MEAN WELL DLC03 Series: DC-DC Regulated Converter - DLC03C-12
Series: Double group output Rated power: 3W Input voltage (range):48V(36~75V) Input current no-load: 10mA, full load: 78mA Output voltage: ± 12V Output current: ± 0 ~ 125mA Efficiency (TYP.):80% Capacitive load (max):* 220μF Size (mm):22.1X13.8X8.55 Click to download Airtac product catalog Product Features 1. The DIP16 package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level B, no additional components are required, and the efficiency is as high as 82%. 4. Protection: short circuit (continuous)/overload/input undervoltage, 1.5KVDC input/output isolation, 3 years warranty.
$41.14
-
MEAN WELL DLC03 Series: DC-DC Regulated Converter - DLC03C-15
Series: Double group output Rated power: 3W Input voltage (range):48V(36~75V) Input current no-load: 10mA, full load: 78mA Output voltage: ± 15V Output current: ± 0 ~ 100mA Efficiency (TYP.):80% Capacitive load (max):* 220μF Size (mm):22.1X13.8X8.55 Click to download Airtac product catalog Product Features 1. The DIP16 package has industry standard pins. 2, 2:1 wide input range, working temperature range -40~85 ℃, no minimum load. 3. Comply with BS EN/EN55032 radiation level B, no additional components are required, and the efficiency is as high as 82%. 4. Protection: short circuit (continuous)/overload/input undervoltage, 1.5KVDC input/output isolation, 3 years warranty.
$41.14
-
MEAN WELL DLP Series: DALI Bus Power Supplies - DLP-04L
Output rated DC voltage: 16V Output DC voltage range: 15.3~18.7V Output rated current: 240mA Output guaranteed supply current: 240mA Output maximum supply current: 250mA Output power rating: 3.84W Input voltage: 90 ~ 264VAC,120 ~ 370VDC appearance: long type Size (mm):145X38X22 Click to download Airtac product catalog Product Features 1. Output 16V/250mA(max). 2. Ultra-thin design: width 35mm(2SU)(R type). 3. Full range input: 90 ~ 264VAC. 4. Can withstand 300VAC surge input up to 5 seconds. 5. Class II isolation level. 6. No-load power consumption <0.5W(L type). 7. It can be installed on the guide rail TS-35/7.5 or 15 (R type). 8, 3 years warranty.
$48.86
-
MEAN WELL DLP Series: DALI Bus Power Supplies - DLP-04R
Output rated DC voltage: 16V Output DC voltage range: 15.3~18.7V Output rated current: 240mA Output guaranteed supply current: 240mA Output maximum supply current: 250mA Output power rating: 3.84W Input voltage: 90 ~ 264VAC,120 ~ 370VDC appearance: rail type Size (mm):35X90X54.5 Click to download Airtac product catalog Product Features 1. Output 16V/250mA(max). 2. Ultra-thin design: width 35mm(2SU)(R type). 3. Full range input: 90 ~ 264VAC. 4. Can withstand 300VAC surge input up to 5 seconds. 5. Class II isolation level. 6. No-load power consumption <0.5W(L type). 7. It can be installed on the guide rail TS-35/7.5 or 15 (R type). 8, 3 years warranty.
