  MEAN WELL RSP-1500 series: single-output enclosed AC/DC power supply with active PFC - RSP-1500-48

  MEAN WELL RSP-1500-48 is an enclosed single-output AC/DC power supply rated at 48 V DC, 32 A and 1536 W, with active PFC and a built-in DC fan. It accepts 90 to 264 VAC or 127 to 370 VDC. Apply the input, temperature and functional limits below. Product Datasheet Download MEAN WELL RSP-1500 Datasheet (PDF) The RSP-1500 section is on PDF pages 17, 18, 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Specifications Complete model RSP-1500-48 Nominal DC output 48 V Rated current / current range 32 A / 0 to 32 A Rated output power 1536 W Maximum ripple and noise 200 mVp-p Voltage adjustment by built-in SVR 43 to 56 V Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 91% Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Ripple and noise use 20 MHz bandwidth and a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes setup tolerance, line regulation and load regulation. Input, Timing and Protection Continuous input range 90 to 264 VAC / 127 to 370 VDC; 47 to 63 Hz Active PFC, typical power factor 0.95 at 230 VAC; 0.98 at 115 VAC, full load Typical AC input current 17 A at 115 VAC; 8 A at 230 VAC Typical inrush current 30 A at 115 VAC; 60 A at 230 VAC Leakage current <2 mA at 240 VAC Setup / rise / typical hold-up time 1500 / 100 ms at full load; hold-up 16 ms at full load Overload threshold 105 to 135% of rated output power Overvoltage threshold 57.6 to 67.2 V Short-circuit and overload protection use constant-current limiting, followed by output shutdown after 5 seconds. Re-power to recover. Overvoltage protection shuts down the output and requires re-powering. Overtemperature protection shuts down the output and recovers automatically when temperature decreases. These protection thresholds are not additional continuous output ratings. The block diagram includes active inrush-current limiting and shows PFC / PWM switching frequencies of 70 / 100 kHz. Cooling, Environment and Derating Cooling Built-in DC fan, forced-air cooling Working temperature -20 to 70°C, with derating Humidity and storage Operation: 20 to 90% RH; storage: -40 to +85°C and 10 to 95% RH, non-condensing Temperature coefficient ±0.05%/°C from 0 to 50°C The 60 Hz input-derating table specifies 100–264 VAC: 1536 W / 32 A; 90 VAC: 1228.8 W / 25.6 A. In the horizontal installation shown, full-load operation extends to 50°C; the permitted load then falls along the model-specific curve to 50% at 70°C. Apply input and temperature derating together. For this fan-cooled model, reduce the allowable ambient temperature by 5°C per 1000 m above 2000 m altitude. This note does not establish an unlimited operating altitude. Vibration rating: 10 to 500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Keep the fan inlet and outlet clear. The published efficiency-versus-load graph is for the 48 V model measured at 230 VAC; it is not an efficiency curve for every voltage or input condition. Remote Sense and Voltage Programming Remote sense compensates up to 0.3 V of load-wiring drop. For remote sensing, connect CN1 pin 8 (+S) and pin 7 (-S) to the corresponding load terminals using a twisted pair. The local-sense/PV example instead connects +S to +V and -S to -V at the supply; do not additionally bridge the sense leads locally while using the remote-sense load connection. External-resistor voltage programming provides approximately 70 to 100% of nominal output. Connect a resistor rated at least 0.25 W between TRIM (pin 4) and -S (pin 3, 5 or 7) on CN1 or CN2. The typical curve indicates 0 ohm at 70%, 470 ohm at 80%, 1.8 kohm at 90% and open circuit at 100%. This resistor-control range is separate from the SVR adjustment range. Remote ON/OFF, Auxiliary Supply and Power OK Remote-control terminals are RCG (CN2 pin 1), RC2 (CN2 pin 2), and RC1 (CN3 pin 5). The external-voltage circuit uses 5 V and the illustrated 620-ohm series resistor between RC2 and RCG: open switch turns the output ON; closed switch turns it OFF. For the internal-auxiliary circuit shown in figure 3.2(B), connect RC1 to RC2 and switch RCG to AUXG: open is ON, closed is OFF. In figure 3.2(C), join RC1 to RC2, join RCG to AUXG, and place the switch between those two joined groups: closed is ON, open is OFF. Use one complete illustrated circuit; do not combine these arrangements. CN3 pin 6 (AUX) supplies 12 V at up to 0.1 A relative to pin 4 (AUXG), only for remote ON/OFF control. It is not specified as a general-purpose auxiliary load supply. Power OK uses CN3 pin 2 (P OK) and pin 1 (P OK GND). This open-collector output needs an external supply and pull-up resistor. Above 65% of rated output voltage, the signal is low (0.5 V maximum at 10 mA) to indicate OK; below 65%, it is high/open to indicate failure. Maximum sink rating is 10 mA at 50 V. Parallel Operation Use up to four compatible supplies with short, large-diameter output wiring. Adjust the difference between individual output voltages to less than 0.2 V. The maximum shared current is rated current per unit × number of units × 0.9; derating still applies. Connect the +S, -S and current-sharing signals between units as shown in the parallel diagram. The current-sharing terminal is labelled LS (pin 6 of CN1/CN2); the connection diagram also uses CS for this function. Remote-sense wires to the load are connected to the master unit only, using a twisted pair. Do not treat the family 6000 W (3+1) headline as a guaranteed usable load rating for every voltage model. Connectors and Pin Assignments CN1 and CN2 use HRS DF11-8DP-2DS headers or equivalent and are internally connected. Their pin assignments are 1 RCG, 2 RC2, 3/5/7 -S, 4 TRIM, 6 LS (current sharing), and 8 +S. The listed mating housing is HRS DF11-8DS or equivalent. CN3 uses HRS DF11-6DP-2DS or equivalent: 1 P OK GND, 2 P OK, 3 RCG, 4 AUXG, 5 RC1, and 6 AUX. Its listed mating housing is HRS DF11-6DS or equivalent. The crimp-contact reference is printed as HRS DF11-**SC or equivalent. The asterisks are an incomplete contact designation: select the exact compatible contact for the intended wire and housing before ordering. These connector references identify mating parts; they do not establish that loose housings, contacts, cables or jumpers are included. The drawings state the required connections, not a confirmed factory-installed jumper configuration. Dimensions, Weight and Installation Housing dimensions (L × W × H) 278 × 127 × 83.5 mm Catalog single-unit reference weight 3000 g Packing reference 3.0 kg; 4 pcs / 13 kg / 1.19 CUFT Drawing dimensions are in millimetres with ±0.5 mm tolerance. Housing dimensions exclude the need to allow for terminal projections, mounting flanges, wiring and the airflow shown in the complete drawing. Case No. 943A is 2U high. The drawing marks 8-M4 L=5 holes across both sides and 4-M4 L=5 on top. Recommended mounting screws are M4, maximum penetration 5 mm, with 7 to 10 kgf·cm mounting torque. The AC input terminal projection is 16 mm maximum; the output copper bars extend 38 mm. The output bar drawing marks 2-M4 and an 8.5 mm hole. AC terminal assignment: 1 FG (protective earth), 2 AC/N, 3 AC/L. Maximum AC-terminal mounting torque is 18 kgf·cm. The drawing identifies the LED and SVR. Use the complete drawing for mounting centres and terminal clearances; hole annotations are not quantities of supplied screws. Safety, EMC and Reliability UL62368-1, CAN/CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, BSMI CNS15598-1, AS/NZS62368.1 and EAC TP TC 004 are listed as approved in this datasheet. Dielectric withstand: input-to-output 3 kVAC; input-to-FG 2 kVAC; output-to-FG 0.5 kVAC. Insulation resistance is 100 MΩ at 500 VDC, 25°C and 70% RH for input/output, input/FG and output/FG. Conducted emissions: BS EN/EN55032 (CISPR32), BSMI CNS15936, Class B / Class A only for BSMI; radiated emissions: Class A. Harmonic current is listed against BS EN/EN61000-3-2 without a class in this table; voltage flicker against BS EN/EN61000-3-3. Immunity: BS EN/EN55035 and BS EN/EN61000-6-2. IEC/EN61000-4 tests list ESD Level 3 (8 kV air) / Level 2 (4 kV contact), radiated RF Level 3, EFT/burst Level 2, surge Level 3 (2 kV line-earth) / Level 2 (1 kV line-line), conducted RF Level 3, and magnetic field Level 4. Voltage-dip and interruption tests list >95% dip for 0.5 periods, 30% dip for 25 periods, and >95% interruption for 250 periods. This power supply is a component for installation in final equipment. EMC tests use a 720 × 360 mm metal plate, 1 mm thick; the completed equipment must be reconfirmed against its applicable EMC requirements. MTBF: 814.4K hours minimum by Telcordia SR-332 (Bellcore), and 90.4K hours minimum by MIL-HDBK-217F at 25°C. MTBF is a reliability calculation, not a service-life guarantee. Manufacturer-stated warranty: 5 years. Conformal coating is listed as an optional treatment for RSP-1500. It is not established as included in the unsuffixed model; confirm the selected coating arrangement when ordering.

  Read more less

  $998.04

  View options

•

  View options

  MEAN WELL RSP-1500 series: single-output enclosed AC/DC power supply with active PFC - RSP-1500-27

  MEAN WELL RSP-1500-27 is an enclosed single-output AC/DC power supply rated at 27 V DC, 56 A and 1512 W, with active PFC and a built-in DC fan. It accepts 90 to 264 VAC or 127 to 370 VDC. Apply the input, temperature and functional limits below. Product Datasheet Download MEAN WELL RSP-1500 Datasheet (PDF) The RSP-1500 section is on PDF pages 17, 18, 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Specifications Complete model RSP-1500-27 Nominal DC output 27 V Rated current / current range 56 A / 0 to 56 A Rated output power 1512 W Maximum ripple and noise 150 mVp-p Voltage adjustment by built-in SVR 24 to 30 V Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 90% Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Ripple and noise use 20 MHz bandwidth and a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes setup tolerance, line regulation and load regulation. Input, Timing and Protection Continuous input range 90 to 264 VAC / 127 to 370 VDC; 47 to 63 Hz Active PFC, typical power factor 0.95 at 230 VAC; 0.98 at 115 VAC, full load Typical AC input current 17 A at 115 VAC; 8 A at 230 VAC Typical inrush current 30 A at 115 VAC; 60 A at 230 VAC Leakage current <2 mA at 240 VAC Setup / rise / typical hold-up time 1500 / 100 ms at full load; hold-up 16 ms at full load Overload threshold 105 to 135% of rated output power Overvoltage threshold 31 to 36.5 V Short-circuit and overload protection use constant-current limiting, followed by output shutdown after 5 seconds. Re-power to recover. Overvoltage protection shuts down the output and requires re-powering. Overtemperature protection shuts down the output and recovers automatically when temperature decreases. These protection thresholds are not additional continuous output ratings. The block diagram includes active inrush-current limiting and shows PFC / PWM switching frequencies of 70 / 100 kHz. Cooling, Environment and Derating Cooling Built-in DC fan, forced-air cooling Working temperature -20 to 70°C, with derating Humidity and storage Operation: 20 to 90% RH; storage: -40 to +85°C and 10 to 95% RH, non-condensing Temperature coefficient ±0.05%/°C from 0 to 50°C The 60 Hz input-derating table specifies 100–264 VAC: 1512 W / 56 A; 90 VAC: 1209.6 W / 44.8 A. In the horizontal installation shown, full-load operation extends to 50°C; the permitted load then falls along the model-specific curve to 50% at 70°C. Apply input and temperature derating together. For this fan-cooled model, reduce the allowable ambient temperature by 5°C per 1000 m above 2000 m altitude. This note does not establish an unlimited operating altitude. Vibration rating: 10 to 500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Keep the fan inlet and outlet clear. The published efficiency-versus-load graph is for the 48 V model measured at 230 VAC; it is not an efficiency curve for every voltage or input condition. Remote Sense and Voltage Programming Remote sense compensates up to 0.3 V of load-wiring drop. For remote sensing, connect CN1 pin 8 (+S) and pin 7 (-S) to the corresponding load terminals using a twisted pair. The local-sense/PV example instead connects +S to +V and -S to -V at the supply; do not additionally bridge the sense leads locally while using the remote-sense load connection. External-resistor voltage programming provides approximately 70 to 100% of nominal output. Connect a resistor rated at least 0.25 W between TRIM (pin 4) and -S (pin 3, 5 or 7) on CN1 or CN2. The typical curve indicates 0 ohm at 70%, 470 ohm at 80%, 1.8 kohm at 90% and open circuit at 100%. This resistor-control range is separate from the SVR adjustment range. Remote ON/OFF, Auxiliary Supply and Power OK Remote-control terminals are RCG (CN2 pin 1), RC2 (CN2 pin 2), and RC1 (CN3 pin 5). The external-voltage circuit uses 5 V and the illustrated 620-ohm series resistor between RC2 and RCG: open switch turns the output ON; closed switch turns it OFF. For the internal-auxiliary circuit shown in figure 3.2(B), connect RC1 to RC2 and switch RCG to AUXG: open is ON, closed is OFF. In figure 3.2(C), join RC1 to RC2, join RCG to AUXG, and place the switch between those two joined groups: closed is ON, open is OFF. Use one complete illustrated circuit; do not combine these arrangements. CN3 pin 6 (AUX) supplies 12 V at up to 0.1 A relative to pin 4 (AUXG), only for remote ON/OFF control. It is not specified as a general-purpose auxiliary load supply. Power OK uses CN3 pin 2 (P OK) and pin 1 (P OK GND). This open-collector output needs an external supply and pull-up resistor. Above 65% of rated output voltage, the signal is low (0.5 V maximum at 10 mA) to indicate OK; below 65%, it is high/open to indicate failure. Maximum sink rating is 10 mA at 50 V. Parallel Operation Use up to four compatible supplies with short, large-diameter output wiring. Adjust the difference between individual output voltages to less than 0.2 V. The maximum shared current is rated current per unit × number of units × 0.9; derating still applies. Connect the +S, -S and current-sharing signals between units as shown in the parallel diagram. The current-sharing terminal is labelled LS (pin 6 of CN1/CN2); the connection diagram also uses CS for this function. Remote-sense wires to the load are connected to the master unit only, using a twisted pair. Do not treat the family 6000 W (3+1) headline as a guaranteed usable load rating for every voltage model. Connectors and Pin Assignments CN1 and CN2 use HRS DF11-8DP-2DS headers or equivalent and are internally connected. Their pin assignments are 1 RCG, 2 RC2, 3/5/7 -S, 4 TRIM, 6 LS (current sharing), and 8 +S. The listed mating housing is HRS DF11-8DS or equivalent. CN3 uses HRS DF11-6DP-2DS or equivalent: 1 P OK GND, 2 P OK, 3 RCG, 4 AUXG, 5 RC1, and 6 AUX. Its listed mating housing is HRS DF11-6DS or equivalent. The crimp-contact reference is printed as HRS DF11-**SC or equivalent. The asterisks are an incomplete contact designation: select the exact compatible contact for the intended wire and housing before ordering. These connector references identify mating parts; they do not establish that loose housings, contacts, cables or jumpers are included. The drawings state the required connections, not a confirmed factory-installed jumper configuration. Dimensions, Weight and Installation Housing dimensions (L × W × H) 278 × 127 × 83.5 mm Catalog single-unit reference weight 3000 g Packing reference 3.0 kg; 4 pcs / 13 kg / 1.19 CUFT Drawing dimensions are in millimetres with ±0.5 mm tolerance. Housing dimensions exclude the need to allow for terminal projections, mounting flanges, wiring and the airflow shown in the complete drawing. Case No. 943A is 2U high. The drawing marks 8-M4 L=5 holes across both sides and 4-M4 L=5 on top. Recommended mounting screws are M4, maximum penetration 5 mm, with 7 to 10 kgf·cm mounting torque. The AC input terminal projection is 16 mm maximum; the output copper bars extend 38 mm. The output bar drawing marks 2-M4 and an 8.5 mm hole. AC terminal assignment: 1 FG (protective earth), 2 AC/N, 3 AC/L. Maximum AC-terminal mounting torque is 18 kgf·cm. The drawing identifies the LED and SVR. Use the complete drawing for mounting centres and terminal clearances; hole annotations are not quantities of supplied screws. Safety, EMC and Reliability UL62368-1, CAN/CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, BSMI CNS15598-1, AS/NZS62368.1 and EAC TP TC 004 are listed as approved in this datasheet. Dielectric withstand: input-to-output 3 kVAC; input-to-FG 2 kVAC; output-to-FG 0.5 kVAC. Insulation resistance is 100 MΩ at 500 VDC, 25°C and 70% RH for input/output, input/FG and output/FG. Conducted emissions: BS EN/EN55032 (CISPR32), BSMI CNS15936, Class B / Class A only for BSMI; radiated emissions: Class A. Harmonic current is listed against BS EN/EN61000-3-2 without a class in this table; voltage flicker against BS EN/EN61000-3-3. Immunity: BS EN/EN55035 and BS EN/EN61000-6-2. IEC/EN61000-4 tests list ESD Level 3 (8 kV air) / Level 2 (4 kV contact), radiated RF Level 3, EFT/burst Level 2, surge Level 3 (2 kV line-earth) / Level 2 (1 kV line-line), conducted RF Level 3, and magnetic field Level 4. Voltage-dip and interruption tests list >95% dip for 0.5 periods, 30% dip for 25 periods, and >95% interruption for 250 periods. This power supply is a component for installation in final equipment. EMC tests use a 720 × 360 mm metal plate, 1 mm thick; the completed equipment must be reconfirmed against its applicable EMC requirements. MTBF: 814.4K hours minimum by Telcordia SR-332 (Bellcore), and 90.4K hours minimum by MIL-HDBK-217F at 25°C. MTBF is a reliability calculation, not a service-life guarantee. Manufacturer-stated warranty: 5 years. Conformal coating is listed as an optional treatment for RSP-1500. It is not established as included in the unsuffixed model; confirm the selected coating arrangement when ordering.

