HVGC Series: Constant Current LED Driver

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-H-DA

  HVGC-1000A-H-DA LED Driver MEAN WELL HVGC-1000A-H-DA is a 1008 W constant-power LED driver with 5600 mA rated current and a 70–180 V constant-current operating region. This IP67 Class I metal-case version provides dali-2 control and output-current potentiometer and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-H-DA; HVGC-1000 Suffix and configuration DALI-2 control and output-current potentiometer. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 5600 mA Rated output power 1008 W Constant-current voltage region 70–180 V Full-power current range 5600–7000 mA Maximum open-circuit voltage 190 V Catalog current-adjustment range 2800–7000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2800 mA / 180 V; 5600 mA / 180 V; 7000 mA / 144 V; 7000 mA / 70 V; 5600 mA / 90 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 96% Temperature coefficient ±0.03%/°C over 0–50°C Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 190–205 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Digital dimming interface DALI-2 technology controlled on the primary side; 16 groups and 64 addresses. Dimming first step 8% fixed at the first step when the controller sends a command. Local current adjustment The constant-current level is adjustable through the built-in Io ADJ potentiometer within the catalog range. Digital control wiring Connect the compatible bus to DA+ purple and DA− pink as shown in the dedicated mechanical drawing. These are digital-control conductors, not the analog DIM or timer PROG interface. DALI standard reference The catalog DA-Type row references IEC 62386-101, -102 and -207, device type 6 (DT6). Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; DA+ purple, DA− pink. 350 ±20 mm in the dedicated drawing. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Digital-controller installation This DA option uses DALI-2, with the control cable identified as DA+ and DA−. Verify the supplied wiring and compatible controller/network; do not treat these terminals as the analog DIM or timer PROG interface. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-M-DA

  HVGC-1000A-M-DA LED Driver MEAN WELL HVGC-1000A-M-DA is a 1008 W constant-power LED driver with 4200 mA rated current and a 95–240 V constant-current operating region. This IP67 Class I metal-case version provides dali-2 control and output-current potentiometer and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-M-DA; HVGC-1000 Suffix and configuration DALI-2 control and output-current potentiometer. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 4200 mA Rated output power 1008 W Constant-current voltage region 95–240 V Full-power current range 4200–5250 mA Maximum open-circuit voltage 250 V Catalog current-adjustment range 2100–5250 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2100 mA / 240 V; 4200 mA / 240 V; 5250 mA / 192 V; 5250 mA / 95 V; 4200 mA / 120 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 96% Temperature coefficient ±0.03%/°C over 0–50°C Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 250–270 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Digital dimming interface DALI-2 technology controlled on the primary side; 16 groups and 64 addresses. Dimming first step 8% fixed at the first step when the controller sends a command. Local current adjustment The constant-current level is adjustable through the built-in Io ADJ potentiometer within the catalog range. Digital control wiring Connect the compatible bus to DA+ purple and DA− pink as shown in the dedicated mechanical drawing. These are digital-control conductors, not the analog DIM or timer PROG interface. DALI standard reference The catalog DA-Type row references IEC 62386-101, -102 and -207, device type 6 (DT6). Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; DA+ purple, DA− pink. 350 ±20 mm in the dedicated drawing. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Digital-controller installation This DA option uses DALI-2, with the control cable identified as DA+ and DA−. Verify the supplied wiring and compatible controller/network; do not treat these terminals as the analog DIM or timer PROG interface. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-L-DA

  HVGC-1000A-L-DA LED Driver MEAN WELL HVGC-1000A-L-DA is a 1003.2 W constant-power LED driver with 2800 mA rated current and a 150–380 V constant-current operating region. This IP67 Class I metal-case version provides dali-2 control and output-current potentiometer and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-L-DA; HVGC-1000 Suffix and configuration DALI-2 control and output-current potentiometer. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 2800 mA Rated output power 1003.2 W Constant-current voltage region 150–380 V Full-power current range 2640–3280 mA Maximum open-circuit voltage 400 V Catalog current-adjustment range 1320–3280 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1320 mA / 380 V; 2640 mA / 380 V; 3280 mA / 306 V; 3280 mA / 150 V; 2640 mA / 190 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 95.5% Temperature coefficient ±0.03%/°C over 0–50°C Rated versus full-power current The table separately specifies 2800 mA rated current and a 2640–3280 mA full-power range. The 380 V full-power corner is plotted at 2640 mA; do not assume 2800 mA at 380 V is within the rated power. Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 400–425 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Digital dimming interface DALI-2 technology controlled on the primary side; 16 groups and 64 addresses. Dimming first step 8% fixed at the first step when the controller sends a command. Local current adjustment The constant-current level is adjustable through the built-in Io ADJ potentiometer within the catalog range. Digital control wiring Connect the compatible bus to DA+ purple and DA− pink as shown in the dedicated mechanical drawing. These are digital-control conductors, not the analog DIM or timer PROG interface. DALI standard reference The catalog DA-Type row references IEC 62386-101, -102 and -207, device type 6 (DT6). Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; DA+ purple, DA− pink. 350 ±20 mm in the dedicated drawing. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Digital-controller installation This DA option uses DALI-2, with the control cable identified as DA+ and DA−. Verify the supplied wiring and compatible controller/network; do not treat these terminals as the analog DIM or timer PROG interface. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-H-DX

