MEAN WELL RPS-200-12 is a PCB open-frame medical AC/DC supply with 12 V output. It delivers 140.4 W by convection and 200.4 W with 10 CFM forced air. Apply the load, thermal and system-integration conditions below.
Product Datasheet
Download MEAN WELL RPS-200 Datasheet (PDF)
The RPS-200 section is on PDF pages 27, 28, 29, 30, 31, 32. Refer to the complete mechanical drawings and notes when planning installation.
Model and Application
Complete model
RPS-200-12.
Series and construction
RPS-200 medical AC/DC power supply; PCB open-frame construction.
Voltage code
12 specifies the nominal DC output voltage.
System class
Suitable for Class I systems with FG or Class II systems without FG, subject to the model-specific EMC conditions below.
Medical application
Primary-to-secondary 2 MOPP. Suitable for BF applications only with appropriate system consideration; final equipment compliance remains an integration requirement.
Catalogue applications include oral irrigators, hemodialysis machines, medical monitors, sleep-apnea devices and pumps. Electric beds are also listed for this series.
DC Output and Load Conditions
Nominal output
12 V.
Convection rating
11.7 A; catalogue-rated 140.4 W.
10 CFM forced air rating
16.7 A; catalogue-rated 200.4 W.
Adjustment range
11.4–12.6 V, using SVR1.
Ripple and noise, maximum
100 mVp-p.
Voltage tolerance
±2.0%; includes setup tolerance, line regulation and load regulation.
Line regulation
±0.5%.
Load regulation
±1.0%.
Efficiency, typical
93%.
The higher rating requires 10 CFM forced airflow. The convection rating applies without that forced airflow; do not treat the two ratings as interchangeable.
Do not exceed the applicable voltage, current or catalogue-rated power limit. Combine the cooling, input-voltage and ambient-temperature limits. Ripple is measured at 20 MHz with a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors.
Input, Start-Up and Consumption
Input range
80–264 VAC or 113–370 VDC; low-input derating applies.
Frequency
47–63 Hz.
AC input current, typical
2 A at 115 VAC; 1 A at 230 VAC.
Cold-start inrush, typical
30 A at 115 VAC; 60 A at 230 VAC.
No-load consumption
Less than 0.5 W.
Set-up and rise
700 ms setup and 30 ms rise at both 230 VAC and 115 VAC, full load.
Hold-up, typical
16 ms at 230 VAC; 16 ms at 115 VAC, full load.
Leakage at 264 VAC
Earth leakage <180 µA; touch current <40 µA. Touch current is measured from primary input to DC output.
Switching-frequency diagram
65 kHz.
Power factor
Built-in active PFC; PF >0.94 at 230 VAC and >0.98 at 115 VAC, full load.
Unless separately stated, parameters are measured at 230 VAC, rated load and 25°C ambient.
Protection
Short circuit and overload
Short-circuit protection is listed. Overload operates at 110–140% of rated output power; hiccup mode recovers automatically after the fault is removed.
Overvoltage threshold
13.2–15.6 V.
Overvoltage response
Output shuts down; re-power on to recover.
Overtemperature response
Output shuts down. Re-power on to recover.
Cooling and Derating
Ambient range
−30 to +70°C, with derating; horizontal mounting.
Convection temperature curve
The graph shows 70% load from −30 to 45°C, falling to 40% at 70°C. Use the model-specific convection current and wattage above.
Input-voltage curve, 60 Hz
80 VAC: 70%; 115 VAC: 100%, maintained to 264 VAC. The curve is explicitly for 10 CFM operation.
10 CFM temperature curve
100% load from −30 to 50°C, falling to 40% at 70°C.
Fan arrangement
The mechanical drawing positions an external 10 CFM fan 5 cm from the assembly in the indicated airflow direction; preserve that airflow path. A fan is not claimed as supplied.
Use the complete plotted curves for intermediate conditions; the maximum ambient temperature is a derated point. Apply the most restrictive simultaneous limit.
Environment
Operating humidity
20–90% RH, non-condensing.
Storage
−40 to +85°C; 10–95% RH, non-condensing.
Temperature coefficient
±0.03%/°C over 0–50°C.
Vibration
10–500 Hz, 2 G; 10 minutes per cycle, 60 minutes each along X, Y and Z.
Operating altitude
5,000 m.
High-altitude derating
Above 2,000 m, reduce allowed ambient temperature by 3.5°C per 1,000 m for fanless operation or 5°C per 1,000 m for fan-cooled operation.
