PWM Series, SPWM Series: PWM Output LED Driver (Constant Voltage)

55 products

MEAN WELL PWM & SPWM Series LED Drivers

MEAN WELL PWM & SPWM Series LED Power Supplies

  • Series Overview
  • Technical Specifications
  • Power Range & Models
  • Smart Control Protocols

Series Overview & Core Features

The PWM and SPWM series are dedicated Constant Voltage (CV) LED drivers that output a high-frequency Pulse Width Modulation (PWM) style voltage. This unique architecture is specifically designed to guarantee color temperature accuracy and brightness uniformity across parallel LED strips, even at extremely low dimming levels.

  • PWM Series (Standard & Smart): The foundational lineup featuring high-frequency dimming (up to 4kHz) to eliminate visible flicker and meet strict IEEE-1789 health standards. It is available in standard analog dimming as well as digital protocols.
  • SPWM Series (Next-Gen Smart): The next evolution of PWM drivers focusing heavily on flawless deep dimming (down to 0.1% ~ 1%) and cutting-edge encrypted native protocols (like KNX Data Secure).
  • IP67 & Class II Design: Both series are fully encapsulated in flame-retardant plastic housings (IP67) with no earth pin (Class II), ensuring safe installation in damp, wet, or indoor architectural locations.
  • Active PFC: Built-in active Power Factor Correction guarantees high energy efficiency and global regulatory compliance.

Technical Specifications

Parameter Specification Detail
Input Voltage 90 ~ 305VAC (Universal) / 100 ~ 305VAC (SPWM)
Output Mode Constant Voltage (CV) - PWM Style Output
IP Rating IP67 (Fully potted)
Dimming Range Deep dimming capability (SPWM reaches 0.1% ~ 1%)
Protections Short circuit / Overload / Over voltage / Over temperature
Safety Standards UL8750, ENEC, CE, CB, UKCA, EAC, KNX

Series Power Range & Availability

Select the series based on your required wattage and smart integration needs. Typical output voltages include 12V, 24V, 36V, and 48V.

Product Branch Available Wattages Core Characteristic
Standard PWM 40W, 60W, 90W, 120W, 200W Standard 3-in-1 dimming or DALI-2 control.
PWM-KN (KNX) 60W, 120W, 200W Integrated KNX protocol. Connects directly to the KNX bus.
PWM-IoT (Bluetooth) 120W, 200W Wireless Bluetooth Mesh control via smartphones.
SPWM (Smart PWM) 120W Next-gen deep dimming with advanced secure protocols.
Application Tip: The PWM and SPWM architectures are the absolute best choice for architectural cove lighting, LED tape lighting, and decorative installations where dead spots or color shifting at low dimming levels are unacceptable.

Smart Integration & Dimming Protocols

To ensure compatibility with your building's control system, select the appropriate model suffix. By embedding the control module directly into the driver, these units eliminate the need for external gateways.

Control Protocol / Suffix Features & Best Usage
Blank
(e.g., PWM-120-24) 		3-in-1 Dimming (0~10V, PWM signal, or Resistance). Ideal for traditional commercial dimming systems and wall sliders.
DA / DA2
(e.g., PWM-120-24DA2) 		DALI / DALI-2. The latest standard in digital lighting control, offering two-way communication for advanced lighting networks in modern office buildings.
KN / KNX Data Secure
(e.g., SPWM-120-24KN) 		KNX Protocol. Direct integration into KNX building automation. The SPWM series offers KNX Data Secure, an encrypted version preventing unauthorized access in secure commercial and hotel networks.
BLE / TY1 / SVA
(IoT Bluetooth Mesh) 		Wireless Mesh Networking. Programmable via Casambi (BLE), Tuya (TY1), or Silvair (SVA) smartphone apps. Perfect for retrofitting existing spaces without running new control wires.
Selection Note: The IoT models allow you to control LED strips directly from a wireless wall switch or mobile device, making them incredibly versatile for high-end residential upgrades and rapid commercial deployments.

Show previous products

  • PWM-90-12

    View options

    MEAN WELL PWM-90 series: 3-in-1 dimmable PWM output LED driver - PWM-90-12

    MEAN WELL PWM-90-12 MEAN WELL PWM-90-12 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 12 V LED strips, rated 7.5 A and 90 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL PWM-90 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 44–51; specifications on page 45. Model, output and control Parameter Specification Model PWM-90-12 Series and function code PWM-90; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 12 V Rated output current 7.5 A Rated output power 90 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM− Dimming range Catalog range 0–100%. Approximate minimum output duty 0.15% at 0.6 VDC, 6 kΩ (one driver), or 6% duty of the external 10 V PWM signal; lower input can dim the output to 0%. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Use a controller with capacity of at least 0.15 mA per PWM driver, as required by the installation instructions. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 88% at the catalog test conditions Typical power factor >0.98 / 115 VAC; >0.96 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.95 A / 115 VAC; 0.5 A / 230 VAC; 0.4 A / 277 VAC Inrush current Cold start: 60 A typical at 230 VAC; 550 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 3 / 6 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 15–17 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 (cover identifies Type HL for this Blank/DA2 version); CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. This 12 V model is excluded from the catalog Class 2 claim. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. BIS IS15885 (Part 2/Sec13) is listed for this model/version. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2394.5 / 224.2 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Dimensions and installation Parameter Specification Dimensions 171 × 63 × 37.5 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DIM+ purple, DIM− pink. Do not connect DIM− to negative LED output. Cable specification Input: SJTW 18 AWG × 2C; LED output: SJTW 16 AWG × 2C. Control: UL2464 18 AWG × 2C. Lead runs: 300 ±20 mm; refer to the mechanical drawing for breakout lengths. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm controller compatibility; the catalog calls for 0.15 mA controller capacity per PWM driver. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Dimming isolation Treat the analog dimming circuit as not isolated from the secondary output, as specified in the LED installation manual; provide appropriate system insulation. Weight 770 g; catalog packing reference per unit (0.77 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $91.18

    View options

  • PWM-60-24DA2

    View options

    MEAN WELL PWM-60 series: DALI-2 PWM output LED driver - PWM-60-24DA2

    MEAN WELL PWM-60-24DA2 MEAN WELL PWM-60-24DA2 is a DALI-2 constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 2.5 A and 60 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact DA2 control version and apply the input and thermal derating below. Download MEAN WELL PWM-60 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 36–43; specifications on page 37. Model, output and control Parameter Specification Model PWM-60-24DA2 Series and function code PWM-60; DA2: DALI-2 DT6 control Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 2.5 A Rated output power 60 W Output PWM frequency 2.5 kHz, fixed typical output waveform frequency. Dimming interface DALI-2 DT6 Dimming range Catalog range 0–100%; DALI first step/minimum output duty approximately 0.2%. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 89% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.8 A / 115 VAC; 0.4 A / 230 VAC; 0.32 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 28–34 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI operation Apply the DALI signal between DA+ and DA−; DT6 brightness control. DALI supports 16 groups and 64 addresses. The catalog identifies the interface as primary-side; maintain the required insulation. DALI polarity The DA/DA2 DALI pair is polarity-insensitive; the wire labels do not imply a polar DC output. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. BIS IS15885 (Part 2/Sec13) is listed for this model/version. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Input/DALI and output/DALI: 1.5 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2626.6 / 227.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. DALI standards IEC62386-101, -102, -207 (DT6) and Part 251; apply only the selected mode and the supplied DA2 version. Emergency-lighting scope This DA2 version is listed for BS EN/EN61347-2-13 Appendix J emergency installations (EL), with AC input 100–240 VAC. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DA+ purple, DA− pink. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm compatibility with this DALI-2 interface. The catalog’s general installation note cites 0.15 mA per PWM driver; this is not a complete DALI bus/controller sizing specification. Follow the dedicated interface wiring and controller requirements. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $80.34

    View options

  • PWM-60-12DA2

    View options

    MEAN WELL PWM-60 series: DALI-2 PWM output LED driver - PWM-60-12DA2

    MEAN WELL PWM-60-12DA2 MEAN WELL PWM-60-12DA2 is a DALI-2 constant-voltage PWM output LED driver for compatible 12 V LED strips, rated 5 A and 60 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact DA2 control version and apply the input and thermal derating below. Download MEAN WELL PWM-60 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 36–43; specifications on page 37. Model, output and control Parameter Specification Model PWM-60-12DA2 Series and function code PWM-60; DA2: DALI-2 DT6 control Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 12 V Rated output current 5 A Rated output power 60 W Output PWM frequency 2.5 kHz, fixed typical output waveform frequency. Dimming interface DALI-2 DT6 Dimming range Catalog range 0–100%; DALI first step/minimum output duty approximately 0.2%. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 86% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.8 A / 115 VAC; 0.4 A / 230 VAC; 0.32 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 15–17 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI operation Apply the DALI signal between DA+ and DA−; DT6 brightness control. DALI supports 16 groups and 64 addresses. The catalog identifies the interface as primary-side; maintain the required insulation. DALI polarity The DA/DA2 DALI pair is polarity-insensitive; the wire labels do not imply a polar DC output. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. BIS IS15885 (Part 2/Sec13) is listed for this model/version. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Input/DALI and output/DALI: 1.5 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2626.6 / 227.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. DALI standards IEC62386-101, -102, -207 (DT6) and Part 251; apply only the selected mode and the supplied DA2 version. Emergency-lighting scope This DA2 version is listed for BS EN/EN61347-2-13 Appendix J emergency installations (EL), with AC input 100–240 VAC. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DA+ purple, DA− pink. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm compatibility with this DALI-2 interface. The catalog’s general installation note cites 0.15 mA per PWM driver; this is not a complete DALI bus/controller sizing specification. Follow the dedicated interface wiring and controller requirements. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $80.34

