MEAN WELL PSPA-1000-48 is a single-output enclosed AC/DC power supply rated at 48 V, 21 A and 1008 W. It combines active PFC, forced-air cooling, remote ON/OFF, remote sensing and active current sharing for industrial equipment. Apply the model-specific temperature, input-voltage and parallel-operation limits below; the series designation is not an unconditional output-power rating. Product Datasheet Download MEAN WELL PSPA-1000 Datasheet (PDF) The PSPA-1000 section is on PDF pages 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Rated Output Complete model PSPA-1000-48 Series / product type PSPA-1000 / single-output enclosed AC/DC power supply Rated DC output 48 V / 21 A / 1008 W Output current range 0 to 21 A Local voltage adjustment 46 to 56 V using the front VR Ripple and noise, maximum 250 mVp-p Voltage tolerance ±1.0% Line regulation ±0.5% Load regulation ±0.5% Efficiency, typical 94% at 230 VAC, rated load and 25°C In the model code, PSPA identifies the series, 1000 is its nominal wattage class and 48 identifies the rated output voltage. This exact model is rated 1008 W. Ripple and noise are measured with 20 MHz bandwidth using a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Unless a different condition is stated, the specification values are measured at 230 VAC, rated load and 25°C ambient. Apply the voltage, current, power and derating limits together. Input and Timing AC input 90 to 264 VAC, universal full range; 300 VAC for 5 seconds only DC input 127 to 370 VDC Frequency 47 to 63 Hz Active PFC / power factor, typical 0.95 at 230 VAC; 0.99 at 115 VAC, at full load AC current, typical 8.5 A at 115 VAC; 5 A at 230 VAC Inrush current, typical 20 A at 115 VAC; 40 A at 230 VAC Leakage current <0.5 mA at 240 VAC Setup / rise time 1000 ms / 50 ms at both 115 VAC and 230 VAC Hold-up time, typical 16 ms at full load The 60 Hz input-derating curve shows 80% load at 90 VAC, rising to 100% at 200 VAC; 100% continues through 264 VAC. Follow the drawn curve between these points and also observe temperature derating. The 300 VAC / 5-second condition does not extend the continuous input range. The block diagram includes active inrush-current limiting and lists PFC switching frequency 65 kHz and PWM switching frequency 90 kHz. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload threshold 105 to 135% of rated output power Overload response Constant current limiting; automatic recovery after the fault is removed Overvoltage threshold 58 to 65 V Overvoltage response Output shuts down; re-power to recover Overtemperature response Output shuts down; re-power to recover The overload range is a protection threshold, not a continuous overload or peak-power operating rating. Cooling and Operating Conditions Cooling Forced air by a built-in DC fan Working ambient temperature -20 to +70°C series specification; apply the model-specific curve below Working humidity 20 to 90% RH, non-condensing Storage temperature / humidity -40 to +85°C / 10 to 95% RH, non-condensing Temperature coefficient ±0.03%/°C over 0 to 50°C Vibration 10 to 500 Hz, 2G; 10 minutes/cycle, 60 minutes each on X, Y and Z axes For this 48 V model, the horizontal-installation curve shows 100% load from -20°C through +60°C, then decreases to 60% load at +70°C. The +70°C operating endpoint is a reduced-load condition, not a full-power rating. Maintain the mechanical drawing’s airflow path from the terminal face toward the opposite fan end. Keep the ventilation path clear; no fan start/stop temperature threshold is specified for this model in this datasheet. For operation above 2000 m, the fan-cooled altitude note requires an additional 5°C ambient-temperature derating per 1000 m. That note does not establish a separate maximum operating-altitude rating. Remote Sense and Remote ON/OFF Sense compensation Up to 0.5 V drop in the load wiring Minimum load with remote sense 5% of rated load, equivalent to 1.05 A at rated voltage CN15 pin 1 / pin 2 RS- / RS+ Remote-control terminals TB1 pin 1 R.C. and pin 2 R.C.G Remote switch state Short R.C. to R.C.G: ON; open: OFF Connect RS+ to the positive load point and RS- to the negative load point. Twist the two sense wires together to reduce noise pickup; use the power terminals, not the sense pins, for load current. The remote ON/OFF function can control a unit individually or in coordination with other units. Use the contact connection shown between R.C. and R.C.G; do not infer an external control-voltage range from another series. POK Output-Status Signal Signal terminal / reference TB1 pin 3 POK / pin 2 R.C.G, as shown in the application circuit TTL output when PSU is ON 2.4 to 5 V TTL output when PSU is OFF 0 to 0.4 V External-TTL sink mode Maximum sink current 10 mA; maximum external voltage 5.6 V POK is the output-status signal identified as DC OK on the series cover. The function manual describes two uses: sinking current from an external TTL circuit or sending a TTL voltage signal. Observe the applicable mode and its limits; it is not a general-purpose power output. Active Current Sharing and Parallel Wiring Parallel capacity Up to 4 units with built-in active current sharing Output-voltage matching Difference between parallel units must be less than 0.2 V Maximum total current Rated current per unit × number of units × 0.9 Four-unit example for this model 75.6 A total; 3628.8 W at nominal 48 V, before additional input/thermal derating Low-load balance limitation Sharing may not be fully balanced below 5% of aggregate rated current Use matching-output units. Parallel the DC outputs using short, large-diameter wiring, then connect the common output to the load. The wiring diagram joins P (TB1 pin 4) between the units and separately joins R.C.G (TB1 pin 2) between the units. Do not confuse the P sharing connection with remote ON/OFF. Each unit must also have the required R.C./R.C.G operating state. For remote sensing, follow the separate remote-sense connection and its 5% minimum-load condition. The series overview describes up to 4000 W (3+1), but the model-specific current rating and the mandatory 0.9 parallel-current equation govern usable output. Input and thermal derating can reduce it further; this is not an unconditional 4000 W system rating. Terminals and Connector Selection TB1 pin 1 R.C. — remote control TB1 pin 2 R.C.G — remote-control ground TB1 pin 3 POK — output-status signal TB1 pin 4 P — current-share connection TB1 pin 5 FG — frame/protective ground TB1 pin 6 / pin 7 AC/N / AC/L TB2 pins 1–4 DC output -V TB2 pins 5–8 DC output +V CN15 pins 1 / 2 RS- / RS+ CN15 connector reference JST B-XH or equivalent Mating-housing reference JST XHP or equivalent Contact reference JST SXH-001T or equivalent The JST references above reproduce the actual printed connector identifiers. B-XH and XHP are abbreviated family references; choose the correct two-position header/housing and wire-compatible contact using the connector supplier’s complete part-number data before ordering. No unprinted suffix is implied. These connector references identify compatible components; they do not establish that a mating housing, contacts, cable or spare parts are supplied with the power supply. No separate MEAN WELL accessory order code is listed on these five model pages. Dimensions and Installation Body dimensions, L × W × H 170 × 120 × 93 mm Mechanical case / general tolerance Case 910A / ±0.5 mm Drawing envelope / projection 185 mm longitudinal envelope; terminal projection marked 14 mm maximum Mounting-hole centres Side drawing: 150 × 50 mm; bottom drawing: 150 × 100 mm Mounting-hole callout 2-M3 L=4 mm max. at the indicated hole groups Recommended mounting screw / penetration M3 / maximum 4 mm into the chassis Recommended mounting torque 6 to 8 kgf·cm Terminal pitch TB1: 8 mm; TB2: 9.5 mm; first-terminal edge offset: 11.5 mm Use the dimensioned mechanical drawing for exact hole positions and connection clearances. The mounting depth is the permitted penetration into the chassis, not a total screw-length instruction; allow for the thickness of the mounting surface. The front drawing identifies the adjustment VR, LED and CN15. Keep live AC connections, frame ground, DC output and low-level signal terminals distinct. The mounting drawing does not state that installation screws or brackets are included. Safety, EMC and Integration Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, for input-output / input-FG / output-FG Approved standards listed UL62368-1; CAN/CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC 004 Conducted and radiated emissions: BS EN/EN55032 (CISPR32) and CNS15936, Class B. Harmonics: BS EN/EN61000-3-2, Class A. Voltage flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN61000-6-2 and BSMI CNS13438. EN61000-4 tests list ESD Level 3 at 8 kV air / Level 2 at 4 kV contact; radiated RF, EFT/burst and conducted RF Level 3; surge Level 4 at 2 kV line-line / 4 kV line-earth; magnetic field Level 4. Voltage dips/interruption are >95% for 0.5 periods, 30% for 25 periods and >95% for 250 periods. This power supply is a component for installation in final equipment. The EMC tests used a 360 × 360 × 1 mm metal plate. The completed equipment must be checked again for compliance; component standards do not automatically certify the finished installation. Weight, Reliability and Catalogue Reference Catalogue packing reference per unit 1.93 kg / 1930 g Catalogue carton data 8 pieces / 16.4 kg / 1.53 CUFT MTBF, minimum prediction 807.1K hours, Telcordia SR-332; 94.9K hours, MIL-HDBK-217F at 25°C Manufacturer warranty statement 5 years, as listed for PSPA-1000 Catalogue location / printed revision PSP / PSPA combined PDF, pages 4–8 / 2024-12-23 The per-unit mass is the catalogue PACKING reference. It is not a measured net or shipped-parcel weight, and the carton total must not be entered as the unit weight. MTBF is a reliability prediction, not a guaranteed operating life. Typical applications listed for this series include industrial automation, test and measurement, laser-related machines, burn-in facilities and RF equipment. Select and integrate the supply according to the actual electrical load and operating conditions.