$48.86
-
MEAN WELL DLW05 Series: Regulator Converter - DLW05A-05
Output DC voltage: ± 5V Output current: ± 50 ~ ± 500mA Rated power: 5W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):75% Input DC current full load: 556mA, no load: 33mA Size (mm):50.8X25.4X11.27 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$38.14
-
MEAN WELL DLW05 Series: Regulator Converter - DLW05A-12
Output DC voltage: ± 12V Output current: ± 20.8 ~ ± 208mA Rated power: 5W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):80% Input DC current full load: 556mA, no load: 33mA Size (mm):50.8X25.4X11.27 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$38.14
-
MEAN WELL DLW05 Series: Regulator Converter - DLW05A-15
Output DC voltage: ± 15V Output current: ± 16.7 ~ ± 167mA Rated power: 5W Input voltage: 9 ~ 18VDC Input efficiency (Typ.):81% Input DC current full load: 556mA, no load: 33mA Size (mm):50.8X25.4X11.27 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$38.14
-
MEAN WELL DLW05 Series: Regulator Converter - DLW05B-05
Output DC voltage: ± 5V Output current: ± 50 ~ ± 500mA Rated power: 5W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):77% Input DC current full load: 270mA, no load: 16mA Size (mm):50.8X25.4X11.27 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$38.14
-
MEAN WELL DLW05 Series: Regulator Converter - DLW05B-12
Output DC voltage: ± 12V Output current: ± 20.8 ~ ± 208mA Rated power: 5W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):82% Input DC current full load: 270mA, no load: 16mA Size (mm):50.8X25.4X11.27 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$38.14
-
MEAN WELL DLW05 Series: Regulator Converter - DLW05B-15
Output DC voltage: ± 15V Output current: ± 16.7 ~ ± 167mA Rated power: 5W Input voltage: 18 ~ 36VDC Input efficiency (Typ.):83% Input DC current full load: 270mA, no load: 16mA Size (mm):50.8X25.4X11.27 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$38.14
-
MEAN WELL DLW05 Series: Regulator Converter - DLW05C-05
Output DC voltage: ± 5V Output current: ± 50 ~ ± 500mA Rated power: 5W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):77% Input DC current full load: 135mA, no load: 10mA Size (mm):50.8X25.4X11.27 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$38.14
-
MEAN WELL DLW05 Series: Regulator Converter - DLW05C-12
Output DC voltage: ± 12V Output current: ± 20.8 ~ ± 208mA Rated power: 5W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):83% Input DC current full load: 135mA, no load: 10mA Size (mm):50.8X25.4X11.27 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$38.14
-
MEAN WELL DLW05 Series: Regulator Converter - DLW05C-15
Output DC voltage: ± 15V Output current: ± 16.7 ~ ± 167mA Rated power: 5W Input voltage: 36 ~ 72VDC Input efficiency (Typ.):85% Input DC current full load: 135mA, no load: 10mA Size (mm):50.8X25.4X11.27 Click to download Airtac product catalog Product Features 1, 2:1 wide range input, 4:1 wide range input (optional). 2. 1500VDC input/output isolation, 3000VDC input/output isolation (optional). 3. Built-in EMI filter circuit, protection type: short circuit/overload, natural cooling. 4. Six-sided protective metal shell, 100% full load aging, low cost, high reliability, certification: FCC/EAC/CE/UKCA,2-year warranty.
$38.14
-
MEAN WELL DPA01W8 series: DC-DC regulator converter - DPA01W8-05
Series: Double group output Rated power: 1W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 5mA, full load: 53mA Output voltage: ± 5V Output current: ± 0 ~ 100mA Efficiency (TYP.):78% Capacitive load (max):* 47μF Size (mm):17.4X7.75X11.1 Click to download Airtac product catalog Product Features 1. SIP6 package has industry standard pins, 8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +95 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation A level, no additional parts are required, and the efficiency is as high as 80%. 3. Protection: short circuit (continuous)/overload/undervoltage lockout, 1.5KVdc input/output isolation, 3 years warranty.
$16.29
-
MEAN WELL DPA01W8 series: DC-DC regulator converter - DPA01W8-12
Series: Double group output Rated power: 1W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 7mA, full load: 56mA Output voltage: ± 12V Output current: ± 0 ~ 42mA Efficiency (TYP.):76% Capacitive load (max):* 47μF Size (mm):17.4X7.75X11.1 Click to download Airtac product catalog Product Features 1. SIP6 package has industry standard pins, 8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +95 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation A level, no additional parts are required, and the efficiency is as high as 80%. 3. Protection: short circuit (continuous)/overload/undervoltage lockout, 1.5KVdc input/output isolation, 3 years warranty.