  HVGC-1000A-H-DX LED Driver MEAN WELL HVGC-1000A-H-DX is a 1008 W constant-power LED driver with 5600 mA rated current and a 70–180 V constant-current operating region. This IP67 Class I metal-case version provides customer-defined smart timer dimming and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-H-DX; HVGC-1000 Suffix and configuration Customer-defined smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 5600 mA Rated output power 1008 W Constant-current voltage region 70–180 V Full-power current range 5600–7000 mA Maximum open-circuit voltage 190 V Catalog current-adjustment range 2800–7000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2800 mA / 180 V; 5600 mA / 180 V; 7000 mA / 144 V; 7000 mA / 70 V; 5600 mA / 90 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 96% Temperature coefficient ±0.03%/°C over 0–50°C Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 190–205 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface DX identifies the customer-requested timer profile, without a separate external programming/control cable in the cable specification. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-M-DX

  HVGC-1000A-M-DX LED Driver MEAN WELL HVGC-1000A-M-DX is a 1008 W constant-power LED driver with 4200 mA rated current and a 95–240 V constant-current operating region. This IP67 Class I metal-case version provides customer-defined smart timer dimming and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-M-DX; HVGC-1000 Suffix and configuration Customer-defined smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 4200 mA Rated output power 1008 W Constant-current voltage region 95–240 V Full-power current range 4200–5250 mA Maximum open-circuit voltage 250 V Catalog current-adjustment range 2100–5250 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2100 mA / 240 V; 4200 mA / 240 V; 5250 mA / 192 V; 5250 mA / 95 V; 4200 mA / 120 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 96% Temperature coefficient ±0.03%/°C over 0–50°C Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 250–270 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface DX identifies the customer-requested timer profile, without a separate external programming/control cable in the cable specification. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-L-DX

  HVGC-1000A-L-DX LED Driver MEAN WELL HVGC-1000A-L-DX is a 1003.2 W constant-power LED driver with 2800 mA rated current and a 150–380 V constant-current operating region. This IP67 Class I metal-case version provides customer-defined smart timer dimming and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-L-DX; HVGC-1000 Suffix and configuration Customer-defined smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 2800 mA Rated output power 1003.2 W Constant-current voltage region 150–380 V Full-power current range 2640–3280 mA Maximum open-circuit voltage 400 V Catalog current-adjustment range 1320–3280 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1320 mA / 380 V; 2640 mA / 380 V; 3280 mA / 306 V; 3280 mA / 150 V; 2640 mA / 190 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 95.5% Temperature coefficient ±0.03%/°C over 0–50°C Rated versus full-power current The table separately specifies 2800 mA rated current and a 2640–3280 mA full-power range. The 380 V full-power corner is plotted at 2640 mA; do not assume 2800 mA at 380 V is within the rated power. Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 400–425 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface DX identifies the customer-requested timer profile, without a separate external programming/control cable in the cable specification. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-H-D2

  HVGC-1000A-H-D2 LED Driver MEAN WELL HVGC-1000A-H-D2 is a 1008 W constant-power LED driver with 5600 mA rated current and a 70–180 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-H-D2; HVGC-1000 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 5600 mA Rated output power 1008 W Constant-current voltage region 70–180 V Full-power current range 5600–7000 mA Maximum open-circuit voltage 190 V Catalog current-adjustment range 2800–7000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2800 mA / 180 V; 5600 mA / 180 V; 7000 mA / 144 V; 7000 mA / 70 V; 5600 mA / 90 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 96% Temperature coefficient ±0.03%/°C over 0–50°C Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 190–205 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; PROG+ purple, PROG− pink. 350 ±20 mm in the dedicated drawing. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-M-D2

  HVGC-1000A-M-D2 LED Driver MEAN WELL HVGC-1000A-M-D2 is a 1008 W constant-power LED driver with 4200 mA rated current and a 95–240 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-M-D2; HVGC-1000 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 4200 mA Rated output power 1008 W Constant-current voltage region 95–240 V Full-power current range 4200–5250 mA Maximum open-circuit voltage 250 V Catalog current-adjustment range 2100–5250 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2100 mA / 240 V; 4200 mA / 240 V; 5250 mA / 192 V; 5250 mA / 95 V; 4200 mA / 120 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 96% Temperature coefficient ±0.03%/°C over 0–50°C Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 250–270 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; PROG+ purple, PROG− pink. 350 ±20 mm in the dedicated drawing. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-L-D2