Read more less

MEAN WELL PSPA-1000-24 is a single-output enclosed AC/DC power supply rated at 24 V, 42 A and 1008 W. It combines active PFC, forced-air cooling, remote ON/OFF, remote sensing and active current sharing for industrial equipment. Apply the model-specific temperature, input-voltage and parallel-operation limits below; the series designation is not an unconditional output-power rating. Product Datasheet Download MEAN WELL PSPA-1000 Datasheet (PDF) The PSPA-1000 section is on PDF pages 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Rated Output Complete model PSPA-1000-24 Series / product type PSPA-1000 / single-output enclosed AC/DC power supply Rated DC output 24 V / 42 A / 1008 W Output current range 0 to 42 A Local voltage adjustment 22 to 28 V using the front VR Ripple and noise, maximum 200 mVp-p Voltage tolerance ±1.0% Line regulation ±0.5% Load regulation ±0.5% Efficiency, typical 93.5% at 230 VAC, rated load and 25°C In the model code, PSPA identifies the series, 1000 is its nominal wattage class and 24 identifies the rated output voltage. This exact model is rated 1008 W. Ripple and noise are measured with 20 MHz bandwidth using a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Unless a different condition is stated, the specification values are measured at 230 VAC, rated load and 25°C ambient. Apply the voltage, current, power and derating limits together. Input and Timing AC input 90 to 264 VAC, universal full range; 300 VAC for 5 seconds only DC input 127 to 370 VDC Frequency 47 to 63 Hz Active PFC / power factor, typical 0.95 at 230 VAC; 0.99 at 115 VAC, at full load AC current, typical 8.5 A at 115 VAC; 5 A at 230 VAC Inrush current, typical 20 A at 115 VAC; 40 A at 230 VAC Leakage current <0.5 mA at 240 VAC Setup / rise time 1000 ms / 50 ms at both 115 VAC and 230 VAC Hold-up time, typical 16 ms at full load The 60 Hz input-derating curve shows 80% load at 90 VAC, rising to 100% at 200 VAC; 100% continues through 264 VAC. Follow the drawn curve between these points and also observe temperature derating. The 300 VAC / 5-second condition does not extend the continuous input range. The block diagram includes active inrush-current limiting and lists PFC switching frequency 65 kHz and PWM switching frequency 90 kHz. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload threshold 105 to 135% of rated output power Overload response Constant current limiting; automatic recovery after the fault is removed Overvoltage threshold 29 to 33 V Overvoltage response Output shuts down; re-power to recover Overtemperature response Output shuts down; re-power to recover The overload range is a protection threshold, not a continuous overload or peak-power operating rating. Cooling and Operating Conditions Cooling Forced air by a built-in DC fan Working ambient temperature -20 to +70°C series specification; apply the model-specific curve below Working humidity 20 to 90% RH, non-condensing Storage temperature / humidity -40 to +85°C / 10 to 95% RH, non-condensing Temperature coefficient ±0.03%/°C over 0 to 50°C Vibration 10 to 500 Hz, 2G; 10 minutes/cycle, 60 minutes each on X, Y and Z axes For this 24 V model, the horizontal-installation curve shows 100% load from -20°C through +60°C, then decreases to 60% load at +70°C. The +70°C operating endpoint is a reduced-load condition, not a full-power rating. Maintain the mechanical drawing’s airflow path from the terminal face toward the opposite fan end. Keep the ventilation path clear; no fan start/stop temperature threshold is specified for this model in this datasheet. For operation above 2000 m, the fan-cooled altitude note requires an additional 5°C ambient-temperature derating per 1000 m. That note does not establish a separate maximum operating-altitude rating. Remote Sense and Remote ON/OFF Sense compensation Up to 0.5 V drop in the load wiring Minimum load with remote sense 5% of rated load, equivalent to 2.1 A at rated voltage CN15 pin 1 / pin 2 RS- / RS+ Remote-control terminals TB1 pin 1 R.C. and pin 2 R.C.G Remote switch state Short R.C. to R.C.G: ON; open: OFF Connect RS+ to the positive load point and RS- to the negative load point. Twist the two sense wires together to reduce noise pickup; use the power terminals, not the sense pins, for load current. The remote ON/OFF function can control a unit individually or in coordination with other units. Use the contact connection shown between R.C. and R.C.G; do not infer an external control-voltage range from another series. POK Output-Status Signal Signal terminal / reference TB1 pin 3 POK / pin 2 R.C.G, as shown in the application circuit TTL output when PSU is ON 2.4 to 5 V TTL output when PSU is OFF 0 to 0.4 V External-TTL sink mode Maximum sink current 10 mA; maximum external voltage 5.6 V POK is the output-status signal identified as DC OK on the series cover. The function manual describes two uses: sinking current from an external TTL circuit or sending a TTL voltage signal. Observe the applicable mode and its limits; it is not a general-purpose power output. Active Current Sharing and Parallel Wiring Parallel capacity Up to 4 units with built-in active current sharing Output-voltage matching Difference between parallel units must be less than 0.2 V Maximum total current Rated current per unit × number of units × 0.9 Four-unit example for this model 151.2 A total; 3628.8 W at nominal 24 V, before additional input/thermal derating Low-load balance limitation Sharing may not be fully balanced below 5% of aggregate rated current Use matching-output units. Parallel the DC outputs using short, large-diameter wiring, then connect the common output to the load. The wiring diagram joins P (TB1 pin 4) between the units and separately joins R.C.G (TB1 pin 2) between the units. Do not confuse the P sharing connection with remote ON/OFF. Each unit must also have the required R.C./R.C.G operating state. For remote sensing, follow the separate remote-sense connection and its 5% minimum-load condition. The series overview describes up to 4000 W (3+1), but the model-specific current rating and the mandatory 0.9 parallel-current equation govern usable output. Input and thermal derating can reduce it further; this is not an unconditional 4000 W system rating. Terminals and Connector Selection TB1 pin 1 R.C. — remote control TB1 pin 2 R.C.G — remote-control ground TB1 pin 3 POK — output-status signal TB1 pin 4 P — current-share connection TB1 pin 5 FG — frame/protective ground TB1 pin 6 / pin 7 AC/N / AC/L TB2 pins 1–4 DC output -V TB2 pins 5–8 DC output +V CN15 pins 1 / 2 RS- / RS+ CN15 connector reference JST B-XH or equivalent Mating-housing reference JST XHP or equivalent Contact reference JST SXH-001T or equivalent The JST references above reproduce the actual printed connector identifiers. B-XH and XHP are abbreviated family references; choose the correct two-position header/housing and wire-compatible contact using the connector supplier’s complete part-number data before ordering. No unprinted suffix is implied. These connector references identify compatible components; they do not establish that a mating housing, contacts, cable or spare parts are supplied with the power supply. No separate MEAN WELL accessory order code is listed on these five model pages. Dimensions and Installation Body dimensions, L × W × H 170 × 120 × 93 mm Mechanical case / general tolerance Case 910A / ±0.5 mm Drawing envelope / projection 185 mm longitudinal envelope; terminal projection marked 14 mm maximum Mounting-hole centres Side drawing: 150 × 50 mm; bottom drawing: 150 × 100 mm Mounting-hole callout 2-M3 L=4 mm max. at the indicated hole groups Recommended mounting screw / penetration M3 / maximum 4 mm into the chassis Recommended mounting torque 6 to 8 kgf·cm Terminal pitch TB1: 8 mm; TB2: 9.5 mm; first-terminal edge offset: 11.5 mm Use the dimensioned mechanical drawing for exact hole positions and connection clearances. The mounting depth is the permitted penetration into the chassis, not a total screw-length instruction; allow for the thickness of the mounting surface. The front drawing identifies the adjustment VR, LED and CN15. Keep live AC connections, frame ground, DC output and low-level signal terminals distinct. The mounting drawing does not state that installation screws or brackets are included. Safety, EMC and Integration Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, for input-output / input-FG / output-FG Approved standards listed UL62368-1; CAN/CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC 004 Conducted and radiated emissions: BS EN/EN55032 (CISPR32) and CNS15936, Class B. Harmonics: BS EN/EN61000-3-2, Class A. Voltage flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN61000-6-2 and BSMI CNS13438. EN61000-4 tests list ESD Level 3 at 8 kV air / Level 2 at 4 kV contact; radiated RF, EFT/burst and conducted RF Level 3; surge Level 4 at 2 kV line-line / 4 kV line-earth; magnetic field Level 4. Voltage dips/interruption are >95% for 0.5 periods, 30% for 25 periods and >95% for 250 periods. This power supply is a component for installation in final equipment. The EMC tests used a 360 × 360 × 1 mm metal plate. The completed equipment must be checked again for compliance; component standards do not automatically certify the finished installation. Weight, Reliability and Catalogue Reference Catalogue packing reference per unit 1.93 kg / 1930 g Catalogue carton data 8 pieces / 16.4 kg / 1.53 CUFT MTBF, minimum prediction 807.1K hours, Telcordia SR-332; 94.9K hours, MIL-HDBK-217F at 25°C Manufacturer warranty statement 5 years, as listed for PSPA-1000 Catalogue location / printed revision PSP / PSPA combined PDF, pages 4–8 / 2024-12-23 The per-unit mass is the catalogue PACKING reference. It is not a measured net or shipped-parcel weight, and the carton total must not be entered as the unit weight. MTBF is a reliability prediction, not a guaranteed operating life. Typical applications listed for this series include industrial automation, test and measurement, laser-related machines, burn-in facilities and RF equipment. Select and integrate the supply according to the actual electrical load and operating conditions.

Read more less

MEAN WELL PSPA-1000-15 is a single-output enclosed AC/DC power supply rated at 15 V, 64 A and 960 W. It combines active PFC, forced-air cooling, remote ON/OFF, remote sensing and active current sharing for industrial equipment. Apply the model-specific temperature, input-voltage and parallel-operation limits below; the series designation is not an unconditional output-power rating. Product Datasheet Download MEAN WELL PSPA-1000 Datasheet (PDF) The PSPA-1000 section is on PDF pages 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Rated Output Complete model PSPA-1000-15 Series / product type PSPA-1000 / single-output enclosed AC/DC power supply Rated DC output 15 V / 64 A / 960 W Output current range 0 to 64 A Local voltage adjustment 14 to 17 V using the front VR Ripple and noise, maximum 150 mVp-p Voltage tolerance ±1.5% Line regulation ±0.5% Load regulation ±1.5% Efficiency, typical 93% at 230 VAC, rated load and 25°C In the model code, PSPA identifies the series, 1000 is its nominal wattage class and 15 identifies the rated output voltage. This exact model is rated 960 W. Ripple and noise are measured with 20 MHz bandwidth using a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Unless a different condition is stated, the specification values are measured at 230 VAC, rated load and 25°C ambient. Apply the voltage, current, power and derating limits together. Input and Timing AC input 90 to 264 VAC, universal full range; 300 VAC for 5 seconds only DC input 127 to 370 VDC Frequency 47 to 63 Hz Active PFC / power factor, typical 0.95 at 230 VAC; 0.99 at 115 VAC, at full load AC current, typical 8.5 A at 115 VAC; 5 A at 230 VAC Inrush current, typical 20 A at 115 VAC; 40 A at 230 VAC Leakage current <0.5 mA at 240 VAC Setup / rise time 1000 ms / 50 ms at both 115 VAC and 230 VAC Hold-up time, typical 16 ms at full load The 60 Hz input-derating curve shows 80% load at 90 VAC, rising to 100% at 200 VAC; 100% continues through 264 VAC. Follow the drawn curve between these points and also observe temperature derating. The 300 VAC / 5-second condition does not extend the continuous input range. The block diagram includes active inrush-current limiting and lists PFC switching frequency 65 kHz and PWM switching frequency 90 kHz. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload threshold 105 to 135% of rated output power Overload response Constant current limiting; automatic recovery after the fault is removed Overvoltage threshold 18.2 to 20.6 V Overvoltage response Output shuts down; re-power to recover Overtemperature response Output shuts down; re-power to recover The overload range is a protection threshold, not a continuous overload or peak-power operating rating. Cooling and Operating Conditions Cooling Forced air by a built-in DC fan Working ambient temperature -20 to +70°C series specification; apply the model-specific curve below Working humidity 20 to 90% RH, non-condensing Storage temperature / humidity -40 to +85°C / 10 to 95% RH, non-condensing Temperature coefficient ±0.03%/°C over 0 to 50°C Vibration 10 to 500 Hz, 2G; 10 minutes/cycle, 60 minutes each on X, Y and Z axes For this 15 V model, the horizontal-installation curve shows 100% load from -20°C through +50°C, then decreases to 60% load at +60°C. The series specification lists -20 to +70°C, but the dedicated 12/15 V curve stops at +60°C; do not extrapolate this model to +70°C. Maintain the mechanical drawing’s airflow path from the terminal face toward the opposite fan end. Keep the ventilation path clear; no fan start/stop temperature threshold is specified for this model in this datasheet. For operation above 2000 m, the fan-cooled altitude note requires an additional 5°C ambient-temperature derating per 1000 m. That note does not establish a separate maximum operating-altitude rating. Remote Sense and Remote ON/OFF Sense compensation Up to 0.5 V drop in the load wiring Minimum load with remote sense 5% of rated load, equivalent to 3.2 A at rated voltage CN15 pin 1 / pin 2 RS- / RS+ Remote-control terminals TB1 pin 1 R.C. and pin 2 R.C.G Remote switch state Short R.C. to R.C.G: ON; open: OFF Connect RS+ to the positive load point and RS- to the negative load point. Twist the two sense wires together to reduce noise pickup; use the power terminals, not the sense pins, for load current. The remote ON/OFF function can control a unit individually or in coordination with other units. Use the contact connection shown between R.C. and R.C.G; do not infer an external control-voltage range from another series. POK Output-Status Signal Signal terminal / reference TB1 pin 3 POK / pin 2 R.C.G, as shown in the application circuit TTL output when PSU is ON 2.4 to 5 V TTL output when PSU is OFF 0 to 0.4 V External-TTL sink mode Maximum sink current 10 mA; maximum external voltage 5.6 V POK is the output-status signal identified as DC OK on the series cover. The function manual describes two uses: sinking current from an external TTL circuit or sending a TTL voltage signal. Observe the applicable mode and its limits; it is not a general-purpose power output. Active Current Sharing and Parallel Wiring Parallel capacity Up to 4 units with built-in active current sharing Output-voltage matching Difference between parallel units must be less than 0.2 V Maximum total current Rated current per unit × number of units × 0.9 Four-unit example for this model 230.4 A total; 3456 W at nominal 15 V, before additional input/thermal derating Low-load balance limitation Sharing may not be fully balanced below 5% of aggregate rated current Use matching-output units. Parallel the DC outputs using short, large-diameter wiring, then connect the common output to the load. The wiring diagram joins P (TB1 pin 4) between the units and separately joins R.C.G (TB1 pin 2) between the units. Do not confuse the P sharing connection with remote ON/OFF. Each unit must also have the required R.C./R.C.G operating state. For remote sensing, follow the separate remote-sense connection and its 5% minimum-load condition. The series overview describes up to 4000 W (3+1), but the model-specific current rating and the mandatory 0.9 parallel-current equation govern usable output. Input and thermal derating can reduce it further; this is not an unconditional 4000 W system rating. Terminals and Connector Selection TB1 pin 1 R.C. — remote control TB1 pin 2 R.C.G — remote-control ground TB1 pin 3 POK — output-status signal TB1 pin 4 P — current-share connection TB1 pin 5 FG — frame/protective ground TB1 pin 6 / pin 7 AC/N / AC/L TB2 pins 1–4 DC output -V TB2 pins 5–8 DC output +V CN15 pins 1 / 2 RS- / RS+ CN15 connector reference JST B-XH or equivalent Mating-housing reference JST XHP or equivalent Contact reference JST SXH-001T or equivalent The JST references above reproduce the actual printed connector identifiers. B-XH and XHP are abbreviated family references; choose the correct two-position header/housing and wire-compatible contact using the connector supplier’s complete part-number data before ordering. No unprinted suffix is implied. These connector references identify compatible components; they do not establish that a mating housing, contacts, cable or spare parts are supplied with the power supply. No separate MEAN WELL accessory order code is listed on these five model pages. Dimensions and Installation Body dimensions, L × W × H 170 × 120 × 93 mm Mechanical case / general tolerance Case 910A / ±0.5 mm Drawing envelope / projection 185 mm longitudinal envelope; terminal projection marked 14 mm maximum Mounting-hole centres Side drawing: 150 × 50 mm; bottom drawing: 150 × 100 mm Mounting-hole callout 2-M3 L=4 mm max. at the indicated hole groups Recommended mounting screw / penetration M3 / maximum 4 mm into the chassis Recommended mounting torque 6 to 8 kgf·cm Terminal pitch TB1: 8 mm; TB2: 9.5 mm; first-terminal edge offset: 11.5 mm Use the dimensioned mechanical drawing for exact hole positions and connection clearances. The mounting depth is the permitted penetration into the chassis, not a total screw-length instruction; allow for the thickness of the mounting surface. The front drawing identifies the adjustment VR, LED and CN15. Keep live AC connections, frame ground, DC output and low-level signal terminals distinct. The mounting drawing does not state that installation screws or brackets are included. Safety, EMC and Integration Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, for input-output / input-FG / output-FG Approved standards listed UL62368-1; CAN/CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC 004 Conducted and radiated emissions: BS EN/EN55032 (CISPR32) and CNS15936, Class B. Harmonics: BS EN/EN61000-3-2, Class A. Voltage flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN61000-6-2 and BSMI CNS13438. EN61000-4 tests list ESD Level 3 at 8 kV air / Level 2 at 4 kV contact; radiated RF, EFT/burst and conducted RF Level 3; surge Level 4 at 2 kV line-line / 4 kV line-earth; magnetic field Level 4. Voltage dips/interruption are >95% for 0.5 periods, 30% for 25 periods and >95% for 250 periods. This power supply is a component for installation in final equipment. The EMC tests used a 360 × 360 × 1 mm metal plate. The completed equipment must be checked again for compliance; component standards do not automatically certify the finished installation. Weight, Reliability and Catalogue Reference Catalogue packing reference per unit 1.93 kg / 1930 g Catalogue carton data 8 pieces / 16.4 kg / 1.53 CUFT MTBF, minimum prediction 807.1K hours, Telcordia SR-332; 94.9K hours, MIL-HDBK-217F at 25°C Manufacturer warranty statement 5 years, as listed for PSPA-1000 Catalogue location / printed revision PSP / PSPA combined PDF, pages 4–8 / 2024-12-23 The per-unit mass is the catalogue PACKING reference. It is not a measured net or shipped-parcel weight, and the carton total must not be entered as the unit weight. MTBF is a reliability prediction, not a guaranteed operating life. Typical applications listed for this series include industrial automation, test and measurement, laser-related machines, burn-in facilities and RF equipment. Select and integrate the supply according to the actual electrical load and operating conditions.

