GS & SGAS Series AC/DC Desktop Adapters

MEAN WELL's GS and SGAS series represent high-efficiency, reliable desktop power solutions. These units are designed to meet the growing global demand for energy-efficient power supplies across a vast array of commercial, industrial, and medical applications.

  • Energy Efficiency: Both series are engineered to meet strict international energy efficiency standards (EISA 2007/DoE Level VI), ensuring minimal power waste.
  • Global Safety: Certified for worldwide use with a multitude of international safety approvals (UL, TUV, CB, etc.), making them ideal for export-ready products.
  • Reliable Build: Housed in robust, 94V-0 flame-retardant plastic enclosures, built to last in professional environments.

GS Series (Green Adapter)

The GS series is the definitive "Green" desktop adapter line. It is a general-purpose, high-reliability power solution suitable for various electronic devices.

  • Application Flexibility: Widely used for consumer electronics, telecommunications equipment, industrial displays, and general office gear.
  • Compact Design: Streamlined desktop form factor that fits well in home and office setups.
  • Eco-Friendly: Extremely low no-load power consumption, significantly reducing energy costs when the device is in standby mode.
  • Wide Range: Available from small portable wattages up to high-power desktop units to suit almost any device requirement.

SGAS Series (Programmable/Smart)

The SGAS series is the intelligent upgrade for applications requiring high-quality, programmable power. These adapters offer advanced functionality for industrial and critical environments.

  • Programmable Output: Offers a wide adjustable output voltage range, allowing users to tune the output to the exact requirement of their specific equipment.
  • Smart Protection: Features advanced internal protection logic, including auto-recovery for short circuits, overloads, and over-temperature scenarios.
  • Industrial-Grade: Designed with high-quality components for long-term operational stability in demanding professional environments.
  • High Reliability: Suitable for medical auxiliary equipment, high-end industrial instruments, and precision testing tools.

Comparison Summary

While both series deliver excellent power quality, the choice depends on your specific application needs.

Feature GS Series SGAS Series
Primary Function Standard fixed output Programmable/Adjustable output
Intelligence Fixed voltage/current High-level protection & tuning
Ideal Use Consumer/Office Electronics Industrial/Precision Equipment
Energy Standard Level VI Efficiency Level VI Efficiency
Selection Tip: Choose the GS series for general-purpose applications where a fixed voltage is all that is required. Select the SGAS series if your application requires a programmable output voltage or if you are integrating power into high-end industrial/precision equipment that demands enhanced reliability.

Show previous products

  • SGAS15B09-P1J

    View options

    MEAN WELL SGAS15B series: Industrial Desktop AC/DC Power Adapter - SGAS15B09-P1J

    MEAN WELL SGAS15B09-P1J provides 9 V at up to 1.66 A, with a catalogue-rated output of 15 W. This Class II industrial desktop AC/DC adapter has an IEC320-C8 two-pole AC inlet and a centre-positive P1J output. Select the load within the current, power and temperature limits. Product Datasheet Download MEAN WELL SGAS15B Datasheet (PDF) The SGAS15B section is on PDF pages 30, 31, 32, 33, 34. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model SGAS15B09-P1J. Series and format SGAS15B single-output industrial desktop AC/DC power adapter. Model code SGAS is the adapter series; 15 is the power family; B denotes the IEC320-C8 two-pole AC inlet; 09 denotes 9 V output; P1J specifies the standard centre-positive output plug. DC output voltage 9 VDC. Rated output current 1.66 A. Output current range 0–1.66 A. Catalogue-rated output power 15 W, subject to temperature derating. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±5.0%. Line regulation ±0.5%. Load regulation ±5.0%. Efficiency, typical 84%. Keep the load within the stated output voltage, rated current and rated power limits simultaneously. Input and Energy Input voltage 90–264 VAC or 135–370 VDC. Frequency 47–63 Hz. Input connection IEC320-C8 two-pole AC inlet; Class II, without FG. AC current 0.4 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Set-up / rise time 3000 / 50 ms at full load. Leakage current, maximum 0.25 mA at 240 VAC. No-load consumption <0.075 W. Energy efficiency Level VI. USA EISA2007/DoE, EU ErP and CoC Version 5. Select a suitable mains lead for the C8 inlet and local supply; confirm mains-lead inclusion with the order. Protection Short circuit / overload 105–250% of rated output power; hiccup mode, automatically recovering after the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Derating and Environment Working temperature −20 to +70°C, subject to the load curve. Temperature-load curve 100% load from −20 to 40°C. The plotted reference levels are 80% at 50°C, 65% at 60°C and 50% at 70°C; follow the complete curve between these points. Static input curve, 60 Hz 100% load from 90 to 264 VAC; temperature derating still applies. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Mechanical Details and Connection Body dimensions, L × W × H 80 × 39 × 27.7 mm. Case Fully enclosed 94V-0 flame-retardant plastic enclosure. Output cable UL2468, 20 AWG; 1200 +150/−0 mm. Standard P1J output Tuning-fork plug, 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm insertion length; centre positive (C+), outside negative. Catalogue single-unit weight 130 g, explicitly listed in PACKING; a catalogue reference, not a measured shipment weight. Packing 72 pieces / 11 kg per carton. Match the DC plug dimensions and polarity to the equipment before connection. Allow space for the inlet or plug, cable and connector. Follow the supplied product marking and installation instructions. Optional DC Plugs and Quick Adapters Ordering and inclusion Custom cable termination is subject to MOQ. Quick adapters are sold separately without MOQ; they are options, not additional included plugs or outputs. Tuning-fork styles OD / ID / length in mm: P1I 5.5 / 2.1 / 9.5; P1L 5.5 / 2.5 / 9.5; P1M 5.5 / 2.5 / 11. Right-angle options: P1IR 5.5 / 2.1 / 9.5; P1JR 5.5 / 2.1 / 11; P1LR 5.5 / 2.5 / 9.5; P1MR 5.5 / 2.5 / 11. Quick adapters: 7.5 A maximum. Barrel styles P2I / P2IR 5.5 / 2.1 / 9.5 mm; P2J / P2JR 5.5 / 2.1 / 11 mm; P2L / P2LR 5.5 / 2.5 / 9.5 mm; P2M / P2MR 5.5 / 2.5 / 11 mm. R denotes right-angle form. Custom cable options; no quick adapter is listed. Locking styles P2S (S761K) 5.53 / 2.03 / 12.06 mm; P2K (761K) 5.53 / 2.54 / 12.06 mm; P2C (S760K) 5.53 / 2.03 / 9.52 mm; P2D (760K) 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent; custom cable options without a listed quick adapter. Mini-pin styles P3A 2.35 / 0.7 / 11 mm; P3B 4.0 / 1.7 / 11 mm; P3C 4.75 / 1.7 / 11 mm. EIAJ equivalent; quick adapters: 5 A maximum. Centre-pin styles OD / ID / length / centre pin in mm: P4A 5.5 / 3.4 / 11 / 1.0; P4B 6.5 / 4.4 / 11 / 1.4; P4C 7.4 / 5.1 / 11 / 0.6. EIAJ equivalent; quick adapters: 7.5 A maximum. Confirm the complete mating dimensions, voltage, polarity and load current. An accessory current rating does not increase this adapter’s 1.66 A output rating. Optional DIN Connectors and Lead Ends R6B Three-pin male locking mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo, pin 2 −Vo. Quick adapter: 7.5 A maximum. R7B Four-pin male locking mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Quick adapter: 7.5 A maximum. R7BF Four-pin female locking mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Custom cable option; no quick adapter is listed. Stripped and tinned leads Custom termination: lead 1 (white) +Vo, lead 2 (black) −Vo; standard L = 25 mm and L1 = 10 mm, with other lengths by request. No quick adapter is listed. Use the connector drawing view to identify pin numbers. Custom cable terminations are alternatives to the standard P1J connector. Safety and Isolation Listed safety standards UL62368-1, CSA C22.2 No.62368-1, TUV BS EN/EN62368-1. Input class Class II, without FG. Limited power source The series lists LPS compliance. Withstand voltage Input to output: 3 kVAC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety and EMC suitability must be confirmed for the completed equipment and installation. EMC Conducted and radiated emissions BS EN/EN55032 (CISPR32), FCC Part 15 / CISPR22 and CAN ICES-3(B)/NMB-3(B): Class B. Harmonic current and flicker BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. Radiated RF BS EN/EN61000-4-3: Level 2, 3 V/m. EFT / burst BS EN/EN61000-4-4: Level 2, 1 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV L–N. Conducted RF BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field BS EN/EN61000-4-8: Level 1, 1 A/m. Dips and interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods, 30% dip for 25 periods and >95% interruption for 250 periods. The adapter is treated as a component of the final system; reconfirm applicable EMC performance in the end equipment. Reliability, Applications and Measurement Conditions Service life 3 years at 100% load, 40°C and 12 operating hours per day. MTBF, minimum 507 thousand hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The datasheet lists a 3-year manufacturer warranty, subject to the manufacturer’s terms. Other voltage options 7.5 V, 18 V and 48 V versions are available by request; specify the required configuration and confirm availability before ordering. Listed applications include consumer electronics, telecommunications, office equipment and industrial equipment. Select the load and connection for this complete model. Unless otherwise specified, test conditions are 230 VAC input, rated load, 25°C and 70% RH. DC output voltage is measured at the plug terminal at 50% load. Ripple and noise are measured with 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input at rated load. Load regulation is measured from 0% to 100% rated load.

