  MEAN WELL RPS-500 series: Open-Frame Medical AC/DC Power Supply - RPS-500-24

  MEAN WELL RPS-500-24 is a 24 V medical AC/DC power supply in the PCB open-frame configuration. Its main output is rated 20.8 A / 499.2 W with 25 CFM external airflow. Natural-convection output is 13.4 A / 321.6 W under the specified temperature and input conditions. It provides 5 V standby, PS-ON control, power-status signalling and remote sense, with 2 MOPP primary-to-secondary isolation. Product Datasheet Download MEAN WELL RPS-500 Datasheet (PDF) The RPS-500 section is on PDF pages 18, 19, 20, 21, 22, 23, 24, 25, 26, 27. Refer to the complete mechanical drawings and notes when planning installation. Model and Application Complete model RPS-500-24 Construction Blank suffix: PCB open-frame type. System configuration Class I with FG or Class II without FG. Typical applications Oral irrigators, hemodialysis machines, medical computer monitors, sleep-apnea devices, pumps and electric beds. Suitable for BF applications with appropriate system design. Component medical approvals do not certify the finished equipment; assess isolation, leakage current, grounding and EMC at system level. Output Ratings Nominal main output 24 V. Main current with specified cooling 20.8 A with 25 CFM external airflow. Main rated power with specified cooling 499.2 W with 25 CFM external airflow. Natural-convection main current 13.4 A. Natural-convection rated power 321.6 W; apply the separate 115 VAC / 230 VAC thermal curves. Peak-power allowance 550 W for 3 seconds; this is not a continuous rating. No repeated-pulse duty cycle is specified on these pages. Main voltage adjustment 22.8–25.2 V. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±2.0%; includes set-up tolerance, line and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93%. Use the individual main-output current and power limits together with the cooling, input-voltage and ambient-temperature limits. The 5 V standby and fan-rail ratings are separate interface limits; they do not authorize adding extra watts to the stated main-output or peak rating. These pages provide no separate combined-output power formula. Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated by parallel 0.1 µF and 47 µF capacitors. Input, Timing and Leakage Input range 80–264 VAC or 113–370 VDC; low-input derating applies. Input frequency 47–63 Hz. Power-factor correction Built-in active PFC; PF >0.94 at 230 VAC and >0.98 at 115 VAC, full load. AC current, typical 5.8 A at 115 VAC; 2.9 A at 230 VAC. Cold-start inrush, typical 40 A at 115 VAC; 80 A at 230 VAC. Set-up and rise time 1000 ms set-up / 30 ms rise at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 10 ms at either 230 VAC or 115 VAC, full load. Earth leakage current Less than 220 µA at 264 VAC, 50 Hz. Touch current Less than 100 µA at 264 VAC, measured from primary input to DC output. Low-power condition Less than 0.5 W using PS-ON control; this is not an unconditional main-output-on no-load figure. Block-diagram frequencies PFC: 90 kHz; PWM: 100 kHz. Protection Short circuit / overload 105–135% of rated output power; hiccup mode, with automatic recovery after the fault is removed. Overvoltage threshold 26.4–31.2 V. Overvoltage response Hiccup mode; automatically recovers after the fault is removed. Overtemperature Output shuts down and automatically recovers after the temperature falls. Protection thresholds are not an increased operating-power allowance. Standby, Control and Status 5 V standby 5 V at up to 0.6 A without a fan, or 1 A with 25 CFM; tolerance ±2%, ripple/noise 120 mVp-p maximum. Observe the cooling condition rather than treating 1 A as unconditional. PS-ON High, 2–5 V: main output on. Low, 0–0.5 V: main output off. CN95 pin 3 is PS-ON; pins 2 and 4 are DC COM. Power Good / Power Fail The TTL status signal goes high 10–500 ms after power set-up, and goes low at least 1 ms before output falls below 90% of its rated value. The available status connection is CN11 pin 4 PG, referenced to pin 3 DC COM; no separate PF pin is assigned. Remote sense CN11 pin 1 −S and pin 2 +S. Connect the sense lines with correct polarity according to the manufacturer instructions; no maximum compensation voltage is stated here. Power indication LED power-on indicator. Fan auxiliary output 12 V at up to 0.5 A for driving a fan; tolerance −15% to +10% at 20% main-output rated current with 25 CFM. CN12 pin 1 DC COM, pin 2 +12 V. Derating and Environment Ambient range −30 to +70°C, subject to the applicable cooling-mode curve. Horizontal-mounting thermal limits At 230 VAC with natural convection: 320 W through 45°C, 300 W at 50°C and 240 W at 60°C. At 115 VAC: 310 W through 30°C, 300 W at 40°C, 240 W at 50°C and 200 W at 60°C. The no-fan curves end at 60°C. With 25 CFM: the family curve shows 500 W through 50°C, falling to 250 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, reaching 100% at 115 VAC and remaining at 100% through 264 VAC. Operating altitude Up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per additional 1000 m for fanless operation, or 5°C per additional 1000 m for fan-cooled operation. Working humidity 20–90% RH, non-condensing. Storage temperature −40 to +85°C. Temperature coefficient ±0.03%/°C over 0–50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. The thermal graphs use rounded family power levels; retain the exact model current and rated-power limits above and use the more restrictive applicable limit. Combine input-voltage, temperature and altitude derating. Do not extrapolate a no-fan curve beyond its plotted endpoint. Installation and Mechanical Details Overall size, L × W × H 127 × 76.2 × 41 mm. Mechanical drawing reference PDF page 23; dimensions in millimetres, general tolerance ±1 mm. Board mounting Four positions on a 115.6 × 64.8 mm centre pattern; 5.7 mm edge references. The bottom drawing marks four Ø5.5 openings and four M3 L=3 positions. Height and underside Overall height 41 mm; the side view separately marks 38.5 mm and underside projection 3.0 mm maximum. External forced-air placement 25 CFM fan positioned 5 cm from the board edge, blowing across it in the shown direction; fan centre is dimensioned 52 mm from the DC-output-side edge. Grounding Use the marked FG connection for a Class I installation. A Class II system without FG is permitted only for the blank PCB type and requires the appropriate equipment design. Heat sinks HS1, HS2, HS3 and HS4 must not be shorted together. On-board fuse marking F8A 250V is printed beside FS1; this is not a complete replacement-fuse ordering code. Follow the complete manufacturer mechanical and installation drawings. Mounting penetration is measured into the chassis; do not confuse it with total screw length. The catalogue does not state that mating connectors, mounting screws or an external fan are supplied. Connectors and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 absent, pin 3 AC/N. Mating housing printed as JST VHR; terminal JST SVH-21T-P1.1 or equivalent. Main DC output CN2 = −V; CN3 = +V. M3.5 pan-head screws in two positions, maximum tightening torque 8 lbs-in (90 cNm). Sense / status CN11 TKP DH2I-2X2 or equivalent: pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. Mating housing printed as TKP DH2; terminal printed only as TKP. Standby / control CN95 TKP DH2L-2X2 or equivalent: pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Mating housing printed as TKP DH2; terminal printed only as TKP. External fan CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502; terminal TKP 8811 or equivalent. VHR and DH2 are abbreviated housing-family references; the control-connector terminal entry gives only the TKP manufacturer name. Confirm the complete housing/contact ordering suffix and circuit count with the connector supplier. Do not invent a missing suffix. No complete replacement-fan ordering model is supplied by these pages. Safety, Isolation and EMC Listed approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Additional design reference BS EN/EN60335-1 is a design reference by request, not an unconditional standard-configuration approval. Patient-protection isolation Primary–secondary: 2 MOPP; primary–earth: 1 MOPP; secondary–earth: 1 MOPP. Withstand voltage Input–output 4 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Insulation resistance Input–output and input–FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMI BS EN/EN55011 (CISPR11). Conducted: Class B for Class I with FG, or Class A for Class II without FG. Radiated: Class A in both configurations. Mains emissions BS EN/EN61000-3-2 harmonic current Class A; BS EN/EN61000-3-3 voltage flicker. Immunity framework BS EN/EN55035; BS EN/EN60601-1-2; BS EN/EN61204-3. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF immunity BS EN/EN61000-4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. BS EN/EN61000-4-5: Level 4, 4 kV line–FG and 2 kV line–line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V; BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. EMC tests used a 360 × 360 mm metal plate, 1 mm thick. This is a component for installation inside equipment; EMC compliance must be reconfirmed in the completed system. Weight, Reliability and Reference Catalogue single-unit weight 460 g, from the explicit 0.46 kg P.W entry in PACKING. This is a catalogue reference, not a measured net or shipping weight. Carton packing reference 30 pieces / 14.8 kg gross / 0.96 CUFT. MTBF estimates 1132.3 thousand hours minimum by Telcordia SR-332 (Bellcore); 144.2 thousand hours minimum by MIL-HDBK-217F at 25°C. Manufacturer warranty 3 years, subject to applicable manufacturer terms. Catalogue edition RPS-500-SPEC 2024-11-22; combined PDF pages 18–27. MTBF is a statistical estimate under the stated methods, not a guaranteed service life.