  Read more less

  $998.04

  View options

•

  View options

  MEAN WELL RSP-1500 series: single-output enclosed AC/DC power supply with active PFC - RSP-1500-24

  MEAN WELL RSP-1500-24 is an enclosed single-output AC/DC power supply rated at 24 V DC, 63 A and 1512 W, with active PFC and a built-in DC fan. It accepts 90 to 264 VAC or 127 to 370 VDC. Apply the input, temperature and functional limits below. Product Datasheet Download MEAN WELL RSP-1500 Datasheet (PDF) The RSP-1500 section is on PDF pages 17, 18, 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Specifications Complete model RSP-1500-24 Nominal DC output 24 V Rated current / current range 63 A / 0 to 63 A Rated output power 1512 W Maximum ripple and noise 150 mVp-p Voltage adjustment by built-in SVR 20 to 26.4 V Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 90% Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Ripple and noise use 20 MHz bandwidth and a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes setup tolerance, line regulation and load regulation. Input, Timing and Protection Continuous input range 90 to 264 VAC / 127 to 370 VDC; 47 to 63 Hz Active PFC, typical power factor 0.95 at 230 VAC; 0.98 at 115 VAC, full load Typical AC input current 17 A at 115 VAC; 8 A at 230 VAC Typical inrush current 30 A at 115 VAC; 60 A at 230 VAC Leakage current <2 mA at 240 VAC Setup / rise / typical hold-up time 1500 / 100 ms at full load; hold-up 14 ms at full load Overload threshold 105 to 135% of rated output power Overvoltage threshold 27.6 to 32.4 V Short-circuit and overload protection use constant-current limiting, followed by output shutdown after 5 seconds. Re-power to recover. Overvoltage protection shuts down the output and requires re-powering. Overtemperature protection shuts down the output and recovers automatically when temperature decreases. These protection thresholds are not additional continuous output ratings. The block diagram includes active inrush-current limiting and shows PFC / PWM switching frequencies of 70 / 100 kHz. Cooling, Environment and Derating Cooling Built-in DC fan, forced-air cooling Working temperature -20 to 70°C, with derating Humidity and storage Operation: 20 to 90% RH; storage: -40 to +85°C and 10 to 95% RH, non-condensing Temperature coefficient ±0.05%/°C from 0 to 50°C The 60 Hz input-derating table specifies 100–264 VAC: 1512 W / 63 A; 90 VAC: 1209.6 W / 50.4 A. In the horizontal installation shown, full-load operation extends to 50°C; the permitted load then falls along the model-specific curve to 50% at 70°C. Apply input and temperature derating together. For this fan-cooled model, reduce the allowable ambient temperature by 5°C per 1000 m above 2000 m altitude. This note does not establish an unlimited operating altitude. Vibration rating: 10 to 500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Keep the fan inlet and outlet clear. The published efficiency-versus-load graph is for the 48 V model measured at 230 VAC; it is not an efficiency curve for every voltage or input condition. Remote Sense and Voltage Programming Remote sense compensates up to 0.3 V of load-wiring drop. For remote sensing, connect CN1 pin 8 (+S) and pin 7 (-S) to the corresponding load terminals using a twisted pair. The local-sense/PV example instead connects +S to +V and -S to -V at the supply; do not additionally bridge the sense leads locally while using the remote-sense load connection. External-resistor voltage programming provides approximately 70 to 100% of nominal output. Connect a resistor rated at least 0.25 W between TRIM (pin 4) and -S (pin 3, 5 or 7) on CN1 or CN2. The typical curve indicates 0 ohm at 70%, 470 ohm at 80%, 1.8 kohm at 90% and open circuit at 100%. This resistor-control range is separate from the SVR adjustment range. Remote ON/OFF, Auxiliary Supply and Power OK Remote-control terminals are RCG (CN2 pin 1), RC2 (CN2 pin 2), and RC1 (CN3 pin 5). The external-voltage circuit uses 5 V and the illustrated 620-ohm series resistor between RC2 and RCG: open switch turns the output ON; closed switch turns it OFF. For the internal-auxiliary circuit shown in figure 3.2(B), connect RC1 to RC2 and switch RCG to AUXG: open is ON, closed is OFF. In figure 3.2(C), join RC1 to RC2, join RCG to AUXG, and place the switch between those two joined groups: closed is ON, open is OFF. Use one complete illustrated circuit; do not combine these arrangements. CN3 pin 6 (AUX) supplies 12 V at up to 0.1 A relative to pin 4 (AUXG), only for remote ON/OFF control. It is not specified as a general-purpose auxiliary load supply. Power OK uses CN3 pin 2 (P OK) and pin 1 (P OK GND). This open-collector output needs an external supply and pull-up resistor. Above 65% of rated output voltage, the signal is low (0.5 V maximum at 10 mA) to indicate OK; below 65%, it is high/open to indicate failure. Maximum sink rating is 10 mA at 50 V. Parallel Operation Use up to four compatible supplies with short, large-diameter output wiring. Adjust the difference between individual output voltages to less than 0.2 V. The maximum shared current is rated current per unit × number of units × 0.9; derating still applies. Connect the +S, -S and current-sharing signals between units as shown in the parallel diagram. The current-sharing terminal is labelled LS (pin 6 of CN1/CN2); the connection diagram also uses CS for this function. Remote-sense wires to the load are connected to the master unit only, using a twisted pair. Do not treat the family 6000 W (3+1) headline as a guaranteed usable load rating for every voltage model. Connectors and Pin Assignments CN1 and CN2 use HRS DF11-8DP-2DS headers or equivalent and are internally connected. Their pin assignments are 1 RCG, 2 RC2, 3/5/7 -S, 4 TRIM, 6 LS (current sharing), and 8 +S. The listed mating housing is HRS DF11-8DS or equivalent. CN3 uses HRS DF11-6DP-2DS or equivalent: 1 P OK GND, 2 P OK, 3 RCG, 4 AUXG, 5 RC1, and 6 AUX. Its listed mating housing is HRS DF11-6DS or equivalent. The crimp-contact reference is printed as HRS DF11-**SC or equivalent. The asterisks are an incomplete contact designation: select the exact compatible contact for the intended wire and housing before ordering. These connector references identify mating parts; they do not establish that loose housings, contacts, cables or jumpers are included. The drawings state the required connections, not a confirmed factory-installed jumper configuration. Dimensions, Weight and Installation Housing dimensions (L × W × H) 278 × 127 × 83.5 mm Catalog single-unit reference weight 3000 g Packing reference 3.0 kg; 4 pcs / 13 kg / 1.19 CUFT Drawing dimensions are in millimetres with ±0.5 mm tolerance. Housing dimensions exclude the need to allow for terminal projections, mounting flanges, wiring and the airflow shown in the complete drawing. Case No. 943A is 2U high. The drawing marks 8-M4 L=5 holes across both sides and 4-M4 L=5 on top. Recommended mounting screws are M4, maximum penetration 5 mm, with 7 to 10 kgf·cm mounting torque. The AC input terminal projection is 16 mm maximum; the output copper bars extend 38 mm. The output bar drawing marks 2-M4 and an 8.5 mm hole. AC terminal assignment: 1 FG (protective earth), 2 AC/N, 3 AC/L. Maximum AC-terminal mounting torque is 18 kgf·cm. The drawing identifies the LED and SVR. Use the complete drawing for mounting centres and terminal clearances; hole annotations are not quantities of supplied screws. Safety, EMC and Reliability UL62368-1, CAN/CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, BSMI CNS15598-1, AS/NZS62368.1 and EAC TP TC 004 are listed as approved in this datasheet. Dielectric withstand: input-to-output 3 kVAC; input-to-FG 2 kVAC; output-to-FG 0.5 kVAC. Insulation resistance is 100 MΩ at 500 VDC, 25°C and 70% RH for input/output, input/FG and output/FG. Conducted emissions: BS EN/EN55032 (CISPR32), BSMI CNS15936, Class B / Class A only for BSMI; radiated emissions: Class A. Harmonic current is listed against BS EN/EN61000-3-2 without a class in this table; voltage flicker against BS EN/EN61000-3-3. Immunity: BS EN/EN55035 and BS EN/EN61000-6-2. IEC/EN61000-4 tests list ESD Level 3 (8 kV air) / Level 2 (4 kV contact), radiated RF Level 3, EFT/burst Level 2, surge Level 3 (2 kV line-earth) / Level 2 (1 kV line-line), conducted RF Level 3, and magnetic field Level 4. Voltage-dip and interruption tests list >95% dip for 0.5 periods, 30% dip for 25 periods, and >95% interruption for 250 periods. This power supply is a component for installation in final equipment. EMC tests use a 720 × 360 mm metal plate, 1 mm thick; the completed equipment must be reconfirmed against its applicable EMC requirements. MTBF: 814.4K hours minimum by Telcordia SR-332 (Bellcore), and 90.4K hours minimum by MIL-HDBK-217F at 25°C. MTBF is a reliability calculation, not a service-life guarantee. Manufacturer-stated warranty: 5 years. Conformal coating is listed as an optional treatment for RSP-1500. It is not established as included in the unsuffixed model; confirm the selected coating arrangement when ordering.

