; not all are terminal pitch. Indicators / local adjustment The mechanical drawing identifies the LED, CN100 and SVR1 voltage adjustment. Keep adjustment within the specified range. Follow the illustrated fan airflow direction and mounting depths. These pages do not state terminal torque, wire gauge or installation-clearance values; do not import such values from another model. Safety, EMC and Reliability Listed safety standards UL62368-1; CAN/CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; AS/NZS 62368.1; EAC TP TC 004. Dielectric withstand / insulation Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance: 100 MΩ for all three pairs at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55032 (CISPR32) Class B conducted and radiated; BS EN/EN61000-3-2 Class A harmonics; BS EN/EN61000-3-3 flicker. Immunity standards / levels BS EN/EN55035 and BS EN/EN61000-6-2. ESD -4-2: Level 3, 8 kV air / Level 2, 4 kV contact; radiated -4-3: Level 3; EFT -4-4: Level 3; conducted -4-6: Level 3; magnetic field -4-8: Level 4. Surge immunity BS EN/EN61000-4-5: Level 4, 2 kV line-line and 4 kV line-earth. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruptions for 250 periods. MTBF, minimum 989.2K hours, Telcordia SR-332 (Bellcore); 130.6K hours, MIL-HDBK-217F at 25°C. EMC tests used a 360 x 700 mm metal plate, 1 mm thick. This is a component for final equipment, which must be rechecked against the applicable EMC requirements. MTBF is statistical and is not a service-life guarantee. Weight and Manufacturer Notes Per-unit catalog packing reference 1.46 kg (1460 g), from the PACKING entry; not a separately measured net or shipment weight. Full packing entry 1.46 kg; 8 pcs / 12.8 kg / 1.58 CUFT. Catalog revision / warranty statement 2026-04-03; the manufacturer datasheet lists 5 years warranty. This adds no separate seller warranty. Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. The complete model-specific curves and protection-restart instructions remain applicable.

Read more less

MEAN WELL HRPG-1000N3-36 is an enclosed AC/DC power supply rated at 1008 W, 36 V and 28 A. It combines active PFC, fan cooling, remote sensing and current sharing; high-peak operation is limited by the input/model curve, pulse duration, duty cycle and average power. Product Datasheet Download MEAN WELL HRPG-1000N3 Datasheet (PDF) The HRPG-1000N3 section is on PDF pages 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Configuration Complete model HRPG-1000N3-36 HRPG / 1000 / N3 HRPG identifies the series; 1000 is the nominal power class; N3 denotes the three-times-peak-power design. Use this model's 1008 W continuous rating and its specific peak/duty curve. Output-voltage code 36 denotes a nominal 36 V single output. Built-in functions Active PFC, fan cooling, remote sensing, remote ON/OFF, DC-OK, active current sharing and an independent 5 V standby output. Output Specifications Nominal voltage / rated current 36 V / 28 A Current range / rated output power 0 to 28 A / 1008 W Output adjustment 32 to 38 V Ripple and noise, maximum 250 mVp-p Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Efficiency, typical 93% Setup / rise time 1000 ms / 50 ms at 230 VAC; 2000 ms / 50 ms at 115 VAC, full load Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load Voltage tolerance includes setup, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth and a 12-inch twisted pair terminated by parallel 0.1 uF and 47 uF capacitors. Setup time is measured at first cold start; repeated input ON/OFF may increase it. Input and Power Conversion Input range / frequency 90 to 264 VAC or 127 to 370 VDC; 47 to 63 Hz for AC input Short-duration withstand 300 VAC for 5 seconds; this does not extend the continuous input range Power factor, typical >0.95 at 230 VAC; >0.99 at 115 VAC, full load AC input current, typical 8.5 A at 115 VAC; 5 A at 230 VAC Inrush current, typical 25 A at 115 VAC; 40 A at 230 VAC Leakage current <1.2 mA at 240 VAC Switching / input functions PFC 65 kHz; PWM 90 kHz; active inrush-current limiting. No-load power <0.85 W with CN100 pins 3 (RC+) and 4 (RC-) open, switching the main output OFF. Peak Power and Repetition Limits Average-power requirement Pav = [Ppk x t + Pnpk x (T - t)] / T <= Prated. This model's Prated is 1008 W. Pulse / duty limit Peak pulses must not exceed 5 seconds. Duty = t / T x 100% <= 35%, with a lower duty limit where required by the input/model curve. 100 VAC curve anchors 1300 W at 35% duty; 1600 W at 10%; 2000 W at 5%. These are upper curve points, not continuous output ratings. 200 VAC, 36 V curve 2200 W at 35% duty; 2500 W at 25%; 2800 W at 15%; 3200 W at 5%. Use the 24 V / 36 V / 48 V curve, not the lower 12 V branch. Ppk is peak power; Pnpk non-peak power; t peak duration; T repetition period; Pav average power. Apply the peak/duty curve, average-power limit, input-voltage and temperature derating together. A 35% global duty ceiling does not authorize maximum peak power at 35% duty. The datasheet advertises up to 320% peak capability for the series. This is a short-duration, input- and model-dependent feature, not an unconditional multiplier of every model's rated wattage. Use the complete plotted curves for intermediate points. The 2500 W / 25% duty / 20-second-period / 511 W non-peak worked example is explicitly for the 24 V model. Do not assign its non-peak limit to this 36 V model without applying the complete curve and average-power calculation. Protection and Restart Timed overload shutdown Output power >105% of rated for more than 5 seconds causes output shutdown; re-power to recover. Model-specific higher overload threshold For this 36 V model, output power >350% of rated causes shutdown; re-power to recover. This protection threshold is not an allowable peak rating. Over-voltage trip / recovery 39 to 46 V; output shuts down, re-power to recover. Over-temperature protection Output shuts down and recovers automatically after temperature falls. Restart after protection The catalog instructs restarting about 30 seconds after input power is disconnected. Short-circuit protection is listed. Do not treat overload shutdown as a documented continuous constant-current operating mode or automatic overload restart. Thermal, Input and Environmental Limits Cooling / fan control Built-in fan. The table specifies ON/OFF control by NTC (RT50) or 30% minimum load; no precise temperature setpoint is given. Operating temperature / humidity -40°C to +70°C is the series table range; apply this model's temperature curve. Working humidity: 20% to 90% RH, non-condensing. Model-specific thermal curve Horizontal mounting: 100% load through 60°C, then derate to 60% load at 70°C. Do not extend operation beyond this model's plotted endpoint. Low-input curve At 60 Hz: 80% load at 90 VAC, increasing to 100% at 200 VAC; 100% is plotted from 200 to 264 VAC. Combine with thermal and peak/duty limits. Storage / temperature coefficient -40°C to +85°C, 10% to 95% RH non-condensing; temperature coefficient ±0.03%/°C over 0°C to 50°C. Vibration 10 to 500 Hz, 5 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Altitude derating Above 2000 m, reduce allowed ambient temperature by 5°C per 1000 m for this fan-cooled model. These pages do not specify a maximum operating altitude. Follow the fan airflow direction and complete mechanical drawing. Do not apply fanless-model altitude derating or a 5000 m limit from another power class. Power Terminals and CN100 Signal Pins AC input terminals 1: AC/L; 2: AC/N; 3: FG / protective earth. DC output terminals 1 to 3: +V; 4 to 6: -V. CN100 pins 1 / 2 1: AUXG, auxiliary-output ground. 2: AUX, auxiliary output referenced to pin 1. CN100 pins 3 / 4 3: RC+, remote-control input. 4: RC-, remote-control ground. CN100 pins 5 / 6 / 8 5: CS, current-sharing signal. 6 and 8: GND, connected to main -V and used as DC-OK return. CN100 pins 7 / 9 / 10 7: DC-OK. 9: +S, positive remote sense. 10: -S, negative remote sense. CN100 connector / housing HRS DF11-10DP-2DS / HRS DF11-10DS, or equivalents. Mating contact family, as printed HRS DF11-**SC, or equivalent. DF11-**SC contains a wildcard; it is not a complete purchasable terminal variant. Select the exact contact for the wire and housing. The reviewed pages do not state an included harness, jumper, connector quantity or separate mounting kit. Remote Sense, Control, Standby and DC-OK Remote sensing Connect +S (pin 9) to load positive and -S (pin 10) to load negative. Twist the sense pair; maximum line-drop compensation is 0.5 V. Remote ON/OFF logic Short pins 3 and 4 for main output ON; open them for OFF. A required closed contact is not evidence that a jumper is included. 5 V standby output 5 V at up to 0.3 A; tolerance ±5%; ripple 50 mVp-p maximum; range 4.75 to 5.25 V, referenced to AUXG (pin 1). The output is not controlled by remote ON/OFF. DC-OK signal TTL signal on pin 7: 3.3 to 5.6 V when ON; 0 to 1 V when OFF. Referenced to GND pin 8; the function table also identifies pin 6 as GND. Active Current Sharing Parallel configuration Up to four units. The series feature list describes up to 4000 W / (3+1), but the usable continuous output must satisfy the rated-current equation and all derating. Maximum parallel output current Rated current per unit x number of units x 0.9. For this model, use 28 A as the rated current per unit. Voltage matching / minimum-load boundary Output-voltage difference between units must be <0.2 V. Below 5% of the combined rated current, sharing may not be fully balanced. Interconnections Use short, large-diameter power wiring to the common load. Join CS pin 5 and GND as shown in the parallel diagram. Keep remote-control and sense connections consistent with that diagram. The documented parallel-current formula is not permission to multiply an individual peak-power curve by the unit count. Verify the complete load, thermal and wiring requirements of the planned parallel system. Dimensions and Installation Body dimensions / case 218 x 105 x 61.5 mm (L x W x H), case 977H; mechanical drawing tolerance ±1 mm. Threaded mounting holes Base: 4-M4, L=6. Sides: 8-M4, L=4, both sides as printed. These annotations are not included screw quantities. Mounting references Base fixing spans 152.4 x 63.5 mm; side fixing spans 152.4 x 38.3 mm. Use the complete drawing for offsets and individual locations. Terminal projections Input side 12 mm maximum; output side 18 mm maximum. Terminal drawing dimensions Input labels 10 mm and 8.2 mm; output labels 11 mm and 9.2 mm. These are drawing labels; not all are terminal pitch. Indicators / local adjustment The mechanical drawing identifies the LED, CN100 and SVR1 voltage adjustment. Keep adjustment within the specified range. Follow the illustrated fan airflow direction and mounting depths. These pages do not state terminal torque, wire gauge or installation-clearance values; do not import such values from another model. Safety, EMC and Reliability Listed safety standards UL62368-1; CAN/CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; AS/NZS 62368.1; EAC TP TC 004. Dielectric withstand / insulation Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance: 100 MΩ for all three pairs at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55032 (CISPR32) Class B conducted and radiated; BS EN/EN61000-3-2 Class A harmonics; BS EN/EN61000-3-3 flicker. Immunity standards / levels BS EN/EN55035 and BS EN/EN61000-6-2. ESD -4-2: Level 3, 8 kV air / Level 2, 4 kV contact; radiated -4-3: Level 3; EFT -4-4: Level 3; conducted -4-6: Level 3; magnetic field -4-8: Level 4. Surge immunity BS EN/EN61000-4-5: Level 4, 2 kV line-line and 4 kV line-earth. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruptions for 250 periods. MTBF, minimum 989.2K hours, Telcordia SR-332 (Bellcore); 130.6K hours, MIL-HDBK-217F at 25°C. EMC tests used a 360 x 700 mm metal plate, 1 mm thick. This is a component for final equipment, which must be rechecked against the applicable EMC requirements. MTBF is statistical and is not a service-life guarantee. Weight and Manufacturer Notes Per-unit catalog packing reference 1.46 kg (1460 g), from the PACKING entry; not a separately measured net or shipment weight. Full packing entry 1.46 kg; 8 pcs / 12.8 kg / 1.58 CUFT. Catalog revision / warranty statement 2026-04-03; the manufacturer datasheet lists 5 years warranty. This adds no separate seller warranty. Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. The complete model-specific curves and protection-restart instructions remain applicable.

Read more less

MEAN WELL HRPG-1000N3-24 is an enclosed AC/DC power supply rated at 1008 W, 24 V and 42 A. It combines active PFC, fan cooling, remote sensing and current sharing; high-peak operation is limited by the input/model curve, pulse duration, duty cycle and average power. Product Datasheet Download MEAN WELL HRPG-1000N3 Datasheet (PDF) The HRPG-1000N3 section is on PDF pages 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Configuration Complete model HRPG-1000N3-24 HRPG / 1000 / N3 HRPG identifies the series; 1000 is the nominal power class; N3 denotes the three-times-peak-power design. Use this model's 1008 W continuous rating and its specific peak/duty curve. Output-voltage code 24 denotes a nominal 24 V single output. Built-in functions Active PFC, fan cooling, remote sensing, remote ON/OFF, DC-OK, active current sharing and an independent 5 V standby output. Output Specifications Nominal voltage / rated current 24 V / 42 A Current range / rated output power 0 to 42 A / 1008 W Output adjustment 22 to 28 V Ripple and noise, maximum 200 mVp-p Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Efficiency, typical 93% Setup / rise time 1000 ms / 50 ms at 230 VAC; 2000 ms / 50 ms at 115 VAC, full load Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load Voltage tolerance includes setup, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth and a 12-inch twisted pair terminated by parallel 0.1 uF and 47 uF capacitors. Setup time is measured at first cold start; repeated input ON/OFF may increase it. Input and Power Conversion Input range / frequency 90 to 264 VAC or 127 to 370 VDC; 47 to 63 Hz for AC input Short-duration withstand 300 VAC for 5 seconds; this does not extend the continuous input range Power factor, typical >0.95 at 230 VAC; >0.99 at 115 VAC, full load AC input current, typical 8.5 A at 115 VAC; 5 A at 230 VAC Inrush current, typical 25 A at 115 VAC; 40 A at 230 VAC Leakage current <1.2 mA at 240 VAC Switching / input functions PFC 65 kHz; PWM 90 kHz; active inrush-current limiting. No-load power <0.85 W with CN100 pins 3 (RC+) and 4 (RC-) open, switching the main output OFF. Peak Power and Repetition Limits Average-power requirement Pav = [Ppk x t + Pnpk x (T - t)] / T <= Prated. This model's Prated is 1008 W. Pulse / duty limit Peak pulses must not exceed 5 seconds. Duty = t / T x 100% <= 35%, with a lower duty limit where required by the input/model curve. 100 VAC curve anchors 1300 W at 35% duty; 1600 W at 10%; 2000 W at 5%. These are upper curve points, not continuous output ratings. 200 VAC, 24 V curve 2200 W at 35% duty; 2500 W at 25%; 2800 W at 15%; 3200 W at 5%. Use the 24 V / 36 V / 48 V curve, not the lower 12 V branch. Ppk is peak power; Pnpk non-peak power; t peak duration; T repetition period; Pav average power. Apply the peak/duty curve, average-power limit, input-voltage and temperature derating together. A 35% global duty ceiling does not authorize maximum peak power at 35% duty. The datasheet advertises up to 320% peak capability for the series. This is a short-duration, input- and model-dependent feature, not an unconditional multiplier of every model's rated wattage. Use the complete plotted curves for intermediate points. The catalog's 24 V example uses 200 VAC input, 2500 W peak, maximum 25% duty and Pav = Prated = 1008 W. For a 5-second pulse, the period is at least 20 seconds; the catalog prints a non-peak limit of 511 W. This example does not replace the complete peak curve. Protection and Restart Timed overload shutdown Output power >105% of rated for more than 5 seconds causes output shutdown; re-power to recover. Model-specific higher overload threshold For this 24 V model, output power >350% of rated causes shutdown; re-power to recover. This protection threshold is not an allowable peak rating. Over-voltage trip / recovery 29 to 33 V; output shuts down, re-power to recover. Over-temperature protection Output shuts down and recovers automatically after temperature falls. Restart after protection The catalog instructs restarting about 30 seconds after input power is disconnected. Short-circuit protection is listed. Do not treat overload shutdown as a documented continuous constant-current operating mode or automatic overload restart. Thermal, Input and Environmental Limits Cooling / fan control Built-in fan. The table specifies ON/OFF control by NTC (RT50) or 30% minimum load; no precise temperature setpoint is given. Operating temperature / humidity -40°C to +70°C is the series table range; apply this model's temperature curve. Working humidity: 20% to 90% RH, non-condensing. Model-specific thermal curve Horizontal mounting: 100% load through 60°C, then derate to 60% load at 70°C. Do not extend operation beyond this model's plotted endpoint. Low-input curve At 60 Hz: 80% load at 90 VAC, increasing to 100% at 200 VAC; 100% is plotted from 200 to 264 VAC. Combine with thermal and peak/duty limits. Storage / temperature coefficient -40°C to +85°C, 10% to 95% RH non-condensing; temperature coefficient ±0.03%/°C over 0°C to 50°C. Vibration 10 to 500 Hz, 5 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Altitude derating Above 2000 m, reduce allowed ambient temperature by 5°C per 1000 m for this fan-cooled model. These pages do not specify a maximum operating altitude. Follow the fan airflow direction and complete mechanical drawing. Do not apply fanless-model altitude derating or a 5000 m limit from another power class. Power Terminals and CN100 Signal Pins AC input terminals 1: AC/L; 2: AC/N; 3: FG / protective earth. DC output terminals 1 to 3: +V; 4 to 6: -V. CN100 pins 1 / 2 1: AUXG, auxiliary-output ground. 2: AUX, auxiliary output referenced to pin 1. CN100 pins 3 / 4 3: RC+, remote-control input. 4: RC-, remote-control ground. CN100 pins 5 / 6 / 8 5: CS, current-sharing signal. 6 and 8: GND, connected to main -V and used as DC-OK return. CN100 pins 7 / 9 / 10 7: DC-OK. 9: +S, positive remote sense. 10: -S, negative remote sense. CN100 connector / housing HRS DF11-10DP-2DS / HRS DF11-10DS, or equivalents. Mating contact family, as printed HRS DF11-**SC, or equivalent. DF11-**SC contains a wildcard; it is not a complete purchasable terminal variant. Select the exact contact for the wire and housing. The reviewed pages do not state an included harness, jumper, connector quantity or separate mounting kit. Remote Sense, Control, Standby and DC-OK Remote sensing Connect +S (pin 9) to load positive and -S (pin 10) to load negative. Twist the sense pair; maximum line-drop compensation is 0.5 V. Remote ON/OFF logic Short pins 3 and 4 for main output ON; open them for OFF. A required closed contact is not evidence that a jumper is included. 5 V standby output 5 V at up to 0.3 A; tolerance ±5%; ripple 50 mVp-p maximum; range 4.75 to 5.25 V, referenced to AUXG (pin 1). The output is not controlled by remote ON/OFF. DC-OK signal TTL signal on pin 7: 3.3 to 5.6 V when ON; 0 to 1 V when OFF. Referenced to GND pin 8; the function table also identifies pin 6 as GND. Active Current Sharing Parallel configuration Up to four units. The series feature list describes up to 4000 W / (3+1), but the usable continuous output must satisfy the rated-current equation and all derating. Maximum parallel output current Rated current per unit x number of units x 0.9. For this model, use 42 A as the rated current per unit. Voltage matching / minimum-load boundary Output-voltage difference between units must be <0.2 V. Below 5% of the combined rated current, sharing may not be fully balanced. Interconnections Use short, large-diameter power wiring to the common load. Join CS pin 5 and GND as shown in the parallel diagram. Keep remote-control and sense connections consistent with that diagram. The documented parallel-current formula is not permission to multiply an individual peak-power curve by the unit count. Verify the complete load, thermal and wiring requirements of the planned parallel system. Dimensions and Installation Body dimensions / case 218 x 105 x 61.5 mm (L x W x H), case 977H; mechanical drawing tolerance ±1 mm. Threaded mounting holes Base: 4-M4, L=6. Sides: 8-M4, L=4, both sides as printed. These annotations are not included screw quantities. Mounting references Base fixing spans 152.4 x 63.5 mm; side fixing spans 152.4 x 38.3 mm. Use the complete drawing for offsets and individual locations. Terminal projections Input side 12 mm maximum; output side 18 mm maximum. Terminal drawing dimensions Input labels 10 mm and 8.2 mm; output labels 11 mm and 9.2 mm. These are drawing labels; not all are terminal pitch. Indicators / local adjustment The mechanical drawing identifies the LED, CN100 and SVR1 voltage adjustment. Keep adjustment within the specified range. Follow the illustrated fan airflow direction and mounting depths. These pages do not state terminal torque, wire gauge or installation-clearance values; do not import such values from another model. Safety, EMC and Reliability Listed safety standards UL62368-1; CAN/CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; AS/NZS 62368.1; EAC TP TC 004. Dielectric withstand / insulation Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance: 100 MΩ for all three pairs at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55032 (CISPR32) Class B conducted and radiated; BS EN/EN61000-3-2 Class A harmonics; BS EN/EN61000-3-3 flicker. Immunity standards / levels BS EN/EN55035 and BS EN/EN61000-6-2. ESD -4-2: Level 3, 8 kV air / Level 2, 4 kV contact; radiated -4-3: Level 3; EFT -4-4: Level 3; conducted -4-6: Level 3; magnetic field -4-8: Level 4. Surge immunity BS EN/EN61000-4-5: Level 4, 2 kV line-line and 4 kV line-earth. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruptions for 250 periods. MTBF, minimum 989.2K hours, Telcordia SR-332 (Bellcore); 130.6K hours, MIL-HDBK-217F at 25°C. EMC tests used a 360 x 700 mm metal plate, 1 mm thick. This is a component for final equipment, which must be rechecked against the applicable EMC requirements. MTBF is statistical and is not a service-life guarantee. Weight and Manufacturer Notes Per-unit catalog packing reference 1.46 kg (1460 g), from the PACKING entry; not a separately measured net or shipment weight. Full packing entry 1.46 kg; 8 pcs / 12.8 kg / 1.58 CUFT. Catalog revision / warranty statement 2026-04-03; the manufacturer datasheet lists 5 years warranty. This adds no separate seller warranty. Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. The complete model-specific curves and protection-restart instructions remain applicable.