  Read more less

  $225.73

  View options

•

  View options

  MEAN WELL RPS-500 series: Open-Frame Medical AC/DC Power Supply - RPS-500-18

  MEAN WELL RPS-500-18 is a 18 V medical AC/DC power supply in the PCB open-frame configuration. Its main output is rated 27.8 A / 500.4 W with 25 CFM external airflow. Natural-convection output is 17.8 A / 320.4 W under the specified temperature and input conditions. It provides 5 V standby, PS-ON control, power-status signalling and remote sense, with 2 MOPP primary-to-secondary isolation. Product Datasheet Download MEAN WELL RPS-500 Datasheet (PDF) The RPS-500 section is on PDF pages 18, 19, 20, 21, 22, 23, 24, 25, 26, 27. Refer to the complete mechanical drawings and notes when planning installation. Model and Application Complete model RPS-500-18 Construction Blank suffix: PCB open-frame type. System configuration Class I with FG or Class II without FG. Typical applications Oral irrigators, hemodialysis machines, medical computer monitors, sleep-apnea devices, pumps and electric beds. Suitable for BF applications with appropriate system design. Component medical approvals do not certify the finished equipment; assess isolation, leakage current, grounding and EMC at system level. Output Ratings Nominal main output 18 V. Main current with specified cooling 27.8 A with 25 CFM external airflow. Main rated power with specified cooling 500.4 W with 25 CFM external airflow. Natural-convection main current 17.8 A. Natural-convection rated power 320.4 W; apply the separate 115 VAC / 230 VAC thermal curves. Peak-power allowance 550 W for 3 seconds; this is not a continuous rating. No repeated-pulse duty cycle is specified on these pages. Main voltage adjustment 17.1–18.9 V. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±3.0%; includes set-up tolerance, line and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 92.5%. Use the individual main-output current and power limits together with the cooling, input-voltage and ambient-temperature limits. The 5 V standby and fan-rail ratings are separate interface limits; they do not authorize adding extra watts to the stated main-output or peak rating. These pages provide no separate combined-output power formula. Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated by parallel 0.1 µF and 47 µF capacitors. Input, Timing and Leakage Input range 80–264 VAC or 113–370 VDC; low-input derating applies. Input frequency 47–63 Hz. Power-factor correction Built-in active PFC; PF >0.94 at 230 VAC and >0.98 at 115 VAC, full load. AC current, typical 5.8 A at 115 VAC; 2.9 A at 230 VAC. Cold-start inrush, typical 40 A at 115 VAC; 80 A at 230 VAC. Set-up and rise time 1000 ms set-up / 30 ms rise at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 10 ms at either 230 VAC or 115 VAC, full load. Earth leakage current Less than 220 µA at 264 VAC, 50 Hz. Touch current Less than 100 µA at 264 VAC, measured from primary input to DC output. Low-power condition Less than 0.5 W using PS-ON control; this is not an unconditional main-output-on no-load figure. Block-diagram frequencies PFC: 90 kHz; PWM: 100 kHz. Protection Short circuit / overload 105–135% of rated output power; hiccup mode, with automatic recovery after the fault is removed. Overvoltage threshold 19.8–23.4 V. Overvoltage response Hiccup mode; automatically recovers after the fault is removed. Overtemperature Output shuts down and automatically recovers after the temperature falls. Protection thresholds are not an increased operating-power allowance. Standby, Control and Status 5 V standby 5 V at up to 0.6 A without a fan, or 1 A with 25 CFM; tolerance ±2%, ripple/noise 120 mVp-p maximum. Observe the cooling condition rather than treating 1 A as unconditional. PS-ON High, 2–5 V: main output on. Low, 0–0.5 V: main output off. CN95 pin 3 is PS-ON; pins 2 and 4 are DC COM. Power Good / Power Fail The TTL status signal goes high 10–500 ms after power set-up, and goes low at least 1 ms before output falls below 90% of its rated value. The available status connection is CN11 pin 4 PG, referenced to pin 3 DC COM; no separate PF pin is assigned. Remote sense CN11 pin 1 −S and pin 2 +S. Connect the sense lines with correct polarity according to the manufacturer instructions; no maximum compensation voltage is stated here. Power indication LED power-on indicator. Fan auxiliary output 12 V at up to 0.5 A for driving a fan; tolerance −15% to +10% at 20% main-output rated current with 25 CFM. CN12 pin 1 DC COM, pin 2 +12 V. Derating and Environment Ambient range −30 to +70°C, subject to the applicable cooling-mode curve. Horizontal-mounting thermal limits At 230 VAC with natural convection: 320 W through 45°C, 300 W at 50°C and 240 W at 60°C. At 115 VAC: 310 W through 30°C, 300 W at 40°C, 240 W at 50°C and 200 W at 60°C. The no-fan curves end at 60°C. With 25 CFM: the family curve shows 500 W through 50°C, falling to 250 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, reaching 100% at 115 VAC and remaining at 100% through 264 VAC. Operating altitude Up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per additional 1000 m for fanless operation, or 5°C per additional 1000 m for fan-cooled operation. Working humidity 20–90% RH, non-condensing. Storage temperature −40 to +85°C. Temperature coefficient ±0.03%/°C over 0–50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. The thermal graphs use rounded family power levels; retain the exact model current and rated-power limits above and use the more restrictive applicable limit. Combine input-voltage, temperature and altitude derating. Do not extrapolate a no-fan curve beyond its plotted endpoint. Installation and Mechanical Details Overall size, L × W × H 127 × 76.2 × 41 mm. Mechanical drawing reference PDF page 23; dimensions in millimetres, general tolerance ±1 mm. Board mounting Four positions on a 115.6 × 64.8 mm centre pattern; 5.7 mm edge references. The bottom drawing marks four Ø5.5 openings and four M3 L=3 positions. Height and underside Overall height 41 mm; the side view separately marks 38.5 mm and underside projection 3.0 mm maximum. External forced-air placement 25 CFM fan positioned 5 cm from the board edge, blowing across it in the shown direction; fan centre is dimensioned 52 mm from the DC-output-side edge. Grounding Use the marked FG connection for a Class I installation. A Class II system without FG is permitted only for the blank PCB type and requires the appropriate equipment design. Heat sinks HS1, HS2, HS3 and HS4 must not be shorted together. On-board fuse marking F8A 250V is printed beside FS1; this is not a complete replacement-fuse ordering code. Follow the complete manufacturer mechanical and installation drawings. Mounting penetration is measured into the chassis; do not confuse it with total screw length. The catalogue does not state that mating connectors, mounting screws or an external fan are supplied. Connectors and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 absent, pin 3 AC/N. Mating housing printed as JST VHR; terminal JST SVH-21T-P1.1 or equivalent. Main DC output CN2 = −V; CN3 = +V. M3.5 pan-head screws in two positions, maximum tightening torque 8 lbs-in (90 cNm). Sense / status CN11 TKP DH2I-2X2 or equivalent: pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. Mating housing printed as TKP DH2; terminal printed only as TKP. Standby / control CN95 TKP DH2L-2X2 or equivalent: pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Mating housing printed as TKP DH2; terminal printed only as TKP. External fan CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502; terminal TKP 8811 or equivalent. VHR and DH2 are abbreviated housing-family references; the control-connector terminal entry gives only the TKP manufacturer name. Confirm the complete housing/contact ordering suffix and circuit count with the connector supplier. Do not invent a missing suffix. No complete replacement-fan ordering model is supplied by these pages. Safety, Isolation and EMC Listed approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Additional design reference BS EN/EN60335-1 is a design reference by request, not an unconditional standard-configuration approval. Patient-protection isolation Primary–secondary: 2 MOPP; primary–earth: 1 MOPP; secondary–earth: 1 MOPP. Withstand voltage Input–output 4 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Insulation resistance Input–output and input–FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMI BS EN/EN55011 (CISPR11). Conducted: Class B for Class I with FG, or Class A for Class II without FG. Radiated: Class A in both configurations. Mains emissions BS EN/EN61000-3-2 harmonic current Class A; BS EN/EN61000-3-3 voltage flicker. Immunity framework BS EN/EN55035; BS EN/EN60601-1-2; BS EN/EN61204-3. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF immunity BS EN/EN61000-4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. BS EN/EN61000-4-5: Level 4, 4 kV line–FG and 2 kV line–line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V; BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. EMC tests used a 360 × 360 mm metal plate, 1 mm thick. This is a component for installation inside equipment; EMC compliance must be reconfirmed in the completed system. Weight, Reliability and Reference Catalogue single-unit weight 460 g, from the explicit 0.46 kg P.W entry in PACKING. This is a catalogue reference, not a measured net or shipping weight. Carton packing reference 30 pieces / 14.8 kg gross / 0.96 CUFT. MTBF estimates 1132.3 thousand hours minimum by Telcordia SR-332 (Bellcore); 144.2 thousand hours minimum by MIL-HDBK-217F at 25°C. Manufacturer warranty 3 years, subject to applicable manufacturer terms. Catalogue edition RPS-500-SPEC 2024-11-22; combined PDF pages 18–27. MTBF is a statistical estimate under the stated methods, not a guaranteed service life.

