MEAN WELL GS06E-11P1J is a GS06E single-output AC/DC wall-plug power adapter rated at 7.5 VDC, 0.8 A and 6 W. Its Class II construction uses an integral two-pin European mains plug without protective earth. The standard P1J output plug is center positive. Apply the stated output-current, power and ambient-temperature limits together.
Product Datasheet
Download MEAN WELL GS06E Datasheet (PDF)
The GS06E section is on PDF pages 10, 11, 12, 13, 14. Refer to the complete mechanical drawings and notes when planning installation.
Model and Configuration
Complete order number
GS06E-11P1J.
Safety model identifier
GS06E-1-1.
Product category
Single-Output Industrial AC/DC Wall-Plug Power Adapter.
AC plug / electrical class
Two-pin European plug; Class II, no protective-earth pin.
No-load power
<0.1 W.
Energy efficiency
Level VI; EU ErP and Code of Conduct (CoC) Version 5.
Limited-power classification
LPS (Limited Power Source), as listed in the catalogue.
Case
Fully enclosed 94V-0 flame-retardant plastic case.
Suitable applications listed for this series include consumer electronics, telecommunications, office equipment and industrial equipment.
Model-Specific DC Output
Nominal output
7.5 VDC.
Rated output current
0.8 A.
Current range
0.01–0.8 A.
Catalogue-rated output power, maximum
6 W.
Ripple and noise, maximum
80 mVp-p.
Voltage tolerance
±5.0%.
Line regulation
±0.5%.
Load regulation
±5.0%.
Efficiency, typical
80%.
Observe the current and power limits together. The voltage set point is measured at the output connector terminals at 50% load.
Input and Timing
AC input
90–264 VAC; 47–63 Hz.
DC input
127–370 VDC.
AC input current
0.2 A at 100 VAC.
Inrush current, maximum
Cold start: 30 A at 115 VAC; 50 A at 230 VAC.
Leakage current, maximum
0.25 mA at 240 VAC.
Set-up / rise at full load
1500 / 50 ms; standard measurement input 230 VAC.
Protection
Short circuit / overload
>110% of rated output power; hiccup operation, automatically recovering when the abnormal load is removed.
Overvoltage
>120% of rated output voltage; diode clamping.
Cooling and Environmental Limits
Working ambient
0 to +50°C; apply derating.
Temperature/load curve
100% load from 0°C to 40°C, decreasing to 70% at 50°C.
Input/load curve
100% load across the specified 90–264 VAC range, subject to the temperature limits.
Working humidity
20–90% RH, non-condensing.
Storage
−20 to +85°C; 10–95% RH, non-condensing.
Temperature coefficient
±0.03%/°C over 0–40°C.
Vibration
10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis.
The maximum ambient temperature does not imply full rated load. Keep the unit within both its electrical and temperature limits.
Safety and Isolation
Catalogue-listed safety standards
TUV BS EN/EN62368-1 and EAC TP TC 004 approved, as listed in the specification table.
Input/output withstand
4242 VDC.
Insulation resistance
Input/output: 100 MΩ at 500 VDC, 25°C and 70% RH.
Evaluate the finished equipment for its applicable safety and EMC requirements with the adapter connected in the intended configuration.
EMC
Conducted / radiated emissions
BS EN/EN55032 (CISPR32), Class B.
Harmonic current
BS EN/EN61000-3-2, Class A.
Voltage flicker
BS EN/EN61000-3-3.
ESD
BS EN/EN61000-4-2: Level 3, 8 kV air; Level 2, 4 kV contact.
RF field susceptibility
BS EN/EN61000-4-3: Level 2, 3 V/m.
EFT bursts
BS EN/EN61000-4-4: Level 2, 1 kV.
Surge susceptibility
BS EN/EN61000-4-5: Level 3, 1 kV line-to-neutral.
Conducted susceptibility
BS EN/EN61000-4-6: Level 2, 3 V.
Magnetic field immunity
BS EN/EN61000-4-8: Level 1, 1 A/m.
Voltage dips / interruptions
BS EN/EN61000-4-11: >95% dip for 0.5 periods; 30% dip for 25 periods; >95% interruption for 250 periods.
Dimensions and Connections
Dimensions, catalogue L × W × H
32 × 66 × 42.5 mm.
Body outline
66 ±1 mm long × 32 ±1 mm wide; body height 42.5 ±1 mm. The catalogue dimension field lists 32 × 66 × 42.5 mm.