Read more less

MEAN WELL HRPG-1000N3-12 is an enclosed AC/DC power supply rated at 960 W, 12 V and 80 A. It combines active PFC, fan cooling, remote sensing and current sharing; high-peak operation is limited by the input/model curve, pulse duration, duty cycle and average power. Product Datasheet Download MEAN WELL HRPG-1000N3 Datasheet (PDF) The HRPG-1000N3 section is on PDF pages 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Configuration Complete model HRPG-1000N3-12 HRPG / 1000 / N3 HRPG identifies the series; 1000 is the nominal power class; N3 denotes the three-times-peak-power design. Use this model's 960 W continuous rating and its specific peak/duty curve. Output-voltage code 12 denotes a nominal 12 V single output. Built-in functions Active PFC, fan cooling, remote sensing, remote ON/OFF, DC-OK, active current sharing and an independent 5 V standby output. Output Specifications Nominal voltage / rated current 12 V / 80 A Current range / rated output power 0 to 80 A / 960 W Output adjustment 11 to 14 V Ripple and noise, maximum 150 mVp-p Voltage tolerance / line / load regulation ±2.0% / ±0.5% / ±2.0% Efficiency, typical 91.5% Setup / rise time 1000 ms / 50 ms at 230 VAC; 2000 ms / 50 ms at 115 VAC, full load Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load Voltage tolerance includes setup, line and load regulation. Ripple/noise is measured with 20 MHz bandwidth and a 12-inch twisted pair terminated by parallel 0.1 uF and 47 uF capacitors. Setup time is measured at first cold start; repeated input ON/OFF may increase it. Input and Power Conversion Input range / frequency 90 to 264 VAC or 127 to 370 VDC; 47 to 63 Hz for AC input Short-duration withstand 300 VAC for 5 seconds; this does not extend the continuous input range Power factor, typical >0.95 at 230 VAC; >0.99 at 115 VAC, full load AC input current, typical 8.5 A at 115 VAC; 5 A at 230 VAC Inrush current, typical 25 A at 115 VAC; 40 A at 230 VAC Leakage current <1.2 mA at 240 VAC Switching / input functions PFC 65 kHz; PWM 90 kHz; active inrush-current limiting. No-load power <0.85 W with CN100 pins 3 (RC+) and 4 (RC-) open, switching the main output OFF. Peak Power and Repetition Limits Average-power requirement Pav = [Ppk x t + Pnpk x (T - t)] / T <= Prated. This model's Prated is 960 W. Pulse / duty limit Peak pulses must not exceed 5 seconds. Duty = t / T x 100% <= 35%, with a lower duty limit where required by the input/model curve. 100 VAC curve anchors 1300 W at 35% duty; 1600 W at 10%; 2000 W at 5%. These are upper curve points, not continuous output ratings. 200 VAC, 12 V curve 2000 W at 35% duty; 2500 W at 15%; 2880 W at 5%. The 12 V branch does not use the 3200 W endpoint shown for the other voltage models. Ppk is peak power; Pnpk non-peak power; t peak duration; T repetition period; Pav average power. Apply the peak/duty curve, average-power limit, input-voltage and temperature derating together. A 35% global duty ceiling does not authorize maximum peak power at 35% duty. The datasheet advertises up to 320% peak capability for the series. This is a short-duration, input- and model-dependent feature, not an unconditional multiplier of every model's rated wattage. Use the complete plotted curves for intermediate points. The 2500 W / 25% duty / 20-second-period / 511 W non-peak worked example is explicitly for the 24 V model. Do not assign its non-peak limit to this 12 V model without applying the complete curve and average-power calculation. Protection and Restart Timed overload shutdown Output power >105% of rated for more than 5 seconds causes output shutdown; re-power to recover. Model-specific higher overload threshold For this 12 V model, output power >320% of rated causes shutdown; re-power to recover. This protection threshold is not an allowable peak rating. Over-voltage trip / recovery 14.5 to 16.5 V; output shuts down, re-power to recover. Over-temperature protection Output shuts down and recovers automatically after temperature falls. Restart after protection The catalog instructs restarting about 30 seconds after input power is disconnected. Short-circuit protection is listed. Do not treat overload shutdown as a documented continuous constant-current operating mode or automatic overload restart. Thermal, Input and Environmental Limits Cooling / fan control Built-in fan. The table specifies ON/OFF control by NTC (RT50) or 30% minimum load; no precise temperature setpoint is given. Operating temperature / humidity -40°C to +70°C is the series table range; apply this model's temperature curve. Working humidity: 20% to 90% RH, non-condensing. Model-specific thermal curve Horizontal mounting: 100% load through 50°C, then derate to 60% load at 60°C. Do not extend operation beyond this model's plotted endpoint. Low-input curve At 60 Hz: 80% load at 90 VAC, increasing to 100% at 200 VAC; 100% is plotted from 200 to 264 VAC. Combine with thermal and peak/duty limits. Storage / temperature coefficient -40°C to +85°C, 10% to 95% RH non-condensing; temperature coefficient ±0.03%/°C over 0°C to 50°C. Vibration 10 to 500 Hz, 5 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Altitude derating Above 2000 m, reduce allowed ambient temperature by 5°C per 1000 m for this fan-cooled model. These pages do not specify a maximum operating altitude. Follow the fan airflow direction and complete mechanical drawing. Do not apply fanless-model altitude derating or a 5000 m limit from another power class. Power Terminals and CN100 Signal Pins AC input terminals 1: AC/L; 2: AC/N; 3: FG / protective earth. DC output terminals 1 to 3: +V; 4 to 6: -V. CN100 pins 1 / 2 1: AUXG, auxiliary-output ground. 2: AUX, auxiliary output referenced to pin 1. CN100 pins 3 / 4 3: RC+, remote-control input. 4: RC-, remote-control ground. CN100 pins 5 / 6 / 8 5: CS, current-sharing signal. 6 and 8: GND, connected to main -V and used as DC-OK return. CN100 pins 7 / 9 / 10 7: DC-OK. 9: +S, positive remote sense. 10: -S, negative remote sense. CN100 connector / housing HRS DF11-10DP-2DS / HRS DF11-10DS, or equivalents. Mating contact family, as printed HRS DF11-**SC, or equivalent. DF11-**SC contains a wildcard; it is not a complete purchasable terminal variant. Select the exact contact for the wire and housing. The reviewed pages do not state an included harness, jumper, connector quantity or separate mounting kit. Remote Sense, Control, Standby and DC-OK Remote sensing Connect +S (pin 9) to load positive and -S (pin 10) to load negative. Twist the sense pair; maximum line-drop compensation is 0.5 V. Remote ON/OFF logic Short pins 3 and 4 for main output ON; open them for OFF. A required closed contact is not evidence that a jumper is included. 5 V standby output 5 V at up to 0.3 A; tolerance ±5%; ripple 50 mVp-p maximum; range 4.75 to 5.25 V, referenced to AUXG (pin 1). The output is not controlled by remote ON/OFF. DC-OK signal TTL signal on pin 7: 3.3 to 5.6 V when ON; 0 to 1 V when OFF. Referenced to GND pin 8; the function table also identifies pin 6 as GND. Active Current Sharing Parallel configuration Up to four units. The series feature list describes up to 4000 W / (3+1), but the usable continuous output must satisfy the rated-current equation and all derating. Maximum parallel output current Rated current per unit x number of units x 0.9. For this model, use 80 A as the rated current per unit. Voltage matching / minimum-load boundary Output-voltage difference between units must be <0.2 V. Below 5% of the combined rated current, sharing may not be fully balanced. Interconnections Use short, large-diameter power wiring to the common load. Join CS pin 5 and GND as shown in the parallel diagram. Keep remote-control and sense connections consistent with that diagram. The documented parallel-current formula is not permission to multiply an individual peak-power curve by the unit count. Verify the complete load, thermal and wiring requirements of the planned parallel system. Dimensions and Installation Body dimensions / case 218 x 105 x 61.5 mm (L x W x H), case 977H; mechanical drawing tolerance ±1 mm. Threaded mounting holes Base: 4-M4, L=6. Sides: 8-M4, L=4, both sides as printed. These annotations are not included screw quantities. Mounting references Base fixing spans 152.4 x 63.5 mm; side fixing spans 152.4 x 38.3 mm. Use the complete drawing for offsets and individual locations. Terminal projections Input side 12 mm maximum; output side 18 mm maximum. Terminal drawing dimensions Input labels 10 mm and 8.2 mm; output labels 11 mm and 9.2 mm. These are drawing labels; not all are terminal pitch. Indicators / local adjustment The mechanical drawing identifies the LED, CN100 and SVR1 voltage adjustment. Keep adjustment within the specified range. Follow the illustrated fan airflow direction and mounting depths. These pages do not state terminal torque, wire gauge or installation-clearance values; do not import such values from another model. Safety, EMC and Reliability Listed safety standards UL62368-1; CAN/CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; AS/NZS 62368.1; EAC TP TC 004. Dielectric withstand / insulation Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance: 100 MΩ for all three pairs at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55032 (CISPR32) Class B conducted and radiated; BS EN/EN61000-3-2 Class A harmonics; BS EN/EN61000-3-3 flicker. Immunity standards / levels BS EN/EN55035 and BS EN/EN61000-6-2. ESD -4-2: Level 3, 8 kV air / Level 2, 4 kV contact; radiated -4-3: Level 3; EFT -4-4: Level 3; conducted -4-6: Level 3; magnetic field -4-8: Level 4. Surge immunity BS EN/EN61000-4-5: Level 4, 2 kV line-line and 4 kV line-earth. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruptions for 250 periods. MTBF, minimum 989.2K hours, Telcordia SR-332 (Bellcore); 130.6K hours, MIL-HDBK-217F at 25°C. EMC tests used a 360 x 700 mm metal plate, 1 mm thick. This is a component for final equipment, which must be rechecked against the applicable EMC requirements. MTBF is statistical and is not a service-life guarantee. Weight and Manufacturer Notes Per-unit catalog packing reference 1.46 kg (1460 g), from the PACKING entry; not a separately measured net or shipment weight. Full packing entry 1.46 kg; 8 pcs / 12.8 kg / 1.58 CUFT. Catalog revision / warranty statement 2026-04-03; the manufacturer datasheet lists 5 years warranty. This adds no separate seller warranty. Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. The complete model-specific curves and protection-restart instructions remain applicable.