  Read more less

  $225.73

  View options

•

  View options

  MEAN WELL RPS-500 series: Open-Frame Medical AC/DC Power Supply - RPS-500-15

  MEAN WELL RPS-500-15 is a 15 V medical AC/DC power supply in the PCB open-frame configuration. Its main output is rated 33.3 A / 499.5 W with 25 CFM external airflow. Natural-convection output is 21.3 A / 319.5 W under the specified temperature and input conditions. It provides 5 V standby, PS-ON control, power-status signalling and remote sense, with 2 MOPP primary-to-secondary isolation. Product Datasheet Download MEAN WELL RPS-500 Datasheet (PDF) The RPS-500 section is on PDF pages 18, 19, 20, 21, 22, 23, 24, 25, 26, 27. Refer to the complete mechanical drawings and notes when planning installation. Model and Application Complete model RPS-500-15 Construction Blank suffix: PCB open-frame type. System configuration Class I with FG or Class II without FG. Typical applications Oral irrigators, hemodialysis machines, medical computer monitors, sleep-apnea devices, pumps and electric beds. Suitable for BF applications with appropriate system design. Component medical approvals do not certify the finished equipment; assess isolation, leakage current, grounding and EMC at system level. Output Ratings Nominal main output 15 V. Main current with specified cooling 33.3 A with 25 CFM external airflow. Main rated power with specified cooling 499.5 W with 25 CFM external airflow. Natural-convection main current 21.3 A. Natural-convection rated power 319.5 W; apply the separate 115 VAC / 230 VAC thermal curves. Peak-power allowance 550 W for 3 seconds; this is not a continuous rating. No repeated-pulse duty cycle is specified on these pages. Main voltage adjustment 14.3–15.8 V. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±3.0%; includes set-up tolerance, line and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 92%. Use the individual main-output current and power limits together with the cooling, input-voltage and ambient-temperature limits. The 5 V standby and fan-rail ratings are separate interface limits; they do not authorize adding extra watts to the stated main-output or peak rating. These pages provide no separate combined-output power formula. Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated by parallel 0.1 µF and 47 µF capacitors. Input, Timing and Leakage Input range 80–264 VAC or 113–370 VDC; low-input derating applies. Input frequency 47–63 Hz. Power-factor correction Built-in active PFC; PF >0.94 at 230 VAC and >0.98 at 115 VAC, full load. AC current, typical 5.8 A at 115 VAC; 2.9 A at 230 VAC. Cold-start inrush, typical 40 A at 115 VAC; 80 A at 230 VAC. Set-up and rise time 1000 ms set-up / 30 ms rise at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 10 ms at either 230 VAC or 115 VAC, full load. Earth leakage current Less than 220 µA at 264 VAC, 50 Hz. Touch current Less than 100 µA at 264 VAC, measured from primary input to DC output. Low-power condition Less than 0.5 W using PS-ON control; this is not an unconditional main-output-on no-load figure. Block-diagram frequencies PFC: 90 kHz; PWM: 100 kHz. Protection Short circuit / overload 105–135% of rated output power; hiccup mode, with automatic recovery after the fault is removed. Overvoltage threshold 16.5–19.5 V. Overvoltage response Hiccup mode; automatically recovers after the fault is removed. Overtemperature Output shuts down and automatically recovers after the temperature falls. Protection thresholds are not an increased operating-power allowance. Standby, Control and Status 5 V standby 5 V at up to 0.6 A without a fan, or 1 A with 25 CFM; tolerance ±2%, ripple/noise 120 mVp-p maximum. Observe the cooling condition rather than treating 1 A as unconditional. PS-ON High, 2–5 V: main output on. Low, 0–0.5 V: main output off. CN95 pin 3 is PS-ON; pins 2 and 4 are DC COM. Power Good / Power Fail The TTL status signal goes high 10–500 ms after power set-up, and goes low at least 1 ms before output falls below 90% of its rated value. The available status connection is CN11 pin 4 PG, referenced to pin 3 DC COM; no separate PF pin is assigned. Remote sense CN11 pin 1 −S and pin 2 +S. Connect the sense lines with correct polarity according to the manufacturer instructions; no maximum compensation voltage is stated here. Power indication LED power-on indicator. Fan auxiliary output 12 V at up to 0.5 A for driving a fan; tolerance −15% to +10% at 20% main-output rated current with 25 CFM. CN12 pin 1 DC COM, pin 2 +12 V. Derating and Environment Ambient range −30 to +70°C, subject to the applicable cooling-mode curve. Horizontal-mounting thermal limits At 230 VAC with natural convection: 320 W through 45°C, 300 W at 50°C and 240 W at 60°C. At 115 VAC: 310 W through 30°C, 300 W at 40°C, 240 W at 50°C and 200 W at 60°C. The no-fan curves end at 60°C. With 25 CFM: the family curve shows 500 W through 50°C, falling to 250 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, reaching 100% at 115 VAC and remaining at 100% through 264 VAC. Operating altitude Up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per additional 1000 m for fanless operation, or 5°C per additional 1000 m for fan-cooled operation. Working humidity 20–90% RH, non-condensing. Storage temperature −40 to +85°C. Temperature coefficient ±0.03%/°C over 0–50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. The thermal graphs use rounded family power levels; retain the exact model current and rated-power limits above and use the more restrictive applicable limit. Combine input-voltage, temperature and altitude derating. Do not extrapolate a no-fan curve beyond its plotted endpoint. Installation and Mechanical Details Overall size, L × W × H 127 × 76.2 × 41 mm. Mechanical drawing reference PDF page 23; dimensions in millimetres, general tolerance ±1 mm. Board mounting Four positions on a 115.6 × 64.8 mm centre pattern; 5.7 mm edge references. The bottom drawing marks four Ø5.5 openings and four M3 L=3 positions. Height and underside Overall height 41 mm; the side view separately marks 38.5 mm and underside projection 3.0 mm maximum. External forced-air placement 25 CFM fan positioned 5 cm from the board edge, blowing across it in the shown direction; fan centre is dimensioned 52 mm from the DC-output-side edge. Grounding Use the marked FG connection for a Class I installation. A Class II system without FG is permitted only for the blank PCB type and requires the appropriate equipment design. Heat sinks HS1, HS2, HS3 and HS4 must not be shorted together. On-board fuse marking F8A 250V is printed beside FS1; this is not a complete replacement-fuse ordering code. Follow the complete manufacturer mechanical and installation drawings. Mounting penetration is measured into the chassis; do not confuse it with total screw length. The catalogue does not state that mating connectors, mounting screws or an external fan are supplied. Connectors and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 absent, pin 3 AC/N. Mating housing printed as JST VHR; terminal JST SVH-21T-P1.1 or equivalent. Main DC output CN2 = −V; CN3 = +V. M3.5 pan-head screws in two positions, maximum tightening torque 8 lbs-in (90 cNm). Sense / status CN11 TKP DH2I-2X2 or equivalent: pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. Mating housing printed as TKP DH2; terminal printed only as TKP. Standby / control CN95 TKP DH2L-2X2 or equivalent: pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Mating housing printed as TKP DH2; terminal printed only as TKP. External fan CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502; terminal TKP 8811 or equivalent. VHR and DH2 are abbreviated housing-family references; the control-connector terminal entry gives only the TKP manufacturer name. Confirm the complete housing/contact ordering suffix and circuit count with the connector supplier. Do not invent a missing suffix. No complete replacement-fan ordering model is supplied by these pages. Safety, Isolation and EMC Listed approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Additional design reference BS EN/EN60335-1 is a design reference by request, not an unconditional standard-configuration approval. Patient-protection isolation Primary–secondary: 2 MOPP; primary–earth: 1 MOPP; secondary–earth: 1 MOPP. Withstand voltage Input–output 4 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Insulation resistance Input–output and input–FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMI BS EN/EN55011 (CISPR11). Conducted: Class B for Class I with FG, or Class A for Class II without FG. Radiated: Class A in both configurations. Mains emissions BS EN/EN61000-3-2 harmonic current Class A; BS EN/EN61000-3-3 voltage flicker. Immunity framework BS EN/EN55035; BS EN/EN60601-1-2; BS EN/EN61204-3. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF immunity BS EN/EN61000-4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. BS EN/EN61000-4-5: Level 4, 4 kV line–FG and 2 kV line–line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V; BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. EMC tests used a 360 × 360 mm metal plate, 1 mm thick. This is a component for installation inside equipment; EMC compliance must be reconfirmed in the completed system. Weight, Reliability and Reference Catalogue single-unit weight 460 g, from the explicit 0.46 kg P.W entry in PACKING. This is a catalogue reference, not a measured net or shipping weight. Carton packing reference 30 pieces / 14.8 kg gross / 0.96 CUFT. MTBF estimates 1132.3 thousand hours minimum by Telcordia SR-332 (Bellcore); 144.2 thousand hours minimum by MIL-HDBK-217F at 25°C. Manufacturer warranty 3 years, subject to applicable manufacturer terms. Catalogue edition RPS-500-SPEC 2024-11-22; combined PDF pages 18–27. MTBF is a statistical estimate under the stated methods, not a guaranteed service life.

