HVGC Series: Constant Current LED Driver

Show previous products

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-M-DX

  HVGC-480-M-DX LED Driver MEAN WELL HVGC-480-M-DX is a 480 W constant-power LED driver with 2100 mA rated current and a 92–228.5 V constant-current operating region. This IP67 Class I metal-case version provides customer-defined smart timer dimming. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-M-DX; HVGC-480 Suffix and configuration Customer-defined smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 2100 mA Rated output power 480 W Constant-current voltage region 92–228.5 V Full-power current range 2100–2625 mA Maximum open-circuit voltage 240 V Catalog current-adjustment range 1050–2625 mA typical. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1050 mA / 228.5 V; 2100 mA / 228.5 V; 2625 mA / 182.8 V; 2625 mA / 92 V; 2100 mA / 114.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 241–257 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example: elapsed operation 0–1.5 h: 70%; 1.5–11 h: 100%; 11–14 h: 70%. Use elapsed time rather than the inconsistent printed clock-time annotation. Programming interface DX identifies the customer-requested timer profile, without a separate external programming/control cable in the cable specification. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-L-DX

  HVGC-480-L-DX LED Driver MEAN WELL HVGC-480-L-DX is a 480 W constant-power LED driver with 1400 mA rated current and a 137–343 V constant-current operating region. This IP67 Class I metal-case version provides customer-defined smart timer dimming. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-L-DX; HVGC-480 Suffix and configuration Customer-defined smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 1400 mA Rated output power 480 W Constant-current voltage region 137–343 V Full-power current range 1400–1750 mA Maximum open-circuit voltage 350 V Catalog current-adjustment range 700–1750 mA typical. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 700 mA / 343 V; 1400 mA / 343 V; 1750 mA / 274.3 V; 1750 mA / 137 V; 1400 mA / 171.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 351–381 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example: elapsed operation 0–1.5 h: 70%; 1.5–11 h: 100%; 11–14 h: 70%. Use elapsed time rather than the inconsistent printed clock-time annotation. Programming interface DX identifies the customer-requested timer profile, without a separate external programming/control cable in the cable specification. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-H-D2

  HVGC-480-H-D2 LED Driver MEAN WELL HVGC-480-H-D2 is a 480 W constant-power LED driver with 2800 mA rated current and a 68–171.5 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-H-D2; HVGC-480 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 2800 mA Rated output power 480 W Constant-current voltage region 68–171.5 V Full-power current range 2800–3500 mA Maximum open-circuit voltage 180 V Catalog current-adjustment range 1400–3500 mA typical. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1400 mA / 171.5 V; 2800 mA / 171.5 V; 3500 mA / 137.1 V; 3500 mA / 68 V; 2800 mA / 86 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 181–193 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example: elapsed operation 0–1.5 h: 70%; 1.5–11 h: 100%; 11–14 h: 70%. Use elapsed time rather than the inconsistent printed clock-time annotation. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; PROG+ purple, PROG− pink. 330 ±20 mm in the dedicated drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-M-D2

  HVGC-480-M-D2 LED Driver MEAN WELL HVGC-480-M-D2 is a 480 W constant-power LED driver with 2100 mA rated current and a 92–228.5 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-M-D2; HVGC-480 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 2100 mA Rated output power 480 W Constant-current voltage region 92–228.5 V Full-power current range 2100–2625 mA Maximum open-circuit voltage 240 V Catalog current-adjustment range 1050–2625 mA typical. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1050 mA / 228.5 V; 2100 mA / 228.5 V; 2625 mA / 182.8 V; 2625 mA / 92 V; 2100 mA / 114.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 241–257 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example: elapsed operation 0–1.5 h: 70%; 1.5–11 h: 100%; 11–14 h: 70%. Use elapsed time rather than the inconsistent printed clock-time annotation. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; PROG+ purple, PROG− pink. 330 ±20 mm in the dedicated drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-L-D2

  HVGC-480-L-D2 LED Driver MEAN WELL HVGC-480-L-D2 is a 480 W constant-power LED driver with 1400 mA rated current and a 137–343 V constant-current operating region. This IP67 Class I metal-case version provides programmable smart timer dimming. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-L-D2; HVGC-480 Suffix and configuration Programmable smart timer dimming. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 1400 mA Rated output power 480 W Constant-current voltage region 137–343 V Full-power current range 1400–1750 mA Maximum open-circuit voltage 350 V Catalog current-adjustment range 700–1750 mA typical. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 700 mA / 343 V; 1400 mA / 343 V; 1750 mA / 274.3 V; 1750 mA / 137 V; 1400 mA / 171.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 351–381 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Smart timer operation Adaptive proportional dimming of the constant-current level over up to 14 consecutive hours. D01/D02/D03 are catalog examples, not guaranteed delivered presets. Agree the required profile with MEAN WELL. D01 example: elapsed operation 0–6 h: 100%; 6–7 h: 70%; 7–11 h: 50%; 11–14 h: 70%. D02 example: elapsed operation 0–1 h: 50%; 1–3 h: 80%; 3–8 h: 100%; 8–11 h: 60%; 11–14 h: 80%. Use elapsed time; the example’s printed ending clock time does not agree with its duration table. D03 example: elapsed operation 0–1.5 h: 70%; 1.5–11 h: 100%; 11–14 h: 70%. Use elapsed time rather than the inconsistent printed clock-time annotation. Programming interface PROG+ purple; PROG− pink. D2 identifies programmable smart-timer dimming, not DALI-2. Confirm compatible programming equipment and the required program with MEAN WELL. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; PROG+ purple, PROG− pink. 330 ±20 mm in the dedicated drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-H