    Read more

    $38.44

    View options

  • SGAS15B05-P1J

    View options

    MEAN WELL SGAS15B series: Industrial Desktop AC/DC Power Adapter - SGAS15B05-P1J

    MEAN WELL SGAS15B05-P1J provides 5 V at up to 2.40 A, with a catalogue-rated output of 12 W. This Class II industrial desktop AC/DC adapter has an IEC320-C8 two-pole AC inlet and a centre-positive P1J output. Select the load within the current, power and temperature limits. Product Datasheet Download MEAN WELL SGAS15B Datasheet (PDF) The SGAS15B section is on PDF pages 30, 31, 32, 33, 34. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model SGAS15B05-P1J. Series and format SGAS15B single-output industrial desktop AC/DC power adapter. Model code SGAS is the adapter series; 15 is the power family; B denotes the IEC320-C8 two-pole AC inlet; 05 denotes 5 V output; P1J specifies the standard centre-positive output plug. DC output voltage 5 VDC. Rated output current 2.40 A. Output current range 0–2.40 A. Catalogue-rated output power 12 W, subject to temperature derating. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±5.0%. Line regulation ±0.5%. Load regulation ±5.0%. Efficiency, typical 79%. Keep the load within the stated output voltage, rated current and rated power limits simultaneously. Input and Energy Input voltage 90–264 VAC or 135–370 VDC. Frequency 47–63 Hz. Input connection IEC320-C8 two-pole AC inlet; Class II, without FG. AC current 0.4 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Set-up / rise time 3000 / 50 ms at full load. Leakage current, maximum 0.25 mA at 240 VAC. No-load consumption <0.075 W. Energy efficiency Level VI. USA EISA2007/DoE, EU ErP and CoC Version 5. Select a suitable mains lead for the C8 inlet and local supply; confirm mains-lead inclusion with the order. Protection Short circuit / overload 105–250% of rated output power; hiccup mode, automatically recovering after the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Derating and Environment Working temperature −20 to +70°C, subject to the load curve. Temperature-load curve 100% load from −20 to 40°C. The plotted reference levels are 80% at 50°C, 65% at 60°C and 50% at 70°C; follow the complete curve between these points. Static input curve, 60 Hz 100% load from 90 to 264 VAC; temperature derating still applies. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Mechanical Details and Connection Body dimensions, L × W × H 80 × 39 × 27.7 mm. Case Fully enclosed 94V-0 flame-retardant plastic enclosure. Output cable UL2468, 20 AWG; 1200 +150/−0 mm. Standard P1J output Tuning-fork plug, 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm insertion length; centre positive (C+), outside negative. Catalogue single-unit weight 130 g, explicitly listed in PACKING; a catalogue reference, not a measured shipment weight. Packing 72 pieces / 11 kg per carton. Match the DC plug dimensions and polarity to the equipment before connection. Allow space for the inlet or plug, cable and connector. Follow the supplied product marking and installation instructions. Optional DC Plugs and Quick Adapters Ordering and inclusion Custom cable termination is subject to MOQ. Quick adapters are sold separately without MOQ; they are options, not additional included plugs or outputs. Tuning-fork styles OD / ID / length in mm: P1I 5.5 / 2.1 / 9.5; P1L 5.5 / 2.5 / 9.5; P1M 5.5 / 2.5 / 11. Right-angle options: P1IR 5.5 / 2.1 / 9.5; P1JR 5.5 / 2.1 / 11; P1LR 5.5 / 2.5 / 9.5; P1MR 5.5 / 2.5 / 11. Quick adapters: 7.5 A maximum. Barrel styles P2I / P2IR 5.5 / 2.1 / 9.5 mm; P2J / P2JR 5.5 / 2.1 / 11 mm; P2L / P2LR 5.5 / 2.5 / 9.5 mm; P2M / P2MR 5.5 / 2.5 / 11 mm. R denotes right-angle form. Custom cable options; no quick adapter is listed. Locking styles P2S (S761K) 5.53 / 2.03 / 12.06 mm; P2K (761K) 5.53 / 2.54 / 12.06 mm; P2C (S760K) 5.53 / 2.03 / 9.52 mm; P2D (760K) 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent; custom cable options without a listed quick adapter. Mini-pin styles P3A 2.35 / 0.7 / 11 mm; P3B 4.0 / 1.7 / 11 mm; P3C 4.75 / 1.7 / 11 mm. EIAJ equivalent; quick adapters: 5 A maximum. Centre-pin styles OD / ID / length / centre pin in mm: P4A 5.5 / 3.4 / 11 / 1.0; P4B 6.5 / 4.4 / 11 / 1.4; P4C 7.4 / 5.1 / 11 / 0.6. EIAJ equivalent; quick adapters: 7.5 A maximum. Confirm the complete mating dimensions, voltage, polarity and load current. An accessory current rating does not increase this adapter’s 2.40 A output rating. Optional DIN Connectors and Lead Ends R6B Three-pin male locking mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo, pin 2 −Vo. Quick adapter: 7.5 A maximum. R7B Four-pin male locking mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Quick adapter: 7.5 A maximum. R7BF Four-pin female locking mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Custom cable option; no quick adapter is listed. Stripped and tinned leads Custom termination: lead 1 (white) +Vo, lead 2 (black) −Vo; standard L = 25 mm and L1 = 10 mm, with other lengths by request. No quick adapter is listed. Use the connector drawing view to identify pin numbers. Custom cable terminations are alternatives to the standard P1J connector. Safety and Isolation Listed safety standards UL62368-1, CSA C22.2 No.62368-1, TUV BS EN/EN62368-1. Input class Class II, without FG. Limited power source The series lists LPS compliance. Withstand voltage Input to output: 3 kVAC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety and EMC suitability must be confirmed for the completed equipment and installation. EMC Conducted and radiated emissions BS EN/EN55032 (CISPR32), FCC Part 15 / CISPR22 and CAN ICES-3(B)/NMB-3(B): Class B. Harmonic current and flicker BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. Radiated RF BS EN/EN61000-4-3: Level 2, 3 V/m. EFT / burst BS EN/EN61000-4-4: Level 2, 1 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV L–N. Conducted RF BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field BS EN/EN61000-4-8: Level 1, 1 A/m. Dips and interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods, 30% dip for 25 periods and >95% interruption for 250 periods. The adapter is treated as a component of the final system; reconfirm applicable EMC performance in the end equipment. Reliability, Applications and Measurement Conditions Service life 3 years at 100% load, 40°C and 12 operating hours per day. MTBF, minimum 507 thousand hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The datasheet lists a 3-year manufacturer warranty, subject to the manufacturer’s terms. Other voltage options 7.5 V, 18 V and 48 V versions are available by request; specify the required configuration and confirm availability before ordering. Listed applications include consumer electronics, telecommunications, office equipment and industrial equipment. Select the load and connection for this complete model. Unless otherwise specified, test conditions are 230 VAC input, rated load, 25°C and 70% RH. DC output voltage is measured at the plug terminal at 50% load. Ripple and noise are measured with 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input at rated load. Load regulation is measured from 0% to 100% rated load.

    Read more

    $38.44

    View options

  • SGAS15A24-P1J

    View options

    MEAN WELL SGAS15A series: Industrial Desktop AC/DC Power Adapter - SGAS15A24-P1J

    MEAN WELL SGAS15A24-P1J provides 24 V at up to 0.625 A, with a catalogue-rated output of 15 W. This Class I industrial desktop AC/DC adapter has an IEC320-C14 three-pole AC inlet and a centre-positive P1J output. Select the load within the current, power and temperature limits. Product Datasheet Download MEAN WELL SGAS15A Datasheet (PDF) The SGAS15A section is on PDF pages 25, 26, 27, 28, 29. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model SGAS15A24-P1J. Series and format SGAS15A single-output industrial desktop AC/DC power adapter. Model code SGAS is the adapter series; 15 is the power family; A denotes the IEC320-C14 three-pole AC inlet; 24 denotes 24 V output; P1J specifies the standard centre-positive output plug. DC output voltage 24 VDC. Rated output current 0.625 A. Output current range 0–0.625 A. Catalogue-rated output power 15 W, subject to temperature derating. Ripple and noise, maximum 100 mVp-p. Voltage tolerance ±2.0%. Line regulation ±0.5%. Load regulation ±2.0%. Efficiency, typical 86%. Keep the load within the stated output voltage, rated current and rated power limits simultaneously. Input and Energy Input voltage 90–264 VAC or 127–370 VDC. Frequency 47–63 Hz. Input connection IEC320-C14 three-pole AC inlet; Class I, with FG. AC current 0.4 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Set-up / rise time 3000 / 50 ms at full load. Leakage current, maximum 0.25 mA at 240 VAC. No-load consumption <0.075 W. Energy efficiency Level VI. USA EISA2007/DoE, EU ErP and CoC Version 5. Select a suitable mains lead for the C14 inlet and local supply; confirm mains-lead inclusion with the order. Protection Short circuit / overload 105–250% of rated output power; hiccup mode, automatically recovering after the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Derating and Environment Working temperature −20 to +70°C, subject to the load curve. Temperature-load curve 100% load from −20 to 40°C. The plotted reference levels are 80% at 50°C, 65% at 60°C and 50% at 70°C; follow the complete curve between these points. Static input curve, 60 Hz 100% load from 90 to 264 VAC; temperature derating still applies. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Mechanical Details and Connection Body dimensions, L × W × H 85.7 × 50.9 × 33.8 mm. Case Fully enclosed 94V-0 flame-retardant plastic enclosure. Output cable UL2468, 24 AWG; 1800 +150/−0 mm. Standard P1J output Tuning-fork plug, 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm insertion length; centre positive (C+), outside negative. Catalogue single-unit weight 150 g, explicitly listed in PACKING; a catalogue reference, not a measured shipment weight. Packing 90 pieces / 14 kg per carton. Match the DC plug dimensions and polarity to the equipment before connection. Allow space for the inlet or plug, cable and connector. Follow the supplied product marking and installation instructions. Optional DC Plugs and Quick Adapters Ordering and inclusion Custom cable termination is subject to MOQ. Quick adapters are sold separately without MOQ; they are options, not additional included plugs or outputs. Tuning-fork styles OD / ID / length in mm: P1I 5.5 / 2.1 / 9.5; P1L 5.5 / 2.5 / 9.5; P1M 5.5 / 2.5 / 11. Right-angle options: P1IR 5.5 / 2.1 / 9.5; P1JR 5.5 / 2.1 / 11; P1LR 5.5 / 2.5 / 9.5; P1MR 5.5 / 2.5 / 11. Quick adapters: 7.5 A maximum. Barrel styles P2I / P2IR 5.5 / 2.1 / 9.5 mm; P2J / P2JR 5.5 / 2.1 / 11 mm; P2L / P2LR 5.5 / 2.5 / 9.5 mm; P2M / P2MR 5.5 / 2.5 / 11 mm. R denotes right-angle form. Custom cable options; no quick adapter is listed. Locking styles P2S (S761K) 5.53 / 2.03 / 12.06 mm; P2K (761K) 5.53 / 2.54 / 12.06 mm; P2C (S760K) 5.53 / 2.03 / 9.52 mm; P2D (760K) 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent; custom cable options without a listed quick adapter. Mini-pin styles P3A 2.35 / 0.7 / 11 mm; P3B 4.0 / 1.7 / 11 mm; P3C 4.75 / 1.7 / 11 mm. EIAJ equivalent; quick adapters: 5 A maximum. Centre-pin styles OD / ID / length / centre pin in mm: P4A 5.5 / 3.4 / 11 / 1.0; P4B 6.5 / 4.4 / 11 / 1.4; P4C 7.4 / 5.1 / 11 / 0.6. EIAJ equivalent; quick adapters: 7.5 A maximum. Confirm the complete mating dimensions, voltage, polarity and load current. An accessory current rating does not increase this adapter’s 0.625 A output rating. Optional DIN Connectors and Lead Ends R6B Three-pin male locking mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo, pin 2 −Vo. Quick adapter: 7.5 A maximum. R7B Four-pin male locking mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Quick adapter: 7.5 A maximum. R7BF Four-pin female locking mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Custom cable option; no quick adapter is listed. Stripped and tinned leads Custom termination: lead 1 (white) +Vo, lead 2 (black) −Vo; standard L = 25 mm and L1 = 10 mm, with other lengths by request. No quick adapter is listed. Use the connector drawing view to identify pin numbers. Custom cable terminations are alternatives to the standard P1J connector. Safety and Isolation Listed safety standards UL62368-1, CSA C22.2 No.62368-1, TUV BS EN/EN62368-1. Input class Class I with protective earth (FG). Limited power source The series lists LPS compliance. Withstand voltage Input to output: 3 kVAC. Input to FG: 1.5 kVAC. Insulation resistance Input to output and input to FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety and EMC suitability must be confirmed for the completed equipment and installation. EMC Conducted and radiated emissions BS EN/EN55032 (CISPR32), FCC Part 15 / CISPR22 and CAN ICES-3(B)/NMB-3(B): Class B. Harmonic current and flicker BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. Radiated RF BS EN/EN61000-4-3: Level 2, 3 V/m. EFT / burst BS EN/EN61000-4-4: Level 2, 1 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV L–N; 2 kV L,N–PE. Conducted RF BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field BS EN/EN61000-4-8: Level 1, 1 A/m. Dips and interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods, 30% dip for 25 periods and >95% interruption for 250 periods. The adapter is treated as a component of the final system; reconfirm applicable EMC performance in the end equipment. Reliability, Applications and Measurement Conditions Service life 3 years at 100% load, 40°C and 12 operating hours per day. MTBF, minimum 507 thousand hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The datasheet lists a 3-year manufacturer warranty, subject to the manufacturer’s terms. Other voltage options 7.5 V, 18 V and 48 V versions are available by request; specify the required configuration and confirm availability before ordering. Listed applications include consumer electronics, telecommunications, office equipment and industrial equipment. Select the load and connection for this complete model. Unless otherwise specified, test conditions are 230 VAC input, rated load, 25°C and 70% RH. DC output voltage is measured at the plug terminal at 50% load. Ripple and noise are measured with 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input at rated load. Load regulation is measured from 0% to 100% rated load.