  Read more less

  $225.73

  View options

•

  View options

  MEAN WELL RPS-500 series: Open-Frame Medical AC/DC Power Supply - RPS-500-12

  MEAN WELL RPS-500-12 is a 12 V medical AC/DC power supply in the PCB open-frame configuration. Its main output is rated 41.6 A / 499.2 W with 25 CFM external airflow. Natural-convection output is 26.7 A / 320.4 W under the specified temperature and input conditions. It provides 5 V standby, PS-ON control, power-status signalling and remote sense, with 2 MOPP primary-to-secondary isolation. Product Datasheet Download MEAN WELL RPS-500 Datasheet (PDF) The RPS-500 section is on PDF pages 18, 19, 20, 21, 22, 23, 24, 25, 26, 27. Refer to the complete mechanical drawings and notes when planning installation. Model and Application Complete model RPS-500-12 Construction Blank suffix: PCB open-frame type. System configuration Class I with FG or Class II without FG. Typical applications Oral irrigators, hemodialysis machines, medical computer monitors, sleep-apnea devices, pumps and electric beds. Suitable for BF applications with appropriate system design. Component medical approvals do not certify the finished equipment; assess isolation, leakage current, grounding and EMC at system level. Output Ratings Nominal main output 12 V. Main current with specified cooling 41.6 A with 25 CFM external airflow. Main rated power with specified cooling 499.2 W with 25 CFM external airflow. Natural-convection main current 26.7 A. Natural-convection rated power 320.4 W; apply the separate 115 VAC / 230 VAC thermal curves. Peak-power allowance 550 W for 3 seconds; this is not a continuous rating. No repeated-pulse duty cycle is specified on these pages. Main voltage adjustment 11.4–12.6 V. Ripple and noise, maximum 200 mVp-p. Voltage tolerance ±3.0%; includes set-up tolerance, line and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 91%. Use the individual main-output current and power limits together with the cooling, input-voltage and ambient-temperature limits. The 5 V standby and fan-rail ratings are separate interface limits; they do not authorize adding extra watts to the stated main-output or peak rating. These pages provide no separate combined-output power formula. Unless otherwise stated, specifications are measured at 230 VAC, rated load and 25°C. Ripple/noise is measured with 20 MHz bandwidth using a 12-inch twisted pair terminated by parallel 0.1 µF and 47 µF capacitors. Input, Timing and Leakage Input range 80–264 VAC or 113–370 VDC; low-input derating applies. Input frequency 47–63 Hz. Power-factor correction Built-in active PFC; PF >0.94 at 230 VAC and >0.98 at 115 VAC, full load. AC current, typical 5.8 A at 115 VAC; 2.9 A at 230 VAC. Cold-start inrush, typical 40 A at 115 VAC; 80 A at 230 VAC. Set-up and rise time 1000 ms set-up / 30 ms rise at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 10 ms at either 230 VAC or 115 VAC, full load. Earth leakage current Less than 220 µA at 264 VAC, 50 Hz. Touch current Less than 100 µA at 264 VAC, measured from primary input to DC output. Low-power condition Less than 0.5 W using PS-ON control; this is not an unconditional main-output-on no-load figure. Block-diagram frequencies PFC: 90 kHz; PWM: 100 kHz. Protection Short circuit / overload 105–135% of rated output power; hiccup mode, with automatic recovery after the fault is removed. Overvoltage threshold 13.2–15.6 V. Overvoltage response Hiccup mode; automatically recovers after the fault is removed. Overtemperature Output shuts down and automatically recovers after the temperature falls. Protection thresholds are not an increased operating-power allowance. Standby, Control and Status 5 V standby 5 V at up to 0.6 A without a fan, or 1 A with 25 CFM; tolerance ±2%, ripple/noise 120 mVp-p maximum. Observe the cooling condition rather than treating 1 A as unconditional. PS-ON High, 2–5 V: main output on. Low, 0–0.5 V: main output off. CN95 pin 3 is PS-ON; pins 2 and 4 are DC COM. Power Good / Power Fail The TTL status signal goes high 10–500 ms after power set-up, and goes low at least 1 ms before output falls below 90% of its rated value. The available status connection is CN11 pin 4 PG, referenced to pin 3 DC COM; no separate PF pin is assigned. Remote sense CN11 pin 1 −S and pin 2 +S. Connect the sense lines with correct polarity according to the manufacturer instructions; no maximum compensation voltage is stated here. Power indication LED power-on indicator. Fan auxiliary output 12 V at up to 0.5 A for driving a fan; tolerance −15% to +10% at 20% main-output rated current with 25 CFM. CN12 pin 1 DC COM, pin 2 +12 V. Derating and Environment Ambient range −30 to +70°C, subject to the applicable cooling-mode curve. Horizontal-mounting thermal limits At 230 VAC with natural convection: 320 W through 45°C, 300 W at 50°C and 240 W at 60°C. At 115 VAC: 310 W through 30°C, 300 W at 40°C, 240 W at 50°C and 200 W at 60°C. The no-fan curves end at 60°C. With 25 CFM: the family curve shows 500 W through 50°C, falling to 250 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, reaching 100% at 115 VAC and remaining at 100% through 264 VAC. Operating altitude Up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per additional 1000 m for fanless operation, or 5°C per additional 1000 m for fan-cooled operation. Working humidity 20–90% RH, non-condensing. Storage temperature −40 to +85°C. Temperature coefficient ±0.03%/°C over 0–50°C. Vibration 10–500 Hz, 2 G, 10 minutes per cycle; 60 minutes along each X, Y and Z axis. The thermal graphs use rounded family power levels; retain the exact model current and rated-power limits above and use the more restrictive applicable limit. Combine input-voltage, temperature and altitude derating. Do not extrapolate a no-fan curve beyond its plotted endpoint. Installation and Mechanical Details Overall size, L × W × H 127 × 76.2 × 41 mm. Mechanical drawing reference PDF page 23; dimensions in millimetres, general tolerance ±1 mm. Board mounting Four positions on a 115.6 × 64.8 mm centre pattern; 5.7 mm edge references. The bottom drawing marks four Ø5.5 openings and four M3 L=3 positions. Height and underside Overall height 41 mm; the side view separately marks 38.5 mm and underside projection 3.0 mm maximum. External forced-air placement 25 CFM fan positioned 5 cm from the board edge, blowing across it in the shown direction; fan centre is dimensioned 52 mm from the DC-output-side edge. Grounding Use the marked FG connection for a Class I installation. A Class II system without FG is permitted only for the blank PCB type and requires the appropriate equipment design. Heat sinks HS1, HS2, HS3 and HS4 must not be shorted together. On-board fuse marking F8A 250V is printed beside FS1; this is not a complete replacement-fuse ordering code. Follow the complete manufacturer mechanical and installation drawings. Mounting penetration is measured into the chassis; do not confuse it with total screw length. The catalogue does not state that mating connectors, mounting screws or an external fan are supplied. Connectors and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 absent, pin 3 AC/N. Mating housing printed as JST VHR; terminal JST SVH-21T-P1.1 or equivalent. Main DC output CN2 = −V; CN3 = +V. M3.5 pan-head screws in two positions, maximum tightening torque 8 lbs-in (90 cNm). Sense / status CN11 TKP DH2I-2X2 or equivalent: pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. Mating housing printed as TKP DH2; terminal printed only as TKP. Standby / control CN95 TKP DH2L-2X2 or equivalent: pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Mating housing printed as TKP DH2; terminal printed only as TKP. External fan CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502; terminal TKP 8811 or equivalent. VHR and DH2 are abbreviated housing-family references; the control-connector terminal entry gives only the TKP manufacturer name. Confirm the complete housing/contact ordering suffix and circuit count with the connector supplier. Do not invent a missing suffix. No complete replacement-fan ordering model is supplied by these pages. Safety, Isolation and EMC Listed approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. Additional design reference BS EN/EN60335-1 is a design reference by request, not an unconditional standard-configuration approval. Patient-protection isolation Primary–secondary: 2 MOPP; primary–earth: 1 MOPP; secondary–earth: 1 MOPP. Withstand voltage Input–output 4 kVAC; input–FG 2 kVAC; output–FG 1.5 kVAC. Insulation resistance Input–output and input–FG: 100 MΩ at 500 VDC, 25°C and 70% RH. EMI BS EN/EN55011 (CISPR11). Conducted: Class B for Class I with FG, or Class A for Class II without FG. Radiated: Class A in both configurations. Mains emissions BS EN/EN61000-3-2 harmonic current Class A; BS EN/EN61000-3-3 voltage flicker. Immunity framework BS EN/EN55035; BS EN/EN60601-1-2; BS EN/EN61204-3. ESD BS EN/EN61000-4-2: Level 4, 15 kV air and 8 kV contact. RF immunity BS EN/EN61000-4-3: Level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9, 9–28 V/m at 385 MHz–5.78 GHz. EFT / surge BS EN/EN61000-4-4: Level 3, 2 kV. BS EN/EN61000-4-5: Level 4, 4 kV line–FG and 2 kV line–line. Conducted / magnetic immunity BS EN/EN61000-4-6: Level 3, 10 V; BS EN/EN61000-4-8: Level 4, 30 A/m. Voltage dips / interruptions BS EN/EN61000-4-11: 100% dip for 1 period; 30% dip for 25 periods; 100% interruption for 250 periods. EMC tests used a 360 × 360 mm metal plate, 1 mm thick. This is a component for installation inside equipment; EMC compliance must be reconfirmed in the completed system. Weight, Reliability and Reference Catalogue single-unit weight 460 g, from the explicit 0.46 kg P.W entry in PACKING. This is a catalogue reference, not a measured net or shipping weight. Carton packing reference 30 pieces / 14.8 kg gross / 0.96 CUFT. MTBF estimates 1132.3 thousand hours minimum by Telcordia SR-332 (Bellcore); 144.2 thousand hours minimum by MIL-HDBK-217F at 25°C. Manufacturer warranty 3 years, subject to applicable manufacturer terms. Catalogue edition RPS-500-SPEC 2024-11-22; combined PDF pages 18–27. MTBF is a statistical estimate under the stated methods, not a guaranteed service life.