Read more less

MEAN WELL HRP-600N3-48 is a single-output enclosed AC/DC power supply rated 48 V, 13 A and 624 W continuously. Its high-peak capability supports short motor-start and electromechanical loads under the model-specific duty and average-power limits. Active PFC, fan control, remote sensing and DC-OK are built in. Product Datasheet Download MEAN WELL HRP-600N3 Datasheet (PDF) The HRP-600N3 section is on PDF pages 13, 14, 15, 16, 17, 18. Refer to the complete mechanical drawings and notes when planning installation. Model and Continuous Output Complete model HRP-600N3-48 Model meaning HRP identifies the series; 600 is the nominal power class; N3 identifies the 3.5-times peak-power family; 48 identifies the main-output voltage. Rated continuous output 48 VDC / 13 A / 624 W Normal current range 0 to 13 A; apply input and temperature derating. Voltage adjustment 40.8–55.2 V using SVR1 Ripple and noise 240 mVp-p maximum Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.2%; load regulation ±0.5%. Typical efficiency 89% Unqualified specifications are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple and noise use 20 MHz bandwidth, a 12-inch twisted pair and 0.1 µF plus 47 µF parallel capacitors at its end. Input and Timing Continuous input 85–264 VAC, 47–63 Hz, or 120–370 VDC. Low-line operation requires derating. Short-duration input withstand 300 VAC for 5 seconds; not a continuous input rating. Typical power factor >0.94 at 230 VAC; >0.98 at 115 VAC, at full load. Typical AC current 7.6 A at 115 VAC; 3.6 A at 230 VAC. Typical inrush / leakage 35 A at 115 VAC; 70 A at 230 VAC. Leakage current <2 mA at 240 VAC. Setup / rise time Setup 1800 ms at 230 VAC or 3600 ms at 115 VAC; rise 50 ms, at full load. Typical hold-up time 16 ms at either 230 VAC or 115 VAC, at full load. The block diagram includes active PFC and active inrush-current limiting; PWM switching frequency is 80 kHz. Peak Power: Duration, Duty and Average Load This is an intermittent high-peak design, not a continuous 2100 W supply. The family claim is up to 350% of the nominal 600 W class; this model retains its 624 W continuous rating. The peak-power chart extends to 2100 W at 200 VAC only at 5% duty, subject to all operating limits. Keep each peak pulse at 5 seconds or less. Duty = t / T × 100% and must not exceed 35%; the model- and input-specific curve can impose a much lower limit. Here t is peak width and T is the complete repeating period. Average power = [Ppk × t + Pnpk × (T − t)] / T must remain at or below 624 W, with any further derating applied. Ppk is peak power and Pnpk is non-peak power. Both the duty curve and this average-power condition must be satisfied. At 200 VAC, use the 24 V / 36 V / 48 V curve: its marked anchors include 1300 W at 35%, 1700 W at 15% and 2100 W at 5% duty. At 100 VAC, the lower dotted curve applies: readable anchors include 800 W at 35% and 1200 W at 5% duty. Use the full curve for intermediate combinations; do not apply the 200 VAC envelope at 100 VAC or extrapolate these curves to other inputs. The −40 to −10°C shaded region is normal-load only. Do not apply peak operation in that region. Protection and Recovery Overload duration If output power exceeds 105% of rated power for more than 5 seconds, the output shuts down; re-power to recover. High-overload current limiting The specification additionally states constant-current limiting for output power above 380% of rated power for more than 5 seconds, followed by shutdown; re-power to recover. Overvoltage 57.6–67.2 V; shutdown, re-power to recover. Overtemperature Shutdown; automatic recovery after temperature decreases. Short-circuit, overload, overvoltage and overtemperature protection are listed. Protection thresholds are not permissible continuous or peak operating ratings; remain within the peak curve, pulse-duration and average-power limits. Cooling, Derating and Environment Fan control, typical Fan turns on at the printed load threshold of 35 ±15%, or when internal sensor RTH2 reaches at least 50°C. RTH2 is not ambient temperature. Horizontal thermal curve 100% normal load from −40 to +50°C, falling to 50% at +70°C. The shaded −40 to −10°C range permits normal load only. Input-voltage curve At 60 Hz: 80% load at 85 VAC, rising to 100% at 100 VAC; full load from 100 to 264 VAC. Operating / storage Working: −40 to +70°C with derating, 20–90% RH. Storage: −40 to +85°C, 10–95% RH. Non-condensing. Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 10–500 Hz, 5 G, 10 minutes/cycle, 60 minutes each on X, Y and Z axes. Altitude Up to 5000 m; above 2000 m reduce allowable ambient temperature by 5°C per additional 1000 m for this fan-cooled model. Cooling air runs from the input/fan end toward the output end in the mechanical drawing. Keep this airflow path unobstructed. Apply thermal, input, altitude and peak-duty limitations together. Remote Sense and DC-OK CN100 pin 1 DC-OK: TTL-level output-status signal. CN100 pin 2 GND: reference for DC-OK. CN100 pin 3 +S: positive remote sense. CN100 pin 4 −S: negative remote sense. Sense compensation Up to 0.5 V of voltage drop in the load wiring. DC-OK levels Between pin 1 and pin 2: 3.3–5.6 V when the PSU is ON; 0–1 V when OFF. Connect +S and −S to the corresponding load terminals and twist the sense pair together. Main load current uses the power terminals, not the sense pins. The catalog does not specify a DC-OK current-drive or isolation rating here. Remote ON/OFF, an auxiliary standby output and active current sharing are not specified for HRP-600N3. Power Terminals and Mating Parts AC input terminals 1 = AC/L; 2 = AC/N; 3 = FG / protective earth. DC output terminals 1–2 = −V; 3–4 = +V. CN100 onboard connector HRS DF11-4DP-2DS or equivalent Mating housing HRS DF11-4DS or equivalent Contact reference HRS DF11-**SC or equivalent; the printed ** suffix is incomplete. Use the numbered drawing for connector orientation. The mating references do not establish that housings, contacts, cables or mounting screws are supplied. Confirm the complete wire-compatible contact suffix before ordering; no dedicated accessory-kit number or supplied quantity is stated. Dimensions and Installation Body dimensions 218 × 105 × 61.5 mm (L × W × H); case 977G; general drawing tolerance ±1 mm. Base mounting 4-M4, L=6 mm; centre spacing 152.4 × 63.5 mm. The base drawing marks 32.8 mm and 20.75 mm edge offsets. Side mounting 8-M4, L=4 mm, both sides; longitudinal spacing 152.4 mm, vertical spacing 38.3 mm and lower-row height 12.5 mm. Terminal projections Input side 12 mm maximum; output side 18 mm maximum beyond the 218 mm body. Terminal drawing marks AC side marks 8.2 mm and 10 mm; DC side marks 11 mm and 9.2 mm. Refer to the drawing for exact locations. Mounting L limits screw penetration into the enclosure, not total screw length; allow for mounting-surface thickness. No mounting or power-terminal tightening torque is specified in this section. The output-end view identifies the LED and SVR1 voltage adjustment. No LED colour or further diagnostic behaviour is specified. Follow the complete drawing and installation manual for the installation envelope. Safety and EMC Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC004; AS/NZS62368.1. Withstand voltage Input–output 3 kVAC; input–FG 2 kVAC; output–FG 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input–output, input–FG and output–FG. Emission / harmonics BS EN/EN55032 Class B conducted and radiated; BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3 voltage flicker. Immunity framework BS EN/EN55035; BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. BS EN/EN61000-4-3: Level 3, 10 V/m. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. BS EN/EN61000-4-5: Level 4, 4 kV line–FG and 2 kV line–line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V. BS EN/EN61000-4-8: Level 4, 30 A/m. Dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. This supply is a component for final equipment. EMC tests used a 360 × 360 × 1 mm metal plate. The completed equipment must be checked again for EMC compliance; component approvals do not automatically certify the installation. Reliability, Weight and Catalogue Reference Minimum MTBF 1380.2K hours, Telcordia TR/SR-332 (Bellcore); 191.8K hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The manufacturer datasheet lists 5 years, subject to applicable manufacturer terms. Catalogue packing reference per unit 1.39 kg / 1390 g Published carton data 8 pieces / 12.1 kg / 1.58 CUFT Document HRP-600N3-SPEC, 2026-04-03; combined HRP-N3 PDF pages 13–18. The per-unit packing reference is not a measured net or shipment weight; do not use the carton total as individual product weight. MTBF is a prediction rather than a guaranteed lifetime. Typical applications listed include industrial automation and control, electromechanical equipment, diagnostic or biological facilities, test and measurement systems, and telecommunications.

Read more less

MEAN WELL HRP-600N3-36 is a single-output enclosed AC/DC power supply rated 36 V, 17.5 A and 630 W continuously. Its high-peak capability supports short motor-start and electromechanical loads under the model-specific duty and average-power limits. Active PFC, fan control, remote sensing and DC-OK are built in. Product Datasheet Download MEAN WELL HRP-600N3 Datasheet (PDF) The HRP-600N3 section is on PDF pages 13, 14, 15, 16, 17, 18. Refer to the complete mechanical drawings and notes when planning installation. Model and Continuous Output Complete model HRP-600N3-36 Model meaning HRP identifies the series; 600 is the nominal power class; N3 identifies the 3.5-times peak-power family; 36 identifies the main-output voltage. Rated continuous output 36 VDC / 17.5 A / 630 W Normal current range 0 to 17.5 A; apply input and temperature derating. Voltage adjustment 28.8–39.6 V using SVR1 Ripple and noise 200 mVp-p maximum Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.2%; load regulation ±0.5%. Typical efficiency 89% Unqualified specifications are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple and noise use 20 MHz bandwidth, a 12-inch twisted pair and 0.1 µF plus 47 µF parallel capacitors at its end. Input and Timing Continuous input 85–264 VAC, 47–63 Hz, or 120–370 VDC. Low-line operation requires derating. Short-duration input withstand 300 VAC for 5 seconds; not a continuous input rating. Typical power factor >0.94 at 230 VAC; >0.98 at 115 VAC, at full load. Typical AC current 7.6 A at 115 VAC; 3.6 A at 230 VAC. Typical inrush / leakage 35 A at 115 VAC; 70 A at 230 VAC. Leakage current <2 mA at 240 VAC. Setup / rise time Setup 1800 ms at 230 VAC or 3600 ms at 115 VAC; rise 50 ms, at full load. Typical hold-up time 16 ms at either 230 VAC or 115 VAC, at full load. The block diagram includes active PFC and active inrush-current limiting; PWM switching frequency is 80 kHz. Peak Power: Duration, Duty and Average Load This is an intermittent high-peak design, not a continuous 2100 W supply. The family claim is up to 350% of the nominal 600 W class; this model retains its 630 W continuous rating. The peak-power chart extends to 2100 W at 200 VAC only at 5% duty, subject to all operating limits. Keep each peak pulse at 5 seconds or less. Duty = t / T × 100% and must not exceed 35%; the model- and input-specific curve can impose a much lower limit. Here t is peak width and T is the complete repeating period. Average power = [Ppk × t + Pnpk × (T − t)] / T must remain at or below 630 W, with any further derating applied. Ppk is peak power and Pnpk is non-peak power. Both the duty curve and this average-power condition must be satisfied. At 200 VAC, use the 24 V / 36 V / 48 V curve: its marked anchors include 1300 W at 35%, 1700 W at 15% and 2100 W at 5% duty. At 100 VAC, the lower dotted curve applies: readable anchors include 800 W at 35% and 1200 W at 5% duty. Use the full curve for intermediate combinations; do not apply the 200 VAC envelope at 100 VAC or extrapolate these curves to other inputs. The −40 to −10°C shaded region is normal-load only. Do not apply peak operation in that region. Protection and Recovery Overload duration If output power exceeds 105% of rated power for more than 5 seconds, the output shuts down; re-power to recover. High-overload current limiting The specification additionally states constant-current limiting for output power above 380% of rated power for more than 5 seconds, followed by shutdown; re-power to recover. Overvoltage 41.4–48.6 V; shutdown, re-power to recover. Overtemperature Shutdown; automatic recovery after temperature decreases. Short-circuit, overload, overvoltage and overtemperature protection are listed. Protection thresholds are not permissible continuous or peak operating ratings; remain within the peak curve, pulse-duration and average-power limits. Cooling, Derating and Environment Fan control, typical Fan turns on at the printed load threshold of 35 ±15%, or when internal sensor RTH2 reaches at least 50°C. RTH2 is not ambient temperature. Horizontal thermal curve 100% normal load from −40 to +50°C, falling to 50% at +70°C. The shaded −40 to −10°C range permits normal load only. Input-voltage curve At 60 Hz: 80% load at 85 VAC, rising to 100% at 100 VAC; full load from 100 to 264 VAC. Operating / storage Working: −40 to +70°C with derating, 20–90% RH. Storage: −40 to +85°C, 10–95% RH. Non-condensing. Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 10–500 Hz, 5 G, 10 minutes/cycle, 60 minutes each on X, Y and Z axes. Altitude Up to 5000 m; above 2000 m reduce allowable ambient temperature by 5°C per additional 1000 m for this fan-cooled model. Cooling air runs from the input/fan end toward the output end in the mechanical drawing. Keep this airflow path unobstructed. Apply thermal, input, altitude and peak-duty limitations together. Remote Sense and DC-OK CN100 pin 1 DC-OK: TTL-level output-status signal. CN100 pin 2 GND: reference for DC-OK. CN100 pin 3 +S: positive remote sense. CN100 pin 4 −S: negative remote sense. Sense compensation Up to 0.5 V of voltage drop in the load wiring. DC-OK levels Between pin 1 and pin 2: 3.3–5.6 V when the PSU is ON; 0–1 V when OFF. Connect +S and −S to the corresponding load terminals and twist the sense pair together. Main load current uses the power terminals, not the sense pins. The catalog does not specify a DC-OK current-drive or isolation rating here. Remote ON/OFF, an auxiliary standby output and active current sharing are not specified for HRP-600N3. Power Terminals and Mating Parts AC input terminals 1 = AC/L; 2 = AC/N; 3 = FG / protective earth. DC output terminals 1–2 = −V; 3–4 = +V. CN100 onboard connector HRS DF11-4DP-2DS or equivalent Mating housing HRS DF11-4DS or equivalent Contact reference HRS DF11-**SC or equivalent; the printed ** suffix is incomplete. Use the numbered drawing for connector orientation. The mating references do not establish that housings, contacts, cables or mounting screws are supplied. Confirm the complete wire-compatible contact suffix before ordering; no dedicated accessory-kit number or supplied quantity is stated. Dimensions and Installation Body dimensions 218 × 105 × 61.5 mm (L × W × H); case 977G; general drawing tolerance ±1 mm. Base mounting 4-M4, L=6 mm; centre spacing 152.4 × 63.5 mm. The base drawing marks 32.8 mm and 20.75 mm edge offsets. Side mounting 8-M4, L=4 mm, both sides; longitudinal spacing 152.4 mm, vertical spacing 38.3 mm and lower-row height 12.5 mm. Terminal projections Input side 12 mm maximum; output side 18 mm maximum beyond the 218 mm body. Terminal drawing marks AC side marks 8.2 mm and 10 mm; DC side marks 11 mm and 9.2 mm. Refer to the drawing for exact locations. Mounting L limits screw penetration into the enclosure, not total screw length; allow for mounting-surface thickness. No mounting or power-terminal tightening torque is specified in this section. The output-end view identifies the LED and SVR1 voltage adjustment. No LED colour or further diagnostic behaviour is specified. Follow the complete drawing and installation manual for the installation envelope. Safety and EMC Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC004; AS/NZS62368.1. Withstand voltage Input–output 3 kVAC; input–FG 2 kVAC; output–FG 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input–output, input–FG and output–FG. Emission / harmonics BS EN/EN55032 Class B conducted and radiated; BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3 voltage flicker. Immunity framework BS EN/EN55035; BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. BS EN/EN61000-4-3: Level 3, 10 V/m. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. BS EN/EN61000-4-5: Level 4, 4 kV line–FG and 2 kV line–line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V. BS EN/EN61000-4-8: Level 4, 30 A/m. Dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. This supply is a component for final equipment. EMC tests used a 360 × 360 × 1 mm metal plate. The completed equipment must be checked again for EMC compliance; component approvals do not automatically certify the installation. Reliability, Weight and Catalogue Reference Minimum MTBF 1380.2K hours, Telcordia TR/SR-332 (Bellcore); 191.8K hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The manufacturer datasheet lists 5 years, subject to applicable manufacturer terms. Catalogue packing reference per unit 1.39 kg / 1390 g Published carton data 8 pieces / 12.1 kg / 1.58 CUFT Document HRP-600N3-SPEC, 2026-04-03; combined HRP-N3 PDF pages 13–18. The per-unit packing reference is not a measured net or shipment weight; do not use the carton total as individual product weight. MTBF is a prediction rather than a guaranteed lifetime. Typical applications listed include industrial automation and control, electromechanical equipment, diagnostic or biological facilities, test and measurement systems, and telecommunications.