    Read more

    $38.44

    View options

  • SGAS15A15-P1J

    View options

    MEAN WELL SGAS15A series: Industrial Desktop AC/DC Power Adapter - SGAS15A15-P1J

    MEAN WELL SGAS15A15-P1J provides 15 V at up to 1.00 A, with a catalogue-rated output of 15 W. This Class I industrial desktop AC/DC adapter has an IEC320-C14 three-pole AC inlet and a centre-positive P1J output. Select the load within the current, power and temperature limits. Product Datasheet Download MEAN WELL SGAS15A Datasheet (PDF) The SGAS15A section is on PDF pages 25, 26, 27, 28, 29. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model SGAS15A15-P1J. Series and format SGAS15A single-output industrial desktop AC/DC power adapter. Model code SGAS is the adapter series; 15 is the power family; A denotes the IEC320-C14 three-pole AC inlet; 15 denotes 15 V output; P1J specifies the standard centre-positive output plug. DC output voltage 15 VDC. Rated output current 1.00 A. Output current range 0–1.00 A. Catalogue-rated output power 15 W, subject to temperature derating. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±3.0%. Line regulation ±0.5%. Load regulation ±3.0%. Efficiency, typical 85%. Keep the load within the stated output voltage, rated current and rated power limits simultaneously. Input and Energy Input voltage 90–264 VAC or 127–370 VDC. Frequency 47–63 Hz. Input connection IEC320-C14 three-pole AC inlet; Class I, with FG. AC current 0.4 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Set-up / rise time 3000 / 50 ms at full load. Leakage current, maximum 0.25 mA at 240 VAC. No-load consumption <0.075 W. Energy efficiency Level VI. USA EISA2007/DoE, EU ErP and CoC Version 5. Select a suitable mains lead for the C14 inlet and local supply; confirm mains-lead inclusion with the order. Protection Short circuit / overload 105–250% of rated output power; hiccup mode, automatically recovering after the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Derating and Environment Working temperature −20 to +70°C, subject to the load curve. Temperature-load curve 100% load from −20 to 40°C. The plotted reference levels are 80% at 50°C, 65% at 60°C and 50% at 70°C; follow the complete curve between these points. Static input curve, 60 Hz 100% load from 90 to 264 VAC; temperature derating still applies. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Mechanical Details and Connection Body dimensions, L × W × H 85.7 × 50.9 × 33.8 mm. Case Fully enclosed 94V-0 flame-retardant plastic enclosure. Output cable UL2468, 24 AWG; 1200 +150/−0 mm. Standard P1J output Tuning-fork plug, 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm insertion length; centre positive (C+), outside negative. Catalogue single-unit weight 150 g, explicitly listed in PACKING; a catalogue reference, not a measured shipment weight. Packing 90 pieces / 14 kg per carton. Match the DC plug dimensions and polarity to the equipment before connection. Allow space for the inlet or plug, cable and connector. Follow the supplied product marking and installation instructions. Optional DC Plugs and Quick Adapters Ordering and inclusion Custom cable termination is subject to MOQ. Quick adapters are sold separately without MOQ; they are options, not additional included plugs or outputs. Tuning-fork styles OD / ID / length in mm: P1I 5.5 / 2.1 / 9.5; P1L 5.5 / 2.5 / 9.5; P1M 5.5 / 2.5 / 11. Right-angle options: P1IR 5.5 / 2.1 / 9.5; P1JR 5.5 / 2.1 / 11; P1LR 5.5 / 2.5 / 9.5; P1MR 5.5 / 2.5 / 11. Quick adapters: 7.5 A maximum. Barrel styles P2I / P2IR 5.5 / 2.1 / 9.5 mm; P2J / P2JR 5.5 / 2.1 / 11 mm; P2L / P2LR 5.5 / 2.5 / 9.5 mm; P2M / P2MR 5.5 / 2.5 / 11 mm. R denotes right-angle form. Custom cable options; no quick adapter is listed. Locking styles P2S (S761K) 5.53 / 2.03 / 12.06 mm; P2K (761K) 5.53 / 2.54 / 12.06 mm; P2C (S760K) 5.53 / 2.03 / 9.52 mm; P2D (760K) 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent; custom cable options without a listed quick adapter. Mini-pin styles P3A 2.35 / 0.7 / 11 mm; P3B 4.0 / 1.7 / 11 mm; P3C 4.75 / 1.7 / 11 mm. EIAJ equivalent; quick adapters: 5 A maximum. Centre-pin styles OD / ID / length / centre pin in mm: P4A 5.5 / 3.4 / 11 / 1.0; P4B 6.5 / 4.4 / 11 / 1.4; P4C 7.4 / 5.1 / 11 / 0.6. EIAJ equivalent; quick adapters: 7.5 A maximum. Confirm the complete mating dimensions, voltage, polarity and load current. An accessory current rating does not increase this adapter’s 1.00 A output rating. Optional DIN Connectors and Lead Ends R6B Three-pin male locking mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo, pin 2 −Vo. Quick adapter: 7.5 A maximum. R7B Four-pin male locking mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Quick adapter: 7.5 A maximum. R7BF Four-pin female locking mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Custom cable option; no quick adapter is listed. Stripped and tinned leads Custom termination: lead 1 (white) +Vo, lead 2 (black) −Vo; standard L = 25 mm and L1 = 10 mm, with other lengths by request. No quick adapter is listed. Use the connector drawing view to identify pin numbers. Custom cable terminations are alternatives to the standard P1J connector. Safety and Isolation Listed safety standards UL62368-1, CSA C22.2 No.62368-1, TUV BS EN/EN62368-1. Input class Class I with protective earth (FG). Limited power source The series lists LPS compliance. Withstand voltage Input to output: 3 kVAC. Input to FG: 1.5 kVAC. Insulation resistance Input to output and input to FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety and EMC suitability must be confirmed for the completed equipment and installation. EMC Conducted and radiated emissions BS EN/EN55032 (CISPR32), FCC Part 15 / CISPR22 and CAN ICES-3(B)/NMB-3(B): Class B. Harmonic current and flicker BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. Radiated RF BS EN/EN61000-4-3: Level 2, 3 V/m. EFT / burst BS EN/EN61000-4-4: Level 2, 1 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV L–N; 2 kV L,N–PE. Conducted RF BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field BS EN/EN61000-4-8: Level 1, 1 A/m. Dips and interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods, 30% dip for 25 periods and >95% interruption for 250 periods. The adapter is treated as a component of the final system; reconfirm applicable EMC performance in the end equipment. Reliability, Applications and Measurement Conditions Service life 3 years at 100% load, 40°C and 12 operating hours per day. MTBF, minimum 507 thousand hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The datasheet lists a 3-year manufacturer warranty, subject to the manufacturer’s terms. Other voltage options 7.5 V, 18 V and 48 V versions are available by request; specify the required configuration and confirm availability before ordering. Listed applications include consumer electronics, telecommunications, office equipment and industrial equipment. Select the load and connection for this complete model. Unless otherwise specified, test conditions are 230 VAC input, rated load, 25°C and 70% RH. DC output voltage is measured at the plug terminal at 50% load. Ripple and noise are measured with 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input at rated load. Load regulation is measured from 0% to 100% rated load.

    Read more

    $38.44

    View options

  • SGAS15A12-P1J

    View options

    MEAN WELL SGAS15A series: Industrial Desktop AC/DC Power Adapter - SGAS15A12-P1J

    MEAN WELL SGAS15A12-P1J provides 12 V at up to 1.25 A, with a catalogue-rated output of 15 W. This Class I industrial desktop AC/DC adapter has an IEC320-C14 three-pole AC inlet and a centre-positive P1J output. Select the load within the current, power and temperature limits. Product Datasheet Download MEAN WELL SGAS15A Datasheet (PDF) The SGAS15A section is on PDF pages 25, 26, 27, 28, 29. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model SGAS15A12-P1J. Series and format SGAS15A single-output industrial desktop AC/DC power adapter. Model code SGAS is the adapter series; 15 is the power family; A denotes the IEC320-C14 three-pole AC inlet; 12 denotes 12 V output; P1J specifies the standard centre-positive output plug. DC output voltage 12 VDC. Rated output current 1.25 A. Output current range 0–1.25 A. Catalogue-rated output power 15 W, subject to temperature derating. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±3.0%. Line regulation ±0.5%. Load regulation ±3.0%. Efficiency, typical 85%. Keep the load within the stated output voltage, rated current and rated power limits simultaneously. Input and Energy Input voltage 90–264 VAC or 127–370 VDC. Frequency 47–63 Hz. Input connection IEC320-C14 three-pole AC inlet; Class I, with FG. AC current 0.4 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Set-up / rise time 3000 / 50 ms at full load. Leakage current, maximum 0.25 mA at 240 VAC. No-load consumption <0.075 W. Energy efficiency Level VI. USA EISA2007/DoE, EU ErP and CoC Version 5. Select a suitable mains lead for the C14 inlet and local supply; confirm mains-lead inclusion with the order. Protection Short circuit / overload 105–250% of rated output power; hiccup mode, automatically recovering after the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Derating and Environment Working temperature −20 to +70°C, subject to the load curve. Temperature-load curve 100% load from −20 to 40°C. The plotted reference levels are 80% at 50°C, 65% at 60°C and 50% at 70°C; follow the complete curve between these points. Static input curve, 60 Hz 100% load from 90 to 264 VAC; temperature derating still applies. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Mechanical Details and Connection Body dimensions, L × W × H 85.7 × 50.9 × 33.8 mm. Case Fully enclosed 94V-0 flame-retardant plastic enclosure. Output cable UL2468, 20 AWG; 1200 +150/−0 mm. Standard P1J output Tuning-fork plug, 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm insertion length; centre positive (C+), outside negative. Catalogue single-unit weight 150 g, explicitly listed in PACKING; a catalogue reference, not a measured shipment weight. Packing 90 pieces / 14 kg per carton. Match the DC plug dimensions and polarity to the equipment before connection. Allow space for the inlet or plug, cable and connector. Follow the supplied product marking and installation instructions. Optional DC Plugs and Quick Adapters Ordering and inclusion Custom cable termination is subject to MOQ. Quick adapters are sold separately without MOQ; they are options, not additional included plugs or outputs. Tuning-fork styles OD / ID / length in mm: P1I 5.5 / 2.1 / 9.5; P1L 5.5 / 2.5 / 9.5; P1M 5.5 / 2.5 / 11. Right-angle options: P1IR 5.5 / 2.1 / 9.5; P1JR 5.5 / 2.1 / 11; P1LR 5.5 / 2.5 / 9.5; P1MR 5.5 / 2.5 / 11. Quick adapters: 7.5 A maximum. Barrel styles P2I / P2IR 5.5 / 2.1 / 9.5 mm; P2J / P2JR 5.5 / 2.1 / 11 mm; P2L / P2LR 5.5 / 2.5 / 9.5 mm; P2M / P2MR 5.5 / 2.5 / 11 mm. R denotes right-angle form. Custom cable options; no quick adapter is listed. Locking styles P2S (S761K) 5.53 / 2.03 / 12.06 mm; P2K (761K) 5.53 / 2.54 / 12.06 mm; P2C (S760K) 5.53 / 2.03 / 9.52 mm; P2D (760K) 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent; custom cable options without a listed quick adapter. Mini-pin styles P3A 2.35 / 0.7 / 11 mm; P3B 4.0 / 1.7 / 11 mm; P3C 4.75 / 1.7 / 11 mm. EIAJ equivalent; quick adapters: 5 A maximum. Centre-pin styles OD / ID / length / centre pin in mm: P4A 5.5 / 3.4 / 11 / 1.0; P4B 6.5 / 4.4 / 11 / 1.4; P4C 7.4 / 5.1 / 11 / 0.6. EIAJ equivalent; quick adapters: 7.5 A maximum. Confirm the complete mating dimensions, voltage, polarity and load current. An accessory current rating does not increase this adapter’s 1.25 A output rating. Optional DIN Connectors and Lead Ends R6B Three-pin male locking mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo, pin 2 −Vo. Quick adapter: 7.5 A maximum. R7B Four-pin male locking mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Quick adapter: 7.5 A maximum. R7BF Four-pin female locking mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Custom cable option; no quick adapter is listed. Stripped and tinned leads Custom termination: lead 1 (white) +Vo, lead 2 (black) −Vo; standard L = 25 mm and L1 = 10 mm, with other lengths by request. No quick adapter is listed. Use the connector drawing view to identify pin numbers. Custom cable terminations are alternatives to the standard P1J connector. Safety and Isolation Listed safety standards UL62368-1, CSA C22.2 No.62368-1, TUV BS EN/EN62368-1. Input class Class I with protective earth (FG). Limited power source The series lists LPS compliance. Withstand voltage Input to output: 3 kVAC. Input to FG: 1.5 kVAC. Insulation resistance Input to output and input to FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety and EMC suitability must be confirmed for the completed equipment and installation. EMC Conducted and radiated emissions BS EN/EN55032 (CISPR32), FCC Part 15 / CISPR22 and CAN ICES-3(B)/NMB-3(B): Class B. Harmonic current and flicker BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. Radiated RF BS EN/EN61000-4-3: Level 2, 3 V/m. EFT / burst BS EN/EN61000-4-4: Level 2, 1 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV L–N; 2 kV L,N–PE. Conducted RF BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field BS EN/EN61000-4-8: Level 1, 1 A/m. Dips and interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods, 30% dip for 25 periods and >95% interruption for 250 periods. The adapter is treated as a component of the final system; reconfirm applicable EMC performance in the end equipment. Reliability, Applications and Measurement Conditions Service life 3 years at 100% load, 40°C and 12 operating hours per day. MTBF, minimum 507 thousand hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The datasheet lists a 3-year manufacturer warranty, subject to the manufacturer’s terms. Other voltage options 7.5 V, 18 V and 48 V versions are available by request; specify the required configuration and confirm availability before ordering. Listed applications include consumer electronics, telecommunications, office equipment and industrial equipment. Select the load and connection for this complete model. Unless otherwise specified, test conditions are 230 VAC input, rated load, 25°C and 70% RH. DC output voltage is measured at the plug terminal at 50% load. Ripple and noise are measured with 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input at rated load. Load regulation is measured from 0% to 100% rated load.

