  MEAN WELL LCM-60DA series: DALI-2 constant-current LED driver - LCM-60DA2

  LCM-60DA2 DALI-2 LED driver MEAN WELL LCM-60DA2 is a 60.3 W multi-stage constant-current LED driver with DALI-2 control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This version has no auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output No auxiliary DC output on this exact model; the separately specified AUX version is required for that function. Standby power <0.5 W, measured at 180–230 VAC; standard non-AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. The 0.5-second setup requires a DALI controller supporting the DALI power-on function; otherwise startup may exceed 0.5 second under IEC 62386-101/102. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI-2 interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring For DA2 PUSH mode, connect a button between DA+ and AC/L, and connect DA− to AC/N. Use the separate DALI bus wiring for DALI-2 mode; do not connect a DALI bus to the mains-wired PUSH arrangement. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. The catalog excludes DA2 from UL 8750 and BIS approvals. Emergency-lighting scope DA2 emergency-lighting (EL) requirements under BS EN/EN 61347-2-13 Appendix J apply at 200–240 VAC. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI-2 interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 DA+, 4 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI-2 constant-current LED driver - LCM-60DA2

  LCM-60DA2 DALI-2 LED driver MEAN WELL LCM-60DA2 is a 60.3 W multi-stage constant-current LED driver with DALI-2 control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This version has no auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output No auxiliary DC output on this exact model; the separately specified AUX version is required for that function. Standby power <0.5 W, measured at 180–230 VAC; standard non-AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. The 0.5-second setup requires a DALI controller supporting the DALI power-on function; otherwise startup may exceed 0.5 second under IEC 62386-101/102. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI-2 interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring For DA2 PUSH mode, connect a button between DA+ and AC/L, and connect DA− to AC/N. Use the separate DALI bus wiring for DALI-2 mode; do not connect a DALI bus to the mains-wired PUSH arrangement. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. The catalog excludes DA2 from UL 8750 and BIS approvals. Emergency-lighting scope DA2 emergency-lighting (EL) requirements under BS EN/EN 61347-2-13 Appendix J apply at 200–240 VAC. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI-2 interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 DA+, 4 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver with auxiliary output - LCM-60DA-AUX

  LCM-60DA-AUX DALI LED driver MEAN WELL LCM-60DA-AUX is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This AUX version provides a 12 V / 50 mA auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output AUX option: 12 V nominal (11.4–12.6 V), 50 mA, for an auxiliary load such as a fan. Standby power <1.2 W, measured at 180–230 VAC; AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver with auxiliary output - LCM-60DA-AUX

  LCM-60DA-AUX DALI LED driver MEAN WELL LCM-60DA-AUX is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This AUX version provides a 12 V / 50 mA auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output AUX option: 12 V nominal (11.4–12.6 V), 50 mA, for an auxiliary load such as a fan. Standby power <1.2 W, measured at 180–230 VAC; AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver with auxiliary output - LCM-60DA-AUX

  LCM-60DA-AUX DALI LED driver MEAN WELL LCM-60DA-AUX is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This AUX version provides a 12 V / 50 mA auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output AUX option: 12 V nominal (11.4–12.6 V), 50 mA, for an auxiliary load such as a fan. Standby power <1.2 W, measured at 180–230 VAC; AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver with auxiliary output - LCM-60DA-AUX

  LCM-60DA-AUX DALI LED driver MEAN WELL LCM-60DA-AUX is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This AUX version provides a 12 V / 50 mA auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output AUX option: 12 V nominal (11.4–12.6 V), 50 mA, for an auxiliary load such as a fan. Standby power <1.2 W, measured at 180–230 VAC; AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver with auxiliary output - LCM-60DA-AUX

  LCM-60DA-AUX DALI LED driver MEAN WELL LCM-60DA-AUX is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This AUX version provides a 12 V / 50 mA auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output AUX option: 12 V nominal (11.4–12.6 V), 50 mA, for an auxiliary load such as a fan. Standby power <1.2 W, measured at 180–230 VAC; AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver with auxiliary output - LCM-60DA-AUX

  LCM-60DA-AUX DALI LED driver MEAN WELL LCM-60DA-AUX is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This AUX version provides a 12 V / 50 mA auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output AUX option: 12 V nominal (11.4–12.6 V), 50 mA, for an auxiliary load such as a fan. Standby power <1.2 W, measured at 180–230 VAC; AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver - LCM-60DA

  LCM-60DA DALI LED driver MEAN WELL LCM-60DA is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This version has no auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output No auxiliary DC output on this exact model; the separately specified AUX version is required for that function. Standby power <0.5 W, measured at 180–230 VAC; standard non-AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver - LCM-60DA

  LCM-60DA DALI LED driver MEAN WELL LCM-60DA is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This version has no auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output No auxiliary DC output on this exact model; the separately specified AUX version is required for that function. Standby power <0.5 W, measured at 180–230 VAC; standard non-AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver - LCM-60DA

  LCM-60DA DALI LED driver MEAN WELL LCM-60DA is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This version has no auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output No auxiliary DC output on this exact model; the separately specified AUX version is required for that function. Standby power <0.5 W, measured at 180–230 VAC; standard non-AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver - LCM-60DA