Read more less

MEAN WELL HRP-600N3-24 is a single-output enclosed AC/DC power supply rated 24 V, 27 A and 648 W continuously. Its high-peak capability supports short motor-start and electromechanical loads under the model-specific duty and average-power limits. Active PFC, fan control, remote sensing and DC-OK are built in. Product Datasheet Download MEAN WELL HRP-600N3 Datasheet (PDF) The HRP-600N3 section is on PDF pages 13, 14, 15, 16, 17, 18. Refer to the complete mechanical drawings and notes when planning installation. Model and Continuous Output Complete model HRP-600N3-24 Model meaning HRP identifies the series; 600 is the nominal power class; N3 identifies the 3.5-times peak-power family; 24 identifies the main-output voltage. Rated continuous output 24 VDC / 27 A / 648 W Normal current range 0 to 27 A; apply input and temperature derating. Voltage adjustment 21.6–28.8 V using SVR1 Ripple and noise 150 mVp-p maximum Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.2%; load regulation ±0.5%. Typical efficiency 88% Unqualified specifications are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple and noise use 20 MHz bandwidth, a 12-inch twisted pair and 0.1 µF plus 47 µF parallel capacitors at its end. Input and Timing Continuous input 85–264 VAC, 47–63 Hz, or 120–370 VDC. Low-line operation requires derating. Short-duration input withstand 300 VAC for 5 seconds; not a continuous input rating. Typical power factor >0.94 at 230 VAC; >0.98 at 115 VAC, at full load. Typical AC current 7.6 A at 115 VAC; 3.6 A at 230 VAC. Typical inrush / leakage 35 A at 115 VAC; 70 A at 230 VAC. Leakage current <2 mA at 240 VAC. Setup / rise time Setup 1800 ms at 230 VAC or 3600 ms at 115 VAC; rise 50 ms, at full load. Typical hold-up time 16 ms at either 230 VAC or 115 VAC, at full load. The block diagram includes active PFC and active inrush-current limiting; PWM switching frequency is 80 kHz. Peak Power: Duration, Duty and Average Load This is an intermittent high-peak design, not a continuous 2100 W supply. The family claim is up to 350% of the nominal 600 W class; this model retains its 648 W continuous rating. The peak-power chart extends to 2100 W at 200 VAC only at 5% duty, subject to all operating limits. Keep each peak pulse at 5 seconds or less. Duty = t / T × 100% and must not exceed 35%; the model- and input-specific curve can impose a much lower limit. Here t is peak width and T is the complete repeating period. Average power = [Ppk × t + Pnpk × (T − t)] / T must remain at or below 648 W, with any further derating applied. Ppk is peak power and Pnpk is non-peak power. Both the duty curve and this average-power condition must be satisfied. At 200 VAC, use the 24 V / 36 V / 48 V curve: its marked anchors include 1300 W at 35%, 1700 W at 15% and 2100 W at 5% duty. At 100 VAC, the lower dotted curve applies: readable anchors include 800 W at 35% and 1200 W at 5% duty. Use the full curve for intermediate combinations; do not apply the 200 VAC envelope at 100 VAC or extrapolate these curves to other inputs. The −40 to −10°C shaded region is normal-load only. Do not apply peak operation in that region. The catalog example for this 24 V model uses 200 VAC input, 1500 W peak and 25% maximum duty with a 648 W average-power ceiling. For a 5-second pulse, use a period of at least 20 seconds. At the example 20-second period, non-peak output must not exceed 364 W. Other pulse widths and periods must be recalculated from the formula. Protection and Recovery Overload duration If output power exceeds 105% of rated power for more than 5 seconds, the output shuts down; re-power to recover. High-overload current limiting The specification additionally states constant-current limiting for output power above 380% of rated power for more than 5 seconds, followed by shutdown; re-power to recover. Overvoltage 30–34.8 V; shutdown, re-power to recover. Overtemperature Shutdown; automatic recovery after temperature decreases. Short-circuit, overload, overvoltage and overtemperature protection are listed. Protection thresholds are not permissible continuous or peak operating ratings; remain within the peak curve, pulse-duration and average-power limits. Cooling, Derating and Environment Fan control, typical Fan turns on at the printed load threshold of 35 ±15%, or when internal sensor RTH2 reaches at least 50°C. RTH2 is not ambient temperature. Horizontal thermal curve 100% normal load from −40 to +50°C, falling to 50% at +70°C. The shaded −40 to −10°C range permits normal load only. Input-voltage curve At 60 Hz: 80% load at 85 VAC, rising to 100% at 100 VAC; full load from 100 to 264 VAC. Operating / storage Working: −40 to +70°C with derating, 20–90% RH. Storage: −40 to +85°C, 10–95% RH. Non-condensing. Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 10–500 Hz, 5 G, 10 minutes/cycle, 60 minutes each on X, Y and Z axes. Altitude Up to 5000 m; above 2000 m reduce allowable ambient temperature by 5°C per additional 1000 m for this fan-cooled model. Cooling air runs from the input/fan end toward the output end in the mechanical drawing. Keep this airflow path unobstructed. Apply thermal, input, altitude and peak-duty limitations together. Remote Sense and DC-OK CN100 pin 1 DC-OK: TTL-level output-status signal. CN100 pin 2 GND: reference for DC-OK. CN100 pin 3 +S: positive remote sense. CN100 pin 4 −S: negative remote sense. Sense compensation Up to 0.5 V of voltage drop in the load wiring. DC-OK levels Between pin 1 and pin 2: 3.3–5.6 V when the PSU is ON; 0–1 V when OFF. Connect +S and −S to the corresponding load terminals and twist the sense pair together. Main load current uses the power terminals, not the sense pins. The catalog does not specify a DC-OK current-drive or isolation rating here. Remote ON/OFF, an auxiliary standby output and active current sharing are not specified for HRP-600N3. Power Terminals and Mating Parts AC input terminals 1 = AC/L; 2 = AC/N; 3 = FG / protective earth. DC output terminals 1–2 = −V; 3–4 = +V. CN100 onboard connector HRS DF11-4DP-2DS or equivalent Mating housing HRS DF11-4DS or equivalent Contact reference HRS DF11-**SC or equivalent; the printed ** suffix is incomplete. Use the numbered drawing for connector orientation. The mating references do not establish that housings, contacts, cables or mounting screws are supplied. Confirm the complete wire-compatible contact suffix before ordering; no dedicated accessory-kit number or supplied quantity is stated. Dimensions and Installation Body dimensions 218 × 105 × 61.5 mm (L × W × H); case 977G; general drawing tolerance ±1 mm. Base mounting 4-M4, L=6 mm; centre spacing 152.4 × 63.5 mm. The base drawing marks 32.8 mm and 20.75 mm edge offsets. Side mounting 8-M4, L=4 mm, both sides; longitudinal spacing 152.4 mm, vertical spacing 38.3 mm and lower-row height 12.5 mm. Terminal projections Input side 12 mm maximum; output side 18 mm maximum beyond the 218 mm body. Terminal drawing marks AC side marks 8.2 mm and 10 mm; DC side marks 11 mm and 9.2 mm. Refer to the drawing for exact locations. Mounting L limits screw penetration into the enclosure, not total screw length; allow for mounting-surface thickness. No mounting or power-terminal tightening torque is specified in this section. The output-end view identifies the LED and SVR1 voltage adjustment. No LED colour or further diagnostic behaviour is specified. Follow the complete drawing and installation manual for the installation envelope. Safety and EMC Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC004; AS/NZS62368.1. Withstand voltage Input–output 3 kVAC; input–FG 2 kVAC; output–FG 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input–output, input–FG and output–FG. Emission / harmonics BS EN/EN55032 Class B conducted and radiated; BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3 voltage flicker. Immunity framework BS EN/EN55035; BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. BS EN/EN61000-4-3: Level 3, 10 V/m. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. BS EN/EN61000-4-5: Level 4, 4 kV line–FG and 2 kV line–line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V. BS EN/EN61000-4-8: Level 4, 30 A/m. Dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. This supply is a component for final equipment. EMC tests used a 360 × 360 × 1 mm metal plate. The completed equipment must be checked again for EMC compliance; component approvals do not automatically certify the installation. Reliability, Weight and Catalogue Reference Minimum MTBF 1380.2K hours, Telcordia TR/SR-332 (Bellcore); 191.8K hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The manufacturer datasheet lists 5 years, subject to applicable manufacturer terms. Catalogue packing reference per unit 1.39 kg / 1390 g Published carton data 8 pieces / 12.1 kg / 1.58 CUFT Document HRP-600N3-SPEC, 2026-04-03; combined HRP-N3 PDF pages 13–18. The per-unit packing reference is not a measured net or shipment weight; do not use the carton total as individual product weight. MTBF is a prediction rather than a guaranteed lifetime. Typical applications listed include industrial automation and control, electromechanical equipment, diagnostic or biological facilities, test and measurement systems, and telecommunications.

Read more less

MEAN WELL HRP-600N3-12 is a single-output enclosed AC/DC power supply rated 12 V, 53 A and 636 W continuously. Its high-peak capability supports short motor-start and electromechanical loads under the model-specific duty and average-power limits. Active PFC, fan control, remote sensing and DC-OK are built in. Product Datasheet Download MEAN WELL HRP-600N3 Datasheet (PDF) The HRP-600N3 section is on PDF pages 13, 14, 15, 16, 17, 18. Refer to the complete mechanical drawings and notes when planning installation. Model and Continuous Output Complete model HRP-600N3-12 Model meaning HRP identifies the series; 600 is the nominal power class; N3 identifies the 3.5-times peak-power family; 12 identifies the main-output voltage. Rated continuous output 12 VDC / 53 A / 636 W Normal current range 0 to 53 A; apply input and temperature derating. Voltage adjustment 10.2–13.8 V using SVR1 Ripple and noise 200 mVp-p maximum Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.3%; load regulation ±0.5%. Typical efficiency 88% Unqualified specifications are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple and noise use 20 MHz bandwidth, a 12-inch twisted pair and 0.1 µF plus 47 µF parallel capacitors at its end. Input and Timing Continuous input 85–264 VAC, 47–63 Hz, or 120–370 VDC. Low-line operation requires derating. Short-duration input withstand 300 VAC for 5 seconds; not a continuous input rating. Typical power factor >0.94 at 230 VAC; >0.98 at 115 VAC, at full load. Typical AC current 7.6 A at 115 VAC; 3.6 A at 230 VAC. Typical inrush / leakage 35 A at 115 VAC; 70 A at 230 VAC. Leakage current <2 mA at 240 VAC. Setup / rise time Setup 1800 ms at 230 VAC or 3600 ms at 115 VAC; rise 50 ms, at full load. Typical hold-up time 16 ms at either 230 VAC or 115 VAC, at full load. The block diagram includes active PFC and active inrush-current limiting; PWM switching frequency is 80 kHz. Peak Power: Duration, Duty and Average Load This is an intermittent high-peak design, not a continuous 2100 W supply. The family claim is up to 350% of the nominal 600 W class; this model retains its 636 W continuous rating. The peak-power chart extends to 2100 W at 200 VAC only at 5% duty, subject to all operating limits. Keep each peak pulse at 5 seconds or less. Duty = t / T × 100% and must not exceed 35%; the model- and input-specific curve can impose a much lower limit. Here t is peak width and T is the complete repeating period. Average power = [Ppk × t + Pnpk × (T − t)] / T must remain at or below 636 W, with any further derating applied. Ppk is peak power and Pnpk is non-peak power. Both the duty curve and this average-power condition must be satisfied. At 200 VAC, use the 12 V curve: its marked anchors include 1200 W at 35%, 1500 W at 15% and 2100 W at 5% duty. At 100 VAC, the lower dotted curve applies: readable anchors include 800 W at 35% and 1200 W at 5% duty. Use the full curve for intermediate combinations; do not apply the 200 VAC envelope at 100 VAC or extrapolate these curves to other inputs. The −40 to −10°C shaded region is normal-load only. Do not apply peak operation in that region. Protection and Recovery Overload duration If output power exceeds 105% of rated power for more than 5 seconds, the output shuts down; re-power to recover. High-overload current limiting The specification additionally states constant-current limiting for output power above 380% of rated power for more than 5 seconds, followed by shutdown; re-power to recover. Overvoltage 14.4–16.8 V; shutdown, re-power to recover. Overtemperature Shutdown; automatic recovery after temperature decreases. Short-circuit, overload, overvoltage and overtemperature protection are listed. Protection thresholds are not permissible continuous or peak operating ratings; remain within the peak curve, pulse-duration and average-power limits. Cooling, Derating and Environment Fan control, typical Fan turns on at the printed load threshold of 35 ±15%, or when internal sensor RTH2 reaches at least 50°C. RTH2 is not ambient temperature. Horizontal thermal curve 100% normal load from −40 to +50°C, falling to 50% at +70°C. The shaded −40 to −10°C range permits normal load only. Input-voltage curve At 60 Hz: 80% load at 85 VAC, rising to 100% at 100 VAC; full load from 100 to 264 VAC. Operating / storage Working: −40 to +70°C with derating, 20–90% RH. Storage: −40 to +85°C, 10–95% RH. Non-condensing. Temperature coefficient ±0.03%/°C from 0 to 50°C Vibration 10–500 Hz, 5 G, 10 minutes/cycle, 60 minutes each on X, Y and Z axes. Altitude Up to 5000 m; above 2000 m reduce allowable ambient temperature by 5°C per additional 1000 m for this fan-cooled model. Cooling air runs from the input/fan end toward the output end in the mechanical drawing. Keep this airflow path unobstructed. Apply thermal, input, altitude and peak-duty limitations together. Remote Sense and DC-OK CN100 pin 1 DC-OK: TTL-level output-status signal. CN100 pin 2 GND: reference for DC-OK. CN100 pin 3 +S: positive remote sense. CN100 pin 4 −S: negative remote sense. Sense compensation Up to 0.5 V of voltage drop in the load wiring. DC-OK levels Between pin 1 and pin 2: 3.3–5.6 V when the PSU is ON; 0–1 V when OFF. Connect +S and −S to the corresponding load terminals and twist the sense pair together. Main load current uses the power terminals, not the sense pins. The catalog does not specify a DC-OK current-drive or isolation rating here. Remote ON/OFF, an auxiliary standby output and active current sharing are not specified for HRP-600N3. Power Terminals and Mating Parts AC input terminals 1 = AC/L; 2 = AC/N; 3 = FG / protective earth. DC output terminals 1–2 = −V; 3–4 = +V. CN100 onboard connector HRS DF11-4DP-2DS or equivalent Mating housing HRS DF11-4DS or equivalent Contact reference HRS DF11-**SC or equivalent; the printed ** suffix is incomplete. Use the numbered drawing for connector orientation. The mating references do not establish that housings, contacts, cables or mounting screws are supplied. Confirm the complete wire-compatible contact suffix before ordering; no dedicated accessory-kit number or supplied quantity is stated. Dimensions and Installation Body dimensions 218 × 105 × 61.5 mm (L × W × H); case 977G; general drawing tolerance ±1 mm. Base mounting 4-M4, L=6 mm; centre spacing 152.4 × 63.5 mm. The base drawing marks 32.8 mm and 20.75 mm edge offsets. Side mounting 8-M4, L=4 mm, both sides; longitudinal spacing 152.4 mm, vertical spacing 38.3 mm and lower-row height 12.5 mm. Terminal projections Input side 12 mm maximum; output side 18 mm maximum beyond the 218 mm body. Terminal drawing marks AC side marks 8.2 mm and 10 mm; DC side marks 11 mm and 9.2 mm. Refer to the drawing for exact locations. Mounting L limits screw penetration into the enclosure, not total screw length; allow for mounting-surface thickness. No mounting or power-terminal tightening torque is specified in this section. The output-end view identifies the LED and SVR1 voltage adjustment. No LED colour or further diagnostic behaviour is specified. Follow the complete drawing and installation manual for the installation envelope. Safety and EMC Safety approvals UL62368-1; TUV BS EN/EN62368-1; EAC TP TC004; AS/NZS62368.1. Withstand voltage Input–output 3 kVAC; input–FG 2 kVAC; output–FG 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input–output, input–FG and output–FG. Emission / harmonics BS EN/EN55032 Class B conducted and radiated; BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3 voltage flicker. Immunity framework BS EN/EN55035; BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. BS EN/EN61000-4-3: Level 3, 10 V/m. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. BS EN/EN61000-4-5: Level 4, 4 kV line–FG and 2 kV line–line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V. BS EN/EN61000-4-8: Level 4, 30 A/m. Dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. This supply is a component for final equipment. EMC tests used a 360 × 360 × 1 mm metal plate. The completed equipment must be checked again for EMC compliance; component approvals do not automatically certify the installation. Reliability, Weight and Catalogue Reference Minimum MTBF 1380.2K hours, Telcordia TR/SR-332 (Bellcore); 191.8K hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The manufacturer datasheet lists 5 years, subject to applicable manufacturer terms. Catalogue packing reference per unit 1.39 kg / 1390 g Published carton data 8 pieces / 12.1 kg / 1.58 CUFT Document HRP-600N3-SPEC, 2026-04-03; combined HRP-N3 PDF pages 13–18. The per-unit packing reference is not a measured net or shipment weight; do not use the carton total as individual product weight. MTBF is a prediction rather than a guaranteed lifetime. Typical applications listed include industrial automation and control, electromechanical equipment, diagnostic or biological facilities, test and measurement systems, and telecommunications.