    Read more

    $38.44

    View options

  • SGAS15A09-P1J

    View options

    MEAN WELL SGAS15A series: Industrial Desktop AC/DC Power Adapter - SGAS15A09-P1J

    MEAN WELL SGAS15A09-P1J provides 9 V at up to 1.66 A, with a catalogue-rated output of 15 W. This Class I industrial desktop AC/DC adapter has an IEC320-C14 three-pole AC inlet and a centre-positive P1J output. Select the load within the current, power and temperature limits. Product Datasheet Download MEAN WELL SGAS15A Datasheet (PDF) The SGAS15A section is on PDF pages 25, 26, 27, 28, 29. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model SGAS15A09-P1J. Series and format SGAS15A single-output industrial desktop AC/DC power adapter. Model code SGAS is the adapter series; 15 is the power family; A denotes the IEC320-C14 three-pole AC inlet; 09 denotes 9 V output; P1J specifies the standard centre-positive output plug. DC output voltage 9 VDC. Rated output current 1.66 A. Output current range 0–1.66 A. Catalogue-rated output power 15 W, subject to temperature derating. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±5.0%. Line regulation ±0.5%. Load regulation ±5.0%. Efficiency, typical 84%. Keep the load within the stated output voltage, rated current and rated power limits simultaneously. Input and Energy Input voltage 90–264 VAC or 127–370 VDC. Frequency 47–63 Hz. Input connection IEC320-C14 three-pole AC inlet; Class I, with FG. AC current 0.4 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Set-up / rise time 3000 / 50 ms at full load. Leakage current, maximum 0.25 mA at 240 VAC. No-load consumption <0.075 W. Energy efficiency Level VI. USA EISA2007/DoE, EU ErP and CoC Version 5. Select a suitable mains lead for the C14 inlet and local supply; confirm mains-lead inclusion with the order. Protection Short circuit / overload 105–250% of rated output power; hiccup mode, automatically recovering after the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Derating and Environment Working temperature −20 to +70°C, subject to the load curve. Temperature-load curve 100% load from −20 to 40°C. The plotted reference levels are 80% at 50°C, 65% at 60°C and 50% at 70°C; follow the complete curve between these points. Static input curve, 60 Hz 100% load from 90 to 264 VAC; temperature derating still applies. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Mechanical Details and Connection Body dimensions, L × W × H 85.7 × 50.9 × 33.8 mm. Case Fully enclosed 94V-0 flame-retardant plastic enclosure. Output cable UL2468, 20 AWG; 1200 +150/−0 mm. Standard P1J output Tuning-fork plug, 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm insertion length; centre positive (C+), outside negative. Catalogue single-unit weight 150 g, explicitly listed in PACKING; a catalogue reference, not a measured shipment weight. Packing 90 pieces / 14 kg per carton. Match the DC plug dimensions and polarity to the equipment before connection. Allow space for the inlet or plug, cable and connector. Follow the supplied product marking and installation instructions. Optional DC Plugs and Quick Adapters Ordering and inclusion Custom cable termination is subject to MOQ. Quick adapters are sold separately without MOQ; they are options, not additional included plugs or outputs. Tuning-fork styles OD / ID / length in mm: P1I 5.5 / 2.1 / 9.5; P1L 5.5 / 2.5 / 9.5; P1M 5.5 / 2.5 / 11. Right-angle options: P1IR 5.5 / 2.1 / 9.5; P1JR 5.5 / 2.1 / 11; P1LR 5.5 / 2.5 / 9.5; P1MR 5.5 / 2.5 / 11. Quick adapters: 7.5 A maximum. Barrel styles P2I / P2IR 5.5 / 2.1 / 9.5 mm; P2J / P2JR 5.5 / 2.1 / 11 mm; P2L / P2LR 5.5 / 2.5 / 9.5 mm; P2M / P2MR 5.5 / 2.5 / 11 mm. R denotes right-angle form. Custom cable options; no quick adapter is listed. Locking styles P2S (S761K) 5.53 / 2.03 / 12.06 mm; P2K (761K) 5.53 / 2.54 / 12.06 mm; P2C (S760K) 5.53 / 2.03 / 9.52 mm; P2D (760K) 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent; custom cable options without a listed quick adapter. Mini-pin styles P3A 2.35 / 0.7 / 11 mm; P3B 4.0 / 1.7 / 11 mm; P3C 4.75 / 1.7 / 11 mm. EIAJ equivalent; quick adapters: 5 A maximum. Centre-pin styles OD / ID / length / centre pin in mm: P4A 5.5 / 3.4 / 11 / 1.0; P4B 6.5 / 4.4 / 11 / 1.4; P4C 7.4 / 5.1 / 11 / 0.6. EIAJ equivalent; quick adapters: 7.5 A maximum. Confirm the complete mating dimensions, voltage, polarity and load current. An accessory current rating does not increase this adapter’s 1.66 A output rating. Optional DIN Connectors and Lead Ends R6B Three-pin male locking mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo, pin 2 −Vo. Quick adapter: 7.5 A maximum. R7B Four-pin male locking mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Quick adapter: 7.5 A maximum. R7BF Four-pin female locking mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Custom cable option; no quick adapter is listed. Stripped and tinned leads Custom termination: lead 1 (white) +Vo, lead 2 (black) −Vo; standard L = 25 mm and L1 = 10 mm, with other lengths by request. No quick adapter is listed. Use the connector drawing view to identify pin numbers. Custom cable terminations are alternatives to the standard P1J connector. Safety and Isolation Listed safety standards UL62368-1, CSA C22.2 No.62368-1, TUV BS EN/EN62368-1. Input class Class I with protective earth (FG). Limited power source The series lists LPS compliance. Withstand voltage Input to output: 3 kVAC. Input to FG: 1.5 kVAC. Insulation resistance Input to output and input to FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety and EMC suitability must be confirmed for the completed equipment and installation. EMC Conducted and radiated emissions BS EN/EN55032 (CISPR32), FCC Part 15 / CISPR22 and CAN ICES-3(B)/NMB-3(B): Class B. Harmonic current and flicker BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. Radiated RF BS EN/EN61000-4-3: Level 2, 3 V/m. EFT / burst BS EN/EN61000-4-4: Level 2, 1 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV L–N; 2 kV L,N–PE. Conducted RF BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field BS EN/EN61000-4-8: Level 1, 1 A/m. Dips and interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods, 30% dip for 25 periods and >95% interruption for 250 periods. The adapter is treated as a component of the final system; reconfirm applicable EMC performance in the end equipment. Reliability, Applications and Measurement Conditions Service life 3 years at 100% load, 40°C and 12 operating hours per day. MTBF, minimum 507 thousand hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The datasheet lists a 3-year manufacturer warranty, subject to the manufacturer’s terms. Other voltage options 7.5 V, 18 V and 48 V versions are available by request; specify the required configuration and confirm availability before ordering. Listed applications include consumer electronics, telecommunications, office equipment and industrial equipment. Select the load and connection for this complete model. Unless otherwise specified, test conditions are 230 VAC input, rated load, 25°C and 70% RH. DC output voltage is measured at the plug terminal at 50% load. Ripple and noise are measured with 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input at rated load. Load regulation is measured from 0% to 100% rated load.