  HVGC-480-H LED Driver MEAN WELL HVGC-480-H is a 480 W constant-power LED driver with 2800 mA rated current and a 68–171.5 V constant-current operating region. This IP67 Class I metal-case version provides fixed output current and voltage. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-H; HVGC-480 Suffix and configuration Fixed output current and voltage. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 2800 mA Rated output power 480 W Constant-current voltage region 68–171.5 V Full-power current range 2800–3500 mA Maximum open-circuit voltage 180 V Catalog current-adjustment range 1400–3500 mA typical. The blank-suffix option is fixed output; this family-table range does not grant a user adjustment or external dimming interface to this SKU. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1400 mA / 171.5 V; 2800 mA / 171.5 V; 3500 mA / 137.1 V; 3500 mA / 68 V; 2800 mA / 86 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 181–193 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Fixed-output configuration The option table and dedicated blank-type mechanical drawing specify fixed Io/Vo and no separate control cable. The generic dimming-page label is not a grant of 3-in-1 dimming to this blank-suffix model. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-M

  HVGC-480-M LED Driver MEAN WELL HVGC-480-M is a 480 W constant-power LED driver with 2100 mA rated current and a 92–228.5 V constant-current operating region. This IP67 Class I metal-case version provides fixed output current and voltage. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-M; HVGC-480 Suffix and configuration Fixed output current and voltage. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 2100 mA Rated output power 480 W Constant-current voltage region 92–228.5 V Full-power current range 2100–2625 mA Maximum open-circuit voltage 240 V Catalog current-adjustment range 1050–2625 mA typical. The blank-suffix option is fixed output; this family-table range does not grant a user adjustment or external dimming interface to this SKU. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1050 mA / 228.5 V; 2100 mA / 228.5 V; 2625 mA / 182.8 V; 2625 mA / 92 V; 2100 mA / 114.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 241–257 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Fixed-output configuration The option table and dedicated blank-type mechanical drawing specify fixed Io/Vo and no separate control cable. The generic dimming-page label is not a grant of 3-in-1 dimming to this blank-suffix model. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-L

  HVGC-480-L LED Driver MEAN WELL HVGC-480-L is a 480 W constant-power LED driver with 1400 mA rated current and a 137–343 V constant-current operating region. This IP67 Class I metal-case version provides fixed output current and voltage. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-L; HVGC-480 Suffix and configuration Fixed output current and voltage. By-request catalog execution; confirm the exact supplied build. Construction and IP rating IP67; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 1400 mA Rated output power 480 W Constant-current voltage region 137–343 V Full-power current range 1400–1750 mA Maximum open-circuit voltage 350 V Catalog current-adjustment range 700–1750 mA typical. The blank-suffix option is fixed output; this family-table range does not grant a user adjustment or external dimming interface to this SKU. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 700 mA / 343 V; 1400 mA / 343 V; 1750 mA / 274.3 V; 1750 mA / 137 V; 1400 mA / 171.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 351–381 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control Fixed-output configuration The option table and dedicated blank-type mechanical drawing specify fixed Io/Vo and no separate control cable. The generic dimming-page label is not a grant of 3-in-1 dimming to this blank-suffix model. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-H-AB

  HVGC-480-H-AB LED Driver MEAN WELL HVGC-480-H-AB is a 480 W constant-power LED driver with 2800 mA rated current and a 68–171.5 V constant-current operating region. This IP65 Class I metal-case version provides 3-in-1 dimming and output-current potentiometer. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-H-AB; HVGC-480 Suffix and configuration 3-in-1 dimming and output-current potentiometer. Standard catalog execution. Construction and IP rating IP65; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 2800 mA Rated output power 480 W Constant-current voltage region 68–171.5 V Full-power current range 2800–3500 mA Maximum open-circuit voltage 180 V Catalog current-adjustment range 1400–3500 mA typical. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1400 mA / 171.5 V; 2800 mA / 171.5 V; 3500 mA / 137.1 V; 3500 mA / 68 V; 2800 mA / 86 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 181–193 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control 3-in-1 dimming Apply 0–10 VDC, a 10 V PWM signal at 100 Hz–3 kHz, or resistance across DIM+ and DIM− to adjust the constant-current level. Local current adjustment Use the built-in Io ADJ potentiometer within this model’s current-adjustment range. Dimming source and synchronization 100 µA typical source current. For N synchronized drivers, the plotted resistance scale extends from 10 kΩ/N to 100 kΩ/N; 100 kΩ/N corresponds to full current. Minimum level and switch-off Minimum dimming level is approximately 6%; output is undefined for 0% < Iout <6%. Approximately 0 VDC, 0 Ω or a 10 V PWM signal at 0% duty can reduce output to 0%. Dimming wiring and load DIM+ purple; DIM− pink. Do not connect DIM− to Vo−. Connect the dimmed output directly to LEDs; this arrangement is not suitable for use with additional drivers. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. This AB version requires consideration for built-in use to comply with Type HL application requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; DIM+ purple, DIM− pink. 330 ±20 mm in the dedicated drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP65 and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Controller installation Verify controller compatibility and capacity for this exact DIM interface. The depicted control conductors are 17 AWG. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-M-AB

