  MEAN WELL MPM-45 series: PCB Mount Medical AC/DC Power Supply - MPM-45-24

  MEAN WELL MPM-45-24 is a pcb mount medical AC/DC power supply with 24 V output, 1.88 A rated current and 45.1 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-45 Datasheet (PDF) The MPM-45 section is on PDF pages 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-45-24 Series MPM-45 medical AC/DC power supply. Output code 24 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. This version uses the specified mounting style and has the model-specific vibration rating stated below. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 24 V. Rated current 1.88 A. Rated cooling condition Natural convection; no minimum load required. Catalogue-rated output power 45.1 W. Peak current and power 2.1 A and 50.4 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC or 113–370 V DC. AC frequency 47–63 Hz. Efficiency, typical 92.5% at the default specified test conditions. AC current, typical 1.2 A at 115 V AC; 0.6 A at 230 V AC. Cold-start inrush, typical 30 A at 115 V AC; 60 A at 230 V AC. Setup / rise time 1000 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 50 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.1 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–135% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 25.2–32.4 V; output shutdown, re-power to recover. Overtemperature Output shutdown, re-power to recover. Touch current Less than 100 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −30 to +80°C; subject to the derating curve. Temperature derating Horizontal mounting, this output-voltage version: 100% load from −30 to +60°C, then along the plotted segments to 75% at +70°C and 40% at +80°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 4000 m / overvoltage category II. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 87 × 52 × 29.5 mm. Case reference IRM60. Drawing tolerance ±1 mm. PCB power pins Bottom view: AC/N above AC/L at the input side; −Vo above +Vo at the output side. The figure orientation matters. Pin and layout dimensions AC/L and AC/N pins are Ø1 mm; +Vo and −Vo pins are Ø2 mm. Protrusion is 3.5 ±1 mm; the bottom view marks 76 mm between pin columns, 6.75 mm between input pins and 5.5 mm between output pins. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 185 g, converted from the explicit 0.185 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 4590.4 K hours minimum, Telcordia SR-332 (Bellcore); 563.4 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-45-SPEC, 2024-10-30; combined catalogue pages 21–24. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $49.29

  View options

•

  View options

  MEAN WELL MPM-45 series: PCB Mount Medical AC/DC Power Supply - MPM-45-15

  MEAN WELL MPM-45-15 is a pcb mount medical AC/DC power supply with 15 V output, 3 A rated current and 45 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-45 Datasheet (PDF) The MPM-45 section is on PDF pages 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-45-15 Series MPM-45 medical AC/DC power supply. Output code 15 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. This version uses the specified mounting style and has the model-specific vibration rating stated below. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 15 V. Rated current 3 A. Rated cooling condition Natural convection; no minimum load required. Catalogue-rated output power 45 W. Peak current and power 3.3 A and 49.5 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 120 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC or 113–370 V DC. AC frequency 47–63 Hz. Efficiency, typical 92.5% at the default specified test conditions. AC current, typical 1.2 A at 115 V AC; 0.6 A at 230 V AC. Cold-start inrush, typical 30 A at 115 V AC; 60 A at 230 V AC. Setup / rise time 1000 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 50 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.1 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–135% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 15.8–20.3 V; output shutdown, re-power to recover. Overtemperature Output shutdown, re-power to recover. Touch current Less than 100 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −30 to +80°C; subject to the derating curve. Temperature derating Horizontal mounting, this output-voltage version: 100% load from −30 to +60°C, then along the plotted segments to 75% at +70°C and 40% at +80°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 4000 m / overvoltage category II. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 87 × 52 × 29.5 mm. Case reference IRM60. Drawing tolerance ±1 mm. PCB power pins Bottom view: AC/N above AC/L at the input side; −Vo above +Vo at the output side. The figure orientation matters. Pin and layout dimensions AC/L and AC/N pins are Ø1 mm; +Vo and −Vo pins are Ø2 mm. Protrusion is 3.5 ±1 mm; the bottom view marks 76 mm between pin columns, 6.75 mm between input pins and 5.5 mm between output pins. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 185 g, converted from the explicit 0.185 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 4590.4 K hours minimum, Telcordia SR-332 (Bellcore); 563.4 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-45-SPEC, 2024-10-30; combined catalogue pages 21–24. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $50.76

  View options

•

  View options

  MEAN WELL MPM-45 series: PCB Mount Medical AC/DC Power Supply - MPM-45-12

  MEAN WELL MPM-45-12 is a pcb mount medical AC/DC power supply with 12 V output, 3.75 A rated current and 45 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-45 Datasheet (PDF) The MPM-45 section is on PDF pages 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-45-12 Series MPM-45 medical AC/DC power supply. Output code 12 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. This version uses the specified mounting style and has the model-specific vibration rating stated below. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 12 V. Rated current 3.75 A. Rated cooling condition Natural convection; no minimum load required. Catalogue-rated output power 45 W. Peak current and power 4.13 A and 49.5 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 120 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC or 113–370 V DC. AC frequency 47–63 Hz. Efficiency, typical 91.5% at the default specified test conditions. AC current, typical 1.2 A at 115 V AC; 0.6 A at 230 V AC. Cold-start inrush, typical 30 A at 115 V AC; 60 A at 230 V AC. Setup / rise time 1000 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 50 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.1 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–135% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 12.6–16.2 V; output shutdown, re-power to recover. Overtemperature Output shutdown, re-power to recover. Touch current Less than 100 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −30 to +80°C; subject to the derating curve. Temperature derating Horizontal mounting, this output-voltage version: 100% load from −30 to +60°C, then along the plotted segments to 75% at +70°C and 40% at +80°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 4000 m / overvoltage category II. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 87 × 52 × 29.5 mm. Case reference IRM60. Drawing tolerance ±1 mm. PCB power pins Bottom view: AC/N above AC/L at the input side; −Vo above +Vo at the output side. The figure orientation matters. Pin and layout dimensions AC/L and AC/N pins are Ø1 mm; +Vo and −Vo pins are Ø2 mm. Protrusion is 3.5 ±1 mm; the bottom view marks 76 mm between pin columns, 6.75 mm between input pins and 5.5 mm between output pins. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 185 g, converted from the explicit 0.185 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 4590.4 K hours minimum, Telcordia SR-332 (Bellcore); 563.4 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-45-SPEC, 2024-10-30; combined catalogue pages 21–24. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $45.84

  View options

•

  View options

  MEAN WELL MPM-45 series: PCB Mount Medical AC/DC Power Supply - MPM-45-5

  MEAN WELL MPM-45-5 is a pcb mount medical AC/DC power supply with 5 V output, 8 A rated current and 40 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-45 Datasheet (PDF) The MPM-45 section is on PDF pages 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-45-5 Series MPM-45 medical AC/DC power supply. Output code 5 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. This version uses the specified mounting style and has the model-specific vibration rating stated below. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 5 V. Rated current 8 A. Rated cooling condition Natural convection; no minimum load required. Catalogue-rated output power 40 W. Peak current and power 8.8 A and 44 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC or 113–370 V DC. AC frequency 47–63 Hz. Efficiency, typical 88% at the default specified test conditions. AC current, typical 1.2 A at 115 V AC; 0.6 A at 230 V AC. Cold-start inrush, typical 30 A at 115 V AC; 60 A at 230 V AC. Setup / rise time 1000 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 50 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.1 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–135% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 5.3–7.2 V; output shutdown, re-power to recover. Overtemperature Output shutdown, re-power to recover. Touch current Less than 100 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −30 to +80°C; subject to the derating curve. Temperature derating Horizontal mounting, 5 V version: 100% load from −30 to +55°C, then along the plotted segments to 75% at +70°C and 40% at +80°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 4000 m / overvoltage category II. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 87 × 52 × 29.5 mm. Case reference IRM60. Drawing tolerance ±1 mm. PCB power pins Bottom view: AC/N above AC/L at the input side; −Vo above +Vo at the output side. The figure orientation matters. Pin and layout dimensions AC/L and AC/N pins are Ø1 mm; +Vo and −Vo pins are Ø2 mm. Protrusion is 3.5 ±1 mm; the bottom view marks 76 mm between pin columns, 6.75 mm between input pins and 5.5 mm between output pins. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 185 g, converted from the explicit 0.185 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 4590.4 K hours minimum, Telcordia SR-332 (Bellcore); 563.4 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-45-SPEC, 2024-10-30; combined catalogue pages 21–24. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $45.84

  View options

•

  View options

  MEAN WELL MPM-30 series: Screw Terminal Medical AC/DC Power Supply - MPM-30-48ST

  MEAN WELL MPM-30-48ST is an encapsulated screw terminal medical AC/DC power supply with 48 V output, 0.63 A rated current and 30.2 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-48ST Series MPM-30 medical encapsulated AC/DC power supply. Output code 48 V nominal DC output. Mounting suffix ST: screw terminal style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 48 V. Rated current 0.63 A. Current range 0–0.63 A; no minimum load required. Catalogue-rated output power 30.2 W. Peak current and power 0.73 A and 35 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 91% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 50.4–64 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 3000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 5 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 91 × 39.5 × 28.5 mm. Case reference IRM30. Drawing tolerance ±1 mm. Screw terminals Top view: input AC/N and AC/L at one end; output −V and +V at the opposite end. Mounting holes Four Ø3.4 mm holes; the drawing marks 80 × 23 mm between the mounting-hole positions. Terminal drawing dimension The output-terminal pitch is marked 5 mm. Follow the full mechanical drawing for clearance. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 120 g, converted from the explicit 0.12 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $46.82

  View options

•

  View options

  MEAN WELL MPM-30 series: Screw Terminal Medical AC/DC Power Supply - MPM-30-24ST

  MEAN WELL MPM-30-24ST is an encapsulated screw terminal medical AC/DC power supply with 24 V output, 1.3 A rated current and 31.2 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-24ST Series MPM-30 medical encapsulated AC/DC power supply. Output code 24 V nominal DC output. Mounting suffix ST: screw terminal style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 24 V. Rated current 1.3 A. Current range 0–1.3 A; no minimum load required. Catalogue-rated output power 31.2 W. Peak current and power 1.5 A and 36 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 90% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 25.2–32.4 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 3000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 5 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 91 × 39.5 × 28.5 mm. Case reference IRM30. Drawing tolerance ±1 mm. Screw terminals Top view: input AC/N and AC/L at one end; output −V and +V at the opposite end. Mounting holes Four Ø3.4 mm holes; the drawing marks 80 × 23 mm between the mounting-hole positions. Terminal drawing dimension The output-terminal pitch is marked 5 mm. Follow the full mechanical drawing for clearance. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 120 g, converted from the explicit 0.12 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $42.39