    Read more

    $38.44

    View options

  • SGAS15A05-P1J

    View options

    MEAN WELL SGAS15A series: Industrial Desktop AC/DC Power Adapter - SGAS15A05-P1J

    MEAN WELL SGAS15A05-P1J provides 5 V at up to 2.40 A, with a catalogue-rated output of 12 W. This Class I industrial desktop AC/DC adapter has an IEC320-C14 three-pole AC inlet and a centre-positive P1J output. Select the load within the current, power and temperature limits. Product Datasheet Download MEAN WELL SGAS15A Datasheet (PDF) The SGAS15A section is on PDF pages 25, 26, 27, 28, 29. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model SGAS15A05-P1J. Series and format SGAS15A single-output industrial desktop AC/DC power adapter. Model code SGAS is the adapter series; 15 is the power family; A denotes the IEC320-C14 three-pole AC inlet; 05 denotes 5 V output; P1J specifies the standard centre-positive output plug. DC output voltage 5 VDC. Rated output current 2.40 A. Output current range 0–2.40 A. Catalogue-rated output power 12 W, subject to temperature derating. Ripple and noise, maximum 80 mVp-p. Voltage tolerance ±5.0%. Line regulation ±0.5%. Load regulation ±5.0%. Efficiency, typical 79%. Keep the load within the stated output voltage, rated current and rated power limits simultaneously. Input and Energy Input voltage 90–264 VAC or 127–370 VDC. Frequency 47–63 Hz. Input connection IEC320-C14 three-pole AC inlet; Class I, with FG. AC current 0.4 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Set-up / rise time 3000 / 50 ms at full load. Leakage current, maximum 0.25 mA at 240 VAC. No-load consumption <0.075 W. Energy efficiency Level VI. USA EISA2007/DoE, EU ErP and CoC Version 5. Select a suitable mains lead for the C14 inlet and local supply; confirm mains-lead inclusion with the order. Protection Short circuit / overload 105–250% of rated output power; hiccup mode, automatically recovering after the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Derating and Environment Working temperature −20 to +70°C, subject to the load curve. Temperature-load curve 100% load from −20 to 40°C. The plotted reference levels are 80% at 50°C, 65% at 60°C and 50% at 70°C; follow the complete curve between these points. Static input curve, 60 Hz 100% load from 90 to 264 VAC; temperature derating still applies. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Mechanical Details and Connection Body dimensions, L × W × H 85.7 × 50.9 × 33.8 mm. Case Fully enclosed 94V-0 flame-retardant plastic enclosure. Output cable UL2468, 20 AWG; 1200 +150/−0 mm. Standard P1J output Tuning-fork plug, 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm insertion length; centre positive (C+), outside negative. Catalogue single-unit weight 150 g, explicitly listed in PACKING; a catalogue reference, not a measured shipment weight. Packing 90 pieces / 14 kg per carton. Match the DC plug dimensions and polarity to the equipment before connection. Allow space for the inlet or plug, cable and connector. Follow the supplied product marking and installation instructions. Optional DC Plugs and Quick Adapters Ordering and inclusion Custom cable termination is subject to MOQ. Quick adapters are sold separately without MOQ; they are options, not additional included plugs or outputs. Tuning-fork styles OD / ID / length in mm: P1I 5.5 / 2.1 / 9.5; P1L 5.5 / 2.5 / 9.5; P1M 5.5 / 2.5 / 11. Right-angle options: P1IR 5.5 / 2.1 / 9.5; P1JR 5.5 / 2.1 / 11; P1LR 5.5 / 2.5 / 9.5; P1MR 5.5 / 2.5 / 11. Quick adapters: 7.5 A maximum. Barrel styles P2I / P2IR 5.5 / 2.1 / 9.5 mm; P2J / P2JR 5.5 / 2.1 / 11 mm; P2L / P2LR 5.5 / 2.5 / 9.5 mm; P2M / P2MR 5.5 / 2.5 / 11 mm. R denotes right-angle form. Custom cable options; no quick adapter is listed. Locking styles P2S (S761K) 5.53 / 2.03 / 12.06 mm; P2K (761K) 5.53 / 2.54 / 12.06 mm; P2C (S760K) 5.53 / 2.03 / 9.52 mm; P2D (760K) 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent; custom cable options without a listed quick adapter. Mini-pin styles P3A 2.35 / 0.7 / 11 mm; P3B 4.0 / 1.7 / 11 mm; P3C 4.75 / 1.7 / 11 mm. EIAJ equivalent; quick adapters: 5 A maximum. Centre-pin styles OD / ID / length / centre pin in mm: P4A 5.5 / 3.4 / 11 / 1.0; P4B 6.5 / 4.4 / 11 / 1.4; P4C 7.4 / 5.1 / 11 / 0.6. EIAJ equivalent; quick adapters: 7.5 A maximum. Confirm the complete mating dimensions, voltage, polarity and load current. An accessory current rating does not increase this adapter’s 2.40 A output rating. Optional DIN Connectors and Lead Ends R6B Three-pin male locking mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo, pin 2 −Vo. Quick adapter: 7.5 A maximum. R7B Four-pin male locking mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Quick adapter: 7.5 A maximum. R7BF Four-pin female locking mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo, pins 2 and 3 −Vo. Custom cable option; no quick adapter is listed. Stripped and tinned leads Custom termination: lead 1 (white) +Vo, lead 2 (black) −Vo; standard L = 25 mm and L1 = 10 mm, with other lengths by request. No quick adapter is listed. Use the connector drawing view to identify pin numbers. Custom cable terminations are alternatives to the standard P1J connector. Safety and Isolation Listed safety standards UL62368-1, CSA C22.2 No.62368-1, TUV BS EN/EN62368-1. Input class Class I with protective earth (FG). Limited power source The series lists LPS compliance. Withstand voltage Input to output: 3 kVAC. Input to FG: 1.5 kVAC. Insulation resistance Input to output and input to FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Safety and EMC suitability must be confirmed for the completed equipment and installation. EMC Conducted and radiated emissions BS EN/EN55032 (CISPR32), FCC Part 15 / CISPR22 and CAN ICES-3(B)/NMB-3(B): Class B. Harmonic current and flicker BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. Radiated RF BS EN/EN61000-4-3: Level 2, 3 V/m. EFT / burst BS EN/EN61000-4-4: Level 2, 1 kV. Surge BS EN/EN61000-4-5: Level 3, 1 kV L–N; 2 kV L,N–PE. Conducted RF BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field BS EN/EN61000-4-8: Level 1, 1 A/m. Dips and interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods, 30% dip for 25 periods and >95% interruption for 250 periods. The adapter is treated as a component of the final system; reconfirm applicable EMC performance in the end equipment. Reliability, Applications and Measurement Conditions Service life 3 years at 100% load, 40°C and 12 operating hours per day. MTBF, minimum 507 thousand hours, MIL-HDBK-217F at 25°C. Manufacturer warranty The datasheet lists a 3-year manufacturer warranty, subject to the manufacturer’s terms. Other voltage options 7.5 V, 18 V and 48 V versions are available by request; specify the required configuration and confirm availability before ordering. Listed applications include consumer electronics, telecommunications, office equipment and industrial equipment. Select the load and connection for this complete model. Unless otherwise specified, test conditions are 230 VAC input, rated load, 25°C and 70% RH. DC output voltage is measured at the plug terminal at 50% load. Ripple and noise are measured with 20 MHz bandwidth, a 12-inch twisted pair and parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input at rated load. Load regulation is measured from 0% to 100% rated load.

    Read more

    $38.44

    View options

  • SGAS06E48-P1J

    View options

    MEAN WELL SGAS06E series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06E48-P1J

    MEAN WELL SGAS06E48-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin European mains plug, providing 48 VDC at 0.125 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06E Datasheet (PDF) The SGAS06E section is on PDF pages 20, 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06E48-P1J. Series / output code SGAS06E; code 48 identifies 48 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin European mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 48 VDC. Rated current / load range 0.125 A rated; 0–0.125 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±2%. Line regulation ±0.5%. Load regulation ±2%. Efficiency, typical 83% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EU ErP and CoC Version 5. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.5 × 30.5 × 20 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin European mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 24 AWG, 1800 mm +150/−0 mm for this output voltage. Catalogue unit weight 80 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 22 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals TUV BS EN/EN62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonics / flicker BS EN/EN61000-3-2, Class A; BS EN/EN61000-3-3. ESD immunity BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field / conducted RF BS EN/EN61000-4-3: Level 2, 3 V/m; BS EN/EN61000-4-6: Level 2, 3 V. EFT / surge BS EN/EN61000-4-4: Level 2, 1 kV; BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 period; 30% dip for 25 periods; >95% interruption for 250 periods. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 230 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 20–24. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06E24-P1J

    View options

    MEAN WELL SGAS06E series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06E24-P1J

    MEAN WELL SGAS06E24-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin European mains plug, providing 24 VDC at 0.25 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06E Datasheet (PDF) The SGAS06E section is on PDF pages 20, 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06E24-P1J. Series / output code SGAS06E; code 24 identifies 24 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin European mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 24 VDC. Rated current / load range 0.25 A rated; 0–0.25 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±2%. Line regulation ±0.5%. Load regulation ±2%. Efficiency, typical 82% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EU ErP and CoC Version 5. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.5 × 30.5 × 20 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin European mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 24 AWG, 1800 mm +150/−0 mm for this output voltage. Catalogue unit weight 80 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 22 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals TUV BS EN/EN62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonics / flicker BS EN/EN61000-3-2, Class A; BS EN/EN61000-3-3. ESD immunity BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field / conducted RF BS EN/EN61000-4-3: Level 2, 3 V/m; BS EN/EN61000-4-6: Level 2, 3 V. EFT / surge BS EN/EN61000-4-4: Level 2, 1 kV; BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 period; 30% dip for 25 periods; >95% interruption for 250 periods. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 230 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 20–24. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06E15-P1J

    View options

    MEAN WELL SGAS06E series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06E15-P1J

    MEAN WELL SGAS06E15-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin European mains plug, providing 15 VDC at 0.4 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06E Datasheet (PDF) The SGAS06E section is on PDF pages 20, 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06E15-P1J. Series / output code SGAS06E; code 15 identifies 15 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin European mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 15 VDC. Rated current / load range 0.4 A rated; 0–0.4 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±3%. Line regulation ±0.5%. Load regulation ±3%. Efficiency, typical 80% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EU ErP and CoC Version 5. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.5 × 30.5 × 20 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin European mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 24 AWG, 1800 mm +150/−0 mm for this output voltage. Catalogue unit weight 80 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 22 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals TUV BS EN/EN62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonics / flicker BS EN/EN61000-3-2, Class A; BS EN/EN61000-3-3. ESD immunity BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field / conducted RF BS EN/EN61000-4-3: Level 2, 3 V/m; BS EN/EN61000-4-6: Level 2, 3 V. EFT / surge BS EN/EN61000-4-4: Level 2, 1 kV; BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 period; 30% dip for 25 periods; >95% interruption for 250 periods. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 230 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 20–24. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06E12-P1J

    View options

    MEAN WELL SGAS06E series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06E12-P1J

    MEAN WELL SGAS06E12-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin European mains plug, providing 12 VDC at 0.5 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06E Datasheet (PDF) The SGAS06E section is on PDF pages 20, 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06E12-P1J. Series / output code SGAS06E; code 12 identifies 12 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin European mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 12 VDC. Rated current / load range 0.5 A rated; 0–0.5 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±3%. Line regulation ±0.5%. Load regulation ±3%. Efficiency, typical 79% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EU ErP and CoC Version 5. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.5 × 30.5 × 20 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin European mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 24 AWG, 1800 mm +150/−0 mm for this output voltage. Catalogue unit weight 80 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 22 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals TUV BS EN/EN62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonics / flicker BS EN/EN61000-3-2, Class A; BS EN/EN61000-3-3. ESD immunity BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field / conducted RF BS EN/EN61000-4-3: Level 2, 3 V/m; BS EN/EN61000-4-6: Level 2, 3 V. EFT / surge BS EN/EN61000-4-4: Level 2, 1 kV; BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 period; 30% dip for 25 periods; >95% interruption for 250 periods. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 230 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 20–24. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06E09-P1J

    View options

    MEAN WELL SGAS06E series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06E09-P1J

    MEAN WELL SGAS06E09-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin European mains plug, providing 9 VDC at 0.66 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06E Datasheet (PDF) The SGAS06E section is on PDF pages 20, 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06E09-P1J. Series / output code SGAS06E; code 09 identifies 9 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin European mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 9 VDC. Rated current / load range 0.66 A rated; 0–0.66 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±5%. Line regulation ±0.5%. Load regulation ±5%. Efficiency, typical 79% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EU ErP and CoC Version 5. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.5 × 30.5 × 20 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin European mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 20 AWG, 1200 mm +150/−0 mm for this output voltage. Catalogue unit weight 80 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 22 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals TUV BS EN/EN62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonics / flicker BS EN/EN61000-3-2, Class A; BS EN/EN61000-3-3. ESD immunity BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field / conducted RF BS EN/EN61000-4-3: Level 2, 3 V/m; BS EN/EN61000-4-6: Level 2, 3 V. EFT / surge BS EN/EN61000-4-4: Level 2, 1 kV; BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 period; 30% dip for 25 periods; >95% interruption for 250 periods. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 230 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 20–24. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06E07-P1J

    View options

    MEAN WELL SGAS06E series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06E07-P1J

    MEAN WELL SGAS06E07-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin European mains plug, providing 7.5 VDC at 0.8 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06E Datasheet (PDF) The SGAS06E section is on PDF pages 20, 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06E07-P1J. Series / output code SGAS06E; code 07 identifies 7.5 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin European mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 7.5 VDC. Rated current / load range 0.8 A rated; 0–0.8 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 85 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±5%. Line regulation ±0.5%. Load regulation ±5%. Efficiency, typical 77% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EU ErP and CoC Version 5. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.5 × 30.5 × 20 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin European mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 20 AWG, 1200 mm +150/−0 mm for this output voltage. Catalogue unit weight 80 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 22 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals TUV BS EN/EN62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonics / flicker BS EN/EN61000-3-2, Class A; BS EN/EN61000-3-3. ESD immunity BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field / conducted RF BS EN/EN61000-4-3: Level 2, 3 V/m; BS EN/EN61000-4-6: Level 2, 3 V. EFT / surge BS EN/EN61000-4-4: Level 2, 1 kV; BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 period; 30% dip for 25 periods; >95% interruption for 250 periods. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 230 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 20–24. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06E05-P1J

    View options

    MEAN WELL SGAS06E series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06E05-P1J