Read more less

MEAN WELL HRP-300N3-48 is a single-output enclosed AC/DC power supply rated 48 V, 7 A and 336 W for normal operation. Its N3 peak-power function supports short-duration motor-starting and electromechanical loads, within the dedicated input, pulse, duty-cycle, average-power and temperature limits. It includes active PFC, fan cooling, remote sense and DC-OK. Product Datasheet Download MEAN WELL HRP-300N3 Datasheet (PDF) The HRP-300N3 section is on PDF pages 7, 8, 9, 10, 11, 12. Refer to the complete mechanical drawings and notes when planning installation. Model and Rated Output Complete model HRP-300N3-48 Model code HRP is the series; 300 is its nominal wattage class; N3 denotes the 3.5-times short-duration peak-power class; the final code identifies the rated output voltage. Actual continuous power and the peak curves govern operation. Rated continuous output 48 VDC / 7 A / 336 W Continuous current range 0 to 7 A, subject to the input and temperature derating curves. Output voltage adjustment 40.8 to 55.2 V using SVR Maximum ripple and noise 250 mVp-p Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.2%; load regulation ±0.5%. Typical efficiency 89% Unless otherwise specified, measurements use 230 VAC input, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple and noise are measured with a 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Input and Timing Continuous input 85–264 VAC, 47–63 Hz, or 120–370 VDC; universal full-range AC input with low-line derating. Short-duration withstand 300 VAC for 5 seconds, separate from the continuous input rating. Typical power factor >0.95 at 230 VAC; >0.99 at 115 VAC, at full load. Typical AC current 3.5 A at 115 VAC; 1.8 A at 230 VAC. Typical inrush current 35 A at 115 VAC; 75 A at 230 VAC. Leakage current <2 mA at 240 VAC. Setup / rise time Setup: 1000 ms at 230 VAC or 2500 ms at 115 VAC; rise: 50 ms at either input, at full load. Typical hold-up time 16 ms at either 230 VAC or 115 VAC, at full load. The block diagram includes active PFC and active inrush-current limiting. PWM switching frequency is 70 kHz. Short-Duration Peak Power Peak duration t ≤5 seconds per pulse. Overall duty-cycle ceiling Duty = t/T ×100% ≤35%, with lower limits imposed by the peak-power/input-voltage curve. Average-power limit Pav = [Ppk × t + Pnpk × (T − t)] / T ≤336 W, before any additional applicable operating derating. 100 VAC curve The printed 100 VAC curve extends to 600 W peak at a maximum 35% duty cycle. 200 VAC curve anchors 600 W at 35% duty; 800 W at 10% duty; 1050 W at 5% duty. Use the full curve for intermediate operating points. Ppk is peak output power, Pnpk is non-peak output power, t is peak width and T is the repetition period. The duration, duty, average-power, input and temperature restrictions apply together; none is an independent permission to run a higher load. The advertised 350% refers to the nominal 300 W class. Do not multiply this model’s 336 W continuous rating by 3.5 or combine the 1050 W curve endpoint with a 35% duty cycle. Peak operation is not specified in the cold shaded region of the temperature curve. For the catalogue’s 24 V example only: at 200 VAC and 800 W peak, duty is at most 10%; a 5-second pulse requires T ≥50 seconds. At a 336 W cycle average, the printed non-peak limit is 284.4 W. This example is not a universal non-peak load allowance. Protection Short circuit / overload Built-in constant-current limiting. The specification states that output above 105% of rated power for more than 5 seconds shuts down the output; re-power to recover. High-load protection threshold The second overload entry prints >380% (1140 W), with constant-current limiting and shutdown after more than 5 seconds; re-power to recover. This is a protection threshold, not an allowed operating peak. Overvoltage 57.6–67.2 V; output shuts down and requires re-powering. Overtemperature: TSW1 Output shuts down; recovery is automatic after temperature decreases. Overtemperature: RTH3 Output shuts down; re-power to recover. The peak-power limits remain applicable before protection operates. Do not use the protection thresholds as continuous load ratings. Cooling, Temperature and Derating Cooling Built-in fan with ON/OFF control; airflow is towards the fan end and away from the power-terminal end. Typical fan start condition Load threshold 35 ±15%, or internal sensor RTH2 ≥50°C. RTH2 temperature is not ambient temperature. Working temperature −40 to +70°C, subject to the horizontal-mounting derating curve. Normal-load temperature curve 100% load through +50°C, derating to 50% at +70°C; the shaded −40 to −10°C region is normal load only. Input-voltage derating At 60 Hz: 80% load at 85 VAC, rising to 100% at 100 VAC; full normal load is shown from 100 to 264 VAC. Altitude Operation up to 5000 m. Above 2000 m, reduce allowable ambient temperature by 5°C for each additional 1000 m for this fan-cooled model. Humidity / storage Working: 20–90% RH. Storage: −40 to +85°C and 10–95% RH; non-condensing. Temperature coefficient ±0.03%/°C over 0 to 50°C. Vibration 10–500 Hz, 5 G, 10 minutes per cycle, 60 minutes on each X, Y and Z axis. Keep the fan and airflow path unobstructed. The input and thermal curves describe normal-load limits; the peak-power curves and average-power restriction must also be met when using short-duration peaks. Remote Sense and DC-OK Remote-sense connections CN100 pin 7 = +S; pin 8 = −S. Connect to the corresponding positive and negative load points and twist the sense wires together. Compensated wiring drop Up to 0.5 V in the load wiring. DC-OK signal TTL-level output between CN100 pin 3 (DC-OK) and pin 5 (GND): 3.3–5.6 V when ON; 0–1 V when OFF. The main power terminals carry the load current; sense and status pins do not. This section does not assign remote ON/OFF, standby output, voltage/current programming or active parallel current sharing to this model. Terminals, Connectors and Accessories Power input Terminal 1 = AC/L; terminal 2 = AC/N; terminal 3 = FG / protective earth. Power output Terminals 4 and 5 = −V; terminals 6 and 7 = +V. CN100 pin 1 / 2 / 4 / 6 NC; leave unassigned. CN100 pin 3 / 5 3 = DC-OK; 5 = GND. CN100 pin 7 / 8 7 = +S; 8 = −S. Onboard connector HRS DF11-08DP-2DS or equivalent, as printed. Mating housing HRS DF11-8DS or equivalent. Contact selection HRS DF11-**SC or equivalent is the printed contact reference; ** is an unresolved contact suffix. Match the exact connector orientation in the drawing. The contact suffix must be completed for the actual wire/contact selection before ordering; do not treat the wildcard reference as a complete orderable part number. The listed connector and mating references do not establish that spare housings, contacts, cables or screws are supplied. These six pages give no separate complete bracket or cable-kit order code. Dimensions and Installation Body dimensions 199 ×105 ×41 mm (L ×W ×H), case 980A; 1U low-profile body. Drawing tolerance ±1 mm. Flange / terminal envelope 125 mm across the mounting flanges; 17 mm maximum terminal projection as drawn. Bottom mounting 4-M4 L=5 at the indicated locations; 120 ×75 mm hole-centre dimensions. Side mounting 4-M4 L=6 on each separately illustrated side view; longitudinal dimensions are 168.5 mm and 167.5 mm for the respective views. Terminal drawing dimensions 11 mm and 9.2 mm are marked in the terminal view; use the drawing for their exact locations. Local adjustment and indication The mechanical drawing identifies SVR and LED near the power-terminal end. The mounting L callouts specify the available thread/penetration depth shown in the drawing, not included screw quantities or total screw lengths. Allow for the mounting surface. No tightening-torque value is stated here. Use the complete mechanical drawing for the 12.25, 12.5, 15, 18 and 42.5 mm offsets and the orientation of each mounting group. Do not substitute dimensions from the ordinary HRP-300 series. Safety, EMC and Integration Listed approved standards UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004; AS/NZS62368.1. Withstand voltage Input–output: 3 kVAC; input–FG: 2 kVAC; output–FG: 0.5 kVAC. Isolation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input–output, input–FG and output–FG. Emission BS EN/EN55032 conducted and radiated Class B; BS EN/EN61000-3-2 harmonic Class A; BS EN/EN61000-3-3 flicker. Immunity standards BS EN/EN55035; BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF field BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. -4-3: Level 3, 10 V/m. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. -4-5: Level 4, 4 kV Line–FG and 2 kV Line–Line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V. -4-8: Level 4, 30 A/m. Dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. The PSU is a component for installation in final equipment. EMC tests used a 360 ×360 ×1 mm metal plate. The complete equipment must be rechecked for EMC compliance; component standards do not certify the final assembly. Weight, Reliability and Catalogue Reference Catalogue PACKING reference per unit 0.9 kg / 900 g. Published carton data 15 pieces / 14.5 kg / 0.84 CUFT. MTBF, minimum prediction 1524.0K hours, Telcordia TR/SR-332 (Bellcore); 187.7K hours, MIL-HDBK-217F at 25°C. Manufacturer warranty statement 5 years, as listed in the datasheet. Document HRP-300N3-SPEC, 2026-04-03; combined HRP-N3 PDF pages 7–12. The per-unit PACKING figure is a catalogue reference, not a measured net or parcel shipping weight. The carton total must not be entered as a per-unit mass. MTBF is a reliability prediction, not a guaranteed lifetime.

Read more less

MEAN WELL HRP-300N3-36 is a single-output enclosed AC/DC power supply rated 36 V, 9 A and 324 W for normal operation. Its N3 peak-power function supports short-duration motor-starting and electromechanical loads, within the dedicated input, pulse, duty-cycle, average-power and temperature limits. It includes active PFC, fan cooling, remote sense and DC-OK. Product Datasheet Download MEAN WELL HRP-300N3 Datasheet (PDF) The HRP-300N3 section is on PDF pages 7, 8, 9, 10, 11, 12. Refer to the complete mechanical drawings and notes when planning installation. Model and Rated Output Complete model HRP-300N3-36 Model code HRP is the series; 300 is its nominal wattage class; N3 denotes the 3.5-times short-duration peak-power class; the final code identifies the rated output voltage. Actual continuous power and the peak curves govern operation. Rated continuous output 36 VDC / 9 A / 324 W Continuous current range 0 to 9 A, subject to the input and temperature derating curves. Output voltage adjustment 28.8 to 39.6 V using SVR Maximum ripple and noise 250 mVp-p Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.2%; load regulation ±0.5%. Typical efficiency 88% Unless otherwise specified, measurements use 230 VAC input, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple and noise are measured with a 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Input and Timing Continuous input 85–264 VAC, 47–63 Hz, or 120–370 VDC; universal full-range AC input with low-line derating. Short-duration withstand 300 VAC for 5 seconds, separate from the continuous input rating. Typical power factor >0.95 at 230 VAC; >0.99 at 115 VAC, at full load. Typical AC current 3.5 A at 115 VAC; 1.8 A at 230 VAC. Typical inrush current 35 A at 115 VAC; 75 A at 230 VAC. Leakage current <2 mA at 240 VAC. Setup / rise time Setup: 1000 ms at 230 VAC or 2500 ms at 115 VAC; rise: 50 ms at either input, at full load. Typical hold-up time 16 ms at either 230 VAC or 115 VAC, at full load. The block diagram includes active PFC and active inrush-current limiting. PWM switching frequency is 70 kHz. Short-Duration Peak Power Peak duration t ≤5 seconds per pulse. Overall duty-cycle ceiling Duty = t/T ×100% ≤35%, with lower limits imposed by the peak-power/input-voltage curve. Average-power limit Pav = [Ppk × t + Pnpk × (T − t)] / T ≤324 W, before any additional applicable operating derating. 100 VAC curve The printed 100 VAC curve extends to 600 W peak at a maximum 35% duty cycle. 200 VAC curve anchors 600 W at 35% duty; 800 W at 10% duty; 1050 W at 5% duty. Use the full curve for intermediate operating points. Ppk is peak output power, Pnpk is non-peak output power, t is peak width and T is the repetition period. The duration, duty, average-power, input and temperature restrictions apply together; none is an independent permission to run a higher load. The advertised 350% refers to the nominal 300 W class. Do not multiply this model’s 324 W continuous rating by 3.5 or combine the 1050 W curve endpoint with a 35% duty cycle. Peak operation is not specified in the cold shaded region of the temperature curve. For the catalogue’s 24 V example only: at 200 VAC and 800 W peak, duty is at most 10%; a 5-second pulse requires T ≥50 seconds. At a 336 W cycle average, the printed non-peak limit is 284.4 W. This example is not a universal non-peak load allowance. Protection Short circuit / overload Built-in constant-current limiting. The specification states that output above 105% of rated power for more than 5 seconds shuts down the output; re-power to recover. High-load protection threshold The second overload entry prints >380% (1140 W), with constant-current limiting and shutdown after more than 5 seconds; re-power to recover. This is a protection threshold, not an allowed operating peak. Overvoltage 41.4–48.6 V; output shuts down and requires re-powering. Overtemperature: TSW1 Output shuts down; recovery is automatic after temperature decreases. Overtemperature: RTH3 Output shuts down; re-power to recover. The peak-power limits remain applicable before protection operates. Do not use the protection thresholds as continuous load ratings. Cooling, Temperature and Derating Cooling Built-in fan with ON/OFF control; airflow is towards the fan end and away from the power-terminal end. Typical fan start condition Load threshold 35 ±15%, or internal sensor RTH2 ≥50°C. RTH2 temperature is not ambient temperature. Working temperature −40 to +70°C, subject to the horizontal-mounting derating curve. Normal-load temperature curve 100% load through +50°C, derating to 50% at +70°C; the shaded −40 to −10°C region is normal load only. Input-voltage derating At 60 Hz: 80% load at 85 VAC, rising to 100% at 100 VAC; full normal load is shown from 100 to 264 VAC. Altitude Operation up to 5000 m. Above 2000 m, reduce allowable ambient temperature by 5°C for each additional 1000 m for this fan-cooled model. Humidity / storage Working: 20–90% RH. Storage: −40 to +85°C and 10–95% RH; non-condensing. Temperature coefficient ±0.03%/°C over 0 to 50°C. Vibration 10–500 Hz, 5 G, 10 minutes per cycle, 60 minutes on each X, Y and Z axis. Keep the fan and airflow path unobstructed. The input and thermal curves describe normal-load limits; the peak-power curves and average-power restriction must also be met when using short-duration peaks. Remote Sense and DC-OK Remote-sense connections CN100 pin 7 = +S; pin 8 = −S. Connect to the corresponding positive and negative load points and twist the sense wires together. Compensated wiring drop Up to 0.5 V in the load wiring. DC-OK signal TTL-level output between CN100 pin 3 (DC-OK) and pin 5 (GND): 3.3–5.6 V when ON; 0–1 V when OFF. The main power terminals carry the load current; sense and status pins do not. This section does not assign remote ON/OFF, standby output, voltage/current programming or active parallel current sharing to this model. Terminals, Connectors and Accessories Power input Terminal 1 = AC/L; terminal 2 = AC/N; terminal 3 = FG / protective earth. Power output Terminals 4 and 5 = −V; terminals 6 and 7 = +V. CN100 pin 1 / 2 / 4 / 6 NC; leave unassigned. CN100 pin 3 / 5 3 = DC-OK; 5 = GND. CN100 pin 7 / 8 7 = +S; 8 = −S. Onboard connector HRS DF11-08DP-2DS or equivalent, as printed. Mating housing HRS DF11-8DS or equivalent. Contact selection HRS DF11-**SC or equivalent is the printed contact reference; ** is an unresolved contact suffix. Match the exact connector orientation in the drawing. The contact suffix must be completed for the actual wire/contact selection before ordering; do not treat the wildcard reference as a complete orderable part number. The listed connector and mating references do not establish that spare housings, contacts, cables or screws are supplied. These six pages give no separate complete bracket or cable-kit order code. Dimensions and Installation Body dimensions 199 ×105 ×41 mm (L ×W ×H), case 980A; 1U low-profile body. Drawing tolerance ±1 mm. Flange / terminal envelope 125 mm across the mounting flanges; 17 mm maximum terminal projection as drawn. Bottom mounting 4-M4 L=5 at the indicated locations; 120 ×75 mm hole-centre dimensions. Side mounting 4-M4 L=6 on each separately illustrated side view; longitudinal dimensions are 168.5 mm and 167.5 mm for the respective views. Terminal drawing dimensions 11 mm and 9.2 mm are marked in the terminal view; use the drawing for their exact locations. Local adjustment and indication The mechanical drawing identifies SVR and LED near the power-terminal end. The mounting L callouts specify the available thread/penetration depth shown in the drawing, not included screw quantities or total screw lengths. Allow for the mounting surface. No tightening-torque value is stated here. Use the complete mechanical drawing for the 12.25, 12.5, 15, 18 and 42.5 mm offsets and the orientation of each mounting group. Do not substitute dimensions from the ordinary HRP-300 series. Safety, EMC and Integration Listed approved standards UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004; AS/NZS62368.1. Withstand voltage Input–output: 3 kVAC; input–FG: 2 kVAC; output–FG: 0.5 kVAC. Isolation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input–output, input–FG and output–FG. Emission BS EN/EN55032 conducted and radiated Class B; BS EN/EN61000-3-2 harmonic Class A; BS EN/EN61000-3-3 flicker. Immunity standards BS EN/EN55035; BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF field BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. -4-3: Level 3, 10 V/m. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. -4-5: Level 4, 4 kV Line–FG and 2 kV Line–Line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V. -4-8: Level 4, 30 A/m. Dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. The PSU is a component for installation in final equipment. EMC tests used a 360 ×360 ×1 mm metal plate. The complete equipment must be rechecked for EMC compliance; component standards do not certify the final assembly. Weight, Reliability and Catalogue Reference Catalogue PACKING reference per unit 0.9 kg / 900 g. Published carton data 15 pieces / 14.5 kg / 0.84 CUFT. MTBF, minimum prediction 1524.0K hours, Telcordia TR/SR-332 (Bellcore); 187.7K hours, MIL-HDBK-217F at 25°C. Manufacturer warranty statement 5 years, as listed in the datasheet. Document HRP-300N3-SPEC, 2026-04-03; combined HRP-N3 PDF pages 7–12. The per-unit PACKING figure is a catalogue reference, not a measured net or parcel shipping weight. The carton total must not be entered as a per-unit mass. MTBF is a reliability prediction, not a guaranteed lifetime.