  HVGC-1000A-L-D2 LED Driver MEAN WELL HVGC-1000A-L-D2 is a 1003.2 W constant-power LED driver with 2800 mA rated current and a 150–380 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-L-D2; HVGC-1000 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 2800 mA Rated output power 1003.2 W Constant-current voltage region 150–380 V Full-power current range 2640–3280 mA Maximum open-circuit voltage 400 V Catalog current-adjustment range 1320–3280 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1320 mA / 380 V; 2640 mA / 380 V; 3280 mA / 306 V; 3280 mA / 150 V; 2640 mA / 190 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 95.5% Temperature coefficient ±0.03%/°C over 0–50°C Rated versus full-power current The table separately specifies 2800 mA rated current and a 2640–3280 mA full-power range. The 380 V full-power corner is plotted at 2640 mA; do not assume 2800 mA at 380 V is within the rated power. Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 400–425 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; PROG+ purple, PROG− pink. 350 ±20 mm in the dedicated drawing. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-H-AB

  HVGC-1000A-H-AB LED Driver MEAN WELL HVGC-1000A-H-AB is a 1008 W constant-power LED driver with 5600 mA rated current and a 70–180 V constant-current operating region. This IP67 Class I metal-case version provides 3-in-1 dimming and output-current potentiometer and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-H-AB; HVGC-1000 Suffix and configuration 3-in-1 dimming and output-current potentiometer. Standard catalog execution. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 5600 mA Rated output power 1008 W Constant-current voltage region 70–180 V Full-power current range 5600–7000 mA Maximum open-circuit voltage 190 V Catalog current-adjustment range 2800–7000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2800 mA / 180 V; 5600 mA / 180 V; 7000 mA / 144 V; 7000 mA / 70 V; 5600 mA / 90 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 96% Temperature coefficient ±0.03%/°C over 0–50°C Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Standby power <2 W with AB-Type dimming OFF. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 190–205 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control 3-in-1 dimming Apply 0–10 VDC, a 10 V PWM signal at 100 Hz–3 kHz, or resistance across DIM+ and DIM− to adjust the constant-current level. Local current adjustment Use the built-in Io ADJ potentiometer within this model’s current-adjustment range. Dimming source and synchronization 100 µA typical source current. For N synchronized drivers, the plotted resistance scale extends from 10 kΩ/N to 100 kΩ/N; 100 kΩ/N corresponds to full current. Minimum level and switch-off Minimum dimming level is approximately 6%; output is undefined for 0% < Iout <6%. Approximately 0 VDC, 0 Ω or a 10 V PWM signal at 0% duty can reduce output to 0%. Dimming wiring and load DIM+ purple; DIM− pink. Do not connect DIM− to Vo−. Connect the dimmed output directly to LEDs; this arrangement is not suitable for use with additional drivers. Dimming isolation The current HVGC-1000 catalog explicitly specifies isolated 3-in-1 dimming. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. This AB version requires consideration for built-in use to comply with Type HL application requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; DIM+ purple, DIM− pink. 350 ±20 mm in the dedicated drawing. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Controller installation Verify controller compatibility and capacity for this exact DIM interface. The depicted control conductors are 17 AWG. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-M-AB

  HVGC-1000A-M-AB LED Driver MEAN WELL HVGC-1000A-M-AB is a 1008 W constant-power LED driver with 4200 mA rated current and a 95–240 V constant-current operating region. This IP67 Class I metal-case version provides 3-in-1 dimming and output-current potentiometer and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-M-AB; HVGC-1000 Suffix and configuration 3-in-1 dimming and output-current potentiometer. Standard catalog execution. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 4200 mA Rated output power 1008 W Constant-current voltage region 95–240 V Full-power current range 4200–5250 mA Maximum open-circuit voltage 250 V Catalog current-adjustment range 2100–5250 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2100 mA / 240 V; 4200 mA / 240 V; 5250 mA / 192 V; 5250 mA / 95 V; 4200 mA / 120 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 96% Temperature coefficient ±0.03%/°C over 0–50°C Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Standby power <2 W with AB-Type dimming OFF. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 250–270 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control 3-in-1 dimming Apply 0–10 VDC, a 10 V PWM signal at 100 Hz–3 kHz, or resistance across DIM+ and DIM− to adjust the constant-current level. Local current adjustment Use the built-in Io ADJ potentiometer within this model’s current-adjustment range. Dimming source and synchronization 100 µA typical source current. For N synchronized drivers, the plotted resistance scale extends from 10 kΩ/N to 100 kΩ/N; 100 kΩ/N corresponds to full current. Minimum level and switch-off Minimum dimming level is approximately 6%; output is undefined for 0% < Iout <6%. Approximately 0 VDC, 0 Ω or a 10 V PWM signal at 0% duty can reduce output to 0%. Dimming wiring and load DIM+ purple; DIM− pink. Do not connect DIM− to Vo−. Connect the dimmed output directly to LEDs; this arrangement is not suitable for use with additional drivers. Dimming isolation The current HVGC-1000 catalog explicitly specifies isolated 3-in-1 dimming. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. This AB version requires consideration for built-in use to comply with Type HL application requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; DIM+ purple, DIM− pink. 350 ±20 mm in the dedicated drawing. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Controller installation Verify controller compatibility and capacity for this exact DIM interface. The depicted control conductors are 17 AWG. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-1000 series: Constant Power LED Driver - HVGC-1000A-L-AB