Read more less

MEAN WELL PSPA-1000-12 is a single-output enclosed AC/DC power supply rated at 12 V, 80 A and 960 W. It combines active PFC, forced-air cooling, remote ON/OFF, remote sensing and active current sharing for industrial equipment. Apply the model-specific temperature, input-voltage and parallel-operation limits below; the series designation is not an unconditional output-power rating. Product Datasheet Download MEAN WELL PSPA-1000 Datasheet (PDF) The PSPA-1000 section is on PDF pages 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Rated Output Complete model PSPA-1000-12 Series / product type PSPA-1000 / single-output enclosed AC/DC power supply Rated DC output 12 V / 80 A / 960 W Output current range 0 to 80 A Local voltage adjustment 11 to 14 V using the front VR Ripple and noise, maximum 150 mVp-p Voltage tolerance ±2.0% Line regulation ±0.5% Load regulation ±2.0% Efficiency, typical 92% at 230 VAC, rated load and 25°C In the model code, PSPA identifies the series, 1000 is its nominal wattage class and 12 identifies the rated output voltage. This exact model is rated 960 W. Ripple and noise are measured with 20 MHz bandwidth using a 12-inch twisted pair terminated by 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes set-up tolerance, line regulation and load regulation. Unless a different condition is stated, the specification values are measured at 230 VAC, rated load and 25°C ambient. Apply the voltage, current, power and derating limits together. Input and Timing AC input 90 to 264 VAC, universal full range; 300 VAC for 5 seconds only DC input 127 to 370 VDC Frequency 47 to 63 Hz Active PFC / power factor, typical 0.95 at 230 VAC; 0.99 at 115 VAC, at full load AC current, typical 8.5 A at 115 VAC; 5 A at 230 VAC Inrush current, typical 20 A at 115 VAC; 40 A at 230 VAC Leakage current <0.5 mA at 240 VAC Setup / rise time 1000 ms / 50 ms at both 115 VAC and 230 VAC Hold-up time, typical 16 ms at full load The 60 Hz input-derating curve shows 80% load at 90 VAC, rising to 100% at 200 VAC; 100% continues through 264 VAC. Follow the drawn curve between these points and also observe temperature derating. The 300 VAC / 5-second condition does not extend the continuous input range. The block diagram includes active inrush-current limiting and lists PFC switching frequency 65 kHz and PWM switching frequency 90 kHz. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload threshold 105 to 135% of rated output power Overload response Constant current limiting; automatic recovery after the fault is removed Overvoltage threshold 14.5 to 16.5 V Overvoltage response Output shuts down; re-power to recover Overtemperature response Output shuts down; re-power to recover The overload range is a protection threshold, not a continuous overload or peak-power operating rating. Cooling and Operating Conditions Cooling Forced air by a built-in DC fan Working ambient temperature -20 to +70°C series specification; apply the model-specific curve below Working humidity 20 to 90% RH, non-condensing Storage temperature / humidity -40 to +85°C / 10 to 95% RH, non-condensing Temperature coefficient ±0.03%/°C over 0 to 50°C Vibration 10 to 500 Hz, 2G; 10 minutes/cycle, 60 minutes each on X, Y and Z axes For this 12 V model, the horizontal-installation curve shows 100% load from -20°C through +50°C, then decreases to 60% load at +60°C. The series specification lists -20 to +70°C, but the dedicated 12/15 V curve stops at +60°C; do not extrapolate this model to +70°C. Maintain the mechanical drawing’s airflow path from the terminal face toward the opposite fan end. Keep the ventilation path clear; no fan start/stop temperature threshold is specified for this model in this datasheet. For operation above 2000 m, the fan-cooled altitude note requires an additional 5°C ambient-temperature derating per 1000 m. That note does not establish a separate maximum operating-altitude rating. Remote Sense and Remote ON/OFF Sense compensation Up to 0.5 V drop in the load wiring Minimum load with remote sense 5% of rated load, equivalent to 4 A at rated voltage CN15 pin 1 / pin 2 RS- / RS+ Remote-control terminals TB1 pin 1 R.C. and pin 2 R.C.G Remote switch state Short R.C. to R.C.G: ON; open: OFF Connect RS+ to the positive load point and RS- to the negative load point. Twist the two sense wires together to reduce noise pickup; use the power terminals, not the sense pins, for load current. The remote ON/OFF function can control a unit individually or in coordination with other units. Use the contact connection shown between R.C. and R.C.G; do not infer an external control-voltage range from another series. POK Output-Status Signal Signal terminal / reference TB1 pin 3 POK / pin 2 R.C.G, as shown in the application circuit TTL output when PSU is ON 2.4 to 5 V TTL output when PSU is OFF 0 to 0.4 V External-TTL sink mode Maximum sink current 10 mA; maximum external voltage 5.6 V POK is the output-status signal identified as DC OK on the series cover. The function manual describes two uses: sinking current from an external TTL circuit or sending a TTL voltage signal. Observe the applicable mode and its limits; it is not a general-purpose power output. Active Current Sharing and Parallel Wiring Parallel capacity Up to 4 units with built-in active current sharing Output-voltage matching Difference between parallel units must be less than 0.2 V Maximum total current Rated current per unit × number of units × 0.9 Four-unit example for this model 288 A total; 3456 W at nominal 12 V, before additional input/thermal derating Low-load balance limitation Sharing may not be fully balanced below 5% of aggregate rated current Use matching-output units. Parallel the DC outputs using short, large-diameter wiring, then connect the common output to the load. The wiring diagram joins P (TB1 pin 4) between the units and separately joins R.C.G (TB1 pin 2) between the units. Do not confuse the P sharing connection with remote ON/OFF. Each unit must also have the required R.C./R.C.G operating state. For remote sensing, follow the separate remote-sense connection and its 5% minimum-load condition. The series overview describes up to 4000 W (3+1), but the model-specific current rating and the mandatory 0.9 parallel-current equation govern usable output. Input and thermal derating can reduce it further; this is not an unconditional 4000 W system rating. Terminals and Connector Selection TB1 pin 1 R.C. — remote control TB1 pin 2 R.C.G — remote-control ground TB1 pin 3 POK — output-status signal TB1 pin 4 P — current-share connection TB1 pin 5 FG — frame/protective ground TB1 pin 6 / pin 7 AC/N / AC/L TB2 pins 1–4 DC output -V TB2 pins 5–8 DC output +V CN15 pins 1 / 2 RS- / RS+ CN15 connector reference JST B-XH or equivalent Mating-housing reference JST XHP or equivalent Contact reference JST SXH-001T or equivalent The JST references above reproduce the actual printed connector identifiers. B-XH and XHP are abbreviated family references; choose the correct two-position header/housing and wire-compatible contact using the connector supplier’s complete part-number data before ordering. No unprinted suffix is implied. These connector references identify compatible components; they do not establish that a mating housing, contacts, cable or spare parts are supplied with the power supply. No separate MEAN WELL accessory order code is listed on these five model pages. Dimensions and Installation Body dimensions, L × W × H 170 × 120 × 93 mm Mechanical case / general tolerance Case 910A / ±0.5 mm Drawing envelope / projection 185 mm longitudinal envelope; terminal projection marked 14 mm maximum Mounting-hole centres Side drawing: 150 × 50 mm; bottom drawing: 150 × 100 mm Mounting-hole callout 2-M3 L=4 mm max. at the indicated hole groups Recommended mounting screw / penetration M3 / maximum 4 mm into the chassis Recommended mounting torque 6 to 8 kgf·cm Terminal pitch TB1: 8 mm; TB2: 9.5 mm; first-terminal edge offset: 11.5 mm Use the dimensioned mechanical drawing for exact hole positions and connection clearances. The mounting depth is the permitted penetration into the chassis, not a total screw-length instruction; allow for the thickness of the mounting surface. The front drawing identifies the adjustment VR, LED and CN15. Keep live AC connections, frame ground, DC output and low-level signal terminals distinct. The mounting drawing does not state that installation screws or brackets are included. Safety, EMC and Integration Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH, for input-output / input-FG / output-FG Approved standards listed UL62368-1; CAN/CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC 004 Conducted and radiated emissions: BS EN/EN55032 (CISPR32) and CNS15936, Class B. Harmonics: BS EN/EN61000-3-2, Class A. Voltage flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN61000-6-2 and BSMI CNS13438. EN61000-4 tests list ESD Level 3 at 8 kV air / Level 2 at 4 kV contact; radiated RF, EFT/burst and conducted RF Level 3; surge Level 4 at 2 kV line-line / 4 kV line-earth; magnetic field Level 4. Voltage dips/interruption are >95% for 0.5 periods, 30% for 25 periods and >95% for 250 periods. This power supply is a component for installation in final equipment. The EMC tests used a 360 × 360 × 1 mm metal plate. The completed equipment must be checked again for compliance; component standards do not automatically certify the finished installation. Weight, Reliability and Catalogue Reference Catalogue packing reference per unit 1.93 kg / 1930 g Catalogue carton data 8 pieces / 16.4 kg / 1.53 CUFT MTBF, minimum prediction 807.1K hours, Telcordia SR-332; 94.9K hours, MIL-HDBK-217F at 25°C Manufacturer warranty statement 5 years, as listed for PSPA-1000 Catalogue location / printed revision PSP / PSPA combined PDF, pages 4–8 / 2024-12-23 The per-unit mass is the catalogue PACKING reference. It is not a measured net or shipped-parcel weight, and the carton total must not be entered as the unit weight. MTBF is a reliability prediction, not a guaranteed operating life. Typical applications listed for this series include industrial automation, test and measurement, laser-related machines, burn-in facilities and RF equipment. Select and integrate the supply according to the actual electrical load and operating conditions.