  Read more less

  $998.04

  View options

•

  View options

  MEAN WELL RSP-1500 series: single-output enclosed AC/DC power supply with active PFC - RSP-1500-15

  MEAN WELL RSP-1500-15 is an enclosed single-output AC/DC power supply rated at 15 V DC, 100 A and 1500 W, with active PFC and a built-in DC fan. It accepts 90 to 264 VAC or 127 to 370 VDC. Apply the input, temperature and functional limits below. Product Datasheet Download MEAN WELL RSP-1500 Datasheet (PDF) The RSP-1500 section is on PDF pages 17, 18, 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Specifications Complete model RSP-1500-15 Nominal DC output 15 V Rated current / current range 100 A / 0 to 100 A Rated output power 1500 W Maximum ripple and noise 150 mVp-p Voltage adjustment by built-in SVR 13.5 to 16.5 V Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 87% Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Ripple and noise use 20 MHz bandwidth and a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes setup tolerance, line regulation and load regulation. Input, Timing and Protection Continuous input range 90 to 264 VAC / 127 to 370 VDC; 47 to 63 Hz Active PFC, typical power factor 0.95 at 230 VAC; 0.98 at 115 VAC, full load Typical AC input current 17 A at 115 VAC; 8 A at 230 VAC Typical inrush current 30 A at 115 VAC; 60 A at 230 VAC Leakage current <2 mA at 240 VAC Setup / rise / typical hold-up time 1500 / 100 ms at full load; hold-up 14 ms at full load Overload threshold 105 to 135% of rated output power Overvoltage threshold 17 to 20.5 V Short-circuit and overload protection use constant-current limiting, followed by output shutdown after 5 seconds. Re-power to recover. Overvoltage protection shuts down the output and requires re-powering. Overtemperature protection shuts down the output and recovers automatically when temperature decreases. These protection thresholds are not additional continuous output ratings. The block diagram includes active inrush-current limiting and shows PFC / PWM switching frequencies of 70 / 100 kHz. Cooling, Environment and Derating Cooling Built-in DC fan, forced-air cooling Working temperature -20 to 70°C, with derating Humidity and storage Operation: 20 to 90% RH; storage: -40 to +85°C and 10 to 95% RH, non-condensing Temperature coefficient ±0.05%/°C from 0 to 50°C The 60 Hz input-derating table specifies 100–264 VAC: 1500 W / 100 A; 90 VAC: 1200 W / 80 A. In the horizontal installation shown, full-load operation extends to 45°C; the permitted load then falls along the model-specific curve to 50% at 70°C. Apply input and temperature derating together. For this fan-cooled model, reduce the allowable ambient temperature by 5°C per 1000 m above 2000 m altitude. This note does not establish an unlimited operating altitude. Vibration rating: 10 to 500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Keep the fan inlet and outlet clear. The published efficiency-versus-load graph is for the 48 V model measured at 230 VAC; it is not an efficiency curve for every voltage or input condition. Remote Sense and Voltage Programming Remote sense compensates up to 0.3 V of load-wiring drop. For remote sensing, connect CN1 pin 8 (+S) and pin 7 (-S) to the corresponding load terminals using a twisted pair. The local-sense/PV example instead connects +S to +V and -S to -V at the supply; do not additionally bridge the sense leads locally while using the remote-sense load connection. External-resistor voltage programming provides approximately 70 to 100% of nominal output. Connect a resistor rated at least 0.25 W between TRIM (pin 4) and -S (pin 3, 5 or 7) on CN1 or CN2. The typical curve indicates 0 ohm at 70%, 470 ohm at 80%, 1.8 kohm at 90% and open circuit at 100%. This resistor-control range is separate from the SVR adjustment range. Remote ON/OFF, Auxiliary Supply and Power OK Remote-control terminals are RCG (CN2 pin 1), RC2 (CN2 pin 2), and RC1 (CN3 pin 5). The external-voltage circuit uses 5 V and the illustrated 620-ohm series resistor between RC2 and RCG: open switch turns the output ON; closed switch turns it OFF. For the internal-auxiliary circuit shown in figure 3.2(B), connect RC1 to RC2 and switch RCG to AUXG: open is ON, closed is OFF. In figure 3.2(C), join RC1 to RC2, join RCG to AUXG, and place the switch between those two joined groups: closed is ON, open is OFF. Use one complete illustrated circuit; do not combine these arrangements. CN3 pin 6 (AUX) supplies 12 V at up to 0.1 A relative to pin 4 (AUXG), only for remote ON/OFF control. It is not specified as a general-purpose auxiliary load supply. Power OK uses CN3 pin 2 (P OK) and pin 1 (P OK GND). This open-collector output needs an external supply and pull-up resistor. Above 65% of rated output voltage, the signal is low (0.5 V maximum at 10 mA) to indicate OK; below 65%, it is high/open to indicate failure. Maximum sink rating is 10 mA at 50 V. Parallel Operation Use up to four compatible supplies with short, large-diameter output wiring. Adjust the difference between individual output voltages to less than 0.2 V. The maximum shared current is rated current per unit × number of units × 0.9; derating still applies. Connect the +S, -S and current-sharing signals between units as shown in the parallel diagram. The current-sharing terminal is labelled LS (pin 6 of CN1/CN2); the connection diagram also uses CS for this function. Remote-sense wires to the load are connected to the master unit only, using a twisted pair. Do not treat the family 6000 W (3+1) headline as a guaranteed usable load rating for every voltage model. Connectors and Pin Assignments CN1 and CN2 use HRS DF11-8DP-2DS headers or equivalent and are internally connected. Their pin assignments are 1 RCG, 2 RC2, 3/5/7 -S, 4 TRIM, 6 LS (current sharing), and 8 +S. The listed mating housing is HRS DF11-8DS or equivalent. CN3 uses HRS DF11-6DP-2DS or equivalent: 1 P OK GND, 2 P OK, 3 RCG, 4 AUXG, 5 RC1, and 6 AUX. Its listed mating housing is HRS DF11-6DS or equivalent. The crimp-contact reference is printed as HRS DF11-**SC or equivalent. The asterisks are an incomplete contact designation: select the exact compatible contact for the intended wire and housing before ordering. These connector references identify mating parts; they do not establish that loose housings, contacts, cables or jumpers are included. The drawings state the required connections, not a confirmed factory-installed jumper configuration. Dimensions, Weight and Installation Housing dimensions (L × W × H) 278 × 127 × 83.5 mm Catalog single-unit reference weight 3000 g Packing reference 3.0 kg; 4 pcs / 13 kg / 1.19 CUFT Drawing dimensions are in millimetres with ±0.5 mm tolerance. Housing dimensions exclude the need to allow for terminal projections, mounting flanges, wiring and the airflow shown in the complete drawing. Case No. 943A is 2U high. The drawing marks 8-M4 L=5 holes across both sides and 4-M4 L=5 on top. Recommended mounting screws are M4, maximum penetration 5 mm, with 7 to 10 kgf·cm mounting torque. The AC input terminal projection is 16 mm maximum; the output copper bars extend 38 mm. The output bar drawing marks 2-M4 and an 8.5 mm hole. AC terminal assignment: 1 FG (protective earth), 2 AC/N, 3 AC/L. Maximum AC-terminal mounting torque is 18 kgf·cm. The drawing identifies the LED and SVR. Use the complete drawing for mounting centres and terminal clearances; hole annotations are not quantities of supplied screws. Safety, EMC and Reliability UL62368-1, CAN/CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, BSMI CNS15598-1, AS/NZS62368.1 and EAC TP TC 004 are listed as approved in this datasheet. Dielectric withstand: input-to-output 3 kVAC; input-to-FG 2 kVAC; output-to-FG 0.5 kVAC. Insulation resistance is 100 MΩ at 500 VDC, 25°C and 70% RH for input/output, input/FG and output/FG. Conducted emissions: BS EN/EN55032 (CISPR32), BSMI CNS15936, Class B / Class A only for BSMI; radiated emissions: Class A. Harmonic current is listed against BS EN/EN61000-3-2 without a class in this table; voltage flicker against BS EN/EN61000-3-3. Immunity: BS EN/EN55035 and BS EN/EN61000-6-2. IEC/EN61000-4 tests list ESD Level 3 (8 kV air) / Level 2 (4 kV contact), radiated RF Level 3, EFT/burst Level 2, surge Level 3 (2 kV line-earth) / Level 2 (1 kV line-line), conducted RF Level 3, and magnetic field Level 4. Voltage-dip and interruption tests list >95% dip for 0.5 periods, 30% dip for 25 periods, and >95% interruption for 250 periods. This power supply is a component for installation in final equipment. EMC tests use a 720 × 360 mm metal plate, 1 mm thick; the completed equipment must be reconfirmed against its applicable EMC requirements. MTBF: 814.4K hours minimum by Telcordia SR-332 (Bellcore), and 90.4K hours minimum by MIL-HDBK-217F at 25°C. MTBF is a reliability calculation, not a service-life guarantee. Manufacturer-stated warranty: 5 years. Conformal coating is listed as an optional treatment for RSP-1500. It is not established as included in the unsuffixed model; confirm the selected coating arrangement when ordering.

  Read more less

  $998.04

  View options

•

  View options

  MEAN WELL RSP-1500 series: single-output enclosed AC/DC power supply with active PFC - RSP-1500-12

  MEAN WELL RSP-1500-12 is an enclosed single-output AC/DC power supply rated at 12 V DC, 125 A and 1500 W, with active PFC and a built-in DC fan. It accepts 90 to 264 VAC or 127 to 370 VDC. Apply the input, temperature and functional limits below. Product Datasheet Download MEAN WELL RSP-1500 Datasheet (PDF) The RSP-1500 section is on PDF pages 17, 18, 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Specifications Complete model RSP-1500-12 Nominal DC output 12 V Rated current / current range 125 A / 0 to 125 A Rated output power 1500 W Maximum ripple and noise 150 mVp-p Voltage adjustment by built-in SVR 10 to 13.5 V Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 87% Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Ripple and noise use 20 MHz bandwidth and a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes setup tolerance, line regulation and load regulation. Input, Timing and Protection Continuous input range 90 to 264 VAC / 127 to 370 VDC; 47 to 63 Hz Active PFC, typical power factor 0.95 at 230 VAC; 0.98 at 115 VAC, full load Typical AC input current 17 A at 115 VAC; 8 A at 230 VAC Typical inrush current 30 A at 115 VAC; 60 A at 230 VAC Leakage current <2 mA at 240 VAC Setup / rise / typical hold-up time 1500 / 100 ms at full load; hold-up 10 ms at full load Overload threshold 105 to 135% of rated output power Overvoltage threshold 13.8 to 16.8 V Short-circuit and overload protection use constant-current limiting, followed by output shutdown after 5 seconds. Re-power to recover. Overvoltage protection shuts down the output and requires re-powering. Overtemperature protection shuts down the output and recovers automatically when temperature decreases. These protection thresholds are not additional continuous output ratings. The block diagram includes active inrush-current limiting and shows PFC / PWM switching frequencies of 70 / 100 kHz. Cooling, Environment and Derating Cooling Built-in DC fan, forced-air cooling Working temperature -20 to 70°C, with derating Humidity and storage Operation: 20 to 90% RH; storage: -40 to +85°C and 10 to 95% RH, non-condensing Temperature coefficient ±0.05%/°C from 0 to 50°C The 60 Hz input-derating table specifies 100–264 VAC: 1500 W / 125 A; 90 VAC: 1200 W / 100 A. In the horizontal installation shown, full-load operation extends to 45°C; the permitted load then falls along the model-specific curve to 50% at 70°C. Apply input and temperature derating together. For this fan-cooled model, reduce the allowable ambient temperature by 5°C per 1000 m above 2000 m altitude. This note does not establish an unlimited operating altitude. Vibration rating: 10 to 500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Keep the fan inlet and outlet clear. The published efficiency-versus-load graph is for the 48 V model measured at 230 VAC; it is not an efficiency curve for every voltage or input condition. Remote Sense and Voltage Programming Remote sense compensates up to 0.3 V of load-wiring drop. For remote sensing, connect CN1 pin 8 (+S) and pin 7 (-S) to the corresponding load terminals using a twisted pair. The local-sense/PV example instead connects +S to +V and -S to -V at the supply; do not additionally bridge the sense leads locally while using the remote-sense load connection. External-resistor voltage programming provides approximately 70 to 100% of nominal output. Connect a resistor rated at least 0.25 W between TRIM (pin 4) and -S (pin 3, 5 or 7) on CN1 or CN2. The typical curve indicates 0 ohm at 70%, 470 ohm at 80%, 1.8 kohm at 90% and open circuit at 100%. This resistor-control range is separate from the SVR adjustment range. Remote ON/OFF, Auxiliary Supply and Power OK Remote-control terminals are RCG (CN2 pin 1), RC2 (CN2 pin 2), and RC1 (CN3 pin 5). The external-voltage circuit uses 5 V and the illustrated 620-ohm series resistor between RC2 and RCG: open switch turns the output ON; closed switch turns it OFF. For the internal-auxiliary circuit shown in figure 3.2(B), connect RC1 to RC2 and switch RCG to AUXG: open is ON, closed is OFF. In figure 3.2(C), join RC1 to RC2, join RCG to AUXG, and place the switch between those two joined groups: closed is ON, open is OFF. Use one complete illustrated circuit; do not combine these arrangements. CN3 pin 6 (AUX) supplies 12 V at up to 0.1 A relative to pin 4 (AUXG), only for remote ON/OFF control. It is not specified as a general-purpose auxiliary load supply. Power OK uses CN3 pin 2 (P OK) and pin 1 (P OK GND). This open-collector output needs an external supply and pull-up resistor. Above 65% of rated output voltage, the signal is low (0.5 V maximum at 10 mA) to indicate OK; below 65%, it is high/open to indicate failure. Maximum sink rating is 10 mA at 50 V. Parallel Operation Use up to four compatible supplies with short, large-diameter output wiring. Adjust the difference between individual output voltages to less than 0.2 V. The maximum shared current is rated current per unit × number of units × 0.9; derating still applies. Connect the +S, -S and current-sharing signals between units as shown in the parallel diagram. The current-sharing terminal is labelled LS (pin 6 of CN1/CN2); the connection diagram also uses CS for this function. Remote-sense wires to the load are connected to the master unit only, using a twisted pair. Do not treat the family 6000 W (3+1) headline as a guaranteed usable load rating for every voltage model. Connectors and Pin Assignments CN1 and CN2 use HRS DF11-8DP-2DS headers or equivalent and are internally connected. Their pin assignments are 1 RCG, 2 RC2, 3/5/7 -S, 4 TRIM, 6 LS (current sharing), and 8 +S. The listed mating housing is HRS DF11-8DS or equivalent. CN3 uses HRS DF11-6DP-2DS or equivalent: 1 P OK GND, 2 P OK, 3 RCG, 4 AUXG, 5 RC1, and 6 AUX. Its listed mating housing is HRS DF11-6DS or equivalent. The crimp-contact reference is printed as HRS DF11-**SC or equivalent. The asterisks are an incomplete contact designation: select the exact compatible contact for the intended wire and housing before ordering. These connector references identify mating parts; they do not establish that loose housings, contacts, cables or jumpers are included. The drawings state the required connections, not a confirmed factory-installed jumper configuration. Dimensions, Weight and Installation Housing dimensions (L × W × H) 278 × 127 × 83.5 mm Catalog single-unit reference weight 3000 g Packing reference 3.0 kg; 4 pcs / 13 kg / 1.19 CUFT Drawing dimensions are in millimetres with ±0.5 mm tolerance. Housing dimensions exclude the need to allow for terminal projections, mounting flanges, wiring and the airflow shown in the complete drawing. Case No. 943A is 2U high. The drawing marks 8-M4 L=5 holes across both sides and 4-M4 L=5 on top. Recommended mounting screws are M4, maximum penetration 5 mm, with 7 to 10 kgf·cm mounting torque. The AC input terminal projection is 16 mm maximum; the output copper bars extend 38 mm. The output bar drawing marks 2-M4 and an 8.5 mm hole. AC terminal assignment: 1 FG (protective earth), 2 AC/N, 3 AC/L. Maximum AC-terminal mounting torque is 18 kgf·cm. The drawing identifies the LED and SVR. Use the complete drawing for mounting centres and terminal clearances; hole annotations are not quantities of supplied screws. Safety, EMC and Reliability UL62368-1, CAN/CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, BSMI CNS15598-1, AS/NZS62368.1 and EAC TP TC 004 are listed as approved in this datasheet. Dielectric withstand: input-to-output 3 kVAC; input-to-FG 2 kVAC; output-to-FG 0.5 kVAC. Insulation resistance is 100 MΩ at 500 VDC, 25°C and 70% RH for input/output, input/FG and output/FG. Conducted emissions: BS EN/EN55032 (CISPR32), BSMI CNS15936, Class B / Class A only for BSMI; radiated emissions: Class A. Harmonic current is listed against BS EN/EN61000-3-2 without a class in this table; voltage flicker against BS EN/EN61000-3-3. Immunity: BS EN/EN55035 and BS EN/EN61000-6-2. IEC/EN61000-4 tests list ESD Level 3 (8 kV air) / Level 2 (4 kV contact), radiated RF Level 3, EFT/burst Level 2, surge Level 3 (2 kV line-earth) / Level 2 (1 kV line-line), conducted RF Level 3, and magnetic field Level 4. Voltage-dip and interruption tests list >95% dip for 0.5 periods, 30% dip for 25 periods, and >95% interruption for 250 periods. This power supply is a component for installation in final equipment. EMC tests use a 720 × 360 mm metal plate, 1 mm thick; the completed equipment must be reconfirmed against its applicable EMC requirements. MTBF: 814.4K hours minimum by Telcordia SR-332 (Bellcore), and 90.4K hours minimum by MIL-HDBK-217F at 25°C. MTBF is a reliability calculation, not a service-life guarantee. Manufacturer-stated warranty: 5 years. Conformal coating is listed as an optional treatment for RSP-1500. It is not established as included in the unsuffixed model; confirm the selected coating arrangement when ordering.