  Read more less

  $225.73

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Side Fan - RPS-400-48-SF

  MEAN WELL RPS-400-48-SF is a 48 V medical AC/DC power supply in the enclosed casing with a side fan configuration. It supplies 8.4 A / 403.2 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-48-SF. SF: Enclosed casing with a side fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 48 V. Forced-air current and power 8.4 A / 403.2 W; Built-in side fan. Cooling configuration This SF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 200 mVp-p. Main-output voltage adjustment 45.6–50.4 V. Voltage tolerance ±1.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 94%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 52.8–62.4 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 160 × 86 × 43 mm; case 248A. Mounting and clearance Bottom: four M3 holes on a 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Use 4–6 kgf·cm mounting torque and the complete bottom-view offsets. Airflow The fitted side fan airflow direction is shown in the SF mechanical drawing; preserve the side clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 640 g (0.64 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 16.4 kg / 0.91 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Side Fan - RPS-400-36-SF

  MEAN WELL RPS-400-36-SF is a 36 V medical AC/DC power supply in the enclosed casing with a side fan configuration. It supplies 11.2 A / 403.2 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-36-SF. SF: Enclosed casing with a side fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 36 V. Forced-air current and power 11.2 A / 403.2 W; Built-in side fan. Cooling configuration This SF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 200 mVp-p. Main-output voltage adjustment 34.2–37.8 V. Voltage tolerance ±1.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 94%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 39.6–46.8 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 160 × 86 × 43 mm; case 248A. Mounting and clearance Bottom: four M3 holes on a 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Use 4–6 kgf·cm mounting torque and the complete bottom-view offsets. Airflow The fitted side fan airflow direction is shown in the SF mechanical drawing; preserve the side clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 640 g (0.64 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 16.4 kg / 0.91 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Side Fan - RPS-400-27-SF

  MEAN WELL RPS-400-27-SF is a 27 V medical AC/DC power supply in the enclosed casing with a side fan configuration. It supplies 14.9 A / 402.3 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-27-SF. SF: Enclosed casing with a side fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 27 V. Forced-air current and power 14.9 A / 402.3 W; Built-in side fan. Cooling configuration This SF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 200 mVp-p. Main-output voltage adjustment 25.6–28.4 V. Voltage tolerance ±1.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93.5%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 29.7–35.1 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 160 × 86 × 43 mm; case 248A. Mounting and clearance Bottom: four M3 holes on a 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Use 4–6 kgf·cm mounting torque and the complete bottom-view offsets. Airflow The fitted side fan airflow direction is shown in the SF mechanical drawing; preserve the side clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 640 g (0.64 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 16.4 kg / 0.91 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Side Fan - RPS-400-24-SF

  MEAN WELL RPS-400-24-SF is a 24 V medical AC/DC power supply in the enclosed casing with a side fan configuration. It supplies 16.7 A / 400.8 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-24-SF. SF: Enclosed casing with a side fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 24 V. Forced-air current and power 16.7 A / 400.8 W; Built-in side fan. Cooling configuration This SF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 150 mVp-p. Main-output voltage adjustment 22.8–25.2 V. Voltage tolerance ±2.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 26.4–31.2 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 160 × 86 × 43 mm; case 248A. Mounting and clearance Bottom: four M3 holes on a 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Use 4–6 kgf·cm mounting torque and the complete bottom-view offsets. Airflow The fitted side fan airflow direction is shown in the SF mechanical drawing; preserve the side clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 640 g (0.64 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 16.4 kg / 0.91 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Side Fan - RPS-400-18-SF