    View options

  • PWM-60-24DA

    View options

    MEAN WELL PWM-60 series: DALI PWM output LED driver - PWM-60-24DA

    MEAN WELL PWM-60-24DA MEAN WELL PWM-60-24DA is a DALI constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 2.5 A and 60 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact DA control version and apply the input and thermal derating below. Download MEAN WELL PWM-60 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 36–43; specifications on page 37. Model, output and control Parameter Specification Model PWM-60-24DA Series and function code PWM-60; DA: DALI control Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 2.5 A Rated output power 60 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface DALI DT6 Dimming range Catalog range 0–100%; DALI first step/minimum output duty approximately 0.2%. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 89% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.8 A / 115 VAC; 0.4 A / 230 VAC; 0.32 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 28–34 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI operation Apply the DALI signal between DA+ and DA−; DT6 brightness control. DALI supports 16 groups and 64 addresses. The catalog identifies the interface as primary-side; maintain the required insulation. DALI polarity The DA/DA2 DALI pair is polarity-insensitive; the wire labels do not imply a polar DC output. Safety, insulation and compliance Parameter Specification Safety and design standards CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Input/DALI and output/DALI: 1.5 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2626.6 / 227.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. DALI standards IEC62386-101, -102, -207 (DT6) and Part 251; apply only the selected mode and the supplied DA version. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DA+ purple, DA− pink. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm compatibility with this DALI interface. The catalog’s general installation note cites 0.15 mA per PWM driver; this is not a complete DALI bus/controller sizing specification. Follow the dedicated interface wiring and controller requirements. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $88.71

    View options

  • PWM-60-12DA

    View options

    MEAN WELL PWM-60 series: DALI PWM output LED driver - PWM-60-12DA

    MEAN WELL PWM-60-12DA MEAN WELL PWM-60-12DA is a DALI constant-voltage PWM output LED driver for compatible 12 V LED strips, rated 5 A and 60 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact DA control version and apply the input and thermal derating below. Download MEAN WELL PWM-60 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 36–43; specifications on page 37. Model, output and control Parameter Specification Model PWM-60-12DA Series and function code PWM-60; DA: DALI control Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 12 V Rated output current 5 A Rated output power 60 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface DALI DT6 Dimming range Catalog range 0–100%; DALI first step/minimum output duty approximately 0.2%. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 86% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.8 A / 115 VAC; 0.4 A / 230 VAC; 0.32 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 15–17 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI operation Apply the DALI signal between DA+ and DA−; DT6 brightness control. DALI supports 16 groups and 64 addresses. The catalog identifies the interface as primary-side; maintain the required insulation. DALI polarity The DA/DA2 DALI pair is polarity-insensitive; the wire labels do not imply a polar DC output. Safety, insulation and compliance Parameter Specification Safety and design standards CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Input/DALI and output/DALI: 1.5 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2626.6 / 227.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. DALI standards IEC62386-101, -102, -207 (DT6) and Part 251; apply only the selected mode and the supplied DA version. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DA+ purple, DA− pink. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm compatibility with this DALI interface. The catalog’s general installation note cites 0.15 mA per PWM driver; this is not a complete DALI bus/controller sizing specification. Follow the dedicated interface wiring and controller requirements. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $88.71

    View options

  • PWM-60-48

    View options

    MEAN WELL PWM-60 series: 3-in-1 dimmable PWM output LED driver - PWM-60-48

    MEAN WELL PWM-60-48 MEAN WELL PWM-60-48 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 48 V LED strips, rated 1.25 A and 60 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL PWM-60 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 36–43; specifications on page 37. Model, output and control Parameter Specification Model PWM-60-48 Series and function code PWM-60; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 48 V Rated output current 1.25 A Rated output power 60 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM− Dimming range Catalog range 0–100% including dim-to-off. The figure marks approximately 0.15% output duty, but its footnote states an approximately 6% minimum and undefined output between 0% and 6%. These statements conflict: neither value is presented here as a confirmed minimum guarantee, and a continuous 0–6% range must not be assumed. Confirm the minimum stable level for the supplied revision with MEAN WELL. Dim-to-off is specified at about 0 VDC, 0 kΩ, or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Use a controller with capacity of at least 0.15 mA per PWM driver, as required by the installation instructions. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 90% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.8 A / 115 VAC; 0.4 A / 230 VAC; 0.32 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 54–60 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. BIS IS15885 (Part 2/Sec13) is listed for this model/version. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2626.6 / 227.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DIM+ purple, DIM− pink. Do not connect DIM− to negative LED output. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm controller compatibility; the catalog calls for 0.15 mA controller capacity per PWM driver. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Dimming isolation Treat the analog dimming circuit as not isolated from the secondary output, as specified in the LED installation manual; provide appropriate system insulation. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $66.54

    View options

  • PWM-60-36

    View options

    MEAN WELL PWM-60 series: 3-in-1 dimmable PWM output LED driver - PWM-60-36

    MEAN WELL PWM-60-36 MEAN WELL PWM-60-36 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 36 V LED strips, rated 1.67 A and 60.12 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL PWM-60 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 36–43; specifications on page 37. Model, output and control Parameter Specification Model PWM-60-36 Series and function code PWM-60; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 36 V Rated output current 1.67 A Rated output power 60.12 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM− Dimming range Catalog range 0–100% including dim-to-off. The figure marks approximately 0.15% output duty, but its footnote states an approximately 6% minimum and undefined output between 0% and 6%. These statements conflict: neither value is presented here as a confirmed minimum guarantee, and a continuous 0–6% range must not be assumed. Confirm the minimum stable level for the supplied revision with MEAN WELL. Dim-to-off is specified at about 0 VDC, 0 kΩ, or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Use a controller with capacity of at least 0.15 mA per PWM driver, as required by the installation instructions. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 90% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.8 A / 115 VAC; 0.4 A / 230 VAC; 0.32 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 41–46 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2626.6 / 227.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DIM+ purple, DIM− pink. Do not connect DIM− to negative LED output. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm controller compatibility; the catalog calls for 0.15 mA controller capacity per PWM driver. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Dimming isolation Treat the analog dimming circuit as not isolated from the secondary output, as specified in the LED installation manual; provide appropriate system insulation. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $66.54

    View options

  • PWM-60-24

    View options

    MEAN WELL PWM-60 series: 3-in-1 dimmable PWM output LED driver - PWM-60-24

    MEAN WELL PWM-60-24 MEAN WELL PWM-60-24 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 2.5 A and 60 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL PWM-60 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 36–43; specifications on page 37. Model, output and control Parameter Specification Model PWM-60-24 Series and function code PWM-60; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 2.5 A Rated output power 60 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM− Dimming range Catalog range 0–100% including dim-to-off. The figure marks approximately 0.15% output duty, but its footnote states an approximately 6% minimum and undefined output between 0% and 6%. These statements conflict: neither value is presented here as a confirmed minimum guarantee, and a continuous 0–6% range must not be assumed. Confirm the minimum stable level for the supplied revision with MEAN WELL. Dim-to-off is specified at about 0 VDC, 0 kΩ, or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Use a controller with capacity of at least 0.15 mA per PWM driver, as required by the installation instructions. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 89% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.8 A / 115 VAC; 0.4 A / 230 VAC; 0.32 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 28–34 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. BIS IS15885 (Part 2/Sec13) is listed for this model/version. UL879 is also listed. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2626.6 / 227.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DIM+ purple, DIM− pink. Do not connect DIM− to negative LED output. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm controller compatibility; the catalog calls for 0.15 mA controller capacity per PWM driver. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Dimming isolation Treat the analog dimming circuit as not isolated from the secondary output, as specified in the LED installation manual; provide appropriate system insulation. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $66.54