  Read more less

  $998.04

  View options

•

  View options

  MEAN WELL RSP-1500 series: single-output enclosed AC/DC power supply with active PFC - RSP-1500-5

  MEAN WELL RSP-1500-5 is an enclosed single-output AC/DC power supply rated at 5 V DC, 240 A and 1200 W, with active PFC and a built-in DC fan. It accepts 90 to 264 VAC or 127 to 370 VDC. Apply the input, temperature and functional limits below. Product Datasheet Download MEAN WELL RSP-1500 Datasheet (PDF) The RSP-1500 section is on PDF pages 17, 18, 19, 20, 21, 22, 23, 24, 25. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Specifications Complete model RSP-1500-5 Nominal DC output 5 V Rated current / current range 240 A / 0 to 240 A Rated output power 1200 W Maximum ripple and noise 150 mVp-p Voltage adjustment by built-in SVR 4.5 to 5.5 V Voltage tolerance / line / load regulation ±2.0% / ±0.5% / ±2.0% Typical efficiency 80% Unless otherwise specified, parameters are measured at 230 VAC input, rated load and 25°C ambient. Ripple and noise use 20 MHz bandwidth and a 12-inch twisted pair terminated with 0.1 µF and 47 µF capacitors in parallel. Voltage tolerance includes setup tolerance, line regulation and load regulation. Input, Timing and Protection Continuous input range 90 to 264 VAC / 127 to 370 VDC; 47 to 63 Hz Active PFC, typical power factor 0.95 at 230 VAC; 0.98 at 115 VAC, full load Typical AC input current 17 A at 115 VAC; 8 A at 230 VAC Typical inrush current 30 A at 115 VAC; 60 A at 230 VAC Leakage current <2 mA at 240 VAC Setup / rise / typical hold-up time 1500 / 100 ms at full load; hold-up 10 ms at full load Overload threshold 105 to 135% of rated output power Overvoltage threshold 5.75 to 6.75 V Short-circuit and overload protection use constant-current limiting, followed by output shutdown after 5 seconds. Re-power to recover. Overvoltage protection shuts down the output and requires re-powering. Overtemperature protection shuts down the output and recovers automatically when temperature decreases. These protection thresholds are not additional continuous output ratings. The block diagram includes active inrush-current limiting and shows PFC / PWM switching frequencies of 70 / 100 kHz. Cooling, Environment and Derating Cooling Built-in DC fan, forced-air cooling Working temperature -20 to 70°C, with derating Humidity and storage Operation: 20 to 90% RH; storage: -40 to +85°C and 10 to 95% RH, non-condensing Temperature coefficient ±0.05%/°C from 0 to 50°C The 60 Hz input-derating table specifies 100–264 VAC: 1200 W / 240 A; 90 VAC: 960 W / 192 A. In the horizontal installation shown, full-load operation extends to 40°C; the permitted load then falls along the model-specific curve to 50% at 70°C. Apply input and temperature derating together. For this fan-cooled model, reduce the allowable ambient temperature by 5°C per 1000 m above 2000 m altitude. This note does not establish an unlimited operating altitude. Vibration rating: 10 to 500 Hz, 2 G; 10 minutes per cycle, 60 minutes along each X, Y and Z axis. Keep the fan inlet and outlet clear. The published efficiency-versus-load graph is for the 48 V model measured at 230 VAC; it is not an efficiency curve for every voltage or input condition. Remote Sense and Voltage Programming Remote sense compensates up to 0.3 V of load-wiring drop. For remote sensing, connect CN1 pin 8 (+S) and pin 7 (-S) to the corresponding load terminals using a twisted pair. The local-sense/PV example instead connects +S to +V and -S to -V at the supply; do not additionally bridge the sense leads locally while using the remote-sense load connection. External-resistor voltage programming provides approximately 70 to 100% of nominal output. Connect a resistor rated at least 0.25 W between TRIM (pin 4) and -S (pin 3, 5 or 7) on CN1 or CN2. The typical curve indicates 0 ohm at 70%, 470 ohm at 80%, 1.8 kohm at 90% and open circuit at 100%. This resistor-control range is separate from the SVR adjustment range. Remote ON/OFF, Auxiliary Supply and Power OK Remote-control terminals are RCG (CN2 pin 1), RC2 (CN2 pin 2), and RC1 (CN3 pin 5). The external-voltage circuit uses 5 V and the illustrated 620-ohm series resistor between RC2 and RCG: open switch turns the output ON; closed switch turns it OFF. For the internal-auxiliary circuit shown in figure 3.2(B), connect RC1 to RC2 and switch RCG to AUXG: open is ON, closed is OFF. In figure 3.2(C), join RC1 to RC2, join RCG to AUXG, and place the switch between those two joined groups: closed is ON, open is OFF. Use one complete illustrated circuit; do not combine these arrangements. CN3 pin 6 (AUX) supplies 12 V at up to 0.1 A relative to pin 4 (AUXG), only for remote ON/OFF control. It is not specified as a general-purpose auxiliary load supply. Power OK uses CN3 pin 2 (P OK) and pin 1 (P OK GND). This open-collector output needs an external supply and pull-up resistor. Above 65% of rated output voltage, the signal is low (0.5 V maximum at 10 mA) to indicate OK; below 65%, it is high/open to indicate failure. Maximum sink rating is 10 mA at 50 V. Parallel Operation Use up to four compatible supplies with short, large-diameter output wiring. Adjust the difference between individual output voltages to less than 0.2 V. The maximum shared current is rated current per unit × number of units × 0.9; derating still applies. Connect the +S, -S and current-sharing signals between units as shown in the parallel diagram. The current-sharing terminal is labelled LS (pin 6 of CN1/CN2); the connection diagram also uses CS for this function. Remote-sense wires to the load are connected to the master unit only, using a twisted pair. Do not treat the family 6000 W (3+1) headline as a guaranteed usable load rating for every voltage model. Connectors and Pin Assignments CN1 and CN2 use HRS DF11-8DP-2DS headers or equivalent and are internally connected. Their pin assignments are 1 RCG, 2 RC2, 3/5/7 -S, 4 TRIM, 6 LS (current sharing), and 8 +S. The listed mating housing is HRS DF11-8DS or equivalent. CN3 uses HRS DF11-6DP-2DS or equivalent: 1 P OK GND, 2 P OK, 3 RCG, 4 AUXG, 5 RC1, and 6 AUX. Its listed mating housing is HRS DF11-6DS or equivalent. The crimp-contact reference is printed as HRS DF11-**SC or equivalent. The asterisks are an incomplete contact designation: select the exact compatible contact for the intended wire and housing before ordering. These connector references identify mating parts; they do not establish that loose housings, contacts, cables or jumpers are included. The drawings state the required connections, not a confirmed factory-installed jumper configuration. Dimensions, Weight and Installation Housing dimensions (L × W × H) 278 × 127 × 83.5 mm Catalog single-unit reference weight 3000 g Packing reference 3.0 kg; 4 pcs / 13 kg / 1.19 CUFT Drawing dimensions are in millimetres with ±0.5 mm tolerance. Housing dimensions exclude the need to allow for terminal projections, mounting flanges, wiring and the airflow shown in the complete drawing. Case No. 943A is 2U high. The drawing marks 8-M4 L=5 holes across both sides and 4-M4 L=5 on top. Recommended mounting screws are M4, maximum penetration 5 mm, with 7 to 10 kgf·cm mounting torque. The AC input terminal projection is 16 mm maximum; the output copper bars extend 38 mm. The output bar drawing marks 2-M4 and an 8.5 mm hole. AC terminal assignment: 1 FG (protective earth), 2 AC/N, 3 AC/L. Maximum AC-terminal mounting torque is 18 kgf·cm. The drawing identifies the LED and SVR. Use the complete drawing for mounting centres and terminal clearances; hole annotations are not quantities of supplied screws. Safety, EMC and Reliability UL62368-1, CAN/CSA C22.2 No. 62368-1, TUV BS EN/EN62368-1, BSMI CNS15598-1, AS/NZS62368.1 and EAC TP TC 004 are listed as approved in this datasheet. Dielectric withstand: input-to-output 3 kVAC; input-to-FG 2 kVAC; output-to-FG 0.5 kVAC. Insulation resistance is 100 MΩ at 500 VDC, 25°C and 70% RH for input/output, input/FG and output/FG. Conducted emissions: BS EN/EN55032 (CISPR32), BSMI CNS15936, Class B / Class A only for BSMI; radiated emissions: Class A. Harmonic current is listed against BS EN/EN61000-3-2 without a class in this table; voltage flicker against BS EN/EN61000-3-3. Immunity: BS EN/EN55035 and BS EN/EN61000-6-2. IEC/EN61000-4 tests list ESD Level 3 (8 kV air) / Level 2 (4 kV contact), radiated RF Level 3, EFT/burst Level 2, surge Level 3 (2 kV line-earth) / Level 2 (1 kV line-line), conducted RF Level 3, and magnetic field Level 4. Voltage-dip and interruption tests list >95% dip for 0.5 periods, 30% dip for 25 periods, and >95% interruption for 250 periods. This power supply is a component for installation in final equipment. EMC tests use a 720 × 360 mm metal plate, 1 mm thick; the completed equipment must be reconfirmed against its applicable EMC requirements. MTBF: 814.4K hours minimum by Telcordia SR-332 (Bellcore), and 90.4K hours minimum by MIL-HDBK-217F at 25°C. MTBF is a reliability calculation, not a service-life guarantee. Manufacturer-stated warranty: 5 years. Conformal coating is listed as an optional treatment for RSP-1500. It is not established as included in the unsuffixed model; confirm the selected coating arrangement when ordering.