$16.29
-
MEAN WELL DPA01W8 series: DC-DC regulator converter - DPA01W8-15
Series: Double group output Rated power: 1W Input voltage (range):Nominal 12V,24V,36V,48V,72V(9~75V) Input current no-load: 8mA, full load: 54mA Output voltage: ± 15V Output current: ± 0 ~ 33mA Efficiency (TYP.):77% Capacitive load (max):* 47μF Size (mm):17.4X7.75X11.1 Click to download Airtac product catalog Product Features 1. SIP6 package has industry standard pins, 8:1(9 ~ 75Vdc) ultra-wide input range, operating temperature range -40 ~ +95 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation A level, no additional parts are required, and the efficiency is as high as 80%. 3. Protection: short circuit (continuous)/overload/undervoltage lockout, 1.5KVdc input/output isolation, 3 years warranty.
$16.29
-
MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02A-05
Series: Double group output Rated power: 2W Input voltage (range):12V(9~18V) Input current no-load: 31mA, full load: 211mA Output voltage: ± 5V Output current: ± 0 ~ 200mA Efficiency (TYP.):79% Capacitive load (max):* 200μF Size (mm):21.8X9.2X11.1 Click to download Airtac product catalog Product Features 1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%. 3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.
$20.02
-
MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02A-12
Series: Double group output Rated power: 2W Input voltage (range):12V(9~18V) Input current no-load: 31mA, full load: 202mA Output voltage: ± 12V Output current: ± 0 ~ 83mA Efficiency (TYP.):82% Capacitive load (max):* 83μF Size (mm):21.8X9.2X11.1 Click to download Airtac product catalog Product Features 1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%. 3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.
$20.02
-
MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02A-15
Series: Double group output Rated power: 2W Input voltage (range):12V(9~18V) Input current no-load: 31mA, full load: 202mA Output voltage: ± 15V Output current: ± 0 ~ 67mA Efficiency (TYP.):83% Capacitive load (max):* 67 μF Size (mm):21.8X9.2X11.1 Click to download Airtac product catalog Product Features 1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%. 3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.
$20.02
-
MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02B-05
Series: Double group output Rated power: 2W Input voltage (range):24V(18~36V) Input current no-load: 18mA, full load: 105mA Output voltage: ± 5V Output current: ± 0 ~ 200mA Efficiency (TYP.):79% Capacitive load (max):* 200μF Size (mm):21.8X9.2X11.1 Click to download Airtac product catalog Product Features 1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%. 3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.
$20.02
-
MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02B-12
Series: Double group output Rated power: 2W Input voltage (range):24V(18~36V) Input current no-load: 19mA, full load: 102mA Output voltage: ± 12V Output current: ± 0 ~ 83mA Efficiency (TYP.):81% Capacitive load (max):* 83μF Size (mm):21.8X9.2X11.1 Click to download Airtac product catalog Product Features 1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%. 3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.
$20.02
-
MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02B-15
Series: Double group output Rated power: 2W Input voltage (range):24V(18~36V) Input current no-load: 19mA, full load: 100mA Output voltage: ± 15V Output current: ± 0 ~ 67mA Efficiency (TYP.):85% Capacitive load (max):* 67 μF Size (mm):21.8X9.2X11.1 Click to download Airtac product catalog Product Features 1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%. 3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.
$20.02
-
MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02C-05
Series: Double group output Rated power: 2W Input voltage (range):48V(36~75V) Input current no-load: 12mA, full load: 53mA Output voltage: ± 5V Output current: ± 0 ~ 200mA Efficiency (TYP.):78% Capacitive load (max):* 200μF Size (mm):21.8X9.2X11.1 Click to download Airtac product catalog Product Features 1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%. 3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.
$20.02
-
MEAN WELL DPAN02 Series: DC-DC Regulated Converter - DPAN02C-12
Series: Double group output Rated power: 2W Input voltage (range):48V(36~75V) Input current no-load: 12mA, full load: 51mA Output voltage: ± 12V Output current: ± 0 ~ 83mA Efficiency (TYP.):82% Capacitive load (max):* 83μF Size (mm):21.8X9.2X11.1 Click to download Airtac product catalog Product Features 1. SIP8 package has industry standard pins, 2:1 wide input range, operating temperature range -40 ~ +90 ℃, no minimum load required. 2. Comply with BS EN/EN55032 radiation level A, no additional components are required, and the efficiency is as high as 85%. 3. Protection: short circuit (continuous)/overload, 1.5KVDC input/output isolation, remote on/off, 3 years warranty.
$20.02