  HVGC-480-M-AB LED Driver MEAN WELL HVGC-480-M-AB is a 480 W constant-power LED driver with 2100 mA rated current and a 92–228.5 V constant-current operating region. This IP65 Class I metal-case version provides 3-in-1 dimming and output-current potentiometer. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-M-AB; HVGC-480 Suffix and configuration 3-in-1 dimming and output-current potentiometer. Standard catalog execution. Construction and IP rating IP65; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 2100 mA Rated output power 480 W Constant-current voltage region 92–228.5 V Full-power current range 2100–2625 mA Maximum open-circuit voltage 240 V Catalog current-adjustment range 1050–2625 mA typical. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 1050 mA / 228.5 V; 2100 mA / 228.5 V; 2625 mA / 182.8 V; 2625 mA / 92 V; 2100 mA / 114.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 241–257 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control 3-in-1 dimming Apply 0–10 VDC, a 10 V PWM signal at 100 Hz–3 kHz, or resistance across DIM+ and DIM− to adjust the constant-current level. Local current adjustment Use the built-in Io ADJ potentiometer within this model’s current-adjustment range. Dimming source and synchronization 100 µA typical source current. For N synchronized drivers, the plotted resistance scale extends from 10 kΩ/N to 100 kΩ/N; 100 kΩ/N corresponds to full current. Minimum level and switch-off Minimum dimming level is approximately 6%; output is undefined for 0% < Iout <6%. Approximately 0 VDC, 0 Ω or a 10 V PWM signal at 0% duty can reduce output to 0%. Dimming wiring and load DIM+ purple; DIM− pink. Do not connect DIM− to Vo−. Connect the dimmed output directly to LEDs; this arrangement is not suitable for use with additional drivers. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. This AB version requires consideration for built-in use to comply with Type HL application requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; DIM+ purple, DIM− pink. 330 ±20 mm in the dedicated drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP65 and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Controller installation Verify controller compatibility and capacity for this exact DIM interface. The depicted control conductors are 17 AWG. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-480 series: Constant Power LED Driver - HVGC-480-L-AB