Read more less

MEAN WELL PSP-600-48 is a single-output enclosed AC/DC power supply rated 48 V, 12.5 A and 600 W. It accepts 88-264 VAC or 124-370 VDC with active PFC and built-in fan cooling. Remote sense, remote ON/OFF, a POK status output and current sharing support system integration; apply the model-specific temperature limits and the parallel-operation conditions. Product Datasheet Download MEAN WELL PSP-600 Datasheet (PDF) The PSP-600 section is on PDF pages 1, 2, 3. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Output Configuration PSP-600 PSP single-output enclosed AC/DC family with active PFC and parallel current sharing; 600 is a family designation, not every variant’s actual wattage. -48 48 V nominal output; complete model PSP-600-48. Configuration Built-in remote ON/OFF, remote sense and POK output. No unlisted suffix, digital interface, auxiliary output or programming option is inferred. Output Specifications Rated output 48 VDC, 12.5 A, 600 W. Current range 0-12.5 A for individual operation, subject to derating; parallel operation has a minimum-load requirement. Voltage adjustment 41-56 V. Ripple and noise 300 mVp-p maximum under the measurement conditions below. Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.5%; load regulation ±0.5%. Timing Setup 1500 ms and rise 50 ms at full load; typical hold-up time 20 ms at full load. Unless separately specified, the reference input is 230 VAC. Unqualified parameters are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Input and Efficiency Input 88-264 VAC, 47-63 Hz, or 124-370 VDC; universal full-range AC input, with low-line derating. Typical efficiency 87%. Typical power factor 0.95 at 230 VAC and 0.99 at 115 VAC, at full load. Typical AC current 6.8 A at 115 VAC; 3.4 A at 230 VAC. Typical inrush / leakage Inrush: 20 A at 115 VAC, 40 A at 230 VAC. Leakage: <1.3 mA at 240 VAC. The block diagram includes active inrush-current limiting and active PFC. Fixed switching frequencies are 88 kHz for PFC and 100 kHz for PWM. Protection Short circuit / overload 105-135% of rated output power; constant-current limiting, with automatic recovery after the fault is removed. Overvoltage 57.6-67.2 V; output shuts down and re-powering is required. Overtemperature Output shuts down; re-power on to recover. Load Derating and Environment Ambient range -20 to +60°C, with the model-specific horizontal-orientation derating curve. Temperature load limits 80% load at -20°C, rising to 100% at 0°C; full load from 0 to +45°C, then derating to 60% at +60°C. Low-line load limits The 60 Hz input curve shows 80% load at 88 VAC, rising to 100% at 115 VAC; 100% from 115 to 264 VAC. Working / storage humidity Working: 20-90% RH. Storage: -40 to +85°C, 10-95% RH. Both are non-condensing. Temperature coefficient / vibration ±0.03%/°C from 0 to +50°C; vibration 10-500 Hz, 2 G, 10 min/cycle, 60 min each along X, Y and Z. Altitude 2000 m for CCC; up to 3000 m for UL/TUV. Above 2000 m, reduce allowable ambient temperature by 5°C per additional 1000 m. Apply both input-voltage and ambient-temperature limits. The -20 to +60°C working range does not mean continuous full output throughout that range. Cooling uses a built-in DC fan. The mechanical drawing shows airflow from the terminal end toward the opposite rear end. No numerical fan-speed, fan-stop temperature or external ventilation-clearance requirement is stated in these three pages. Remote Control, Remote Sense and POK Remote ON/OFF Short R.C.G terminal 6 to R.C. terminal 7 for power ON; open the same connection for OFF. POK output TTL voltage measured between POK terminal 5 (+) and R.C.G terminal 6 (-): 3.3-5.6 V when the supply is ON, 0-1 V when OFF. Remote sense connector CN5 Pin 1: RS+ to load positive. Pin 2: RS- to load negative. Use the page 3 remote-sensing wiring diagram. POK is the documented DC output-status signal. These pages do not specify its sink/source current limit or an isolation rating; do not assign ratings from another family. The remote-sense compensation limit, an external PV/PC programming range and an auxiliary-output rating are not specified here. RS+/RS- are sense connections, not load-power terminals. The ON condition requires the R.C.G/R.C connection above; the catalog does not establish a supplied factory jumper or a separately included control cable. Parallel Current Sharing Use no more than 4 units. Minimize the difference between unit output voltages to less than 0.2 V before parallel operation; consult the manufacturer for other arrangements. Maximum combined current = rated current per unit × number of units × 0.9. The minimum load must be greater than 3% of rated current per unit × number of units. Both limits apply in addition to the input and temperature derating. For 4 identical PSP-600-48 units, these formulas give a maximum combined current of 45 A and a minimum load strictly greater than 1.5 A, before further applicable derating. Follow the complete page 3 parallel diagram: main +V and -V outputs, current-share P, R.C.G and corresponding RS+/RS- connections are interconnected as drawn. The load-sense pair is connected only at the master unit; do not run separate remote load-sense pairs from each unit. The cover’s “up to 2400 W (3+1)” is a family-level current-sharing statement, not an unconditional continuous output or fault-redundancy rating for every voltage model. Use the actual model current, the 0.9 factor and the stated load conditions. Power and Control Terminal Assignment 1 / AC/L AC line input 2 / AC/N AC neutral input 3 / FG Protective earth 4 / P Parallel current-share signal 5 / POK TTL output-status signal, positive relative to R.C.G 6 / R.C.G Remote-control and POK reference 7 / R.C. Short to R.C.G for ON; open for OFF 8-11 / +V Main positive DC output terminals 12-15 / -V Main negative DC output terminals Use the numbered front-view drawing on PDF page 2. Terminals 1-7 are the upper AC/control strip; terminals 8-15 are the lower DC output strip. Connect protective earth to FG; keep AC, output and signal wiring distinct. Dimensions, Mounting and Mating Parts Body / case 170 × 120 × 93 mm (L × W × H); case 910A; drawing tolerance ±0.5 mm. Mounting M3 mounting holes with 4 mm maximum penetration. The plan-view pattern is 150 × 100 mm and the side-view pattern 150 × 50 mm; use the full drawing for orientation and offsets. Installation envelope Drawing depth including the terminal-side extension is 185 mm; the terminal projection is marked 14 mm maximum. These are distinct from the 170 mm body length. Terminal pitch Upper AC/control strip: 8 mm; lower DC output strip: 9.5 mm. The drawing also marks 11.5 mm end offsets. CN5 connector references Two positions. Onboard connector: JST B-XH or equivalent; mating housing: JST XHP or equivalent; contact: JST SXH-001T or equivalent. The mounting-hole 4 mm limit is penetration into the enclosure, not overall screw length. Allow for mounting-material thickness; no mounting torque, power-terminal thread/torque or main load-wire gauge is specified in these pages. The CN5 header and housing references are printed in shortened form. Do not invent an expanded order code or assume a cable/contact kit is included. No dedicated bracket, terminal-cover or full cable order code or quantity is given in this section. Safety, EMC and Reliability Approvals listed UL62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004 Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input-output, input-FG and output-FG. EMC emission BS EN/EN55032(CISPR32) Class B; BS EN/EN61000-3-2,-3; GB9245; GB17625.1; BSMI CNS15936; EAC TP TC020 EMC immunity BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level; EAC TP TC020 Minimum MTBF 1132.9K hours, Telcordia SR-332 (Bellcore); 142.2K hours, MIL-HDBK-217F at 25°C. The EMC list retains the printed GB9245 reference. Confirm the applicable certificate/standard edition for the intended installation rather than treating a catalog list as an equipment certificate. The supply is a component. The published EMC setup mounts it on a 360 × 360 mm metal plate, 1 mm thick; final equipment must be checked again for EMC compliance. MTBF is a reliability-model reference, not guaranteed service life. The manufacturer datasheet lists a 3-year warranty for PSP-600, subject to the applicable manufacturer terms. Weight and Datasheet Reference Per-unit catalog PACKING reference 1900 g (1.9 kg). Published packing 8 pieces / 15.5 kg / 1.00 CUFT. Document reference PSP-600-SPEC, 2024-12-23; pages 1-3 of the linked combined PSP/PSPA catalog. The per-unit catalog weight is not a measured net weight or shipment weight; the carton total must not be used as an individual product weight. The separate PSPA family in the same PDF has its own specifications and is not substituted for this PSP-600 model.