  MEAN WELL RPS-400-18-SF is an 18 V medical AC/DC power supply in the enclosed casing with a side fan configuration. It supplies 22.3 A / 401.4 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-18-SF. SF: Enclosed casing with a side fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 18 V. Forced-air current and power 22.3 A / 401.4 W; Built-in side fan. Cooling configuration This SF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 150 mVp-p. Main-output voltage adjustment 17.1–18.9 V. Voltage tolerance ±3.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 19.8–23.4 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 160 × 86 × 43 mm; case 248A. Mounting and clearance Bottom: four M3 holes on a 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Use 4–6 kgf·cm mounting torque and the complete bottom-view offsets. Airflow The fitted side fan airflow direction is shown in the SF mechanical drawing; preserve the side clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 640 g (0.64 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 16.4 kg / 0.91 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Side Fan - RPS-400-15-SF

  MEAN WELL RPS-400-15-SF is a 15 V medical AC/DC power supply in the enclosed casing with a side fan configuration. It supplies 26.7 A / 400.5 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-15-SF. SF: Enclosed casing with a side fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 15 V. Forced-air current and power 26.7 A / 400.5 W; Built-in side fan. Cooling configuration This SF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 120 mVp-p. Main-output voltage adjustment 14.3–15.8 V. Voltage tolerance ±3.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 92%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 16.5–19.5 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 160 × 86 × 43 mm; case 248A. Mounting and clearance Bottom: four M3 holes on a 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Use 4–6 kgf·cm mounting torque and the complete bottom-view offsets. Airflow The fitted side fan airflow direction is shown in the SF mechanical drawing; preserve the side clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 640 g (0.64 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 16.4 kg / 0.91 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Side Fan - RPS-400-12-SF

  MEAN WELL RPS-400-12-SF is a 12 V medical AC/DC power supply in the enclosed casing with a side fan configuration. It supplies 33.3 A / 399.6 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-12-SF. SF: Enclosed casing with a side fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 12 V. Forced-air current and power 33.3 A / 399.6 W; Built-in side fan. Cooling configuration This SF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 120 mVp-p. Main-output voltage adjustment 11.4–12.6 V. Voltage tolerance ±3.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 91.5%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 13.2–15.6 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 160 × 86 × 43 mm; case 248A. Mounting and clearance Bottom: four M3 holes on a 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Use 4–6 kgf·cm mounting torque and the complete bottom-view offsets. Airflow The fitted side fan airflow direction is shown in the SF mechanical drawing; preserve the side clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 640 g (0.64 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 16.4 kg / 0.91 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Top Fan - RPS-400-48-TF

  MEAN WELL RPS-400-48-TF is a 48 V medical AC/DC power supply in the enclosed casing with a top fan configuration. It supplies 8.4 A / 403.2 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-48-TF. TF: Enclosed casing with a top fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 48 V. Forced-air current and power 8.4 A / 403.2 W; Built-in top fan. Cooling configuration This TF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 200 mVp-p. Main-output voltage adjustment 45.6–50.4 V. Voltage tolerance ±1.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 94%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 52.8–62.4 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 58.5 mm; case 247A-D / 247B-T. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow The fitted top fan exhaust direction is shown in the TF mechanical drawing; preserve the top clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 580 g (0.58 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 14.9 kg / 0.86 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Top Fan - RPS-400-36-TF

  MEAN WELL RPS-400-36-TF is a 36 V medical AC/DC power supply in the enclosed casing with a top fan configuration. It supplies 11.2 A / 403.2 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-36-TF. TF: Enclosed casing with a top fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 36 V. Forced-air current and power 11.2 A / 403.2 W; Built-in top fan. Cooling configuration This TF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 200 mVp-p. Main-output voltage adjustment 34.2–37.8 V. Voltage tolerance ±1.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 94%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 39.6–46.8 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 58.5 mm; case 247A-D / 247B-T. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow The fitted top fan exhaust direction is shown in the TF mechanical drawing; preserve the top clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 580 g (0.58 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 14.9 kg / 0.86 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Top Fan - RPS-400-27-TF

  MEAN WELL RPS-400-27-TF is a 27 V medical AC/DC power supply in the enclosed casing with a top fan configuration. It supplies 14.9 A / 402.3 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-27-TF. TF: Enclosed casing with a top fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 27 V. Forced-air current and power 14.9 A / 402.3 W; Built-in top fan. Cooling configuration This TF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 200 mVp-p. Main-output voltage adjustment 25.6–28.4 V. Voltage tolerance ±1.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93.5%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 29.7–35.1 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 58.5 mm; case 247A-D / 247B-T. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow The fitted top fan exhaust direction is shown in the TF mechanical drawing; preserve the top clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 580 g (0.58 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 14.9 kg / 0.86 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Top Fan - RPS-400-24-TF

  MEAN WELL RPS-400-24-TF is a 24 V medical AC/DC power supply in the enclosed casing with a top fan configuration. It supplies 16.7 A / 400.8 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-24-TF. TF: Enclosed casing with a top fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 24 V. Forced-air current and power 16.7 A / 400.8 W; Built-in top fan. Cooling configuration This TF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 150 mVp-p. Main-output voltage adjustment 22.8–25.2 V. Voltage tolerance ±2.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 26.4–31.2 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 58.5 mm; case 247A-D / 247B-T. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow The fitted top fan exhaust direction is shown in the TF mechanical drawing; preserve the top clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 580 g (0.58 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 14.9 kg / 0.86 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Top Fan - RPS-400-18-TF

  MEAN WELL RPS-400-18-TF is an 18 V medical AC/DC power supply in the enclosed casing with a top fan configuration. It supplies 22.3 A / 401.4 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-18-TF. TF: Enclosed casing with a top fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 18 V. Forced-air current and power 22.3 A / 401.4 W; Built-in top fan. Cooling configuration This TF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 150 mVp-p. Main-output voltage adjustment 17.1–18.9 V. Voltage tolerance ±3.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 19.8–23.4 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 58.5 mm; case 247A-D / 247B-T. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow The fitted top fan exhaust direction is shown in the TF mechanical drawing; preserve the top clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 580 g (0.58 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 14.9 kg / 0.86 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Top Fan - RPS-400-15-TF

  MEAN WELL RPS-400-15-TF is a 15 V medical AC/DC power supply in the enclosed casing with a top fan configuration. It supplies 26.7 A / 400.5 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-15-TF. TF: Enclosed casing with a top fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 15 V. Forced-air current and power 26.7 A / 400.5 W; Built-in top fan. Cooling configuration This TF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 120 mVp-p. Main-output voltage adjustment 14.3–15.8 V. Voltage tolerance ±3.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 92%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 16.5–19.5 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 58.5 mm; case 247A-D / 247B-T. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow The fitted top fan exhaust direction is shown in the TF mechanical drawing; preserve the top clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 580 g (0.58 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 14.9 kg / 0.86 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $229.67

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply with Top Fan - RPS-400-12-TF

  MEAN WELL RPS-400-12-TF is a 12 V medical AC/DC power supply in the enclosed casing with a top fan configuration. It supplies 33.3 A / 399.6 W with its fitted fan. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-12-TF. TF: Enclosed casing with a top fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 12 V. Forced-air current and power 33.3 A / 399.6 W; Built-in top fan. Cooling configuration This TF version is rated with its built-in fan. The type-selection table does not assign a fanless convection mode to TF/SF. Ripple and noise, maximum 120 mVp-p. Main-output voltage adjustment 11.4–12.6 V. Voltage tolerance ±3.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 91.5%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 13.2–15.6 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. The external CN12 fan connector is excluded for TF/SF. The built-in fan control is specified as fan-on by 20% load minimum for TF/SF. Preserve the fitted fan and its airflow direction. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves With its built-in fan, the horizontal TF/SF curve holds nominal 400 W from −30 to 50°C, then falls to 150 W at 70°C. The catalogue does not provide a fanless convection mode for this version. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 58.5 mm; case 247A-D / 247B-T. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow The fitted top fan exhaust direction is shown in the TF mechanical drawing; preserve the top clearance and airflow path. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 580 g (0.58 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 14.9 kg / 0.86 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $213.41

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply, Enclosed - RPS-400-48-C