  LCM-60DA DALI LED driver MEAN WELL LCM-60DA is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This version has no auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output No auxiliary DC output on this exact model; the separately specified AUX version is required for that function. Standby power <0.5 W, measured at 180–230 VAC; standard non-AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver - LCM-60DA

  LCM-60DA DALI LED driver MEAN WELL LCM-60DA is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This version has no auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output No auxiliary DC output on this exact model; the separately specified AUX version is required for that function. Standby power <0.5 W, measured at 180–230 VAC; standard non-AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60DA series: DALI constant-current LED driver - LCM-60DA

  LCM-60DA DALI LED driver MEAN WELL LCM-60DA is a 60.3 W multi-stage constant-current LED driver with DALI control, pushbutton dimming and six primary DIP current settings. Match the LED string to the selected current and voltage window; 700 mA is the factory default. This version has no auxiliary DC output. Download MEAN WELL LCM-60DA Datasheet (PDF)Download MEAN WELL LCM-40/60 DA/DA2 Installation Manual LCM catalog, PDF pages 66–73. Select the exact interface and AUX suffix when ordering. Output and DIP settings Output mode and rating Constant-current output; rated power 60.3 W. The current and voltage limits below apply together; a family wattage does not authorize extra voltage or current. Current accuracy and ripple Current tolerance ±5%; maximum current ripple 5% at rated current. Ripple is measured at 60–100% of maximum output voltage and under rated power. Current selection DIP positions are listed as 1/2/3/4/5/6; ON and OFF refer to the marked switch positions. Select a current compatible with the LED module rating before energizing. 500 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP OFF/OFF/OFF/OFF/OFF/OFF. 600 mA LED operating window 2–90 V; maximum open-circuit voltage 95 V; DIP ON/OFF/OFF/OFF/OFF/OFF. 700 mA — default LED operating window 2–86 V; maximum open-circuit voltage 95 V; DIP ON/ON/OFF/OFF/OFF/OFF. 900 mA LED operating window 2–67 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/OFF/OFF/ON. 1050 mA LED operating window 2–57 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/OFF/ON. 1400 mA LED operating window 2–42 V; maximum open-circuit voltage 73 V; DIP ON/ON/ON/ON/ON/ON. Other output currents Contact MEAN WELL for other current settings; undocumented DIP combinations are not specified here. Auxiliary output No auxiliary DC output on this exact model; the separately specified AUX version is required for that function. Standby power <0.5 W, measured at 180–230 VAC; standard non-AUX configuration. Input and electrical performance Input voltage and frequency 180–295 VAC, 47–63 Hz; 254–392 VDC. Power factor and harmonics Built-in active PFC. Power factor ≥0.975 at 230 VAC and ≥0.95 at 277 VAC, full load. THD <20% at load ≥75%. Typical efficiency 92% at 900 mA / 67 V. Typical input current 0.32 A at 230 VAC; 0.27 A at 277 VAC (typical). Setup time 500 ms at 230 VAC. Measured at first cold start; repeated ON/OFF operation can increase setup time. Inrush and breaker loading Cold-start inrush 20 A at 230 VAC, width 270 µs at 50% Ipeak, per NEMA 410. Catalog maximum on a 16 A breaker at 230 VAC: B type 25 units / C type 32 units; assess actual circuit conditions. Leakage current <0.5 mA at 240 VAC. Input/load derating At 60 Hz: 80% load at 180 VAC, increasing to 100% at 200 VAC; the plotted full-load region continues to 295 VAC. Control and temperature compensation Digital dimming DALI interface on DA+/DA−, with selectable linear or logarithmic dimming curve. 16 groups and 64 addresses; the first output-current dimming step is fixed at 6%. PUSH wiring Connect the pushbutton between the dedicated PUSH terminal and AC/L. Never connect the PUSH button to AC/N; this can cause a short circuit. PUSH operation Short push 0.1–1 s: on/off. Long push 1.5–10 s: increase/decrease brightness; the direction reverses for the next long push. Reset push >11 s: return to 100% dimming level. Pushes shorter than 0.05 s cause no change. Factory dimming level is 100%. PUSH limits Up to 10 drivers per pushbutton; maximum button-to-last-driver cable length 20 m. Synchronization Up to 10 drivers (1 master + 9 slaves), with a 10–100% synchronization range. Set all units to 100% dimming before connecting the sync cable. Use a flat 22–24 AWG (0.2–0.3 mm²) cable shorter than 5 m; minimum dimming depends on the dimmer. External NTC temperature compensation An external NTC across +NTC/−NTC senses the luminaire or its environment. Without an NTC, current follows the selected DIP setting. Reference THINKING TTC03 series: 220 kΩ keeps 100% current below 60°C, 330 kΩ below 70°C, or 470 kΩ below 80°C; above the corresponding threshold current is reduced according to the catalog curve. MEAN WELL does not supply the NTC; verify other brands against the curve. NTC/control interlock Dimming and synchronization are invalid while NTC temperature compensation is in use. Protection and operating conditions Protection