Read more less

MEAN WELL PSP-600-27 is a single-output enclosed AC/DC power supply rated 27 V, 22.2 A and 599.4 W. It accepts 88-264 VAC or 124-370 VDC with active PFC and built-in fan cooling. Remote sense, remote ON/OFF, a POK status output and current sharing support system integration; apply the model-specific temperature limits and the parallel-operation conditions. Product Datasheet Download MEAN WELL PSP-600 Datasheet (PDF) The PSP-600 section is on PDF pages 1, 2, 3. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Output Configuration PSP-600 PSP single-output enclosed AC/DC family with active PFC and parallel current sharing; 600 is a family designation, not every variant’s actual wattage. -27 27 V nominal output; complete model PSP-600-27. Configuration Built-in remote ON/OFF, remote sense and POK output. No unlisted suffix, digital interface, auxiliary output or programming option is inferred. Output Specifications Rated output 27 VDC, 22.2 A, 599.4 W. Current range 0-22.2 A for individual operation, subject to derating; parallel operation has a minimum-load requirement. Voltage adjustment 24-30 V. Ripple and noise 240 mVp-p maximum under the measurement conditions below. Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.5%; load regulation ±0.5%. Timing Setup 1500 ms and rise 50 ms at full load; typical hold-up time 20 ms at full load. Unless separately specified, the reference input is 230 VAC. Unqualified parameters are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Input and Efficiency Input 88-264 VAC, 47-63 Hz, or 124-370 VDC; universal full-range AC input, with low-line derating. Typical efficiency 86%. Typical power factor 0.95 at 230 VAC and 0.99 at 115 VAC, at full load. Typical AC current 6.8 A at 115 VAC; 3.4 A at 230 VAC. Typical inrush / leakage Inrush: 20 A at 115 VAC, 40 A at 230 VAC. Leakage: <1.3 mA at 240 VAC. The block diagram includes active inrush-current limiting and active PFC. Fixed switching frequencies are 88 kHz for PFC and 100 kHz for PWM. Protection Short circuit / overload 105-135% of rated output power; constant-current limiting, with automatic recovery after the fault is removed. Overvoltage 31-36.5 V; output shuts down and re-powering is required. Overtemperature Output shuts down; re-power on to recover. Load Derating and Environment Ambient range -20 to +60°C, with the model-specific horizontal-orientation derating curve. Temperature load limits 80% load at -20°C, rising to 100% at 0°C; full load from 0 to +45°C, then derating to 60% at +60°C. Low-line load limits The 60 Hz input curve shows 80% load at 88 VAC, rising to 100% at 115 VAC; 100% from 115 to 264 VAC. Working / storage humidity Working: 20-90% RH. Storage: -40 to +85°C, 10-95% RH. Both are non-condensing. Temperature coefficient / vibration ±0.03%/°C from 0 to +50°C; vibration 10-500 Hz, 2 G, 10 min/cycle, 60 min each along X, Y and Z. Altitude 2000 m for CCC; up to 3000 m for UL/TUV. Above 2000 m, reduce allowable ambient temperature by 5°C per additional 1000 m. Apply both input-voltage and ambient-temperature limits. The -20 to +60°C working range does not mean continuous full output throughout that range. Cooling uses a built-in DC fan. The mechanical drawing shows airflow from the terminal end toward the opposite rear end. No numerical fan-speed, fan-stop temperature or external ventilation-clearance requirement is stated in these three pages. Remote Control, Remote Sense and POK Remote ON/OFF Short R.C.G terminal 6 to R.C. terminal 7 for power ON; open the same connection for OFF. POK output TTL voltage measured between POK terminal 5 (+) and R.C.G terminal 6 (-): 3.3-5.6 V when the supply is ON, 0-1 V when OFF. Remote sense connector CN5 Pin 1: RS+ to load positive. Pin 2: RS- to load negative. Use the page 3 remote-sensing wiring diagram. POK is the documented DC output-status signal. These pages do not specify its sink/source current limit or an isolation rating; do not assign ratings from another family. The remote-sense compensation limit, an external PV/PC programming range and an auxiliary-output rating are not specified here. RS+/RS- are sense connections, not load-power terminals. The ON condition requires the R.C.G/R.C connection above; the catalog does not establish a supplied factory jumper or a separately included control cable. Parallel Current Sharing Use no more than 4 units. Minimize the difference between unit output voltages to less than 0.2 V before parallel operation; consult the manufacturer for other arrangements. Maximum combined current = rated current per unit × number of units × 0.9. The minimum load must be greater than 3% of rated current per unit × number of units. Both limits apply in addition to the input and temperature derating. For 4 identical PSP-600-27 units, these formulas give a maximum combined current of 79.92 A and a minimum load strictly greater than 2.664 A, before further applicable derating. Follow the complete page 3 parallel diagram: main +V and -V outputs, current-share P, R.C.G and corresponding RS+/RS- connections are interconnected as drawn. The load-sense pair is connected only at the master unit; do not run separate remote load-sense pairs from each unit. The cover’s “up to 2400 W (3+1)” is a family-level current-sharing statement, not an unconditional continuous output or fault-redundancy rating for every voltage model. Use the actual model current, the 0.9 factor and the stated load conditions. Power and Control Terminal Assignment 1 / AC/L AC line input 2 / AC/N AC neutral input 3 / FG Protective earth 4 / P Parallel current-share signal 5 / POK TTL output-status signal, positive relative to R.C.G 6 / R.C.G Remote-control and POK reference 7 / R.C. Short to R.C.G for ON; open for OFF 8-11 / +V Main positive DC output terminals 12-15 / -V Main negative DC output terminals Use the numbered front-view drawing on PDF page 2. Terminals 1-7 are the upper AC/control strip; terminals 8-15 are the lower DC output strip. Connect protective earth to FG; keep AC, output and signal wiring distinct. Dimensions, Mounting and Mating Parts Body / case 170 × 120 × 93 mm (L × W × H); case 910A; drawing tolerance ±0.5 mm. Mounting M3 mounting holes with 4 mm maximum penetration. The plan-view pattern is 150 × 100 mm and the side-view pattern 150 × 50 mm; use the full drawing for orientation and offsets. Installation envelope Drawing depth including the terminal-side extension is 185 mm; the terminal projection is marked 14 mm maximum. These are distinct from the 170 mm body length. Terminal pitch Upper AC/control strip: 8 mm; lower DC output strip: 9.5 mm. The drawing also marks 11.5 mm end offsets. CN5 connector references Two positions. Onboard connector: JST B-XH or equivalent; mating housing: JST XHP or equivalent; contact: JST SXH-001T or equivalent. The mounting-hole 4 mm limit is penetration into the enclosure, not overall screw length. Allow for mounting-material thickness; no mounting torque, power-terminal thread/torque or main load-wire gauge is specified in these pages. The CN5 header and housing references are printed in shortened form. Do not invent an expanded order code or assume a cable/contact kit is included. No dedicated bracket, terminal-cover or full cable order code or quantity is given in this section. Safety, EMC and Reliability Approvals listed UL62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004 Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input-output, input-FG and output-FG. EMC emission BS EN/EN55032(CISPR32) Class B; BS EN/EN61000-3-2,-3; GB9245; GB17625.1; BSMI CNS15936; EAC TP TC020 EMC immunity BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level; EAC TP TC020 Minimum MTBF 1132.9K hours, Telcordia SR-332 (Bellcore); 142.2K hours, MIL-HDBK-217F at 25°C. The EMC list retains the printed GB9245 reference. Confirm the applicable certificate/standard edition for the intended installation rather than treating a catalog list as an equipment certificate. The supply is a component. The published EMC setup mounts it on a 360 × 360 mm metal plate, 1 mm thick; final equipment must be checked again for EMC compliance. MTBF is a reliability-model reference, not guaranteed service life. The manufacturer datasheet lists a 3-year warranty for PSP-600, subject to the applicable manufacturer terms. Weight and Datasheet Reference Per-unit catalog PACKING reference 1900 g (1.9 kg). Published packing 8 pieces / 15.5 kg / 1.00 CUFT. Document reference PSP-600-SPEC, 2024-12-23; pages 1-3 of the linked combined PSP/PSPA catalog. The per-unit catalog weight is not a measured net weight or shipment weight; the carton total must not be used as an individual product weight. The separate PSPA family in the same PDF has its own specifications and is not substituted for this PSP-600 model.

Read more less

MEAN WELL PSP-600-24 is a single-output enclosed AC/DC power supply rated 24 V, 25 A and 600 W. It accepts 88-264 VAC or 124-370 VDC with active PFC and built-in fan cooling. Remote sense, remote ON/OFF, a POK status output and current sharing support system integration; apply the model-specific temperature limits and the parallel-operation conditions. Product Datasheet Download MEAN WELL PSP-600 Datasheet (PDF) The PSP-600 section is on PDF pages 1, 2, 3. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Output Configuration PSP-600 PSP single-output enclosed AC/DC family with active PFC and parallel current sharing; 600 is a family designation, not every variant’s actual wattage. -24 24 V nominal output; complete model PSP-600-24. Configuration Built-in remote ON/OFF, remote sense and POK output. No unlisted suffix, digital interface, auxiliary output or programming option is inferred. Output Specifications Rated output 24 VDC, 25 A, 600 W. Current range 0-25 A for individual operation, subject to derating; parallel operation has a minimum-load requirement. Voltage adjustment 20-26.4 V. Ripple and noise 240 mVp-p maximum under the measurement conditions below. Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.5%; load regulation ±0.5%. Timing Setup 1500 ms and rise 50 ms at full load; typical hold-up time 20 ms at full load. Unless separately specified, the reference input is 230 VAC. Unqualified parameters are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Input and Efficiency Input 88-264 VAC, 47-63 Hz, or 124-370 VDC; universal full-range AC input, with low-line derating. Typical efficiency 86%. Typical power factor 0.95 at 230 VAC and 0.99 at 115 VAC, at full load. Typical AC current 6.8 A at 115 VAC; 3.4 A at 230 VAC. Typical inrush / leakage Inrush: 20 A at 115 VAC, 40 A at 230 VAC. Leakage: <1.3 mA at 240 VAC. The block diagram includes active inrush-current limiting and active PFC. Fixed switching frequencies are 88 kHz for PFC and 100 kHz for PWM. Protection Short circuit / overload 105-135% of rated output power; constant-current limiting, with automatic recovery after the fault is removed. Overvoltage 27.6-32.4 V; output shuts down and re-powering is required. Overtemperature Output shuts down; re-power on to recover. Load Derating and Environment Ambient range -20 to +60°C, with the model-specific horizontal-orientation derating curve. Temperature load limits 80% load at -20°C, rising to 100% at 0°C; full load from 0 to +45°C, then derating to 60% at +60°C. Low-line load limits The 60 Hz input curve shows 80% load at 88 VAC, rising to 100% at 115 VAC; 100% from 115 to 264 VAC. Working / storage humidity Working: 20-90% RH. Storage: -40 to +85°C, 10-95% RH. Both are non-condensing. Temperature coefficient / vibration ±0.03%/°C from 0 to +50°C; vibration 10-500 Hz, 2 G, 10 min/cycle, 60 min each along X, Y and Z. Altitude 2000 m for CCC; up to 3000 m for UL/TUV. Above 2000 m, reduce allowable ambient temperature by 5°C per additional 1000 m. Apply both input-voltage and ambient-temperature limits. The -20 to +60°C working range does not mean continuous full output throughout that range. Cooling uses a built-in DC fan. The mechanical drawing shows airflow from the terminal end toward the opposite rear end. No numerical fan-speed, fan-stop temperature or external ventilation-clearance requirement is stated in these three pages. Remote Control, Remote Sense and POK Remote ON/OFF Short R.C.G terminal 6 to R.C. terminal 7 for power ON; open the same connection for OFF. POK output TTL voltage measured between POK terminal 5 (+) and R.C.G terminal 6 (-): 3.3-5.6 V when the supply is ON, 0-1 V when OFF. Remote sense connector CN5 Pin 1: RS+ to load positive. Pin 2: RS- to load negative. Use the page 3 remote-sensing wiring diagram. POK is the documented DC output-status signal. These pages do not specify its sink/source current limit or an isolation rating; do not assign ratings from another family. The remote-sense compensation limit, an external PV/PC programming range and an auxiliary-output rating are not specified here. RS+/RS- are sense connections, not load-power terminals. The ON condition requires the R.C.G/R.C connection above; the catalog does not establish a supplied factory jumper or a separately included control cable. Parallel Current Sharing Use no more than 4 units. Minimize the difference between unit output voltages to less than 0.2 V before parallel operation; consult the manufacturer for other arrangements. Maximum combined current = rated current per unit × number of units × 0.9. The minimum load must be greater than 3% of rated current per unit × number of units. Both limits apply in addition to the input and temperature derating. For 4 identical PSP-600-24 units, these formulas give a maximum combined current of 90 A and a minimum load strictly greater than 3 A, before further applicable derating. Follow the complete page 3 parallel diagram: main +V and -V outputs, current-share P, R.C.G and corresponding RS+/RS- connections are interconnected as drawn. The load-sense pair is connected only at the master unit; do not run separate remote load-sense pairs from each unit. The cover’s “up to 2400 W (3+1)” is a family-level current-sharing statement, not an unconditional continuous output or fault-redundancy rating for every voltage model. Use the actual model current, the 0.9 factor and the stated load conditions. Power and Control Terminal Assignment 1 / AC/L AC line input 2 / AC/N AC neutral input 3 / FG Protective earth 4 / P Parallel current-share signal 5 / POK TTL output-status signal, positive relative to R.C.G 6 / R.C.G Remote-control and POK reference 7 / R.C. Short to R.C.G for ON; open for OFF 8-11 / +V Main positive DC output terminals 12-15 / -V Main negative DC output terminals Use the numbered front-view drawing on PDF page 2. Terminals 1-7 are the upper AC/control strip; terminals 8-15 are the lower DC output strip. Connect protective earth to FG; keep AC, output and signal wiring distinct. Dimensions, Mounting and Mating Parts Body / case 170 × 120 × 93 mm (L × W × H); case 910A; drawing tolerance ±0.5 mm. Mounting M3 mounting holes with 4 mm maximum penetration. The plan-view pattern is 150 × 100 mm and the side-view pattern 150 × 50 mm; use the full drawing for orientation and offsets. Installation envelope Drawing depth including the terminal-side extension is 185 mm; the terminal projection is marked 14 mm maximum. These are distinct from the 170 mm body length. Terminal pitch Upper AC/control strip: 8 mm; lower DC output strip: 9.5 mm. The drawing also marks 11.5 mm end offsets. CN5 connector references Two positions. Onboard connector: JST B-XH or equivalent; mating housing: JST XHP or equivalent; contact: JST SXH-001T or equivalent. The mounting-hole 4 mm limit is penetration into the enclosure, not overall screw length. Allow for mounting-material thickness; no mounting torque, power-terminal thread/torque or main load-wire gauge is specified in these pages. The CN5 header and housing references are printed in shortened form. Do not invent an expanded order code or assume a cable/contact kit is included. No dedicated bracket, terminal-cover or full cable order code or quantity is given in this section. Safety, EMC and Reliability Approvals listed UL62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004 Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input-output, input-FG and output-FG. EMC emission BS EN/EN55032(CISPR32) Class B; BS EN/EN61000-3-2,-3; GB9245; GB17625.1; BSMI CNS15936; EAC TP TC020 EMC immunity BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level; EAC TP TC020 Minimum MTBF 1132.9K hours, Telcordia SR-332 (Bellcore); 142.2K hours, MIL-HDBK-217F at 25°C. The EMC list retains the printed GB9245 reference. Confirm the applicable certificate/standard edition for the intended installation rather than treating a catalog list as an equipment certificate. The supply is a component. The published EMC setup mounts it on a 360 × 360 mm metal plate, 1 mm thick; final equipment must be checked again for EMC compliance. MTBF is a reliability-model reference, not guaranteed service life. The manufacturer datasheet lists a 3-year warranty for PSP-600, subject to the applicable manufacturer terms. Weight and Datasheet Reference Per-unit catalog PACKING reference 1900 g (1.9 kg). Published packing 8 pieces / 15.5 kg / 1.00 CUFT. Document reference PSP-600-SPEC, 2024-12-23; pages 1-3 of the linked combined PSP/PSPA catalog. The per-unit catalog weight is not a measured net weight or shipment weight; the carton total must not be used as an individual product weight. The separate PSPA family in the same PDF has its own specifications and is not substituted for this PSP-600 model.