  View options

•

  View options

  MEAN WELL MPM-30 series: Screw Terminal Medical AC/DC Power Supply - MPM-30-15ST

  MEAN WELL MPM-30-15ST is an encapsulated screw terminal medical AC/DC power supply with 15 V output, 2 A rated current and 30 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-15ST Series MPM-30 medical encapsulated AC/DC power supply. Output code 15 V nominal DC output. Mounting suffix ST: screw terminal style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 15 V. Rated current 2 A. Current range 0–2 A; no minimum load required. Catalogue-rated output power 30 W. Peak current and power 2.3 A and 34.5 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 120 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 89% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 15.8–20.3 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 3000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 5 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 91 × 39.5 × 28.5 mm. Case reference IRM30. Drawing tolerance ±1 mm. Screw terminals Top view: input AC/N and AC/L at one end; output −V and +V at the opposite end. Mounting holes Four Ø3.4 mm holes; the drawing marks 80 × 23 mm between the mounting-hole positions. Terminal drawing dimension The output-terminal pitch is marked 5 mm. Follow the full mechanical drawing for clearance. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 120 g, converted from the explicit 0.12 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $46.82

  View options

•

  View options

  MEAN WELL MPM-30 series: Screw Terminal Medical AC/DC Power Supply - MPM-30-12ST

  MEAN WELL MPM-30-12ST is an encapsulated screw terminal medical AC/DC power supply with 12 V output, 2.5 A rated current and 30 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-12ST Series MPM-30 medical encapsulated AC/DC power supply. Output code 12 V nominal DC output. Mounting suffix ST: screw terminal style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 12 V. Rated current 2.5 A. Current range 0–2.5 A; no minimum load required. Catalogue-rated output power 30 W. Peak current and power 2.9 A and 34.8 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 120 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 90% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 12.6–16.2 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 3000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 5 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 91 × 39.5 × 28.5 mm. Case reference IRM30. Drawing tolerance ±1 mm. Screw terminals Top view: input AC/N and AC/L at one end; output −V and +V at the opposite end. Mounting holes Four Ø3.4 mm holes; the drawing marks 80 × 23 mm between the mounting-hole positions. Terminal drawing dimension The output-terminal pitch is marked 5 mm. Follow the full mechanical drawing for clearance. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 120 g, converted from the explicit 0.12 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $42.39

  View options

•

  View options

  MEAN WELL MPM-30 series: Screw Terminal Medical AC/DC Power Supply - MPM-30-5ST

  MEAN WELL MPM-30-5ST is an encapsulated screw terminal medical AC/DC power supply with 5 V output, 6 A rated current and 30 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-5ST Series MPM-30 medical encapsulated AC/DC power supply. Output code 5 V nominal DC output. Mounting suffix ST: screw terminal style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 5 V. Rated current 6 A. Current range 0–6 A; no minimum load required. Catalogue-rated output power 30 W. Peak current and power 6.9 A and 34.5 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 86.5% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 5.3–6.8 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 3000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 5 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 91 × 39.5 × 28.5 mm. Case reference IRM30. Drawing tolerance ±1 mm. Screw terminals Top view: input AC/N and AC/L at one end; output −V and +V at the opposite end. Mounting holes Four Ø3.4 mm holes; the drawing marks 80 × 23 mm between the mounting-hole positions. Terminal drawing dimension The output-terminal pitch is marked 5 mm. Follow the full mechanical drawing for clearance. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 120 g, converted from the explicit 0.12 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $45.34

  View options

•

  View options

  MEAN WELL MPM-30 series: Screw Terminal Medical AC/DC Power Supply - MPM-30-3.3ST

  MEAN WELL MPM-30-3.3ST is an encapsulated screw terminal medical AC/DC power supply with 3.3 V output, 6 A rated current and 19.8 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-3.3ST Series MPM-30 medical encapsulated AC/DC power supply. Output code 3.3 V nominal DC output. Mounting suffix ST: screw terminal style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 3.3 V. Rated current 6 A. Current range 0–6 A; no minimum load required. Catalogue-rated output power 19.8 W. Peak current and power 7.8 A and 25.7 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 82.5% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 3.5–4.5 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 3000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 5 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 91 × 39.5 × 28.5 mm. Case reference IRM30. Drawing tolerance ±1 mm. Screw terminals Top view: input AC/N and AC/L at one end; output −V and +V at the opposite end. Mounting holes Four Ø3.4 mm holes; the drawing marks 80 × 23 mm between the mounting-hole positions. Terminal drawing dimension The output-terminal pitch is marked 5 mm. Follow the full mechanical drawing for clearance. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 120 g, converted from the explicit 0.12 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $46.82

  View options

•

  View options

  MEAN WELL MPM-30 series: PCB Mount Medical AC/DC Power Supply - MPM-30-48

  MEAN WELL MPM-30-48 is an encapsulated pcb mount medical AC/DC power supply with 48 V output, 0.63 A rated current and 30.2 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-48 Series MPM-30 medical encapsulated AC/DC power supply. Output code 48 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 48 V. Rated current 0.63 A. Current range 0–0.63 A; no minimum load required. Catalogue-rated output power 30.2 W. Peak current and power 0.73 A and 35 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 91% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 50.4–64 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 5000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 69.5 × 39 × 24 mm. Case reference IRM30. Drawing tolerance ±1 mm. PCB power pins The bottom view identifies +V and −V on one side, AC/L and AC/N on the other. Follow the exact illustrated orientation; the additional unlabeled location is not assigned a new electrical function here. Pin and layout dimensions Pin diameter 1.04 mm; protrusion 3.5 ±1 mm. Bottom-view callouts include 61.5 mm between the side pin columns, 9.0 mm between the output pins, and 30 mm between AC/L and AC/N. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 102 g, converted from the explicit 0.102 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $42.39

  View options

•

  View options

  MEAN WELL MPM-30 series: PCB Mount Medical AC/DC Power Supply - MPM-30-24

  MEAN WELL MPM-30-24 is an encapsulated pcb mount medical AC/DC power supply with 24 V output, 1.3 A rated current and 31.2 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-24 Series MPM-30 medical encapsulated AC/DC power supply. Output code 24 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 24 V. Rated current 1.3 A. Current range 0–1.3 A; no minimum load required. Catalogue-rated output power 31.2 W. Peak current and power 1.5 A and 36 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 90% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 25.2–32.4 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 5000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 69.5 × 39 × 24 mm. Case reference IRM30. Drawing tolerance ±1 mm. PCB power pins The bottom view identifies +V and −V on one side, AC/L and AC/N on the other. Follow the exact illustrated orientation; the additional unlabeled location is not assigned a new electrical function here. Pin and layout dimensions Pin diameter 1.04 mm; protrusion 3.5 ±1 mm. Bottom-view callouts include 61.5 mm between the side pin columns, 9.0 mm between the output pins, and 30 mm between AC/L and AC/N. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 102 g, converted from the explicit 0.102 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $41.40

  View options

•

  View options

  MEAN WELL MPM-30 series: PCB Mount Medical AC/DC Power Supply - MPM-30-15

  MEAN WELL MPM-30-15 is an encapsulated pcb mount medical AC/DC power supply with 15 V output, 2 A rated current and 30 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-15 Series MPM-30 medical encapsulated AC/DC power supply. Output code 15 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 15 V. Rated current 2 A. Current range 0–2 A; no minimum load required. Catalogue-rated output power 30 W. Peak current and power 2.3 A and 34.5 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 120 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 89% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 15.8–20.3 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 5000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 69.5 × 39 × 24 mm. Case reference IRM30. Drawing tolerance ±1 mm. PCB power pins The bottom view identifies +V and −V on one side, AC/L and AC/N on the other. Follow the exact illustrated orientation; the additional unlabeled location is not assigned a new electrical function here. Pin and layout dimensions Pin diameter 1.04 mm; protrusion 3.5 ±1 mm. Bottom-view callouts include 61.5 mm between the side pin columns, 9.0 mm between the output pins, and 30 mm between AC/L and AC/N. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 102 g, converted from the explicit 0.102 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $41.40

  View options

•

  View options

  MEAN WELL MPM-30 series: PCB Mount Medical AC/DC Power Supply - MPM-30-12

  MEAN WELL MPM-30-12 is an encapsulated pcb mount medical AC/DC power supply with 12 V output, 2.5 A rated current and 30 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-12 Series MPM-30 medical encapsulated AC/DC power supply. Output code 12 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 12 V. Rated current 2.5 A. Current range 0–2.5 A; no minimum load required. Catalogue-rated output power 30 W. Peak current and power 2.9 A and 34.8 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 120 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±0.5%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 90% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 12.6–16.2 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 5000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 69.5 × 39 × 24 mm. Case reference IRM30. Drawing tolerance ±1 mm. PCB power pins The bottom view identifies +V and −V on one side, AC/L and AC/N on the other. Follow the exact illustrated orientation; the additional unlabeled location is not assigned a new electrical function here. Pin and layout dimensions Pin diameter 1.04 mm; protrusion 3.5 ±1 mm. Bottom-view callouts include 61.5 mm between the side pin columns, 9.0 mm between the output pins, and 30 mm between AC/L and AC/N. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 102 g, converted from the explicit 0.102 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $38.44

  View options

•

  View options

  MEAN WELL MPM-30 series: PCB Mount Medical AC/DC Power Supply - MPM-30-5

  MEAN WELL MPM-30-5 is an encapsulated pcb mount medical AC/DC power supply with 5 V output, 6 A rated current and 30 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-5 Series MPM-30 medical encapsulated AC/DC power supply. Output code 5 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 5 V. Rated current 6 A. Current range 0–6 A; no minimum load required. Catalogue-rated output power 30 W. Peak current and power 6.9 A and 34.5 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 86.5% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 5.3–6.8 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 5000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 69.5 × 39 × 24 mm. Case reference IRM30. Drawing tolerance ±1 mm. PCB power pins The bottom view identifies +V and −V on one side, AC/L and AC/N on the other. Follow the exact illustrated orientation; the additional unlabeled location is not assigned a new electrical function here. Pin and layout dimensions Pin diameter 1.04 mm; protrusion 3.5 ±1 mm. Bottom-view callouts include 61.5 mm between the side pin columns, 9.0 mm between the output pins, and 30 mm between AC/L and AC/N. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 102 g, converted from the explicit 0.102 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $41.40