Short circuit: constant-current limiting with automatic recovery after the fault is removed. Overvoltage: 105–125 V, shutdown; reapply power to recover. Overtemperature: shutdown; reapply power to recover. Case temperature Working case-temperature range −30 to +90°C; maximum Tcase +90°C. Case temperature is not ambient temperature. Cooling/load derating Free-air convection, horizontal mounting. The ambient-temperature plot labels 1050 mA and 1400 mA as full load only through +40°C, where that curve ends. The curve labelled “Others” is 100% through +50°C, falling to 60% at +60°C. Follow the matching current-setting curve; do not extrapolate beyond its endpoint. The Tcase curve is 100% through +90°C. Altitude derating For fanless operation above 2,000 m, reduce allowable ambient temperature by 3.5°C for each additional 1,000 m. Humidity and storage Operating humidity: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C from 0 to +50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle, 60 minutes each along X, Y and Z axes. Safety and compliance Construction and safety Class II plastic enclosure; no FG connection; SELV. UL 8750; BIS IS 15885 (Part 2/Sec 13); CSA C22.2 No. 250.13-12; ENEC BS EN/EN 61347-1 and 61347-2-13; BS EN/EN 62384, independent controlgear; GB/T 19510.1 and GB/T 19510.213; EAC TP TC 004. DALI standards The family specification lists IEC 62386-101, -102, -207 and -251; use the exact DALI interface of this model. Insulation tests I/P–O/P: 3.75 kVAC; I/P–DA: 1.5 kVAC; O/P–DA: 1.5 kVAC. I/P–O/P insulation resistance >100 MΩ at 500 VDC, 25°C / 70% RH. EMC and system integration BS EN/EN 55015; BS EN/EN 61000-3-2 Class C (load ≥40%); BS EN/EN 61000-3-3; GB/T 17743, GB/T 17625.1; EAC TP TC 020. Immunity: BS EN/EN 61000-4-2/-3/-4/-5/-6/-8/-11 and BS EN/EN 61547, light-industry level; line-to-line surge 2 kV. These are component results; reconfirm EMC in the final equipment. ErP installation condition For the catalog’s latest ErP lighting-fixture compliance condition, use the driver behind a switch rather than permanently connected to mains. Installation and reference information Dimensions and mounting 123.5 × 81.5 × 23 mm (L × W × H), tolerance ±1 mm. Use the mounting drawing: top-view Ø4.2 mm fixing holes on 110 × 68 mm centers; the side-view tabs are marked 2 × Ø4 mm. Maintain the stated horizontal cooling orientation. Terminal assignment TB1: 1 AC/L, 2 AC/N, 3 PUSH, 4 DA+, 5 DA−. TB5: 1 +V, 2 −V. TB3: 1 +FAN/+AUX, 2 −FAN/−AUX, 3 +NTC, 4 −NTC. The fan/auxiliary output is active only on the AUX version. Sync connector parts CN100/CN101: JST B2B-XH or equivalent; pins 1/3 positive and 2/4 negative. Mating housing JST XHP or equivalent; terminal JST SXH-001T-P0.6 or equivalent. These are specified connector components, not an included MEAN WELL cable. Installation Disconnect power before wiring or changing DIP settings. Match LED polarity and the complete current/voltage/power envelope, and use the exact terminal diagram for this interface. Apply the installation instructions in the linked manual. Per-unit weight reference 240 g (0.24 kg), the catalog PACKING reference per unit; not a shipment weight. Reliability and warranty MTBF 2270.7K / 193.7K hours, respectively Telcordia SR-332 / MIL-HDBK-217F at 25°C. Manufacturer catalog warranty: 3 years, subject to its terms. Specification conditions Unless otherwise stated, parameters are measured at 230 VAC input, rated current and 25°C ambient. Performance plots use Tcase 80°C; the plotted examples do not replace the model limits. Manufacturer installation instructions Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. PUSH button specification Use only a normally open pushbutton without an indicator light. Follow the model-specific PUSH-to-line diagram; never wire the PUSH button to neutral. Push-terminal wiring For AC input, LED output and the applicable PUSH/DALI push terminals, the manual specifies 14–18 AWG stranded wire, 0.823–2.08 mm², or solid-wire diameter 1.024–1.628 mm. Strip 10 mm. Suggested push-down force 3–4 kp (6.61–8.81 lbf); no screw-tightening torque is specified for these push terminals. Small screw-terminal wiring For the fitted FAN/NTC screw terminals: 22–26 AWG stranded wire, 0.129–0.326 mm², or solid-wire diameter 0.404–0.643 mm; strip 7 mm. Use a 3 mm Phillips screwdriver; recommended tightening torque 2.88 kgf·cm (2.5 lbf·in). Apply these values only to the fitted small screw terminals, not the mains/output push terminals or the KNX bus connector. Cover and tools The manual specifies a 6 mm Phillips screwdriver and 4.6 kgf·cm (4 lbf·in) for the cover screws. Its terminal-tool table specifies a 3 mm Phillips screwdriver; the connection drawing shows pressing the release button with a slotted screwdriver to insert/remove the wire. Use a suitable tool for the actual release mechanism. DALI wiring length Maximum DALI cable length 300 m, based on the manual’s stated 1.5 mm² or 14 AWG cable reference. This is separate from the 20 m PUSH-cable limit. Circuit-breaker reference Maximum units on a 230 VAC breaker according to the installation manual: B10: 15; B16: 25; C10: 27; C16: 32. These are calculated references for ABB S201 miniature circuit breakers; select protection for the actual installation.