  HVGC-480-L-AB LED Driver MEAN WELL HVGC-480-L-AB is a 480 W constant-power LED driver with 1400 mA rated current and a 137–343 V constant-current operating region. This IP65 Class I metal-case version provides 3-in-1 dimming and output-current potentiometer. Select the LED operating point within the model-specific I–V envelope; current and voltage limits cannot be combined arbitrarily. Download MEAN WELL HVGC-480 Datasheet (PDF)Download MEAN WELL LED Installation Manual Catalog: HVGC-480, PDF pages 46–56, revision 2025-10-10. Model selection Full model and series HVGC-480-L-AB; HVGC-480 Suffix and configuration 3-in-1 dimming and output-current potentiometer. Standard catalog execution. Construction and IP rating IP65; metal housing; Class I protective-earth design; active PFC; fanless free-air convection cooling. Auxiliary-output identity This exact model has no auxiliary power output. Applications Harbor, LED high-bay, parking-space and fishing-lamp lighting. Subject to the final luminaire design. The catalog specifies North America and EU lighting-equipment applications; consult MEAN WELL for other uses. Output specifications Rated output current 1400 mA Rated output power 480 W Constant-current voltage region 137–343 V Full-power current range 1400–1750 mA Maximum open-circuit voltage 350 V Catalog current-adjustment range 700–1750 mA typical. Use only the adjustment/control method specified for this suffix. Recommended operating envelope Match the LED forward-voltage sum and selected current to the shaded I–V region in the catalog, within the rated power limit. Key plotted current / voltage points: 700 mA / 343 V; 1400 mA / 343 V; 1750 mA / 274.3 V; 1750 mA / 137 V; 1400 mA / 171.5 V. Current tolerance and ripple Current tolerance ±5%; current ripple 5.0% maximum at rated current. Efficiency (typical) 94.5% Temperature coefficient ±0.03%/°C over 0–60°C Input and performance Input voltage and frequency 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Input current (typical) 1.52 A at 347 VAC; 1.11 A at 480 VAC Power factor (typical) ≥0.98 / ≥0.98 / ≥0.97 / ≥0.96 / ≥0.95 at 230 / 277 / 347 / 400 / 480 VAC respectively, full load. Total harmonic distortion THD <20% at load ≥50% on 230 / 277 / 347 / 400 / 480 VAC. Setup time 500 ms at 230, 347 and 480 VAC. Measured at the first cold start; turning power on/off may increase setup time. Inrush current (typical) Cold start: 40 A, pulse width 1100 µs measured at 50% Ipeak at 480 VAC, per NEMA 410. Circuit-breaker reference 2 units on a 16 A type B breaker; 4 units on a 16 A type C breaker at 480 VAC. These are catalog reference limits; verify the actual breaker and installation conditions. Leakage current <0.75 mA at 480 VAC Input/load characteristic At 60 Hz, 100% load over 180–528 VAC. Apply thermal limits separately. Protection Short-circuit protection Constant-current limiting; automatically recovers after the fault is removed. Over-voltage protection 351–381 V; output voltage shuts down; cycle input power to recover. Over-temperature protection Output voltage shuts down; cycle input power to recover. Adjustment and control 3-in-1 dimming Apply 0–10 VDC, a 10 V PWM signal at 100 Hz–3 kHz, or resistance across DIM+ and DIM− to adjust the constant-current level. Local current adjustment Use the built-in Io ADJ potentiometer within this model’s current-adjustment range. Dimming source and synchronization 100 µA typical source current. For N synchronized drivers, the plotted resistance scale extends from 10 kΩ/N to 100 kΩ/N; 100 kΩ/N corresponds to full current. Minimum level and switch-off Minimum dimming level is approximately 6%; output is undefined for 0% < Iout <6%. Approximately 0 VDC, 0 Ω or a 10 V PWM signal at 0% duty can reduce output to 0%. Dimming wiring and load DIM+ purple; DIM− pink. Do not connect DIM− to Vo−. Connect the dimmed output directly to LEDs; this arrangement is not suitable for use with additional drivers. Thermal and environmental conditions Case operating temperature Tcase −40 to +90°C; maximum case temperature +90°C. This is not the ambient-temperature limit. Cooling and ambient derating Horizontal mounting and free-air convection. At 180 VAC, 100% load through +50°C, then 60% at +55°C; at 230 VAC, 100% through +55°C, then 60% at +60°C; above 277 VAC, 100% through +60°C, then 60% at +65°C. The curves stop at these endpoints. At rated current in the constant-power region, maximum workable ambient temperature is +55°C typical at 230 VAC. Case-temperature load curve The horizontal-mounting case-temperature curve shows 100% load through +90°C and stops there. Observe both case and ambient limits. Altitude derating Above 2000 m (6500 ft), reduce allowable ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity and storage Working: 20–95% RH, non-condensing. Storage: −40 to +80°C and 10–95% RH, non-condensing. Vibration 10–500 Hz, 5G; 12 minutes per cycle; 72 minutes along each X, Y and Z axis. Typical lifetime >50,000 hours when Tcase, particularly the tc / TMP point, is about +80°C or less. Lifetime varies with temperature; use the dedicated curve, not an unconditional service-life guarantee. MTBF 932.9K h minimum, Telcordia SR-332 (Bellcore); 74K h minimum, MIL-HDBK-217F at 25°C Warranty Manufacturer catalog: 5-year warranty, subject to MEAN WELL’s warranty statement. Safety and EMC Safety standards UL8750 (Type HL); CSA C22.2 No. 250.13-14; ENEC BS EN/EN61347-1, BS EN/EN61347-2-13 independent; BS EN/EN62384; EAC TP TC 004. Type HL application For use in Class I, Division 2 hazardous-location lighting equipment under the applicable final-system requirements. This AB version requires consideration for built-in use to comply with Type HL application requirements. Type HL is not a standalone explosion-proof classification. Dielectric withstand Input/output: 3.75 kVAC; input/FG: 2 kVAC; output/FG: 1.5 kVAC. Insulation resistance Input/output, input/FG and output/FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMC emission BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥50%; BS EN/EN61000-3-3; FCC Part 15 Class B; EAC TP TC 020. EMC immunity BS EN/EN61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN61547, light-industry level; EAC TP TC 020. Surge: 4 kV line-to-earth / 2 kV line-to-line. Mechanical and wiring Dimensions and enclosure 262 × 125 × 43.8 mm (L × W × H); case no. 251; drawing tolerance ±1 mm. Mounting four Ø4.5 mm mounting features; main case body length excluding end flanges 235.2 mm. Use the exact drawing for fixing geometry. Case-temperature measuring point the tc point is 113.8 mm from the right inner end line and 58 mm from the lower edge. Input cable SOOW 17 AWG × 3 conductors / H07RN-F 3 × 1.0 mm²; brown AC/L, blue AC/N, green/yellow FG protective earth. the drawing gives 300 ±20 mm. Output cable SOOW 17 AWG × 2 conductors / H07RN-F 2 × 1.0 mm²; brown Vo+, blue Vo−. the output lead drawing gives 300 ±20 mm. Unit mass and packing Catalog packing reference: 2.72 kg per unit; 4 pcs / 11.45 kg / 0.55 CUFT per carton. This is the stated per-unit reference, not a carton-weight average. Control cable SJOW 17 AWG × 2 conductors / H05RN-F 2 × 1.0 mm²; DIM+ purple, DIM− pink. 330 ±20 mm in the dedicated drawing. Installation Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Weather protection This model is IP65 and must be installed indoors or in a location sheltered from rain outdoors, as required by the installation manual. The IP rating does not permit immersion. Controller installation Verify controller compatibility and capacity for this exact DIM interface. The depicted control conductors are 17 AWG. If standalone dimming conductors smaller than 18 AWG are used, use only SELV controllers or networks and contact MEAN WELL before using FELV control. Input switching For the catalog ErP condition, use this driver behind a switch; do not connect it permanently to the mains. Specification conditions Measurement conditions Unless otherwise stated: 347 VAC input, rated current and +25°C ambient. Performance plots Power-factor curves are shown at Tcase +80°C. THD and efficiency plots illustrate the L output range at Tcase +80°C; use this exact model’s table values and stated load/input limits. Accessories and supplied configuration The applicable catalog pages do not identify a separately orderable dedicated connector or programmer code. Confirm any required programming equipment or custom build with MEAN WELL; accessories are not implied by the model description.