    View options

  • PWM-60-12

    View options

    MEAN WELL PWM-60 series: 3-in-1 dimmable PWM output LED driver - PWM-60-12

    MEAN WELL PWM-60-12 MEAN WELL PWM-60-12 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 12 V LED strips, rated 5 A and 60 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL PWM-60 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 36–43; specifications on page 37. Model, output and control Parameter Specification Model PWM-60-12 Series and function code PWM-60; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 12 V Rated output current 5 A Rated output power 60 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM− Dimming range Catalog range 0–100% including dim-to-off. The figure marks approximately 0.15% output duty, but its footnote states an approximately 6% minimum and undefined output between 0% and 6%. These statements conflict: neither value is presented here as a confirmed minimum guarantee, and a continuous 0–6% range must not be assumed. Confirm the minimum stable level for the supplied revision with MEAN WELL. Dim-to-off is specified at about 0 VDC, 0 kΩ, or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Use a controller with capacity of at least 0.15 mA per PWM driver, as required by the installation instructions. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 86% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.8 A / 115 VAC; 0.4 A / 230 VAC; 0.32 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 15–17 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. BIS IS15885 (Part 2/Sec13) is listed for this model/version. UL879 is also listed. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2626.6 / 227.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DIM+ purple, DIM− pink. Do not connect DIM− to negative LED output. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm controller compatibility; the catalog calls for 0.15 mA controller capacity per PWM driver. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Dimming isolation Treat the analog dimming circuit as not isolated from the secondary output, as specified in the LED installation manual; provide appropriate system insulation. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $66.54

    View options

  • PWM-40-48

    View options

    MEAN WELL PWM-40 series: 3-in-1 dimmable PWM output LED driver - PWM-40-48

    MEAN WELL PWM-40-48 MEAN WELL PWM-40-48 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 48 V LED strips, rated 0.84 A and 40.32 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL PWM-40 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 28–35; specifications on page 29. Model, output and control Parameter Specification Model PWM-40-48 Series and function code PWM-40; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 48 V Rated output current 0.84 A Rated output power 40.32 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM− Dimming range Catalog range 0–100% including dim-to-off. The figure marks approximately 0.15% output duty, but its footnote states an approximately 6% minimum and undefined output between 0% and 6%. These statements conflict: neither value is presented here as a confirmed minimum guarantee, and a continuous 0–6% range must not be assumed. Confirm the minimum stable level for the supplied revision with MEAN WELL. Dim-to-off is specified at about 0 VDC, 0 kΩ, or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Use a controller with capacity of at least 0.15 mA per PWM driver, as required by the installation instructions. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 90% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.6 A / 115 VAC; 0.3 A / 230 VAC; 0.25 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 54–60 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2625.4 / 226.4 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DIM+ purple, DIM− pink. Do not connect DIM− to negative LED output. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm controller compatibility; the catalog calls for 0.15 mA controller capacity per PWM driver. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Dimming isolation Treat the analog dimming circuit as not isolated from the secondary output, as specified in the LED installation manual; provide appropriate system insulation. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $63.09

    View options

  • PWM-40-36

    View options

    MEAN WELL PWM-40 series: 3-in-1 dimmable PWM output LED driver - PWM-40-36

    MEAN WELL PWM-40-36 MEAN WELL PWM-40-36 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 36 V LED strips, rated 1.12 A and 40.32 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL PWM-40 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 28–35; specifications on page 29. Model, output and control Parameter Specification Model PWM-40-36 Series and function code PWM-40; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 36 V Rated output current 1.12 A Rated output power 40.32 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM− Dimming range Catalog range 0–100% including dim-to-off. The figure marks approximately 0.15% output duty, but its footnote states an approximately 6% minimum and undefined output between 0% and 6%. These statements conflict: neither value is presented here as a confirmed minimum guarantee, and a continuous 0–6% range must not be assumed. Confirm the minimum stable level for the supplied revision with MEAN WELL. Dim-to-off is specified at about 0 VDC, 0 kΩ, or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Use a controller with capacity of at least 0.15 mA per PWM driver, as required by the installation instructions. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 90% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.6 A / 115 VAC; 0.3 A / 230 VAC; 0.25 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 41–46 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2625.4 / 226.4 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DIM+ purple, DIM− pink. Do not connect DIM− to negative LED output. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm controller compatibility; the catalog calls for 0.15 mA controller capacity per PWM driver. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Dimming isolation Treat the analog dimming circuit as not isolated from the secondary output, as specified in the LED installation manual; provide appropriate system insulation. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $63.09

    View options

  • PWM-40-24

    View options

    MEAN WELL PWM-40 series: 3-in-1 dimmable PWM output LED driver - PWM-40-24

    MEAN WELL PWM-40-24 MEAN WELL PWM-40-24 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 1.67 A and 40.08 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL PWM-40 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 28–35; specifications on page 29. Model, output and control Parameter Specification Model PWM-40-24 Series and function code PWM-40; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 1.67 A Rated output power 40.08 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM− Dimming range Catalog range 0–100% including dim-to-off. The figure marks approximately 0.15% output duty, but its footnote states an approximately 6% minimum and undefined output between 0% and 6%. These statements conflict: neither value is presented here as a confirmed minimum guarantee, and a continuous 0–6% range must not be assumed. Confirm the minimum stable level for the supplied revision with MEAN WELL. Dim-to-off is specified at about 0 VDC, 0 kΩ, or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Use a controller with capacity of at least 0.15 mA per PWM driver, as required by the installation instructions. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 89% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.6 A / 115 VAC; 0.3 A / 230 VAC; 0.25 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 28–34 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. BIS IS15885 (Part 2/Sec13) is listed for this model/version. UL879 is also listed. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2625.4 / 226.4 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DIM+ purple, DIM− pink. Do not connect DIM− to negative LED output. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm controller compatibility; the catalog calls for 0.15 mA controller capacity per PWM driver. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Dimming isolation Treat the analog dimming circuit as not isolated from the secondary output, as specified in the LED installation manual; provide appropriate system insulation. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $63.09

    View options

  • PWM-40-12

    View options

    MEAN WELL PWM-40 series: 3-in-1 dimmable PWM output LED driver - PWM-40-12

    MEAN WELL PWM-40-12 MEAN WELL PWM-40-12 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 12 V LED strips, rated 3.34 A and 40.08 W. Its Class II plastic enclosure is fully encapsulated to IP67. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL PWM-40 Datasheet (PDF)Download MEAN WELL LED Installation Manual (PDF)Datasheet section: PDF pages 28–35; specifications on page 29. Model, output and control Parameter Specification Model PWM-40-12 Series and function code PWM-40; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 12 V Rated output current 3.34 A Rated output power 40.08 W Output PWM frequency 1.47 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM− Dimming range Catalog range 0–100% including dim-to-off. The figure marks approximately 0.15% output duty, but its footnote states an approximately 6% minimum and undefined output between 0% and 6%. These statements conflict: neither value is presented here as a confirmed minimum guarantee, and a continuous 0–6% range must not be assumed. Confirm the minimum stable level for the supplied revision with MEAN WELL. Dim-to-off is specified at about 0 VDC, 0 kΩ, or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Use a controller with capacity of at least 0.15 mA per PWM driver, as required by the installation instructions. Input and performance Parameter Specification Input voltage 90–305 VAC or 127–431 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 86% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <20% at ≥60% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 0.6 A / 115 VAC; 0.3 A / 230 VAC; 0.25 A / 277 VAC Inrush current Cold start: 50 A typical at 230 VAC; 270 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 9 / 16 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W no-load consumption. Setup and rise time 500 ms setup, 80 ms rise / 115 or 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 16 ms / 115 or 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 108–130% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 15–17 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −40 to +85°C; maximum case temperature +85°C, subject to derating. Cooling and load derating Free-air convection with recommended horizontal mounting. 100% through +50°C ambient, falling to 50% at +70°C. The −40°C to −25°C region is for 230 VAC input only. Keep Tc at or below +85°C; apply both ambient and input limits. Input/load derating At 60 Hz: 80% at 90 VAC, rising to 100% at 100 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 10–500 Hz, 5 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Type HL; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 and BS EN/EN62384, independent control gear; IP67; EAC TP TC 004; GB/T19510.1 and GB/T19510.213. BS EN/EN60335-1 is a design reference. Class II without FG; SELV output. Class 2 power unit. Type HL applications: Class I, Division 2 hazardous (classified) locations, subject to the listed installation conditions. BIS IS15885 (Part 2/Sec13) is listed for this model/version. UL879 is also listed. EMC Emission: BS EN/EN55015, BS EN/EN61000-3-2 Class C at ≥60% load, BS EN/EN61000-3-3, GB/T17743, GB17625.1 and EAC TP TC 020. Immunity: BS EN/EN61000-4-2/-3/-4/-5/-6/-8/-11, BS EN/EN61547 light-industry level, line-to-line surge 2 kV, and EAC TP TC 020. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 2625.4 / 226.4 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Dimensions and installation Parameter Specification Dimensions 150 × 53 × 35 mm (L × W × H); plastic housing. Lead connections Input: AC/L brown, AC/N blue. LED output: +V red, −V black. Control: DIM+ purple, DIM− pink. Do not connect DIM− to negative LED output. Cable specification Input: SJTW 18 AWG × 2C. LED output: UL2464 18 AWG × 2C. Control: UL2464 22 AWG × 2C. Input and output/control lead runs: 300 ±20 mm. Mounting Use the model-specific drawing; 4.5 mm mounting holes. Maintain recommended horizontal mounting and keep the marked Tc point below the case-temperature limit. Ingress protection Fully encapsulated IP67, for dry, damp or wet locations subject to the installation instructions. Suitable indoors or outdoors without direct sunlight; do not immerse or operate the product in water. Seal system interconnections and any waterproof connector against water ingress. Installation Disconnect the supply before installation or maintenance and prevent inadvertent reconnection. Keep ventilation clear, do not stack objects on the unit, and leave 10–15 cm clearance when the adjacent device is a heat source. Approved primary/secondary cables must carry at least the unit’s rated current. Nonstandard mounting or high ambient temperature requires derating. Confirm controller compatibility; the catalog calls for 0.15 mA controller capacity per PWM driver. Insulate system interconnections and enclose single-insulated wires; do not dismantle the driver. Damaged external cables must be replaced by the manufacturer, its service agent or an equally qualified person. Control-wire insulation The standalone control conductors are smaller than 18 AWG: use an SELV controller or network. Consult MEAN WELL for assistance before a FELV application. Dimming isolation Treat the analog dimming circuit as not isolated from the secondary output, as specified in the LED installation manual; provide appropriate system insulation. Weight 490 g; catalog packing reference per unit (0.49 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $63.09