Dimensions and Installation
Dimensions, L × W × H
101.6 × 50.8 × 29 mm. General drawing tolerance ±1 mm.
Mounting geometry
Four 3.3 mm mounting holes on a 95.25 × 44.45 mm pattern; 3.175 mm edge offsets; underside projection 3 mm maximum. Follow the complete PCB drawing.
Adjustment
Use SVR1 within the stated voltage-adjustment range.
Indicator
The mechanical drawing identifies an LED power indicator.
Follow the manufacturer’s installation manual and the model-specific drawing. No separate mounting-kit ordering code is listed in these assigned pages.
Input and Output Connectors
AC input CN1
JST B3P-VH or equivalent; pin 1: AC/L, pin 2: No pin, pin 3: AC/N.
DC output CN2
JST B6P-VH or equivalent; pins 1, 2, 3 are +V; pins 4, 5, 6 are −V.
Input/output mating housing
JST VHR or equivalent, exactly the family designation printed in the sheet. Select the matching circuit count; no complete housing suffix is supplied here.
Input/output contact
JST SVH-21T-P1.1 or equivalent.
Connector references identify compatible interfaces, not an included loose cable or accessory kit. Confirm fit and ratings for an equivalent component.
Fan Supply and Connector
Fan output
12 V at 0.5 A for the cooling fan only.
Specified tolerance
±15% at 20% of the main-output rated current under 10 CFM conditions.
CN101
JST B2B-PH-K-S or equivalent; pin 1: +12 V, pin 2: DC COM.
Mating housing
JST PHR-2 or equivalent.
Contact
JST SPH-002T-P0.5S or equivalent.
This output is intended to power the additional external fan for cooling and full-load delivery. Do not use it to drive other devices.
Safety and EMC
Safety approvals
IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional approval.
Isolation barriers
Primary–secondary: 2 MOPP; primary–earth: 1 MOPP; secondary–earth: 1 MOPP.
Withstand voltage
Input–output: 4 kVAC; input–FG: 2 kVAC; output–FG: 1.5 kVAC.
Insulation resistance
I/P–O/P, I/P–FG: 100 MΩ at 500 VDC, 25°C and 70% RH.
Emissions, BS EN/EN55011 (CISPR11)
Conducted Class B; radiated Class B with FG in Class I, or Class A without FG in Class II for the PCB type. The enclosed -C type is not suitable for Class II.
Harmonics and flicker
BS EN/EN61000-3-2 Class A; BS EN/EN61000-3-3 listed.
Immunity framework
BS EN/EN55035 and BS EN/EN60601-1-2.
ESD, IEC/EN61000-4-2
Level 4: 15 kV air and 8 kV contact.
RF field, IEC/EN61000-4-3
Level 3: 10 V/m at 80 MHz–2.7 GHz; Table 9 proximity fields 9–28 V/m at 385 MHz–5.78 GHz.
EFT, IEC/EN61000-4-4
Level 3, 2 kV.
Surge, IEC/EN61000-4-5
Level 4: 4 kV line–FG; 2 kV line–line.
Conducted immunity, IEC/EN61000-4-6
Level 3, 10 V.
Magnetic field, IEC/EN61000-4-8
Level 4, 30 A/m.
Voltage dips and interruptions, IEC/EN61000-4-11
100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods.
EMC testing uses a 360 × 360 × 1 mm metal plate. This supply is a component for installation in final equipment; the complete equipment must be reconfirmed for EMC and applicable medical-system safety.
Weight and Catalogue Reference
Single-unit catalogue weight
190 g (0.19 kg), explicitly listed in PACKING; a catalogue reference rather than measured shipment weight.
Packing
72 pieces / 14.7 kg / 0.84 CUFT.
Minimum MTBF estimates
2669.7 thousand hours, Telcordia SR-332 (Bellcore); 500.3 thousand hours, MIL-HDBK-217F at 25°C.
Manufacturer warranty
3 years, subject to the applicable manufacturer terms.
Catalogue version
RPS-200-SPEC 2026-02-28; combined PDF pages 27–32.
Lifetime feature
The family feature page states lifetime greater than 65,000 hours; it does not state the test conditions there. This is distinct from the MTBF estimates.
Family power-density claim
The family introduction states up to 21.9 W/in³; this is not an individual configuration measurement.
MTBF is a statistical estimate under the listed methods, not a guaranteed service life.