  Read more less

  $107.94

  View options

•

  View options

  MEAN WELL LCM-60 series: EnOcean wireless constant-current LED driver - LCM-60EO

  MEAN WELL LCM-60EO MEAN WELL LCM-60EO is a 60 W-class multiple-stage constant-current LED driver with EnOcean wireless. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60EO; multiple-stage constant-current AC/DC LED driver. EO identifies the integrated EnOcean module. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. EO terminal configuration The shared specification table lists 12 V / 50 mA auxiliary output, but the EO-specific drawing exposes no FAN/AUX terminals. Do not use the standard-model FAN terminal assignments on this EO model. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between SYNC+ and SYNC− at CN100 or CN101 on this EO version. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. Use an EO master; slaves may be standard models. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. EnOcean radio Integrated EnOcean module, standard 868 MHz; memory for up to 33 switches. Verify the frequency and applicable local requirements with an accredited certification agency before installation; the catalog regional reference table is not a universal approval. Pairing and unlinking Connect the LED load before energizing the driver. Press LRN for about 2 seconds: the LED load alternates between 10% and 90%, indicating pairing/unlinking mode. Quickly press the switch’s I button 4 times; steady 100% output for 4 seconds confirms linking. Repeat the same procedure for an already linked switch to unlink it. Multiple switches may be linked while this mode remains active. Exit and reset Pairing mode ends after 30 seconds without a wireless telegram, or by pressing LRN again. Hold LRN for 10 seconds to clear all linked switches and restore factory settings. Wireless configuration and accessories NAVIGAN software with an NWC300 USB interface provides additional dimming configuration; these are separate third-party commissioning tools. MEAN WELL batteryless wireless-switch order code: WPD-06SWT, selected separately. Supported EnOcean profiles Rocker switch F6-02-02; occupancy F5-07-01, A5-07-02 and A5-07-03; light level A5-06-02 and A5-06-03; central controller A5-38-08; demand response A5-37-01. Catalog third-party switch examples Legrand 0 784 42; Siemens 5WG4222-3AB10; Berker 24121009; Jung ENO A 595; Busch-jaeger EASYSENS/ENOCEAN; Gira 2422 03; Peha D 455/61.022 FU-BLS N; Eltako F4T65; VIMAR 20505+20506.B+21507.B. These are reference examples; confirm details with the original supplier. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +NTC, pin 2 −NTC. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. This EO version also uses these connectors for external analog dimming. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–65. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $211.93

  View options

•

  View options

  MEAN WELL LCM-60 series: EnOcean wireless constant-current LED driver - LCM-60EO

  MEAN WELL LCM-60EO MEAN WELL LCM-60EO is a 60 W-class multiple-stage constant-current LED driver with EnOcean wireless. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60EO; multiple-stage constant-current AC/DC LED driver. EO identifies the integrated EnOcean module. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. EO terminal configuration The shared specification table lists 12 V / 50 mA auxiliary output, but the EO-specific drawing exposes no FAN/AUX terminals. Do not use the standard-model FAN terminal assignments on this EO model. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between SYNC+ and SYNC− at CN100 or CN101 on this EO version. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. Use an EO master; slaves may be standard models. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. EnOcean radio Integrated EnOcean module, standard 868 MHz; memory for up to 33 switches. Verify the frequency and applicable local requirements with an accredited certification agency before installation; the catalog regional reference table is not a universal approval. Pairing and unlinking Connect the LED load before energizing the driver. Press LRN for about 2 seconds: the LED load alternates between 10% and 90%, indicating pairing/unlinking mode. Quickly press the switch’s I button 4 times; steady 100% output for 4 seconds confirms linking. Repeat the same procedure for an already linked switch to unlink it. Multiple switches may be linked while this mode remains active. Exit and reset Pairing mode ends after 30 seconds without a wireless telegram, or by pressing LRN again. Hold LRN for 10 seconds to clear all linked switches and restore factory settings. Wireless configuration and accessories NAVIGAN software with an NWC300 USB interface provides additional dimming configuration; these are separate third-party commissioning tools. MEAN WELL batteryless wireless-switch order code: WPD-06SWT, selected separately. Supported EnOcean profiles Rocker switch F6-02-02; occupancy F5-07-01, A5-07-02 and A5-07-03; light level A5-06-02 and A5-06-03; central controller A5-38-08; demand response A5-37-01. Catalog third-party switch examples Legrand 0 784 42; Siemens 5WG4222-3AB10; Berker 24121009; Jung ENO A 595; Busch-jaeger EASYSENS/ENOCEAN; Gira 2422 03; Peha D 455/61.022 FU-BLS N; Eltako F4T65; VIMAR 20505+20506.B+21507.B. These are reference examples; confirm details with the original supplier. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +NTC, pin 2 −NTC. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. This EO version also uses these connectors for external analog dimming. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–65. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $211.93