    View options

  • SPWM-240-48DA2Q

    View options

    MEAN WELL SPWM-240 series: 4-channel DALI-2 PWM output LED driver - SPWM-240-48DA2Q

    MEAN WELL SPWM-240-48DA2Q MEAN WELL SPWM-240-48DA2Q is a 4-channel DALI-2 constant-voltage PWM output LED driver for compatible 48 V LED strips, rated 5 A and 240 W total across the configured output channels. Its slim Class II housing uses terminal-block connections. Select for the exact DA2Q control version and apply the input and thermal derating below. Download MEAN WELL SPWM-240 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 19–27; specifications on page 20. Model, output and control Parameter Specification Model SPWM-240-48DA2Q Series and function code SPWM-240; DA2Q: DALI-2 with four output channels and selectable DT6/DT8 modes Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 48 V Rated output current 5 A maximum, shared total rating across all output channels Rated output power 240 W maximum total; not per channel Voltage adjustment range 47–50 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz typical output waveform frequency. Dimming interface DALI-2 DT8 RGBW/tunable white, selectable DT6 modes and primary-side PUSH Dimming range Minimum dimming level 0.1% for this DALI-2 version. Input and performance Parameter Specification Input voltage 180–305 VAC or 255–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 94% at the catalog test conditions Typical power factor >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 230 VAC or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.3 A / 230 VAC; 1.1 A / 277 VAC Inrush current Cold start: 60 A typical at 230 VAC; 600 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 3 / 5 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 10 ms / 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 52–63 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +90°C; maximum case temperature +90°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. 100% load through +45°C ambient, falling to 60% at +50°C. Keep measured Tc at or below +90°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 180 VAC, rising to 100% at 200 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI/PUSH connection Use the DALI pair for DALI control. For primary-side PUSH, follow the dedicated wiring diagram: connect TB1 pin 5 (DA−/N) to neutral and a push button between line and pin 4 (DA+/L); PUSH2 uses a second button between line and pin 3 (PUSH/L). PUSH timing and limits Factory brightness 100%. Short press: 0.1–1 second; long press: >1 second. One common push button supports up to 10 drivers; maximum cable length to the last driver is 20 m. PUSH brightness Short press switches on/off. Long press dims up/down and stops at maximum or minimum dim (not dim-off); each next push reverses direction. Brightening from off is possible. Responses depend on the DIP mode below. DIP 1/2/3: ON / ON / ON 1 DT6 logical gear / 1 DALI address; use CH1 for the LED load. PUSH1 controls brightness; PUSH2 has no response. DIP 1/2/3: ON / ON / OFF 4 DT6 logical gears / 4 addresses; CH1–CH4 are separate brightness channels. PUSH1 controls all four synchronously; PUSH2 has no response. DIP 1/2/3: OFF / OFF / OFF Factory default RGBW DT8: 1 logical gear / 1 address. CH1 red, CH2 green, CH3 blue, CH4 white. PUSH1 controls brightness. PUSH2 short press selects white or RGB control; long press adjusts white (minimum 0) or changes RGB colour. DIP 1/2/3: ON / OFF / OFF 1 tunable-white Tc DT8 logical gear / 1 address: CH1 cool white + CH2 warm white; CH3/CH4 unused. PUSH1 controls brightness; PUSH2 short press switches on/off and long press performs Dim2Warm. DIP 1/2/3: OFF / ON / OFF 2 tunable-white Tc DT8 logical gears / 2 addresses: CH1 cool + CH2 warm, CH3 cool + CH4 warm. PUSH1 synchronizes brightness of both gears; PUSH2 synchronizes Dim2Warm and on/off. DIP 1/2/3: OFF / OFF / ON Mixed DT6 + tunable-white DT8: 2 logical gears / 2 addresses. CH3 is DT6; CH1 cool + CH2 warm form DT8, CH4 unused. PUSH1 responds only for DT6; PUSH2 responds only for DT8. Dim2Warm behavior Dimming down warms colour temperature; dimming up cools it. Long press stops at minimum dim, not dim-off; next push reverses direction. Operation from off is possible. RGBW duty and load limits Normalized colour control (factory default): a+b+c+d ≤100%. Extended colour control, enabled by DALI commands: sum ≤400%. In either mode, instantaneous total output power of all four channels must not exceed 240 W. The duty sum does not multiply the product power rating; size all connected channels for the shared 5 A total rating. Safety, insulation and compliance Parameter Specification Safety and design standards ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1801.3 / 155.5 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. DALI standards IEC62386-101, -102, -207 (DT6), -209 (DT8) and Part 251; apply only the selected mode and the supplied DA2Q version. Emergency-lighting scope DA2/DA2Q emergency operation is listed to BS EN/EN61347-2-13 Appendix J (EL), DC input 176–280 V. This is the emergency condition; the normal input specification remains as listed above. Dimensions and installation Parameter Specification Dimensions 380 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N, 3 PUSH/L, 4 DA+/L, 5 DA−/N. TB2: 1 +V, 2 +V, 3 CH1/−R/CW, 4 CH2/−G/WW, 5 CH3/−B/CW, 6 CH4/−W/WW. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 540 g; catalog packing reference per unit (0.54 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $122.72

    View options

  • SPWM-240-24DA2Q

    View options

    MEAN WELL SPWM-240 series: 4-channel DALI-2 PWM output LED driver - SPWM-240-24DA2Q

