MEAN WELL DKE10W8 series: voltage regulator converter - DKE10W8-15
Series: Double group output Rated power: 10W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 473mA Output voltage: ± 15V Output current: ± 0 ~ 333mA Efficiency (TYP.):86% Capacitive load (max):* 100μF Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1. The DIP2 "x1" package has industry standard pins. 2.8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 3. Comply with BS EN/EN55032 Radiation Class A, no additional parts are required, and the efficiency is as high as 88%. 4. Protection function: short circuit (continuous)/overload/overvoltage/undervoltage lockout, 3KVdc input/output isolation, remote on/off control (optional),3 years warranty
$36.86
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15A-05
Output DC voltage: ± 5V Output current: ± 150 ~ ± 1500mA Rated power: 15W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):81% Input DC current full load: 1700mA, no load: 40mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15A-12
Output DC voltage: ± 12V Output current: ± 62.5 ~ ± 625mA Rated power: 15W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):82% Input DC current full load: 1700mA, no load: 40mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15A-15
Output DC voltage: ± 15V Output current: ± 50 ~ ± 500mA Rated power: 15W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):82% Input DC current full load: 1700mA, no load: 40mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15A-24
Output DC voltage: ± 24V Output current: ± 31.3 ~ ± 313mA Rated power: 15W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):82% Input DC current full load: 1700mA, no load: 40mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15B-05
Output DC voltage: ± 5V Output current: ± 150 ~ ± 1500mA Rated power: 15W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):83% Input DC current full load: 800mA, no load: 20mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15B-12
Output DC voltage: ± 12V Output current: ± 62.5 ~ ± 625mA Rated power: 15W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):83% Input DC current full load: 800mA, no load: 20mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15B-15
Output DC voltage: ± 15V Output current: ± 50 ~ ± 500mA Rated power: 15W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):83% Input DC current full load: 800mA, no load: 20mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15B-24
Output DC voltage: ± 24V Output current: ± 31.3 ~ ± 313mA Rated power: 15W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):84% Input DC current full load: 800mA, no load: 20mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15C-05
Output DC voltage: ± 5V Output current: ± 150 ~ ± 1500mA Rated power: 15W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):79% Input DC current full load: 400mA, no load: 10mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15C-12
Output DC voltage: ± 12V Output current: ± 62.5 ~ ± 625mA Rated power: 15W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):82% Input DC current full load: 400mA, no load: 10mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15C-15
Output DC voltage: ± 15V Output current: ± 50 ~ ± 500mA Rated power: 15W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):82% Input DC current full load: 400mA, no load: 10mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKE15 Series: Regulated Voltage Converter - DKE15C-24
Output DC voltage: ± 24V Output current: ± 31.3 ~ ± 313mA Rated power: 15W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):85% Input DC current full load: 400mA, no load: 10mA Size (mm):50.8X50.8X11 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$56.14
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10A-05
Series: Double group output Rated power: 10W Input voltage (range):12V(9~18V) Input current no-load: 40mA, full load: 985mA Output voltage: ± 5V Output current: ± 0 ~ 1000mA Efficiency (TYP.):85% Capacitive load (max):* 1000μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10A-12
Series: Double group output Rated power: 10W Input voltage (range):12V(9~18V) Input current no-load: 40mA, full load: 957mA Output voltage: ± 12V Output current: ± 0 ~ 416mA Efficiency (TYP.):87% Capacitive load (max):* 440μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10A-15
Series: Double group output Rated power: 10W Input voltage (range):12V(9~18V) Input current no-load: 40mA, full load: 957mA Output voltage: ± 15V Output current: ± 0 ~ 333mA Efficiency (TYP.):89% Capacitive load (max):* 330μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10B-05
Series: Double group output Rated power: 10W Input voltage (range):24V(18~36V) Input current no-load: 25mA, full load: 490mA Output voltage: ± 5V Output current: ± 0 ~ 1000mA Efficiency (TYP.):85% Capacitive load (max):* 1000μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10B-12
Series: Double group output Rated power: 10W Input voltage (range):24V(18~36V) Input current no-load: 25mA, full load: 478mA Output voltage: ± 12V Output current: ± 0 ~ 416mA Efficiency (TYP.):88% Capacitive load (max):* 440μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10B-15
Series: Double group output Rated power: 10W Input voltage (range):24V(18~36V) Input current no-load: 25mA, full load: 478mA Output voltage: ± 15V Output current: ± 0 ~ 333mA Efficiency (TYP.):90% Capacitive load (max):* 330μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10C-05
Series: Double group output Rated power: 10W Input voltage (range):48V(36~75V) Input current no-load: 15mA, full load: 246mA Output voltage: ± 5V Output current: ± 0 ~ 1000mA Efficiency (TYP.):85% Capacitive load (max):* 1000μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10C-12
Series: Double group output Rated power: 10W Input voltage (range):48V(36~75V) Input current no-load: 15mA, full load: 239mA Output voltage: ± 12V Output current: ± 0 ~ 416mA Efficiency (TYP.):86% Capacitive load (max):* 440μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10C-15
Series: Double group output Rated power: 10W Input voltage (range):48V(36~75V) Input current no-load: 15mA, full load: 239mA Output voltage: ± 15V Output current: ± 0 ~ 333mA Efficiency (TYP.):89% Capacitive load (max):* 330μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10E-05
Series: Double group output Rated power: 10W Input voltage (range):5V(4.7~9V) Input current no-load: 40mA, full load: 2353mA Output voltage: ± 5V Output current: ± 0 ~ 1000mA Efficiency (TYP.):85% Capacitive load (max):* 1000μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
-
MEAN WELL DKM10 Series: Regulator Converter - DKM10E-12
Series: Double group output Rated power: 10W Input voltage (range):5V(4.7~9V) Input current no-load: 40mA, full load: 2295mA Output voltage: ± 12V Output current: ± 0 ~ 416mA Efficiency (TYP.):87% Capacitive load (max):* 440μF Size (mm):25.4X25.4X10.2 Click to download Airtac product catalog Product Features 1. The DIP 1 "X1" package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 90%. 4. Protection: short circuit (continuous)/overload/overvoltage/undervoltage input, 1.5KVDC input/output isolation, remote on/off, fine adjustment output (± 10%),3-year warranty.
$42.43
You have seen 456 out of 8679 products