    MEAN WELL SGAS06E05-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin European mains plug, providing 5 VDC at 1 A with a 5 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06E Datasheet (PDF) The SGAS06E section is on PDF pages 20, 21, 22, 23, 24. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06E05-P1J. Series / output code SGAS06E; code 05 identifies 5 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin European mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 5 VDC. Rated current / load range 1 A rated; 0–1 A operating range. Rated power 5 W; observe the current limit and all applicable derating. Ripple and noise, maximum 75 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±5%. Line regulation ±0.5%. Load regulation ±5%. Efficiency, typical 75% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EU ErP and CoC Version 5. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.5 × 30.5 × 20 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin European mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 20 AWG, 1200 mm +150/−0 mm for this output voltage. Catalogue unit weight 80 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 22 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals TUV BS EN/EN62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonics / flicker BS EN/EN61000-3-2, Class A; BS EN/EN61000-3-3. ESD immunity BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field / conducted RF BS EN/EN61000-4-3: Level 2, 3 V/m; BS EN/EN61000-4-6: Level 2, 3 V. EFT / surge BS EN/EN61000-4-4: Level 2, 1 kV; BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 period; 30% dip for 25 periods; >95% interruption for 250 periods. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 230 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 20–24. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06U48-P1J

    View options

    MEAN WELL SGAS06U series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06U48-P1J

    MEAN WELL SGAS06U48-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin US mains plug, providing 48 VDC at 0.125 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06U Datasheet (PDF) The SGAS06U section is on PDF pages 15, 16, 17, 18, 19. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06U48-P1J. Series / output code SGAS06U; code 48 identifies 48 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin US mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 48 VDC. Rated current / load range 0.125 A rated; 0–0.125 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±2%. Line regulation ±0.5%. Load regulation ±2%. Efficiency, typical 84% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EISA 2007 / US DoE requirements. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.8 × 32.8 × 23.8 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin US mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 24 AWG, 1800 mm +150/−0 mm for this output voltage. Catalogue unit weight 70 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 17 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals UL62368-1 and CSA C22.2 No.62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions FCC Part 15 / CISPR22 and CAN ICES-3(B) / NMB-3(B), Class B. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 115 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 15–19. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06U24-P1J

    View options

    MEAN WELL SGAS06U series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06U24-P1J

    MEAN WELL SGAS06U24-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin US mains plug, providing 24 VDC at 0.25 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06U Datasheet (PDF) The SGAS06U section is on PDF pages 15, 16, 17, 18, 19. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06U24-P1J. Series / output code SGAS06U; code 24 identifies 24 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin US mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 24 VDC. Rated current / load range 0.25 A rated; 0–0.25 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±2%. Line regulation ±0.5%. Load regulation ±2%. Efficiency, typical 83% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EISA 2007 / US DoE requirements. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.8 × 32.8 × 23.8 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin US mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 24 AWG, 1800 mm +150/−0 mm for this output voltage. Catalogue unit weight 70 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 17 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals UL62368-1 and CSA C22.2 No.62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions FCC Part 15 / CISPR22 and CAN ICES-3(B) / NMB-3(B), Class B. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 115 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 15–19. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06U15-P1J

    View options

    MEAN WELL SGAS06U series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06U15-P1J

    MEAN WELL SGAS06U15-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin US mains plug, providing 15 VDC at 0.4 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06U Datasheet (PDF) The SGAS06U section is on PDF pages 15, 16, 17, 18, 19. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06U15-P1J. Series / output code SGAS06U; code 15 identifies 15 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin US mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 15 VDC. Rated current / load range 0.4 A rated; 0–0.4 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±3%. Line regulation ±0.5%. Load regulation ±3%. Efficiency, typical 81% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EISA 2007 / US DoE requirements. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.8 × 32.8 × 23.8 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin US mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 24 AWG, 1800 mm +150/−0 mm for this output voltage. Catalogue unit weight 70 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 17 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals UL62368-1 and CSA C22.2 No.62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions FCC Part 15 / CISPR22 and CAN ICES-3(B) / NMB-3(B), Class B. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 115 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 15–19. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06U12-P1J

    View options

    MEAN WELL SGAS06U series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06U12-P1J

    MEAN WELL SGAS06U12-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin US mains plug, providing 12 VDC at 0.5 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06U Datasheet (PDF) The SGAS06U section is on PDF pages 15, 16, 17, 18, 19. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06U12-P1J. Series / output code SGAS06U; code 12 identifies 12 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin US mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 12 VDC. Rated current / load range 0.5 A rated; 0–0.5 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±3%. Line regulation ±0.5%. Load regulation ±3%. Efficiency, typical 80% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EISA 2007 / US DoE requirements. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.8 × 32.8 × 23.8 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin US mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 24 AWG, 1800 mm +150/−0 mm for this output voltage. Catalogue unit weight 70 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 17 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals UL62368-1 and CSA C22.2 No.62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions FCC Part 15 / CISPR22 and CAN ICES-3(B) / NMB-3(B), Class B. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 115 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 15–19. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06U09-P1J

    View options

    MEAN WELL SGAS06U series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06U09-P1J

    MEAN WELL SGAS06U09-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin US mains plug, providing 9 VDC at 0.66 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06U Datasheet (PDF) The SGAS06U section is on PDF pages 15, 16, 17, 18, 19. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06U09-P1J. Series / output code SGAS06U; code 09 identifies 9 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin US mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 9 VDC. Rated current / load range 0.66 A rated; 0–0.66 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 80 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±5%. Line regulation ±0.5%. Load regulation ±5%. Efficiency, typical 80% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EISA 2007 / US DoE requirements. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.8 × 32.8 × 23.8 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin US mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 20 AWG, 1200 mm +150/−0 mm for this output voltage. Catalogue unit weight 70 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 17 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals UL62368-1 and CSA C22.2 No.62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions FCC Part 15 / CISPR22 and CAN ICES-3(B) / NMB-3(B), Class B. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 115 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 15–19. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06U07-P1J

    View options

    MEAN WELL SGAS06U series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06U07-P1J

    MEAN WELL SGAS06U07-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin US mains plug, providing 7.5 VDC at 0.8 A with a 6 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06U Datasheet (PDF) The SGAS06U section is on PDF pages 15, 16, 17, 18, 19. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06U07-P1J. Series / output code SGAS06U; code 07 identifies 7.5 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin US mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 7.5 VDC. Rated current / load range 0.8 A rated; 0–0.8 A operating range. Rated power 6 W; observe the current limit and all applicable derating. Ripple and noise, maximum 85 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±5%. Line regulation ±0.5%. Load regulation ±5%. Efficiency, typical 77% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EISA 2007 / US DoE requirements. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.8 × 32.8 × 23.8 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin US mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 20 AWG, 1200 mm +150/−0 mm for this output voltage. Catalogue unit weight 70 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 17 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals UL62368-1 and CSA C22.2 No.62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions FCC Part 15 / CISPR22 and CAN ICES-3(B) / NMB-3(B), Class B. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 115 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 15–19. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • SGAS06U05-P1J

    View options

    MEAN WELL SGAS06U series: Industrial Wall-Mounted AC/DC Power Adapter - SGAS06U05-P1J

    MEAN WELL SGAS06U05-P1J is a compact Class II industrial wall-mounted AC/DC power adapter with a two-pin US mains plug, providing 5 VDC at 1 A with a 5 W rated output. Its standard P1J connector is center-positive. Observe the ambient-temperature derating for the installation. Product Datasheet Download MEAN WELL SGAS06U Datasheet (PDF) The SGAS06U section is on PDF pages 15, 16, 17, 18, 19. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order model SGAS06U05-P1J. Series / output code SGAS06U; code 05 identifies 5 VDC. The series power number is not the rating of every voltage version. Mains connection two-pin US mains plug; Class II construction without a functional-ground connection. DC connection P1J standard tuning-fork plug: 5.5 mm outside diameter, 2.1 mm inside diameter, 11 ± 0.5 mm length; center positive and outer sleeve negative. Construction Single-output industrial wall-mounted adapter in a 94V-0 flame-retardant plastic enclosure; compact format for one outlet. Output Ratings DC output voltage 5 VDC. Rated current / load range 1 A rated; 0–1 A operating range. Rated power 5 W; observe the current limit and all applicable derating. Ripple and noise, maximum 75 mVp-p; measured with the bandwidth and termination stated below. Voltage tolerance ±5%. Line regulation ±0.5%. Load regulation ±5%. Efficiency, typical 75% under the general measurement conditions below. Input and Timing Input range 90–264 VAC or 127–370 VDC; AC frequency 47–63 Hz. AC input current 0.2 A at 100 VAC. Cold-start inrush, maximum 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise time 1500 ms / 50 ms at full load. No-load power Less than 0.1 W. Energy efficiency Level VI; complies with EISA 2007 / US DoE requirements. Protection Short circuit / overload 105–180% of rated output power for overload protection; hiccup mode with automatic recovery after the fault condition is removed. Overvoltage protection Threshold above 120% of rated output voltage; diode-clamp protection. Limited power source LPS compliance is listed for this series. Operating Conditions and Derating Operating temperature −20 to +70°C; full output is limited by the ambient-temperature curve. Temperature curve 100% load from −20 to +40°C; marked curve points are 85% at 50°C, 70% at 60°C and 50% at 70°C. Input-voltage curve 100% load across 90–264 VAC on the 60 Hz input curve. Operating humidity 20–90% RH, non-condensing. Storage temperature / humidity −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each on X, Y and Z axes. Apply both input-voltage and temperature limits. The upper ambient-temperature rating is not a full-load rating. Mechanical Details and Cable Body dimensions 41.8 × 32.8 × 23.8 mm (L × W × H); allow additional clearance for the mains pins and cable. Mains-plug arrangement two-pin US mains plug is integral to the adapter; no detachable AC cord is required. DC cable UL2468 20 AWG, 1200 mm +150/−0 mm for this output voltage. Catalogue unit weight 70 g, catalogue packing reference per unit; not a measured net or shipping weight. Use the dimensional drawing on PDF page 17 for the mains-pin geometry, outlet clearance and lead arrangement. Check the mating DC socket dimensions and polarity before connection. Optional DC Plugs and Accessories Tuning-fork choices P1I: 5.5 / 2.1 / 9.5; P1L: 5.5 / 2.5 / 9.5; P1M: 5.5 / 2.5 / 11; P1IR: 5.5 / 2.1 / 9.5; P1JR: 5.5 / 2.1 / 11; P1LR: 5.5 / 2.5 / 9.5; P1MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). Codes ending in R are right-angled; the others are straight. Quick adapters are listed with a 7.5 A maximum rating. Barrel choices P2I: 5.5 / 2.1 / 9.5; P2J: 5.5 / 2.1 / 11; P2L: 5.5 / 2.5 / 9.5; P2M: 5.5 / 2.5 / 11; P2IR: 5.5 / 2.1 / 9.5; P2JR: 5.5 / 2.1 / 11; P2LR: 5.5 / 2.5 / 9.5; P2MR: 5.5 / 2.5 / 11 mm (outside diameter / inside diameter / length). R suffix indicates right-angle form. Factory customization only; no quick adapter is listed. Locking choices P2S (S761K): 5.53 / 2.03 / 12.06; P2K (761K): 5.53 / 2.54 / 12.06; P2C (S760K): 5.53 / 2.03 / 9.52; P2D (760K): 5.53 / 2.54 / 9.52 mm (outside diameter / inside diameter / length). SWITCHCRAFT original or equivalent; factory customization only, with no quick adapter listed. Minimum-pin choices P3A: 2.35 / 0.7 / 11; P3B: 4.0 / 1.7 / 11; P3C: 4.75 / 1.7 / 11 mm (outside diameter / inside diameter / length). EIAJ equivalent; quick adapters are available with a 5 A maximum rating. Center-pin choices P4A: 5.5 / 3.4 / 11 / 1.0; P4B: 6.5 / 4.4 / 11 / 1.4; P4C: 7.4 / 5.1 / 11 / 0.6 mm (outside / inside / length / center-pin diameter). EIAJ equivalent; quick adapters are listed with a 7.5 A maximum rating. R6B, locking 3-pin male KYCON KPPX-3P equivalent; pins 1 and 3 = +Vo, pin 2 = −Vo. Quick adapter available, maximum 7.5 A. R7B, locking 4-pin male KYCON KPPX-4P equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Quick adapter available, maximum 7.5 A. R7BF, locking 4-pin female KYCON KPJX-CM-4S equivalent; pins 1 and 4 = +Vo, pins 2 and 3 = −Vo. Factory-customized option; no quick adapter is listed. The supplied configuration is the P1J order model above. Optional quick adapters are sold separately without a minimum-order requirement. Factory changes to the DC plug require a minimum order; confirm the requested assembly before ordering. Accessory current limits do not increase the adapter output rating. Confirm mating dimensions, polarity and the lower of the adapter, cable and connector current ratings. Custom stripped and tinned leads are also illustrated: lead 1 ribbed = +Vo; lead 2 lettered = −Vo. Standard drawing lengths are L = 25 mm and L1 = 10 mm; lengths may be customized. Confirm the lead assembly when ordering. Safety and EMC Listed safety approvals UL62368-1 and CSA C22.2 No.62368-1. Dielectric withstand Input to output: 4242 VDC. Insulation resistance Input to output: 100 MΩ at 500 VDC, 25°C and 70% RH. Conducted / radiated emissions FCC Part 15 / CISPR22 and CAN ICES-3(B) / NMB-3(B), Class B. Final equipment EMC performance depends on the installation and must be checked with the actual connected equipment. Measurement Conditions and Reliability General test conditions Unless otherwise specified: 115 VAC input, rated load, 25°C and 70% RH. DC voltage set point Measured at the output plug at 50% load. Ripple/noise measurement 20 MHz bandwidth; 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. MTBF, minimum 885 thousand hours, MIL-HDBK-217F at 25°C. Catalogue life condition 3 years at 100% load, 40°C and 12 hours/day. Manufacturer warranty 3 years, subject to manufacturer warranty terms. Catalogue revision 2022-04-26; combined PDF pages 15–19. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Line regulation is measured from low to high input voltage at rated load; load regulation is measured from 0% to 100% rated load. Applications and Selection Suitable application examples include consumer electronics, telecommunications equipment, office equipment and industrial equipment. Choose the exact mains-plug version, DC voltage, current capacity and output connector required by the equipment.