Read more less

MEAN WELL HRP-300N3-24 is a single-output enclosed AC/DC power supply rated 24 V, 14 A and 336 W for normal operation. Its N3 peak-power function supports short-duration motor-starting and electromechanical loads, within the dedicated input, pulse, duty-cycle, average-power and temperature limits. It includes active PFC, fan cooling, remote sense and DC-OK. Product Datasheet Download MEAN WELL HRP-300N3 Datasheet (PDF) The HRP-300N3 section is on PDF pages 7, 8, 9, 10, 11, 12. Refer to the complete mechanical drawings and notes when planning installation. Model and Rated Output Complete model HRP-300N3-24 Model code HRP is the series; 300 is its nominal wattage class; N3 denotes the 3.5-times short-duration peak-power class; the final code identifies the rated output voltage. Actual continuous power and the peak curves govern operation. Rated continuous output 24 VDC / 14 A / 336 W Continuous current range 0 to 14 A, subject to the input and temperature derating curves. Output voltage adjustment 21.6 to 28.8 V using SVR Maximum ripple and noise 150 mVp-p Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.2%; load regulation ±0.5%. Typical efficiency 87% Unless otherwise specified, measurements use 230 VAC input, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple and noise are measured with a 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Input and Timing Continuous input 85–264 VAC, 47–63 Hz, or 120–370 VDC; universal full-range AC input with low-line derating. Short-duration withstand 300 VAC for 5 seconds, separate from the continuous input rating. Typical power factor >0.95 at 230 VAC; >0.99 at 115 VAC, at full load. Typical AC current 3.5 A at 115 VAC; 1.8 A at 230 VAC. Typical inrush current 35 A at 115 VAC; 75 A at 230 VAC. Leakage current <2 mA at 240 VAC. Setup / rise time Setup: 1000 ms at 230 VAC or 2500 ms at 115 VAC; rise: 50 ms at either input, at full load. Typical hold-up time 16 ms at either 230 VAC or 115 VAC, at full load. The block diagram includes active PFC and active inrush-current limiting. PWM switching frequency is 70 kHz. Short-Duration Peak Power Peak duration t ≤5 seconds per pulse. Overall duty-cycle ceiling Duty = t/T ×100% ≤35%, with lower limits imposed by the peak-power/input-voltage curve. Average-power limit Pav = [Ppk × t + Pnpk × (T − t)] / T ≤336 W, before any additional applicable operating derating. 100 VAC curve The printed 100 VAC curve extends to 600 W peak at a maximum 35% duty cycle. 200 VAC curve anchors 600 W at 35% duty; 800 W at 10% duty; 1050 W at 5% duty. Use the full curve for intermediate operating points. Ppk is peak output power, Pnpk is non-peak output power, t is peak width and T is the repetition period. The duration, duty, average-power, input and temperature restrictions apply together; none is an independent permission to run a higher load. The advertised 350% refers to the nominal 300 W class. Do not multiply this model’s 336 W continuous rating by 3.5 or combine the 1050 W curve endpoint with a 35% duty cycle. Peak operation is not specified in the cold shaded region of the temperature curve. For the catalogue’s 24 V example only: at 200 VAC and 800 W peak, duty is at most 10%; a 5-second pulse requires T ≥50 seconds. At a 336 W cycle average, the printed non-peak limit is 284.4 W. This example is not a universal non-peak load allowance. Protection Short circuit / overload Built-in constant-current limiting. The specification states that output above 105% of rated power for more than 5 seconds shuts down the output; re-power to recover. High-load protection threshold The second overload entry prints >380% (1140 W), with constant-current limiting and shutdown after more than 5 seconds; re-power to recover. This is a protection threshold, not an allowed operating peak. Overvoltage 30–34.8 V; output shuts down and requires re-powering. Overtemperature: TSW1 Output shuts down; recovery is automatic after temperature decreases. Overtemperature: RTH3 Output shuts down; re-power to recover. The peak-power limits remain applicable before protection operates. Do not use the protection thresholds as continuous load ratings. Cooling, Temperature and Derating Cooling Built-in fan with ON/OFF control; airflow is towards the fan end and away from the power-terminal end. Typical fan start condition Load threshold 35 ±15%, or internal sensor RTH2 ≥50°C. RTH2 temperature is not ambient temperature. Working temperature −40 to +70°C, subject to the horizontal-mounting derating curve. Normal-load temperature curve 100% load through +50°C, derating to 50% at +70°C; the shaded −40 to −10°C region is normal load only. Input-voltage derating At 60 Hz: 80% load at 85 VAC, rising to 100% at 100 VAC; full normal load is shown from 100 to 264 VAC. Altitude Operation up to 5000 m. Above 2000 m, reduce allowable ambient temperature by 5°C for each additional 1000 m for this fan-cooled model. Humidity / storage Working: 20–90% RH. Storage: −40 to +85°C and 10–95% RH; non-condensing. Temperature coefficient ±0.03%/°C over 0 to 50°C. Vibration 10–500 Hz, 5 G, 10 minutes per cycle, 60 minutes on each X, Y and Z axis. Keep the fan and airflow path unobstructed. The input and thermal curves describe normal-load limits; the peak-power curves and average-power restriction must also be met when using short-duration peaks. Remote Sense and DC-OK Remote-sense connections CN100 pin 7 = +S; pin 8 = −S. Connect to the corresponding positive and negative load points and twist the sense wires together. Compensated wiring drop Up to 0.5 V in the load wiring. DC-OK signal TTL-level output between CN100 pin 3 (DC-OK) and pin 5 (GND): 3.3–5.6 V when ON; 0–1 V when OFF. The main power terminals carry the load current; sense and status pins do not. This section does not assign remote ON/OFF, standby output, voltage/current programming or active parallel current sharing to this model. Terminals, Connectors and Accessories Power input Terminal 1 = AC/L; terminal 2 = AC/N; terminal 3 = FG / protective earth. Power output Terminals 4 and 5 = −V; terminals 6 and 7 = +V. CN100 pin 1 / 2 / 4 / 6 NC; leave unassigned. CN100 pin 3 / 5 3 = DC-OK; 5 = GND. CN100 pin 7 / 8 7 = +S; 8 = −S. Onboard connector HRS DF11-08DP-2DS or equivalent, as printed. Mating housing HRS DF11-8DS or equivalent. Contact selection HRS DF11-**SC or equivalent is the printed contact reference; ** is an unresolved contact suffix. Match the exact connector orientation in the drawing. The contact suffix must be completed for the actual wire/contact selection before ordering; do not treat the wildcard reference as a complete orderable part number. The listed connector and mating references do not establish that spare housings, contacts, cables or screws are supplied. These six pages give no separate complete bracket or cable-kit order code. Dimensions and Installation Body dimensions 199 ×105 ×41 mm (L ×W ×H), case 980A; 1U low-profile body. Drawing tolerance ±1 mm. Flange / terminal envelope 125 mm across the mounting flanges; 17 mm maximum terminal projection as drawn. Bottom mounting 4-M4 L=5 at the indicated locations; 120 ×75 mm hole-centre dimensions. Side mounting 4-M4 L=6 on each separately illustrated side view; longitudinal dimensions are 168.5 mm and 167.5 mm for the respective views. Terminal drawing dimensions 11 mm and 9.2 mm are marked in the terminal view; use the drawing for their exact locations. Local adjustment and indication The mechanical drawing identifies SVR and LED near the power-terminal end. The mounting L callouts specify the available thread/penetration depth shown in the drawing, not included screw quantities or total screw lengths. Allow for the mounting surface. No tightening-torque value is stated here. Use the complete mechanical drawing for the 12.25, 12.5, 15, 18 and 42.5 mm offsets and the orientation of each mounting group. Do not substitute dimensions from the ordinary HRP-300 series. Safety, EMC and Integration Listed approved standards UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004; AS/NZS62368.1. Withstand voltage Input–output: 3 kVAC; input–FG: 2 kVAC; output–FG: 0.5 kVAC. Isolation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input–output, input–FG and output–FG. Emission BS EN/EN55032 conducted and radiated Class B; BS EN/EN61000-3-2 harmonic Class A; BS EN/EN61000-3-3 flicker. Immunity standards BS EN/EN55035; BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF field BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. -4-3: Level 3, 10 V/m. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. -4-5: Level 4, 4 kV Line–FG and 2 kV Line–Line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V. -4-8: Level 4, 30 A/m. Dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. The PSU is a component for installation in final equipment. EMC tests used a 360 ×360 ×1 mm metal plate. The complete equipment must be rechecked for EMC compliance; component standards do not certify the final assembly. Weight, Reliability and Catalogue Reference Catalogue PACKING reference per unit 0.9 kg / 900 g. Published carton data 15 pieces / 14.5 kg / 0.84 CUFT. MTBF, minimum prediction 1524.0K hours, Telcordia TR/SR-332 (Bellcore); 187.7K hours, MIL-HDBK-217F at 25°C. Manufacturer warranty statement 5 years, as listed in the datasheet. Document HRP-300N3-SPEC, 2026-04-03; combined HRP-N3 PDF pages 7–12. The per-unit PACKING figure is a catalogue reference, not a measured net or parcel shipping weight. The carton total must not be entered as a per-unit mass. MTBF is a reliability prediction, not a guaranteed lifetime.

Read more less

MEAN WELL HRP-300N3-12 is a single-output enclosed AC/DC power supply rated 12 V, 27 A and 324 W for normal operation. Its N3 peak-power function supports short-duration motor-starting and electromechanical loads, within the dedicated input, pulse, duty-cycle, average-power and temperature limits. It includes active PFC, fan cooling, remote sense and DC-OK. Product Datasheet Download MEAN WELL HRP-300N3 Datasheet (PDF) The HRP-300N3 section is on PDF pages 7, 8, 9, 10, 11, 12. Refer to the complete mechanical drawings and notes when planning installation. Model and Rated Output Complete model HRP-300N3-12 Model code HRP is the series; 300 is its nominal wattage class; N3 denotes the 3.5-times short-duration peak-power class; the final code identifies the rated output voltage. Actual continuous power and the peak curves govern operation. Rated continuous output 12 VDC / 27 A / 324 W Continuous current range 0 to 27 A, subject to the input and temperature derating curves. Output voltage adjustment 10.2 to 13.8 V using SVR Maximum ripple and noise 120 mVp-p Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.3%; load regulation ±0.5%. Typical efficiency 88% Unless otherwise specified, measurements use 230 VAC input, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple and noise are measured with a 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Input and Timing Continuous input 85–264 VAC, 47–63 Hz, or 120–370 VDC; universal full-range AC input with low-line derating. Short-duration withstand 300 VAC for 5 seconds, separate from the continuous input rating. Typical power factor >0.95 at 230 VAC; >0.99 at 115 VAC, at full load. Typical AC current 3.5 A at 115 VAC; 1.8 A at 230 VAC. Typical inrush current 35 A at 115 VAC; 75 A at 230 VAC. Leakage current <2 mA at 240 VAC. Setup / rise time Setup: 1000 ms at 230 VAC or 2500 ms at 115 VAC; rise: 50 ms at either input, at full load. Typical hold-up time 16 ms at either 230 VAC or 115 VAC, at full load. The block diagram includes active PFC and active inrush-current limiting. PWM switching frequency is 70 kHz. Short-Duration Peak Power Peak duration t ≤5 seconds per pulse. Overall duty-cycle ceiling Duty = t/T ×100% ≤35%, with lower limits imposed by the peak-power/input-voltage curve. Average-power limit Pav = [Ppk × t + Pnpk × (T − t)] / T ≤324 W, before any additional applicable operating derating. 100 VAC curve The printed 100 VAC curve extends to 600 W peak at a maximum 35% duty cycle. 200 VAC curve anchors 600 W at 35% duty; 800 W at 10% duty; 1050 W at 5% duty. Use the full curve for intermediate operating points. Ppk is peak output power, Pnpk is non-peak output power, t is peak width and T is the repetition period. The duration, duty, average-power, input and temperature restrictions apply together; none is an independent permission to run a higher load. The advertised 350% refers to the nominal 300 W class. Do not multiply this model’s 324 W continuous rating by 3.5 or combine the 1050 W curve endpoint with a 35% duty cycle. Peak operation is not specified in the cold shaded region of the temperature curve. For the catalogue’s 24 V example only: at 200 VAC and 800 W peak, duty is at most 10%; a 5-second pulse requires T ≥50 seconds. At a 336 W cycle average, the printed non-peak limit is 284.4 W. This example is not a universal non-peak load allowance. Protection Short circuit / overload Built-in constant-current limiting. The specification states that output above 105% of rated power for more than 5 seconds shuts down the output; re-power to recover. High-load protection threshold The second overload entry prints >380% (1140 W), with constant-current limiting and shutdown after more than 5 seconds; re-power to recover. This is a protection threshold, not an allowed operating peak. Overvoltage 14.4–16.8 V; output shuts down and requires re-powering. Overtemperature: TSW1 Output shuts down; recovery is automatic after temperature decreases. Overtemperature: RTH3 Output shuts down; re-power to recover. The peak-power limits remain applicable before protection operates. Do not use the protection thresholds as continuous load ratings. Cooling, Temperature and Derating Cooling Built-in fan with ON/OFF control; airflow is towards the fan end and away from the power-terminal end. Typical fan start condition Load threshold 35 ±15%, or internal sensor RTH2 ≥50°C. RTH2 temperature is not ambient temperature. Working temperature −40 to +70°C, subject to the horizontal-mounting derating curve. Normal-load temperature curve 100% load through +50°C, derating to 50% at +70°C; the shaded −40 to −10°C region is normal load only. Input-voltage derating At 60 Hz: 80% load at 85 VAC, rising to 100% at 100 VAC; full normal load is shown from 100 to 264 VAC. Altitude Operation up to 5000 m. Above 2000 m, reduce allowable ambient temperature by 5°C for each additional 1000 m for this fan-cooled model. Humidity / storage Working: 20–90% RH. Storage: −40 to +85°C and 10–95% RH; non-condensing. Temperature coefficient ±0.03%/°C over 0 to 50°C. Vibration 10–500 Hz, 5 G, 10 minutes per cycle, 60 minutes on each X, Y and Z axis. Keep the fan and airflow path unobstructed. The input and thermal curves describe normal-load limits; the peak-power curves and average-power restriction must also be met when using short-duration peaks. Remote Sense and DC-OK Remote-sense connections CN100 pin 7 = +S; pin 8 = −S. Connect to the corresponding positive and negative load points and twist the sense wires together. Compensated wiring drop Up to 0.5 V in the load wiring. DC-OK signal TTL-level output between CN100 pin 3 (DC-OK) and pin 5 (GND): 3.3–5.6 V when ON; 0–1 V when OFF. The main power terminals carry the load current; sense and status pins do not. This section does not assign remote ON/OFF, standby output, voltage/current programming or active parallel current sharing to this model. Terminals, Connectors and Accessories Power input Terminal 1 = AC/L; terminal 2 = AC/N; terminal 3 = FG / protective earth. Power output Terminals 4 and 5 = −V; terminals 6 and 7 = +V. CN100 pin 1 / 2 / 4 / 6 NC; leave unassigned. CN100 pin 3 / 5 3 = DC-OK; 5 = GND. CN100 pin 7 / 8 7 = +S; 8 = −S. Onboard connector HRS DF11-08DP-2DS or equivalent, as printed. Mating housing HRS DF11-8DS or equivalent. Contact selection HRS DF11-**SC or equivalent is the printed contact reference; ** is an unresolved contact suffix. Match the exact connector orientation in the drawing. The contact suffix must be completed for the actual wire/contact selection before ordering; do not treat the wildcard reference as a complete orderable part number. The listed connector and mating references do not establish that spare housings, contacts, cables or screws are supplied. These six pages give no separate complete bracket or cable-kit order code. Dimensions and Installation Body dimensions 199 ×105 ×41 mm (L ×W ×H), case 980A; 1U low-profile body. Drawing tolerance ±1 mm. Flange / terminal envelope 125 mm across the mounting flanges; 17 mm maximum terminal projection as drawn. Bottom mounting 4-M4 L=5 at the indicated locations; 120 ×75 mm hole-centre dimensions. Side mounting 4-M4 L=6 on each separately illustrated side view; longitudinal dimensions are 168.5 mm and 167.5 mm for the respective views. Terminal drawing dimensions 11 mm and 9.2 mm are marked in the terminal view; use the drawing for their exact locations. Local adjustment and indication The mechanical drawing identifies SVR and LED near the power-terminal end. The mounting L callouts specify the available thread/penetration depth shown in the drawing, not included screw quantities or total screw lengths. Allow for the mounting surface. No tightening-torque value is stated here. Use the complete mechanical drawing for the 12.25, 12.5, 15, 18 and 42.5 mm offsets and the orientation of each mounting group. Do not substitute dimensions from the ordinary HRP-300 series. Safety, EMC and Integration Listed approved standards UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004; AS/NZS62368.1. Withstand voltage Input–output: 3 kVAC; input–FG: 2 kVAC; output–FG: 0.5 kVAC. Isolation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input–output, input–FG and output–FG. Emission BS EN/EN55032 conducted and radiated Class B; BS EN/EN61000-3-2 harmonic Class A; BS EN/EN61000-3-3 flicker. Immunity standards BS EN/EN55035; BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF field BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. -4-3: Level 3, 10 V/m. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. -4-5: Level 4, 4 kV Line–FG and 2 kV Line–Line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V. -4-8: Level 4, 30 A/m. Dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. The PSU is a component for installation in final equipment. EMC tests used a 360 ×360 ×1 mm metal plate. The complete equipment must be rechecked for EMC compliance; component standards do not certify the final assembly. Weight, Reliability and Catalogue Reference Catalogue PACKING reference per unit 0.9 kg / 900 g. Published carton data 15 pieces / 14.5 kg / 0.84 CUFT. MTBF, minimum prediction 1524.0K hours, Telcordia TR/SR-332 (Bellcore); 187.7K hours, MIL-HDBK-217F at 25°C. Manufacturer warranty statement 5 years, as listed in the datasheet. Document HRP-300N3-SPEC, 2026-04-03; combined HRP-N3 PDF pages 7–12. The per-unit PACKING figure is a catalogue reference, not a measured net or parcel shipping weight. The carton total must not be entered as a per-unit mass. MTBF is a reliability prediction, not a guaranteed lifetime.

