MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01M-05
Rated power: 1W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 13mA, full load: 107mA Output voltage: ± 5V Output current: ± 10 ~ 100mA Efficiency (TYP.):82% Capacitive load (maximum):220μF Performance difference:-40 ~ +90 ℃ working temperature, longest one second short circuit protection, standard product Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01M-05SC
Rated power: 1W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 13mA, full load: 107mA Output voltage: ± 5V Output current: ± 10 ~ 100mA Efficiency (TYP.):82% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01M-12
Rated power: 1W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 12mA, full load: 103mA Output voltage: ± 12V Output current: ± 4.2 ~ 42mA Efficiency (TYP.):82% Capacitive load (maximum):220μF Performance difference:-40 ~ +90 ℃ working temperature, longest one second short circuit protection, standard product Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01M-12SC
Rated power: 1W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 12mA, full load: 103mA Output voltage: ± 12V Output current: ± 4.2 ~ 42mA Efficiency (TYP.):82% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01M-15
Rated power: 1W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 13mA, full load: 102mA Output voltage: ± 15V Output current: ± 3.4 ~ 34mA Efficiency (TYP.):83% Capacitive load (maximum):220μF Performance difference:-40 ~ +90 ℃ working temperature, longest one second short circuit protection, standard product Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01M-15SC
Rated power: 1W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 13mA, full load: 102mA Output voltage: ± 15V Output current: ± 3.4 ~ 34mA Efficiency (TYP.):83% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01N-05
Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 5V Output current: ± 10 ~ 100mA Efficiency (TYP.):76% Capacitive load (maximum):220μF Performance difference:-40 ~ +90 ℃ working temperature, longest one second short circuit protection, standard product Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01N-05SC
Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 5V Output current: ± 10 ~ 100mA Efficiency (TYP.):76% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01N-12
Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 12V Output current: ± 4.2 ~ 42mA Efficiency (TYP.):77% Capacitive load (maximum):220μF Performance difference:-40 ~ +90 ℃ working temperature, longest one second short circuit protection, standard product Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01N-12SC
Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 12V Output current: ± 4.2 ~ 42mA Efficiency (TYP.):77% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01N-15
Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 15V Output current: ± 3.4 ~ 34mA Efficiency (TYP.):78% Capacitive load (maximum):220μF Performance difference:-40 ~ +90 ℃ working temperature, longest one second short circuit protection, standard product Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01 Series: DC-DC Unregulated Converter - DETN01N-15SC
Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 15V Output current: ± 3.4 ~ 34mA Efficiency (TYP.):78% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industrial standard pins, operating temperature range -40 ~ +90 ℃, conforming to BS EN/EN55032 radiation Class B, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, 3 years warranty.
$14.14
-
MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01L-05N
New series Rated power: 1W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 30mA, full load: 260mA Output voltage: ± 5V Output current: ± 10 ~ 100mA Efficiency (TYP.):78% Capacitive load (max):± 470μF Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%. 2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
$14.14
-
MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01L-12N
New series Rated power: 1W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 28mA, full load: 257mA Output voltage: ± 12V Output current: ± 4.2 ~ 42mA Efficiency (TYP.):80% Capacitive load (maximum):± 100 μF Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%. 2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
$14.14
-
MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01L-15N
New series Rated power: 1W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 28mA, full load: 253mA Output voltage: ± 15V Output current: ± 3.4 ~ 34mA Efficiency (TYP.):78% Capacitive load (maximum):± 100 μF Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%. 2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
$14.14
-
MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01M-05N
New series Rated power: 1W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 13mA, full load: 107mA Output voltage: ± 5V Output current: ± 10 ~ 100mA Efficiency (TYP.):75% Capacitive load (max):± 470μF Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%. 2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
$14.14
-
MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01M-12N
New series Rated power: 1W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 12mA, full load: 103mA Output voltage: ± 12V Output current: ± 4.2 ~ 42mA Efficiency (TYP.):83% Capacitive load (maximum):± 100 μF Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%. 2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
$14.14
-
MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01M-15N
New series Rated power: 1W Input voltage (range):Normal 12V(10.8~13.2V) Input current no-load: 13mA, full load: 102mA Output voltage: ± 15V Output current: ± 3.4 ~ 34mA Efficiency (TYP.):79% Capacitive load (maximum):± 100 μF Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%. 2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
$14.14
-
MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01N-05N
New series Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 5V Output current: ± 10 ~ 100mA Efficiency (TYP.):74% Capacitive load (max):± 470μF Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%. 2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
$14.14
-
MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01N-12N
New series Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 12V Output current: ± 4.2 ~ 42mA Efficiency (TYP.):82% Capacitive load (maximum):± 100 μF Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%. 2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
$14.14
-
MEAN WELL DETN01-N series: DC-DC unregulated converter - DETN01N-15N
New series Rated power: 1W Input voltage (range):Normal 24V(21.6~26.4V) Input current no-load: 11mA, full load: 55mA Output voltage: ± 15V Output current: ± 3.4 ~ 34mA Efficiency (TYP.):82% Capacitive load (maximum):± 100 μF Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. The SMD package has industry standard pins, the operating temperature range is -40 ~ +100 ℃, and the efficiency is as high as 83%. 2.3KVDC input/output isolation, low cost, ± 3.3Vo models (optional, ordering models: DETN01L-03N,DETN01M-03N,DETN01N-03N),3-year warranty.
$14.14
-
MEAN WELL DETN02 Series: DC-DC Unregulated Converter - DETN02L-05
Rated power: 2W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 60mA, full load: 513mA Output voltage: ± 5V Output current: ± 20 ~ 200mA Efficiency (TYP.):78% Capacitive load (maximum):220μF Performance difference:-40 ~ +100 ℃ working temperature, up to 0.5 seconds short circuit protection, standard product Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industry standard pins, operating temperature range -40 ~ +100 ℃, conforming to BS EN/EN55032 radiation Class A, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, optional reel packaging, 3 years warranty.
$15.00
-
MEAN WELL DETN02 Series: DC-DC Unregulated Converter - DETN02L-05SC
Rated power: 2W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 60mA, full load: 513mA Output voltage: ± 5V Output current: ± 20 ~ 200mA Efficiency (TYP.):78% Capacitive load (maximum):220μF Performance difference:-40 ~ +105 ℃ working temperature, continuous short circuit protection, optional Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industry standard pins, operating temperature range -40 ~ +100 ℃, conforming to BS EN/EN55032 radiation Class A, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, optional reel packaging, 3 years warranty.
$15.00
-
MEAN WELL DETN02 Series: DC-DC Unregulated Converter - DETN02L-12
Rated power: 2W Input voltage (range):Normal 5V(4.5~5.5V) Input current no-load: 60mA, full load: 500mA Output voltage: ± 12V Output current: ± 8 ~ 84mA Efficiency (TYP.):80% Capacitive load (maximum):220μF Performance difference:-40 ~ +100 ℃ working temperature, up to 0.5 seconds short circuit protection, standard product Size (mm):15.24X10.9X7.1 Click to download Airtac product catalog Product Features 1. SMD package has industry standard pins, operating temperature range -40 ~ +100 ℃, conforming to BS EN/EN55032 radiation Class A, no additional components, and efficiency as high as 83%. 2. Protection: short circuit, 3KVDC input/output isolation, low cost, optional reel packaging, 3 years warranty.
$15.00
You have seen 360 out of 8679 products
