Rated power: 960W Input voltage: three-phase 340 ~ 550VAC (also two-phase operation),480 ~ 780VDC Output voltage: 48V Output current: 0 ~ 20A Size (mm):110X125.2X150 Product Features 1, 340 ~ 550VAC three-phase wide range AC input (two-phase operation). 2. Ultra-thin, width 63~110mm, mounting guide rail: TS-35/7.5 or TS-35/15. 3. Built-in active PFC function (TDR-480/960). 4. Built-in passive PFC function (TDR-240). 5, the efficiency of up to 94.5, natural air cooling heat dissipation. 6. Protection type: overload/overvoltage/overtemperature, DC output voltage is adjustable. 7. Through UL508/UL61010-1 industrial control equipment certification, parallel function, TDR-960 * 4 sets. 8. DC OK relay contact (TDR-480 optional),3-year warranty.

Read more less

Rated power: 960W Input voltage: three-phase 340 ~ 550VAC (also two-phase operation),480 ~ 780VDC Output voltage: 24V Output current: 0 ~ 40A Size (mm):110X125.2X150 Product Features 1, 340 ~ 550VAC three-phase wide range AC input (two-phase operation). 2. Ultra-thin, width 63~110mm, mounting guide rail: TS-35/7.5 or TS-35/15. 3. Built-in active PFC function (TDR-480/960). 4. Built-in passive PFC function (TDR-240). 5, the efficiency of up to 94.5, natural air cooling heat dissipation. 6. Protection type: overload/overvoltage/overtemperature, DC output voltage is adjustable. 7. Through UL508/UL61010-1 industrial control equipment certification, parallel function, TDR-960 * 4 sets. 8. DC OK relay contact (TDR-480 optional),3-year warranty.

Read more less

Rated power: 480W Input voltage: three-phase 340 ~ 550VAC (dual-phase operation),480 ~ 780VDC Output voltage: 48V Output current: 0 ~ 10A Size (mm):85.5X125.2X128.5 Product Features 1, 340 ~ 550VAC three-phase wide range AC input (two-phase operation). 2. Ultra-thin, width 63~110mm, mounting guide rail: TS-35/7.5 or TS-35/15. 3. Built-in active PFC function (TDR-480/960). 4. Built-in passive PFC function (TDR-240). 5, the efficiency of up to 94.5, natural air cooling heat dissipation. 6. Protection type: overload/overvoltage/overtemperature, DC output voltage is adjustable. 7. Through UL508/UL61010-1 industrial control equipment certification, parallel function, TDR-960 * 4 sets. 8. DC OK relay contact (TDR-480 optional),3-year warranty.

Read more less

Rated power: 480W Input voltage: three-phase 340 ~ 550VAC (dual-phase operation),480 ~ 780VDC Output voltage: 24V Output current: 0 ~ 20A Size (mm):85.5X125.2X128.5 Product Features 1, 340 ~ 550VAC three-phase wide range AC input (two-phase operation). 2. Ultra-thin, width 63~110mm, mounting guide rail: TS-35/7.5 or TS-35/15. 3. Built-in active PFC function (TDR-480/960). 4. Built-in passive PFC function (TDR-240). 5, the efficiency of up to 94.5, natural air cooling heat dissipation. 6. Protection type: overload/overvoltage/overtemperature, DC output voltage is adjustable. 7. Through UL508/UL61010-1 industrial control equipment certification, parallel function, TDR-960 * 4 sets. 8. DC OK relay contact (TDR-480 optional),3-year warranty.

Read more less

Rated power: 240W Input voltage: three-phase 340 ~ 550VAC (two-phase operation when connecting L1,L3,FG or L2,L3,FG) or 480 ~ 780VDC Output voltage: 48V Output current: 0 ~ 5A Size (mm):63X125.2X113.5 Product Features 1, 340 ~ 550VAC three-phase wide range AC input (two-phase operation). 2. Ultra-thin, width 63~110mm, mounting guide rail: TS-35/7.5 or TS-35/15. 3. Built-in active PFC function (TDR-480/960). 4. Built-in passive PFC function (TDR-240). 5, the efficiency of up to 94.5, natural air cooling heat dissipation. 6. Protection type: overload/overvoltage/overtemperature, DC output voltage is adjustable. 7. Through UL508/UL61010-1 industrial control equipment certification, parallel function, TDR-960 * 4 sets. 8. DC OK relay contact (TDR-480 optional),3-year warranty.

Read more less

Rated power: 240W Input voltage: three-phase 340 ~ 550VAC (two-phase operation when connecting L1,L3,FG or L2,L3,FG) or 480 ~ 780VDC Output voltage: 24V Output current: 0 ~ 10A Size (mm):63X125.2X113.5 Product Features 1, 340 ~ 550VAC three-phase wide range AC input (two-phase operation). 2. Ultra-thin, width 63~110mm, mounting guide rail: TS-35/7.5 or TS-35/15. 3. Built-in active PFC function (TDR-480/960). 4. Built-in passive PFC function (TDR-240). 5, the efficiency of up to 94.5, natural air cooling heat dissipation. 6. Protection type: overload/overvoltage/overtemperature, DC output voltage is adjustable. 7. Through UL508/UL61010-1 industrial control equipment certification, parallel function, TDR-960 * 4 sets. 8. DC OK relay contact (TDR-480 optional),3-year warranty.

Read more less

Rated power: 480W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 48V Output current: 0 ~ 10A Size (mm):85.5X125.2X128.5 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 480W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 24V Output current: 0 ~ 20A Size (mm):85.5X125.2X128.5 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 240W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 48V Output current: 0 ~ 5A Size (mm):63X125.2X113.5 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 240W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 24V Output current: 0 ~ 10A Size (mm):63X125.2X113.5 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 120W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 48V Output current: 0 ~ 2.5A Size (mm):40X125.2X113.5 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 120W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 24V Output current: 0 ~ 5A Size (mm):40X125.2X113.5 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 120W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 12V Output current: 0 ~ 10A Size (mm):40X125.2X113.5 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 60W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 48V Output current: 0 ~ 1.25A Size (mm):32X125.2X102 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 60W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 24V Output current: 0 ~ 2.5A Size (mm):32X125.2X102 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 60W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 12V Output current: 0 ~ 5A Size (mm):32X125.2X102 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less

Rated power: 50W Input voltage: 180 ~ 550VAC or 254 ~ 780VDC Output voltage: 5V Output current: 0 ~ 10A Size (mm):32X125.2X102 Product Features 1. Single and dual phase wide range input 180 ~ 550VAC. 2. Mounting guide rail: TS-35/7.5 or TS-35/15. 3. With active PFC function (WDR-240/480), built-in constant current limiting circuit. 4. Natural air cooling and heat dissipation. 5. Protection type: short circuit/overload/overvoltage/overtemperature. 6. DC output voltage is adjustable. 7. EN61000-6-2(EN50082-2) industrial tolerance level, DC OK relay is activated. 8. Overvoltage class III (WDR-60),3 years warranty.

Read more less