  Read more less

  $426.32

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-3500D2

  HVGC-320-3500D2 LED driver MEAN WELL HVGC-320-3500D2 is a 320 W, 3500 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming with a programmable function, available by request. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 3500 mA constant current; 320 W rated power. Constant current region 45.7–91.4 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 94 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating D2 type; IP67. Built-in smart timer dimming with a programmable function, available by request. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface The purple and pink control pair is PROG+ / PROG− for D2. It is not the B-type analog DIM input. D2 denotes the programmable option and does not mean the D02 example profile. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 96–105 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. Input and output leads Input: STW 18 AWG × 3C; brown AC/L, blue AC/N and green/yellow FG. Output: STW 18 AWG × 2C; red +V and black −V. Input and output lead lengths: 300 ±20 mm. Control leads UL2517 22 AWG × 2C; purple PROG+ and pink PROG− for programming; not an analog DIM input. Lead length: 300 ±20 mm. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-2800D2

  HVGC-320-2800D2 LED driver MEAN WELL HVGC-320-2800D2 is a 320 W, 2800 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming with a programmable function, available by request. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 2800 mA constant current; 320 W rated power. Constant current region 57–114.3 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 118 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating D2 type; IP67. Built-in smart timer dimming with a programmable function, available by request. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface The purple and pink control pair is PROG+ / PROG− for D2. It is not the B-type analog DIM input. D2 denotes the programmable option and does not mean the D02 example profile. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 120–131 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. Input and output leads Input: STW 18 AWG × 3C; brown AC/L, blue AC/N and green/yellow FG. Output: STW 18 AWG × 2C; red +V and black −V. Input and output lead lengths: 300 ±20 mm. Control leads UL2517 22 AWG × 2C; purple PROG+ and pink PROG− for programming; not an analog DIM input. Lead length: 300 ±20 mm. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-2100D2

  HVGC-320-2100D2 LED driver MEAN WELL HVGC-320-2100D2 is a 320 W, 2100 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming with a programmable function, available by request. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 2100 mA constant current; 320 W rated power. Constant current region 76.2–152.4 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 156 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating D2 type; IP67. Built-in smart timer dimming with a programmable function, available by request. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface The purple and pink control pair is PROG+ / PROG− for D2. It is not the B-type analog DIM input. D2 denotes the programmable option and does not mean the D02 example profile. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 160–175 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. Input and output leads Input: STW 18 AWG × 3C; brown AC/L, blue AC/N and green/yellow FG. Output: STW 18 AWG × 2C; red +V and black −V. Input and output lead lengths: 300 ±20 mm. Control leads UL2517 22 AWG × 2C; purple PROG+ and pink PROG− for programming; not an analog DIM input. Lead length: 300 ±20 mm. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-1750D2

  HVGC-320-1750D2 LED driver MEAN WELL HVGC-320-1750D2 is a 320 W, 1750 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming with a programmable function, available by request. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 1750 mA constant current; 320 W rated power. Constant current region 91.4–182.8 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 187 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating D2 type; IP67. Built-in smart timer dimming with a programmable function, available by request. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface The purple and pink control pair is PROG+ / PROG− for D2. It is not the B-type analog DIM input. D2 denotes the programmable option and does not mean the D02 example profile. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 192–210 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. Input and output leads Input: STW 18 AWG × 3C; brown AC/L, blue AC/N and green/yellow FG. Output: STW 18 AWG × 2C; red +V and black −V. Input and output lead lengths: 300 ±20 mm. Control leads UL2517 22 AWG × 2C; purple PROG+ and pink PROG− for programming; not an analog DIM input. Lead length: 300 ±20 mm. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-1400D2

  HVGC-320-1400D2 LED driver MEAN WELL HVGC-320-1400D2 is a 320 W, 1400 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming with a programmable function, available by request. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 1400 mA constant current; 320 W rated power. Constant current region 114.3–228.6 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 234 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating D2 type; IP67. Built-in smart timer dimming with a programmable function, available by request. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface The purple and pink control pair is PROG+ / PROG− for D2. It is not the B-type analog DIM input. D2 denotes the programmable option and does not mean the D02 example profile. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 240–263 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. Input and output leads Input: STW 18 AWG × 3C; brown AC/L, blue AC/N and green/yellow FG. Output: STW 18 AWG × 2C; red +V and black −V. Input and output lead lengths: 300 ±20 mm. Control leads UL2517 22 AWG × 2C; purple PROG+ and pink PROG− for programming; not an analog DIM input. Lead length: 300 ±20 mm. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-1050D2