  Read more less

  $998.04

  View options

•

  View options

  MEAN WELL RSP-1000 series: single-output enclosed AC/DC power supply with active PFC - RSP-1000-48

  MEAN WELL RSP-1000-48 is a single-output enclosed AC/DC power supply rated 48 V, 21 A and 1008 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage programming, remote sense, remote ON/OFF and active current sharing. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-1000 Datasheet (PDF) The RSP-1000 section is on PDF pages 9, 10, 11, 12, 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-1000-48 Model encoding RSP series; 1000 output-power family designation; 48 V nominal output. Actual rated power: 1008 W. Rated output 48 V DC; 21 A; 1008 W Output current range 0-21 A Manual voltage adjustment 43-55 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 90% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.95 at 230 VAC; 0.98 at 115 VAC Typical AC input current 12 A at 115 VAC; 6 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 300 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 110 / 90 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 907.2 W and 18.9 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 56.6-66.2 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. Operating Conditions Temperature and cooling -20 to +60°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 60% at +60°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.02%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 2 to load negative; maximum wiring-drop compensation is 0.5 V. Twist the sense leads together. The remote-sense example assumes voltage programming is inactive and the supply is ON. Factory defaults: Remote ON-OFF6 is shorted to -S2, and Vco8 is shorted to Vca10. Short 6 to 2 for ON; open for OFF. Keep 8/10 shorted when voltage programming is unused; otherwise the supply has no output. For simultaneous remote control, connect each unit’s +S/+V and -S/-V locally as shown. Voltage programming: 40-110% of nominal output using external voltage or resistance. For voltage control, apply the source between Vci9 and -S2 and connect +S to +V and -S to -V as in page 13, Fig.4.1. The curve shows2 V for 40% and 5 V for 100%; operation below 40% is non-linear. The120% typical OVP marker is not an extended output rating. Resistance programming uses the distinct Fig.4.2 (decrease) and Fig.4.3 (increase) circuits on page 13, including their auxiliary/sense connections. R1 decrease values shown are 390/560/820/1.2k/2.2k/4.7kΩ/open for 40/50/60/70/80/90/100% respectively. R2 increase values are open/18k/7.5kΩ for 100/105/110%. Resistors are typically 1/8 W. These are circuit-specific references, not interchangeable resistor connections. DC_OK is an open-collector output on pin 5, referenced to GND11/12: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. Maximum external TTL sink current is 10 mA; maximum external voltage is 5.6 V. Auxiliary output is 5 V (+5%,-8%; 4.6-5.25 V), maximum 0.5 A, from pin 4 to isolated G-AUX3. It has built-in ORing diodes and is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. Active current sharing supports up to 4 units. Use short, large-diameter load wires; set unit output voltages less than 0.2 V apart. Interconnect +S1, -S2 and CS7 among units as shown on page 14; use twisted-pair sense leads. Maximum total output current = each unit’s rated current × unit count ×0.9. Below 5% of the aggregate rated current, sharing may not be fully balanced. For 4 identical RSP-1000-48 units, the formula limits aggregate current to 75.6 A before other applicable derating. The cover’s up-to 4, 000 W (3+1) family statement is not a model-independent continuous system output guarantee. This family documents voltage programming and active current sharing, not a separate PC constant-current-programming function or OTP alarm output. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / -S Negative remote sense; also reference for Vci and remote ON/OFF 3 / G-AUX Isolated auxiliary-output return 4 / 5V-AUX 4.6-5.25 V, up to 0.5 A, referenced to pin 3; built-in ORing diodes; independent of remote ON/OFF 5 / DC_OK Open-collector output-status signal, referenced to pins 11/12 6 / Remote ON-OFF Short to pin 2 for ON; open for OFF 7 / CS Current-share signal; interconnect CS pins for parallel operation 8 / Vco Short to Vca pin 10 when voltage programming is not used 9 / Vci External DC voltage input for output-voltage programming, referenced to -S pin 2 10 / Vca External-resistance programming connection; typical resistor power 1/8 W 11, 12 / GND Connected to -V; return for DC_OK Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 295 × 127 × 41 mm (L × W × H), 1U; case 952B; drawing tolerance ±0.5 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-12DP-2DS or equivalent Mating housing HRS DF11-12DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 15; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 12 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class A under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55035, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254, BSMI CNS13438 Minimum MTBF 939.4K hours, Telcordia SR-332(Bellcore); 116.5K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 360 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. The cover explicitly excludes 48 V from the BIS marking; no BIS approval is claimed here for this output. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1950 g (1.95 kg) Published packing 1.95 kg; 6 pieces / 12.7 kg / 1.15 CUFT Specification revision 2024-12-23 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-1000 section occupies PDF pages 9-16. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $611.14

  View options

•

  View options

  MEAN WELL RSP-1000 series: single-output enclosed AC/DC power supply with active PFC - RSP-1000-27

  MEAN WELL RSP-1000-27 is a single-output enclosed AC/DC power supply rated 27 V, 37 A and 999 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage programming, remote sense, remote ON/OFF and active current sharing. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-1000 Datasheet (PDF) The RSP-1000 section is on PDF pages 9, 10, 11, 12, 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-1000-27 Model encoding RSP series; 1000 output-power family designation; 27 V nominal output. Actual rated power: 999 W. Rated output 27 V DC; 37 A; 999 W Output current range 0-37 A Manual voltage adjustment 24-30 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 88% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.95 at 230 VAC; 0.98 at 115 VAC Typical AC input current 12 A at 115 VAC; 6 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 300 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 110 / 90 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 899.1 W and 33.3 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 31-36.5 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. Operating Conditions Temperature and cooling -20 to +60°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 60% at +60°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.02%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 2 to load negative; maximum wiring-drop compensation is 0.5 V. Twist the sense leads together. The remote-sense example assumes voltage programming is inactive and the supply is ON. Factory defaults: Remote ON-OFF6 is shorted to -S2, and Vco8 is shorted to Vca10. Short 6 to 2 for ON; open for OFF. Keep 8/10 shorted when voltage programming is unused; otherwise the supply has no output. For simultaneous remote control, connect each unit’s +S/+V and -S/-V locally as shown. Voltage programming: 40-110% of nominal output using external voltage or resistance. For voltage control, apply the source between Vci9 and -S2 and connect +S to +V and -S to -V as in page 13, Fig.4.1. The curve shows2 V for 40% and 5 V for 100%; operation below 40% is non-linear. The120% typical OVP marker is not an extended output rating. Resistance programming uses the distinct Fig.4.2 (decrease) and Fig.4.3 (increase) circuits on page 13, including their auxiliary/sense connections. R1 decrease values shown are 390/560/820/1.2k/2.2k/4.7kΩ/open for 40/50/60/70/80/90/100% respectively. R2 increase values are open/18k/7.5kΩ for 100/105/110%. Resistors are typically 1/8 W. These are circuit-specific references, not interchangeable resistor connections. DC_OK is an open-collector output on pin 5, referenced to GND11/12: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. Maximum external TTL sink current is 10 mA; maximum external voltage is 5.6 V. Auxiliary output is 5 V (+5%,-8%; 4.6-5.25 V), maximum 0.5 A, from pin 4 to isolated G-AUX3. It has built-in ORing diodes and is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. Active current sharing supports up to 4 units. Use short, large-diameter load wires; set unit output voltages less than 0.2 V apart. Interconnect +S1, -S2 and CS7 among units as shown on page 14; use twisted-pair sense leads. Maximum total output current = each unit’s rated current × unit count ×0.9. Below 5% of the aggregate rated current, sharing may not be fully balanced. For 4 identical RSP-1000-27 units, the formula limits aggregate current to 133.2 A before other applicable derating. The cover’s up-to 4, 000 W (3+1) family statement is not a model-independent continuous system output guarantee. This family documents voltage programming and active current sharing, not a separate PC constant-current-programming function or OTP alarm output. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / -S Negative remote sense; also reference for Vci and remote ON/OFF 3 / G-AUX Isolated auxiliary-output return 4 / 5V-AUX 4.6-5.25 V, up to 0.5 A, referenced to pin 3; built-in ORing diodes; independent of remote ON/OFF 5 / DC_OK Open-collector output-status signal, referenced to pins 11/12 6 / Remote ON-OFF Short to pin 2 for ON; open for OFF 7 / CS Current-share signal; interconnect CS pins for parallel operation 8 / Vco Short to Vca pin 10 when voltage programming is not used 9 / Vci External DC voltage input for output-voltage programming, referenced to -S pin 2 10 / Vca External-resistance programming connection; typical resistor power 1/8 W 11, 12 / GND Connected to -V; return for DC_OK Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 295 × 127 × 41 mm (L × W × H), 1U; case 952B; drawing tolerance ±0.5 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-12DP-2DS or equivalent Mating housing HRS DF11-12DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 15; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 12 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004; BIS IS13252(Part1) / IEC60950-1 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class A under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55035, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254, BSMI CNS13438 Minimum MTBF 939.4K hours, Telcordia SR-332(Bellcore); 116.5K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 360 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1950 g (1.95 kg) Published packing 1.95 kg; 6 pieces / 12.7 kg / 1.15 CUFT Specification revision 2024-12-23 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-1000 section occupies PDF pages 9-16. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $611.14

  View options

•

  View options

  MEAN WELL RSP-1000 series: single-output enclosed AC/DC power supply with active PFC - RSP-1000-24

  MEAN WELL RSP-1000-24 is a single-output enclosed AC/DC power supply rated 24 V, 40 A and 960 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage programming, remote sense, remote ON/OFF and active current sharing. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-1000 Datasheet (PDF) The RSP-1000 section is on PDF pages 9, 10, 11, 12, 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-1000-24 Model encoding RSP series; 1000 output-power family designation; 24 V nominal output. Actual rated power: 960 W. Rated output 24 V DC; 40 A; 960 W Output current range 0-40 A Manual voltage adjustment 20-26.4 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 88% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.95 at 230 VAC; 0.98 at 115 VAC Typical AC input current 12 A at 115 VAC; 6 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 300 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 110 / 90 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 864 W and 36 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 27.6-32.4 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. Operating Conditions Temperature and cooling -20 to +60°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 60% at +60°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.02%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 2 to load negative; maximum wiring-drop compensation is 0.5 V. Twist the sense leads together. The remote-sense example assumes voltage programming is inactive and the supply is ON. Factory defaults: Remote ON-OFF6 is shorted to -S2, and Vco8 is shorted to Vca10. Short 6 to 2 for ON; open for OFF. Keep 8/10 shorted when voltage programming is unused; otherwise the supply has no output. For simultaneous remote control, connect each unit’s +S/+V and -S/-V locally as shown. Voltage programming: 40-110% of nominal output using external voltage or resistance. For voltage control, apply the source between Vci9 and -S2 and connect +S to +V and -S to -V as in page 13, Fig.4.1. The curve shows2 V for 40% and 5 V for 100%; operation below 40% is non-linear. The120% typical OVP marker is not an extended output rating. Resistance programming uses the distinct Fig.4.2 (decrease) and Fig.4.3 (increase) circuits on page 13, including their auxiliary/sense connections. R1 decrease values shown are 390/560/820/1.2k/2.2k/4.7kΩ/open for 40/50/60/70/80/90/100% respectively. R2 increase values are open/18k/7.5kΩ for 100/105/110%. Resistors are typically 1/8 W. These are circuit-specific references, not interchangeable resistor connections. DC_OK is an open-collector output on pin 5, referenced to GND11/12: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. Maximum external TTL sink current is 10 mA; maximum external voltage is 5.6 V. Auxiliary output is 5 V (+5%,-8%; 4.6-5.25 V), maximum 0.5 A, from pin 4 to isolated G-AUX3. It has built-in ORing diodes and is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. Active current sharing supports up to 4 units. Use short, large-diameter load wires; set unit output voltages less than 0.2 V apart. Interconnect +S1, -S2 and CS7 among units as shown on page 14; use twisted-pair sense leads. Maximum total output current = each unit’s rated current × unit count ×0.9. Below 5% of the aggregate rated current, sharing may not be fully balanced. For 4 identical RSP-1000-24 units, the formula limits aggregate current to 144 A before other applicable derating. The cover’s up-to 4, 000 W (3+1) family statement is not a model-independent continuous system output guarantee. This family documents voltage programming and active current sharing, not a separate PC constant-current-programming function or OTP alarm output. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / -S Negative remote sense; also reference for Vci and remote ON/OFF 3 / G-AUX Isolated auxiliary-output return 4 / 5V-AUX 4.6-5.25 V, up to 0.5 A, referenced to pin 3; built-in ORing diodes; independent of remote ON/OFF 5 / DC_OK Open-collector output-status signal, referenced to pins 11/12 6 / Remote ON-OFF Short to pin 2 for ON; open for OFF 7 / CS Current-share signal; interconnect CS pins for parallel operation 8 / Vco Short to Vca pin 10 when voltage programming is not used 9 / Vci External DC voltage input for output-voltage programming, referenced to -S pin 2 10 / Vca External-resistance programming connection; typical resistor power 1/8 W 11, 12 / GND Connected to -V; return for DC_OK Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 295 × 127 × 41 mm (L × W × H), 1U; case 952B; drawing tolerance ±0.5 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-12DP-2DS or equivalent Mating housing HRS DF11-12DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 15; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 12 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004; BIS IS13252(Part1) / IEC60950-1 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class A under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55035, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254, BSMI CNS13438 Minimum MTBF 939.4K hours, Telcordia SR-332(Bellcore); 116.5K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 360 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1950 g (1.95 kg) Published packing 1.95 kg; 6 pieces / 12.7 kg / 1.15 CUFT Specification revision 2024-12-23 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-1000 section occupies PDF pages 9-16. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $611.14

  View options

•

  View options

  MEAN WELL RSP-1000 series: single-output enclosed AC/DC power supply with active PFC - RSP-1000-15