Read more less

MEAN WELL PSP-600-15 is a single-output enclosed AC/DC power supply rated 15 V, 40 A and 600 W. It accepts 88-264 VAC or 124-370 VDC with active PFC and built-in fan cooling. Remote sense, remote ON/OFF, a POK status output and current sharing support system integration; apply the model-specific temperature limits and the parallel-operation conditions. Product Datasheet Download MEAN WELL PSP-600 Datasheet (PDF) The PSP-600 section is on PDF pages 1, 2, 3. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Output Configuration PSP-600 PSP single-output enclosed AC/DC family with active PFC and parallel current sharing; 600 is a family designation, not every variant’s actual wattage. -15 15 V nominal output; complete model PSP-600-15. Configuration Built-in remote ON/OFF, remote sense and POK output. No unlisted suffix, digital interface, auxiliary output or programming option is inferred. Output Specifications Rated output 15 VDC, 40 A, 600 W. Current range 0-40 A for individual operation, subject to derating; parallel operation has a minimum-load requirement. Voltage adjustment 13.5-18 V. Ripple and noise 240 mVp-p maximum under the measurement conditions below. Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.5%; load regulation ±0.5%. Timing Setup 1500 ms and rise 50 ms at full load; typical hold-up time 20 ms at full load. Unless separately specified, the reference input is 230 VAC. Unqualified parameters are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Input and Efficiency Input 88-264 VAC, 47-63 Hz, or 124-370 VDC; universal full-range AC input, with low-line derating. Typical efficiency 85%. Typical power factor 0.95 at 230 VAC and 0.99 at 115 VAC, at full load. Typical AC current 6.8 A at 115 VAC; 3.4 A at 230 VAC. Typical inrush / leakage Inrush: 20 A at 115 VAC, 40 A at 230 VAC. Leakage: <1.3 mA at 240 VAC. The block diagram includes active inrush-current limiting and active PFC. Fixed switching frequencies are 88 kHz for PFC and 100 kHz for PWM. Protection Short circuit / overload 105-135% of rated output power; constant-current limiting, with automatic recovery after the fault is removed. Overvoltage 18-21 V; output shuts down and re-powering is required. Overtemperature Output shuts down; re-power on to recover. Load Derating and Environment Ambient range -20 to +60°C, with the model-specific horizontal-orientation derating curve. Temperature load limits 80% load at -20°C, rising to 100% at 0°C; full load from 0 to +45°C, then derating to 60% at +60°C. Low-line load limits The 60 Hz input curve shows 80% load at 88 VAC, rising to 100% at 115 VAC; 100% from 115 to 264 VAC. Working / storage humidity Working: 20-90% RH. Storage: -40 to +85°C, 10-95% RH. Both are non-condensing. Temperature coefficient / vibration ±0.03%/°C from 0 to +50°C; vibration 10-500 Hz, 2 G, 10 min/cycle, 60 min each along X, Y and Z. Altitude 2000 m for CCC; up to 3000 m for UL/TUV. Above 2000 m, reduce allowable ambient temperature by 5°C per additional 1000 m. Apply both input-voltage and ambient-temperature limits. The -20 to +60°C working range does not mean continuous full output throughout that range. Cooling uses a built-in DC fan. The mechanical drawing shows airflow from the terminal end toward the opposite rear end. No numerical fan-speed, fan-stop temperature or external ventilation-clearance requirement is stated in these three pages. Remote Control, Remote Sense and POK Remote ON/OFF Short R.C.G terminal 6 to R.C. terminal 7 for power ON; open the same connection for OFF. POK output TTL voltage measured between POK terminal 5 (+) and R.C.G terminal 6 (-): 3.3-5.6 V when the supply is ON, 0-1 V when OFF. Remote sense connector CN5 Pin 1: RS+ to load positive. Pin 2: RS- to load negative. Use the page 3 remote-sensing wiring diagram. POK is the documented DC output-status signal. These pages do not specify its sink/source current limit or an isolation rating; do not assign ratings from another family. The remote-sense compensation limit, an external PV/PC programming range and an auxiliary-output rating are not specified here. RS+/RS- are sense connections, not load-power terminals. The ON condition requires the R.C.G/R.C connection above; the catalog does not establish a supplied factory jumper or a separately included control cable. Parallel Current Sharing Use no more than 4 units. Minimize the difference between unit output voltages to less than 0.2 V before parallel operation; consult the manufacturer for other arrangements. Maximum combined current = rated current per unit × number of units × 0.9. The minimum load must be greater than 3% of rated current per unit × number of units. Both limits apply in addition to the input and temperature derating. For 4 identical PSP-600-15 units, these formulas give a maximum combined current of 144 A and a minimum load strictly greater than 4.8 A, before further applicable derating. Follow the complete page 3 parallel diagram: main +V and -V outputs, current-share P, R.C.G and corresponding RS+/RS- connections are interconnected as drawn. The load-sense pair is connected only at the master unit; do not run separate remote load-sense pairs from each unit. The cover’s “up to 2400 W (3+1)” is a family-level current-sharing statement, not an unconditional continuous output or fault-redundancy rating for every voltage model. Use the actual model current, the 0.9 factor and the stated load conditions. Power and Control Terminal Assignment 1 / AC/L AC line input 2 / AC/N AC neutral input 3 / FG Protective earth 4 / P Parallel current-share signal 5 / POK TTL output-status signal, positive relative to R.C.G 6 / R.C.G Remote-control and POK reference 7 / R.C. Short to R.C.G for ON; open for OFF 8-11 / +V Main positive DC output terminals 12-15 / -V Main negative DC output terminals Use the numbered front-view drawing on PDF page 2. Terminals 1-7 are the upper AC/control strip; terminals 8-15 are the lower DC output strip. Connect protective earth to FG; keep AC, output and signal wiring distinct. Dimensions, Mounting and Mating Parts Body / case 170 × 120 × 93 mm (L × W × H); case 910A; drawing tolerance ±0.5 mm. Mounting M3 mounting holes with 4 mm maximum penetration. The plan-view pattern is 150 × 100 mm and the side-view pattern 150 × 50 mm; use the full drawing for orientation and offsets. Installation envelope Drawing depth including the terminal-side extension is 185 mm; the terminal projection is marked 14 mm maximum. These are distinct from the 170 mm body length. Terminal pitch Upper AC/control strip: 8 mm; lower DC output strip: 9.5 mm. The drawing also marks 11.5 mm end offsets. CN5 connector references Two positions. Onboard connector: JST B-XH or equivalent; mating housing: JST XHP or equivalent; contact: JST SXH-001T or equivalent. The mounting-hole 4 mm limit is penetration into the enclosure, not overall screw length. Allow for mounting-material thickness; no mounting torque, power-terminal thread/torque or main load-wire gauge is specified in these pages. The CN5 header and housing references are printed in shortened form. Do not invent an expanded order code or assume a cable/contact kit is included. No dedicated bracket, terminal-cover or full cable order code or quantity is given in this section. Safety, EMC and Reliability Approvals listed UL62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004 Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input-output, input-FG and output-FG. EMC emission BS EN/EN55032(CISPR32) Class B; BS EN/EN61000-3-2,-3; GB9245; GB17625.1; BSMI CNS15936; EAC TP TC020 EMC immunity BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level; EAC TP TC020 Minimum MTBF 1132.9K hours, Telcordia SR-332 (Bellcore); 142.2K hours, MIL-HDBK-217F at 25°C. The EMC list retains the printed GB9245 reference. Confirm the applicable certificate/standard edition for the intended installation rather than treating a catalog list as an equipment certificate. The supply is a component. The published EMC setup mounts it on a 360 × 360 mm metal plate, 1 mm thick; final equipment must be checked again for EMC compliance. MTBF is a reliability-model reference, not guaranteed service life. The manufacturer datasheet lists a 3-year warranty for PSP-600, subject to the applicable manufacturer terms. Weight and Datasheet Reference Per-unit catalog PACKING reference 1900 g (1.9 kg). Published packing 8 pieces / 15.5 kg / 1.00 CUFT. Document reference PSP-600-SPEC, 2024-12-23; pages 1-3 of the linked combined PSP/PSPA catalog. The per-unit catalog weight is not a measured net weight or shipment weight; the carton total must not be used as an individual product weight. The separate PSPA family in the same PDF has its own specifications and is not substituted for this PSP-600 model.