Read more less

MEAN WELL HRP-150N3-48 is a fanless enclosed AC/DC power supply rated at 158.4 W, 48 V and 3.3 A, with active PFC and remote sensing. Its N3 high-peak design supports intermittent loads only within the specified pulse, duty-cycle, average-power and derating limits. Product Datasheet Download MEAN WELL HRP-150N3 Datasheet (PDF) The HRP-150N3 section is on PDF pages 1, 2, 3, 4, 5, 6. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Configuration Complete model HRP-150N3-48 HRP / 150 / N3 HRP identifies the series, 150 the nominal power class, and N3 the three-times-peak-power design. Peak operation is conditional; this model's rated output is 158.4 W. Voltage code 48 denotes a nominal 48 V single output. Functional scope Active PFC, fanless cooling, constant-current limiting and remote sensing. CN100 pins 3 to 6 are NC; no standby, remote ON/OFF, DC-OK or active current-sharing function is specified. Output Specifications Nominal output / rated current 48 V / 3.3 A Current range / rated output power 0 to 3.3 A / 158.4 W Output voltage adjustment 40.8 to 55.2 V Ripple and noise, maximum 240 mVp-p Voltage tolerance / line / load regulation ±1.5% / ±0.2% / ±0.5% Efficiency, typical 89% Setup / rise time 3000 ms / 50 ms at both 230 VAC and 115 VAC, full load Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load Voltage tolerance includes setup, line and load regulation. Ripple/noise: 20 MHz bandwidth, a 12-inch twisted pair terminated with parallel 0.1 uF and 47 uF capacitors. Input and Power Conversion Input voltage / frequency 85 to 264 VAC or 120 to 370 VDC; 47 to 63 Hz for AC input Power factor, typical >0.95 at 230 VAC; >0.98 at 115 VAC, full load AC input current, typical 1.7 A at 115 VAC; 0.9 A at 230 VAC Inrush current, typical 35 A at 115 VAC; 70 A at 230 VAC Leakage current <1 mA at 240 VAC Short-duration input withstand 300 VAC for 5 seconds; not a continuous operating rating Conversion functions Built-in active PFC and active inrush-current limiting; PWM frequency 90 kHz. Peak Power and Duty Cycle Peak-pulse width t <= 5 seconds Overall duty ceiling Duty <= 35%, with a lower limit where required by the input-specific curve 100 VAC curve anchor At 300 W peak, maximum duty is 10%. 200 VAC curve anchors At 300 W peak, maximum duty is 35%; at 450 W peak, maximum duty is 5%. Low-temperature restriction The shaded -40°C to -10°C region is marked Normal load only; peak-load operation is excluded in that region. The N3 three-times-peak capability is intermittent. Meet the input-specific peak/duty curve, the pulse-width limit, average-power limit and all thermal/input derating limits together. The 35% duty ceiling is not permission to deliver the maximum peak power at 35% duty. Pav = [Ppk x t + Pnpk x (T - t)] / T <= Prated. Here Pav is average power, Ppk peak power, Pnpk non-peak power, t peak-pulse width and T repetition period. For this model, Prated = 158.4 W. Duty = t / T x 100%. Read the complete PDF curve for intermediate operating points. Do not extrapolate an unrestricted peak by multiplying the individual rated wattage by three. The 450 W / 156 W / 140 W worked example in the PDF is explicitly for the 12 V model. Use this model's own 158.4 W rating in the average-power calculation; the 12 V example does not establish its non-peak operating power. Protection and Recovery Overload timing Output power >105% of rated for more than 5 seconds causes output shutdown; remove and restore input power to recover. Constant-current overload statement The table additionally specifies constant-current limiting for output power >330% of rated for more than 5 seconds, followed by output shutdown; re-power to recover. Over-voltage trip / recovery 57.6 to 67.2 V; output shutdown, re-power to recover. Over-temperature protection Output shutdown; automatic recovery after temperature falls. Short-circuit protection is included in the feature list. Protection thresholds do not expand the allowable peak-power/duty operating envelope. Do not replace the stated re-power recovery with an automatic-restart claim. Environment and Derating Cooling / mounting orientation Free-air convection, fanless; derating curves specify horizontal mounting. Ambient / working humidity -40°C to +70°C subject to the curves; 20% to 90% RH, non-condensing Storage temperature / humidity -50°C to +85°C; 10% to 95% RH, non-condensing Temperature coefficient ±0.04%/°C over 0°C to 50°C Altitude Operating altitude up to 5000 m; above 2000 m reduce allowed ambient temperature by 3.5°C per 1000 m for this fanless model. Vibration 10 to 500 Hz, 5 G, 10 minutes per cycle, 60 minutes each along X, Y and Z With cover: 100% load through 40°C, falling to 50% at 60°C. Without cover: 100% through 50°C, falling to 50% at 70°C. Use the applicable manufacturer installation configuration; the 70°C endpoint does not describe the covered unit. At 60 Hz, the input curve shows approximately 75% load at 85 VAC, rising to 100% at 100 VAC; full load is plotted from 100 to 264 VAC. Thermal, altitude, low-temperature and peak/duty limits still apply. Power Terminals, Remote Sense and Mating Parts Power terminal assignment 1: AC/L; 2: AC/N; 3: FG / protective earth; 4 and 5: DC -V; 6 and 7: DC +V. CN100 pin assignment 1: -S; 2: +S; pins 3 to 6: NC, leave unconnected. Sense compensation / connection Maximum 0.5 V line-drop compensation. Connect +S to load positive and -S to load negative; twist the sense pair. CN100 connector / mating housing HRS DF11-6DP-2DSA / HRS DF11-6DS, or equivalents Mating contact family, as printed HRS DF11-**SC, or equivalent DF11-**SC is a printed wildcard, not a complete purchasable contact variant. Confirm the exact terminal for the selected wire and housing. The reviewed pages do not state included mating parts, quantities, a default jumper or a separately orderable mounting kit. Dimensions and Installation Body dimensions, L x W x H 159 x 97 x 38 mm; case 901I; drawing tolerance ±1 mm Threaded mounting holes Base: 2-M3, L=4. Side: 3-M3, L=6. These are hole/depth annotations, not included screw quantities. Drawing mounting references Flanged fixing span 152.5 x 84.5 mm; base threaded-hole spacing 78 mm; side spacings 117 mm horizontally and 18 mm vertically. Other drawing references 3.5 mm hole/slot references; terminal-side projection 10 mm maximum. Power-terminal drawing dimensions Drawing labels 9.5 mm and 8.2 mm; use the drawing for their exact locations. Local voltage adjustment SVR1 is marked in the mechanical drawing; keep adjustment within this model's specified range. Use the complete mechanical drawing for hole positions and allowable depths. No terminal tightening torque, wire gauge or installation clearance is specified in these pages; do not infer those values from another HRP model. Safety, EMC and Reliability Listed safety standards UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004; AS/NZS 62368.1 Dielectric withstand / insulation Input-output 3 kVAC; input-FG 2 kVAC; output-FG 0.5 kVAC. Insulation resistance 100 MΩ for all three pairs at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55032 Class B conducted and radiated; BS EN/EN61000-3-2 Class A harmonics; BS EN/EN61000-3-3 flicker. Immunity framework BS EN/EN55035 and BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF field / EFT BS EN/EN61000-4-2: Level 3, 8 kV air / Level 2, 4 kV contact; -4-3: Level 3, 10 V/m; -4-4: Level 3, 2 kV. Surge / conducted / magnetic field BS EN/EN61000-4-5: Level 4, 4 kV line-FG and 2 kV line-line; -4-6: Level 3, 10 V; -4-8: Level 4, 30 A/m, as printed. Voltage dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. MTBF, minimum 1706.0K hours, Telcordia TR/SR-332 (Bellcore); 222.8K hours, MIL-HDBK-217F at 25°C. The supply is a component for installation in final equipment. EMC testing used a 360 x 360 mm metal plate, 1 mm thick; the finished equipment must be rechecked. MTBF is a statistical reliability figure, not a service-life guarantee. Weight Reference and Manufacturer Notes Per-unit packing mass reference 0.54 kg (540 g), from the catalog PACKING entry; not a separately measured net or shipment weight. Full packing entry 0.54 kg; 24 pcs / 12.96 kg / 0.9 CUFT Catalog revision / warranty statement 2026-04-03. The manufacturer datasheet lists 5 years warranty; this does not add a separate seller warranty. Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Use the model-specific output figures and combined derating limits for selection.

Read more less

MEAN WELL HRP-150N3-36 is a fanless enclosed AC/DC power supply rated at 154.8 W, 36 V and 4.3 A, with active PFC and remote sensing. Its N3 high-peak design supports intermittent loads only within the specified pulse, duty-cycle, average-power and derating limits. Product Datasheet Download MEAN WELL HRP-150N3 Datasheet (PDF) The HRP-150N3 section is on PDF pages 1, 2, 3, 4, 5, 6. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Configuration Complete model HRP-150N3-36 HRP / 150 / N3 HRP identifies the series, 150 the nominal power class, and N3 the three-times-peak-power design. Peak operation is conditional; this model's rated output is 154.8 W. Voltage code 36 denotes a nominal 36 V single output. Functional scope Active PFC, fanless cooling, constant-current limiting and remote sensing. CN100 pins 3 to 6 are NC; no standby, remote ON/OFF, DC-OK or active current-sharing function is specified. Output Specifications Nominal output / rated current 36 V / 4.3 A Current range / rated output power 0 to 4.3 A / 154.8 W Output voltage adjustment 28.8 to 39.6 V Ripple and noise, maximum 200 mVp-p Voltage tolerance / line / load regulation ±1.5% / ±0.2% / ±0.5% Efficiency, typical 89% Setup / rise time 3000 ms / 50 ms at both 230 VAC and 115 VAC, full load Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load Voltage tolerance includes setup, line and load regulation. Ripple/noise: 20 MHz bandwidth, a 12-inch twisted pair terminated with parallel 0.1 uF and 47 uF capacitors. Input and Power Conversion Input voltage / frequency 85 to 264 VAC or 120 to 370 VDC; 47 to 63 Hz for AC input Power factor, typical >0.95 at 230 VAC; >0.98 at 115 VAC, full load AC input current, typical 1.7 A at 115 VAC; 0.9 A at 230 VAC Inrush current, typical 35 A at 115 VAC; 70 A at 230 VAC Leakage current <1 mA at 240 VAC Short-duration input withstand 300 VAC for 5 seconds; not a continuous operating rating Conversion functions Built-in active PFC and active inrush-current limiting; PWM frequency 90 kHz. Peak Power and Duty Cycle Peak-pulse width t <= 5 seconds Overall duty ceiling Duty <= 35%, with a lower limit where required by the input-specific curve 100 VAC curve anchor At 300 W peak, maximum duty is 10%. 200 VAC curve anchors At 300 W peak, maximum duty is 35%; at 450 W peak, maximum duty is 5%. Low-temperature restriction The shaded -40°C to -10°C region is marked Normal load only; peak-load operation is excluded in that region. The N3 three-times-peak capability is intermittent. Meet the input-specific peak/duty curve, the pulse-width limit, average-power limit and all thermal/input derating limits together. The 35% duty ceiling is not permission to deliver the maximum peak power at 35% duty. Pav = [Ppk x t + Pnpk x (T - t)] / T <= Prated. Here Pav is average power, Ppk peak power, Pnpk non-peak power, t peak-pulse width and T repetition period. For this model, Prated = 154.8 W. Duty = t / T x 100%. Read the complete PDF curve for intermediate operating points. Do not extrapolate an unrestricted peak by multiplying the individual rated wattage by three. The 450 W / 156 W / 140 W worked example in the PDF is explicitly for the 12 V model. Use this model's own 154.8 W rating in the average-power calculation; the 12 V example does not establish its non-peak operating power. Protection and Recovery Overload timing Output power >105% of rated for more than 5 seconds causes output shutdown; remove and restore input power to recover. Constant-current overload statement The table additionally specifies constant-current limiting for output power >330% of rated for more than 5 seconds, followed by output shutdown; re-power to recover. Over-voltage trip / recovery 41.4 to 48.6 V; output shutdown, re-power to recover. Over-temperature protection Output shutdown; automatic recovery after temperature falls. Short-circuit protection is included in the feature list. Protection thresholds do not expand the allowable peak-power/duty operating envelope. Do not replace the stated re-power recovery with an automatic-restart claim. Environment and Derating Cooling / mounting orientation Free-air convection, fanless; derating curves specify horizontal mounting. Ambient / working humidity -40°C to +70°C subject to the curves; 20% to 90% RH, non-condensing Storage temperature / humidity -50°C to +85°C; 10% to 95% RH, non-condensing Temperature coefficient ±0.04%/°C over 0°C to 50°C Altitude Operating altitude up to 5000 m; above 2000 m reduce allowed ambient temperature by 3.5°C per 1000 m for this fanless model. Vibration 10 to 500 Hz, 5 G, 10 minutes per cycle, 60 minutes each along X, Y and Z With cover: 100% load through 40°C, falling to 50% at 60°C. Without cover: 100% through 50°C, falling to 50% at 70°C. Use the applicable manufacturer installation configuration; the 70°C endpoint does not describe the covered unit. At 60 Hz, the input curve shows approximately 75% load at 85 VAC, rising to 100% at 100 VAC; full load is plotted from 100 to 264 VAC. Thermal, altitude, low-temperature and peak/duty limits still apply. Power Terminals, Remote Sense and Mating Parts Power terminal assignment 1: AC/L; 2: AC/N; 3: FG / protective earth; 4 and 5: DC -V; 6 and 7: DC +V. CN100 pin assignment 1: -S; 2: +S; pins 3 to 6: NC, leave unconnected. Sense compensation / connection Maximum 0.5 V line-drop compensation. Connect +S to load positive and -S to load negative; twist the sense pair. CN100 connector / mating housing HRS DF11-6DP-2DSA / HRS DF11-6DS, or equivalents Mating contact family, as printed HRS DF11-**SC, or equivalent DF11-**SC is a printed wildcard, not a complete purchasable contact variant. Confirm the exact terminal for the selected wire and housing. The reviewed pages do not state included mating parts, quantities, a default jumper or a separately orderable mounting kit. Dimensions and Installation Body dimensions, L x W x H 159 x 97 x 38 mm; case 901I; drawing tolerance ±1 mm Threaded mounting holes Base: 2-M3, L=4. Side: 3-M3, L=6. These are hole/depth annotations, not included screw quantities. Drawing mounting references Flanged fixing span 152.5 x 84.5 mm; base threaded-hole spacing 78 mm; side spacings 117 mm horizontally and 18 mm vertically. Other drawing references 3.5 mm hole/slot references; terminal-side projection 10 mm maximum. Power-terminal drawing dimensions Drawing labels 9.5 mm and 8.2 mm; use the drawing for their exact locations. Local voltage adjustment SVR1 is marked in the mechanical drawing; keep adjustment within this model's specified range. Use the complete mechanical drawing for hole positions and allowable depths. No terminal tightening torque, wire gauge or installation clearance is specified in these pages; do not infer those values from another HRP model. Safety, EMC and Reliability Listed safety standards UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004; AS/NZS 62368.1 Dielectric withstand / insulation Input-output 3 kVAC; input-FG 2 kVAC; output-FG 0.5 kVAC. Insulation resistance 100 MΩ for all three pairs at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55032 Class B conducted and radiated; BS EN/EN61000-3-2 Class A harmonics; BS EN/EN61000-3-3 flicker. Immunity framework BS EN/EN55035 and BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF field / EFT BS EN/EN61000-4-2: Level 3, 8 kV air / Level 2, 4 kV contact; -4-3: Level 3, 10 V/m; -4-4: Level 3, 2 kV. Surge / conducted / magnetic field BS EN/EN61000-4-5: Level 4, 4 kV line-FG and 2 kV line-line; -4-6: Level 3, 10 V; -4-8: Level 4, 30 A/m, as printed. Voltage dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. MTBF, minimum 1706.0K hours, Telcordia TR/SR-332 (Bellcore); 222.8K hours, MIL-HDBK-217F at 25°C. The supply is a component for installation in final equipment. EMC testing used a 360 x 360 mm metal plate, 1 mm thick; the finished equipment must be rechecked. MTBF is a statistical reliability figure, not a service-life guarantee. Weight Reference and Manufacturer Notes Per-unit packing mass reference 0.54 kg (540 g), from the catalog PACKING entry; not a separately measured net or shipment weight. Full packing entry 0.54 kg; 24 pcs / 12.96 kg / 0.9 CUFT Catalog revision / warranty statement 2026-04-03. The manufacturer datasheet lists 5 years warranty; this does not add a separate seller warranty. Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Use the model-specific output figures and combined derating limits for selection.

