MEAN WELL DKA20W8 series: voltage regulator converter - DKA20W8-15
Series: Double group output Rated power: 20W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 20mA, full load: 947mA Output voltage: ± 15V Output current: ± 0 ~ 666mA Efficiency (TYP.):88% Capacitive load (max):* 100μF Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1. The DIP2 "x1" package has industry standard pins. 2.8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 3. Comply with BS EN/EN55032 Radiation Class A, no additional parts are required, and the efficiency is as high as 89%. 4. Protection function: short circuit (continuous)/overload/overvoltage/undervoltage lockout, 3KVdc input/output isolation, remote on/off control, 3 years warranty
$52.29
-
MEAN WELL DKA30 Series: Dual Output Converter - DKA30A-05
Output DC voltage: ± 5V Output current: ± 250 ~ ± 2500mA Rated power: 25W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):80% Input DC current full load: 3.2A, no load: 40mA Size (mm):50.8X50.8X21 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, built-in electromagnetic interference filter, remote on/off, corrected output (± 10%). 3. Protection type: short circuit/overload, natural cooling, six-sided protective metal shell, epoxy resin potting, 100% full load aging. 4. Certification: FCC/EAC/CE/UKCA,2-year warranty.
$73.71
-
MEAN WELL DKA30 Series: Dual Output Converter - DKA30A-12
Output DC voltage: ± 12V Output current: ± 125 ~ ± 1250mA Rated power: 30W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):80% Input DC current full load: 3.2A, no load: 40mA Size (mm):50.8X50.8X21 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, built-in electromagnetic interference filter, remote on/off, corrected output (± 10%). 3. Protection type: short circuit/overload, natural cooling, six-sided protective metal shell, epoxy resin potting, 100% full load aging. 4. Certification: FCC/EAC/CE/UKCA,2-year warranty.
$73.71
-
MEAN WELL DKA30 Series: Dual Output Converter - DKA30A-15
Output DC voltage: ± 15V Output current: ± 100 ~ ± 1000mA Rated power: 30W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):80% Input DC current full load: 3.2A, no load: 40mA Size (mm):50.8X50.8X21 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, built-in electromagnetic interference filter, remote on/off, corrected output (± 10%). 3. Protection type: short circuit/overload, natural cooling, six-sided protective metal shell, epoxy resin potting, 100% full load aging. 4. Certification: FCC/EAC/CE/UKCA,2-year warranty.
$73.71
-
MEAN WELL DKA30 Series: Dual Output Converter - DKA30B-05
Output DC voltage: ± 5V Output current: ± 250 ~ ± 2500mA Rated power: 25W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):80% Input DC current full load: 1.5A, no load: 20mA Size (mm):50.8X50.8X21 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, built-in electromagnetic interference filter, remote on/off, corrected output (± 10%). 3. Protection type: short circuit/overload, natural cooling, six-sided protective metal shell, epoxy resin potting, 100% full load aging. 4. Certification: FCC/EAC/CE/UKCA,2-year warranty.
$73.71
-
MEAN WELL DKA30 Series: Dual Output Converter - DKA30B-12
Output DC voltage: ± 12V Output current: ± 125 ~ ± 1250mA Rated power: 30W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):83% Input DC current full load: 1.5A, no load: 20mA Size (mm):50.8X50.8X21 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, built-in electromagnetic interference filter, remote on/off, corrected output (± 10%). 3. Protection type: short circuit/overload, natural cooling, six-sided protective metal shell, epoxy resin potting, 100% full load aging. 4. Certification: FCC/EAC/CE/UKCA,2-year warranty.
$73.71
-
MEAN WELL DKA30 Series: Dual Output Converter - DKA30B-15
Output DC voltage: ± 15V Output current: ± 100 ~ ± 1000mA Rated power: 30W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):83% Input DC current full load: 1.5A, no load: 20mA Size (mm):50.8X50.8X21 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, built-in electromagnetic interference filter, remote on/off, corrected output (± 10%). 3. Protection type: short circuit/overload, natural cooling, six-sided protective metal shell, epoxy resin potting, 100% full load aging. 4. Certification: FCC/EAC/CE/UKCA,2-year warranty.
$73.71
-
MEAN WELL DKA30 Series: Dual Output Converter - DKA30C-05
Output DC voltage: ± 5V Output current: ± 250 ~ ± 2500mA Rated power: 25W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):80% Input DC current full load: 0.77A, no load: 10mA Size (mm):50.8X50.8X21 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, built-in electromagnetic interference filter, remote on/off, corrected output (± 10%). 3. Protection type: short circuit/overload, natural cooling, six-sided protective metal shell, epoxy resin potting, 100% full load aging. 4. Certification: FCC/EAC/CE/UKCA,2-year warranty.