  View options

•

  View options

  MEAN WELL LCM-60 series: EnOcean wireless constant-current LED driver - LCM-60EO

  MEAN WELL LCM-60EO MEAN WELL LCM-60EO is a 60 W-class multiple-stage constant-current LED driver with EnOcean wireless. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60EO; multiple-stage constant-current AC/DC LED driver. EO identifies the integrated EnOcean module. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. EO terminal configuration The shared specification table lists 12 V / 50 mA auxiliary output, but the EO-specific drawing exposes no FAN/AUX terminals. Do not use the standard-model FAN terminal assignments on this EO model. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between SYNC+ and SYNC− at CN100 or CN101 on this EO version. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. Use an EO master; slaves may be standard models. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. EnOcean radio Integrated EnOcean module, standard 868 MHz; memory for up to 33 switches. Verify the frequency and applicable local requirements with an accredited certification agency before installation; the catalog regional reference table is not a universal approval. Pairing and unlinking Connect the LED load before energizing the driver. Press LRN for about 2 seconds: the LED load alternates between 10% and 90%, indicating pairing/unlinking mode. Quickly press the switch’s I button 4 times; steady 100% output for 4 seconds confirms linking. Repeat the same procedure for an already linked switch to unlink it. Multiple switches may be linked while this mode remains active. Exit and reset Pairing mode ends after 30 seconds without a wireless telegram, or by pressing LRN again. Hold LRN for 10 seconds to clear all linked switches and restore factory settings. Wireless configuration and accessories NAVIGAN software with an NWC300 USB interface provides additional dimming configuration; these are separate third-party commissioning tools. MEAN WELL batteryless wireless-switch order code: WPD-06SWT, selected separately. Supported EnOcean profiles Rocker switch F6-02-02; occupancy F5-07-01, A5-07-02 and A5-07-03; light level A5-06-02 and A5-06-03; central controller A5-38-08; demand response A5-37-01. Catalog third-party switch examples Legrand 0 784 42; Siemens 5WG4222-3AB10; Berker 24121009; Jung ENO A 595; Busch-jaeger EASYSENS/ENOCEAN; Gira 2422 03; Peha D 455/61.022 FU-BLS N; Eltako F4T65; VIMAR 20505+20506.B+21507.B. These are reference examples; confirm details with the original supplier. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +NTC, pin 2 −NTC. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. This EO version also uses these connectors for external analog dimming. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–65. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $211.93

  View options

•

  View options

  MEAN WELL LCM-60 series: EnOcean wireless constant-current LED driver - LCM-60EO

  MEAN WELL LCM-60EO MEAN WELL LCM-60EO is a 60 W-class multiple-stage constant-current LED driver with EnOcean wireless. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60EO; multiple-stage constant-current AC/DC LED driver. EO identifies the integrated EnOcean module. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. EO terminal configuration The shared specification table lists 12 V / 50 mA auxiliary output, but the EO-specific drawing exposes no FAN/AUX terminals. Do not use the standard-model FAN terminal assignments on this EO model. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between SYNC+ and SYNC− at CN100 or CN101 on this EO version. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. Use an EO master; slaves may be standard models. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. EnOcean radio Integrated EnOcean module, standard 868 MHz; memory for up to 33 switches. Verify the frequency and applicable local requirements with an accredited certification agency before installation; the catalog regional reference table is not a universal approval. Pairing and unlinking Connect the LED load before energizing the driver. Press LRN for about 2 seconds: the LED load alternates between 10% and 90%, indicating pairing/unlinking mode. Quickly press the switch’s I button 4 times; steady 100% output for 4 seconds confirms linking. Repeat the same procedure for an already linked switch to unlink it. Multiple switches may be linked while this mode remains active. Exit and reset Pairing mode ends after 30 seconds without a wireless telegram, or by pressing LRN again. Hold LRN for 10 seconds to clear all linked switches and restore factory settings. Wireless configuration and accessories NAVIGAN software with an NWC300 USB interface provides additional dimming configuration; these are separate third-party commissioning tools. MEAN WELL batteryless wireless-switch order code: WPD-06SWT, selected separately. Supported EnOcean profiles Rocker switch F6-02-02; occupancy F5-07-01, A5-07-02 and A5-07-03; light level A5-06-02 and A5-06-03; central controller A5-38-08; demand response A5-37-01. Catalog third-party switch examples Legrand 0 784 42; Siemens 5WG4222-3AB10; Berker 24121009; Jung ENO A 595; Busch-jaeger EASYSENS/ENOCEAN; Gira 2422 03; Peha D 455/61.022 FU-BLS N; Eltako F4T65; VIMAR 20505+20506.B+21507.B. These are reference examples; confirm details with the original supplier. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +NTC, pin 2 −NTC. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. This EO version also uses these connectors for external analog dimming. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–65. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $211.93