  View options

•

  View options

  MEAN WELL MPM-30 series: PCB Mount Medical AC/DC Power Supply - MPM-30-3.3

  MEAN WELL MPM-30-3.3 is an encapsulated pcb mount medical AC/DC power supply with 3.3 V output, 6 A rated current and 19.8 W catalogue-rated output power. It uses Class II construction without FG and provides 2 MOPP primary-secondary isolation. BF applications require appropriate system consideration; apply the model-specific peak, thermal and input-voltage limits. Product Datasheet Download MEAN WELL MPM-30 Datasheet (PDF) The MPM-30 section is on PDF pages 17, 18, 19, 20. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Selection Complete model MPM-30-3.3 Series MPM-30 medical encapsulated AC/DC power supply. Output code 3.3 V nominal DC output. Mounting suffix Blank suffix: PCB mounting style. The encapsulated, potted construction supports compact integration and resistance to dust, moisture and vibration. It does not establish an unlisted IP rating. Typical applications include portable medical devices, mobile clinical workstations, medical computer monitors and medical examination instruments. DC Output and Peak Operation Nominal DC voltage 3.3 V. Rated current 6 A. Current range 0–6 A; no minimum load required. Catalogue-rated output power 19.8 W. Peak current and power 7.8 A and 25.7 W for up to 10 seconds; subject to the duty and average-power limits below. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±2.0%; includes setup tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Peak operation is limited to a maximum 33% duty cycle within every 30 seconds. Average output power must not exceed the rated power. The peak rating is not a continuous-output allowance; observe the specified current and power limits together. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted-pair wire terminated by 0.1 µF and 47 µF capacitors in parallel. Use the catalogue-rated power, current and voltage as separate selection limits. Input and Timing Input voltage 80–264 V AC. AC frequency 47–63 Hz. Efficiency, typical 82.5% at the default specified test conditions. AC current, typical 0.75 A at 115 V AC; 0.5 A at 230 V AC. Cold-start inrush, typical 25 A at 115 V AC; 45 A at 230 V AC. Setup / rise time 500 ms / 30 ms at both 230 V AC and 115 V AC, full load. Hold-up time, typical 40 ms at 230 V AC; 12 ms at 115 V AC, full load. No-load consumption Less than 0.075 W. Protection and Medical Isolation Short circuit Short-circuit protection is listed. Overload 115–165% of rated output power; hiccup mode, automatic recovery after the fault is removed. Overvoltage 3.5–4.5 V; output shutdown, re-power to recover. Touch current Less than 80 µA at 264 V AC, measured from primary to DC output. Primary-secondary isolation 2 × MOPP. Construction Class II, without FG. Withstand voltage Input to output: 4 kV AC. Isolation resistance Input to output: 100 MΩ at 500 V DC, 25°C and 70% RH. Suitable for BF applications only with appropriate system consideration. These component ratings do not certify an assembled medical device or permit ignoring the final equipment insulation and leakage-current requirements. Cooling and Operating Limits Operating ambient −40 to +85°C; subject to the derating curve. Temperature derating Horizontal mounting: 100% load from −40 to +60°C, then along the plotted segments to 80% at +70°C, 50% at +80°C and 40% at +85°C. Input-voltage derating The 60 Hz AC-input curve gives 80% load at 80 V AC, rising to 100% at 100 V AC and remaining at 100% to 264 V AC. Working humidity 20–90% RH, non-condensing. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Operating altitude Up to 5000 m. Altitude derating For fanless operation above 2000 m (6500 ft), reduce permissible ambient temperature by 3.5°C per additional 1000 m. Vibration 2 G, 10–500 Hz, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. Apply the temperature, input-voltage and altitude limits together. Maximum ambient temperature does not imply full rated output at that temperature. Peak operation must also stay within the average-power and duty-cycle limits. Dimensions, Connections and Installation Dimensions (L × W × H) 69.5 × 39 × 24 mm. Case reference IRM30. Drawing tolerance ±1 mm. PCB power pins The bottom view identifies +V and −V on one side, AC/L and AC/N on the other. Follow the exact illustrated orientation; the additional unlabeled location is not assigned a new electrical function here. Pin and layout dimensions Pin diameter 1.04 mm; protrusion 3.5 ±1 mm. Bottom-view callouts include 61.5 mm between the side pin columns, 9.0 mm between the output pins, and 30 mm between AC/L and AC/N. Soldering limits Wave soldering: 265°C for 5 seconds maximum. Manual soldering: 390°C for 3 seconds maximum. Use the mechanical drawing for this mounting version and the manufacturer installation instructions. PCB and screw-terminal styles have different dimensions, connection layouts and vibration ratings; they are not interchangeable mounting patterns. The reviewed pages do not specify a separate accessory ordering code, mating connector, DIN-rail adaptor or included mounting kit for this model. Mounting hardware and connection details must be selected from the actual installation requirements; no unlisted tightening torque or screw depth is inferred. Safety Approvals and EMC Medical safety standards IEC 60601-1:2005+A1; TUV BS EN/EN 60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No. 60601-1:2014+A2; EAC TP TC 004 approved. Additional design option Design reference to BS EN/EN60335-1 is by request; not a standard approval claim for this supplied model. Emissions BS EN/EN55011 (CISPR11): Class B conducted and radiated; BS EN/EN61000-3-2: Class A harmonic current; BS EN/EN61000-3-3: voltage flicker. Immunity BS EN/EN55035 and BS EN/EN60601-1-2. ESD, BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field, -4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT, -4-4: Level 3, 2 kV. Surge, -4-5: Level 3, 1 kV line-to-line. Conducted immunity, -4-6: Level 3, 10 V. Magnetic field, -4-8: Level 4, 30 A/m. Voltage dips and interruptions, BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. The power supply is a component to be installed in final equipment. Re-confirm final-equipment EMC compliance under the manufacturer component-EMI guidance; component results alone are not approval of the assembled equipment. Weight, Reliability and Measurement Notes Catalogue unit-weight reference 102 g, converted from the explicit 0.102 kg PACKING reference per unit. This is not a measured net weight or a shipment weight. MTBF 6325.8 K hours minimum, Telcordia SR-332 (Bellcore); 778.9 K hours minimum, MIL-HDBK-217F at 25°C. Default test conditions 230 V AC input, rated load and 25°C ambient unless otherwise specified. Manufacturer warranty statement The catalogue lists three years; manufacturer terms apply. Datasheet version MPM-30-SPEC, 2024-10-30; combined catalogue pages 17–20. MTBF is a statistical reliability estimate, not a guaranteed service life. The unit-weight reference is taken directly from the specification, not obtained by dividing the carton weight.

  Read more less

  $42.39

  View options

•

  View options

  MEAN WELL MPM-20 series: Encapsulated Medical AC/DC Power Supply - MPM-20-24

  MEAN WELL MPM-20-24 is an encapsulated PCB-mount medical AC/DC power module with a 24 V output rated at 0.9 A and 21.6 W. It accepts 80–264 VAC or 113–370 VDC, requires no minimum load, and provides Class II construction with 2 × MOPP primary-secondary isolation. Peak operation and BF applications are subject to the conditions below. Product Datasheet Download MEAN WELL MPM-20 Datasheet (PDF) The MPM-20 section is on PDF pages 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Medical Application Exact model MPM-20-24; encapsulated PCB pin-type AC/DC power module. The final model-code field identifies the nominal DC output voltage. Electrical protection class Class II, double insulation, no functional-ground (FG) connection. Patient-protection insulation Primary-to-secondary isolation: 2 × MOPP. BF application Suitable for BF applications with appropriate system consideration; the power module alone does not certify a completed medical device as BF. Typical applications Portable medical devices, mobile clinical workstations, medical computer monitors and examination instruments. The plastic enclosure and internal potting support compact construction, heat dissipation and vibration resistance. The reviewed pages do not specify an IP ingress-protection rating; comply with the stated non-condensing humidity conditions. Model-Specific DC Output DC voltage 24 V. Rated continuous current 0.9 A. Current range 0–0.9 A; no minimum load required. Rated output power 21.6 W, as listed for this exact model. Peak current 0.99 A, subject to the peak-load conditions below. Peak output power 23.8 W, for a maximum of 10 seconds and subject to all duty-cycle and average-power limits. Ripple and noise, maximum 180 mVp-p. Voltage tolerance ±2.0%; includes set-up tolerance, line regulation and load regulation. Line regulation ±0.3%. Load regulation ±0.5%. Efficiency, typical 87%. Peak loading is limited to 33% maximum duty cycle within every 30 seconds, and average output power must not exceed this model’s rated output power. The 10-second peak specification does not remove either limit; reduce the duty further when the remaining load would otherwise exceed the permitted average. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Input and Start-Up AC input range 80–264 VAC, subject to low-input derating. DC input range 113–370 VDC. AC frequency 47–440 Hz. Input current, typical 0.75 A at 115 VAC; 0.5 A at 230 VAC. Cold-start inrush, typical 20 A at 115 VAC; 45 A at 230 VAC. No-load input consumption Less than 0.1 W. Set-up and rise time 1500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, at full load. Hold-up time, typical 40 ms at 230 VAC; 10 ms at 115 VAC, at full load. Touch current Less than 80 µA at 264 VAC; measured from primary input to DC output. Switching frequency reference 100 kHz in the block diagram. Unless specifically stated otherwise, catalogue parameters are measured at 230 VAC input, rated load and 25°C ambient. Typical figures are not guaranteed minimum performance values. Protection Short circuit and overload Overload protection operates at 110–150% of rated output power. Hiccup mode recovers automatically after the fault is removed; short-circuit protection is also listed. Overvoltage threshold 27.6–32.4 V. Overvoltage action Output voltage shuts off and is clamped by a zener diode. Overtemperature action Output shuts down and recovers automatically after temperature falls. The overload-protection threshold is not a continuous output rating or an additional peak-load allowance. Observe the separately stated model-specific output and peak-load limits. Cooling, Derating and Environment Working ambient range -35 to +85°C, with load derating. Cooling and curve orientation Fanless operation; the published ambient/load curve is for horizontal mounting. Temperature/load curve for this model -35°C: 100%; 55°C: 100%; 60°C: 70%; 70°C: 50%; 85°C: 30%. Curve selection 12–24 V output-voltage curve. Input-voltage/load curve At 60 Hz: 80% load at 80 VAC, rising to 100% at 100 VAC; 100% plateau from 100 to 264 VAC. Operating humidity 20–90% RH, non-condensing. Storage conditions −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–55°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Operating altitude Up to 5,000 m. High-altitude temperature reduction Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless module. Use the complete temperature and input-voltage curves for intermediate conditions, and apply input, temperature, altitude and peak-load restrictions together. A wide operating-temperature range does not mean full rated load throughout that range. Mechanical Dimensions and PCB Connections Dimensions, L × W × H 52.4 × 27.2 × 24 mm. Mechanical case No.219A; drawing dimensions in millimetres, general tolerance ±0.5 mm. Input pins, bottom view As drawn with the input pins on the left: upper pin AC/N; lower pin AC/L. Output pins, bottom view As drawn with the output pins on the right: upper pin −V; lower pin +V. Pin-column spacing 45 mm between input and output pin columns; input column is 3.4 mm from the left body edge. Pin spacing and edge reference Input-pair spacing 20.8 mm; output-pair spacing 8 mm; upper pins are 3.2 mm from the top body edge. Pin projection 3.5 mm, +1 / −0.5 mm. Pin dimension 1.04 mm is marked in the side drawing; explicitly identified as pin diameter. Soldering limits Wave soldering: 265°C for 5 seconds maximum; manual soldering: 390°C for 3 seconds maximum. Use the bottom-view pin arrangement rather than a top-view assumption when designing the PCB footprint. Follow the manufacturer’s installation instructions and the drawing for clearances and soldering. The assigned pages list no complete order code for a separate mating connector, mounting bracket or accessory kit; no such item is implied as supplied. Safety and EMC Conditions Listed medical safety approvals IEC60601-1:2005+A1; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005/A2:2021; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Other safety applicability IEC60335-1:2010/AMD2:2016 and Dekra BS EN/EN60335-1:2012+A11+A13+A1+A14+A2+A15 are also listed as approved. Input-to-output withstand voltage 4 kVAC. Input-to-output insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted and radiated emissions BS EN/EN55011 (CISPR11), Class B, for Class II configuration. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3 is listed; no numerical test level is specified. Immunity framework BS EN/EN55035 and BS EN/EN60601-1-2. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 3, 10 V/m over 80 MHz–2.7 GHz; Table 9 proximity-field levels 9–28 V/m over 385 MHz–5.78 GHz. EFT / burst BS EN/EN61000-4-4: Level 3, 2 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV line-to-line. Conducted susceptibility BS EN/EN61000-4-6: Level 3, 10 V. Magnetic-field immunity BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips and interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. This power supply is a component for installation in final equipment. Reconfirm the completed equipment’s EMC compliance and medical-system suitability; component approval and primary-secondary insulation do not establish every protection measure of the complete system. Weight, Reliability and Catalogue Reference Single-unit catalogue weight 56 g (0.056 kg), explicitly listed in PACKING. This is a catalogue unit-weight reference, not a measured shipping weight. Packing reference 240 pieces / 14.4 kg / 0.94 CUFT. Minimum MTBF estimates 7319.8 thousand hours by Telcordia SR-332 (Bellcore); 1210.0 thousand hours by MIL-HDBK-217F at 25°C. Catalogue warranty 3-year manufacturer warranty, subject to the applicable terms. Specification version MPM-20-SPEC dated 2024-10-30; combined catalogue pages 13–16. Rating convention The displayed power, current and peak values preserve the catalogue’s printed precision. MTBF values are statistical estimates under the stated methods and are not a guaranteed operating life.