Read more less

MEAN WELL PSP-600-13.5 is a single-output enclosed AC/DC power supply rated 13.5 V, 44.5 A and 600.75 W. It accepts 88-264 VAC or 124-370 VDC with active PFC and built-in fan cooling. Remote sense, remote ON/OFF, a POK status output and current sharing support system integration; apply the model-specific temperature limits and the parallel-operation conditions. Product Datasheet Download MEAN WELL PSP-600 Datasheet (PDF) The PSP-600 section is on PDF pages 1, 2, 3. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Output Configuration PSP-600 PSP single-output enclosed AC/DC family with active PFC and parallel current sharing; 600 is a family designation, not every variant’s actual wattage. -13.5 13.5 V nominal output; complete model PSP-600-13.5. Configuration Built-in remote ON/OFF, remote sense and POK output. No unlisted suffix, digital interface, auxiliary output or programming option is inferred. Output Specifications Rated output 13.5 VDC, 44.5 A, 600.75 W. Current range 0-44.5 A for individual operation, subject to derating; parallel operation has a minimum-load requirement. Voltage adjustment 12-15 V. Ripple and noise 240 mVp-p maximum under the measurement conditions below. Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.5%; load regulation ±0.5%. Timing Setup 1500 ms and rise 50 ms at full load; typical hold-up time 20 ms at full load. Unless separately specified, the reference input is 230 VAC. Unqualified parameters are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Input and Efficiency Input 88-264 VAC, 47-63 Hz, or 124-370 VDC; universal full-range AC input, with low-line derating. Typical efficiency 85%. Typical power factor 0.95 at 230 VAC and 0.99 at 115 VAC, at full load. Typical AC current 6.8 A at 115 VAC; 3.4 A at 230 VAC. Typical inrush / leakage Inrush: 20 A at 115 VAC, 40 A at 230 VAC. Leakage: <1.3 mA at 240 VAC. The block diagram includes active inrush-current limiting and active PFC. Fixed switching frequencies are 88 kHz for PFC and 100 kHz for PWM. Protection Short circuit / overload 105-135% of rated output power; constant-current limiting, with automatic recovery after the fault is removed. Overvoltage 15.5-18.2 V; output shuts down and re-powering is required. Overtemperature Output shuts down; re-power on to recover. Load Derating and Environment Ambient range -20 to +60°C, with the model-specific horizontal-orientation derating curve. Temperature load limits 80% load at -20°C, rising to 100% at 0°C; full load from 0 to +45°C, then derating to 60% at +60°C. Low-line load limits The 60 Hz input curve shows 80% load at 88 VAC, rising to 100% at 115 VAC; 100% from 115 to 264 VAC. Working / storage humidity Working: 20-90% RH. Storage: -40 to +85°C, 10-95% RH. Both are non-condensing. Temperature coefficient / vibration ±0.03%/°C from 0 to +50°C; vibration 10-500 Hz, 2 G, 10 min/cycle, 60 min each along X, Y and Z. Altitude 2000 m for CCC; up to 3000 m for UL/TUV. Above 2000 m, reduce allowable ambient temperature by 5°C per additional 1000 m. Apply both input-voltage and ambient-temperature limits. The -20 to +60°C working range does not mean continuous full output throughout that range. Cooling uses a built-in DC fan. The mechanical drawing shows airflow from the terminal end toward the opposite rear end. No numerical fan-speed, fan-stop temperature or external ventilation-clearance requirement is stated in these three pages. Remote Control, Remote Sense and POK Remote ON/OFF Short R.C.G terminal 6 to R.C. terminal 7 for power ON; open the same connection for OFF. POK output TTL voltage measured between POK terminal 5 (+) and R.C.G terminal 6 (-): 3.3-5.6 V when the supply is ON, 0-1 V when OFF. Remote sense connector CN5 Pin 1: RS+ to load positive. Pin 2: RS- to load negative. Use the page 3 remote-sensing wiring diagram. POK is the documented DC output-status signal. These pages do not specify its sink/source current limit or an isolation rating; do not assign ratings from another family. The remote-sense compensation limit, an external PV/PC programming range and an auxiliary-output rating are not specified here. RS+/RS- are sense connections, not load-power terminals. The ON condition requires the R.C.G/R.C connection above; the catalog does not establish a supplied factory jumper or a separately included control cable. Parallel Current Sharing Use no more than 4 units. Minimize the difference between unit output voltages to less than 0.2 V before parallel operation; consult the manufacturer for other arrangements. Maximum combined current = rated current per unit × number of units × 0.9. The minimum load must be greater than 3% of rated current per unit × number of units. Both limits apply in addition to the input and temperature derating. For 4 identical PSP-600-13.5 units, these formulas give a maximum combined current of 160.2 A and a minimum load strictly greater than 5.34 A, before further applicable derating. Follow the complete page 3 parallel diagram: main +V and -V outputs, current-share P, R.C.G and corresponding RS+/RS- connections are interconnected as drawn. The load-sense pair is connected only at the master unit; do not run separate remote load-sense pairs from each unit. The cover’s “up to 2400 W (3+1)” is a family-level current-sharing statement, not an unconditional continuous output or fault-redundancy rating for every voltage model. Use the actual model current, the 0.9 factor and the stated load conditions. Power and Control Terminal Assignment 1 / AC/L AC line input 2 / AC/N AC neutral input 3 / FG Protective earth 4 / P Parallel current-share signal 5 / POK TTL output-status signal, positive relative to R.C.G 6 / R.C.G Remote-control and POK reference 7 / R.C. Short to R.C.G for ON; open for OFF 8-11 / +V Main positive DC output terminals 12-15 / -V Main negative DC output terminals Use the numbered front-view drawing on PDF page 2. Terminals 1-7 are the upper AC/control strip; terminals 8-15 are the lower DC output strip. Connect protective earth to FG; keep AC, output and signal wiring distinct. Dimensions, Mounting and Mating Parts Body / case 170 × 120 × 93 mm (L × W × H); case 910A; drawing tolerance ±0.5 mm. Mounting M3 mounting holes with 4 mm maximum penetration. The plan-view pattern is 150 × 100 mm and the side-view pattern 150 × 50 mm; use the full drawing for orientation and offsets. Installation envelope Drawing depth including the terminal-side extension is 185 mm; the terminal projection is marked 14 mm maximum. These are distinct from the 170 mm body length. Terminal pitch Upper AC/control strip: 8 mm; lower DC output strip: 9.5 mm. The drawing also marks 11.5 mm end offsets. CN5 connector references Two positions. Onboard connector: JST B-XH or equivalent; mating housing: JST XHP or equivalent; contact: JST SXH-001T or equivalent. The mounting-hole 4 mm limit is penetration into the enclosure, not overall screw length. Allow for mounting-material thickness; no mounting torque, power-terminal thread/torque or main load-wire gauge is specified in these pages. The CN5 header and housing references are printed in shortened form. Do not invent an expanded order code or assume a cable/contact kit is included. No dedicated bracket, terminal-cover or full cable order code or quantity is given in this section. Safety, EMC and Reliability Approvals listed UL62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004 Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input-output, input-FG and output-FG. EMC emission BS EN/EN55032(CISPR32) Class B; BS EN/EN61000-3-2,-3; GB9245; GB17625.1; BSMI CNS15936; EAC TP TC020 EMC immunity BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level; EAC TP TC020 Minimum MTBF 1132.9K hours, Telcordia SR-332 (Bellcore); 142.2K hours, MIL-HDBK-217F at 25°C. The EMC list retains the printed GB9245 reference. Confirm the applicable certificate/standard edition for the intended installation rather than treating a catalog list as an equipment certificate. The supply is a component. The published EMC setup mounts it on a 360 × 360 mm metal plate, 1 mm thick; final equipment must be checked again for EMC compliance. MTBF is a reliability-model reference, not guaranteed service life. The manufacturer datasheet lists a 3-year warranty for PSP-600, subject to the applicable manufacturer terms. Weight and Datasheet Reference Per-unit catalog PACKING reference 1900 g (1.9 kg). Published packing 8 pieces / 15.5 kg / 1.00 CUFT. Document reference PSP-600-SPEC, 2024-12-23; pages 1-3 of the linked combined PSP/PSPA catalog. The per-unit catalog weight is not a measured net weight or shipment weight; the carton total must not be used as an individual product weight. The separate PSPA family in the same PDF has its own specifications and is not substituted for this PSP-600 model.

Read more less

MEAN WELL PSP-600-12 is a single-output enclosed AC/DC power supply rated 12 V, 50 A and 600 W. It accepts 88-264 VAC or 124-370 VDC with active PFC and built-in fan cooling. Remote sense, remote ON/OFF, a POK status output and current sharing support system integration; apply the model-specific temperature limits and the parallel-operation conditions. Product Datasheet Download MEAN WELL PSP-600 Datasheet (PDF) The PSP-600 section is on PDF pages 1, 2, 3. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Output Configuration PSP-600 PSP single-output enclosed AC/DC family with active PFC and parallel current sharing; 600 is a family designation, not every variant’s actual wattage. -12 12 V nominal output; complete model PSP-600-12. Configuration Built-in remote ON/OFF, remote sense and POK output. No unlisted suffix, digital interface, auxiliary output or programming option is inferred. Output Specifications Rated output 12 VDC, 50 A, 600 W. Current range 0-50 A for individual operation, subject to derating; parallel operation has a minimum-load requirement. Voltage adjustment 10-13.2 V. Ripple and noise 240 mVp-p maximum under the measurement conditions below. Accuracy and regulation Voltage tolerance ±1.0%; line regulation ±0.5%; load regulation ±0.5%. Timing Setup 1500 ms and rise 50 ms at full load; typical hold-up time 20 ms at full load. Unless separately specified, the reference input is 230 VAC. Unqualified parameters are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Input and Efficiency Input 88-264 VAC, 47-63 Hz, or 124-370 VDC; universal full-range AC input, with low-line derating. Typical efficiency 84%. Typical power factor 0.95 at 230 VAC and 0.99 at 115 VAC, at full load. Typical AC current 6.8 A at 115 VAC; 3.4 A at 230 VAC. Typical inrush / leakage Inrush: 20 A at 115 VAC, 40 A at 230 VAC. Leakage: <1.3 mA at 240 VAC. The block diagram includes active inrush-current limiting and active PFC. Fixed switching frequencies are 88 kHz for PFC and 100 kHz for PWM. Protection Short circuit / overload 105-135% of rated output power; constant-current limiting, with automatic recovery after the fault is removed. Overvoltage 13.8-16.2 V; output shuts down and re-powering is required. Overtemperature Output shuts down; re-power on to recover. Load Derating and Environment Ambient range -20 to +60°C, with the model-specific horizontal-orientation derating curve. Temperature load limits 80% load at -20°C, rising to 100% at 0°C; full load from 0 to +40°C, then derating to 50% at +60°C. Low-line load limits The 60 Hz input curve shows 80% load at 88 VAC, rising to 100% at 115 VAC; 100% from 115 to 264 VAC. Working / storage humidity Working: 20-90% RH. Storage: -40 to +85°C, 10-95% RH. Both are non-condensing. Temperature coefficient / vibration ±0.03%/°C from 0 to +50°C; vibration 10-500 Hz, 2 G, 10 min/cycle, 60 min each along X, Y and Z. Altitude 2000 m for CCC; up to 3000 m for UL/TUV. Above 2000 m, reduce allowable ambient temperature by 5°C per additional 1000 m. Apply both input-voltage and ambient-temperature limits. The -20 to +60°C working range does not mean continuous full output throughout that range. Cooling uses a built-in DC fan. The mechanical drawing shows airflow from the terminal end toward the opposite rear end. No numerical fan-speed, fan-stop temperature or external ventilation-clearance requirement is stated in these three pages. Remote Control, Remote Sense and POK Remote ON/OFF Short R.C.G terminal 6 to R.C. terminal 7 for power ON; open the same connection for OFF. POK output TTL voltage measured between POK terminal 5 (+) and R.C.G terminal 6 (-): 3.3-5.6 V when the supply is ON, 0-1 V when OFF. Remote sense connector CN5 Pin 1: RS+ to load positive. Pin 2: RS- to load negative. Use the page 3 remote-sensing wiring diagram. POK is the documented DC output-status signal. These pages do not specify its sink/source current limit or an isolation rating; do not assign ratings from another family. The remote-sense compensation limit, an external PV/PC programming range and an auxiliary-output rating are not specified here. RS+/RS- are sense connections, not load-power terminals. The ON condition requires the R.C.G/R.C connection above; the catalog does not establish a supplied factory jumper or a separately included control cable. Parallel Current Sharing Use no more than 4 units. Minimize the difference between unit output voltages to less than 0.2 V before parallel operation; consult the manufacturer for other arrangements. Maximum combined current = rated current per unit × number of units × 0.9. The minimum load must be greater than 3% of rated current per unit × number of units. Both limits apply in addition to the input and temperature derating. For 4 identical PSP-600-12 units, these formulas give a maximum combined current of 180 A and a minimum load strictly greater than 6 A, before further applicable derating. Follow the complete page 3 parallel diagram: main +V and -V outputs, current-share P, R.C.G and corresponding RS+/RS- connections are interconnected as drawn. The load-sense pair is connected only at the master unit; do not run separate remote load-sense pairs from each unit. The cover’s “up to 2400 W (3+1)” is a family-level current-sharing statement, not an unconditional continuous output or fault-redundancy rating for every voltage model. Use the actual model current, the 0.9 factor and the stated load conditions. Power and Control Terminal Assignment 1 / AC/L AC line input 2 / AC/N AC neutral input 3 / FG Protective earth 4 / P Parallel current-share signal 5 / POK TTL output-status signal, positive relative to R.C.G 6 / R.C.G Remote-control and POK reference 7 / R.C. Short to R.C.G for ON; open for OFF 8-11 / +V Main positive DC output terminals 12-15 / -V Main negative DC output terminals Use the numbered front-view drawing on PDF page 2. Terminals 1-7 are the upper AC/control strip; terminals 8-15 are the lower DC output strip. Connect protective earth to FG; keep AC, output and signal wiring distinct. Dimensions, Mounting and Mating Parts Body / case 170 × 120 × 93 mm (L × W × H); case 910A; drawing tolerance ±0.5 mm. Mounting M3 mounting holes with 4 mm maximum penetration. The plan-view pattern is 150 × 100 mm and the side-view pattern 150 × 50 mm; use the full drawing for orientation and offsets. Installation envelope Drawing depth including the terminal-side extension is 185 mm; the terminal projection is marked 14 mm maximum. These are distinct from the 170 mm body length. Terminal pitch Upper AC/control strip: 8 mm; lower DC output strip: 9.5 mm. The drawing also marks 11.5 mm end offsets. CN5 connector references Two positions. Onboard connector: JST B-XH or equivalent; mating housing: JST XHP or equivalent; contact: JST SXH-001T or equivalent. The mounting-hole 4 mm limit is penetration into the enclosure, not overall screw length. Allow for mounting-material thickness; no mounting torque, power-terminal thread/torque or main load-wire gauge is specified in these pages. The CN5 header and housing references are printed in shortened form. Do not invent an expanded order code or assume a cable/contact kit is included. No dedicated bracket, terminal-cover or full cable order code or quantity is given in this section. Safety, EMC and Reliability Approvals listed UL62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004 Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input-output, input-FG and output-FG. EMC emission BS EN/EN55032(CISPR32) Class B; BS EN/EN61000-3-2,-3; GB9245; GB17625.1; BSMI CNS15936; EAC TP TC020 EMC immunity BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level; EAC TP TC020 Minimum MTBF 1132.9K hours, Telcordia SR-332 (Bellcore); 142.2K hours, MIL-HDBK-217F at 25°C. The EMC list retains the printed GB9245 reference. Confirm the applicable certificate/standard edition for the intended installation rather than treating a catalog list as an equipment certificate. The supply is a component. The published EMC setup mounts it on a 360 × 360 mm metal plate, 1 mm thick; final equipment must be checked again for EMC compliance. MTBF is a reliability-model reference, not guaranteed service life. The manufacturer datasheet lists a 3-year warranty for PSP-600, subject to the applicable manufacturer terms. Weight and Datasheet Reference Per-unit catalog PACKING reference 1900 g (1.9 kg). Published packing 8 pieces / 15.5 kg / 1.00 CUFT. Document reference PSP-600-SPEC, 2024-12-23; pages 1-3 of the linked combined PSP/PSPA catalog. The per-unit catalog weight is not a measured net weight or shipment weight; the carton total must not be used as an individual product weight. The separate PSPA family in the same PDF has its own specifications and is not substituted for this PSP-600 model.