    MEAN WELL SPWM-240-24DA2Q MEAN WELL SPWM-240-24DA2Q is a 4-channel DALI-2 constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 10 A and 240 W total across the configured output channels. Its slim Class II housing uses terminal-block connections. Select for the exact DA2Q control version and apply the input and thermal derating below. Download MEAN WELL SPWM-240 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 19–27; specifications on page 20. Model, output and control Parameter Specification Model SPWM-240-24DA2Q Series and function code SPWM-240; DA2Q: DALI-2 with four output channels and selectable DT6/DT8 modes Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 10 A maximum, shared total rating across all output channels Rated output power 240 W maximum total; not per channel Voltage adjustment range 23–26 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz typical output waveform frequency. Dimming interface DALI-2 DT8 RGBW/tunable white, selectable DT6 modes and primary-side PUSH Dimming range Minimum dimming level 0.1% for this DALI-2 version. Input and performance Parameter Specification Input voltage 180–305 VAC or 255–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 93% at the catalog test conditions Typical power factor >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 230 VAC or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.3 A / 230 VAC; 1.1 A / 277 VAC Inrush current Cold start: 60 A typical at 230 VAC; 600 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 3 / 5 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 10 ms / 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 27–36 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +90°C; maximum case temperature +90°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. 100% load through +45°C ambient, falling to 60% at +50°C. Keep measured Tc at or below +90°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 180 VAC, rising to 100% at 200 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI/PUSH connection Use the DALI pair for DALI control. For primary-side PUSH, follow the dedicated wiring diagram: connect TB1 pin 5 (DA−/N) to neutral and a push button between line and pin 4 (DA+/L); PUSH2 uses a second button between line and pin 3 (PUSH/L). PUSH timing and limits Factory brightness 100%. Short press: 0.1–1 second; long press: >1 second. One common push button supports up to 10 drivers; maximum cable length to the last driver is 20 m. PUSH brightness Short press switches on/off. Long press dims up/down and stops at maximum or minimum dim (not dim-off); each next push reverses direction. Brightening from off is possible. Responses depend on the DIP mode below. DIP 1/2/3: ON / ON / ON 1 DT6 logical gear / 1 DALI address; use CH1 for the LED load. PUSH1 controls brightness; PUSH2 has no response. DIP 1/2/3: ON / ON / OFF 4 DT6 logical gears / 4 addresses; CH1–CH4 are separate brightness channels. PUSH1 controls all four synchronously; PUSH2 has no response. DIP 1/2/3: OFF / OFF / OFF Factory default RGBW DT8: 1 logical gear / 1 address. CH1 red, CH2 green, CH3 blue, CH4 white. PUSH1 controls brightness. PUSH2 short press selects white or RGB control; long press adjusts white (minimum 0) or changes RGB colour. DIP 1/2/3: ON / OFF / OFF 1 tunable-white Tc DT8 logical gear / 1 address: CH1 cool white + CH2 warm white; CH3/CH4 unused. PUSH1 controls brightness; PUSH2 short press switches on/off and long press performs Dim2Warm. DIP 1/2/3: OFF / ON / OFF 2 tunable-white Tc DT8 logical gears / 2 addresses: CH1 cool + CH2 warm, CH3 cool + CH4 warm. PUSH1 synchronizes brightness of both gears; PUSH2 synchronizes Dim2Warm and on/off. DIP 1/2/3: OFF / OFF / ON Mixed DT6 + tunable-white DT8: 2 logical gears / 2 addresses. CH3 is DT6; CH1 cool + CH2 warm form DT8, CH4 unused. PUSH1 responds only for DT6; PUSH2 responds only for DT8. Dim2Warm behavior Dimming down warms colour temperature; dimming up cools it. Long press stops at minimum dim, not dim-off; next push reverses direction. Operation from off is possible. RGBW duty and load limits Normalized colour control (factory default): a+b+c+d ≤100%. Extended colour control, enabled by DALI commands: sum ≤400%. In either mode, instantaneous total output power of all four channels must not exceed 240 W. The duty sum does not multiply the product power rating; size all connected channels for the shared 10 A total rating. Safety, insulation and compliance Parameter Specification Safety and design standards ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1801.3 / 155.5 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. DALI standards IEC62386-101, -102, -207 (DT6), -209 (DT8) and Part 251; apply only the selected mode and the supplied DA2Q version. Emergency-lighting scope DA2/DA2Q emergency operation is listed to BS EN/EN61347-2-13 Appendix J (EL), DC input 176–280 V. This is the emergency condition; the normal input specification remains as listed above. Dimensions and installation Parameter Specification Dimensions 380 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N, 3 PUSH/L, 4 DA+/L, 5 DA−/N. TB2: 1 +V, 2 +V, 3 CH1/−R/CW, 4 CH2/−G/WW, 5 CH3/−B/CW, 6 CH4/−W/WW. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 540 g; catalog packing reference per unit (0.54 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $122.72

    View options

  • SPWM-240-48DA2

    View options

    MEAN WELL SPWM-240 series: DALI-2 PWM output LED driver - SPWM-240-48DA2

    MEAN WELL SPWM-240-48DA2 MEAN WELL SPWM-240-48DA2 is a DALI-2 constant-voltage PWM output LED driver for compatible 48 V LED strips, rated 5 A and 240 W. Its slim Class II housing uses terminal-block connections. Select for the exact DA2 control version and apply the input and thermal derating below. Download MEAN WELL SPWM-240 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 19–27; specifications on page 20. Model, output and control Parameter Specification Model SPWM-240-48DA2 Series and function code SPWM-240; DA2: DALI-2 DT6 control Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 48 V Rated output current 5 A maximum Rated output power 240 W maximum Voltage adjustment range 47–50 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz, fixed typical output waveform frequency. Dimming interface DALI-2 DT6 brightness control and primary-side PUSH Dimming range Minimum dimming level 0.1% for this DALI-2 version. Input and performance Parameter Specification Input voltage 180–305 VAC or 255–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 94% at the catalog test conditions Typical power factor >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 230 VAC or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.3 A / 230 VAC; 1.1 A / 277 VAC Inrush current Cold start: 60 A typical at 230 VAC; 600 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 3 / 5 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 10 ms / 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 52–63 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +90°C; maximum case temperature +90°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. 100% load through +45°C ambient, falling to 60% at +50°C. Keep measured Tc at or below +90°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 180 VAC, rising to 100% at 200 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI/PUSH connection Use the DALI pair for DALI control. For primary-side PUSH, follow the dedicated wiring diagram: connect TB1 pin 5 (DA−/N) to neutral and a push button between line and pin 4 (DA+/PUSH); pin 3 is NC. PUSH timing and limits Factory brightness 100%. Short press: 0.1–1 second; long press: >1 second. One common push button supports up to 10 drivers; maximum cable length to the last driver is 20 m. PUSH brightness Short press switches on/off. Long press dims up/down and stops at maximum or minimum dim (not dim-off); each next push reverses direction. Brightening from off is possible. This DA2 version has no PUSH2 colour button. Safety, insulation and compliance Parameter Specification Safety and design standards ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1801.3 / 155.5 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. DALI standards IEC62386-101, -102, -207 (DT6) and Part 251; apply only the selected mode and the supplied DA2 version. Emergency-lighting scope DA2/DA2Q emergency operation is listed to BS EN/EN61347-2-13 Appendix J (EL), DC input 176–280 V. This is the emergency condition; the normal input specification remains as listed above. Dimensions and installation Parameter Specification Dimensions 380 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N, 3 NC, 4 DA+/PUSH, 5 DA−/N. TB2: 1 +V, 2 +V, 3 −V, 4 −V. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 540 g; catalog packing reference per unit (0.54 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $106.46

    View options

  • SPWM-240-24DA2

    View options

    MEAN WELL SPWM-240 series: DALI-2 PWM output LED driver - SPWM-240-24DA2

    MEAN WELL SPWM-240-24DA2 MEAN WELL SPWM-240-24DA2 is a DALI-2 constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 10 A and 240 W. Its slim Class II housing uses terminal-block connections. Select for the exact DA2 control version and apply the input and thermal derating below. Download MEAN WELL SPWM-240 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 19–27; specifications on page 20. Model, output and control Parameter Specification Model SPWM-240-24DA2 Series and function code SPWM-240; DA2: DALI-2 DT6 control Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 10 A maximum Rated output power 240 W maximum Voltage adjustment range 23–26 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz, fixed typical output waveform frequency. Dimming interface DALI-2 DT6 brightness control and primary-side PUSH Dimming range Minimum dimming level 0.1% for this DALI-2 version. Input and performance Parameter Specification Input voltage 180–305 VAC or 255–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 93% at the catalog test conditions Typical power factor >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 230 VAC or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.3 A / 230 VAC; 1.1 A / 277 VAC Inrush current Cold start: 60 A typical at 230 VAC; 600 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 3 / 5 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 10 ms / 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 27–36 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +90°C; maximum case temperature +90°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. 100% load through +45°C ambient, falling to 60% at +50°C. Keep measured Tc at or below +90°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 180 VAC, rising to 100% at 200 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI/PUSH connection Use the DALI pair for DALI control. For primary-side PUSH, follow the dedicated wiring diagram: connect TB1 pin 5 (DA−/N) to neutral and a push button between line and pin 4 (DA+/PUSH); pin 3 is NC. PUSH timing and limits Factory brightness 100%. Short press: 0.1–1 second; long press: >1 second. One common push button supports up to 10 drivers; maximum cable length to the last driver is 20 m. PUSH brightness Short press switches on/off. Long press dims up/down and stops at maximum or minimum dim (not dim-off); each next push reverses direction. Brightening from off is possible. This DA2 version has no PUSH2 colour button. Safety, insulation and compliance Parameter Specification Safety and design standards ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1801.3 / 155.5 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. DALI standards IEC62386-101, -102, -207 (DT6) and Part 251; apply only the selected mode and the supplied DA2 version. Emergency-lighting scope DA2/DA2Q emergency operation is listed to BS EN/EN61347-2-13 Appendix J (EL), DC input 176–280 V. This is the emergency condition; the normal input specification remains as listed above. Dimensions and installation Parameter Specification Dimensions 380 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N, 3 NC, 4 DA+/PUSH, 5 DA−/N. TB2: 1 +V, 2 +V, 3 −V, 4 −V. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 540 g; catalog packing reference per unit (0.54 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $106.46

    View options

  • SPWM-240-48

    View options

    MEAN WELL SPWM-240 series: 3-in-1 dimmable PWM output LED driver - SPWM-240-48

    MEAN WELL SPWM-240-48 MEAN WELL SPWM-240-48 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 48 V LED strips, rated 5 A and 240 W. Its slim Class II housing uses terminal-block connections. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL SPWM-240 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 19–27; specifications on page 20. Model, output and control Parameter Specification Model SPWM-240-48 Series and function code SPWM-240; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 48 V Rated output current 5 A maximum Rated output power 240 W maximum Voltage adjustment range 47–50 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 300 Hz–3 kHz, or 0–100 kΩ resistance between DIM+ and DIM− Dimming range Approximate minimum 6%; output current is undefined between 0% and 6%. Dim-to-off is available at about 0 VDC, 0 kΩ or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Connect LEDs directly; use with additional drivers is not recommended. Input and performance Parameter Specification Input voltage 180–305 VAC or 255–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 94% at the catalog test conditions Typical power factor >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 230 VAC or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.3 A / 230 VAC; 1.1 A / 277 VAC Inrush current Cold start: 60 A typical at 230 VAC; 600 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 3 / 5 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 10 ms / 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 52–63 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +90°C; maximum case temperature +90°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. 100% load through +45°C ambient, falling to 60% at +50°C. Keep measured Tc at or below +90°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 180 VAC, rising to 100% at 200 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1801.3 / 155.5 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. Dimensions and installation Parameter Specification Dimensions 380 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N. TB2: 1 +V, 2 +V, 3 −V, 4 −V, 5 DIM+, 6 DIM−. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 540 g; catalog packing reference per unit (0.54 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $101.04