  HVGC-1000A-L-AB LED Driver MEAN WELL HVGC-1000A-L-AB is a 1003.2 W constant-power LED driver with 2800 mA rated current and a 150–380 V constant-current operating region. This IP67 Class I metal-case version provides 3-in-1 dimming and output-current potentiometer and a 12 V / 500 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-1000 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-1000, PDF pages 67–77, revision 2026-02-09. Model selection Full model and series HVGC-1000A-L-AB; HVGC-1000 Suffix and configuration 3-in-1 dimming and output-current potentiometer. Standard catalog execution. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 1000 identifies the auxiliary-output version. Nominal 12 V ±10%, 500 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, high-bay, flood, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 2800 mA Rated output power 1003.2 W Constant-current voltage region 150–380 V Full-power current range 2640–3280 mA Maximum open-circuit voltage 400 V Catalog current-adjustment range 1320–3280 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1320 mA / 380 V; 2640 mA / 380 V; 3280 mA / 306 V; 3280 mA / 150 V; 2640 mA / 190 V. Current tolerance and ripple Current tolerance ±5%; current ripple 3.0% maximum at rated current. Efficiency (typical) 95.5% Temperature coefficient ±0.03%/°C over 0–50°C Rated versus full-power current The table separately specifies 2800 mA rated current and a 2640–3280 mA full-power range. The 380 V full-power corner is plotted at 2640 mA; do not assume 2800 mA at 380 V is within the rated power. Input and performance Input voltage and frequency 180–528 VAC; 47–63 Hz AC. Input current (typical) 3.15 A at 347 VAC; 2.28 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <10% at 347 VAC and load >80%. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1850 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 4 units on a 30 A type B breaker; 8 units on a 30 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 70% load at 180 VAC, increasing to 100% at 230 VAC; 100% through 528 VAC. Apply thermal limits separately. Standby power <2 W with AB-Type dimming OFF. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 400–425 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control 3-in-1 dimming Apply 0–10 VDC, a 10 V PWM signal at 100 Hz–3 kHz, or resistance across DIM+ and DIM− to adjust the constant-current level. Local current adjustment Use the built-in Io ADJ potentiometer within this model’s current-adjustment range. Dimming source and synchronization 100 µA typical source current. For N synchronized drivers, the plotted resistance scale extends from 10 kΩ/N to 100 kΩ/N; 100 kΩ/N corresponds to full current. Minimum level and switch-off Minimum dimming level is approximately 6%; output is undefined for 0% < Iout <6%. Approximately 0 VDC, 0 Ω or a 10 V PWM signal at 0% duty can reduce output to 0%. Dimming wiring and load DIM+ purple; DIM− pink. Do not connect DIM− to Vo−. Connect the dimmed output directly to LEDs; this arrangement is not suitable for use with additional drivers. Dimming isolation The current HVGC-1000 catalog explicitly specifies isolated 3-in-1 dimming. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 277 VAC, 100% load through +45°C, then 60% at +50°C; above 347 VAC, 100% through +50°C, then 60% at +55°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 347 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 682.8K h minimum, Telcordia SR-332 (Bellcore); 68.4K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CAN/CSA C22.2 No. 250.13-17; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; CCC GB/T19510.1 and GB/T19510.213; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. This AB version requires consideration for built-in use to comply with Type HL application requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3 kVAC; input/FG: 2 kVAC; output/FG: 1.8 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission Conducted/radiated: BS EN/EN55015 (CISPR15) / GB/T17743. Harmonic current: BS EN/EN61000-3-2 / GB17625.1, Class C at load ≥50%. Voltage flicker: BS EN/EN61000-3-3. FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61547; CCC GB/T17743 and GB17625.1. EN61000-4-2 ESD: level 3, 8 kV air / level 2, 4 kV contact; -4-3 radiated: level 2; -4-4 EFT: level 3; -4-5 surge: 4 kV line-to-line / 8 kV line-to-earth; -4-6 conducted: level 2; -4-8 magnetic field: level 4. Voltage dips and interruptions EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Mechanical and wiring Dimensions and enclosure 310 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 283.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 145 mm from the right inner end line and 57 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 4.4 kg per unit; 4 pcs / 18.75 kg / 1.16 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; DIM+ purple, DIM− pink. 350 ±20 mm in the dedicated drawing. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; AUX+ gray, AUX− black; 350 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Controller installation Verify controller compatibility and capacity for this exact DIM interface. The depicted control conductors are 17 AWG. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 1000 identifies the auxiliary-output version. Its auxiliary output is 12 V at 500 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. AC input switching requirement To prevent abnormal operation, the catalog specifically requires a “two-way switch” at the AC input. Confirm the required switching arrangement with MEAN WELL and follow the applicable installation design. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $814.69