  MEAN WELL RSP-1000-15 is a single-output enclosed AC/DC power supply rated 15 V, 50 A and 750 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage programming, remote sense, remote ON/OFF and active current sharing. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-1000 Datasheet (PDF) The RSP-1000 section is on PDF pages 9, 10, 11, 12, 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-1000-15 Model encoding RSP series; 1000 output-power family designation; 15 V nominal output. Actual rated power: 750 W. Rated output 15 V DC; 50 A; 750 W Output current range 0-50 A Manual voltage adjustment 13.5-16.5 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 85% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.95 at 230 VAC; 0.98 at 115 VAC Typical AC input current 12 A at 115 VAC; 6 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 300 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 110 / 90 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 675 W and 45 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 17-20.5 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. Operating Conditions Temperature and cooling -20 to +60°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 60% at +60°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.02%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 2 to load negative; maximum wiring-drop compensation is 0.5 V. Twist the sense leads together. The remote-sense example assumes voltage programming is inactive and the supply is ON. Factory defaults: Remote ON-OFF6 is shorted to -S2, and Vco8 is shorted to Vca10. Short 6 to 2 for ON; open for OFF. Keep 8/10 shorted when voltage programming is unused; otherwise the supply has no output. For simultaneous remote control, connect each unit’s +S/+V and -S/-V locally as shown. Voltage programming: 40-110% of nominal output using external voltage or resistance. For voltage control, apply the source between Vci9 and -S2 and connect +S to +V and -S to -V as in page 13, Fig.4.1. The curve shows2 V for 40% and 5 V for 100%; operation below 40% is non-linear. The120% typical OVP marker is not an extended output rating. Resistance programming uses the distinct Fig.4.2 (decrease) and Fig.4.3 (increase) circuits on page 13, including their auxiliary/sense connections. R1 decrease values shown are 390/560/820/1.2k/2.2k/4.7kΩ/open for 40/50/60/70/80/90/100% respectively. R2 increase values are open/18k/7.5kΩ for 100/105/110%. Resistors are typically 1/8 W. These are circuit-specific references, not interchangeable resistor connections. DC_OK is an open-collector output on pin 5, referenced to GND11/12: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. Maximum external TTL sink current is 10 mA; maximum external voltage is 5.6 V. Auxiliary output is 5 V (+5%,-8%; 4.6-5.25 V), maximum 0.5 A, from pin 4 to isolated G-AUX3. It has built-in ORing diodes and is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. Active current sharing supports up to 4 units. Use short, large-diameter load wires; set unit output voltages less than 0.2 V apart. Interconnect +S1, -S2 and CS7 among units as shown on page 14; use twisted-pair sense leads. Maximum total output current = each unit’s rated current × unit count ×0.9. Below 5% of the aggregate rated current, sharing may not be fully balanced. For 4 identical RSP-1000-15 units, the formula limits aggregate current to 180 A before other applicable derating. The cover’s up-to 4, 000 W (3+1) family statement is not a model-independent continuous system output guarantee. This family documents voltage programming and active current sharing, not a separate PC constant-current-programming function or OTP alarm output. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / -S Negative remote sense; also reference for Vci and remote ON/OFF 3 / G-AUX Isolated auxiliary-output return 4 / 5V-AUX 4.6-5.25 V, up to 0.5 A, referenced to pin 3; built-in ORing diodes; independent of remote ON/OFF 5 / DC_OK Open-collector output-status signal, referenced to pins 11/12 6 / Remote ON-OFF Short to pin 2 for ON; open for OFF 7 / CS Current-share signal; interconnect CS pins for parallel operation 8 / Vco Short to Vca pin 10 when voltage programming is not used 9 / Vci External DC voltage input for output-voltage programming, referenced to -S pin 2 10 / Vca External-resistance programming connection; typical resistor power 1/8 W 11, 12 / GND Connected to -V; return for DC_OK Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 295 × 127 × 41 mm (L × W × H), 1U; case 952B; drawing tolerance ±0.5 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-12DP-2DS or equivalent Mating housing HRS DF11-12DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 15; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 12 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004; BIS IS13252(Part1) / IEC60950-1 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class A under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55035, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254, BSMI CNS13438 Minimum MTBF 939.4K hours, Telcordia SR-332(Bellcore); 116.5K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 360 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1950 g (1.95 kg) Published packing 1.95 kg; 6 pieces / 12.7 kg / 1.15 CUFT Specification revision 2024-12-23 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-1000 section occupies PDF pages 9-16. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $611.14

  View options

•

  View options

  MEAN WELL RSP-1000 series: single-output enclosed AC/DC power supply with active PFC - RSP-1000-12

  MEAN WELL RSP-1000-12 is a single-output enclosed AC/DC power supply rated 12 V, 60 A and 720 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage programming, remote sense, remote ON/OFF and active current sharing. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-1000 Datasheet (PDF) The RSP-1000 section is on PDF pages 9, 10, 11, 12, 13, 14, 15, 16. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-1000-12 Model encoding RSP series; 1000 output-power family designation; 12 V nominal output. Actual rated power: 720 W. Rated output 12 V DC; 60 A; 720 W Output current range 0-60 A Manual voltage adjustment 10-13.5 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 83% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.95 at 230 VAC; 0.98 at 115 VAC Typical AC input current 12 A at 115 VAC; 6 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 300 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 110 / 90 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 648 W and 54 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 13.8-16.8 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. Operating Conditions Temperature and cooling -20 to +60°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 60% at +60°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.02%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 2 to load negative; maximum wiring-drop compensation is 0.5 V. Twist the sense leads together. The remote-sense example assumes voltage programming is inactive and the supply is ON. Factory defaults: Remote ON-OFF6 is shorted to -S2, and Vco8 is shorted to Vca10. Short 6 to 2 for ON; open for OFF. Keep 8/10 shorted when voltage programming is unused; otherwise the supply has no output. For simultaneous remote control, connect each unit’s +S/+V and -S/-V locally as shown. Voltage programming: 40-110% of nominal output using external voltage or resistance. For voltage control, apply the source between Vci9 and -S2 and connect +S to +V and -S to -V as in page 13, Fig.4.1. The curve shows2 V for 40% and 5 V for 100%; operation below 40% is non-linear. The120% typical OVP marker is not an extended output rating. Resistance programming uses the distinct Fig.4.2 (decrease) and Fig.4.3 (increase) circuits on page 13, including their auxiliary/sense connections. R1 decrease values shown are 390/560/820/1.2k/2.2k/4.7kΩ/open for 40/50/60/70/80/90/100% respectively. R2 increase values are open/18k/7.5kΩ for 100/105/110%. Resistors are typically 1/8 W. These are circuit-specific references, not interchangeable resistor connections. DC_OK is an open-collector output on pin 5, referenced to GND11/12: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. Maximum external TTL sink current is 10 mA; maximum external voltage is 5.6 V. Auxiliary output is 5 V (+5%,-8%; 4.6-5.25 V), maximum 0.5 A, from pin 4 to isolated G-AUX3. It has built-in ORing diodes and is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. Active current sharing supports up to 4 units. Use short, large-diameter load wires; set unit output voltages less than 0.2 V apart. Interconnect +S1, -S2 and CS7 among units as shown on page 14; use twisted-pair sense leads. Maximum total output current = each unit’s rated current × unit count ×0.9. Below 5% of the aggregate rated current, sharing may not be fully balanced. For 4 identical RSP-1000-12 units, the formula limits aggregate current to 216 A before other applicable derating. The cover’s up-to 4, 000 W (3+1) family statement is not a model-independent continuous system output guarantee. This family documents voltage programming and active current sharing, not a separate PC constant-current-programming function or OTP alarm output. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / -S Negative remote sense; also reference for Vci and remote ON/OFF 3 / G-AUX Isolated auxiliary-output return 4 / 5V-AUX 4.6-5.25 V, up to 0.5 A, referenced to pin 3; built-in ORing diodes; independent of remote ON/OFF 5 / DC_OK Open-collector output-status signal, referenced to pins 11/12 6 / Remote ON-OFF Short to pin 2 for ON; open for OFF 7 / CS Current-share signal; interconnect CS pins for parallel operation 8 / Vco Short to Vca pin 10 when voltage programming is not used 9 / Vci External DC voltage input for output-voltage programming, referenced to -S pin 2 10 / Vca External-resistance programming connection; typical resistor power 1/8 W 11, 12 / GND Connected to -V; return for DC_OK Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 295 × 127 × 41 mm (L × W × H), 1U; case 952B; drawing tolerance ±0.5 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-12DP-2DS or equivalent Mating housing HRS DF11-12DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 15; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 12 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004; BIS IS13252(Part1) / IEC60950-1 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class A under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55035, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254, BSMI CNS13438 Minimum MTBF 939.4K hours, Telcordia SR-332(Bellcore); 116.5K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 360 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1950 g (1.95 kg) Published packing 1.95 kg; 6 pieces / 12.7 kg / 1.15 CUFT Specification revision 2024-12-23 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-1000 section occupies PDF pages 9-16. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $611.14

  View options

•

  View options

  MEAN WELL RSP-750 series: single-output enclosed AC/DC power supply with active PFC - RSP-750-48

  MEAN WELL RSP-750-48 is a single-output enclosed AC/DC power supply rated 48 V, 15.7 A and 753.6 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage/current programming, remote sense and remote ON/OFF. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-750 Datasheet (PDF) The RSP-750 section is on PDF pages 1, 2, 3, 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-750-48 Model encoding RSP series; 750 output-power family designation; 48 V nominal output. Actual rated power: 753.6 W. Rated output 48 V DC; 15.7 A; 753.6 W Output current range 0-15.7 A Manual voltage adjustment 43-55 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 92% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.97 at 230 VAC; 0.98 at 115 VAC Typical AC input current 8.2 A at 115 VAC; 3.9 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 1000 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 90 / 70 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 678.24 W and 14.13 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 56.6-66.2 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. At light or no load, reducing the PV setting from high to low can trigger floating overvoltage protection. The datasheet recommends switching the supply off, setting PV to its lowest level, then adjusting to the required output. Operating Conditions Temperature and cooling -30 to +70°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 50% at +70°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.03%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 3 to load negative; maximum load-wiring compensation is 0.5 V. Use the complete function diagram for local +S/+VS and -S/-VS connections when remote sensing is not used. Factory default shorts on CN50 are Remote ON-OFF13 to 12V-AUX14, PV5 toPS6, and PC7 toPO8. Keep the programming pairs shorted when their functions are unused. Missing required shorting connections can leave the supply without output. Remote ON/OFF: a short between pins 13 and 14 turns output ON; an open circuit turns it OFF. For simultaneous control of multiple supplies, the manual requires each supply’s local +S/+V and -S/-V connections; this instruction does not establish a current-sharing capability. Voltage programming (PV): use an external 2-5.5 VDC source from PV5 to GND10/11 to program 40-110% of nominal output voltage. Remove only the applicable PV/PS short when using this function and follow page 5. Below 40% the graph is non-linear; an external input below 0.5 V may cause undervoltage protection and require restart. The120% Vout and 10% UVP graph labels are typical markers, not an extension of the specified operating range. Constant-current programming (PC): use an external 2-5.5 VDC source from PC7 to GND10/11 to set 40-110% of rated current. Follow page 5 and restore the PC7/PO8 short when unused. The graph is non-linear below 40%; its 115% typical marker is not an allowed operating extension. DC_OK is an open-collector output on pin 9, referenced to GND10/11: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. For external TTL sinking, maximum sink current is 10 mA and maximum external voltage is 5.6 V. Auxiliary output is 12 V ±10% (10.8-13.2 V), maximum 0.1 A, from pin 14 to isolated G-AUX12. It is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. These RSP-750 pages do not specify active current-sharing, a parallel-unit limit or an OTP warning output. Do not transfer those functions from other families. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / +VS Positive output signal; local pairing with +S for programming configurations 3 / -S Negative remote sense; connect to load negative 4 / -VS Negative output signal; use the negative local pairing shown in the function diagrams 5 / PV External output-voltage programming input, referenced to pins 10/11 (GND) 6 / PS Output-voltage programming reference; short to pin 5 when programming is not used 7 / PC External constant-current programming input 8 / PO Current-programming reference; short to pin 7 when programming is not used 9 / DC_OK Open-collector output-status signal, referenced to pins 10/11 10, 11 / GND Connected to -V; return for DC_OK and programming 12 / G-AUX Isolated auxiliary-output return 13 / Remote ON-OFF Short to pin 14 for ON; open for OFF 14 / 12V-AUX 10.8-13.2 V, up to 0.1 A, referenced to pin 12; independent of remote ON/OFF Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 250 × 127 × 41 mm (L × W × H), 1U; case 212A; drawing tolerance ±1 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-14DP-2DS or equivalent Mating housing HRS DF11-14DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 7; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 14 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class B under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55024, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254 Minimum MTBF 336.9K hours, Telcordia SR-332(Bellcore); 109.1K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 720 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. The cover explicitly excludes 48 V from the BIS marking; no BIS approval is claimed here for this output. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1640 g (1.64 kg) Published packing 1.64 kg; 6 pieces / 10.8 kg / 1.1 CUFT Specification revision 2025-01-10 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-750 section occupies PDF pages 1-8. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $394.29

  View options

•

  View options

  MEAN WELL RSP-750 series: single-output enclosed AC/DC power supply with active PFC - RSP-750-27