    View options

  • SPWM-240-24

    View options

    MEAN WELL SPWM-240 series: 3-in-1 dimmable PWM output LED driver - SPWM-240-24

    MEAN WELL SPWM-240-24 MEAN WELL SPWM-240-24 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 10 A and 240 W. Its slim Class II housing uses terminal-block connections. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL SPWM-240 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 19–27; specifications on page 20. Model, output and control Parameter Specification Model SPWM-240-24 Series and function code SPWM-240; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 10 A maximum Rated output power 240 W maximum Voltage adjustment range 23–26 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 300 Hz–3 kHz, or 0–100 kΩ resistance between DIM+ and DIM− Dimming range Approximate minimum 6%; output current is undefined between 0% and 6%. Dim-to-off is available at about 0 VDC, 0 kΩ or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Connect LEDs directly; use with additional drivers is not recommended. Input and performance Parameter Specification Input voltage 180–305 VAC or 255–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 93% at the catalog test conditions Typical power factor >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 230 VAC or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.3 A / 230 VAC; 1.1 A / 277 VAC Inrush current Cold start: 60 A typical at 230 VAC; 600 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 3 / 5 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 10 ms / 230 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 27–36 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +90°C; maximum case temperature +90°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. 100% load through +45°C ambient, falling to 60% at +50°C. Keep measured Tc at or below +90°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 180 VAC, rising to 100% at 200 VAC; 100% through 305 VAC. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1801.3 / 155.5 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. Dimensions and installation Parameter Specification Dimensions 380 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N. TB2: 1 +V, 2 +V, 3 −V, 4 −V, 5 DIM+, 6 DIM−. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 540 g; catalog packing reference per unit (0.54 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $101.04

    View options

  • SPWM-150-24DA2Q

    View options

    MEAN WELL SPWM-150 series: 4-channel DALI-2 PWM output LED driver - SPWM-150-24DA2Q

    MEAN WELL SPWM-150-24DA2Q MEAN WELL SPWM-150-24DA2Q is a 4-channel DALI-2 constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 6.3 A and 151.2 W total across the configured output channels. Its slim Class II housing uses terminal-block connections. Select for the exact DA2Q control version and apply the input and thermal derating below. Download MEAN WELL SPWM-150 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 10–18; specifications on page 11. Model, output and control Parameter Specification Model SPWM-150-24DA2Q Series and function code SPWM-150; DA2Q: DALI-2 with four output channels and selectable DT6/DT8 modes Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 6.3 A maximum, shared total rating across all output channels Rated output power 151.2 W maximum total; not per channel Voltage adjustment range 23–26 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz typical output waveform frequency. Dimming interface DALI-2 DT8 RGBW/tunable white, selectable DT6 modes and primary-side PUSH Dimming range Minimum dimming level 0.1% for this DALI-2 version. Input and performance Parameter Specification Input voltage 100–305 VAC or 156–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 93% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.5 A / 115 VAC; 1 A / 230 VAC; 0.8 A / 277 VAC Inrush current Cold start: 55 A typical at 230 VAC; 500 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 5 / 8 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC; 1200 ms setup, 80 ms rise / 115 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 10 ms / 230 VAC or 115 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 27–36 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +80°C; maximum case temperature +80°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. At 110 VAC: 90% load through +40°C, falling to 60% at +50°C. At 230 VAC: 100% through +45°C, falling to 60% at +50°C. Keep measured Tc at or below +80°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 100 VAC, rising to 90% at 110 VAC; the 90% plateau continues below 200 VAC, with a step to 100% at 200 VAC through 305 VAC. Below 110 VAC at −20°C, a restart may occur within 5 seconds after power-on. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI/PUSH connection Use the DALI pair for DALI control. For primary-side PUSH, follow the dedicated wiring diagram: connect TB1 pin 5 (DA−/N) to neutral and a push button between line and pin 4 (DA+/L); PUSH2 uses a second button between line and pin 3 (PUSH/L). PUSH timing and limits Factory brightness 100%. Short press: 0.1–1 second; long press: >1 second. One common push button supports up to 10 drivers; maximum cable length to the last driver is 20 m. PUSH brightness Short press switches on/off. Long press dims up/down and stops at maximum or minimum dim (not dim-off); each next push reverses direction. Brightening from off is possible. Responses depend on the DIP mode below. DIP 1/2/3: ON / ON / ON 1 DT6 logical gear / 1 DALI address; use CH1 for the LED load. PUSH1 controls brightness; PUSH2 has no response. DIP 1/2/3: ON / ON / OFF 4 DT6 logical gears / 4 addresses; CH1–CH4 are separate brightness channels. PUSH1 controls all four synchronously; PUSH2 has no response. DIP 1/2/3: OFF / OFF / OFF Factory default RGBW DT8: 1 logical gear / 1 address. CH1 red, CH2 green, CH3 blue, CH4 white. PUSH1 controls brightness. PUSH2 short press selects white or RGB control; long press adjusts white (minimum 0) or changes RGB colour. DIP 1/2/3: ON / OFF / OFF 1 tunable-white Tc DT8 logical gear / 1 address: CH1 cool white + CH2 warm white; CH3/CH4 unused. PUSH1 controls brightness; PUSH2 short press switches on/off and long press performs Dim2Warm. DIP 1/2/3: OFF / ON / OFF 2 tunable-white Tc DT8 logical gears / 2 addresses: CH1 cool + CH2 warm, CH3 cool + CH4 warm. PUSH1 synchronizes brightness of both gears; PUSH2 synchronizes Dim2Warm and on/off. DIP 1/2/3: OFF / OFF / ON Mixed DT6 + tunable-white DT8: 2 logical gears / 2 addresses. CH3 is DT6; CH1 cool + CH2 warm form DT8, CH4 unused. PUSH1 responds only for DT6; PUSH2 responds only for DT8. Dim2Warm behavior Dimming down warms colour temperature; dimming up cools it. Long press stops at minimum dim, not dim-off; next push reverses direction. Operation from off is possible. RGBW duty and load limits Normalized colour control (factory default): a+b+c+d ≤100%. Extended colour control, enabled by DALI commands: sum ≤400%. In either mode, instantaneous total output power of all four channels must not exceed 151.2 W. The duty sum does not multiply the product power rating; size all connected channels for the shared 6.3 A total rating. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Class P; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1926.4 / 158.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. DALI standards IEC62386-101, -102, -207 (DT6), -209 (DT8) and Part 251; apply only the selected mode and the supplied DA2Q version. Emergency-lighting scope DA2/DA2Q emergency operation is listed to BS EN/EN61347-2-13 Appendix J (EL), DC input 176–280 V. This is the emergency condition; the normal input specification remains as listed above. Dimensions and installation Parameter Specification Dimensions 340 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N, 3 PUSH/L, 4 DA+/L, 5 DA−/N. TB2: 1 +V, 2 +V, 3 CH1/−R/CW, 4 CH2/−G/WW, 5 CH3/−B/CW, 6 CH4/−W/WW. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 400 g; catalog packing reference per unit (0.40 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $106.46

    View options

  • SPWM-150-12DA2Q

    View options

    MEAN WELL SPWM-150 series: 4-channel DALI-2 PWM output LED driver - SPWM-150-12DA2Q