  HVGC-320-1050D2 LED driver MEAN WELL HVGC-320-1050D2 is a 320 W, 1050 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming with a programmable function, available by request. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 1050 mA constant current; 320 W rated power. Constant current region 152.4–304.8 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 311 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating D2 type; IP67. Built-in smart timer dimming with a programmable function, available by request. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface The purple and pink control pair is PROG+ / PROG− for D2. It is not the B-type analog DIM input. D2 denotes the programmable option and does not mean the D02 example profile. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 320–351 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. Input and output leads Input: STW 18 AWG × 3C; brown AC/L, blue AC/N and green/yellow FG. Output: STW 18 AWG × 2C; red +V and black −V. Input and output lead lengths: 300 ±20 mm. Control leads UL2517 22 AWG × 2C; purple PROG+ and pink PROG− for programming; not an analog DIM input. Lead length: 300 ±20 mm. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-700D2

  HVGC-320-700D2 LED driver MEAN WELL HVGC-320-700D2 is a 300 W, 700 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming with a programmable function, available by request. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 700 mA constant current; 300 W rated power. Constant current region 214–428 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 442 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating D2 type; IP67. Built-in smart timer dimming with a programmable function, available by request. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface The purple and pink control pair is PROG+ / PROG− for D2. It is not the B-type analog DIM input. D2 denotes the programmable option and does not mean the D02 example profile. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 445–455 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. Input and output leads Input: STW 18 AWG × 3C; brown AC/L, blue AC/N and green/yellow FG. Output: STW 18 AWG × 2C; red +V and black −V. Input and output lead lengths: 300 ±20 mm. Control leads UL2517 22 AWG × 2C; purple PROG+ and pink PROG− for programming; not an analog DIM input. Lead length: 300 ±20 mm. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Programmable timer installation This D2 version provides smart-timer dimming and a programmable function. Its purple and pink control wires are PROG+ and PROG−, respectively. Confirm the required programming equipment, procedure and ordered profile with MEAN WELL; D2 does not mean DALI-2 or the analog DIM interface. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-3500DX

  HVGC-320-3500DX LED driver MEAN WELL HVGC-320-3500DX is a 320 W, 3500 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 3500 mA constant current; 320 W rated power. Constant current region 45.7–91.4 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 94 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating DX type; IP67. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface DX denotes the requested smart timer option. A separate DX wiring drawing and its factory program must be confirmed with MEAN WELL; do not assume a D2 programming lead or a B-type analog input. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 96–105 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. These details come from the depicted A/AB/B/D2 versions; obtain the exact DX drawing before mounting. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. The DX version is not drawn separately; confirm its supplied tc marking. Wiring confirmation The mechanical page depicts A, AB, B and D2, but not DX separately. Obtain the supplied DX wiring drawing to confirm cable type, gauge, length, colors and any control conductors. No D2 or analog DIM wiring is assigned to DX here. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-2800DX

  HVGC-320-2800DX LED driver MEAN WELL HVGC-320-2800DX is a 320 W, 2800 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 2800 mA constant current; 320 W rated power. Constant current region 57–114.3 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 118 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating DX type; IP67. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface DX denotes the requested smart timer option. A separate DX wiring drawing and its factory program must be confirmed with MEAN WELL; do not assume a D2 programming lead or a B-type analog input. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 120–131 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. These details come from the depicted A/AB/B/D2 versions; obtain the exact DX drawing before mounting. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. The DX version is not drawn separately; confirm its supplied tc marking. Wiring confirmation The mechanical page depicts A, AB, B and D2, but not DX separately. Obtain the supplied DX wiring drawing to confirm cable type, gauge, length, colors and any control conductors. No D2 or analog DIM wiring is assigned to DX here. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-2100DX

  HVGC-320-2100DX LED driver MEAN WELL HVGC-320-2100DX is a 320 W, 2100 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 2100 mA constant current; 320 W rated power. Constant current region 76.2–152.4 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 156 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating DX type; IP67. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface DX denotes the requested smart timer option. A separate DX wiring drawing and its factory program must be confirmed with MEAN WELL; do not assume a D2 programming lead or a B-type analog input. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 160–175 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. These details come from the depicted A/AB/B/D2 versions; obtain the exact DX drawing before mounting. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. The DX version is not drawn separately; confirm its supplied tc marking. Wiring confirmation The mechanical page depicts A, AB, B and D2, but not DX separately. Obtain the supplied DX wiring drawing to confirm cable type, gauge, length, colors and any control conductors. No D2 or analog DIM wiring is assigned to DX here. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-1750DX

  HVGC-320-1750DX LED driver MEAN WELL HVGC-320-1750DX is a 320 W, 1750 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 1750 mA constant current; 320 W rated power. Constant current region 91.4–182.8 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 187 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating DX type; IP67. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface DX denotes the requested smart timer option. A separate DX wiring drawing and its factory program must be confirmed with MEAN WELL; do not assume a D2 programming lead or a B-type analog input. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 192–210 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. These details come from the depicted A/AB/B/D2 versions; obtain the exact DX drawing before mounting. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. The DX version is not drawn separately; confirm its supplied tc marking. Wiring confirmation The mechanical page depicts A, AB, B and D2, but not DX separately. Obtain the supplied DX wiring drawing to confirm cable type, gauge, length, colors and any control conductors. No D2 or analog DIM wiring is assigned to DX here. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-1400DX