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-U-DA

  HVGC-650A-U-DA LED Driver MEAN WELL HVGC-650A-U-DA is a 649.6 W constant-power LED driver with 11200 mA rated current and a 24–58 V constant-current operating region. This IP67 Class I metal-case version provides dali control and output-current potentiometer and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-U-DA; HVGC-650 Suffix and configuration DALI control and output-current potentiometer. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 11200 mA Rated output power 649.6 W Constant-current voltage region 24–58 V Full-power current range 11200–14000 mA Maximum open-circuit voltage 70 V Catalog current-adjustment range 5600–14000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 5600 mA / 58 V; 11200 mA / 58 V; 14000 mA / 46.4 V; 11200 mA / 29 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95.5% Temperature coefficient ±0.03%/°C over 0–55°C Lower-voltage source qualification The specification table gives 24–58 V. The I–V illustration labels one corner 23.2 V; these differ. Keep the specified 24 V lower limit unless MEAN WELL confirms a different approved operating point. Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 62–78 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Digital dimming interface DALI technology controlled on the primary side; 16 groups and 64 addresses. Dimming first step 6% fixed at the first step when the controller sends a command. Local current adjustment The constant-current level is adjustable through the built-in Io ADJ potentiometer within the catalog range. Digital control wiring Connect the compatible bus to DA+ purple and DA− pink as shown in the dedicated mechanical drawing. These are digital-control conductors, not the analog DIM or timer PROG interface. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. SELV scope The HVGC-650 series cover identifies SELV only for H and U output ranges; this U model is within that stated range. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SJOW 17 AWG × 4 conductors / H05RN-F; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Four-conductor output The U output uses two red positive and two black negative conductors for the same LED output; these are not independent channels. Control cable SJOW 17 AWG × 2 conductors / H05RN-F; DA+ purple, DA− pink. Use the supplied drawing for lead length; no separate control-lead dimension is assigned here. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Digital-controller installation This DA option uses DALI, with the control cable identified as DA+ and DA−. Verify the supplied wiring and compatible controller/network; do not treat these terminals as the analog DIM or timer PROG interface. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-H-DA

  HVGC-650A-H-DA LED Driver MEAN WELL HVGC-650A-H-DA is a 649.6 W constant-power LED driver with 5600 mA rated current and a 46.4–116 V constant-current operating region. This IP67 Class I metal-case version provides dali control and output-current potentiometer and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-H-DA; HVGC-650 Suffix and configuration DALI control and output-current potentiometer. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 5600 mA Rated output power 649.6 W Constant-current voltage region 46.4–116 V Full-power current range 5600–7000 mA Maximum open-circuit voltage 120 V Catalog current-adjustment range 2800–7000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2800 mA / 116 V; 5600 mA / 116 V; 7000 mA / 92.8 V; 7000 mA / 46.4 V; 5600 mA / 58 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95% Temperature coefficient ±0.03%/°C over 0–55°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 118–136 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Digital dimming interface DALI technology controlled on the primary side; 16 groups and 64 addresses. Dimming first step 6% fixed at the first step when the controller sends a command. Local current adjustment The constant-current level is adjustable through the built-in Io ADJ potentiometer within the catalog range. Digital control wiring Connect the compatible bus to DA+ purple and DA− pink as shown in the dedicated mechanical drawing. These are digital-control conductors, not the analog DIM or timer PROG interface. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. SELV scope The HVGC-650 series cover identifies SELV only for H and U output ranges; this H model is within that stated range. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SJOW 17 AWG × 2 conductors / H05RN-F; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F; DA+ purple, DA− pink. Use the supplied drawing for lead length; no separate control-lead dimension is assigned here. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Digital-controller installation This DA option uses DALI, with the control cable identified as DA+ and DA−. Verify the supplied wiring and compatible controller/network; do not treat these terminals as the analog DIM or timer PROG interface. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-M-DA

  HVGC-650A-M-DA LED Driver MEAN WELL HVGC-650A-M-DA is a 651 W constant-power LED driver with 4200 mA rated current and a 62–155 V constant-current operating region. This IP67 Class I metal-case version provides dali control and output-current potentiometer and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-M-DA; HVGC-650 Suffix and configuration DALI control and output-current potentiometer. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 4200 mA Rated output power 651 W Constant-current voltage region 62–155 V Full-power current range 4200–5250 mA Maximum open-circuit voltage 160 V Catalog current-adjustment range 2100–5250 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2100 mA / 155 V; 4200 mA / 155 V; 5250 mA / 124 V; 5250 mA / 62 V; 4200 mA / 77.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95% Temperature coefficient ±0.03%/°C over 0–55°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 158–178 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Digital dimming interface DALI technology controlled on the primary side; 16 groups and 64 addresses. Dimming first step 6% fixed at the first step when the controller sends a command. Local current adjustment The constant-current level is adjustable through the built-in Io ADJ potentiometer within the catalog range. Digital control wiring Connect the compatible bus to DA+ purple and DA− pink as shown in the dedicated mechanical drawing. These are digital-control conductors, not the analog DIM or timer PROG interface. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SJOW 17 AWG × 2 conductors / H05RN-F; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F; DA+ purple, DA− pink. Use the supplied drawing for lead length; no separate control-lead dimension is assigned here. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Digital-controller installation This DA option uses DALI, with the control cable identified as DA+ and DA−. Verify the supplied wiring and compatible controller/network; do not treat these terminals as the analog DIM or timer PROG interface. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-L-DA