  View options

•

  View options

  MEAN WELL LCM-60 series: EnOcean wireless constant-current LED driver - LCM-60EO

  MEAN WELL LCM-60EO MEAN WELL LCM-60EO is a 60 W-class multiple-stage constant-current LED driver with EnOcean wireless. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60EO; multiple-stage constant-current AC/DC LED driver. EO identifies the integrated EnOcean module. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. EO terminal configuration The shared specification table lists 12 V / 50 mA auxiliary output, but the EO-specific drawing exposes no FAN/AUX terminals. Do not use the standard-model FAN terminal assignments on this EO model. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between SYNC+ and SYNC− at CN100 or CN101 on this EO version. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. Use an EO master; slaves may be standard models. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. EnOcean radio Integrated EnOcean module, standard 868 MHz; memory for up to 33 switches. Verify the frequency and applicable local requirements with an accredited certification agency before installation; the catalog regional reference table is not a universal approval. Pairing and unlinking Connect the LED load before energizing the driver. Press LRN for about 2 seconds: the LED load alternates between 10% and 90%, indicating pairing/unlinking mode. Quickly press the switch’s I button 4 times; steady 100% output for 4 seconds confirms linking. Repeat the same procedure for an already linked switch to unlink it. Multiple switches may be linked while this mode remains active. Exit and reset Pairing mode ends after 30 seconds without a wireless telegram, or by pressing LRN again. Hold LRN for 10 seconds to clear all linked switches and restore factory settings. Wireless configuration and accessories NAVIGAN software with an NWC300 USB interface provides additional dimming configuration; these are separate third-party commissioning tools. MEAN WELL batteryless wireless-switch order code: WPD-06SWT, selected separately. Supported EnOcean profiles Rocker switch F6-02-02; occupancy F5-07-01, A5-07-02 and A5-07-03; light level A5-06-02 and A5-06-03; central controller A5-38-08; demand response A5-37-01. Catalog third-party switch examples Legrand 0 784 42; Siemens 5WG4222-3AB10; Berker 24121009; Jung ENO A 595; Busch-jaeger EASYSENS/ENOCEAN; Gira 2422 03; Peha D 455/61.022 FU-BLS N; Eltako F4T65; VIMAR 20505+20506.B+21507.B. These are reference examples; confirm details with the original supplier. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +NTC, pin 2 −NTC. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. This EO version also uses these connectors for external analog dimming. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–65. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $211.93

  View options

•

  View options

  MEAN WELL LCM-60 series: EnOcean wireless constant-current LED driver - LCM-60EO

  MEAN WELL LCM-60EO MEAN WELL LCM-60EO is a 60 W-class multiple-stage constant-current LED driver with EnOcean wireless. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60EO; multiple-stage constant-current AC/DC LED driver. EO identifies the integrated EnOcean module. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. EO terminal configuration The shared specification table lists 12 V / 50 mA auxiliary output, but the EO-specific drawing exposes no FAN/AUX terminals. Do not use the standard-model FAN terminal assignments on this EO model. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between SYNC+ and SYNC− at CN100 or CN101 on this EO version. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. Use an EO master; slaves may be standard models. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. EnOcean radio Integrated EnOcean module, standard 868 MHz; memory for up to 33 switches. Verify the frequency and applicable local requirements with an accredited certification agency before installation; the catalog regional reference table is not a universal approval. Pairing and unlinking Connect the LED load before energizing the driver. Press LRN for about 2 seconds: the LED load alternates between 10% and 90%, indicating pairing/unlinking mode. Quickly press the switch’s I button 4 times; steady 100% output for 4 seconds confirms linking. Repeat the same procedure for an already linked switch to unlink it. Multiple switches may be linked while this mode remains active. Exit and reset Pairing mode ends after 30 seconds without a wireless telegram, or by pressing LRN again. Hold LRN for 10 seconds to clear all linked switches and restore factory settings. Wireless configuration and accessories NAVIGAN software with an NWC300 USB interface provides additional dimming configuration; these are separate third-party commissioning tools. MEAN WELL batteryless wireless-switch order code: WPD-06SWT, selected separately. Supported EnOcean profiles Rocker switch F6-02-02; occupancy F5-07-01, A5-07-02 and A5-07-03; light level A5-06-02 and A5-06-03; central controller A5-38-08; demand response A5-37-01. Catalog third-party switch examples Legrand 0 784 42; Siemens 5WG4222-3AB10; Berker 24121009; Jung ENO A 595; Busch-jaeger EASYSENS/ENOCEAN; Gira 2422 03; Peha D 455/61.022 FU-BLS N; Eltako F4T65; VIMAR 20505+20506.B+21507.B. These are reference examples; confirm details with the original supplier. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +NTC, pin 2 −NTC. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. This EO version also uses these connectors for external analog dimming. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–65. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $211.93

  View options

•

  View options

  MEAN WELL LCM-60 series: 3-in-1 dimming constant-current LED driver - LCM-60

  MEAN WELL LCM-60 MEAN WELL LCM-60 is a 60 W-class multiple-stage constant-current LED driver with 3-in-1 dimming. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60; multiple-stage constant-current AC/DC LED driver. Standard model with 3-in-1 dim-to-off control. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. Auxiliary DC output Nominal 12 V, deviation 11.4–12.6 V, at 50 mA; +FAN/−FAN terminals can supply an external fan. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM−. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +FAN, pin 2 −FAN, pin 3 +NTC, pin 4 −NTC, pin 5 DIM+, pin 6 DIM−. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–61. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $78.86

  View options

•

  View options

  MEAN WELL LCM-60 series: 3-in-1 dimming constant-current LED driver - LCM-60

  MEAN WELL LCM-60 MEAN WELL LCM-60 is a 60 W-class multiple-stage constant-current LED driver with 3-in-1 dimming. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60; multiple-stage constant-current AC/DC LED driver. Standard model with 3-in-1 dim-to-off control. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. Auxiliary DC output Nominal 12 V, deviation 11.4–12.6 V, at 50 mA; +FAN/−FAN terminals can supply an external fan. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM−. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +FAN, pin 2 −FAN, pin 3 +NTC, pin 4 −NTC, pin 5 DIM+, pin 6 DIM−. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–61. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $78.86