  HVGC-320-1400DX LED driver MEAN WELL HVGC-320-1400DX is a 320 W, 1400 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 1400 mA constant current; 320 W rated power. Constant current region 114.3–228.6 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 234 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating DX type; IP67. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface DX denotes the requested smart timer option. A separate DX wiring drawing and its factory program must be confirmed with MEAN WELL; do not assume a D2 programming lead or a B-type analog input. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 240–263 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. These details come from the depicted A/AB/B/D2 versions; obtain the exact DX drawing before mounting. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. The DX version is not drawn separately; confirm its supplied tc marking. Wiring confirmation The mechanical page depicts A, AB, B and D2, but not DX separately. Obtain the supplied DX wiring drawing to confirm cable type, gauge, length, colors and any control conductors. No D2 or analog DIM wiring is assigned to DX here. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.

  Read more less

  $265.16

  View options

•

  View options

  MEAN WELL HVGC-320 series: Constant Current LED Driver - HVGC-320-1050DX

  HVGC-320-1050DX LED driver MEAN WELL HVGC-320-1050DX is a 320 W, 1050 mA constant current LED driver with high-voltage output, a metal Class I enclosure, active PFC and fanless free-air convection cooling. Its IP67 design supports suitable indoor or outdoor installations subject to the installation requirements. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Download MEAN WELL HVGC-320 Datasheet (PDF)Download MEAN WELL LED Installation Manual HVGC catalog, PDF pages 37–45. Use the exact output and function suffix when selecting the driver. Output and function Rated output 1050 mA constant current; 320 W rated power. Constant current region 152.4–304.8 V. Select the LED load within this range; the highest output voltage depends on the system configuration. Contact MEAN WELL for compatibility questions. Open-circuit voltage 311 V maximum. Current accuracy Current tolerance: ±5%. Current ripple: 5% maximum at rated current. Function and ingress rating DX type; IP67. Built-in smart timer dimming by user request; confirm the supplied timing profile with MEAN WELL. Current adjustment No internal user-adjustable current potentiometer is specified for this suffix. LED connection This series operates in constant current mode to drive LEDs directly. The exact current option and function suffix determine the operating limits. Smart timer profile Adaptive proportional current profiles may run for up to 14 consecutive hours. The actual profile must be agreed with MEAN WELL; examples do not establish the factory program for this SKU. Residential example D01 Elapsed time after power-on: 100% for 0–6 h, 70% for 6–7 h, 50% for 7–11 h, then 70% for 11–14 h. Street example D02 Elapsed time: 50% for 0–1 h, 80% for 1–3 h, 100% for 3–8 h, 60% for 8–11 h, then 80% for 11–14 h. Tunnel example D03 Elapsed time: 70% for 0–1.5 h, 100% for 1.5–11 h, then 70% for 11–14 h. These intervals follow the software tables; some clock-time examples in the catalog are inconsistent. Confirm the commissioned schedule. Programming interface DX denotes the requested smart timer option. A separate DX wiring drawing and its factory program must be confirmed with MEAN WELL; do not assume a D2 programming lead or a B-type analog input. Catalog option By request; confirm specification and availability with MEAN WELL. Input and performance Input range 180–528 VAC or 254–747 VDC; 47–63 Hz AC. Apply the voltage-specific thermal limits. AC current and power factor Typical AC current: 1.1 A at 347 VAC; 0.8 A at 480 VAC. Full-load typical PF: ≥0.98 / ≥0.97 / ≥0.95 / ≥0.93 at 230 / 277 / 347 / 480 VAC. Efficiency and harmonic distortion Typical efficiency: 93.5%. THD <20% at loads ≥50% at 230, 277 and 347 VAC; 60% at 480 VAC. Set-up time 500 ms at 230, 347 and 480 VAC. Measured at first cold start; repeated power cycling may increase set-up time. Mains loading Typical cold-start inrush: 50 A; 920 µs pulse width measured at 50% Ipeak at 480 VAC, per NEMA 410. Maximum units on a 16 A type B / type C circuit breaker at 480 VAC: 2 / 4. Leakage and measurement conditions Leakage current <0.75 mA at 480 VAC. Unless otherwise stated, specifications use 347 VAC, rated output current and 25°C ambient. Separate rise-time, hold-up-time and idle-power values are not stated. Protection Short circuit Constant current limiting; automatic recovery when the fault is removed. Overvoltage 320–351 V; shuts down output voltage; re-power to recover. Overtemperature Shuts down and latches off output voltage; re-power to recover. Temperature and reliability Case and ambient limits Operating case temperature: −40 to +90°C, with maximum Tcase +90°C. Horizontal installation: at 180 VAC, 100% load from −40 to +50°C, then 60% at +60°C; at 230 VAC, 100% through +55°C, then 60% at +65°C; above 277 VAC, 100% through +60°C, then 60% at +70°C. The case-temperature load curve shows 100% from −40 to +90°C. Meet both case and ambient limits; free-air convection cooling. Input and altitude derating The 60 Hz static graph shows 100% load from 180 to 528 VAC; the notes still