  HVGC-650A-L-DA LED Driver MEAN WELL HVGC-650A-L-DA is a 649.6 W constant-power LED driver with 2800 mA rated current and a 92.8–232 V constant-current operating region. This IP67 Class I metal-case version provides dali control and output-current potentiometer and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-L-DA; HVGC-650 Suffix and configuration DALI control and output-current potentiometer. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 2800 mA Rated output power 649.6 W Constant-current voltage region 92.8–232 V Full-power current range 2800–3500 mA Maximum open-circuit voltage 240 V Catalog current-adjustment range 1400–3500 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1400 mA / 232 V; 2800 mA / 232 V; 3500 mA / 185.6 V; 3500 mA / 92.8 V; 2800 mA / 116 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95% Temperature coefficient ±0.03%/°C over 0–55°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 240–259 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Digital dimming interface DALI technology controlled on the primary side; 16 groups and 64 addresses. Dimming first step 6% fixed at the first step when the controller sends a command. Local current adjustment The constant-current level is adjustable through the built-in Io ADJ potentiometer within the catalog range. Digital control wiring Connect the compatible bus to DA+ purple and DA− pink as shown in the dedicated mechanical drawing. These are digital-control conductors, not the analog DIM or timer PROG interface. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SJOW 17 AWG × 2 conductors / H05RN-F; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F; DA+ purple, DA− pink. Use the supplied drawing for lead length; no separate control-lead dimension is assigned here. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP67 with an adjustment function and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Digital-controller installation This DA option uses DALI, with the control cable identified as DA+ and DA−. Verify the supplied wiring and compatible controller/network; do not treat these terminals as the analog DIM or timer PROG interface. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-U-DX

  HVGC-650A-U-DX LED Driver MEAN WELL HVGC-650A-U-DX is a 649.6 W constant-power LED driver with 11200 mA rated current and a 24–58 V constant-current operating region. This IP67 Class I metal-case version provides customer-defined smart timer dimming and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-U-DX; HVGC-650 Suffix and configuration Customer-defined smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 11200 mA Rated output power 649.6 W Constant-current voltage region 24–58 V Full-power current range 11200–14000 mA Maximum open-circuit voltage 70 V Catalog current-adjustment range 5600–14000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 5600 mA / 58 V; 11200 mA / 58 V; 14000 mA / 46.4 V; 11200 mA / 29 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95.5% Temperature coefficient ±0.03%/°C over 0–55°C Lower-voltage source qualification The specification table gives 24–58 V. The I–V illustration labels one corner 23.2 V; these differ. Keep the specified 24 V lower limit unless MEAN WELL confirms a different approved operating point. Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 62–78 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface DX identifies the customer-requested timer profile, without a separate external programming/control cable in the cable specification. The catalog does not provide a separate DX mechanical drawing; confirm the supplied wiring drawing before installation. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. SELV scope The HVGC-650 series cover identifies SELV only for H and U output ranges; this U model is within that stated range. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting For the depicted AB/D2/DA versions, four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. DX is not separately drawn; confirm the supplied wiring drawing. Case-temperature measuring point For the depicted AB/D2/DA versions, the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. DX is not separately drawn; confirm the supplied wiring drawing. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. For the depicted AB/D2/DA versions, the drawing gives 300 ±20 mm. DX is not separately drawn; confirm the supplied wiring drawing. Output cable SJOW 17 AWG × 4 conductors / H05RN-F; red Vo+, black Vo−. For the depicted AB/D2/DA versions, the output lead drawing gives 300 ±20 mm. DX is not separately drawn; confirm the supplied wiring drawing. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Four-conductor output The U output uses two red positive and two black negative conductors for the same LED output; these are not independent channels. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-H-DX

  HVGC-650A-H-DX LED Driver MEAN WELL HVGC-650A-H-DX is a 649.6 W constant-power LED driver with 5600 mA rated current and a 46.4–116 V constant-current operating region. This IP67 Class I metal-case version provides customer-defined smart timer dimming and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-H-DX; HVGC-650 Suffix and configuration Customer-defined smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 5600 mA Rated output power 649.6 W Constant-current voltage region 46.4–116 V Full-power current range 5600–7000 mA Maximum open-circuit voltage 120 V Catalog current-adjustment range 2800–7000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2800 mA / 116 V; 5600 mA / 116 V; 7000 mA / 92.8 V; 7000 mA / 46.4 V; 5600 mA / 58 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95% Temperature coefficient ±0.03%/°C over 0–55°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 118–136 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface DX identifies the customer-requested timer profile, without a separate external programming/control cable in the cable specification. The catalog does not provide a separate DX mechanical drawing; confirm the supplied wiring drawing before installation. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. SELV scope The HVGC-650 series cover identifies SELV only for H and U output ranges; this H model is within that stated range. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting For the depicted AB/D2/DA versions, four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. DX is not separately drawn; confirm the supplied wiring drawing. Case-temperature measuring point For the depicted AB/D2/DA versions, the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. DX is not separately drawn; confirm the supplied wiring drawing. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. For the depicted AB/D2/DA versions, the drawing gives 300 ±20 mm. DX is not separately drawn; confirm the supplied wiring drawing. Output cable SJOW 17 AWG × 2 conductors / H05RN-F; red Vo+, black Vo−. For the depicted AB/D2/DA versions, the output lead drawing gives 300 ±20 mm. DX is not separately drawn; confirm the supplied wiring drawing. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-M-DX