  View options

•

  View options

  MEAN WELL LCM-60 series: 3-in-1 dimming constant-current LED driver - LCM-60

  MEAN WELL LCM-60 MEAN WELL LCM-60 is a 60 W-class multiple-stage constant-current LED driver with 3-in-1 dimming. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60; multiple-stage constant-current AC/DC LED driver. Standard model with 3-in-1 dim-to-off control. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. Auxiliary DC output Nominal 12 V, deviation 11.4–12.6 V, at 50 mA; +FAN/−FAN terminals can supply an external fan. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM−. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +FAN, pin 2 −FAN, pin 3 +NTC, pin 4 −NTC, pin 5 DIM+, pin 6 DIM−. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–61. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $78.86

  View options

•

  View options

  MEAN WELL LCM-60 series: 3-in-1 dimming constant-current LED driver - LCM-60

  MEAN WELL LCM-60 MEAN WELL LCM-60 is a 60 W-class multiple-stage constant-current LED driver with 3-in-1 dimming. 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Select the DIP current and matching LED voltage before use. Designed for indoor, office, architectural and panel lighting. Download MEAN WELL LCM-60 Datasheet (PDF)Download MEAN WELL LCM-40/60 Installation Manual Output and selection Parameter Specification Model and operating mode LCM-60; multiple-stage constant-current AC/DC LED driver. Standard model with 3-in-1 dim-to-off control. Rated output power 60.3 W catalog rating; each setting must also remain within its LED-voltage window. Output current and voltage DIP-selected output, factory default 700 mA. Match the LED forward voltage to the selected row below; a power rating does not override its voltage limit. Current ripple and tolerance Ripple: 5% maximum at rated current; measured at 60–100% of maximum output voltage under rated power delivery. Current tolerance: ±5%. Typical efficiency 92%, measured at 900 mA / 67 V output selected by DIP. General test basis: 230 VAC, rated current, 25°C ambient; PF/THD/efficiency plots use Tcase 80°C. Startup time 500 ms at 230 VAC, first cold start; repeated ON/OFF may increase startup time. Auxiliary DC output Nominal 12 V, deviation 11.4–12.6 V, at 50 mA; +FAN/−FAN terminals can supply an external fan. DIP current settings Parameter Specification 500 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: OFF / OFF / OFF / OFF / OFF / OFF. 600 mA 2–90 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / OFF / OFF / OFF / OFF / OFF. 700 mA (default) 2–86 VDC; maximum open-circuit voltage 102 V. DIP 1/2/3/4/5/6: ON / ON / OFF / OFF / OFF / OFF. 900 mA 2–67 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / OFF / OFF / ON. 1050 mA 2–57 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / OFF / ON. 1400 mA 2–42 VDC; maximum open-circuit voltage 76 V. DIP 1/2/3/4/5/6: ON / ON / ON / ON / ON / ON. Control and commissioning Parameter Specification Dimming inputs Use 0–10 VDC, 10 V PWM at 100 Hz–3 kHz, or resistance between DIM+ and DIM−. Dimming source current: 100 μA typical. Connect directly to LEDs, not to additional drivers. Never connect DIM− to −V. Dimming range Minimum dimming level about 6%; output is undefined between 0% and 6%. Output can reach 0% with approximately 0 kΩ, 0 VDC, or 0% PWM duty. Resistance full scale is 100 kΩ/N, where N is the number of drivers in synchronized dimming. Do not activate temperature compensation during dimming. Synchronization Up to 10 drivers: 1 master + 9 slaves. Dimming operating range 10–100%; minimum also depends on the dimmer setting. Flat synchronization cable <5 m, 22–24 AWG (0.2–0.3 mm²). Set every unit to 100% dimming before connecting. Synchronization is a control connection, not parallel connection of LED power outputs. External NTC compensation Connect a temperature-sensing NTC resistor across +NTC / −NTC at the LED or surrounding sensing point. With no NTC, normal operation follows the DIP-selected current. Reference resistances: 220 kΩ holds 100% below 60°C and reduces current above 60°C; 330 kΩ uses 70°C; 470 kΩ uses 80°C. Follow the respective continuous derating curves. NTC compatibility and control limits Reference measurements use THINKING TTC03 series; MEAN WELL does not supply the NTC resistor. Check the temperature curve before substituting another make. Dimming and synchronization are invalid while temperature compensation is in use. Input and protection Parameter Specification Input supply 180–295 VAC; 254–417 VDC; 47–63 Hz AC. Active PFC. Power factor and THD Typical PF ≥0.975 at 230 VAC; ≥0.96 at 277 VAC, full load. THD <20% at load ≥75%. Typical AC current 0.32 A / 230 VAC; 0.27 A / 277 VAC. Inrush and breaker reference Cold-start inrush: 20 A typical at 230 VAC; width 270 μs at 50% Ipeak, per NEMA 410. Catalog 16 A circuit-breaker loading at 230 VAC: 25 type B / 32 type C units. Confirm the actual installation and breaker. Leakage