require assessment of low-input derating. Follow the separate voltage-dependent ambient-temperature curves. Above 2,000 m altitude, reduce allowable ambient temperature by 3.5°C per 1,000 m for this fanless design. Environment Working humidity: 20–95% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient: ±0.03%/°C over 0–60°C. Vibration: 10–500 Hz, 5 G, 12 min/cycle, 72 min along each X, Y and Z axis. Operating curves PFC switching frequency 45 kHz; PWM switching frequency 50 kHz. PF curves use Tc 80°C; THD and efficiency examples use the 700 mA model at Tc 80°C, distinguishing 230, 277, 347 and 480 VAC. These examples do not guarantee identical performance for every current option. Life and reliability Typical lifetime >50,000 hours at Tc / TMP about 80°C or lower. The lifetime graph indicates approximately 100,000 h at Tc 20–70°C, 70,000 h at 75°C, 50,000 h at 80°C, 35,000 h at 85°C and 25,000 h at 90°C. MTBF: 1721.7K hours minimum, Telcordia SR-332 (Bellcore); 146.9K hours minimum, MIL-HDBK-217F at 25°C. Warranty Five-year manufacturer warranty, subject to its warranty statement and the specified operating conditions. Mechanical details and wiring Dimensions 262 × 90 × 43.8 mm (L × W × H); case 228; drawing tolerance ±1 mm. Mounting reference The mechanical drawings show four Ø4.5 mm mounting slots, vertical spacing 40 mm, and main case body length 235.2 mm excluding end mounting flanges. Use the full drawing for fixing positions. These details come from the depicted A/AB/B/D2 versions; obtain the exact DX drawing before mounting. Temperature measurement point The marked tc point is 117.6 mm from the main case right edge and 45 mm from the bottom edge; use this point for case-temperature verification. The DX version is not drawn separately; confirm its supplied tc marking. Wiring confirmation The mechanical page depicts A, AB, B and D2, but not DX separately. Obtain the supplied DX wiring drawing to confirm cable type, gauge, length, colors and any control conductors. No D2 or analog DIM wiring is assigned to DX here. Unit weight and packing 2 kg (2000 g) per unit. Carton reference: 8 pcs / 17 kg / 0.92 CUFT. Per-unit mass is separately stated in the specification. Safety and EMC Electrical classification Metal Class I design requiring protective earth. This electrical protection class is distinct from any hazardous-location designation. Safety standards UL 8750 Type HL; CSA C22.2 No. 250.13-12; IEC/BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384 (independent); EAC TP TC 004. CCC-certified versions under GB/T 19510.1, GB/T 19510.213, GB/T 17743 and GB 17625.1 are optional; confirm the exact version with MEAN WELL. Type HL application The family specifies Type HL for Class I, Division 2 hazardous classified locations. Isolation Withstand voltage: input–output 3.75 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Isolation resistance: 100 MΩ at 500 VDC, 25°C and 70% RH across these paths. EMC Emissions: BS EN/EN 55015; BS EN/EN 61000-3-2 at ≥50% load; BS EN/EN 61000-3-3; FCC Part 15 Subpart B; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2, -3, -4, -5, -6, -8 and -11; BS EN/EN 61547, light-industry level; EAC TP TC 020. Surge immunity: 4 kV line-to-earth and 2 kV line-to-line. System integration The driver is a component; final equipment manufacturers must re-qualify EMC for the complete installation. For the stated ErP luminaire requirement, use behind a mains switch without a permanent unswitched mains connection. The product is intended for North American and EU lighting equipment; contact MEAN WELL for other uses. Applications Applications LED street, high-bay, parking-space and fishing-lamp lighting. Installation manual requirements Installation safety Disconnect the mains supply and prevent accidental reconnection before installation or maintenance. Have faults examined by a qualified technician; do not open the power-supply case yourself. Ventilation and mounting Keep ventilation clear and do not stack objects on the unit. Keep 10–15 cm clearance when the adjacent device is a heat source. Follow this model’s mounting, ambient-temperature and output-derating requirements. System wiring and protection Use approved primary and secondary wiring rated for at least the applicable unit current. Provide suitable system-level insulation and an enclosure around single-insulated wiring; verify EMC again in the completed system. Environmental and load limits Do not immerse the unit or install it near fire or above its specified ambient limit. Keep output current and power within the model’s rated operating envelope. If a fitted external flexible cable is damaged, replacement is limited to the manufacturer, its service agent or a similarly qualified person. Connection seals and support If waterproof connectors are fitted, secure their connections to prevent water entry. Verify the mounting structure and luminaire strength; use safety cables for bay-light applications. Protective-earth installation Connect the fitted FG/PE conductor to PE according to this Class I model’s wiring diagram. Timer ordering This DX version uses customer-defined smart-timer dimming by request. Confirm the ordered profile and operating procedure with MEAN WELL; DX does not mean DALI or DALI-2. Confirm the exact LED load, operating temperature, control interface and installation requirements against the linked datasheet and manual before commissioning.