  Read more less

  $30.06

  View options

•

  View options

  MEAN WELL MPM-20 series: Encapsulated Medical AC/DC Power Supply - MPM-20-15

  MEAN WELL MPM-20-15 is an encapsulated PCB-mount medical AC/DC power module with a 15 V output rated at 1.4 A and 21 W. It accepts 80–264 VAC or 113–370 VDC, requires no minimum load, and provides Class II construction with 2 × MOPP primary-secondary isolation. Peak operation and BF applications are subject to the conditions below. Product Datasheet Download MEAN WELL MPM-20 Datasheet (PDF) The MPM-20 section is on PDF pages 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Medical Application Exact model MPM-20-15; encapsulated PCB pin-type AC/DC power module. The final model-code field identifies the nominal DC output voltage. Electrical protection class Class II, double insulation, no functional-ground (FG) connection. Patient-protection insulation Primary-to-secondary isolation: 2 × MOPP. BF application Suitable for BF applications with appropriate system consideration; the power module alone does not certify a completed medical device as BF. Typical applications Portable medical devices, mobile clinical workstations, medical computer monitors and examination instruments. The plastic enclosure and internal potting support compact construction, heat dissipation and vibration resistance. The reviewed pages do not specify an IP ingress-protection rating; comply with the stated non-condensing humidity conditions. Model-Specific DC Output DC voltage 15 V. Rated continuous current 1.4 A. Current range 0–1.4 A; no minimum load required. Rated output power 21 W, as listed for this exact model. Peak current 1.54 A, subject to the peak-load conditions below. Peak output power 23.1 W, for a maximum of 10 seconds and subject to all duty-cycle and average-power limits. Ripple and noise, maximum 180 mVp-p. Voltage tolerance ±2.0%; includes set-up tolerance, line regulation and load regulation. Line regulation ±0.3%. Load regulation ±0.5%. Efficiency, typical 87%. Peak loading is limited to 33% maximum duty cycle within every 30 seconds, and average output power must not exceed this model’s rated output power. The 10-second peak specification does not remove either limit; reduce the duty further when the remaining load would otherwise exceed the permitted average. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Input and Start-Up AC input range 80–264 VAC, subject to low-input derating. DC input range 113–370 VDC. AC frequency 47–440 Hz. Input current, typical 0.75 A at 115 VAC; 0.5 A at 230 VAC. Cold-start inrush, typical 20 A at 115 VAC; 45 A at 230 VAC. No-load input consumption Less than 0.1 W. Set-up and rise time 1500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, at full load. Hold-up time, typical 40 ms at 230 VAC; 10 ms at 115 VAC, at full load. Touch current Less than 80 µA at 264 VAC; measured from primary input to DC output. Switching frequency reference 100 kHz in the block diagram. Unless specifically stated otherwise, catalogue parameters are measured at 230 VAC input, rated load and 25°C ambient. Typical figures are not guaranteed minimum performance values. Protection Short circuit and overload Overload protection operates at 110–150% of rated output power. Hiccup mode recovers automatically after the fault is removed; short-circuit protection is also listed. Overvoltage threshold 17.3–20.3 V. Overvoltage action Output voltage shuts off and is clamped by a zener diode. Overtemperature action Output shuts down and recovers automatically after temperature falls. The overload-protection threshold is not a continuous output rating or an additional peak-load allowance. Observe the separately stated model-specific output and peak-load limits. Cooling, Derating and Environment Working ambient range -35 to +85°C, with load derating. Cooling and curve orientation Fanless operation; the published ambient/load curve is for horizontal mounting. Temperature/load curve for this model -35°C: 100%; 55°C: 100%; 60°C: 70%; 70°C: 50%; 85°C: 30%. Curve selection 12–24 V output-voltage curve. Input-voltage/load curve At 60 Hz: 80% load at 80 VAC, rising to 100% at 100 VAC; 100% plateau from 100 to 264 VAC. Operating humidity 20–90% RH, non-condensing. Storage conditions −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–55°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Operating altitude Up to 5,000 m. High-altitude temperature reduction Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless module. Use the complete temperature and input-voltage curves for intermediate conditions, and apply input, temperature, altitude and peak-load restrictions together. A wide operating-temperature range does not mean full rated load throughout that range. Mechanical Dimensions and PCB Connections Dimensions, L × W × H 52.4 × 27.2 × 24 mm. Mechanical case No.219A; drawing dimensions in millimetres, general tolerance ±0.5 mm. Input pins, bottom view As drawn with the input pins on the left: upper pin AC/N; lower pin AC/L. Output pins, bottom view As drawn with the output pins on the right: upper pin −V; lower pin +V. Pin-column spacing 45 mm between input and output pin columns; input column is 3.4 mm from the left body edge. Pin spacing and edge reference Input-pair spacing 20.8 mm; output-pair spacing 8 mm; upper pins are 3.2 mm from the top body edge. Pin projection 3.5 mm, +1 / −0.5 mm. Pin dimension 1.04 mm is marked in the side drawing; explicitly identified as pin diameter. Soldering limits Wave soldering: 265°C for 5 seconds maximum; manual soldering: 390°C for 3 seconds maximum. Use the bottom-view pin arrangement rather than a top-view assumption when designing the PCB footprint. Follow the manufacturer’s installation instructions and the drawing for clearances and soldering. The assigned pages list no complete order code for a separate mating connector, mounting bracket or accessory kit; no such item is implied as supplied. Safety and EMC Conditions Listed medical safety approvals IEC60601-1:2005+A1; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005/A2:2021; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Other safety applicability IEC60335-1:2010/AMD2:2016 and Dekra BS EN/EN60335-1:2012+A11+A13+A1+A14+A2+A15 are also listed as approved. Input-to-output withstand voltage 4 kVAC. Input-to-output insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted and radiated emissions BS EN/EN55011 (CISPR11), Class B, for Class II configuration. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3 is listed; no numerical test level is specified. Immunity framework BS EN/EN55035 and BS EN/EN60601-1-2. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 3, 10 V/m over 80 MHz–2.7 GHz; Table 9 proximity-field levels 9–28 V/m over 385 MHz–5.78 GHz. EFT / burst BS EN/EN61000-4-4: Level 3, 2 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV line-to-line. Conducted susceptibility BS EN/EN61000-4-6: Level 3, 10 V. Magnetic-field immunity BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips and interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. This power supply is a component for installation in final equipment. Reconfirm the completed equipment’s EMC compliance and medical-system suitability; component approval and primary-secondary insulation do not establish every protection measure of the complete system. Weight, Reliability and Catalogue Reference Single-unit catalogue weight 56 g (0.056 kg), explicitly listed in PACKING. This is a catalogue unit-weight reference, not a measured shipping weight. Packing reference 240 pieces / 14.4 kg / 0.94 CUFT. Minimum MTBF estimates 7319.8 thousand hours by Telcordia SR-332 (Bellcore); 1210.0 thousand hours by MIL-HDBK-217F at 25°C. Catalogue warranty 3-year manufacturer warranty, subject to the applicable terms. Specification version MPM-20-SPEC dated 2024-10-30; combined catalogue pages 13–16. Rating convention The displayed power, current and peak values preserve the catalogue’s printed precision. MTBF values are statistical estimates under the stated methods and are not a guaranteed operating life.