  HVGC-650A-M-DX LED Driver MEAN WELL HVGC-650A-M-DX is a 651 W constant-power LED driver with 4200 mA rated current and a 62–155 V constant-current operating region. This IP67 Class I metal-case version provides customer-defined smart timer dimming and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-M-DX; HVGC-650 Suffix and configuration Customer-defined smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 4200 mA Rated output power 651 W Constant-current voltage region 62–155 V Full-power current range 4200–5250 mA Maximum open-circuit voltage 160 V Catalog current-adjustment range 2100–5250 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2100 mA / 155 V; 4200 mA / 155 V; 5250 mA / 124 V; 5250 mA / 62 V; 4200 mA / 77.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95% Temperature coefficient ±0.03%/°C over 0–55°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 158–178 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface DX identifies the customer-requested timer profile, without a separate external programming/control cable in the cable specification. The catalog does not provide a separate DX mechanical drawing; confirm the supplied wiring drawing before installation. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting For the depicted AB/D2/DA versions, four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. DX is not separately drawn; confirm the supplied wiring drawing. Case-temperature measuring point For the depicted AB/D2/DA versions, the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. DX is not separately drawn; confirm the supplied wiring drawing. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. For the depicted AB/D2/DA versions, the drawing gives 300 ±20 mm. DX is not separately drawn; confirm the supplied wiring drawing. Output cable SJOW 17 AWG × 2 conductors / H05RN-F; red Vo+, black Vo−. For the depicted AB/D2/DA versions, the output lead drawing gives 300 ±20 mm. DX is not separately drawn; confirm the supplied wiring drawing. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-L-DX

  HVGC-650A-L-DX LED Driver MEAN WELL HVGC-650A-L-DX is a 649.6 W constant-power LED driver with 2800 mA rated current and a 92.8–232 V constant-current operating region. This IP67 Class I metal-case version provides customer-defined smart timer dimming and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-L-DX; HVGC-650 Suffix and configuration Customer-defined smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 2800 mA Rated output power 649.6 W Constant-current voltage region 92.8–232 V Full-power current range 2800–3500 mA Maximum open-circuit voltage 240 V Catalog current-adjustment range 1400–3500 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1400 mA / 232 V; 2800 mA / 232 V; 3500 mA / 185.6 V; 3500 mA / 92.8 V; 2800 mA / 116 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95% Temperature coefficient ±0.03%/°C over 0–55°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 240–259 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface DX identifies the customer-requested timer profile, without a separate external programming/control cable in the cable specification. The catalog does not provide a separate DX mechanical drawing; confirm the supplied wiring drawing before installation. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting For the depicted AB/D2/DA versions, four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. DX is not separately drawn; confirm the supplied wiring drawing. Case-temperature measuring point For the depicted AB/D2/DA versions, the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. DX is not separately drawn; confirm the supplied wiring drawing. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. For the depicted AB/D2/DA versions, the drawing gives 300 ±20 mm. DX is not separately drawn; confirm the supplied wiring drawing. Output cable SJOW 17 AWG × 2 conductors / H05RN-F; red Vo+, black Vo−. For the depicted AB/D2/DA versions, the output lead drawing gives 300 ±20 mm. DX is not separately drawn; confirm the supplied wiring drawing. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-U-D2

  HVGC-650A-U-D2 LED Driver MEAN WELL HVGC-650A-U-D2 is a 649.6 W constant-power LED driver with 11200 mA rated current and a 24–58 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-U-D2; HVGC-650 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 11200 mA Rated output power 649.6 W Constant-current voltage region 24–58 V Full-power current range 11200–14000 mA Maximum open-circuit voltage 70 V Catalog current-adjustment range 5600–14000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 5600 mA / 58 V; 11200 mA / 58 V; 14000 mA / 46.4 V; 11200 mA / 29 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95.5% Temperature coefficient ±0.03%/°C over 0–55°C Lower-voltage source qualification The specification table gives 24–58 V. The I–V illustration labels one corner 23.2 V; these differ. Keep the specified 24 V lower limit unless MEAN WELL confirms a different approved operating point. Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 62–78 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. SELV scope The HVGC-650 series cover identifies SELV only for H and U output ranges; this U model is within that stated range. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SJOW 17 AWG × 4 conductors / H05RN-F; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Four-conductor output The U output uses two red positive and two black negative conductors for the same LED output; these are not independent channels. Control cable SJOW 17 AWG × 2 conductors / H05RN-F; PROG+ purple, PROG− pink. Use the supplied drawing for lead length; no separate control-lead dimension is assigned here. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-H-D2