    MEAN WELL SPWM-150-12DA2Q MEAN WELL SPWM-150-12DA2Q is a 4-channel DALI-2 constant-voltage PWM output LED driver for compatible 12 V LED strips, rated 12.5 A and 150 W total across the configured output channels. Its slim Class II housing uses terminal-block connections. Select for the exact DA2Q control version and apply the input and thermal derating below. Download MEAN WELL SPWM-150 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 10–18; specifications on page 11. Model, output and control Parameter Specification Model SPWM-150-12DA2Q Series and function code SPWM-150; DA2Q: DALI-2 with four output channels and selectable DT6/DT8 modes Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 12 V Rated output current 12.5 A maximum, shared total rating across all output channels Rated output power 150 W maximum total; not per channel Voltage adjustment range 11–14 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz typical output waveform frequency. Dimming interface DALI-2 DT8 RGBW/tunable white, selectable DT6 modes and primary-side PUSH Dimming range Minimum dimming level 0.1% for this DALI-2 version. Input and performance Parameter Specification Input voltage 100–305 VAC or 156–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 92% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.5 A / 115 VAC; 1 A / 230 VAC; 0.8 A / 277 VAC Inrush current Cold start: 55 A typical at 230 VAC; 500 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 5 / 8 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC; 1200 ms setup, 80 ms rise / 115 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 10 ms / 230 VAC or 115 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 15–20 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +80°C; maximum case temperature +80°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. At 110 VAC: 90% load through +40°C, falling to 60% at +50°C. At 230 VAC: 100% through +45°C, falling to 60% at +50°C. Keep measured Tc at or below +80°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 100 VAC, rising to 90% at 110 VAC; the 90% plateau continues below 200 VAC, with a step to 100% at 200 VAC through 305 VAC. Below 110 VAC at −20°C, a restart may occur within 5 seconds after power-on. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI/PUSH connection Use the DALI pair for DALI control. For primary-side PUSH, follow the dedicated wiring diagram: connect TB1 pin 5 (DA−/N) to neutral and a push button between line and pin 4 (DA+/L); PUSH2 uses a second button between line and pin 3 (PUSH/L). PUSH timing and limits Factory brightness 100%. Short press: 0.1–1 second; long press: >1 second. One common push button supports up to 10 drivers; maximum cable length to the last driver is 20 m. PUSH brightness Short press switches on/off. Long press dims up/down and stops at maximum or minimum dim (not dim-off); each next push reverses direction. Brightening from off is possible. Responses depend on the DIP mode below. DIP 1/2/3: ON / ON / ON 1 DT6 logical gear / 1 DALI address; use CH1 for the LED load. PUSH1 controls brightness; PUSH2 has no response. DIP 1/2/3: ON / ON / OFF 4 DT6 logical gears / 4 addresses; CH1–CH4 are separate brightness channels. PUSH1 controls all four synchronously; PUSH2 has no response. DIP 1/2/3: OFF / OFF / OFF Factory default RGBW DT8: 1 logical gear / 1 address. CH1 red, CH2 green, CH3 blue, CH4 white. PUSH1 controls brightness. PUSH2 short press selects white or RGB control; long press adjusts white (minimum 0) or changes RGB colour. DIP 1/2/3: ON / OFF / OFF 1 tunable-white Tc DT8 logical gear / 1 address: CH1 cool white + CH2 warm white; CH3/CH4 unused. PUSH1 controls brightness; PUSH2 short press switches on/off and long press performs Dim2Warm. DIP 1/2/3: OFF / ON / OFF 2 tunable-white Tc DT8 logical gears / 2 addresses: CH1 cool + CH2 warm, CH3 cool + CH4 warm. PUSH1 synchronizes brightness of both gears; PUSH2 synchronizes Dim2Warm and on/off. DIP 1/2/3: OFF / OFF / ON Mixed DT6 + tunable-white DT8: 2 logical gears / 2 addresses. CH3 is DT6; CH1 cool + CH2 warm form DT8, CH4 unused. PUSH1 responds only for DT6; PUSH2 responds only for DT8. Dim2Warm behavior Dimming down warms colour temperature; dimming up cools it. Long press stops at minimum dim, not dim-off; next push reverses direction. Operation from off is possible. RGBW duty and load limits Normalized colour control (factory default): a+b+c+d ≤100%. Extended colour control, enabled by DALI commands: sum ≤400%. In either mode, instantaneous total output power of all four channels must not exceed 150 W. The duty sum does not multiply the product power rating; size all connected channels for the shared 12.5 A total rating. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Class P; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1926.4 / 158.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. DALI standards IEC62386-101, -102, -207 (DT6), -209 (DT8) and Part 251; apply only the selected mode and the supplied DA2Q version. Emergency-lighting scope DA2/DA2Q emergency operation is listed to BS EN/EN61347-2-13 Appendix J (EL), DC input 176–280 V. This is the emergency condition; the normal input specification remains as listed above. Dimensions and installation Parameter Specification Dimensions 340 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N, 3 PUSH/L, 4 DA+/L, 5 DA−/N. TB2: 1 +V, 2 +V, 3 CH1/−R/CW, 4 CH2/−G/WW, 5 CH3/−B/CW, 6 CH4/−W/WW. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 400 g; catalog packing reference per unit (0.40 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $106.46

    View options

  • SPWM-150-24DA2

    View options

    MEAN WELL SPWM-150 series: DALI-2 PWM output LED driver - SPWM-150-24DA2

    MEAN WELL SPWM-150-24DA2 MEAN WELL SPWM-150-24DA2 is a DALI-2 constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 6.3 A and 151.2 W. Its slim Class II housing uses terminal-block connections. Select for the exact DA2 control version and apply the input and thermal derating below. Download MEAN WELL SPWM-150 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 10–18; specifications on page 11. Model, output and control Parameter Specification Model SPWM-150-24DA2 Series and function code SPWM-150; DA2: DALI-2 DT6 control Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 6.3 A maximum Rated output power 151.2 W maximum Voltage adjustment range 23–26 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz, fixed typical output waveform frequency. Dimming interface DALI-2 DT6 brightness control and primary-side PUSH Dimming range Minimum dimming level 0.1% for this DALI-2 version. Input and performance Parameter Specification Input voltage 100–305 VAC or 156–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 93% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.5 A / 115 VAC; 1 A / 230 VAC; 0.8 A / 277 VAC Inrush current Cold start: 55 A typical at 230 VAC; 500 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 5 / 8 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC; 1200 ms setup, 80 ms rise / 115 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 10 ms / 230 VAC or 115 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 27–36 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +80°C; maximum case temperature +80°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. At 110 VAC: 90% load through +40°C, falling to 60% at +50°C. At 230 VAC: 100% through +45°C, falling to 60% at +50°C. Keep measured Tc at or below +80°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 100 VAC, rising to 90% at 110 VAC; the 90% plateau continues below 200 VAC, with a step to 100% at 200 VAC through 305 VAC. Below 110 VAC at −20°C, a restart may occur within 5 seconds after power-on. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI/PUSH connection Use the DALI pair for DALI control. For primary-side PUSH, follow the dedicated wiring diagram: connect TB1 pin 5 (DA−/N) to neutral and a push button between line and pin 4 (DA+/PUSH); pin 3 is NC. PUSH timing and limits Factory brightness 100%. Short press: 0.1–1 second; long press: >1 second. One common push button supports up to 10 drivers; maximum cable length to the last driver is 20 m. PUSH brightness Short press switches on/off. Long press dims up/down and stops at maximum or minimum dim (not dim-off); each next push reverses direction. Brightening from off is possible. This DA2 version has no PUSH2 colour button. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Class P; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1926.4 / 158.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. DALI standards IEC62386-101, -102, -207 (DT6) and Part 251; apply only the selected mode and the supplied DA2 version. Emergency-lighting scope DA2/DA2Q emergency operation is listed to BS EN/EN61347-2-13 Appendix J (EL), DC input 176–280 V. This is the emergency condition; the normal input specification remains as listed above. Dimensions and installation Parameter Specification Dimensions 340 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N, 3 NC, 4 DA+/PUSH, 5 DA−/N. TB2: 1 +V, 2 +V, 3 −V, 4 −V. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 400 g; catalog packing reference per unit (0.40 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $91.18