  Read more less

  $30.06

  View options

•

  View options

  MEAN WELL MPM-20 series: Encapsulated Medical AC/DC Power Supply - MPM-20-12

  MEAN WELL MPM-20-12 is an encapsulated PCB-mount medical AC/DC power module with a 12 V output rated at 1.8 A and 21.6 W. It accepts 80–264 VAC or 113–370 VDC, requires no minimum load, and provides Class II construction with 2 × MOPP primary-secondary isolation. Peak operation and BF applications are subject to the conditions below. Product Datasheet Download MEAN WELL MPM-20 Datasheet (PDF) The MPM-20 section is on PDF pages 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Medical Application Exact model MPM-20-12; encapsulated PCB pin-type AC/DC power module. The final model-code field identifies the nominal DC output voltage. Electrical protection class Class II, double insulation, no functional-ground (FG) connection. Patient-protection insulation Primary-to-secondary isolation: 2 × MOPP. BF application Suitable for BF applications with appropriate system consideration; the power module alone does not certify a completed medical device as BF. Typical applications Portable medical devices, mobile clinical workstations, medical computer monitors and examination instruments. The plastic enclosure and internal potting support compact construction, heat dissipation and vibration resistance. The reviewed pages do not specify an IP ingress-protection rating; comply with the stated non-condensing humidity conditions. Model-Specific DC Output DC voltage 12 V. Rated continuous current 1.8 A. Current range 0–1.8 A; no minimum load required. Rated output power 21.6 W, as listed for this exact model. Peak current 1.98 A, subject to the peak-load conditions below. Peak output power 23.8 W, for a maximum of 10 seconds and subject to all duty-cycle and average-power limits. Ripple and noise, maximum 150 mVp-p. Voltage tolerance ±2.0%; includes set-up tolerance, line regulation and load regulation. Line regulation ±0.3%. Load regulation ±0.5%. Efficiency, typical 85.5%. Peak loading is limited to 33% maximum duty cycle within every 30 seconds, and average output power must not exceed this model’s rated output power. The 10-second peak specification does not remove either limit; reduce the duty further when the remaining load would otherwise exceed the permitted average. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Input and Start-Up AC input range 80–264 VAC, subject to low-input derating. DC input range 113–370 VDC. AC frequency 47–440 Hz. Input current, typical 0.75 A at 115 VAC; 0.5 A at 230 VAC. Cold-start inrush, typical 20 A at 115 VAC; 45 A at 230 VAC. No-load input consumption Less than 0.1 W. Set-up and rise time 1500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, at full load. Hold-up time, typical 40 ms at 230 VAC; 10 ms at 115 VAC, at full load. Touch current Less than 80 µA at 264 VAC; measured from primary input to DC output. Switching frequency reference 100 kHz in the block diagram. Unless specifically stated otherwise, catalogue parameters are measured at 230 VAC input, rated load and 25°C ambient. Typical figures are not guaranteed minimum performance values. Protection Short circuit and overload Overload protection operates at 110–150% of rated output power. Hiccup mode recovers automatically after the fault is removed; short-circuit protection is also listed. Overvoltage threshold 13.8–16.2 V. Overvoltage action Output voltage shuts off and is clamped by a zener diode. Overtemperature action Output shuts down and recovers automatically after temperature falls. The overload-protection threshold is not a continuous output rating or an additional peak-load allowance. Observe the separately stated model-specific output and peak-load limits. Cooling, Derating and Environment Working ambient range -35 to +85°C, with load derating. Cooling and curve orientation Fanless operation; the published ambient/load curve is for horizontal mounting. Temperature/load curve for this model -35°C: 100%; 55°C: 100%; 60°C: 70%; 70°C: 50%; 85°C: 30%. Curve selection 12–24 V output-voltage curve. Input-voltage/load curve At 60 Hz: 80% load at 80 VAC, rising to 100% at 100 VAC; 100% plateau from 100 to 264 VAC. Operating humidity 20–90% RH, non-condensing. Storage conditions −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–55°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Operating altitude Up to 5,000 m. High-altitude temperature reduction Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless module. Use the complete temperature and input-voltage curves for intermediate conditions, and apply input, temperature, altitude and peak-load restrictions together. A wide operating-temperature range does not mean full rated load throughout that range. Mechanical Dimensions and PCB Connections Dimensions, L × W × H 52.4 × 27.2 × 24 mm. Mechanical case No.219A; drawing dimensions in millimetres, general tolerance ±0.5 mm. Input pins, bottom view As drawn with the input pins on the left: upper pin AC/N; lower pin AC/L. Output pins, bottom view As drawn with the output pins on the right: upper pin −V; lower pin +V. Pin-column spacing 45 mm between input and output pin columns; input column is 3.4 mm from the left body edge. Pin spacing and edge reference Input-pair spacing 20.8 mm; output-pair spacing 8 mm; upper pins are 3.2 mm from the top body edge. Pin projection 3.5 mm, +1 / −0.5 mm. Pin dimension 1.04 mm is marked in the side drawing; explicitly identified as pin diameter. Soldering limits Wave soldering: 265°C for 5 seconds maximum; manual soldering: 390°C for 3 seconds maximum. Use the bottom-view pin arrangement rather than a top-view assumption when designing the PCB footprint. Follow the manufacturer’s installation instructions and the drawing for clearances and soldering. The assigned pages list no complete order code for a separate mating connector, mounting bracket or accessory kit; no such item is implied as supplied. Safety and EMC Conditions Listed medical safety approvals IEC60601-1:2005+A1; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005/A2:2021; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Other safety applicability IEC60335-1:2010/AMD2:2016 and Dekra BS EN/EN60335-1:2012+A11+A13+A1+A14+A2+A15 are also listed as approved. Input-to-output withstand voltage 4 kVAC. Input-to-output insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted and radiated emissions BS EN/EN55011 (CISPR11), Class B, for Class II configuration. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3 is listed; no numerical test level is specified. Immunity framework BS EN/EN55035 and BS EN/EN60601-1-2. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 3, 10 V/m over 80 MHz–2.7 GHz; Table 9 proximity-field levels 9–28 V/m over 385 MHz–5.78 GHz. EFT / burst BS EN/EN61000-4-4: Level 3, 2 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV line-to-line. Conducted susceptibility BS EN/EN61000-4-6: Level 3, 10 V. Magnetic-field immunity BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips and interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. This power supply is a component for installation in final equipment. Reconfirm the completed equipment’s EMC compliance and medical-system suitability; component approval and primary-secondary insulation do not establish every protection measure of the complete system. Weight, Reliability and Catalogue Reference Single-unit catalogue weight 56 g (0.056 kg), explicitly listed in PACKING. This is a catalogue unit-weight reference, not a measured shipping weight. Packing reference 240 pieces / 14.4 kg / 0.94 CUFT. Minimum MTBF estimates 7319.8 thousand hours by Telcordia SR-332 (Bellcore); 1210.0 thousand hours by MIL-HDBK-217F at 25°C. Catalogue warranty 3-year manufacturer warranty, subject to the applicable terms. Specification version MPM-20-SPEC dated 2024-10-30; combined catalogue pages 13–16. Rating convention The displayed power, current and peak values preserve the catalogue’s printed precision. MTBF values are statistical estimates under the stated methods and are not a guaranteed operating life.

  Read more less

  $30.06

  View options

•

  View options

  MEAN WELL MPM-20 series: Encapsulated Medical AC/DC Power Supply - MPM-20-5

  MEAN WELL MPM-20-5 is an encapsulated PCB-mount medical AC/DC power module with a 5 V output rated at 4 A and 20 W. It accepts 80–264 VAC or 113–370 VDC, requires no minimum load, and provides Class II construction with 2 × MOPP primary-secondary isolation. Peak operation and BF applications are subject to the conditions below. Product Datasheet Download MEAN WELL MPM-20 Datasheet (PDF) The MPM-20 section is on PDF pages 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Medical Application Exact model MPM-20-5; encapsulated PCB pin-type AC/DC power module. The final model-code field identifies the nominal DC output voltage. Electrical protection class Class II, double insulation, no functional-ground (FG) connection. Patient-protection insulation Primary-to-secondary isolation: 2 × MOPP. BF application Suitable for BF applications with appropriate system consideration; the power module alone does not certify a completed medical device as BF. Typical applications Portable medical devices, mobile clinical workstations, medical computer monitors and examination instruments. The plastic enclosure and internal potting support compact construction, heat dissipation and vibration resistance. The reviewed pages do not specify an IP ingress-protection rating; comply with the stated non-condensing humidity conditions. Model-Specific DC Output DC voltage 5 V. Rated continuous current 4 A. Current range 0–4 A; no minimum load required. Rated output power 20 W, as listed for this exact model. Peak current 4.4 A, subject to the peak-load conditions below. Peak output power 22 W, for a maximum of 10 seconds and subject to all duty-cycle and average-power limits. Ripple and noise, maximum 150 mVp-p. Voltage tolerance ±2.0%; includes set-up tolerance, line regulation and load regulation. Line regulation ±0.5%. Load regulation ±0.5%. Efficiency, typical 85%. Peak loading is limited to 33% maximum duty cycle within every 30 seconds, and average output power must not exceed this model’s rated output power. The 10-second peak specification does not remove either limit; reduce the duty further when the remaining load would otherwise exceed the permitted average. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Input and Start-Up AC input range 80–264 VAC, subject to low-input derating. DC input range 113–370 VDC. AC frequency 47–440 Hz. Input current, typical 0.75 A at 115 VAC; 0.5 A at 230 VAC. Cold-start inrush, typical 20 A at 115 VAC; 45 A at 230 VAC. No-load input consumption Less than 0.1 W. Set-up and rise time 1500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, at full load. Hold-up time, typical 40 ms at 230 VAC; 10 ms at 115 VAC, at full load. Touch current Less than 80 µA at 264 VAC; measured from primary input to DC output. Switching frequency reference 100 kHz in the block diagram. Unless specifically stated otherwise, catalogue parameters are measured at 230 VAC input, rated load and 25°C ambient. Typical figures are not guaranteed minimum performance values. Protection Short circuit and overload Overload protection operates at 110–150% of rated output power. Hiccup mode recovers automatically after the fault is removed; short-circuit protection is also listed. Overvoltage threshold 5.8–6.8 V. Overvoltage action Output voltage shuts off and is clamped by a zener diode. Overtemperature action Output shuts down and recovers automatically after temperature falls. The overload-protection threshold is not a continuous output rating or an additional peak-load allowance. Observe the separately stated model-specific output and peak-load limits. Cooling, Derating and Environment Working ambient range -35 to +85°C, with load derating. Cooling and curve orientation Fanless operation; the published ambient/load curve is for horizontal mounting. Temperature/load curve for this model -35°C: 100%; 50°C: 100%; 60°C: 70%; 70°C: 50%; 85°C: 30%. Curve selection 3.3 V / 5 V output-voltage curve. Input-voltage/load curve At 60 Hz: 80% load at 80 VAC, rising to 100% at 100 VAC; 100% plateau from 100 to 264 VAC. Operating humidity 20–90% RH, non-condensing. Storage conditions −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–55°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Operating altitude Up to 5,000 m. High-altitude temperature reduction Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless module. Use the complete temperature and input-voltage curves for intermediate conditions, and apply input, temperature, altitude and peak-load restrictions together. A wide operating-temperature range does not mean full rated load throughout that range. Mechanical Dimensions and PCB Connections Dimensions, L × W × H 52.4 × 27.2 × 24 mm. Mechanical case No.219A; drawing dimensions in millimetres, general tolerance ±0.5 mm. Input pins, bottom view As drawn with the input pins on the left: upper pin AC/N; lower pin AC/L. Output pins, bottom view As drawn with the output pins on the right: upper pin −V; lower pin +V. Pin-column spacing 45 mm between input and output pin columns; input column is 3.4 mm from the left body edge. Pin spacing and edge reference Input-pair spacing 20.8 mm; output-pair spacing 8 mm; upper pins are 3.2 mm from the top body edge. Pin projection 3.5 mm, +1 / −0.5 mm. Pin dimension 1.04 mm is marked in the side drawing; explicitly identified as pin diameter. Soldering limits Wave soldering: 265°C for 5 seconds maximum; manual soldering: 390°C for 3 seconds maximum. Use the bottom-view pin arrangement rather than a top-view assumption when designing the PCB footprint. Follow the manufacturer’s installation instructions and the drawing for clearances and soldering. The assigned pages list no complete order code for a separate mating connector, mounting bracket or accessory kit; no such item is implied as supplied. Safety and EMC Conditions Listed medical safety approvals IEC60601-1:2005+A1; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005/A2:2021; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Other safety applicability IEC60335-1:2010/AMD2:2016 and Dekra BS EN/EN60335-1:2012+A11+A13+A1+A14+A2+A15 are also listed as approved. Input-to-output withstand voltage 4 kVAC. Input-to-output insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted and radiated emissions BS EN/EN55011 (CISPR11), Class B, for Class II configuration. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3 is listed; no numerical test level is specified. Immunity framework BS EN/EN55035 and BS EN/EN60601-1-2. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 3, 10 V/m over 80 MHz–2.7 GHz; Table 9 proximity-field levels 9–28 V/m over 385 MHz–5.78 GHz. EFT / burst BS EN/EN61000-4-4: Level 3, 2 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV line-to-line. Conducted susceptibility BS EN/EN61000-4-6: Level 3, 10 V. Magnetic-field immunity BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips and interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. This power supply is a component for installation in final equipment. Reconfirm the completed equipment’s EMC compliance and medical-system suitability; component approval and primary-secondary insulation do not establish every protection measure of the complete system. Weight, Reliability and Catalogue Reference Single-unit catalogue weight 56 g (0.056 kg), explicitly listed in PACKING. This is a catalogue unit-weight reference, not a measured shipping weight. Packing reference 240 pieces / 14.4 kg / 0.94 CUFT. Minimum MTBF estimates 7319.8 thousand hours by Telcordia SR-332 (Bellcore); 1210.0 thousand hours by MIL-HDBK-217F at 25°C. Catalogue warranty 3-year manufacturer warranty, subject to the applicable terms. Specification version MPM-20-SPEC dated 2024-10-30; combined catalogue pages 13–16. Rating convention The displayed power, current and peak values preserve the catalogue’s printed precision. MTBF values are statistical estimates under the stated methods and are not a guaranteed operating life.