$73.71
-
MEAN WELL DKA30 Series: Dual Output Converter - DKA30C-12
Output DC voltage: ± 12V Output current: ± 125 ~ ± 1250mA Rated power: 30W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):81% Input DC current full load: 0.77A, no load: 10mA Size (mm):50.8X50.8X21 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, built-in electromagnetic interference filter, remote on/off, corrected output (± 10%). 3. Protection type: short circuit/overload, natural cooling, six-sided protective metal shell, epoxy resin potting, 100% full load aging. 4. Certification: FCC/EAC/CE/UKCA,2-year warranty.
$73.71
-
MEAN WELL DKA30 Series: Dual Output Converter - DKA30C-15
Output DC voltage: ± 15V Output current: ± 100 ~ ± 1000mA Rated power: 30W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):81% Input DC current full load: 0.77A, no load: 10mA Size (mm):50.8X50.8X21 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, built-in electromagnetic interference filter, remote on/off, corrected output (± 10%). 3. Protection type: short circuit/overload, natural cooling, six-sided protective metal shell, epoxy resin potting, 100% full load aging. 4. Certification: FCC/EAC/CE/UKCA,2-year warranty.
$73.71
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10A-05
Output DC voltage: ± 5V Output current: ± 100 ~ ± 1000mA Rated power: 10W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):78% Input DC current full load: 1100mA, no load: 30mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10A-12
Output DC voltage: ± 12V Output current: ± 42 ~ ± 420mA Rated power: 10W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):80% Input DC current full load: 1100mA, no load: 30mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10A-15
Output DC voltage: ± 15V Output current: ± 33.3 ~ ± 333mA Rated power: 10W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):80% Input DC current full load: 1100mA, no load: 30mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10A-24
Output DC voltage: ± 24V Output current: ± 21 ~ ± 210mA Rated power: 10W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):82% Input DC current full load: 1100mA, no load: 30mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10B-05
Output DC voltage: ± 5V Output current: ± 100 ~ ± 1000mA Rated power: 10W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):81% Input DC current full load: 530mA, no load: 16mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10B-12
Output DC voltage: ± 12V Output current: ± 42 ~ ± 420mA Rated power: 10W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):80% Input DC current full load: 530mA, no load: 16mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10B-15
Output DC voltage: ± 15V Output current: ± 33.3 ~ ± 333mA Rated power: 10W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):80% Input DC current full load: 530mA, no load: 16mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10B-24
Output DC voltage: ± 24V Output current: ± 21 ~ ± 210mA Rated power: 10W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):81% Input DC current full load: 530mA, no load: 16mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10C-05
Output DC voltage: ± 5V Output current: ± 100 ~ ± 1000mA Rated power: 10W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):82% Input DC current full load: 270mA, no load: 8mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10C-12
Output DC voltage: ± 12V Output current: ± 42 ~ ± 420mA Rated power: 10W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):83% Input DC current full load: 270mA, no load: 8mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10C-15
Output DC voltage: ± 15V Output current: ± 33.3 ~ ± 333mA Rated power: 10W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):82% Input DC current full load: 270mA, no load: 8mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10 Series: Regulated Voltage Converter - DKE10C-24
Output DC voltage: ± 24V Output current: ± 21 ~ ± 210mA Rated power: 10W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):85% Input DC current full load: 270mA, no load: 8mA Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$54.00
-
MEAN WELL DKE10W8 series: voltage regulator converter - DKE10W8-05
Series: Double group output Rated power: 10W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 484mA Output voltage: ± 5V Output current: ± 0 ~ 1000mA Efficiency (TYP.):85% Capacitive load (max):* 330μF Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1. The DIP2 "x1" package has industry standard pins. 2.8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 3. Comply with BS EN/EN55032 Radiation Class A, no additional parts are required, and the efficiency is as high as 88%. 4. Protection function: short circuit (continuous)/overload/overvoltage/undervoltage lockout, 3KVdc input/output isolation, remote on/off control (optional),3 years warranty
$36.86
-
MEAN WELL DKE10W8 series: voltage regulator converter - DKE10W8-12
Series: Double group output Rated power: 10W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 10mA, full load: 478mA Output voltage: ± 12V Output current: ± 0 ~ 417mA Efficiency (TYP.):87% Capacitive load (max):* 150μF Size (mm):50.8X25.4X11.2 Click to download Airtac product catalog Product Features 1. The DIP2 "x1" package has industry standard pins. 2.8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 3. Comply with BS EN/EN55032 Radiation Class A, no additional parts are required, and the efficiency is as high as 88%. 4. Protection function: short circuit (continuous)/overload/overvoltage/undervoltage lockout, 3KVdc input/output isolation, remote on/off control (optional),3 years warranty
$36.86