Read more less

MEAN WELL PSP-600-5 is a single-output enclosed AC/DC power supply rated 5 V, 80 A and 400 W. It accepts 88-264 VAC or 124-370 VDC with active PFC and built-in fan cooling. Remote sense, remote ON/OFF, a POK status output and current sharing support system integration; apply the model-specific temperature limits and the parallel-operation conditions. Product Datasheet Download MEAN WELL PSP-600 Datasheet (PDF) The PSP-600 section is on PDF pages 1, 2, 3. Refer to the complete mechanical drawings and notes when planning installation. Model Code and Output Configuration PSP-600 PSP single-output enclosed AC/DC family with active PFC and parallel current sharing; 600 is a family designation, not every variant’s actual wattage. -5 5 V nominal output; complete model PSP-600-5. Configuration Built-in remote ON/OFF, remote sense and POK output. No unlisted suffix, digital interface, auxiliary output or programming option is inferred. Output Specifications Rated output 5 VDC, 80 A, 400 W. Current range 0-80 A for individual operation, subject to derating; parallel operation has a minimum-load requirement. Voltage adjustment 4.75-5.5 V. Ripple and noise 180 mVp-p maximum under the measurement conditions below. Accuracy and regulation Voltage tolerance ±2.0%; line regulation ±0.5%; load regulation ±1.0%. Timing Setup 1500 ms and rise 50 ms at full load; typical hold-up time 20 ms at full load. Unless separately specified, the reference input is 230 VAC. Unqualified parameters are measured at 230 VAC, rated load and 25°C ambient. Voltage tolerance includes setup tolerance, line regulation and load regulation. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Input and Efficiency Input 88-264 VAC, 47-63 Hz, or 124-370 VDC; universal full-range AC input, with low-line derating. Typical efficiency 79%. Typical power factor 0.95 at 230 VAC and 0.99 at 115 VAC, at full load. Typical AC current 6.8 A at 115 VAC; 3.4 A at 230 VAC. Typical inrush / leakage Inrush: 20 A at 115 VAC, 40 A at 230 VAC. Leakage: <1.3 mA at 240 VAC. The block diagram includes active inrush-current limiting and active PFC. Fixed switching frequencies are 88 kHz for PFC and 100 kHz for PWM. Protection Short circuit / overload 105-135% of rated output power; constant-current limiting, with automatic recovery after the fault is removed. Overvoltage 5.75-6.75 V; output shuts down and re-powering is required. Overtemperature Output shuts down; re-power on to recover. Load Derating and Environment Ambient range -20 to +60°C, with the model-specific horizontal-orientation derating curve. Temperature load limits 80% load at -20°C, rising to 100% at 0°C; full load from 0 to +45°C, then derating to 60% at +60°C. Low-line load limits The 60 Hz input curve shows 80% load at 88 VAC, rising to 100% at 115 VAC; 100% from 115 to 264 VAC. Working / storage humidity Working: 20-90% RH. Storage: -40 to +85°C, 10-95% RH. Both are non-condensing. Temperature coefficient / vibration ±0.03%/°C from 0 to +50°C; vibration 10-500 Hz, 2 G, 10 min/cycle, 60 min each along X, Y and Z. Altitude 2000 m for CCC; up to 3000 m for UL/TUV. Above 2000 m, reduce allowable ambient temperature by 5°C per additional 1000 m. Apply both input-voltage and ambient-temperature limits. The -20 to +60°C working range does not mean continuous full output throughout that range. Cooling uses a built-in DC fan. The mechanical drawing shows airflow from the terminal end toward the opposite rear end. No numerical fan-speed, fan-stop temperature or external ventilation-clearance requirement is stated in these three pages. Remote Control, Remote Sense and POK Remote ON/OFF Short R.C.G terminal 6 to R.C. terminal 7 for power ON; open the same connection for OFF. POK output TTL voltage measured between POK terminal 5 (+) and R.C.G terminal 6 (-): 3.3-5.6 V when the supply is ON, 0-1 V when OFF. Remote sense connector CN5 Pin 1: RS+ to load positive. Pin 2: RS- to load negative. Use the page 3 remote-sensing wiring diagram. POK is the documented DC output-status signal. These pages do not specify its sink/source current limit or an isolation rating; do not assign ratings from another family. The remote-sense compensation limit, an external PV/PC programming range and an auxiliary-output rating are not specified here. RS+/RS- are sense connections, not load-power terminals. The ON condition requires the R.C.G/R.C connection above; the catalog does not establish a supplied factory jumper or a separately included control cable. Parallel Current Sharing Use no more than 4 units. Minimize the difference between unit output voltages to less than 0.2 V before parallel operation; consult the manufacturer for other arrangements. Maximum combined current = rated current per unit × number of units × 0.9. The minimum load must be greater than 3% of rated current per unit × number of units. Both limits apply in addition to the input and temperature derating. For 4 identical PSP-600-5 units, these formulas give a maximum combined current of 288 A and a minimum load strictly greater than 9.6 A, before further applicable derating. Follow the complete page 3 parallel diagram: main +V and -V outputs, current-share P, R.C.G and corresponding RS+/RS- connections are interconnected as drawn. The load-sense pair is connected only at the master unit; do not run separate remote load-sense pairs from each unit. The cover’s “up to 2400 W (3+1)” is a family-level current-sharing statement, not an unconditional continuous output or fault-redundancy rating for every voltage model. Use the actual model current, the 0.9 factor and the stated load conditions. Power and Control Terminal Assignment 1 / AC/L AC line input 2 / AC/N AC neutral input 3 / FG Protective earth 4 / P Parallel current-share signal 5 / POK TTL output-status signal, positive relative to R.C.G 6 / R.C.G Remote-control and POK reference 7 / R.C. Short to R.C.G for ON; open for OFF 8-11 / +V Main positive DC output terminals 12-15 / -V Main negative DC output terminals Use the numbered front-view drawing on PDF page 2. Terminals 1-7 are the upper AC/control strip; terminals 8-15 are the lower DC output strip. Connect protective earth to FG; keep AC, output and signal wiring distinct. Dimensions, Mounting and Mating Parts Body / case 170 × 120 × 93 mm (L × W × H); case 910A; drawing tolerance ±0.5 mm. Mounting M3 mounting holes with 4 mm maximum penetration. The plan-view pattern is 150 × 100 mm and the side-view pattern 150 × 50 mm; use the full drawing for orientation and offsets. Installation envelope Drawing depth including the terminal-side extension is 185 mm; the terminal projection is marked 14 mm maximum. These are distinct from the 170 mm body length. Terminal pitch Upper AC/control strip: 8 mm; lower DC output strip: 9.5 mm. The drawing also marks 11.5 mm end offsets. CN5 connector references Two positions. Onboard connector: JST B-XH or equivalent; mating housing: JST XHP or equivalent; contact: JST SXH-001T or equivalent. The mounting-hole 4 mm limit is penetration into the enclosure, not overall screw length. Allow for mounting-material thickness; no mounting torque, power-terminal thread/torque or main load-wire gauge is specified in these pages. The CN5 header and housing references are printed in shortened form. Do not invent an expanded order code or assume a cable/contact kit is included. No dedicated bracket, terminal-cover or full cable order code or quantity is given in this section. Safety, EMC and Reliability Approvals listed UL62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004 Withstand voltage Input-output: 3 kVAC; input-FG: 2 kVAC; output-FG: 0.5 kVAC. Insulation resistance 100 MΩ at 500 VDC, 25°C and 70% RH for input-output, input-FG and output-FG. EMC emission BS EN/EN55032(CISPR32) Class B; BS EN/EN61000-3-2,-3; GB9245; GB17625.1; BSMI CNS15936; EAC TP TC020 EMC immunity BS EN/EN61000-4-2,3,4,5,6,8,11; BS EN/EN55035, light industry level; EAC TP TC020 Minimum MTBF 1132.9K hours, Telcordia SR-332 (Bellcore); 142.2K hours, MIL-HDBK-217F at 25°C. The EMC list retains the printed GB9245 reference. Confirm the applicable certificate/standard edition for the intended installation rather than treating a catalog list as an equipment certificate. The supply is a component. The published EMC setup mounts it on a 360 × 360 mm metal plate, 1 mm thick; final equipment must be checked again for EMC compliance. MTBF is a reliability-model reference, not guaranteed service life. The manufacturer datasheet lists a 3-year warranty for PSP-600, subject to the applicable manufacturer terms. Weight and Datasheet Reference Per-unit catalog PACKING reference 1900 g (1.9 kg). Published packing 8 pieces / 15.5 kg / 1.00 CUFT. Document reference PSP-600-SPEC, 2024-12-23; pages 1-3 of the linked combined PSP/PSPA catalog. The per-unit catalog weight is not a measured net weight or shipment weight; the carton total must not be used as an individual product weight. The separate PSPA family in the same PDF has its own specifications and is not substituted for this PSP-600 model.

Read more less