  Read more less

  $33.02

  View options

•

  View options

  MEAN WELL MPM-20 series: Encapsulated Medical AC/DC Power Supply - MPM-20-3.3

  MEAN WELL MPM-20-3.3 is an encapsulated PCB-mount medical AC/DC power module with a 3.3 V output rated at 4.5 A and 14.9 W. It accepts 80–264 VAC or 113–370 VDC, requires no minimum load, and provides Class II construction with 2 × MOPP primary-secondary isolation. Peak operation and BF applications are subject to the conditions below. Product Datasheet Download MEAN WELL MPM-20 Datasheet (PDF) The MPM-20 section is on PDF pages 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Medical Application Exact model MPM-20-3.3; encapsulated PCB pin-type AC/DC power module. The final model-code field identifies the nominal DC output voltage. Electrical protection class Class II, double insulation, no functional-ground (FG) connection. Patient-protection insulation Primary-to-secondary isolation: 2 × MOPP. BF application Suitable for BF applications with appropriate system consideration; the power module alone does not certify a completed medical device as BF. Typical applications Portable medical devices, mobile clinical workstations, medical computer monitors and examination instruments. The plastic enclosure and internal potting support compact construction, heat dissipation and vibration resistance. The reviewed pages do not specify an IP ingress-protection rating; comply with the stated non-condensing humidity conditions. Model-Specific DC Output DC voltage 3.3 V. Rated continuous current 4.5 A. Current range 0–4.5 A; no minimum load required. Rated output power 14.9 W, as listed for this exact model. Peak current 4.95 A, subject to the peak-load conditions below. Peak output power 16.3 W, for a maximum of 10 seconds and subject to all duty-cycle and average-power limits. Ripple and noise, maximum 150 mVp-p. Voltage tolerance ±2.0%; includes set-up tolerance, line regulation and load regulation. Line regulation ±0.5%. Load regulation ±0.5%. Efficiency, typical 81%. Peak loading is limited to 33% maximum duty cycle within every 30 seconds, and average output power must not exceed this model’s rated output power. The 10-second peak specification does not remove either limit; reduce the duty further when the remaining load would otherwise exceed the permitted average. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Input and Start-Up AC input range 80–264 VAC, subject to low-input derating. DC input range 113–370 VDC. AC frequency 47–440 Hz. Input current, typical 0.75 A at 115 VAC; 0.5 A at 230 VAC. Cold-start inrush, typical 20 A at 115 VAC; 45 A at 230 VAC. No-load input consumption Less than 0.1 W. Set-up and rise time 1500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, at full load. Hold-up time, typical 40 ms at 230 VAC; 10 ms at 115 VAC, at full load. Touch current Less than 80 µA at 264 VAC; measured from primary input to DC output. Switching frequency reference 100 kHz in the block diagram. Unless specifically stated otherwise, catalogue parameters are measured at 230 VAC input, rated load and 25°C ambient. Typical figures are not guaranteed minimum performance values. Protection Short circuit and overload Overload protection operates at 110–150% of rated output power. Hiccup mode recovers automatically after the fault is removed; short-circuit protection is also listed. Overvoltage threshold 3.8–5 V. Overvoltage action Output voltage shuts off and is clamped by a zener diode. Overtemperature action Output shuts down and recovers automatically after temperature falls. The overload-protection threshold is not a continuous output rating or an additional peak-load allowance. Observe the separately stated model-specific output and peak-load limits. Cooling, Derating and Environment Working ambient range -35 to +85°C, with load derating. Cooling and curve orientation Fanless operation; the published ambient/load curve is for horizontal mounting. Temperature/load curve for this model -35°C: 100%; 50°C: 100%; 60°C: 70%; 70°C: 50%; 85°C: 30%. Curve selection 3.3 V / 5 V output-voltage curve. Input-voltage/load curve At 60 Hz: 80% load at 80 VAC, rising to 100% at 100 VAC; 100% plateau from 100 to 264 VAC. Operating humidity 20–90% RH, non-condensing. Storage conditions −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–55°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Operating altitude Up to 5,000 m. High-altitude temperature reduction Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless module. Use the complete temperature and input-voltage curves for intermediate conditions, and apply input, temperature, altitude and peak-load restrictions together. A wide operating-temperature range does not mean full rated load throughout that range. Mechanical Dimensions and PCB Connections Dimensions, L × W × H 52.4 × 27.2 × 24 mm. Mechanical case No.219A; drawing dimensions in millimetres, general tolerance ±0.5 mm. Input pins, bottom view As drawn with the input pins on the left: upper pin AC/N; lower pin AC/L. Output pins, bottom view As drawn with the output pins on the right: upper pin −V; lower pin +V. Pin-column spacing 45 mm between input and output pin columns; input column is 3.4 mm from the left body edge. Pin spacing and edge reference Input-pair spacing 20.8 mm; output-pair spacing 8 mm; upper pins are 3.2 mm from the top body edge. Pin projection 3.5 mm, +1 / −0.5 mm. Pin dimension 1.04 mm is marked in the side drawing; explicitly identified as pin diameter. Soldering limits Wave soldering: 265°C for 5 seconds maximum; manual soldering: 390°C for 3 seconds maximum. Use the bottom-view pin arrangement rather than a top-view assumption when designing the PCB footprint. Follow the manufacturer’s installation instructions and the drawing for clearances and soldering. The assigned pages list no complete order code for a separate mating connector, mounting bracket or accessory kit; no such item is implied as supplied. Safety and EMC Conditions Listed medical safety approvals IEC60601-1:2005+A1; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005/A2:2021; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Other safety applicability IEC60335-1:2010/AMD2:2016 and Dekra BS EN/EN60335-1:2012+A11+A13+A1+A14+A2+A15 are also listed as approved. Input-to-output withstand voltage 4 kVAC. Input-to-output insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted and radiated emissions BS EN/EN55011 (CISPR11), Class B, for Class II configuration. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3 is listed; no numerical test level is specified. Immunity framework BS EN/EN55035 and BS EN/EN60601-1-2. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 3, 10 V/m over 80 MHz–2.7 GHz; Table 9 proximity-field levels 9–28 V/m over 385 MHz–5.78 GHz. EFT / burst BS EN/EN61000-4-4: Level 3, 2 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV line-to-line. Conducted susceptibility BS EN/EN61000-4-6: Level 3, 10 V. Magnetic-field immunity BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips and interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. This power supply is a component for installation in final equipment. Reconfirm the completed equipment’s EMC compliance and medical-system suitability; component approval and primary-secondary insulation do not establish every protection measure of the complete system. Weight, Reliability and Catalogue Reference Single-unit catalogue weight 56 g (0.056 kg), explicitly listed in PACKING. This is a catalogue unit-weight reference, not a measured shipping weight. Packing reference 240 pieces / 14.4 kg / 0.94 CUFT. Minimum MTBF estimates 7319.8 thousand hours by Telcordia SR-332 (Bellcore); 1210.0 thousand hours by MIL-HDBK-217F at 25°C. Catalogue warranty 3-year manufacturer warranty, subject to the applicable terms. Specification version MPM-20-SPEC dated 2024-10-30; combined catalogue pages 13–16. Rating convention The displayed power, current and peak values preserve the catalogue’s printed precision. MTBF values are statistical estimates under the stated methods and are not a guaranteed operating life.