  MEAN WELL RSP-750-27 is a single-output enclosed AC/DC power supply rated 27 V, 27.8 A and 750.6 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage/current programming, remote sense and remote ON/OFF. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-750 Datasheet (PDF) The RSP-750 section is on PDF pages 1, 2, 3, 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-750-27 Model encoding RSP series; 750 output-power family designation; 27 V nominal output. Actual rated power: 750.6 W. Rated output 27 V DC; 27.8 A; 750.6 W Output current range 0-27.8 A Manual voltage adjustment 24-30 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 90.5% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.97 at 230 VAC; 0.98 at 115 VAC Typical AC input current 8.2 A at 115 VAC; 3.9 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 1000 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 90 / 70 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 675.54 W and 25.02 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 31-36.5 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. At light or no load, reducing the PV setting from high to low can trigger floating overvoltage protection. The datasheet recommends switching the supply off, setting PV to its lowest level, then adjusting to the required output. Operating Conditions Temperature and cooling -30 to +70°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 50% at +70°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.03%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 3 to load negative; maximum load-wiring compensation is 0.5 V. Use the complete function diagram for local +S/+VS and -S/-VS connections when remote sensing is not used. Factory default shorts on CN50 are Remote ON-OFF13 to 12V-AUX14, PV5 toPS6, and PC7 toPO8. Keep the programming pairs shorted when their functions are unused. Missing required shorting connections can leave the supply without output. Remote ON/OFF: a short between pins 13 and 14 turns output ON; an open circuit turns it OFF. For simultaneous control of multiple supplies, the manual requires each supply’s local +S/+V and -S/-V connections; this instruction does not establish a current-sharing capability. Voltage programming (PV): use an external 2-5.5 VDC source from PV5 to GND10/11 to program 40-110% of nominal output voltage. Remove only the applicable PV/PS short when using this function and follow page 5. Below 40% the graph is non-linear; an external input below 0.5 V may cause undervoltage protection and require restart. The120% Vout and 10% UVP graph labels are typical markers, not an extension of the specified operating range. Constant-current programming (PC): use an external 2-5.5 VDC source from PC7 to GND10/11 to set 40-110% of rated current. Follow page 5 and restore the PC7/PO8 short when unused. The graph is non-linear below 40%; its 115% typical marker is not an allowed operating extension. DC_OK is an open-collector output on pin 9, referenced to GND10/11: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. For external TTL sinking, maximum sink current is 10 mA and maximum external voltage is 5.6 V. Auxiliary output is 12 V ±10% (10.8-13.2 V), maximum 0.1 A, from pin 14 to isolated G-AUX12. It is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. These RSP-750 pages do not specify active current-sharing, a parallel-unit limit or an OTP warning output. Do not transfer those functions from other families. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / +VS Positive output signal; local pairing with +S for programming configurations 3 / -S Negative remote sense; connect to load negative 4 / -VS Negative output signal; use the negative local pairing shown in the function diagrams 5 / PV External output-voltage programming input, referenced to pins 10/11 (GND) 6 / PS Output-voltage programming reference; short to pin 5 when programming is not used 7 / PC External constant-current programming input 8 / PO Current-programming reference; short to pin 7 when programming is not used 9 / DC_OK Open-collector output-status signal, referenced to pins 10/11 10, 11 / GND Connected to -V; return for DC_OK and programming 12 / G-AUX Isolated auxiliary-output return 13 / Remote ON-OFF Short to pin 14 for ON; open for OFF 14 / 12V-AUX 10.8-13.2 V, up to 0.1 A, referenced to pin 12; independent of remote ON/OFF Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 250 × 127 × 41 mm (L × W × H), 1U; case 212A; drawing tolerance ±1 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-14DP-2DS or equivalent Mating housing HRS DF11-14DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 7; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 14 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004; BIS IS13252(Part1): 2010 / IEC60950-1: 2005 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class B under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55024, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254 Minimum MTBF 336.9K hours, Telcordia SR-332(Bellcore); 109.1K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 720 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. The datasheet notes that Taiwan-sourced products do not carry the BIS logo. Confirm the actual unit and applicable certificate with MEAN WELL when this marking is required. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1640 g (1.64 kg) Published packing 1.64 kg; 6 pieces / 10.8 kg / 1.1 CUFT Specification revision 2025-01-10 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-750 section occupies PDF pages 1-8. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $394.29

  View options

•

  View options

  MEAN WELL RSP-750 series: single-output enclosed AC/DC power supply with active PFC - RSP-750-24

  MEAN WELL RSP-750-24 is a single-output enclosed AC/DC power supply rated 24 V, 31.3 A and 751.2 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage/current programming, remote sense and remote ON/OFF. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-750 Datasheet (PDF) The RSP-750 section is on PDF pages 1, 2, 3, 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-750-24 Model encoding RSP series; 750 output-power family designation; 24 V nominal output. Actual rated power: 751.2 W. Rated output 24 V DC; 31.3 A; 751.2 W Output current range 0-31.3 A Manual voltage adjustment 20-26.4 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 90.5% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.97 at 230 VAC; 0.98 at 115 VAC Typical AC input current 8.2 A at 115 VAC; 3.9 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 1000 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 90 / 70 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 676.08 W and 28.17 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 27.6-32.4 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. At light or no load, reducing the PV setting from high to low can trigger floating overvoltage protection. The datasheet recommends switching the supply off, setting PV to its lowest level, then adjusting to the required output. Operating Conditions Temperature and cooling -30 to +70°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 50% at +70°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.03%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 3 to load negative; maximum load-wiring compensation is 0.5 V. Use the complete function diagram for local +S/+VS and -S/-VS connections when remote sensing is not used. Factory default shorts on CN50 are Remote ON-OFF13 to 12V-AUX14, PV5 toPS6, and PC7 toPO8. Keep the programming pairs shorted when their functions are unused. Missing required shorting connections can leave the supply without output. Remote ON/OFF: a short between pins 13 and 14 turns output ON; an open circuit turns it OFF. For simultaneous control of multiple supplies, the manual requires each supply’s local +S/+V and -S/-V connections; this instruction does not establish a current-sharing capability. Voltage programming (PV): use an external 2-5.5 VDC source from PV5 to GND10/11 to program 40-110% of nominal output voltage. Remove only the applicable PV/PS short when using this function and follow page 5. Below 40% the graph is non-linear; an external input below 0.5 V may cause undervoltage protection and require restart. The120% Vout and 10% UVP graph labels are typical markers, not an extension of the specified operating range. Constant-current programming (PC): use an external 2-5.5 VDC source from PC7 to GND10/11 to set 40-110% of rated current. Follow page 5 and restore the PC7/PO8 short when unused. The graph is non-linear below 40%; its 115% typical marker is not an allowed operating extension. DC_OK is an open-collector output on pin 9, referenced to GND10/11: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. For external TTL sinking, maximum sink current is 10 mA and maximum external voltage is 5.6 V. Auxiliary output is 12 V ±10% (10.8-13.2 V), maximum 0.1 A, from pin 14 to isolated G-AUX12. It is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. These RSP-750 pages do not specify active current-sharing, a parallel-unit limit or an OTP warning output. Do not transfer those functions from other families. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / +VS Positive output signal; local pairing with +S for programming configurations 3 / -S Negative remote sense; connect to load negative 4 / -VS Negative output signal; use the negative local pairing shown in the function diagrams 5 / PV External output-voltage programming input, referenced to pins 10/11 (GND) 6 / PS Output-voltage programming reference; short to pin 5 when programming is not used 7 / PC External constant-current programming input 8 / PO Current-programming reference; short to pin 7 when programming is not used 9 / DC_OK Open-collector output-status signal, referenced to pins 10/11 10, 11 / GND Connected to -V; return for DC_OK and programming 12 / G-AUX Isolated auxiliary-output return 13 / Remote ON-OFF Short to pin 14 for ON; open for OFF 14 / 12V-AUX 10.8-13.2 V, up to 0.1 A, referenced to pin 12; independent of remote ON/OFF Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 250 × 127 × 41 mm (L × W × H), 1U; case 212A; drawing tolerance ±1 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-14DP-2DS or equivalent Mating housing HRS DF11-14DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 7; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 14 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004; BIS IS13252(Part1): 2010 / IEC60950-1: 2005 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class B under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55024, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254 Minimum MTBF 336.9K hours, Telcordia SR-332(Bellcore); 109.1K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 720 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. The datasheet notes that Taiwan-sourced products do not carry the BIS logo. Confirm the actual unit and applicable certificate with MEAN WELL when this marking is required. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1640 g (1.64 kg) Published packing 1.64 kg; 6 pieces / 10.8 kg / 1.1 CUFT Specification revision 2025-01-10 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-750 section occupies PDF pages 1-8. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $394.29

  View options

•

  View options

  MEAN WELL RSP-750 series: single-output enclosed AC/DC power supply with active PFC - RSP-750-15

  MEAN WELL RSP-750-15 is a single-output enclosed AC/DC power supply rated 15 V, 50 A and 750 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage/current programming, remote sense and remote ON/OFF. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-750 Datasheet (PDF) The RSP-750 section is on PDF pages 1, 2, 3, 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-750-15 Model encoding RSP series; 750 output-power family designation; 15 V nominal output. Actual rated power: 750 W. Rated output 15 V DC; 50 A; 750 W Output current range 0-50 A Manual voltage adjustment 13.5-16.5 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 89% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.97 at 230 VAC; 0.98 at 115 VAC Typical AC input current 8.2 A at 115 VAC; 3.9 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 1000 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 90 / 70 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 675 W and 45 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 17-20.5 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. At light or no load, reducing the PV setting from high to low can trigger floating overvoltage protection. The datasheet recommends switching the supply off, setting PV to its lowest level, then adjusting to the required output. Operating Conditions Temperature and cooling -30 to +70°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 50% at +70°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.03%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 3 to load negative; maximum load-wiring compensation is 0.5 V. Use the complete function diagram for local +S/+VS and -S/-VS connections when remote sensing is not used. Factory default shorts on CN50 are Remote ON-OFF13 to 12V-AUX14, PV5 toPS6, and PC7 toPO8. Keep the programming pairs shorted when their functions are unused. Missing required shorting connections can leave the supply without output. Remote ON/OFF: a short between pins 13 and 14 turns output ON; an open circuit turns it OFF. For simultaneous control of multiple supplies, the manual requires each supply’s local +S/+V and -S/-V connections; this instruction does not establish a current-sharing capability. Voltage programming (PV): use an external 2-5.5 VDC source from PV5 to GND10/11 to program 40-110% of nominal output voltage. Remove only the applicable PV/PS short when using this function and follow page 5. Below 40% the graph is non-linear; an external input below 0.5 V may cause undervoltage protection and require restart. The120% Vout and 10% UVP graph labels are typical markers, not an extension of the specified operating range. Constant-current programming (PC): use an external 2-5.5 VDC source from PC7 to GND10/11 to set 40-110% of rated current. Follow page 5 and restore the PC7/PO8 short when unused. The graph is non-linear below 40%; its 115% typical marker is not an allowed operating extension. DC_OK is an open-collector output on pin 9, referenced to GND10/11: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. For external TTL sinking, maximum sink current is 10 mA and maximum external voltage is 5.6 V. Auxiliary output is 12 V ±10% (10.8-13.2 V), maximum 0.1 A, from pin 14 to isolated G-AUX12. It is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. These RSP-750 pages do not specify active current-sharing, a parallel-unit limit or an OTP warning output. Do not transfer those functions from other families. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / +VS Positive output signal; local pairing with +S for programming configurations 3 / -S Negative remote sense; connect to load negative 4 / -VS Negative output signal; use the negative local pairing shown in the function diagrams 5 / PV External output-voltage programming input, referenced to pins 10/11 (GND) 6 / PS Output-voltage programming reference; short to pin 5 when programming is not used 7 / PC External constant-current programming input 8 / PO Current-programming reference; short to pin 7 when programming is not used 9 / DC_OK Open-collector output-status signal, referenced to pins 10/11 10, 11 / GND Connected to -V; return for DC_OK and programming 12 / G-AUX Isolated auxiliary-output return 13 / Remote ON-OFF Short to pin 14 for ON; open for OFF 14 / 12V-AUX 10.8-13.2 V, up to 0.1 A, referenced to pin 12; independent of remote ON/OFF Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 250 × 127 × 41 mm (L × W × H), 1U; case 212A; drawing tolerance ±1 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-14DP-2DS or equivalent Mating housing HRS DF11-14DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 7; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 14 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004; BIS IS13252(Part1): 2010 / IEC60950-1: 2005 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class B under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55024, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254 Minimum MTBF 336.9K hours, Telcordia SR-332(Bellcore); 109.1K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 720 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. The datasheet notes that Taiwan-sourced products do not carry the BIS logo. Confirm the actual unit and applicable certificate with MEAN WELL when this marking is required. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1640 g (1.64 kg) Published packing 1.64 kg; 6 pieces / 10.8 kg / 1.1 CUFT Specification revision 2025-01-10 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-750 section occupies PDF pages 1-8. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $394.29

  View options

•

  View options

  MEAN WELL RSP-750 series: single-output enclosed AC/DC power supply with active PFC - RSP-750-12