    View options

  • SPWM-150-12DA2

    View options

    MEAN WELL SPWM-150 series: DALI-2 PWM output LED driver - SPWM-150-12DA2

    MEAN WELL SPWM-150-12DA2 MEAN WELL SPWM-150-12DA2 is a DALI-2 constant-voltage PWM output LED driver for compatible 12 V LED strips, rated 12.5 A and 150 W. Its slim Class II housing uses terminal-block connections. Select for the exact DA2 control version and apply the input and thermal derating below. Download MEAN WELL SPWM-150 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 10–18; specifications on page 11. Model, output and control Parameter Specification Model SPWM-150-12DA2 Series and function code SPWM-150; DA2: DALI-2 DT6 control Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 12 V Rated output current 12.5 A maximum Rated output power 150 W maximum Voltage adjustment range 11–14 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz, fixed typical output waveform frequency. Dimming interface DALI-2 DT6 brightness control and primary-side PUSH Dimming range Minimum dimming level 0.1% for this DALI-2 version. Input and performance Parameter Specification Input voltage 100–305 VAC or 156–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 92% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.5 A / 115 VAC; 1 A / 230 VAC; 0.8 A / 277 VAC Inrush current Cold start: 55 A typical at 230 VAC; 500 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 5 / 8 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC; 1200 ms setup, 80 ms rise / 115 VAC. Cold-start measurement; rapid switching may increase setup time. DALI power-on timing requires a compatible controller; otherwise setup can exceed 0.5 s. Hold-up time 10 ms / 230 VAC or 115 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Hiccup mode; automatic recovery after the fault is removed. Overvoltage protection 15–20 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +80°C; maximum case temperature +80°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. At 110 VAC: 90% load through +40°C, falling to 60% at +50°C. At 230 VAC: 100% through +45°C, falling to 60% at +50°C. Keep measured Tc at or below +80°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 100 VAC, rising to 90% at 110 VAC; the 90% plateau continues below 200 VAC, with a step to 100% at 200 VAC through 305 VAC. Below 110 VAC at −20°C, a restart may occur within 5 seconds after power-on. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Control wiring and operation Parameter Specification DALI/PUSH connection Use the DALI pair for DALI control. For primary-side PUSH, follow the dedicated wiring diagram: connect TB1 pin 5 (DA−/N) to neutral and a push button between line and pin 4 (DA+/PUSH); pin 3 is NC. PUSH timing and limits Factory brightness 100%. Short press: 0.1–1 second; long press: >1 second. One common push button supports up to 10 drivers; maximum cable length to the last driver is 20 m. PUSH brightness Short press switches on/off. Long press dims up/down and stops at maximum or minimum dim (not dim-off); each next push reverses direction. Brightening from off is possible. This DA2 version has no PUSH2 colour button. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Class P; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1926.4 / 158.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. DALI standards IEC62386-101, -102, -207 (DT6) and Part 251; apply only the selected mode and the supplied DA2 version. Emergency-lighting scope DA2/DA2Q emergency operation is listed to BS EN/EN61347-2-13 Appendix J (EL), DC input 176–280 V. This is the emergency condition; the normal input specification remains as listed above. Dimensions and installation Parameter Specification Dimensions 340 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N, 3 NC, 4 DA+/PUSH, 5 DA−/N. TB2: 1 +V, 2 +V, 3 −V, 4 −V. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 400 g; catalog packing reference per unit (0.40 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $91.18

    View options

  • SPWM-150-24

    View options

    MEAN WELL SPWM-150 series: 3-in-1 dimmable PWM output LED driver - SPWM-150-24

    MEAN WELL SPWM-150-24 MEAN WELL SPWM-150-24 is a 3-in-1 dimmable constant-voltage PWM output LED driver for compatible 24 V LED strips, rated 6.3 A and 151.2 W. Its slim Class II housing uses terminal-block connections. Select for the exact Blank control version and apply the input and thermal derating below. Download MEAN WELL SPWM-150 Datasheet (PDF)Download MEAN WELL SPWM User Manual (PDF)Datasheet section: PDF pages 10–18; specifications on page 11. Model, output and control Parameter Specification Model SPWM-150-24 Series and function code SPWM-150; blank suffix: 3-in-1 dimming Output mode Constant voltage with PWM-style output; dimming varies output-current duty cycle. Built-in active power factor correction (PFC). DC output voltage 24 V Rated output current 6.3 A maximum Rated output power 151.2 W maximum Voltage adjustment range 23–26 V via +V ADJ; keep the load within rated current and power. Output PWM frequency 3.2 kHz, fixed typical output waveform frequency. Dimming interface 0–10 VDC, additive 10 V PWM at 300 Hz–3 kHz, or 0–100 kΩ resistance between DIM+ and DIM− Dimming range Approximate minimum 6%; output current is undefined between 0% and 6%. Dim-to-off is available at about 0 VDC, 0 kΩ or 0% duty of the external 10 V PWM signal. Dimming source and synchronization 100 μA typical source current. Resistance scaling: 100 kΩ / N at full output, where N is the number of synchronized drivers. Do not connect DIM− to the negative LED output. Connect LEDs directly; use with additional drivers is not recommended. Input and performance Parameter Specification Input voltage 100–305 VAC or 156–410 VDC; apply input-voltage and thermal derating. Before DC wiring, verify the manufacturer’s polarity requirements for this model. Input frequency 47–63 Hz Typical efficiency 93% at the catalog test conditions Typical power factor >0.97 / 115 VAC; >0.95 / 230 VAC; >0.92 / 277 VAC at full load; PF changes with load. THD <10% at ≥50% load / 115 or 230 VAC, or ≥75% / 277 VAC; consult the model-specific load curves. Typical AC input current 1.5 A / 115 VAC; 1 A / 230 VAC; 0.8 A / 277 VAC Inrush current Cold start: 55 A typical at 230 VAC; 500 μs pulse width measured at 50% peak, per NEMA 410. Circuit-breaker reference 5 / 8 units for type B / type C 16 A breakers at 230 VAC, respectively. Catalog reference only; verify the actual breaker and system conditions. Leakage current <0.25 mA at 277 VAC No-load or standby power <0.5 W with dimming off. Setup and rise time 500 ms setup, 80 ms rise / 230 VAC; 1200 ms setup, 80 ms rise / 115 VAC. Cold-start measurement; rapid switching may increase setup time. Hold-up time 10 ms / 230 VAC or 115 VAC typical Protection and operating conditions Parameter Specification Overload protection 105–150% of rated output; Hiccup mode; automatic recovery after the fault is removed. Short-circuit protection Output shuts down; remove the fault, then re-power to recover. Overvoltage protection 27–36 V; Output shuts down; remove the fault, then re-power to recover. Overtemperature protection Output shuts down; remove the fault, then re-power to recover. Working case temperature −20 to +80°C; maximum case temperature +80°C, subject to derating. Cooling and load derating Free-air convection, vertical mounting, as specified by the catalog curves. At 110 VAC: 90% load through +40°C, falling to 60% at +50°C. At 230 VAC: 100% through +45°C, falling to 60% at +50°C. Keep measured Tc at or below +80°C; the case-temperature limit does not replace the ambient curve. Input/load derating At 60 Hz, vertical mounting: 80% at 100 VAC, rising to 90% at 110 VAC; the 90% plateau continues below 200 VAC, with a step to 100% at 200 VAC through 305 VAC. Below 110 VAC at −20°C, a restart may occur within 5 seconds after power-on. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–50°C Altitude derating Above 2000 m, reduce the allowable ambient temperature by 3.5°C per additional 1000 m for this fanless design. Vibration 5–100 Hz, 2 G, 12 minutes per cycle, 72 minutes along each X/Y/Z axis. Safety, insulation and compliance Parameter Specification Safety and design standards UL8750 Class P; CSA C22.2 No. 250.13-12; ENEC BS EN/EN61347-1 and BS EN/EN61347-2-13; Class II plastic housing without FG and SELV output. BS EN/EN62384, GB/T19510.1, GB/T19510.213 and EAC TP TC 004; AS/NZS61347-1/-2-13 are design references. RCM is voluntary; the catalog identifies Non-IC independent LED control gear as unsuitable for residential installations under that classification. EMC Emission: BS EN/EN55015 (CISPR15), GB/T17743; BS EN/EN61000-3-2 / GB17625.1 Class C at ≥50% load; BS EN/EN61000-3-3. Immunity: BS EN/EN61547; BS EN/EN61000-4-2 ESD 8 kV air / 4 kV contact; -4-3/-4-4/-4-6/-4-8 level 2; -4-5 line-to-line 2 kV (level 4); -4-11:2020 30% dip for 10 periods and 100% interruption for 0.5 periods. Final equipment requires EMC requalification. Insulation Input/output withstand: 3.75 kVAC. Insulation resistance input/output: 100 MΩ at 500 VDC, 25°C / 70% RH. MTBF 1926.4 / 158.1 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F (25°C), respectively; statistical estimates, not guaranteed service life. Flicker measurement PstLM ≤1 and SVM ≤0.4, measured at full load with the light source provided by MEAN WELL. Dimensions and installation Parameter Specification Dimensions 340 × 38 × 28.5 mm (L × W × H); slim plastic terminal-block housing. Terminal connections TB1: 1 AC/L, 2 AC/N. TB2: 1 +V, 2 +V, 3 −V, 4 −V, 5 DIM+, 6 DIM−. Terminal wire preparation TB1/TB2: 0.75–2.50 mm² (18–14 AWG), 6–7 mm stripping length, M2.5 terminal screws; suggested tightening torque 0.4 N·m (3.5 lb·in). Mounting Use the model-specific drawing and 4.2 mm mounting features. Provide ≥15 cm spacing between drivers and do not stack them. The SPWM manual requires a ≥7 mm shim below the fixing screws to leave a heat-dissipation gap. Installation Qualified personnel only. Disconnect power before wiring or maintenance; verify secure, correct wiring before energizing. Do not open the case. Do not install in damp locations, excessive heat, direct sunlight or near fire. Close and secure the protective terminal covers. Capacitive loads are not recommended. Weight 400 g; catalog packing reference per unit (0.40 kg × 1000), not a measured net or shipping parcel weight. Service-life reference Typical lifetime >50,000 hours when the marked Tc/TMP point is about +75°C or below. Manufacturer catalog warranty: 5 years, subject to MEAN WELL’s warranty statement; not an additional store promise. Unless stated otherwise, catalog parameters are measured at 230 VAC input, rated current and +25°C ambient. Typical figures and load curves apply only to their stated conditions. Read the linked drawings and installation instructions before system design.

    Read more

    $82.80

    View options

You have seen 48 out of 55 products

Show more products