Stepped outline / mains plug
Stepped body height 62.5 ±1 mm; round-pin projection 19 ±0.5 mm.
Fixed DC cable
UL2468, 20 AWG; 1200 mm, +150/−0 mm.
Standard output connector
P1J tuning-fork plug: 5.5 mm outside diameter × 2.1 mm inside diameter × 11 ±0.5 mm length.
Polarity
C+: center/inside positive, outside negative.
Optional DC Plugs and Accessories
Dimension order
Outside diameter / inside diameter / insertion length, in mm.
Tuning-fork alternatives
P1I: 5.5 / 2.1 / 9.5 mm; P1L: 5.5 / 2.5 / 9.5 mm; P1M: 5.5 / 2.5 / 11.0 mm; P1IR: 5.5 / 2.1 / 9.5 mm; P1JR: 5.5 / 2.1 / 11.0 mm; P1LR: 5.5 / 2.5 / 9.5 mm; P1MR: 5.5 / 2.5 / 11.0 mm.
Barrel alternatives
P2I: 5.5 / 2.1 / 9.5 mm; P2J: 5.5 / 2.1 / 11.0 mm; P2L: 5.5 / 2.5 / 9.5 mm; P2M: 5.5 / 2.5 / 11.0 mm; P2IR: 5.5 / 2.1 / 9.5 mm; P2JR: 5.5 / 2.1 / 11.0 mm; P2LR: 5.5 / 2.5 / 9.5 mm; P2MR: 5.5 / 2.5 / 11.0 mm.
Locking alternatives
P2S (S761K): 5.53 / 2.03 / 12.06 mm; P2K (761K): 5.53 / 2.54 / 12.06 mm; P2C (S760K): 5.53 / 2.03 / 9.52 mm; P2D (760K): 5.53 / 2.54 / 9.52 mm. SWITCHCRAFT original or equivalent.
Minimum-pin alternatives
P3A: 2.35 / 0.7 / 11.0 mm; P3B: 4.0 / 1.7 / 11.0 mm; P3C: 4.75 / 1.7 / 11.0 mm. EIAJ equivalent.
Center-pin alternatives
P4A: 5.5 / 3.4 / 11.0 mm, center pin 1.0 mm; P4B: 6.5 / 4.4 / 11.0 mm, center pin 1.4 mm; P4C: 7.4 / 5.1 / 11.0 mm, center pin 0.6 mm. EIAJ equivalent.
R6B
Locking three-pin male mini-DIN, KYCON KPPX-3P equivalent: pins 1 and 3 +Vo; pin 2 −Vo.
R7B
Locking four-pin male mini-DIN, KYCON KPPX-4P equivalent: pins 1 and 4 +Vo; pins 2 and 3 −Vo.
R7BF
Locking four-pin female mini-DIN, KYCON KPJX-CM-4S equivalent: pins 1 and 4 +Vo; pins 2 and 3 −Vo.
Stripped and tinned leads
Custom termination: ribbed lead 1 = +Vo; letter-marked lead 2 = −Vo. Standard drawing lengths L = 25 mm and L1 = 10 mm; L1 may be customized.
P1J is the standard termination of this order number. Factory changes to the listed plug styles are available by request with a minimum order quantity. Quick adapters are sold separately without a minimum order quantity; they are not supplied merely because a style is listed here.
The quick-adapter table lists tuning-fork, center-pin, R6B and R7B types at 7.5 A maximum, and minimum-pin P3 types at 5 A maximum. The barrel, locking, R7BF and stripped/tinned entries have no quick-adapter availability listed. A connector rating does not increase the power adapter output rating.
Choose the mating dimensions and polarity required by the equipment. Keep the load within both the power-adapter limits and the selected connector limits.
Reliability and Packing
Minimum MTBF
≥500 thousand hours, MIL-HDBK-217F at 25°C.
Catalogue single-unit weight
100 g; explicit per-unit catalogue packing reference, not a measured shipping-package weight.
Carton packing
90 pieces / 10 kg / carton.
Manufacturer warranty
2 years, as stated in this catalogue.
Measurement Conditions and Datasheet
General measurement conditions
Unless otherwise specified: 230 VAC, rated load, 25°C and 70% RH.
Ripple/noise method
20 MHz bandwidth; a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors.
Voltage-tolerance scope
Includes set-point error, line regulation and load regulation.
Regulation measurements
Line regulation: low to high input at rated load. Load regulation: 0–100% rated load.
Catalogue revision
2022-04-15; combined PDF pages 10–14.