  MEAN WELL RPS-400-48-C is a 48 V medical AC/DC power supply in the enclosed casing without a built-in fan configuration. It supplies 5.3 A / 254.4 W by convection or 8.4 A / 403.2 W with 25 CFM airflow. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-48-C. C: Enclosed casing without a built-in fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 48 V. Forced-air current and power 8.4 A / 403.2 W; 25 CFM external airflow. Convection current and power 5.3 A / 254.4 W, subject to the input-voltage and temperature curves. Ripple and noise, maximum 200 mVp-p. Main-output voltage adjustment 45.6–50.4 V. Voltage tolerance ±1.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 94%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 52.8–62.4 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. Use the dedicated CN12 polarity below. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves The convection curve uses nominal 250 W up to 35°C at 115 VAC, then 130 W at 60°C; at 230 VAC it holds 250 W to 40°C, then 160 W at 60°C. With 25 CFM, the plotted nominal 400 W holds to 50°C and falls to 200 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 43 mm; case 247A. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow Use an external 25 CFM fan 5 cm from the unit in the direction shown in the mechanical drawing to obtain the forced-air rating. The catalogue does not state that this external fan is included. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Fan connector CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502 or equivalent; terminal TKP 8811 or equivalent. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 510 g (0.51 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 13.2 kg / 0.77 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $201.09

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply, Enclosed - RPS-400-36-C

  MEAN WELL RPS-400-36-C is a 36 V medical AC/DC power supply in the enclosed casing without a built-in fan configuration. It supplies 7 A / 252 W by convection or 11.2 A / 403.2 W with 25 CFM airflow. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-36-C. C: Enclosed casing without a built-in fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 36 V. Forced-air current and power 11.2 A / 403.2 W; 25 CFM external airflow. Convection current and power 7 A / 252 W, subject to the input-voltage and temperature curves. Ripple and noise, maximum 200 mVp-p. Main-output voltage adjustment 34.2–37.8 V. Voltage tolerance ±1.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 94%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 39.6–46.8 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. Use the dedicated CN12 polarity below. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves The convection curve uses nominal 250 W up to 35°C at 115 VAC, then 130 W at 60°C; at 230 VAC it holds 250 W to 40°C, then 160 W at 60°C. With 25 CFM, the plotted nominal 400 W holds to 50°C and falls to 200 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 43 mm; case 247A. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow Use an external 25 CFM fan 5 cm from the unit in the direction shown in the mechanical drawing to obtain the forced-air rating. The catalogue does not state that this external fan is included. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Fan connector CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502 or equivalent; terminal TKP 8811 or equivalent. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 510 g (0.51 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 13.2 kg / 0.77 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $201.09

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply, Enclosed - RPS-400-27-C

  MEAN WELL RPS-400-27-C is a 27 V medical AC/DC power supply in the enclosed casing without a built-in fan configuration. It supplies 9.3 A / 251.1 W by convection or 14.9 A / 402.3 W with 25 CFM airflow. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-27-C. C: Enclosed casing without a built-in fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 27 V. Forced-air current and power 14.9 A / 402.3 W; 25 CFM external airflow. Convection current and power 9.3 A / 251.1 W, subject to the input-voltage and temperature curves. Ripple and noise, maximum 200 mVp-p. Main-output voltage adjustment 25.6–28.4 V. Voltage tolerance ±1.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93.5%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 29.7–35.1 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. Use the dedicated CN12 polarity below. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves The convection curve uses nominal 250 W up to 35°C at 115 VAC, then 130 W at 60°C; at 230 VAC it holds 250 W to 40°C, then 160 W at 60°C. With 25 CFM, the plotted nominal 400 W holds to 50°C and falls to 200 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 43 mm; case 247A. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow Use an external 25 CFM fan 5 cm from the unit in the direction shown in the mechanical drawing to obtain the forced-air rating. The catalogue does not state that this external fan is included. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Fan connector CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502 or equivalent; terminal TKP 8811 or equivalent. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 510 g (0.51 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 13.2 kg / 0.77 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $201.09

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply, Enclosed - RPS-400-24-C

  MEAN WELL RPS-400-24-C is a 24 V medical AC/DC power supply in the enclosed casing without a built-in fan configuration. It supplies 10.5 A / 252 W by convection or 16.7 A / 400.8 W with 25 CFM airflow. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-24-C. C: Enclosed casing without a built-in fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 24 V. Forced-air current and power 16.7 A / 400.8 W; 25 CFM external airflow. Convection current and power 10.5 A / 252 W, subject to the input-voltage and temperature curves. Ripple and noise, maximum 150 mVp-p. Main-output voltage adjustment 22.8–25.2 V. Voltage tolerance ±2.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 26.4–31.2 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. Use the dedicated CN12 polarity below. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves The convection curve uses nominal 250 W up to 35°C at 115 VAC, then 130 W at 60°C; at 230 VAC it holds 250 W to 40°C, then 160 W at 60°C. With 25 CFM, the plotted nominal 400 W holds to 50°C and falls to 200 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 43 mm; case 247A. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow Use an external 25 CFM fan 5 cm from the unit in the direction shown in the mechanical drawing to obtain the forced-air rating. The catalogue does not state that this external fan is included. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Fan connector CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502 or equivalent; terminal TKP 8811 or equivalent. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 510 g (0.51 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 13.2 kg / 0.77 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $201.09

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply, Enclosed - RPS-400-18-C

  MEAN WELL RPS-400-18-C is an 18 V medical AC/DC power supply in the enclosed casing without a built-in fan configuration. It supplies 13.9 A / 250.2 W by convection or 22.3 A / 401.4 W with 25 CFM airflow. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-18-C. C: Enclosed casing without a built-in fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 18 V. Forced-air current and power 22.3 A / 401.4 W; 25 CFM external airflow. Convection current and power 13.9 A / 250.2 W, subject to the input-voltage and temperature curves. Ripple and noise, maximum 150 mVp-p. Main-output voltage adjustment 17.1–18.9 V. Voltage tolerance ±3.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 93%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 19.8–23.4 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. Use the dedicated CN12 polarity below. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves The convection curve uses nominal 250 W up to 35°C at 115 VAC, then 130 W at 60°C; at 230 VAC it holds 250 W to 40°C, then 160 W at 60°C. With 25 CFM, the plotted nominal 400 W holds to 50°C and falls to 200 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 43 mm; case 247A. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow Use an external 25 CFM fan 5 cm from the unit in the direction shown in the mechanical drawing to obtain the forced-air rating. The catalogue does not state that this external fan is included. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Fan connector CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502 or equivalent; terminal TKP 8811 or equivalent. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 510 g (0.51 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 13.2 kg / 0.77 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $201.09