    Read more

    $29.57

    View options

  • GS06E-8P1J

    View options

    MEAN WELL GS06E series: Single-Output Industrial AC/DC Wall-Plug Power Adapter - GS06E-8P1J

    MEAN WELL GS06E-8P1J is a GS06E single-output AC/DC wall-plug power adapter rated at 48 VDC, 0.125 A and 6 W. Its Class II construction uses an integral two-pin European mains plug without protective earth. The standard P1J output plug is center positive. Apply the stated output-current, power and ambient-temperature limits together. Product Datasheet Download MEAN WELL GS06E Datasheet (PDF) The GS06E section is on PDF pages 10, 11, 12, 13, 14. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order number GS06E-8P1J. Safety model identifier GS06E-8. Product category Single-Output Industrial AC/DC Wall-Plug Power Adapter. AC plug / electrical class Two-pin European plug; Class II, no protective-earth pin. No-load power <0.1 W. Energy efficiency Level VI; EU ErP and Code of Conduct (CoC) Version 5. Limited-power classification LPS (Limited Power Source), as listed in the catalogue. Case Fully enclosed 94V-0 flame-retardant plastic case. Suitable applications listed for this series include consumer electronics, telecommunications, office equipment and industrial equipment. Model-Specific DC Output Nominal output 48 VDC. Rated output current 0.125 A. Current range 0.01–0.125 A. Catalogue-rated output power, maximum 6 W. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±5.0%. Line regulation ±0.5%. Load regulation ±5.0%. Efficiency, typical 83%. Observe the current and power limits together. The voltage set point is measured at the output connector terminals at 50% load. Input and Timing AC input 90–264 VAC; 47–63 Hz. DC input 127–370 VDC. AC input current 0.2 A at 100 VAC. Inrush current, maximum Cold start: 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise at full load 1500 / 50 ms; standard measurement input 230 VAC. Protection Short circuit / overload >110% of rated output power; hiccup operation, automatically recovering when the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Cooling and Environmental Limits Working ambient 0 to +50°C; apply derating. Temperature/load curve 100% load from 0°C to 40°C, decreasing to 70% at 50°C. Input/load curve 100% load across the specified 90–264 VAC range, subject to the temperature limits. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. The maximum ambient temperature does not imply full rated load. Keep the unit within both its electrical and temperature limits. Safety and Isolation Catalogue-listed safety standards TUV BS EN/EN62368-1 and EAC TP TC 004 approved, as listed in the specification table. Input/output withstand 4242 VDC. Insulation resistance Input/output: 100 MΩ at 500 VDC, 25°C and 70% RH. Evaluate the finished equipment for its applicable safety and EMC requirements with the adapter connected in the intended configuration. EMC Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 2, 3 V/m. EFT bursts BS EN/EN61000-4-4: Level 2, 1 kV. Surge susceptibility BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Conducted susceptibility BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Dimensions and Connections Dimensions, catalogue L × W × H 32 × 66 × 42.5 mm. Body outline 66 ±1 mm long × 32 ±1 mm wide; body height 42.5 ±1 mm. The catalogue dimension field lists 32 × 66 × 42.5 mm. Stepped outline / mains plug Stepped body height 62.5 ±1 mm; round-pin projection 19 ±0.5 mm. Fixed DC cable UL2468, 24 AWG; 1800 mm, +150/−0 mm. Standard output connector P1J tuning-fork plug: 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm length. Polarity C+: center/inside positive, outside negative. Optional DC Plugs and Accessories Dimension order Outside diameter / inside diameter / insertion length, in mm. Tuning-fork alternatives P1I: 5.5 / 2.1 / 9.5 mm; P1L: 5.5 / 2.5 / 9.5 mm; P1M: 5.5 / 2.5 / 11.0 mm; P1IR: 5.5 / 2.1 / 9.5 mm; P1JR: 5.5 / 2.1 / 11.0 mm; P1LR: 5.5 / 2.5 / 9.5 mm; P1MR: 5.5 / 2.5 / 11.0 mm. Barrel alternatives P2I: 5.5 / 2.1 / 9.5 mm; P2J: 5.5 / 2.1 / 11.0 mm; P2L: 5.5 / 2.5 / 9.5 mm; P2M: 5.5 / 2.5 / 11.0 mm; P2IR: 5.5 / 2.1 / 9.5 mm; P2JR: 5.5 / 2.1 / 11.0 mm; P2LR: 5.5 / 2.5 / 9.5 mm; P2MR: 5.5 / 2.5 / 11.0 mm. Locking alternatives P2S (S761K): 5.53 / 2.03 / 12.06 mm; P2K (761K): 5.53 / 2.54 / 12.06 mm; P2C (S760K): 5.53 / 2.03 / 9.52 mm; P2D (760K): 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent. Minimum-pin alternatives P3A: 2.35 / 0.7 / 11.0 mm; P3B: 4.0 / 1.7 / 11.0 mm; P3C: 4.75 / 1.7 / 11.0 mm. EIAJ equivalent. Center-pin alternatives P4A: 5.5 / 3.4 / 11.0 mm, center pin 1.0 mm; P4B: 6.5 / 4.4 / 11.0 mm, center pin 1.4 mm; P4C: 7.4 / 5.1 / 11.0 mm, center pin 0.6 mm. EIAJ equivalent. R6B Locking three-pin male mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo; pin 2 −Vo. R7B Locking four-pin male mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo; pins 2 and 3 −Vo. R7BF Locking four-pin female mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo; pins 2 and 3 −Vo. Stripped and tinned leads Custom termination: ribbed lead 1 = +Vo; letter-marked lead 2 = −Vo. Standard drawing lengths L = 25 mm and L1 = 10 mm; L1 may be customized. P1J is the standard termination of this order number. Factory changes to the listed plug styles are available by request with a minimum order quantity. Quick adapters are sold separately without a minimum order quantity; they are not supplied merely because a style is listed here. The quick-adapter table lists tuning-fork, center-pin, R6B and R7B types at 7.5 A maximum, and minimum-pin P3 types at 5 A maximum. The barrel, locking, R7BF and stripped/tinned entries have no quick-adapter availability listed. A connector rating does not increase the power adapter output rating. Choose the mating dimensions and polarity required by the equipment. Keep the load within both the power-adapter limits and the selected connector limits. Reliability and Packing Minimum MTBF ≥500 thousand hours, MIL-HDBK-217F at 25°C. Catalogue single-unit weight 100 g; explicit per-unit catalogue packing reference, not a measured shipping-package weight. Carton packing 90 pieces / 10 kg / carton. Manufacturer warranty 2 years, as stated in this catalogue. Measurement Conditions and Datasheet General measurement conditions Unless otherwise specified: 230 VAC, rated load, 25°C and 70% RH. Ripple/noise method 20 MHz bandwidth; a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. Voltage-tolerance scope Includes set-point error, line regulation and load regulation. Regulation measurements Line regulation: low to high input at rated load. Load regulation: 0–100% rated load. Catalogue revision 2022-04-15; combined PDF pages 10–14.

    Read more

    $55.20

    View options

  • GS06E-6P1J

    View options

    MEAN WELL GS06E series: Single-Output Industrial AC/DC Wall-Plug Power Adapter - GS06E-6P1J