  MEAN WELL RSP-750-12 is a single-output enclosed AC/DC power supply rated 12 V, 62.5 A and 750 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage/current programming, remote sense and remote ON/OFF. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-750 Datasheet (PDF) The RSP-750 section is on PDF pages 1, 2, 3, 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-750-12 Model encoding RSP series; 750 output-power family designation; 12 V nominal output. Actual rated power: 750 W. Rated output 12 V DC; 62.5 A; 750 W Output current range 0-62.5 A Manual voltage adjustment 10-13.5 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±1.0% / ±0.5% / ±0.5% Typical efficiency 87% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.97 at 230 VAC; 0.98 at 115 VAC Typical AC input current 8.2 A at 115 VAC; 3.9 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 1000 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 90 / 70 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 675 W and 56.25 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 13.8-16.8 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. At light or no load, reducing the PV setting from high to low can trigger floating overvoltage protection. The datasheet recommends switching the supply off, setting PV to its lowest level, then adjusting to the required output. Operating Conditions Temperature and cooling -30 to +70°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 50% at +70°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.03%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 3 to load negative; maximum load-wiring compensation is 0.5 V. Use the complete function diagram for local +S/+VS and -S/-VS connections when remote sensing is not used. Factory default shorts on CN50 are Remote ON-OFF13 to 12V-AUX14, PV5 toPS6, and PC7 toPO8. Keep the programming pairs shorted when their functions are unused. Missing required shorting connections can leave the supply without output. Remote ON/OFF: a short between pins 13 and 14 turns output ON; an open circuit turns it OFF. For simultaneous control of multiple supplies, the manual requires each supply’s local +S/+V and -S/-V connections; this instruction does not establish a current-sharing capability. Voltage programming (PV): use an external 2-5.5 VDC source from PV5 to GND10/11 to program 40-110% of nominal output voltage. Remove only the applicable PV/PS short when using this function and follow page 5. Below 40% the graph is non-linear; an external input below 0.5 V may cause undervoltage protection and require restart. The120% Vout and 10% UVP graph labels are typical markers, not an extension of the specified operating range. Constant-current programming (PC): use an external 2-5.5 VDC source from PC7 to GND10/11 to set 40-110% of rated current. Follow page 5 and restore the PC7/PO8 short when unused. The graph is non-linear below 40%; its 115% typical marker is not an allowed operating extension. DC_OK is an open-collector output on pin 9, referenced to GND10/11: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. For external TTL sinking, maximum sink current is 10 mA and maximum external voltage is 5.6 V. Auxiliary output is 12 V ±10% (10.8-13.2 V), maximum 0.1 A, from pin 14 to isolated G-AUX12. It is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. These RSP-750 pages do not specify active current-sharing, a parallel-unit limit or an OTP warning output. Do not transfer those functions from other families. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / +VS Positive output signal; local pairing with +S for programming configurations 3 / -S Negative remote sense; connect to load negative 4 / -VS Negative output signal; use the negative local pairing shown in the function diagrams 5 / PV External output-voltage programming input, referenced to pins 10/11 (GND) 6 / PS Output-voltage programming reference; short to pin 5 when programming is not used 7 / PC External constant-current programming input 8 / PO Current-programming reference; short to pin 7 when programming is not used 9 / DC_OK Open-collector output-status signal, referenced to pins 10/11 10, 11 / GND Connected to -V; return for DC_OK and programming 12 / G-AUX Isolated auxiliary-output return 13 / Remote ON-OFF Short to pin 14 for ON; open for OFF 14 / 12V-AUX 10.8-13.2 V, up to 0.1 A, referenced to pin 12; independent of remote ON/OFF Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 250 × 127 × 41 mm (L × W × H), 1U; case 212A; drawing tolerance ±1 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-14DP-2DS or equivalent Mating housing HRS DF11-14DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 7; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 14 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004; BIS IS13252(Part1): 2010 / IEC60950-1: 2005 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class B under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55024, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254 Minimum MTBF 336.9K hours, Telcordia SR-332(Bellcore); 109.1K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 720 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. The datasheet notes that Taiwan-sourced products do not carry the BIS logo. Confirm the actual unit and applicable certificate with MEAN WELL when this marking is required. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1640 g (1.64 kg) Published packing 1.64 kg; 6 pieces / 10.8 kg / 1.1 CUFT Specification revision 2025-01-10 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-750 section occupies PDF pages 1-8. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $394.29

  View options

•

  View options

  MEAN WELL RSP-750 series: single-output enclosed AC/DC power supply with active PFC - RSP-750-5

  MEAN WELL RSP-750-5 is a single-output enclosed AC/DC power supply rated 5 V, 100 A and 500 W. It accepts 90-264 VAC or 127-370 VDC, with active PFC and fan cooling in a 41 mm(1U) enclosure. It provides voltage/current programming, remote sense and remote ON/OFF. Observe model-specific ratings, derating and the required control jumpers. Product Datasheet Download MEAN WELL RSP-750 Datasheet (PDF) The RSP-750 section is on PDF pages 1, 2, 3, 4, 5, 6, 7, 8. Refer to the complete mechanical drawings and notes when planning installation. Model and Output Complete model RSP-750-5 Model encoding RSP series; 750 output-power family designation; 5 V nominal output. Actual rated power: 500 W. Rated output 5 V DC; 100 A; 500 W Output current range 0-100 A Manual voltage adjustment 4.75-5.5 V via SVR51 Ripple / noise 150 mVp-p maximum Voltage tolerance / line / load regulation ±2.0% / ±0.5% / ±2.0% Typical efficiency 82% Unless stated otherwise, values are measured at 230 VAC input, rated load and 25°C ambient. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair with parallel 0.1 µF and 47 µF capacitors. Voltage tolerance includes setup, line and load regulation. Manual adjustment and remote programming are separate functions. Neither permits exceeding the model-specific ratings or applicable derating limits. Input and Timing Input 90-264 VAC or 127-370 VDC; 47-63 Hz Typical power factor at full load 0.97 at 230 VAC; 0.98 at 115 VAC Typical AC input current 5.6 A at 115 VAC; 2.8 A at 230 VAC Typical inrush / leakage 25 A at 115 VAC; 40 A at 230 VAC. Leakage: <2.0 mA at 240 VAC. Setup / rise / hold-up 1000 / 50 ms at full load; typical hold-up 16 ms at both 115 and 230 VAC, at full load. PFC / PWM frequency 90 / 70 kHz Built-in active PFC and active inrush-current limiting are shown in the block diagram. At 90 VAC / 60 Hz, the published maximum is 450 W and 90 A. The input/load curve rises from 90% at 90 VAC to 100% at 100 VAC, then remains at 100% through 264 VAC. Apply temperature derating as well. Protection Protection functions Short circuit, overload, overvoltage and overtemperature Overload 105-125% of rated output power; constant-current limiting; automatic recovery after fault removal. Overvoltage 5.75-6.75 V; output shutdown; re-power on to recover. Overtemperature Output shutdown; automatic recovery after temperature falls. Overload protection is not a continuous or timed peak-power rating. Overload and overtemperature recovery are automatic; an overvoltage shutdown requires input power to be reapplied. At light or no load, reducing the PV setting from high to low can trigger floating overvoltage protection. The datasheet recommends switching the supply off, setting PV to its lowest level, then adjusting to the required output. For RSP-750-5 only, external output capacitance is strongly recommended not to exceed 5, 000 µF. Operating Conditions Temperature and cooling -30 to +70°C, subject to derating; built-in DC fan with speed control. Temperature/load curve Horizontal mounting: 100% load through +50°C, falling linearly to 50% at +70°C. Humidity / storage Operating: 20-90% RH. Storage:-40 to +85°C and 10-95% RH. Both non-condensing. Temperature coefficient ±0.03%/°C over 0-50°C Vibration 10-500 Hz, 2 G; 10 min/cycle; 60 min each along X, Y, Z. Above 2, 000 m (6, 500 ft), reduce the allowable ambient temperature by 5°C per additional 1, 000 m for this fan-cooled model. These pages do not specify a separate maximum operating altitude. Keep fan inlets and the airflow path unobstructed. The assigned pages do not give a fan thermostat threshold, fan-stop temperature or numerical external ventilation clearance; do not apply limits from another RSP family. The efficiency-versus-load plot is for the 48 V model at 230 VAC only; it is not a guaranteed efficiency curve for every voltage model. Control Functions and Default Connections Remote sense: connect +S pin 1 to load positive and -S pin 3 to load negative; maximum load-wiring compensation is 0.5 V. Use the complete function diagram for local +S/+VS and -S/-VS connections when remote sensing is not used. Factory default shorts on CN50 are Remote ON-OFF13 to 12V-AUX14, PV5 toPS6, and PC7 toPO8. Keep the programming pairs shorted when their functions are unused. Missing required shorting connections can leave the supply without output. Remote ON/OFF: a short between pins 13 and 14 turns output ON; an open circuit turns it OFF. For simultaneous control of multiple supplies, the manual requires each supply’s local +S/+V and -S/-V connections; this instruction does not establish a current-sharing capability. Voltage programming (PV): use an external 2-5.5 VDC source from PV5 to GND10/11 to program 40-110% of nominal output voltage. Remove only the applicable PV/PS short when using this function and follow page 5. Below 40% the graph is non-linear; an external input below 0.5 V may cause undervoltage protection and require restart. The120% Vout and 10% UVP graph labels are typical markers, not an extension of the specified operating range. Constant-current programming (PC): use an external 2-5.5 VDC source from PC7 to GND10/11 to set 40-110% of rated current. Follow page 5 and restore the PC7/PO8 short when unused. The graph is non-linear below 40%; its 115% typical marker is not an allowed operating extension. DC_OK is an open-collector output on pin 9, referenced to GND10/11: 0-1 V indicates ON and 3.3-5.6 V indicates OFF. For external TTL sinking, maximum sink current is 10 mA and maximum external voltage is 5.6 V. Auxiliary output is 12 V ±10% (10.8-13.2 V), maximum 0.1 A, from pin 14 to isolated G-AUX12. It is not controlled by remote ON/OFF. Do not interchange isolated auxiliary return with the main-output GND. These RSP-750 pages do not specify active current-sharing, a parallel-unit limit or an OTP warning output. Do not transfer those functions from other families. CN50 Pin Assignment 1 / +S Positive remote sense; connect to load positive 2 / +VS Positive output signal; local pairing with +S for programming configurations 3 / -S Negative remote sense; connect to load negative 4 / -VS Negative output signal; use the negative local pairing shown in the function diagrams 5 / PV External output-voltage programming input, referenced to pins 10/11 (GND) 6 / PS Output-voltage programming reference; short to pin 5 when programming is not used 7 / PC External constant-current programming input 8 / PO Current-programming reference; short to pin 7 when programming is not used 9 / DC_OK Open-collector output-status signal, referenced to pins 10/11 10, 11 / GND Connected to -V; return for DC_OK and programming 12 / G-AUX Isolated auxiliary-output return 13 / Remote ON-OFF Short to pin 14 for ON; open for OFF 14 / 12V-AUX 10.8-13.2 V, up to 0.1 A, referenced to pin 12; independent of remote ON/OFF Pin numbers refer to the CN50 orientation in the linked mechanical drawing. Main output current uses the power terminals, not signal or sense pins. Mounting and Connections Dimensions / case 250 × 127 × 41 mm (L × W × H), 1U; case 212A; drawing tolerance ±1 mm. Side mounting, hole group 1 3-M4 on each side; maximum penetration6 mm; recommended torque7-11 kgf·cm. Base mounting, hole group 2 3-M4; maximum penetration4 mm; recommended torque7-11 kgf·cm. AC input TB1 Pin1: AC/N; pin 2: AC/L; pin 3: FG protective earth. Maximum terminal torque18 kgf·cm. DC output terminals Two M5 output connections,+V and-V; maximum terminal torque10 kgf·cm. CN50 onboard header HRS DF11-14DP-2DS or equivalent Mating housing HRS DF11-14DS or equivalent Contacts as printed HRS DF11-**SC or equivalent Use the full hole pattern on PDF page 7; the rear fan airflow is shown toward the terminal end. M4 mounting depths are chassis penetration limits, not overall screw length. Allow for mounting-material thickness and do not confuse mounting-screw torque with AC/DC terminal torque. CN50 has 14 positions. The contact reference contains **; the exact wire/contact variant is not specified here. Confirm the appropriate complete contact before ordering. Apart from the expressly stated factory shorting connector, these pages do not establish that a loose mating housing, contacts or cable kit is supplied. No separate bracket or terminal-cover order code is given. Conformal coating is optional. The unsuffixed model number does not confirm that coating is fitted, and these pages do not define a coating order suffix. No numerical wire gauge or external ventilation-clearance requirement is specified here. Safety, EMC and Reliability Safety approvals listed UL62368-1; CSA C22.2 No.62368-1; TUV BS EN/EN62368-1; CCC GB4943.1; BSMI CNS15598-1; AS/NZS62368.1; EAC TP TC004; BIS IS13252(Part1): 2010 / IEC60950-1: 2005 Withstand / insulation Input-output3 kVAC; input-FG2 kVAC; output-FG0.5 kVAC.100 MΩ at 500 VDC, 25°C, 70% RH for all three paths. EMC emission Conducted Class B; radiated Class B under BS EN/EN55032(CISPR32), CNS15936. Harmonics: BS EN/EN61000-3-2; flicker: BS EN/EN61000-3-3. Immunity standards BS EN/EN55024, BS EN/EN61000-6-2, CCC GB17625.1, GB/T9254 Minimum MTBF 336.9K hours, Telcordia SR-332(Bellcore); 109.1K hours, MIL-HDBK-217F at 25°C. The power supply is a component: final equipment must be checked again for EMC compliance. The published EMC setup uses a 720 ×360 mm metal plate, 1 mm thick. The MTBF results are reliability-model references, not guaranteed service life. The manufacturer datasheet lists a 5-year warranty, subject to applicable manufacturer terms. The datasheet notes that Taiwan-sourced products do not carry the BIS logo. Confirm the actual unit and applicable certificate with MEAN WELL when this marking is required. Immunity tests: BS EN/EN61000-4-2; level 3, 8 kV air; level 2, 4 kV contact; BS EN/EN61000-4-3; level 3; BS EN/EN61000-4-4; level 3; BS EN/EN61000-4-5; level 4, 4 kV line-earth; level 3, 2 kV line-line; BS EN/EN61000-4-6; level 3; BS EN/EN61000-4-8; level 4; BS EN/EN61000-4-11; >95% dip for 0.5 periods, 30% dip for 25 periods; >95% interruptions for 250 periods. Weight and Datasheet Scope Per-unit catalog PACKING reference 1640 g (1.64 kg) Published packing 1.64 kg; 6 pieces / 10.8 kg / 1.1 CUFT Specification revision 2025-01-10 The per-unit catalog reference is not a measured net mass or a customer shipment weight; the carton total is not the single-product mass. This RSP-750 section occupies PDF pages 1-8. Consult its complete diagrams before wiring or programming. The catalog lists factory automation, test/measurement, laser-related equipment, burn-in and RF applications; each installation still requires the stated operating limits.

  Read more less

  $394.29

  View options

Back to top