  HVGC-650A-H-D2 LED Driver MEAN WELL HVGC-650A-H-D2 is a 649.6 W constant-power LED driver with 5600 mA rated current and a 46.4–116 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-H-D2; HVGC-650 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 5600 mA Rated output power 649.6 W Constant-current voltage region 46.4–116 V Full-power current range 5600–7000 mA Maximum open-circuit voltage 120 V Catalog current-adjustment range 2800–7000 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2800 mA / 116 V; 5600 mA / 116 V; 7000 mA / 92.8 V; 7000 mA / 46.4 V; 5600 mA / 58 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95% Temperature coefficient ±0.03%/°C over 0–55°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 118–136 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. SELV scope The HVGC-650 series cover identifies SELV only for H and U output ranges; this H model is within that stated range. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SJOW 17 AWG × 2 conductors / H05RN-F; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F; PROG+ purple, PROG− pink. Use the supplied drawing for lead length; no separate control-lead dimension is assigned here. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-M-D2

  HVGC-650A-M-D2 LED Driver MEAN WELL HVGC-650A-M-D2 is a 651 W constant-power LED driver with 4200 mA rated current and a 62–155 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-M-D2; HVGC-650 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 4200 mA Rated output power 651 W Constant-current voltage region 62–155 V Full-power current range 4200–5250 mA Maximum open-circuit voltage 160 V Catalog current-adjustment range 2100–5250 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 2100 mA / 155 V; 4200 mA / 155 V; 5250 mA / 124 V; 5250 mA / 62 V; 4200 mA / 77.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95% Temperature coefficient ±0.03%/°C over 0–55°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 158–178 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SJOW 17 AWG × 2 conductors / H05RN-F; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F; PROG+ purple, PROG− pink. Use the supplied drawing for lead length; no separate control-lead dimension is assigned here. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

•

  View options

  MEAN WELL HVGC-650 series: Constant Power LED Driver - HVGC-650A-L-D2

  HVGC-650A-L-D2 LED Driver MEAN WELL HVGC-650A-L-D2 is a 649.6 W constant-power LED driver with 2800 mA rated current and a 92.8–232 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming and a 12 V / 200 mA auxiliary output. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-650 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-650, PDF pages 57–66, revision 2026-02-09. Model selection Full model and series HVGC-650A-L-D2; HVGC-650 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity The A immediately after 650 identifies the auxiliary-output version. Nominal 12 V ±10%, 200 mA; ripple and noise 150 mVp-p. Keep this circuit separate from the LED output and control interface. Applications Harbor, LED high-bay, parking-lot, fishing-lamp, horticulture and stadium lighting. Subject to the final luminaire design. Output specifications Rated output current 2800 mA Rated output power 649.6 W Constant-current voltage region 92.8–232 V Full-power current range 2800–3500 mA Maximum open-circuit voltage 240 V Catalog current-adjustment range 1400–3500 mA. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1400 mA / 232 V; 2800 mA / 232 V; 3500 mA / 185.6 V; 3500 mA / 92.8 V; 2800 mA / 116 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 95% Temperature coefficient ±0.03%/°C over 0–55°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 2.1 A at 347 VAC; 1.5 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1250 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 80% load at 180 VAC, increasing to 100% at 200 VAC; 100% through 528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 240–259 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example qualification The D03 table lists 18:00 / 20:00 / 24:00 / 04:00 with 100% / 75% / 50% / 25%, but its illustration and explanatory text show a different 70% / 100% / 70% profile. Confirm the required programmed profile with MEAN WELL; neither inconsistent example is a promised preset. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +85°C; maximum case temperature +85°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 200 VAC, 100% load through +45°C, then 60% at +50°C; at 230 VAC, 100% through +50°C, then 60% at +55°C; above 277 VAC, 100% through +55°C, then 60% at +60°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +50°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +85°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 728.1K h minimum, Telcordia SR-332 (Bellcore); 60.2K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-2-13; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 4.2 kVAC; input/FG: 2.1 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety source qualification The safety row additionally prints “BS EN/EN60384”. Verify the applicable certificate with MEAN WELL; this text is not silently changed to a different standard. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 8 kV line-to-earth / 4 kV line-to-line. Mechanical and wiring Dimensions and enclosure 280 × 144 × 48.5 mm (L × W × H); case no. 228; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 253.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 126.6 mm from the right inner end line and 47 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SJOW 17 AWG × 2 conductors / H05RN-F; red Vo+, black Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 3.9 kg per unit; 4 pcs / 16.6 kg / 0.98 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F; PROG+ purple, PROG− pink. Use the supplied drawing for lead length; no separate control-lead dimension is assigned here. Auxiliary cable SJOW 17 AWG × 2 conductors / H05RN-F; AUX+ gray, AUX− black; 300 ±20 mm in the auxiliary-output drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Auxiliary-output identity The A suffix immediately after 650 identifies the auxiliary-output version. Its auxiliary output is 12 V at 200 mA, with AUX+ gray and AUX− black. Keep the auxiliary circuit separate from the LED power and control interfaces and within its stated rating. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $557.42

  View options

Show more products