and standby Leakage <0.5 mA at 240 VAC. Standby <1 W measured at 180–230 VAC. Short circuit Constant-current limiting; automatically recovers after the fault is removed. Overtemperature Output shuts down; reapply power to recover. Overvoltage protection 105–125 V; output shuts down; reapply power to recover. Operating limits Parameter Specification Temperature and cooling Free-air convection. Tcase −30 to +90°C; maximum case temperature +90°C. Horizontal mounting ambient curve: 1050 / 1400 mA: ambient limit 40°C at full load; the graph ends there for these settings. Other listed settings: full load through 50°C, then derate to 60% at 60°C. Case and ambient temperatures are different limits. Input and altitude derating At 60 Hz: 80% load at 180 VAC, rising to 100% at 200 VAC, remaining 100% through 295 VAC. Apply thermal limits concurrently. Above 2000 m, reduce permissible ambient temperature by 3.5°C per additional 1000 m for this fanless driver. Humidity, storage and coefficient Operating: 20–90% RH, non-condensing. Storage: −40 to +80°C, 10–95% RH. Temperature coefficient ±0.03%/°C over 0–40°C. Vibration and MTBF Vibration 10–500 Hz, 2 G, 10 minutes/cycle, 60 minutes on each X/Y/Z axis. MTBF 2628.7 / 260.6 thousand hours minimum, Telcordia SR-332 / MIL-HDBK-217F at 25°C, respectively. Safety and installation conditions Parameter Specification Construction Plastic housing, Class II, no FG; SELV output. Safety approval scope UL8750; CSA C22.2 No.250.13-12; ENEC BS EN/EN61347-1 and -2-13; BS EN/EN62384 independent; GB/T19510.1 and GB/T19510.213; BIS IS15885; EAC TP TC 004, as listed in the catalog. Insulation Input–output withstand 3.75 kVAC. Input–output insulation resistance >100 MΩ at 500 VDC, 25°C and 70% RH. EMC BS EN/EN55015; BS EN/EN61000-3-2 Class C at load ≥40%; BS EN/EN61000-3-3; GB/T17743; GB17625.1; EAC TP TC 020. Immunity: BS EN/EN61000-4-2, -3, -4, -5, -6, -8, -11 and BS EN/EN61547, light-industry level, line-to-line surge 2 kV. Requalify EMC on the complete final installation. ErP installation condition The 2026-02-09 catalog states this driver must be installed behind a switch, without permanent connection to the mains, to fulfill the latest lighting-fixture ErP requirements. Manufacturer warranty 3 years, subject to the manufacturer’s applicable terms. Dimensions, connections and accessories Parameter Specification Dimensions and mounting 123.5 × 81.5 × 23 mm; case LCM-60A; two Ø4.2 mm top mounting positions, 110 × 68 mm center spacing. L × W × H; drawing tolerance ±1 mm. Follow the full drawing; the two Ø4 mm side mounting details are separate. Catalog unit packing reference 240 g per unit, converted from the explicit single-unit PACKING value; not a measured net or parcel weight. Case temperature measuring point Bottom view: tc 40 mm from the right edge and 15 mm from the adjacent horizontal edge shown in the drawing. Measure this designated point in the final installation. Terminal assignments TB1: pin 1 AC/L, pin 2 AC/N. TB5: pin 1 +V, pin 2 −V. TB3: pin 1 +FAN, pin 2 −FAN, pin 3 +NTC, pin 4 −NTC, pin 5 DIM+, pin 6 DIM−. Synchronization connector CN101/CN100: pins 1/3 +, pins 2/4 −; JST B2B-XH or equivalent, mating housing JST XHP or equivalent, terminal JST SXH-001T-P0.6 or equivalent. Installation and clearance Install indoors by a qualified electrician. Keep at least 50 mm of ventilation clearance around the driver. Follow the dedicated installation manual and the model-specific load and temperature derating limits. LED load connection Do not connect a DC/DC converter or constant-current driver between this driver and the LED load. The selected output voltage and total output power must remain within the rated limits. Ambient installation limit The dedicated installation manual limits ambient temperature to 60°C. This is separate from the case-temperature rating; also obey the current model-specific load derating curve. Wire preparation and tools For the model’s actual small screw terminals: stranded 0.129–0.326 mm² (22–26 AWG), or solid diameter 0.404–0.643 mm; strip 7 mm; use a 3 mm Phillips screwdriver; recommended torque 2.88 kgf·cm. For the AC and LED-output push terminals: stranded 0.823–2.08 mm² (14–18 AWG), or solid diameter 1.024–1.628 mm; strip 10 mm; suggested push-down force 3–4 kp. Apply only to the populated terminals in the exact model drawing. Terminal cover Blue cover: 6 mm Phillips screwdriver; recommended torque 4.6 kgf·cm. The cover torque is not a push-terminal torque. Breaker-document difference The current catalog lists 25 type-B16 / 32 type-C16 units at 230 VAC. The LCM-40/60 installation manual’s ABB S201 example instead lists 25 B16 / 44 C16 for LCM-60 (15 B10 / 27 C10). Use the current catalog limit and verify the selected breaker and installation. Catalog reference: LCM-60, 2026-02-09; combined PDF pages 54–61. Apply the exact model wiring, current, voltage and thermal limits together.

  Read more less

  $78.86

  View options

Show more products