Read more less

MEAN WELL HRP-150N3-24 is a fanless enclosed AC/DC power supply rated at 156 W, 24 V and 6.5 A, with active PFC and remote sensing. Its N3 high-peak design supports intermittent loads only within the specified pulse, duty-cycle, average-power and derating limits. Product Datasheet Download MEAN WELL HRP-150N3 Datasheet (PDF) The HRP-150N3 section is on PDF pages 1, 2, 3, 4, 5, 6. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Configuration Complete model HRP-150N3-24 HRP / 150 / N3 HRP identifies the series, 150 the nominal power class, and N3 the three-times-peak-power design. Peak operation is conditional; this model's rated output is 156 W. Voltage code 24 denotes a nominal 24 V single output. Functional scope Active PFC, fanless cooling, constant-current limiting and remote sensing. CN100 pins 3 to 6 are NC; no standby, remote ON/OFF, DC-OK or active current-sharing function is specified. Output Specifications Nominal output / rated current 24 V / 6.5 A Current range / rated output power 0 to 6.5 A / 156 W Output voltage adjustment 21.6 to 28.8 V Ripple and noise, maximum 150 mVp-p Voltage tolerance / line / load regulation ±1.5% / ±0.2% / ±0.5% Efficiency, typical 88% Setup / rise time 3000 ms / 50 ms at both 230 VAC and 115 VAC, full load Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load Voltage tolerance includes setup, line and load regulation. Ripple/noise: 20 MHz bandwidth, a 12-inch twisted pair terminated with parallel 0.1 uF and 47 uF capacitors. Input and Power Conversion Input voltage / frequency 85 to 264 VAC or 120 to 370 VDC; 47 to 63 Hz for AC input Power factor, typical >0.95 at 230 VAC; >0.98 at 115 VAC, full load AC input current, typical 1.7 A at 115 VAC; 0.9 A at 230 VAC Inrush current, typical 35 A at 115 VAC; 70 A at 230 VAC Leakage current <1 mA at 240 VAC Short-duration input withstand 300 VAC for 5 seconds; not a continuous operating rating Conversion functions Built-in active PFC and active inrush-current limiting; PWM frequency 90 kHz. Peak Power and Duty Cycle Peak-pulse width t <= 5 seconds Overall duty ceiling Duty <= 35%, with a lower limit where required by the input-specific curve 100 VAC curve anchor At 300 W peak, maximum duty is 10%. 200 VAC curve anchors At 300 W peak, maximum duty is 35%; at 450 W peak, maximum duty is 5%. Low-temperature restriction The shaded -40°C to -10°C region is marked Normal load only; peak-load operation is excluded in that region. The N3 three-times-peak capability is intermittent. Meet the input-specific peak/duty curve, the pulse-width limit, average-power limit and all thermal/input derating limits together. The 35% duty ceiling is not permission to deliver the maximum peak power at 35% duty. Pav = [Ppk x t + Pnpk x (T - t)] / T <= Prated. Here Pav is average power, Ppk peak power, Pnpk non-peak power, t peak-pulse width and T repetition period. For this model, Prated = 156 W. Duty = t / T x 100%. Read the complete PDF curve for intermediate operating points. Do not extrapolate an unrestricted peak by multiplying the individual rated wattage by three. The 450 W / 156 W / 140 W worked example in the PDF is explicitly for the 12 V model. Use this model's own 156 W rating in the average-power calculation; the 12 V example does not establish its non-peak operating power. Protection and Recovery Overload timing Output power >105% of rated for more than 5 seconds causes output shutdown; remove and restore input power to recover. Constant-current overload statement The table additionally specifies constant-current limiting for output power >330% of rated for more than 5 seconds, followed by output shutdown; re-power to recover. Over-voltage trip / recovery 30 to 34.8 V; output shutdown, re-power to recover. Over-temperature protection Output shutdown; automatic recovery after temperature falls. Short-circuit protection is included in the feature list. Protection thresholds do not expand the allowable peak-power/duty operating envelope. Do not replace the stated re-power recovery with an automatic-restart claim. Environment and Derating Cooling / mounting orientation Free-air convection, fanless; derating curves specify horizontal mounting. Ambient / working humidity -40°C to +70°C subject to the curves; 20% to 90% RH, non-condensing Storage temperature / humidity -50°C to +85°C; 10% to 95% RH, non-condensing Temperature coefficient ±0.04%/°C over 0°C to 50°C Altitude Operating altitude up to 5000 m; above 2000 m reduce allowed ambient temperature by 3.5°C per 1000 m for this fanless model. Vibration 10 to 500 Hz, 5 G, 10 minutes per cycle, 60 minutes each along X, Y and Z With cover: 100% load through 40°C, falling to 50% at 60°C. Without cover: 100% through 50°C, falling to 50% at 70°C. Use the applicable manufacturer installation configuration; the 70°C endpoint does not describe the covered unit. At 60 Hz, the input curve shows approximately 75% load at 85 VAC, rising to 100% at 100 VAC; full load is plotted from 100 to 264 VAC. Thermal, altitude, low-temperature and peak/duty limits still apply. Power Terminals, Remote Sense and Mating Parts Power terminal assignment 1: AC/L; 2: AC/N; 3: FG / protective earth; 4 and 5: DC -V; 6 and 7: DC +V. CN100 pin assignment 1: -S; 2: +S; pins 3 to 6: NC, leave unconnected. Sense compensation / connection Maximum 0.5 V line-drop compensation. Connect +S to load positive and -S to load negative; twist the sense pair. CN100 connector / mating housing HRS DF11-6DP-2DSA / HRS DF11-6DS, or equivalents Mating contact family, as printed HRS DF11-**SC, or equivalent DF11-**SC is a printed wildcard, not a complete purchasable contact variant. Confirm the exact terminal for the selected wire and housing. The reviewed pages do not state included mating parts, quantities, a default jumper or a separately orderable mounting kit. Dimensions and Installation Body dimensions, L x W x H 159 x 97 x 38 mm; case 901I; drawing tolerance ±1 mm Threaded mounting holes Base: 2-M3, L=4. Side: 3-M3, L=6. These are hole/depth annotations, not included screw quantities. Drawing mounting references Flanged fixing span 152.5 x 84.5 mm; base threaded-hole spacing 78 mm; side spacings 117 mm horizontally and 18 mm vertically. Other drawing references 3.5 mm hole/slot references; terminal-side projection 10 mm maximum. Power-terminal drawing dimensions Drawing labels 9.5 mm and 8.2 mm; use the drawing for their exact locations. Local voltage adjustment SVR1 is marked in the mechanical drawing; keep adjustment within this model's specified range. Use the complete mechanical drawing for hole positions and allowable depths. No terminal tightening torque, wire gauge or installation clearance is specified in these pages; do not infer those values from another HRP model. Safety, EMC and Reliability Listed safety standards UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004; AS/NZS 62368.1 Dielectric withstand / insulation Input-output 3 kVAC; input-FG 2 kVAC; output-FG 0.5 kVAC. Insulation resistance 100 MΩ for all three pairs at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55032 Class B conducted and radiated; BS EN/EN61000-3-2 Class A harmonics; BS EN/EN61000-3-3 flicker. Immunity framework BS EN/EN55035 and BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF field / EFT BS EN/EN61000-4-2: Level 3, 8 kV air / Level 2, 4 kV contact; -4-3: Level 3, 10 V/m; -4-4: Level 3, 2 kV. Surge / conducted / magnetic field BS EN/EN61000-4-5: Level 4, 4 kV line-FG and 2 kV line-line; -4-6: Level 3, 10 V; -4-8: Level 4, 30 A/m, as printed. Voltage dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. MTBF, minimum 1706.0K hours, Telcordia TR/SR-332 (Bellcore); 222.8K hours, MIL-HDBK-217F at 25°C. The supply is a component for installation in final equipment. EMC testing used a 360 x 360 mm metal plate, 1 mm thick; the finished equipment must be rechecked. MTBF is a statistical reliability figure, not a service-life guarantee. Weight Reference and Manufacturer Notes Per-unit packing mass reference 0.54 kg (540 g), from the catalog PACKING entry; not a separately measured net or shipment weight. Full packing entry 0.54 kg; 24 pcs / 12.96 kg / 0.9 CUFT Catalog revision / warranty statement 2026-04-03. The manufacturer datasheet lists 5 years warranty; this does not add a separate seller warranty. Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Use the model-specific output figures and combined derating limits for selection.

Read more less

MEAN WELL HRP-150N3-12 is a fanless enclosed AC/DC power supply rated at 156 W, 12 V and 13 A, with active PFC and remote sensing. Its N3 high-peak design supports intermittent loads only within the specified pulse, duty-cycle, average-power and derating limits. Product Datasheet Download MEAN WELL HRP-150N3 Datasheet (PDF) The HRP-150N3 section is on PDF pages 1, 2, 3, 4, 5, 6. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Configuration Complete model HRP-150N3-12 HRP / 150 / N3 HRP identifies the series, 150 the nominal power class, and N3 the three-times-peak-power design. Peak operation is conditional; this model's rated output is 156 W. Voltage code 12 denotes a nominal 12 V single output. Functional scope Active PFC, fanless cooling, constant-current limiting and remote sensing. CN100 pins 3 to 6 are NC; no standby, remote ON/OFF, DC-OK or active current-sharing function is specified. Output Specifications Nominal output / rated current 12 V / 13 A Current range / rated output power 0 to 13 A / 156 W Output voltage adjustment 10.2 to 13.8 V Ripple and noise, maximum 120 mVp-p Voltage tolerance / line / load regulation ±1.5% / ±0.3% / ±0.5% Efficiency, typical 88% Setup / rise time 3000 ms / 50 ms at both 230 VAC and 115 VAC, full load Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load Voltage tolerance includes setup, line and load regulation. Ripple/noise: 20 MHz bandwidth, a 12-inch twisted pair terminated with parallel 0.1 uF and 47 uF capacitors. Input and Power Conversion Input voltage / frequency 85 to 264 VAC or 120 to 370 VDC; 47 to 63 Hz for AC input Power factor, typical >0.95 at 230 VAC; >0.98 at 115 VAC, full load AC input current, typical 1.7 A at 115 VAC; 0.9 A at 230 VAC Inrush current, typical 35 A at 115 VAC; 70 A at 230 VAC Leakage current <1 mA at 240 VAC Short-duration input withstand 300 VAC for 5 seconds; not a continuous operating rating Conversion functions Built-in active PFC and active inrush-current limiting; PWM frequency 90 kHz. Peak Power and Duty Cycle Peak-pulse width t <= 5 seconds Overall duty ceiling Duty <= 35%, with a lower limit where required by the input-specific curve 100 VAC curve anchor At 300 W peak, maximum duty is 10%. 200 VAC curve anchors At 300 W peak, maximum duty is 35%; at 450 W peak, maximum duty is 5%. Low-temperature restriction The shaded -40°C to -10°C region is marked Normal load only; peak-load operation is excluded in that region. The N3 three-times-peak capability is intermittent. Meet the input-specific peak/duty curve, the pulse-width limit, average-power limit and all thermal/input derating limits together. The 35% duty ceiling is not permission to deliver the maximum peak power at 35% duty. Pav = [Ppk x t + Pnpk x (T - t)] / T <= Prated. Here Pav is average power, Ppk peak power, Pnpk non-peak power, t peak-pulse width and T repetition period. For this model, Prated = 156 W. Duty = t / T x 100%. Read the complete PDF curve for intermediate operating points. Do not extrapolate an unrestricted peak by multiplying the individual rated wattage by three. The catalog's 12 V example uses 200 VAC input, 450 W peak, at most 5% duty and Pav = Prated = 156 W. For a 5-second pulse, T must be at least 100 seconds; the printed non-peak limit is 140 W. This is a worked conditional example, not a continuous 450 W rating. Protection and Recovery Overload timing Output power >105% of rated for more than 5 seconds causes output shutdown; remove and restore input power to recover. Constant-current overload statement The table additionally specifies constant-current limiting for output power >330% of rated for more than 5 seconds, followed by output shutdown; re-power to recover. Over-voltage trip / recovery 14.4 to 16.8 V; output shutdown, re-power to recover. Over-temperature protection Output shutdown; automatic recovery after temperature falls. Short-circuit protection is included in the feature list. Protection thresholds do not expand the allowable peak-power/duty operating envelope. Do not replace the stated re-power recovery with an automatic-restart claim. Environment and Derating Cooling / mounting orientation Free-air convection, fanless; derating curves specify horizontal mounting. Ambient / working humidity -40°C to +70°C subject to the curves; 20% to 90% RH, non-condensing Storage temperature / humidity -50°C to +85°C; 10% to 95% RH, non-condensing Temperature coefficient ±0.04%/°C over 0°C to 50°C Altitude Operating altitude up to 5000 m; above 2000 m reduce allowed ambient temperature by 3.5°C per 1000 m for this fanless model. Vibration 10 to 500 Hz, 5 G, 10 minutes per cycle, 60 minutes each along X, Y and Z With cover: 100% load through 40°C, falling to 50% at 60°C. Without cover: 100% through 50°C, falling to 50% at 70°C. Use the applicable manufacturer installation configuration; the 70°C endpoint does not describe the covered unit. At 60 Hz, the input curve shows approximately 75% load at 85 VAC, rising to 100% at 100 VAC; full load is plotted from 100 to 264 VAC. Thermal, altitude, low-temperature and peak/duty limits still apply. Power Terminals, Remote Sense and Mating Parts Power terminal assignment 1: AC/L; 2: AC/N; 3: FG / protective earth; 4 and 5: DC -V; 6 and 7: DC +V. CN100 pin assignment 1: -S; 2: +S; pins 3 to 6: NC, leave unconnected. Sense compensation / connection Maximum 0.5 V line-drop compensation. Connect +S to load positive and -S to load negative; twist the sense pair. CN100 connector / mating housing HRS DF11-6DP-2DSA / HRS DF11-6DS, or equivalents Mating contact family, as printed HRS DF11-**SC, or equivalent DF11-**SC is a printed wildcard, not a complete purchasable contact variant. Confirm the exact terminal for the selected wire and housing. The reviewed pages do not state included mating parts, quantities, a default jumper or a separately orderable mounting kit. Dimensions and Installation Body dimensions, L x W x H 159 x 97 x 38 mm; case 901I; drawing tolerance ±1 mm Threaded mounting holes Base: 2-M3, L=4. Side: 3-M3, L=6. These are hole/depth annotations, not included screw quantities. Drawing mounting references Flanged fixing span 152.5 x 84.5 mm; base threaded-hole spacing 78 mm; side spacings 117 mm horizontally and 18 mm vertically. Other drawing references 3.5 mm hole/slot references; terminal-side projection 10 mm maximum. Power-terminal drawing dimensions Drawing labels 9.5 mm and 8.2 mm; use the drawing for their exact locations. Local voltage adjustment SVR1 is marked in the mechanical drawing; keep adjustment within this model's specified range. Use the complete mechanical drawing for hole positions and allowable depths. No terminal tightening torque, wire gauge or installation clearance is specified in these pages; do not infer those values from another HRP model. Safety, EMC and Reliability Listed safety standards UL62368-1; TUV BS EN/EN62368-1; EAC TP TC 004; AS/NZS 62368.1 Dielectric withstand / insulation Input-output 3 kVAC; input-FG 2 kVAC; output-FG 0.5 kVAC. Insulation resistance 100 MΩ for all three pairs at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55032 Class B conducted and radiated; BS EN/EN61000-3-2 Class A harmonics; BS EN/EN61000-3-3 flicker. Immunity framework BS EN/EN55035 and BS EN/EN61000-6-2 (BS EN/EN50082-2). ESD / RF field / EFT BS EN/EN61000-4-2: Level 3, 8 kV air / Level 2, 4 kV contact; -4-3: Level 3, 10 V/m; -4-4: Level 3, 2 kV. Surge / conducted / magnetic field BS EN/EN61000-4-5: Level 4, 4 kV line-FG and 2 kV line-line; -4-6: Level 3, 10 V; -4-8: Level 4, 30 A/m, as printed. Voltage dips and interruptions BS EN/EN61000-4-11: 95% dip for 0.5 periods; 30% dip for 25 periods; 95% interruptions for 250 periods. MTBF, minimum 1706.0K hours, Telcordia TR/SR-332 (Bellcore); 222.8K hours, MIL-HDBK-217F at 25°C. The supply is a component for installation in final equipment. EMC testing used a 360 x 360 mm metal plate, 1 mm thick; the finished equipment must be rechecked. MTBF is a statistical reliability figure, not a service-life guarantee. Weight Reference and Manufacturer Notes Per-unit packing mass reference 0.54 kg (540 g), from the catalog PACKING entry; not a separately measured net or shipment weight. Full packing entry 0.54 kg; 24 pcs / 12.96 kg / 0.9 CUFT Catalog revision / warranty statement 2026-04-03. The manufacturer datasheet lists 5 years warranty; this does not add a separate seller warranty. Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Use the model-specific output figures and combined derating limits for selection.