    MEAN WELL GS06E-6P1J is a GS06E single-output AC/DC wall-plug power adapter rated at 24 VDC, 0.25 A and 6 W. Its Class II construction uses an integral two-pin European mains plug without protective earth. The standard P1J output plug is center positive. Apply the stated output-current, power and ambient-temperature limits together. Product Datasheet Download MEAN WELL GS06E Datasheet (PDF) The GS06E section is on PDF pages 10, 11, 12, 13, 14. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order number GS06E-6P1J. Safety model identifier GS06E-6. Product category Single-Output Industrial AC/DC Wall-Plug Power Adapter. AC plug / electrical class Two-pin European plug; Class II, no protective-earth pin. No-load power <0.1 W. Energy efficiency Level VI; EU ErP and Code of Conduct (CoC) Version 5. Limited-power classification LPS (Limited Power Source), as listed in the catalogue. Case Fully enclosed 94V-0 flame-retardant plastic case. Suitable applications listed for this series include consumer electronics, telecommunications, office equipment and industrial equipment. Model-Specific DC Output Nominal output 24 VDC. Rated output current 0.25 A. Current range 0.01–0.25 A. Catalogue-rated output power, maximum 6 W. Ripple and noise, maximum 180 mVp-p. Voltage tolerance ±5.0%. Line regulation ±0.5%. Load regulation ±5.0%. Efficiency, typical 81%. Observe the current and power limits together. The voltage set point is measured at the output connector terminals at 50% load. Input and Timing AC input 90–264 VAC; 47–63 Hz. DC input 127–370 VDC. AC input current 0.2 A at 100 VAC. Inrush current, maximum Cold start: 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise at full load 1500 / 50 ms; standard measurement input 230 VAC. Protection Short circuit / overload >110% of rated output power; hiccup operation, automatically recovering when the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Cooling and Environmental Limits Working ambient 0 to +50°C; apply derating. Temperature/load curve 100% load from 0°C to 40°C, decreasing to 70% at 50°C. Input/load curve 100% load across the specified 90–264 VAC range, subject to the temperature limits. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. The maximum ambient temperature does not imply full rated load. Keep the unit within both its electrical and temperature limits. Safety and Isolation Catalogue-listed safety standards TUV BS EN/EN62368-1 and EAC TP TC 004 approved, as listed in the specification table. Input/output withstand 4242 VDC. Insulation resistance Input/output: 100 MΩ at 500 VDC, 25°C and 70% RH. Evaluate the finished equipment for its applicable safety and EMC requirements with the adapter connected in the intended configuration. EMC Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 2, 3 V/m. EFT bursts BS EN/EN61000-4-4: Level 2, 1 kV. Surge susceptibility BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Conducted susceptibility BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Dimensions and Connections Dimensions, catalogue L × W × H 32 × 66 × 42.5 mm. Body outline 66 ±1 mm long × 32 ±1 mm wide; body height 42.5 ±1 mm. The catalogue dimension field lists 32 × 66 × 42.5 mm. Stepped outline / mains plug Stepped body height 62.5 ±1 mm; round-pin projection 19 ±0.5 mm. Fixed DC cable UL2468, 24 AWG; 1800 mm, +150/−0 mm. Standard output connector P1J tuning-fork plug: 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm length. Polarity C+: center/inside positive, outside negative. Optional DC Plugs and Accessories Dimension order Outside diameter / inside diameter / insertion length, in mm. Tuning-fork alternatives P1I: 5.5 / 2.1 / 9.5 mm; P1L: 5.5 / 2.5 / 9.5 mm; P1M: 5.5 / 2.5 / 11.0 mm; P1IR: 5.5 / 2.1 / 9.5 mm; P1JR: 5.5 / 2.1 / 11.0 mm; P1LR: 5.5 / 2.5 / 9.5 mm; P1MR: 5.5 / 2.5 / 11.0 mm. Barrel alternatives P2I: 5.5 / 2.1 / 9.5 mm; P2J: 5.5 / 2.1 / 11.0 mm; P2L: 5.5 / 2.5 / 9.5 mm; P2M: 5.5 / 2.5 / 11.0 mm; P2IR: 5.5 / 2.1 / 9.5 mm; P2JR: 5.5 / 2.1 / 11.0 mm; P2LR: 5.5 / 2.5 / 9.5 mm; P2MR: 5.5 / 2.5 / 11.0 mm. Locking alternatives P2S (S761K): 5.53 / 2.03 / 12.06 mm; P2K (761K): 5.53 / 2.54 / 12.06 mm; P2C (S760K): 5.53 / 2.03 / 9.52 mm; P2D (760K): 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent. Minimum-pin alternatives P3A: 2.35 / 0.7 / 11.0 mm; P3B: 4.0 / 1.7 / 11.0 mm; P3C: 4.75 / 1.7 / 11.0 mm. EIAJ equivalent. Center-pin alternatives P4A: 5.5 / 3.4 / 11.0 mm, center pin 1.0 mm; P4B: 6.5 / 4.4 / 11.0 mm, center pin 1.4 mm; P4C: 7.4 / 5.1 / 11.0 mm, center pin 0.6 mm. EIAJ equivalent. R6B Locking three-pin male mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo; pin 2 −Vo. R7B Locking four-pin male mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo; pins 2 and 3 −Vo. R7BF Locking four-pin female mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo; pins 2 and 3 −Vo. Stripped and tinned leads Custom termination: ribbed lead 1 = +Vo; letter-marked lead 2 = −Vo. Standard drawing lengths L = 25 mm and L1 = 10 mm; L1 may be customized. P1J is the standard termination of this order number. Factory changes to the listed plug styles are available by request with a minimum order quantity. Quick adapters are sold separately without a minimum order quantity; they are not supplied merely because a style is listed here. The quick-adapter table lists tuning-fork, center-pin, R6B and R7B types at 7.5 A maximum, and minimum-pin P3 types at 5 A maximum. The barrel, locking, R7BF and stripped/tinned entries have no quick-adapter availability listed. A connector rating does not increase the power adapter output rating. Choose the mating dimensions and polarity required by the equipment. Keep the load within both the power-adapter limits and the selected connector limits. Reliability and Packing Minimum MTBF ≥500 thousand hours, MIL-HDBK-217F at 25°C. Catalogue single-unit weight 100 g; explicit per-unit catalogue packing reference, not a measured shipping-package weight. Carton packing 90 pieces / 10 kg / carton. Manufacturer warranty 2 years, as stated in this catalogue. Measurement Conditions and Datasheet General measurement conditions Unless otherwise specified: 230 VAC, rated load, 25°C and 70% RH. Ripple/noise method 20 MHz bandwidth; a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. Voltage-tolerance scope Includes set-point error, line regulation and load regulation. Regulation measurements Line regulation: low to high input at rated load. Load regulation: 0–100% rated load. Catalogue revision 2022-04-15; combined PDF pages 10–14.

    Read more

    $55.20

    View options

  • GS06E-5P1J

    View options

    MEAN WELL GS06E series: Single-Output Industrial AC/DC Wall-Plug Power Adapter - GS06E-5P1J

    MEAN WELL GS06E-5P1J is a GS06E single-output AC/DC wall-plug power adapter rated at 18 VDC, 0.33 A and 6 W. Its Class II construction uses an integral two-pin European mains plug without protective earth. The standard P1J output plug is center positive. Apply the stated output-current, power and ambient-temperature limits together. Product Datasheet Download MEAN WELL GS06E Datasheet (PDF) The GS06E section is on PDF pages 10, 11, 12, 13, 14. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete order number GS06E-5P1J. Safety model identifier GS06E-5. Product category Single-Output Industrial AC/DC Wall-Plug Power Adapter. AC plug / electrical class Two-pin European plug; Class II, no protective-earth pin. No-load power <0.1 W. Energy efficiency Level VI; EU ErP and Code of Conduct (CoC) Version 5. Limited-power classification LPS (Limited Power Source), as listed in the catalogue. Case Fully enclosed 94V-0 flame-retardant plastic case. Suitable applications listed for this series include consumer electronics, telecommunications, office equipment and industrial equipment. Model-Specific DC Output Nominal output 18 VDC. Rated output current 0.33 A. Current range 0.01–0.33 A. Catalogue-rated output power, maximum 6 W. Ripple and noise, maximum 150 mVp-p. Voltage tolerance ±5.0%. Line regulation ±0.5%. Load regulation ±5.0%. Efficiency, typical 81%. Observe the current and power limits together. The voltage set point is measured at the output connector terminals at 50% load. Input and Timing AC input 90–264 VAC; 47–63 Hz. DC input 127–370 VDC. AC input current 0.2 A at 100 VAC. Inrush current, maximum Cold start: 30 A at 115 VAC; 50 A at 230 VAC. Leakage current, maximum 0.25 mA at 240 VAC. Set-up / rise at full load 1500 / 50 ms; standard measurement input 230 VAC. Protection Short circuit / overload >110% of rated output power; hiccup operation, automatically recovering when the abnormal load is removed. Overvoltage >120% of rated output voltage; diode clamping. Cooling and Environmental Limits Working ambient 0 to +50°C; apply derating. Temperature/load curve 100% load from 0°C to 40°C, decreasing to 70% at 50°C. Input/load curve 100% load across the specified 90–264 VAC range, subject to the temperature limits. Working humidity 20–90% RH, non-condensing. Storage −20 to +85°C; 10–95% RH, non-condensing. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration 10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. The maximum ambient temperature does not imply full rated load. Keep the unit within both its electrical and temperature limits. Safety and Isolation Catalogue-listed safety standards TUV BS EN/EN62368-1 and EAC TP TC 004 approved, as listed in the specification table. Input/output withstand 4242 VDC. Insulation resistance Input/output: 100 MΩ at 500 VDC, 25°C and 70% RH. Evaluate the finished equipment for its applicable safety and EMC requirements with the adapter connected in the intended configuration. EMC Conducted / radiated emissions BS EN/EN55032 (CISPR32), Class B. Harmonic current BS EN/EN61000-3-2, Class A. Voltage flicker BS EN/EN61000-3-3. ESD BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact. RF field susceptibility BS EN/EN61000-4-3: Level 2, 3 V/m. EFT bursts BS EN/EN61000-4-4: Level 2, 1 kV. Surge susceptibility BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral. Conducted susceptibility BS EN/EN61000-4-6: Level 2, 3 V. Magnetic field immunity BS EN/EN61000-4-8: Level 1, 1 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods. Dimensions and Connections Dimensions, catalogue L × W × H 32 × 66 × 42.5 mm. Body outline 66 ±1 mm long × 32 ±1 mm wide; body height 42.5 ±1 mm. The catalogue dimension field lists 32 × 66 × 42.5 mm. Stepped outline / mains plug Stepped body height 62.5 ±1 mm; round-pin projection 19 ±0.5 mm. Fixed DC cable UL2468, 24 AWG; 1800 mm, +150/−0 mm. Standard output connector P1J tuning-fork plug: 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm length. Polarity C+: center/inside positive, outside negative. Optional DC Plugs and Accessories Dimension order Outside diameter / inside diameter / insertion length, in mm. Tuning-fork alternatives P1I: 5.5 / 2.1 / 9.5 mm; P1L: 5.5 / 2.5 / 9.5 mm; P1M: 5.5 / 2.5 / 11.0 mm; P1IR: 5.5 / 2.1 / 9.5 mm; P1JR: 5.5 / 2.1 / 11.0 mm; P1LR: 5.5 / 2.5 / 9.5 mm; P1MR: 5.5 / 2.5 / 11.0 mm. Barrel alternatives P2I: 5.5 / 2.1 / 9.5 mm; P2J: 5.5 / 2.1 / 11.0 mm; P2L: 5.5 / 2.5 / 9.5 mm; P2M: 5.5 / 2.5 / 11.0 mm; P2IR: 5.5 / 2.1 / 9.5 mm; P2JR: 5.5 / 2.1 / 11.0 mm; P2LR: 5.5 / 2.5 / 9.5 mm; P2MR: 5.5 / 2.5 / 11.0 mm. Locking alternatives P2S (S761K): 5.53 / 2.03 / 12.06 mm; P2K (761K): 5.53 / 2.54 / 12.06 mm; P2C (S760K): 5.53 / 2.03 / 9.52 mm; P2D (760K): 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent. Minimum-pin alternatives P3A: 2.35 / 0.7 / 11.0 mm; P3B: 4.0 / 1.7 / 11.0 mm; P3C: 4.75 / 1.7 / 11.0 mm. EIAJ equivalent. Center-pin alternatives P4A: 5.5 / 3.4 / 11.0 mm, center pin 1.0 mm; P4B: 6.5 / 4.4 / 11.0 mm, center pin 1.4 mm; P4C: 7.4 / 5.1 / 11.0 mm, center pin 0.6 mm. EIAJ equivalent. R6B Locking three-pin male mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo; pin 2 −Vo. R7B Locking four-pin male mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo; pins 2 and 3 −Vo. R7BF Locking four-pin female mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo; pins 2 and 3 −Vo. Stripped and tinned leads Custom termination: ribbed lead 1 = +Vo; letter-marked lead 2 = −Vo. Standard drawing lengths L = 25 mm and L1 = 10 mm; L1 may be customized. P1J is the standard termination of this order number. Factory changes to the listed plug styles are available by request with a minimum order quantity. Quick adapters are sold separately without a minimum order quantity; they are not supplied merely because a style is listed here. The quick-adapter table lists tuning-fork, center-pin, R6B and R7B types at 7.5 A maximum, and minimum-pin P3 types at 5 A maximum. The barrel, locking, R7BF and stripped/tinned entries have no quick-adapter availability listed. A connector rating does not increase the power adapter output rating. Choose the mating dimensions and polarity required by the equipment. Keep the load within both the power-adapter limits and the selected connector limits. Reliability and Packing Minimum MTBF ≥500 thousand hours, MIL-HDBK-217F at 25°C. Catalogue single-unit weight 100 g; explicit per-unit catalogue packing reference, not a measured shipping-package weight. Carton packing 90 pieces / 10 kg / carton. Manufacturer warranty 2 years, as stated in this catalogue. Measurement Conditions and Datasheet General measurement conditions Unless otherwise specified: 230 VAC, rated load, 25°C and 70% RH. Ripple/noise method 20 MHz bandwidth; a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors. Voltage-tolerance scope Includes set-point error, line regulation and load regulation. Regulation measurements Line regulation: low to high input at rated load. Load regulation: 0–100% rated load. Catalogue revision 2022-04-15; combined PDF pages 10–14.

    Read more

    $55.20

    View options

You have seen 48 out of 62 products