  Read more less

  $33.02

  View options

•

  View options

  MEAN WELL MPM-15 series: Encapsulated Medical AC/DC Power Supply - MPM-15-24

  MEAN WELL MPM-15-24 is an encapsulated PCB-mount medical AC/DC power module with a 24 V output rated at 0.63 A and 15.1 W. It accepts 80–264 VAC or 113–370 VDC, requires no minimum load, and provides Class II construction with 2 × MOPP primary-secondary isolation. Peak operation and BF applications are subject to the conditions below. Product Datasheet Download MEAN WELL MPM-15 Datasheet (PDF) The MPM-15 section is on PDF pages 9, 10, 11, 12. Refer to the complete mechanical drawings and notes when planning installation. Model and Medical Application Exact model MPM-15-24; encapsulated PCB pin-type AC/DC power module. The final model-code field identifies the nominal DC output voltage. Electrical protection class Class II, double insulation, no functional-ground (FG) connection. Patient-protection insulation Primary-to-secondary isolation: 2 × MOPP. BF application Suitable for BF applications with appropriate system consideration; the power module alone does not certify a completed medical device as BF. Typical applications Portable medical devices, mobile clinical workstations, medical computer monitors and examination instruments. The plastic enclosure and internal potting support compact construction, heat dissipation and vibration resistance. The reviewed pages do not specify an IP ingress-protection rating; comply with the stated non-condensing humidity conditions. Model-Specific DC Output DC voltage 24 V. Rated continuous current 0.63 A. Current range 0–0.63 A; no minimum load required. Rated output power 15.1 W, as listed for this exact model. Peak current 0.69 A, subject to the peak-load conditions below. Peak output power 16.6 W, for a maximum of 10 seconds and subject to all duty-cycle and average-power limits. Ripple and noise, maximum 180 mVp-p. Voltage tolerance ±2.0%; includes set-up tolerance, line regulation and load regulation. Line regulation ±0.3%. Load regulation ±0.5%. Efficiency, typical 86.5%. Peak loading is limited to 33% maximum duty cycle within every 30 seconds, and average output power must not exceed this model’s rated output power. The 10-second peak specification does not remove either limit; reduce the duty further when the remaining load would otherwise exceed the permitted average. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Input and Start-Up AC input range 80–264 VAC, subject to low-input derating. DC input range 113–370 VDC. AC frequency 47–440 Hz. Input current, typical 0.6 A at 115 VAC; 0.3 A at 230 VAC. Cold-start inrush, typical 20 A at 115 VAC; 45 A at 230 VAC. No-load input consumption Less than 0.1 W. Set-up and rise time 1500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, at full load. Hold-up time, typical 40 ms at 230 VAC; 10 ms at 115 VAC, at full load. Touch current Less than 80 µA at 264 VAC; measured from primary input to DC output. Switching frequency reference 100 kHz in the block diagram. Unless specifically stated otherwise, catalogue parameters are measured at 230 VAC input, rated load and 25°C ambient. Typical figures are not guaranteed minimum performance values. Protection Short circuit and overload Overload protection operates at 110–150% of rated output power. Hiccup mode recovers automatically after the fault is removed; short-circuit protection is also listed. Overvoltage threshold 27.6–32.4 V. Overvoltage action Output voltage shuts off and is clamped by a zener diode. Overtemperature action Output shuts down and recovers automatically after temperature falls. The overload-protection threshold is not a continuous output rating or an additional peak-load allowance. Observe the separately stated model-specific output and peak-load limits. Cooling, Derating and Environment Working ambient range -40 to +85°C, with load derating. Cooling and curve orientation Fanless operation; the published ambient/load curve is for horizontal mounting. Temperature/load curve for this model -40°C: 100%; 60°C: 100%; 70°C: 50%; 85°C: 30%. Curve selection 12–24 V output-voltage curve. Input-voltage/load curve At 60 Hz: 80% load at 80 VAC, rising to 100% at 100 VAC; 100% plateau from 100 to 264 VAC. Operating humidity 20–90% RH, non-condensing. Storage conditions −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Operating altitude Up to 5,000 m. High-altitude temperature reduction Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless module. Use the complete temperature and input-voltage curves for intermediate conditions, and apply input, temperature, altitude and peak-load restrictions together. A wide operating-temperature range does not mean full rated load throughout that range. Mechanical Dimensions and PCB Connections Dimensions, L × W × H 52.4 × 27.2 × 24 mm. Mechanical case No.219A; drawing dimensions in millimetres, general tolerance ±0.5 mm. Input pins, bottom view As drawn with the input pins on the left: upper pin AC/N; lower pin AC/L. Output pins, bottom view As drawn with the output pins on the right: upper pin −V; lower pin +V. Pin-column spacing 45 mm between input and output pin columns; input column is 3.4 mm from the left body edge. Pin spacing and edge reference Input-pair spacing 20.8 mm; output-pair spacing 8 mm; upper pins are 3.2 mm from the top body edge. Pin projection 3.5 ±1 mm. Pin dimension 1.04 mm is marked in the side drawing; explicitly identified as pin diameter. Soldering limits Wave soldering: 265°C for 5 seconds maximum; manual soldering: 390°C for 3 seconds maximum. Use the bottom-view pin arrangement rather than a top-view assumption when designing the PCB footprint. Follow the manufacturer’s installation instructions and the drawing for clearances and soldering. The assigned pages list no complete order code for a separate mating connector, mounting bracket or accessory kit; no such item is implied as supplied. Safety and EMC Conditions Listed medical safety approvals IEC60601-1:2005+A1; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005/A2:2021; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Other safety applicability IEC60335-1:2010/AMD2:2016 and Dekra BS EN/EN60335-1:2012+A11+A13+A1+A14+A2+A15 are also listed as approved. Input-to-output withstand voltage 4 kVAC. Input-to-output insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted and radiated emissions BS EN/EN55011 (CISPR11), Class B, for Class II configuration. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3 is listed; no numerical test level is specified. Immunity framework BS EN/EN55035 and BS EN/EN60601-1-2. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 3, 10 V/m over 80 MHz–2.7 GHz; Table 9 proximity-field levels 9–28 V/m over 385 MHz–5.78 GHz. EFT / burst BS EN/EN61000-4-4: Level 3, 2 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV line-to-line. Conducted susceptibility BS EN/EN61000-4-6: Level 3, 10 V. Magnetic-field immunity BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips and interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. This power supply is a component for installation in final equipment. Reconfirm the completed equipment’s EMC compliance and medical-system suitability; component approval and primary-secondary insulation do not establish every protection measure of the complete system. Weight, Reliability and Catalogue Reference Single-unit catalogue weight 56 g (0.056 kg), explicitly listed in PACKING. This is a catalogue unit-weight reference, not a measured shipping weight. Packing reference 240 pieces / 14.4 kg / 0.94 CUFT. Minimum MTBF estimates 7319.8 thousand hours by Telcordia SR-332 (Bellcore); 1210.0 thousand hours by MIL-HDBK-217F at 25°C. Catalogue warranty 3-year manufacturer warranty, subject to the applicable terms. Specification version MPM-15-SPEC dated 2024-10-30; combined catalogue pages 9–12. Rating convention The displayed power, current and peak values preserve the catalogue’s printed precision. MTBF values are statistical estimates under the stated methods and are not a guaranteed operating life.

  Read more less

  $25.14

  View options

•

  View options

  MEAN WELL MPM-15 series: Encapsulated Medical AC/DC Power Supply - MPM-15-15

  MEAN WELL MPM-15-15 is an encapsulated PCB-mount medical AC/DC power module with a 15 V output rated at 1 A and 15 W. It accepts 80–264 VAC or 113–370 VDC, requires no minimum load, and provides Class II construction with 2 × MOPP primary-secondary isolation. Peak operation and BF applications are subject to the conditions below. Product Datasheet Download MEAN WELL MPM-15 Datasheet (PDF) The MPM-15 section is on PDF pages 9, 10, 11, 12. Refer to the complete mechanical drawings and notes when planning installation. Model and Medical Application Exact model MPM-15-15; encapsulated PCB pin-type AC/DC power module. The final model-code field identifies the nominal DC output voltage. Electrical protection class Class II, double insulation, no functional-ground (FG) connection. Patient-protection insulation Primary-to-secondary isolation: 2 × MOPP. BF application Suitable for BF applications with appropriate system consideration; the power module alone does not certify a completed medical device as BF. Typical applications Portable medical devices, mobile clinical workstations, medical computer monitors and examination instruments. The plastic enclosure and internal potting support compact construction, heat dissipation and vibration resistance. The reviewed pages do not specify an IP ingress-protection rating; comply with the stated non-condensing humidity conditions. Model-Specific DC Output DC voltage 15 V. Rated continuous current 1 A. Current range 0–1 A; no minimum load required. Rated output power 15 W, as listed for this exact model. Peak current 1.1 A, subject to the peak-load conditions below. Peak output power 16.5 W, for a maximum of 10 seconds and subject to all duty-cycle and average-power limits. Ripple and noise, maximum 180 mVp-p. Voltage tolerance ±2.0%; includes set-up tolerance, line regulation and load regulation. Line regulation ±0.3%. Load regulation ±0.5%. Efficiency, typical 87%. Peak loading is limited to 33% maximum duty cycle within every 30 seconds, and average output power must not exceed this model’s rated output power. The 10-second peak specification does not remove either limit; reduce the duty further when the remaining load would otherwise exceed the permitted average. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Input and Start-Up AC input range 80–264 VAC, subject to low-input derating. DC input range 113–370 VDC. AC frequency 47–440 Hz. Input current, typical 0.6 A at 115 VAC; 0.3 A at 230 VAC. Cold-start inrush, typical 20 A at 115 VAC; 45 A at 230 VAC. No-load input consumption Less than 0.1 W. Set-up and rise time 1500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, at full load. Hold-up time, typical 40 ms at 230 VAC; 10 ms at 115 VAC, at full load. Touch current Less than 80 µA at 264 VAC; measured from primary input to DC output. Switching frequency reference 100 kHz in the block diagram. Unless specifically stated otherwise, catalogue parameters are measured at 230 VAC input, rated load and 25°C ambient. Typical figures are not guaranteed minimum performance values. Protection Short circuit and overload Overload protection operates at 110–150% of rated output power. Hiccup mode recovers automatically after the fault is removed; short-circuit protection is also listed. Overvoltage threshold 17.3–20.3 V. Overvoltage action Output voltage shuts off and is clamped by a zener diode. Overtemperature action Output shuts down and recovers automatically after temperature falls. The overload-protection threshold is not a continuous output rating or an additional peak-load allowance. Observe the separately stated model-specific output and peak-load limits. Cooling, Derating and Environment Working ambient range -40 to +85°C, with load derating. Cooling and curve orientation Fanless operation; the published ambient/load curve is for horizontal mounting. Temperature/load curve for this model -40°C: 100%; 60°C: 100%; 70°C: 50%; 85°C: 30%. Curve selection 12–24 V output-voltage curve. Input-voltage/load curve At 60 Hz: 80% load at 80 VAC, rising to 100% at 100 VAC; 100% plateau from 100 to 264 VAC. Operating humidity 20–90% RH, non-condensing. Storage conditions −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Operating altitude Up to 5,000 m. High-altitude temperature reduction Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless module. Use the complete temperature and input-voltage curves for intermediate conditions, and apply input, temperature, altitude and peak-load restrictions together. A wide operating-temperature range does not mean full rated load throughout that range. Mechanical Dimensions and PCB Connections Dimensions, L × W × H 52.4 × 27.2 × 24 mm. Mechanical case No.219A; drawing dimensions in millimetres, general tolerance ±0.5 mm. Input pins, bottom view As drawn with the input pins on the left: upper pin AC/N; lower pin AC/L. Output pins, bottom view As drawn with the output pins on the right: upper pin −V; lower pin +V. Pin-column spacing 45 mm between input and output pin columns; input column is 3.4 mm from the left body edge. Pin spacing and edge reference Input-pair spacing 20.8 mm; output-pair spacing 8 mm; upper pins are 3.2 mm from the top body edge. Pin projection 3.5 ±1 mm. Pin dimension 1.04 mm is marked in the side drawing; explicitly identified as pin diameter. Soldering limits Wave soldering: 265°C for 5 seconds maximum; manual soldering: 390°C for 3 seconds maximum. Use the bottom-view pin arrangement rather than a top-view assumption when designing the PCB footprint. Follow the manufacturer’s installation instructions and the drawing for clearances and soldering. The assigned pages list no complete order code for a separate mating connector, mounting bracket or accessory kit; no such item is implied as supplied. Safety and EMC Conditions Listed medical safety approvals IEC60601-1:2005+A1; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005/A2:2021; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Other safety applicability IEC60335-1:2010/AMD2:2016 and Dekra BS EN/EN60335-1:2012+A11+A13+A1+A14+A2+A15 are also listed as approved. Input-to-output withstand voltage 4 kVAC. Input-to-output insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted and radiated emissions BS EN/EN55011 (CISPR11), Class B, for Class II configuration. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3 is listed; no numerical test level is specified. Immunity framework BS EN/EN55035 and BS EN/EN60601-1-2. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 3, 10 V/m over 80 MHz–2.7 GHz; Table 9 proximity-field levels 9–28 V/m over 385 MHz–5.78 GHz. EFT / burst BS EN/EN61000-4-4: Level 3, 2 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV line-to-line. Conducted susceptibility BS EN/EN61000-4-6: Level 3, 10 V. Magnetic-field immunity BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips and interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. This power supply is a component for installation in final equipment. Reconfirm the completed equipment’s EMC compliance and medical-system suitability; component approval and primary-secondary insulation do not establish every protection measure of the complete system. Weight, Reliability and Catalogue Reference Single-unit catalogue weight 56 g (0.056 kg), explicitly listed in PACKING. This is a catalogue unit-weight reference, not a measured shipping weight. Packing reference 240 pieces / 14.4 kg / 0.94 CUFT. Minimum MTBF estimates 7319.8 thousand hours by Telcordia SR-332 (Bellcore); 1210.0 thousand hours by MIL-HDBK-217F at 25°C. Catalogue warranty 3-year manufacturer warranty, subject to the applicable terms. Specification version MPM-15-SPEC dated 2024-10-30; combined catalogue pages 9–12. Rating convention The displayed power, current and peak values preserve the catalogue’s printed precision. MTBF values are statistical estimates under the stated methods and are not a guaranteed operating life.