  View options

•

  View options

  MEAN WELL RPS-400 series: Medical AC/DC Power Supply, Enclosed - RPS-400-15-C

  MEAN WELL RPS-400-15-C is a 15 V medical AC/DC power supply in the enclosed casing without a built-in fan configuration. It supplies 16.7 A / 250.5 W by convection or 26.7 A / 400.5 W with 25 CFM airflow. Select the installation class, load and operating temperature using the version-specific limits below. Product Datasheet Download MEAN WELL RPS-400 Datasheet (PDF) The RPS-400 section is on PDF pages 8, 9, 10, 11, 12, 13, 14, 15, 16, 17. Refer to the complete mechanical drawings and notes when planning installation. Model and Configuration Complete model RPS-400-15-C. C: Enclosed casing without a built-in fan. System class This enclosed version is not suitable for a Class II system without FG; use the Class I arrangement with FG. Integration use Medical power conversion for applications such as oral irrigators, hemodialysis equipment, medical monitors, sleep-apnea devices, pumps and electric beds. BF use requires appropriate complete-system consideration. Main DC Output Nominal main output 15 V. Forced-air current and power 26.7 A / 400.5 W; 25 CFM external airflow. Convection current and power 16.7 A / 250.5 W, subject to the input-voltage and temperature curves. Ripple and noise, maximum 120 mVp-p. Main-output voltage adjustment 14.3–15.8 V. Voltage tolerance ±3.0%, including set-up tolerance, line regulation and load regulation. Line / load regulation ±0.5% / ±1.0%. Efficiency, typical 92%. Use the exact model ratings above; the series designation is not a substitute for its printed wattage. Forced-air ratings are cooling-dependent continuous ratings, not an unrestricted overload or peak-power allowance. Unless specified otherwise, values are measured at 230 VAC, rated load and 25°C. Ripple/noise uses 20 MHz bandwidth and a 12-inch twisted pair terminated with parallel 0.1 µF and 47 µF capacitors. Input and Timing Input range 80–264 VAC or 113–370 VDC; 47–63 Hz AC. Apply the input derating curve. Power factor Built-in active PFC; at full load, PF >0.94 at 230 VAC and >0.98 at 115 VAC. Input current, typical 4.2 A at 115 VAC; 2.1 A at 230 VAC. Cold-start inrush, typical 35 A at 115 VAC; 70 A at 230 VAC. Set-up / rise time 1000 ms / 30 ms at 230 VAC; 1500 ms / 30 ms at 115 VAC, full load. Hold-up time, typical 16 ms at both 230 VAC and 115 VAC, full load. Leakage current Earth leakage <200 µA at 264 VAC / 50 Hz; touch current <70 µA at 264 VAC, measured from primary input to DC output. No-load power Less than 0.5 W by PS-ON control. Protection and Auxiliary Outputs Short circuit / overload Short-circuit protection; overload at 105–135% of rated output power. Hiccup mode recovers automatically after the fault is removed. Overvoltage Threshold 16.5–19.5 V; output shuts down and requires re-power on to recover. Overtemperature Output shuts down and recovers automatically after temperature decreases. 5 V standby 5 V, 0.6 A without a fan or 1 A with 25 CFM; tolerance ±2%, maximum ripple 120 mVp-p. These are cooling-qualified standby limits. 12 V fan supply 12 V / 0.5 A for driving a fan. Tolerance −15% to +10% at 35% main-output rated current with 25 CFM. Use the dedicated CN12 polarity below. Control, Status and Remote Sense PS-ON high (2–5 V) turns the main output on; low (0–0.5 V) turns it off. The PG TTL signal goes high 10–500 ms after power set-up and goes low at least 1 ms before output falls below 90% of its rated voltage, providing the listed power-good/power-fail indication. CN11: TKP DH2I-2X2 or equivalent; pin 1 −S, pin 2 +S, pin 3 DC COM, pin 4 PG. The −S/+S pins are the remote-sense connections; this section does not specify a numerical cable-drop compensation limit. Follow the complete connection and installation instructions. CN95: TKP DH2L-2X2 or equivalent; pin 1 5Vsb, pins 2 and 4 DC COM, pin 3 PS-ON. Both CN11 and CN95 list TKP DH2 or equivalent mating housings and TKP or equivalent terminals; the catalogue does not provide a more complete terminal ordering suffix. Cooling, Derating and Environment Horizontal temperature/load curves The convection curve uses nominal 250 W up to 35°C at 115 VAC, then 130 W at 60°C; at 230 VAC it holds 250 W to 40°C, then 160 W at 60°C. With 25 CFM, the plotted nominal 400 W holds to 50°C and falls to 200 W at 70°C. Input-voltage curve, 60 Hz 70% load at 80 VAC, 80% at 90 VAC, rising to 100% at 115 VAC and remaining at 100% through 264 VAC. Working ambient / humidity −30 to +70°C with derating; 20–90% RH, non-condensing. Convection curves for PCB/C end at 60°C; the 70°C point requires the plotted forced-air configuration. Storage −40 to +85°C; 10–95% RH, non-condensing. Temperature coefficient / vibration ±0.03%/°C over 0–50°C. Vibration: 10–500 Hz, 2 G, 10 minutes per cycle and 60 minutes each along X, Y and Z. Altitude Operating altitude up to 4000 m. Above 2000 m, reduce allowable ambient temperature by 3.5°C per 1000 m for fanless operation or 5°C per 1000 m for fan-cooled operation. The plotted curves use nominal series-level wattages. Apply them together with this exact model’s voltage/current/power ratings, its installed cooling arrangement and input derating; neither the curve nor the upper temperature permits exceeding the model rating. Dimensions and Installation Dimensions, L × W × H 130 × 86 × 43 mm; case 247A. Mounting and clearance Bottom: four M3 holes, 120 × 50 mm pattern, maximum penetration 2 mm (hole group 1). Side: two M3 holes, maximum penetration 4 mm (hole group 2). Use 4–6 kgf·cm mounting torque and the complete hole-location drawing. Airflow Use an external 25 CFM fan 5 cm from the unit in the direction shown in the mechanical drawing to obtain the forced-air rating. The catalogue does not state that this external fan is included. Board and adjustment references SVR1 is the main-output adjustment reference. FS1 is marked F8A/250V. HS1, HS2, HS3 and HS4 must not be shorted. Drawing units are millimetres with general tolerance ±1 mm unless separately marked. Use the full model-specific mechanical drawing for offsets and clearances; included screws, loose connectors and installation hardware are not stated. Power Connections and Mating Parts AC input CN1 JST B3P-VH or equivalent: pin 1 AC/L, pin 2 no pin, pin 3 AC/N. Mating housing: JST VHR or equivalent; terminal: JST SVH-21T-P1.1 or equivalent. VHR is the printed family reference, not an invented complete ordering suffix. Main DC output CN2: −V; CN3: +V. M3.5 pan-head screws at two positions; maximum torque 8 lbs-in (90 cNm), as printed. Fan connector CN12 TKP 8812-2 or equivalent: pin 1 DC COM, pin 2 +12 V. Mating housing TKP 2502 or equivalent; terminal TKP 8811 or equivalent. Mating-part references identify compatible interface components; they do not establish that loose mating parts are supplied. Choose the correct position count and terminal for each connection. Safety, Isolation and EMC Medical approvals IEC60601-1:2005+A1+A2; TUV BS EN/EN60601-1:2006+A1+A12+A2; ANSI/AAMI ES60601-1:2005+A2; CAN/CSA C22.2 No.60601-1:2014+A2; EAC TP TC004. BS EN/EN60335-1 is a design reference by request, not an unconditional additional approval. Isolation / withstand Primary-secondary: 2 × MOPP; primary-earth and secondary-earth: 1 × MOPP each. Withstand: input-output 4 kVAC, input-FG 2 kVAC, output-FG 1.5 kVAC. BF suitability depends on appropriate complete-system configuration. Insulation resistance Input-output and input-FG: 100 MΩ at 500 VDC, 25°C and 70% RH. Emissions BS EN/EN55011 (CISPR11). Use the Class I configuration with FG; the specification lists conducted and radiated Class B. Do not transfer the PCB-only Class II option to this enclosed version. Harmonic current: BS EN/EN61000-3-2 Class A; flicker: BS EN/EN61000-3-3. Immunity: BS EN/EN55035, BS EN/EN60601-1-2 and BS EN/EN61204-3. ESD (EN61000-4-2): level 4, 15 kV air / 8 kV contact. RF (-4-3): level 3, 10 V/m at 80 MHz–2.7 GHz; Table 9: 9–28 V/m at 385 MHz–5.78 GHz. EFT (-4-4): level 3, 2 kV; surge (-4-5): level 4, 4 kV line-FG / 2 kV line-line. Conducted susceptibility (-4-6): level 3, 10 V; magnetic field (-4-8): level 4, 30 A/m. Dips/interruption (-4-11): 100% dip for 1 period, 30% dip for 25 periods and 100% interruption for 250 periods. Class I EMC testing used a 360 × 360 × 1 mm metal plate. This is an installation component; re-confirm EMC compliance in the final equipment. Weight, Reliability and Catalogue Single-unit catalogue weight 510 g (0.51 kg), explicitly listed as P.W. in PACKING; a catalogue unit reference, not a measured shipping-parcel weight. Packing reference 24 pieces / 13.2 kg / 0.77 CUFT. Minimum MTBF estimates 1393.3 thousand hours, Telcordia SR-332 (Bellcore); 194.1 thousand hours, MIL-HDBK-217F at 25°C. These statistical estimates are not guaranteed service lives. Catalogue and warranty RPS-400-SPEC, 2024-11-22, combined PDF pages 8–17. Three-year manufacturer warranty, subject to applicable terms.

  Read more less

  $201.09