  Read more less

  $25.14

  View options

•

  View options

  MEAN WELL MPM-15 series: Encapsulated Medical AC/DC Power Supply - MPM-15-12

  MEAN WELL MPM-15-12 is an encapsulated PCB-mount medical AC/DC power module with a 12 V output rated at 1.25 A and 15 W. It accepts 80–264 VAC or 113–370 VDC, requires no minimum load, and provides Class II construction with 2 × MOPP primary-secondary isolation. Peak operation and BF applications are subject to the conditions below. Product Datasheet Download MEAN WELL MPM-15 Datasheet (PDF) The MPM-15 section is on PDF pages 9, 10, 11, 12. Refer to the complete mechanical drawings and notes when planning installation. Model and Medical Application Exact model MPM-15-12; encapsulated PCB pin-type AC/DC power module. The final model-code field identifies the nominal DC output voltage. Electrical protection class Class II, double insulation, no functional-ground (FG) connection. Patient-protection insulation Primary-to-secondary isolation: 2 × MOPP. BF application Suitable for BF applications with appropriate system consideration; the power module alone does not certify a completed medical device as BF. Typical applications Portable medical devices, mobile clinical workstations, medical computer monitors and examination instruments. The plastic enclosure and internal potting support compact construction, heat dissipation and vibration resistance. The reviewed pages do not specify an IP ingress-protection rating; comply with the stated non-condensing humidity conditions. Model-Specific DC Output DC voltage 12 V. Rated continuous current 1.25 A. Current range 0–1.25 A; no minimum load required. Rated output power 15 W, as listed for this exact model. Peak current 1.38 A, subject to the peak-load conditions below. Peak output power 16.6 W, for a maximum of 10 seconds and subject to all duty-cycle and average-power limits. Ripple and noise, maximum 150 mVp-p. Voltage tolerance ±2.0%; includes set-up tolerance, line regulation and load regulation. Line regulation ±0.3%. Load regulation ±0.5%. Efficiency, typical 86.5%. Peak loading is limited to 33% maximum duty cycle within every 30 seconds, and average output power must not exceed this model’s rated output power. The 10-second peak specification does not remove either limit; reduce the duty further when the remaining load would otherwise exceed the permitted average. Ripple and noise are measured at 20 MHz bandwidth with a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Input and Start-Up AC input range 80–264 VAC, subject to low-input derating. DC input range 113–370 VDC. AC frequency 47–440 Hz. Input current, typical 0.6 A at 115 VAC; 0.3 A at 230 VAC. Cold-start inrush, typical 20 A at 115 VAC; 45 A at 230 VAC. No-load input consumption Less than 0.1 W. Set-up and rise time 1500 ms set-up and 30 ms rise at both 230 VAC and 115 VAC, at full load. Hold-up time, typical 40 ms at 230 VAC; 10 ms at 115 VAC, at full load. Touch current Less than 80 µA at 264 VAC; measured from primary input to DC output. Switching frequency reference 100 kHz in the block diagram. Unless specifically stated otherwise, catalogue parameters are measured at 230 VAC input, rated load and 25°C ambient. Typical figures are not guaranteed minimum performance values. Protection Short circuit and overload Overload protection operates at 110–150% of rated output power. Hiccup mode recovers automatically after the fault is removed; short-circuit protection is also listed. Overvoltage threshold 13.8–16.2 V. Overvoltage action Output voltage shuts off and is clamped by a zener diode. Overtemperature action Output shuts down and recovers automatically after temperature falls. The overload-protection threshold is not a continuous output rating or an additional peak-load allowance. Observe the separately stated model-specific output and peak-load limits. Cooling, Derating and Environment Working ambient range -40 to +85°C, with load derating. Cooling and curve orientation Fanless operation; the published ambient/load curve is for horizontal mounting. Temperature/load curve for this model -40°C: 100%; 60°C: 100%; 70°C: 50%; 85°C: 30%. Curve selection 12–24 V output-voltage curve. Input-voltage/load curve At 60 Hz: 80% load at 80 VAC, rising to 100% at 100 VAC; 100% plateau from 100 to 264 VAC. Operating humidity 20–90% RH, non-condensing. Storage conditions −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–60°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z. Operating altitude Up to 5,000 m. High-altitude temperature reduction Above 2,000 m, reduce the allowable ambient temperature by 3.5°C per additional 1,000 m for this fanless module. Use the complete temperature and input-voltage curves for intermediate conditions, and apply input, temperature, altitude and peak-load restrictions together. A wide operating-temperature range does not mean full rated load throughout that range. Mechanical Dimensions and PCB Connections Dimensions, L × W × H 52.4 × 27.2 × 24 mm. Mechanical case No.219A; drawing dimensions in millimetres, general tolerance ±0.5 mm. Input pins, bottom view As drawn with the input pins on the left: upper pin AC/N; lower pin AC/L. Output pins, bottom view As drawn with the output pins on the right: upper pin −V; lower pin +V. Pin-column spacing 45 mm between input and output pin columns; input column is 3.4 mm from the left body edge. Pin spacing and edge reference Input-pair spacing 20.8 mm; output-pair spacing 8 mm; upper pins are 3.2 mm from the top body edge. Pin projection 3.5 ±1 mm. Pin dimension 1.04 mm is marked in the side drawing; explicitly identified as pin diameter. Soldering limits Wave soldering: 265°C for 5 seconds maximum; manual soldering: 390°C for 3 seconds maximum. Use the bottom-view pin arrangement rather than a top-view assumption when designing the PCB footprint. Follow the manufacturer’s installation instructions and the drawing for clearances and soldering. The assigned pages list no complete order code for a separate mating connector, mounting bracket or accessory kit; no such item is implied as supplied. Safety and EMC Conditions Listed medical safety approvals IEC60601-1:2005+A1; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005/A2:2021; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Other safety applicability IEC60335-1:2010/AMD2:2016 and Dekra BS EN/EN60335-1:2012+A11+A13+A1+A14+A2+A15 are also listed as approved. Input-to-output withstand voltage 4 kVAC. Input-to-output insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted and radiated emissions BS EN/EN55011 (CISPR11), Class B, for Class II configuration. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3 is listed; no numerical test level is specified. Immunity framework BS EN/EN55035 and BS EN/EN60601-1-2. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 3, 10 V/m over 80 MHz–2.7 GHz; Table 9 proximity-field levels 9–28 V/m over 385 MHz–5.78 GHz. EFT / burst BS EN/EN61000-4-4: Level 3, 2 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV line-to-line. Conducted susceptibility BS EN/EN61000-4-6: Level 3, 10 V. Magnetic-field immunity BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips and interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. This power supply is a component for installation in final equipment. Reconfirm the completed equipment’s EMC compliance and medical-system suitability; component approval and primary-secondary insulation do not establish every protection measure of the complete system. Weight, Reliability and Catalogue Reference Single-unit catalogue weight 56 g (0.056 kg), explicitly listed in PACKING. This is a catalogue unit-weight reference, not a measured shipping weight. Packing reference 240 pieces / 14.4 kg / 0.94 CUFT. Minimum MTBF estimates 7319.8 thousand hours by Telcordia SR-332 (Bellcore); 1210.0 thousand hours by MIL-HDBK-217F at 25°C. Catalogue warranty 3-year manufacturer warranty, subject to the applicable terms. Specification version MPM-15-SPEC dated 2024-10-30; combined catalogue pages 9–12. Rating convention The displayed power, current and peak values preserve the catalogue’s printed precision. MTBF values are statistical estimates under the stated methods and are not a guaranteed operating life.

  Read more less

  $24.15

  View options
